Lenovo V530-15ICB Owner's manual

V530-15ICB User Guide and Hardware
Maintenance Manual
Energy Star Machine Types: 10TV, 10TW, 10XS, and 10XT

Note: Be ore using this in ormation and the product it supports, be sure to read and understand the
Important Product Information Guide and Appendix A “Notices” on page 57.
First Edition (May 2018)
© Copyright Leno o 2018.
LIMITED AND RESTRICTED RIGHTS NOTICE: I data or so tware is delivered pursuant to a General Services
Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set orth in Contract No. GS-
35F-05925.

Contents
Chapter 1. O er iew. . . . . . . . . . . 1
Front view . . . . . . . . . . . . . . . . . . 1
Rear view . . . . . . . . . . . . . . . . . . 3
System board . . . . . . . . . . . . . . . . 5
Machine type and model label . . . . . . . . . . 6
Chapter 2. Specifications . . . . . . . . 7
Chapter 3. Computer locks . . . . . . . 9
Locking the computer cover . . . . . . . . . . . 9
Attaching a Kensington-style cable lock . . . . . 10
Chapter 4. Replacing hardware . . . . 11
Be ore replacing hardware . . . . . . . . . . 11
Knowing FRUs (including CRUs) . . . . . . . . 11
Locating FRUs (including CRUs) . . . . . . . . 12
Removing the computer cover . . . . . . . . . 14
Replacing the ront bezel . . . . . . . . . . . 15
Replacing the optical drive . . . . . . . . . . 16
Replacing the optical drive bracket . . . . . . . 17
Pivoting the drive bay assembly upward and
downward . . . . . . . . . . . . . . . . . 18
Replacing the storage drive . . . . . . . . . . 19
Replacing a memory module. . . . . . . . . . 22
Replacing the heat sink and an assembly . . . . 24
Replacing the coin-cell battery . . . . . . . . . 25
Replacing a PCI Express card . . . . . . . . . 28
Replacing the Wi-Fi card . . . . . . . . . . . 29
Replacing the M.2 solid-state drive . . . . . . . 33
Replacing the M.2 solid-state drive bracket . . . . 36
Replacing the power supply assembly . . . . . . 37
Replacing the internal speaker . . . . . . . . . 39
Replacing the thermal sensor . . . . . . . . . 40
Replacing the ront an . . . . . . . . . . . . 41
Replacing the Wi-Fi antennas . . . . . . . . . 42
Replacing the power button board . . . . . . . 44
Replacing the card reader . . . . . . . . . . . 47
Replacing the microprocessor . . . . . . . . . 49
Replacing the rear an . . . . . . . . . . . . 53
Replacing the system board . . . . . . . . . . 54
Completing the parts replacement . . . . . . . 55
Appendix A. Notices . . . . . . . . . . 57
Appendix B. Trademarks . . . . . . . 59
© Copyright Lenovo 2018 i

ii V530-15ICB User Guide and Hardware Maintenance Manual

Chapter 1. O er iew
This chapter provides basic in ormation to help you get amiliar with your computer.
Front iew
Note: Your computer model might look slightly di erent rom the illustration.
Figure 1. Front view
1 Optical drive eject/close button 2 Optical drive activity indicator
3 Internal speaker (optional) 4 Card reader slot (optional)
5 Power indicator 6 Power button
7 Microphone connector 8 Headphone connector
9 USB 3.1 Gen 1 connectors (4) 10 USB 3.1 Gen 2 connectors (2)
11 Storage drive activity indicator
1 Optical dri e eject/close button
Used to eject the tray o the optical drive. A ter you insert a disc into the tray, press the eject/close button to
close the tray.
© Copyright Lenovo 2018 1

2 Optical dri e acti ity indicator
This indicator is on when the optical drive is in use.
3 Internal speaker
Used to listen to the sounds rom your computer without using a headset or headphones.
4 Card reader slot
Used to read data rom a supported memory card.
5 Power indicator
This indicator is on when the computer is on.
6 Power button
Used to turn on your computer. When you cannot shut down the computer rom the operating system, press
and hold the power button or our or more seconds to turn o the computer.
7 Microphone connector
Used to connect a microphone to your computer when you want to record sound or interact with the
computer using speech recognition so tware.
8 Headphone connector
Used to connect headphones to your computer.
9 USB 3.1 Gen 1 connector
Used to connect a USB-compatible device. For optimal data trans er, connect a USB 3.1 Gen 1 device to a
USB 3.1 Gen 2 or USB 3.1 Gen 1 connector instead o a USB 2.0 connector.
10 USB 3.1 Gen 2 connector
Used to connect a USB-compatible device. For optimal data trans er, connect a USB 3.1 Gen 2 device to a
USB 3.1 Gen 2 connector instead o a USB 3.1 Gen 1 or USB 2.0 connector.
11 Storage dri e acti ity indicator
This indicator is on when the storage drive is in use.
2V530-15ICB User Guide and Hardware Maintenance Manual

Rear iew
Note: Your computer model might look slightly di erent rom the illustration.
Figure 2. Rear view
1 Microphone connector 2 VGA-out connector
3 DisplayPort® 1.2 out connector 4 HDMITM 1.4 out connector
5 USB 2.0 connectors (4) 6 Audio line-out connector
7 Audio line-in connector 8 Serial connector
9 Ethernet connector 10 Serial connector (optional)
11 PCI-Express card area 12 Padlock loop
13 Security-lock slot 14 Power cord connector
1 Microphone connector
Used to connect a microphone to your computer when you want to record sound or interact with the
computer using speech recognition so tware.
2 VGA-out connector
Used to send video signals rom the computer to another video device, such as a monitor.
Chapter 1.Overview 3

3 DisplayPort 1.2 out connector
Used to send audio and video signals rom the computer to another audio or video device, such as a high-
per ormance monitor.
4 HDMI 1.4 out connector
Used to send audio and video signals rom the computer to another audio or video device, such as a high-
per ormance monitor.
5 USB 2.0 connector
Used to connect a device that requires a USB 2.0 connection.
6 Audio line-out connector
Used to send audio signals rom the computer to external devices, such as powered stereo speakers,
headphones, or multimedia keyboards. To connect a stereo system or other external recording device,
connect a cable between the audio line-in connector o the device and the audio line-out connector o the
computer.
Note: I your computer has both an audio line-out connector and a headset or headphone connector, always
use the headset connector or headphone connector or earphones, headphones, or a headset. The
headphone connector does not support headset microphones.
7 Audio line-in connector
Used to receive audio signals rom an external audio device, such as a stereo system. To connect an external
audio device, connect a cable between the audio line-out connector o the device and the audio line-in
connector o the computer.
8 Serial connector
Used to connect an external modem, a serial printer, or other devices that use a serial connector.
9 Ethernet connector
Used to connect an Ethernet cable or network access.
10 Serial connector (optional)
Used to connect an external modem, a serial printer, or other devices that use a serial connector.
11 PCI-Express card area
To improve the operating per ormance o the computer, you can connect PCI-Express cards into this area.
Depending on the computer model, the connectors in this area vary.
12 Padlock loop
Used to secure a padlock.
13 Security-lock slot
Used to secure a Kensington-style cable lock.
14 Power cord connector
4V530-15ICB User Guide and Hardware Maintenance Manual

Used to connect the power cord to your computer or power supply.
System board
Note: See “Front view” and “Rear view” or additional component descriptions.
Figure 3. System board
1 4-pin power connector 2 Microprocessor an connector
3 Buzzer 4 Auxiliary an connector 2
5 Memory slot (DIMM2) 6 Memory slot (DIMM4)
7 Power button board connector 8 Internal speaker connector
9 10-pin power connector 10 SATA power connectors (2)
11 Auxiliary an connector 1 12 Clear CMOS /Recovery jumper
13 SATA 3.0 connectors (3) 14 M.2 solid-state drive slot
15 M.2 Wi-Fi card slot 16 PCH
17 Thermal sensor connector 18 Front USB 2.0 connector 1 (card reader connector)
19 Parallel connector 20 Serial (COM2) connector
21 PCI Express x1 card slot 22 PCI Express x16 graphics card slot
23 Coin-cell battery 24 System an connector
25 Microprocessor socket
Chapter 1.Overview 5

Machine type and model label
The machine type and model label identi ies the computer. When you contact Lenovo or help, the machine
type and model in ormation helps support technicians to identi y the computer and provide aster service.
The machine type and model label is attached on the computer as shown.
Figure 4. achine type and model label
6V530-15ICB User Guide and Hardware Maintenance Manual

Chapter 2. Specifications
Power supply
180-watt automatic voltage-sensing power supply
Storage dri es
• 3.5-inch storage drive
• 2.5-inch storage drive
• M.2 solid-state drive
Video features
• The integrated graphics card supports the ollowing:
– DisplayPort 1.2 out connector
– HDMI 1.4 out connector
– VGA-out connector
• The optional discrete graphics card provides an enhanced video experience and extended capabilities.
Audio features
• The integrated audio card supports the ollowing:
– Audio line-in connector
– Audio line-out connector
– Headphone connector
– Internal speaker (optional)
– Microphone connector
• The optional discrete audio card provides an enhanced audio experience and extended capabilities.
Input/Output (I/O) features
• Audio connectors (audio line-in, audio line-out, headphone, and microphone)
• Card reader slot (optional)
• Display connectors (DisplayPort 1.2 out, HDMI 1.4 out, and VGA-out)
• Ethernet connector
• Serial connector
• USB connector
Expansion
• Card reader (optional)
• Memory slot
• M.2 solid-state drive slot
• Optical drive
• PCI Express x1 card slot
• PCI Express x16 graphics card slot
• Storage drive bay
© Copyright Lenovo 2018 7

Network features
• Ethernet LAN
• Wireless LAN (optional)
• Bluetooth (optional)
Physical dimensions
• Width: 145.0 mm (5.7 inches)
• Height: 366.0 mm (14.4 inches)
• Depth: 276.0 mm (10.9 inches)
Weight (without the package)
Maximum con iguration as shipped: 6.2 kg (13.7 lb)
8V530-15ICB User Guide and Hardware Maintenance Manual

Chapter 3. Computer locks
This chapter provides instructions on how to lock your computer with the locking devices to keep your
computer sa e.
Locking the computer co er
Locking the computer cover helps prevent unauthorized access to the inside o your computer. Your
computer eatures a padlock loop so that the computer cover cannot be removed when a padlock is
installed.
Figure 5. Locking the computer cover
© Copyright Lenovo 2018 9

Attaching a Kensington-style cable lock
You can use a Kensington-style cable lock to secure your computer to a desk, table, or other nonpermanent
ixture. The cable lock connects to the security-lock slot at the rear o your computer. Depending on the type
selected, the cable lock can be operated with a key or a combination. The cable lock also locks the buttons
used to open the computer cover. This is the same type o lock used with many notebook computers. You
can order such a cable lock directly rom Lenovo by searching or Kensington at:
http://www.lenovo.com/support
Figure 6. Attaching a Kensington-style cable lock
10 V530-15ICB User Guide and Hardware Maintenance Manual

Chapter 4. Replacing hardware
This chapter provides instructions on how to replace hardware or your computer.
Before replacing hardware
Attention: Do not open your computer or attempt any repairs be ore reading this section and the Important
Product Information Guide.
Notes before replacing hardware
• Use computer components provided only by Lenovo.
• When installing or replacing an option, use the appropriate instructions explained in this manual along with
the instructions that come with the option.
• In most areas o the world, Lenovo requires the return o de ective CRUs. In ormation about this will come
with the CRU or will come a ew days a ter the CRU arrives.
Handling static-sensiti e de ices
Do not open the static-protective package containing the new part until the de ective part has been removed
and you are ready to install the new part. Static electricity, although harmless to you, can seriously damage
computer components and options.
When you handle options and other computer components, take these precautions to avoid static-electricity
damage:
• Limit your movement. Movement can cause static electricity to build up around you.
• Always handle options and other computer components care ully. Handle PCI/PCIe cards, memory
modules, system boards, and microprocessors by the edges. Never touch any exposed circuitry.
• Prevent others rom touching the options and other computer components.
• Touch the static-protective package containing the part to a metal expansion-slot cover or other
unpainted metal sur ace on the computer or at least two seconds. This reduces static electricity rom the
package and your body be ore you install or replace a new part.
• When possible, remove the new part rom the static-protective package, and install it directly in the
computer without setting the part down. When this is not possible, place the static-protective package on
a smooth, level sur ace and place the part on the package.
• Do not place the part on the computer cover or other metal sur ace.
Knowing FRUs (including CRUs)
• Field Replaceable Units (FRUs) are computer parts that a trained technician can upgrade or replace. FRUs
include all CRUs. For detailed FRU in ormation, such as the FRU part numbers and supported computer
models, go to:
http://www.lenovo.com/serviceparts-lookup
• Customer Replaceable Units (CRUs) are computer parts that a user can upgrade or replace.
– Sel -service CRUs: You can install sel -service CRUs easily. These CRUs might be stand-alone,
latched, or secured by up to two screws. Examples o sel -service CRUs include the keyboard, mouse,
any USB device. You are responsible or replacing all sel -service CRUs.
– Optional-service CRUs: Handling optional-service CRUs requires some technical skills and simple tools
(such as a screwdriver). These CRUs are isolated parts within the computer. They are usually
© Copyright Lenovo 2018 11

concealed by an access panel that is secured by more than two screws. You must remove the screws
and panel to access the speci ic CRU. Optional-service CRUs can be removed and installed by users
or, during the warranty period, by a Lenovo service technician.
Before replacing FRUs
Be ore replacing any FRU, read the ollowing:
• Only certi ied and trained personnel can service the computer.
• Be ore replacing an FRU, read the entire section about replacing the part.
• Be extremely care ul during writing operations such as copying, saving, or ormatting.
The sequence o the drives in the computer that you are servicing might have been altered. I you select
an incorrect drive, data or programs might be overwritten.
• Replace an FRU only with another FRU o the correct model.
When you replace an FRU, ensure that the model o the machine and the FRU part number are correct.
• An FRU should not be replaced because o a single, unreproducible ailure.
Single ailures can occur or a variety o reasons that have nothing to do with a hardware de ect, such as
cosmic radiation, electrostatic discharge, or so tware errors. Consider replacing an FRU only when a
problem recurs. I you suspect that an FRU is de ective, clear the error log and run the test again. I the
error does not recur, do not replace the FRU.
• Only replace a de ective FRU.
Locating FRUs (including CRUs)
Notes:
• Sel -service CRUs: 1, 6, 8, 10 , 11 , 19 , 20 , 21 , 22 , 23 , 24 , 25 , 27 , 28 , 32
• Optional-service CRUs: 2, 4, 5, 30
• Some o the ollowing components are optional.
• To replace a component that is not in the list below, contact a Lenovo service technician. For a list o
Lenovo Support phone numbers, go to:
http://www.lenovo.com/support/phone
12 V530-15ICB User Guide and Hardware Maintenance Manual

Figure 7. Locating FRUs (including CRUs)
1 Computer cover 2 Heat sink and an assembly
3 Rear an 4 Wi-Fi card
5 Wi-Fi card shield 6 Coin-cell battery
7 Microprocessor 8 Memory module
9 System board 10 M.2 solid-state drive
11 M.2 solid-state drive bracket 12 Power button board
13 Optical drive cable 14 Card reader
15 Internal speaker 16 Wi-Fi antennas (2)
17 Rear Wi-Fi antenna cover 18 Thermal sensor
Chapter 4.Replacing hardware 13

19 Optical drive bracket 20 Optical drive
21 Front bezel 22 Card reader slot cover
23 Keyboard 24 Mouse
25 Power cord 26 Storage drive cable
27 Storage converter 28 Primary or secondary storage drive (a 2.5-inch or 3.5-
inch storage drive)
29 Front an 30 Power supply assembly
31 Chassis 32 PCI Express card
Remo ing the computer co er
Attention: Do not open your computer or attempt any repairs be ore reading the Important Product
Information Guide.
CAUTION:
Before you open the computer co er, turn off the computer and wait se eral minutes until the
computer is cool.
1. Remove any media rom the drives and turn o all connected devices and the computer.
2. Disconnect all power cords rom electrical outlets and disconnect all cables rom the computer.
3. Unlock any locking device that secures the computer cover.
4. Remove the computer cover.
Figure 8. Removing the computer cover
5. Complete the replacement. See “Completing the parts replacement” on page 55.
14 V530-15ICB User Guide and Hardware Maintenance Manual

Replacing the front bezel
Attention: Do not open your computer or attempt any repairs be ore reading the Important Product
Information Guide.
1. Remove the computer cover. See “Removing the computer cover” on page 14.
2. Replace the ront bezel.
Figure 9. Removing the front bezel
Figure 10. Installing the front bezel
3. Complete the replacement. See “Completing the parts replacement” on page 55.
Chapter 4.Replacing hardware 15

Replacing the optical dri e
Attention: Do not open your computer or attempt any repairs be ore reading the Important Product
Information Guide.
1. Remove the computer cover. See “Removing the computer cover” on page 14.
2. Remove the ront bezel. See “Replacing the ront bezel” on page 15.
3. Disconnect the signal cable and the power cable rom the optical drive.
4. Replace the optical drive.
Figure 11. Removing the optical drive
Figure 12. Installing the optical drive
5. Connect the signal cable and the power cable to the new optical drive.
16 V530-15ICB User Guide and Hardware Maintenance Manual
