Lenovo ThinkCentre M60q Chromebox User manual

ThinkCentre M60q Chromebox / ThinkCentre
M60q Chromebox Enterprise
User Guide

Read this first
Before using this documentation and the product it supports ensure that you read and understand the
following:
• Safety and Warranty Guide
• Generic Safety and Compliance Notices
• Setup Guide
First Edition (November 2022)
© Copyright Lenovo 2022.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services
Administration “GSA” contract use reproduction or disclosure is subject to restrictions set forth in Contract No. GS-
35F-05925.

Contents
Dis over your Lenovo Chromebox . . . iii
Chapter 1. Meet your Chromebox. . . . 1
Front . . . . . . . . . . . . . . . . . . . . 1
Rear . . . . . . . . . . . . . . . . . . . . 2
Features and specifications . . . . . . . . . . . 3
USB specifications . . . . . . . . . . . . . . 3
Chapter 2. Explore your
Chromebox. . . . . . . . . . . . . . . . 5
Connect an external display . . . . . . . . . . . 5
Use the keyboard shortcuts . . . . . . . . . . . 5
Lock your Chromebox . . . . . . . . . . . . . 6
Set the power plan . . . . . . . . . . . . . . 6
Purchase accessories . . . . . . . . . . . . . 7
Shut down your Chromebox . . . . . . . . . . . 7
Chapter 3. Help and support . . . . . . 9
Frequently asked questions . . . . . . . . . . . 9
Get help from Google . . . . . . . . . . . . 10
Call Lenovo . . . . . . . . . . . . . . . . 10
Before you contact Lenovo . . . . . . . . 10
Lenovo Customer Support Center . . . . . . 11
Chapter 4. CRU repla ement . . . . . 13
CRU list . . . . . . . . . . . . . . . . . . 13
Remove or replace a CRU . . . . . . . . . . . 14
Power adapter and power cord . . . . . . . 14
Power adapter bracket . . . . . . . . . . 15
VESA mount bracket . . . . . . . . . . . 16
Vertical stand . . . . . . . . . . . . . . 16
External Wi-Fi antenna . . . . . . . . . . 17
Front cover . . . . . . . . . . . . . . . 18
System fan and heat sink . . . . . . . . . 19
ThinkCentre LED cable . . . . . . . . . . 20
Reset board kit . . . . . . . . . . . . . 20
Board-to-Board module. . . . . . . . . . 21
Bottom cover . . . . . . . . . . . . . . 22
M.2 solid-state drive . . . . . . . . . . . 22
Memory module . . . . . . . . . . . . . 23
Appendix A. Complian e
information . . . . . . . . . . . . . . . 27
Appendix B. Noti es and
trademarks . . . . . . . . . . . . . . . 31
© Copyright Lenovo 2022 i

ii ThinkCentre M60q Chromebox / ThinkCentre M60q Chromebox Enterprise User Guide

Dis over your Lenovo Chromebox
Thank you for hoosing a Lenovo® Chromebox! We are dedi ated to delivering the best solution to
you.
Before starting your tour read the following information:
• Illustrations in this documentation might look different from your product.
• Depending on the model some optional accessories features software programs and user interface
instructions might not be applicable to your Chromebox.
• Documentation content is subject to change without notice. To get the latest documentation go to https://
pcsupport.lenovo.com.
© Copyright Lenovo 2022 iii

iv ThinkCentre M60q Chromebox / ThinkCentre M60q Chromebox Enterprise User Guide

Chapter 1. Meet your Chromebox
Front
Item Des ription Item Des ription
1 ThinkCentre® LED 2 Power button with power indicator
3Storage drive activity indicator 4USB-C® (3.2 Gen 2) monitor connector
5 USB-A 3.2 Gen 2 connectors 6 Headset connector
* for selected models
Statement on USB transfer rate
Depending on many factors such as the processing capability of the host and peripheral devices file
attributes and other factors related to system configuration and operating environments the actual transfer
rate using the various USB connectors on this device will vary and will be slower than the data rate listed
below for each corresponding device.
USB devi e Data rate (Gbit/s)
3.2 Gen 1 5
3.2 Gen 2 10
3.2 Gen 2 × 2 20
Thunderbolt 3 40
Thunderbolt 4 40
Related topi s
“USB specifications” on page 3.
© Copyright Lenovo 2022 1

Rear
Item Des ription Item Des ription
1Emergency reset hole 2Security-lock slot
3Optional connector* 4 Wi-Fi® antenna slot
5 Ethernet connector 6 USB-A 3.2 Gen 1 connectors
7 HDMI™ out connector 8 USB-A 3.2 Gen 1 connector
9DisplayPort™ out connector 10 Power adapter connector
* for selected models
Optional onne tor
Depending on the Chromebox model the connector might be a DisplayPort out connector a USB-C
connector or an HDMI™ out connector.
Related topi s
• “Lock your Chromebox” on page 6.
• “Connect an external display” on page 5.
• “USB specifications” on page 3.
2ThinkCentre M60q Chromebox / ThinkCentre M60q Chromebox Enterprise User Guide

Features and spe ifi ations
For detailed specifications of your Chromebox go to https://psref.lenovo.com.
Spe ifi ation Des ription
Dimensions
• Width: 179.0 mm (7.0 inches)
• Height: 36.5 mm (1.4 inches)
• Depth: 182.9 mm (7.2 inches)
Weight (without pa kaging) Maximum configuration as shipped: 1.07 kg (2.35 lb)
Power supply • 65-watt automatic voltage-sensing power supply
• 90-watt automatic voltage-sensing power supply
Ele tri al input • Input voltage: From 100 V ac to 240 V ac
• Input frequency: 50/60 Hz
Memory
Double data rate 4(DDR4) small outline dual in-line memory module (SODIMM)
Maximum memory capacity: 32 GB
Storage devi e M.2 solid-state drive*
Video features
The integrated graphics card supports the following:
• DisplayPort out connector
• HDMI out connector
• USB-C (3.2 Gen 2) monitor connector
Expansion • Memory slots
• M.2 solid-state drive slot*
Network features
• Bluetooth
• Ethernet LAN
• Wireless LAN
* for selected models
USB spe ifi ations
Note: Depending on the model some USB connectors might not be available on your Chromebox.
Chapter 1.Meet your Chromebox 3

Conne tor name Des ription
• USB-A 3.2 Gen 1 connector
• USB-A 3.2 Gen 2 connector
Connect USB-A compatible devices such as a USB-A
keyboard USB-A mouse USB-A storage device or USB-
A printer.
• USB-C (3.2 Gen 2) connector
• Charge USB-C compatible devices with the output
voltage and current of 5 V and 3 A.
• Connect to USB-C accessories to help expand your
Chromebox functionality. To purchase USB-C
accessories go to https://www.lenovo.com/accessories.
4ThinkCentre M60q Chromebox / ThinkCentre M60q Chromebox Enterprise User Guide

Chapter 2. Explore your Chromebox
Conne t an external display
Connect a projector or a monitor to your Chromebox to give presentations or expand your workspace.
Change display settings
1. Click the setting icon in the system tray and then click Devi e ➙ Displays.
2. Follow the on-screen instructions to change the display settings as you prefer.
Use the keyboard short uts
The function keys on the keyboard help you work more easily and effectively.
Fun tion key Fun tion
Refresh your current page.
Make the current window full screen.
Open the task view to see all your open windows.
Darken the display.
Brighten the display.
Mute the speakers.
Decrease the speaker volume.
Increase the speaker volume.
*Lock the screen.
*Turn on the Chromebox put it to sleep mode or wake it up.
* for selected models
Your Chromebox also supports some key combinations.
Short ut key Fun tion
alt + Go to the previous page.
alt + Go to the next page.
ctrl + Take a screenshot.
alt + Switch the letter case between the upper case and lower case.
l + Lock the screen.
ctrl + alt + ? View all keyboard shortcuts.
© Copyright Lenovo 2022 5

To change the keyboard settings:
1. Click the setting icon in the system tray and then click Devi e ➙ Keyboard.
2. Follow the on-screen instructions to change the settings as you prefer.
Lo k your Chromebox
Note: Lenovo makes no comments judgments or warranties about the function quality or performance of
the locking device and security feature. You can purchase the device from Lenovo.
Kensington-style able lo k
Lock your Chromebox to a desk table or other fixtures through a Kensington-style cable lock.
Set the power plan
For ENERGY STAR® compliant Chromebox the following power plan takes effect when your Chromebox has
been idle for a specified duration:
• Turn off the display: After seven minutes and thirty seconds
• Put the Chromebox to sleep: After eight minutes and thirty seconds
To awaken the Chromebox from Sleep mode press any key on your keyboard.
To reset the power plan:
1. Click the setting icon in the system tray and then click Devi e ➙ Power.
2. Follow the on-screen instructions to change the settings as you prefer.
6ThinkCentre M60q Chromebox / ThinkCentre M60q Chromebox Enterprise User Guide

Pur hase a essories
Lenovo has a number of hardware accessories and upgrades to help expand the capabilities of your
Chromebox. Options include memory modules storage devices network cards power adapters keyboards
mice and more.
To shop at Lenovo go to https://www.lenovo.com/accessories.
Shut down your Chromebox
When you finish working with your Chromebox shut it down to save power.
• Click in the system tray.
• Press the power button.
Chapter 2.Explore your Chromebox 7

8ThinkCentre M60q Chromebox / ThinkCentre M60q Chromebox Enterprise User Guide

Chapter 3. Help and support
Frequently asked questions
What do I do if my Chromebox
stops responding?
1. Press and hold the power button until the Chromebox turns off. Then restart
the Chromebox.
2. If step 1 does not work:
• Insert a straightened paper clip into the emergency reset hole to cut off
power supply temporarily. Then restart the Chromebox with ac power
connected.
What do I do if I spill liquid on the
Chromebox?
1. Carefully unplug the ac power adapter and turn off the Chromebox
immediately. The more quickly you stop the current from passing through the
Chromebox the more likely you will reduce damage from short circuits.
Attention: Although you might lose some data or work by turning off the
Chromebox immediately leaving the Chromebox on might make your
Chromebox unusable.
2. Do not try to drain out the liquid by turning over the Chromebox. If your
Chromebox has keyboard drainage holes on the bottom the liquid will be
drained out through the holes.
3. Wait until you are certain that all the liquid is dry before turning on your
Chromebox.
How do I disinfect my
Chromebox?
1. Squeeze out excess liquid from wipe or disinfecting cloth before using.
Recommended wipes are hydrogen peroxide wipes and alcohol based wipes.
Do not use wipes containing sodium hypochlorite (bleach).
2. Gently wipe the Chromebox thoroughly being careful to ensure no liquid
drips into the Chromebox. Do not wipe on connector pins.
3. After disinfecting follow the cleaning procedure from the wipe supplier to
minimize chemical buildup of disinfectant residue.
4. Always allow the Chromebox to completely dry prior to any use.
For more information about cleaning and disinfecting go to https://
support.lenovo.com/in/en/solutions/ht035676.
How do I find accessibility
information? https://www.lenovo.com/accessibility
What app works on a
Chromebox?
Chromeboxes use apps from the Google Play Store and on the Web page instead
of traditional apps. There are apps to be productive get creative enjoy movies
and shows play games and more.
How do I get more apps? Download Chromebox apps from the Google Play Store app. Find the app by
clicking the Launcher icon and searching Play Store.
Can I use Microsoft Office
software?
Chromeboxes work with Microsoft® Word Excel® and PowerPoint®. You can
download the apps from the Google Play Store or use them on the Web page.
Additional functionality available with a Microsoft 365 subscription.
Where can I find my files? All your files are stored in the Files app. Find the app by clicking the Launcher icon
and searching Files.
How do I transfer my local files?
Transfer your local files using a compatible storage device. Your Chromebox
works with most external storage devices such as a USB key or removable hard
disk drive.
© Copyright Lenovo 2022 9

Why does my Chromebox need
my Google Account information?
You will use your Google Account to sign in to your Chromebox. It is the same
account you use for Google services such as Gmail and Drive. Your Chromebox
uses your account information to sign you into apps and services automatically.
How do I set up this Chromebox
for my child?
If you want to set up parental controls for your child it is important that you sign in
using your child’s personal Google Account. If they do not have one yet you can
create one during the sign-in process on your Chromebox.
Get help from Google
After signing in to your Chromebox start Get Help from the app Launcher. The Get Help app provides
comprehensive instructions on using your Chromebox.
In addition if you are interested in visiting the Chromebox Help Center and Community go to http://
google.com/support/chromebook.
Note: The instructions concerning Chrome OS is applicable to those of your Chromebox.
Call Lenovo
If you have tried to correct the problem yourself and still need help you can call Lenovo Customer Support
Center.
Before you onta t Lenovo
Prepare the following before you contact Lenovo:
1. Record the problem symptoms and details:
• What is the problem? Is it continuous or intermittent?
• Any error message or error code?
• What operating system are you using? Which version?
• Which software applications were running at the time of the problem?
• Can the problem be reproduced? If so how?
2. Record the system information:
• Product name
• Machine type and serial number
The following illustration shows where to find the machine type and serial number of your
Chromebox.
10 ThinkCentre M60q Chromebox / ThinkCentre M60q Chromebox Enterprise User Guide

Lenovo Customer Support Center
During the warranty period you can call Lenovo Customer Support Center for help.
Telephone numbers
For a list of the Lenovo Support phone numbers for your country or region go to:
https://pcsupport.lenovo.com/supportphonelist
Note: Phone numbers are subject to change without notice. If the number for your country or region is not
provided contact your Lenovo reseller or Lenovo marketing representative.
Servi es available during the warranty period
• Problem determination - Trained personnel are available to assist you with determining if you have a
hardware problem and deciding what action is necessary to fix the problem.
• Lenovo hardware repair - If the problem is determined to be caused by Lenovo hardware under warranty
trained service personnel are available to provide the applicable level of service.
• Engineering change management - Occasionally there might be changes that are required after a product
has been sold. Lenovo or your reseller if authorized by Lenovo will make selected Engineering Changes
(ECs) that apply to your hardware available.
Servi es not overed
• Replacement or use of parts not manufactured for or by Lenovo or nonwarranted parts
• Identification of software problem sources
• Configuration of UEFI BIOS as part of an installation or upgrade
• Changes modifications or upgrades to device drivers
• Installation and maintenance of network operating systems (NOS)
• Installation and maintenance of programs
For the terms and conditions of the Lenovo Limited Warranty that apply to your Lenovo hardware product
see Safety and Warranty Guide that comes with your Chromebox.
Chapter 3.Help and support 11

12 ThinkCentre M60q Chromebox / ThinkCentre M60q Chromebox Enterprise User Guide

Chapter 4. CRU repla ement
Customer Replaceable Units (CRUs) are parts that can be upgraded or replaced by the customer. Lenovo
Chromeboxes contain the following types of CRUs:
• Self-servi e CRUs: Refer to parts that can be installed or replaced easily by customer themselves or by
trained service technicians at an additional cost.
• Optional-servi e CRUs: Refer to parts that can be installed or replaced by customers with a greater skill
level. Trained service technicians can also provide service to install or replace the parts under the type of
warranty designated for the customer’s machine.
If you intend on installing the CRU Lenovo will ship the CRU to you. CRU information and replacement
instructions are shipped with your product and are available from Lenovo at any time upon request. You
might be required to return the defective part that is replaced by the CRU. When return is required: (1) return
instructions a prepaid shipping label and a container will be included with the replacement CRU; and (2) you
might be charged for the replacement CRU if Lenovo does not receive the defective CRU within thirty (30)
days of your receipt of the replacement CRU. For full details see the Lenovo Limited Warranty
documentation at:
https://www.lenovo.com/warranty/llw_02
CRU list
The following is the CRU list of your Chromebox.
Self-servi e CRUs
• Bottom cover
• External adapter cage*
• External antenna*
• Front cover
• Keyboard*
• Memory module
• Mouse*
• Power adapter
• Power cord
• Vertical stand*
• VESA mount bracket kit*
Optional-servi e CRUs
• Board-to-Board module*
• M.2 solid-state drive*
• Reset board kit
• System fan and heat sink
• ThinkCentre LED cable
* for selected models
© Copyright Lenovo 2022 13

Remove or repla e a CRU
This section provides instructions on how to remove or replace a CRU.
Power adapter and power ord
Prerequisite
Before you start read Generic Safety and Compliance Notices and print the following instructions.
For access do the following:
1. Turn off the Chromebox and remove all connected devices and cables.
2. Disconnect the Chromebox from ac power and all connected cables.
Removal steps
14 ThinkCentre M60q Chromebox / ThinkCentre M60q Chromebox Enterprise User Guide
