Lenovo V530S-07ICB Owner's manual

V530S-07ICB User Guide and Hardware
Maintenance Manual
Energy Star Machine Types: 10TX, 10T , 10XV, and 10XW

Note: Before using this information and the product it supports, be sure to read and understand the
Important Product Information Guide and Appendix A “Notices” on page 47.
First Edition (July 2018)
Copyright Lenovo 2018.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services
Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-
35F-05925.

Contents
Chapter 1. Overview . . . . . . . . . . . 1
Front view . . . . . . . . . . . . . . . . . . 1
Rear view . . . . . . . . . . . . . . . . . . 3
System board . . . . . . . . . . . . . . . . 5
Machine type and model label . . . . . . . . . . 6
Chapter 2. Specifications . . . . . . . . 7
Chapter 3. Computer locks . . . . . . . 9
Chapter 4. Replacing hardware . . . . 11
Before replacing hardware . . . . . . . . . . 11
Knowing FRUs (including CRUs) . . . . . . . . 11
Locating FRUs (including CRUs) . . . . . . . . 12
Removing the computer cover . . . . . . . . . 14
Replacing the front bezel . . . . . . . . . . . 14
Replacing the optical drive . . . . . . . . . . 15
Replacing the storage drive . . . . . . . . . . 17
Replacing the card reader . . . . . . . . . . . 21
Replacing the storage drive activity indicator . . . 23
Replacing the internal speaker . . . . . . . . . 23
Replacing the thermal sensor . . . . . . . . . 24
Replacing the Wi-Fi card . . . . . . . . . . . 25
Replacing the Wi-Fi antennas . . . . . . . . . 27
Replacing the M.2 solid-state drive . . . . . . . 30
Replacing the coin-cell battery . . . . . . . . . 32
Replacing a memory module. . . . . . . . . . 34
Replacing the heat sink and fan assembly . . . . 36
Replacing the microprocessor . . . . . . . . . 37
Replacing a PCI Express card . . . . . . . . . 41
Replacing the power supply assembly . . . . . . 42
Replacing the system board . . . . . . . . . . 44
Completing the parts replacement . . . . . . . 45
Appendix A. Notices . . . . . . . . . . 47
Appendix B. Trademarks . . . . . . . 49
© Copyright Lenovo 2018 i

ii V530S-07ICB User Guide and Hardware Maintenance Manual

Chapter 1. Overview
This chapter provides basic information to help you get familiar with your computer.
Front view
Note: our computer model might look slightly different from the illustration.
Figure 1. Front view
1 Optical drive eject/close button 2 Optical drive activity indicator
3 Card reader slot (optional) 4 Storage drive activity indicator
5 Power indicator 6 Power button
7 Microphone connector 8 Headset connector (also known as combo audio jack)
9 USB 3.1 Gen 1 connectors (2) 10 USB 3.1 Gen 2 connectors (2)
1 Optical drive eject/close button
Used to eject the tray of the optical drive. After you insert a disc into the tray, press the eject/close button to
close the tray.
© Copyright Lenovo 2018 1

2 Optical drive activity indicator
This indicator is on when the optical drive is in use.
3 Card reader slot
Used to read data from a supported memory card.
4 Storage drive activity indicator
This indicator is on when the storage drive is in use.
5 Power indicator
This indicator is on when the computer is on.
6 Power button
Used to turn on your computer. When you cannot shut down the computer from the operating system, press
and hold the power button for four or more seconds to turn off the computer.
7 Microphone connector
Used to connect a microphone to your computer when you want to record sound or interact with the
computer using speech recognition software.
8 Headset connector
Used to connect a headset or headphones to your computer.
9 USB 3.1 Gen 1 connector
Used to connect a USB-compatible device. For optimal data transfer, connect a USB 3.1 Gen 1 device to a
USB 3.1 Gen 2 or USB 3.1 Gen 1 connector instead of a USB 2.0 connector.
10 USB 3.1 Gen 2 connector
Used to connect a USB-compatible device. For optimal data transfer, connect a USB 3.1 Gen 2 device to a
USB 3.1 Gen 2 connector instead of a USB 3.1 Gen 1 or USB 2.0 connector.
2V530S-07ICB User Guide and Hardware Maintenance Manual

Rear view
Note: our computer model might look slightly different from the illustration.
Figure 2. Rear view
1 Audio line-out connector 2 HDMITM 1.4 out connector
3 DisplayPort® 1.2 out connector 4 VGA-out connector
5 USB 2.0 connectors (2) 6 USB 3.1 Gen 1 connectors (2)
7 Power cord connector 8 Serial connector
9 Ethernet connector 10 Smart cable clip slots (3)
11 Padlock loop 12 Security-lock slot
13 Serial connector (optional) 14 PCI-Express card area
1 Audio line-out connector
Used to send audio signals from the computer to external devices, such as powered stereo speakers,
headphones, or multimedia keyboards. To connect a stereo system or other external recording device,
connect a cable between the audio line-in connector of the device and the audio line-out connector of the
computer.
Chapter 1.Overview 3

Note: If your computer has both an audio line-out connector and a headset or headphone connector, always
use the headset or headphone connector for earphones, headphones, or a headset. The headphone
connector does not support headset microphones.
2 HDMI 1.4 out connector
Used to send audio and video signals from the computer to another audio or video device, such as a high-
performance monitor.
3 DisplayPort 1.2 out connector
Used to send audio and video signals from the computer to another audio or video device, such as a high-
performance monitor.
4 VGA-out connector
Used to send video signals from the computer to another video device, such as a monitor.
5 USB 2.0 connector
Used to connect a device that requires a USB 2.0 connection.
6 USB 3.1 Gen 1 connector
Used to connect a USB-compatible device. For optimal data transfer, connect a USB 3.1 Gen 1 device to a
USB 3.1 Gen 2 or USB 3.1 Gen 1 connector instead of a USB 2.0 connector.
7 Power cord connector
Used to connect the power cord to your computer for power supply.
8 Serial connector
Used to connect an external modem, a serial printer, or other devices that use a serial connector.
9 Ethernet connector
Used to connect an Ethernet cable for network access.
10 Smart cable clip slots
Used to secure a smart cable clip.
11 Padlock loop
Used to secure a padlock.
12 Security-lock slot
Used to secure a Kensington-style cable lock.
13 Serial connector
Used to connect an external modem, a serial printer, or other devices that use a serial connector.
14 PCI-Express card area
4V530S-07ICB User Guide and Hardware Maintenance Manual

To improve the operating performance of the computer, you can connect PCI-Express cards into this area.
Depending on the computer model, the connectors in this area vary.
System board
Note: See “Front view” and “Rear view” for additional component descriptions.
Figure 3. System board
1 4-pin power connector 2 Microprocessor socket
3 Microprocessor fan connector 4 Coin-cell battery
5 Buzzer 6 Memory slot (DIMM1)
7 Memory slot (DIMM2) 8 6-pin power connector
9 Internal speaker connector 10 Clear CMOS /Recovery jumper
11 Storage drive activity indicator connector 12 Thermal sensor connector
13 M.2 solid-state drive slot 14 M.2 Wi-Fi card slot
15 SATA connector (connecting to the storage drive) 16 SATA power connector
17 SATA connector (connecting to the optical drive) 18 Card reader connector
19 Serial (COM2) connector 20 PCI Express x16 graphics card slot
21 PCI Express x1 card slot 22 Parallel connector
23 PCH
Chapter 1.Overview 5

Machine type and model label
The machine type and model label identifies the computer. When you contact Lenovo for help, the machine
type and model information helps support technicians to identify the computer and provide faster service.
The machine type and model label is attached on the computer as shown.
Figure 4. achine type and model label
6V530S-07ICB User Guide and Hardware Maintenance Manual
