Lenovo 81VS007WIX User manual

IdeaPad 1 (11", 05) and IdeaPad 1 (14", 05)
IdeaPad Slim 1 (11", 05) and IdeaPad Slim 1
(14", 05)
User Guide
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Lenovo IdeaPad Slim
1 14" (81VS007WIX) o cerca il tuo prodotto tra le migliori offerte di Notebook

Read this first
Before using this documentation and the roduct it su orts, ensure that you read and understand the
following:
• A endix A “Im ortant safety information” on age 27
• Safety and Warranty Guide
• Setup Guide
First Edition (September 2019)
© Copyright Lenovo 2019
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered ursuant to a General Services
Administration “GSA” contract, use, re roduction, or disclosure is subject to restrictions set forth in Contract No. GS-
35F-05925.

Contents
About this guide iii
Chapter 1 Meet your computer 1
Front . . . . . . . . . . . . . . . . . . . . 1
Base . . . . . . . . . . . . . . . . . . . . 2
Left . . . . . . . . . . . . . . . . . . . . 3
Right . . . . . . . . . . . . . . . . . . . . 4
Bottom . . . . . . . . . . . . . . . . . . . 5
Features and s ecifications . . . . . . . . . . . 6
Statement on USB transfer rate . . . . . . . . 7
O erating environment . . . . . . . . . . . 7
Chapter 2 Get started with your
computer 9
Get started with Windows 10 . . . . . . . . . . 9
Windows account . . . . . . . . . . . . . 9
Windows deskto . . . . . . . . . . . . 11
Lenovo Vantage and Lenovo PC Manager . . . . 12
Connect to Wi-Fi networks . . . . . . . . . . 12
Forget a Wi-Fi network . . . . . . . . . . 12
Turn air lane mode on and off . . . . . . . 12
The Novo Button menu . . . . . . . . . . . . 13
O en the Novo Button menu . . . . . . . . 13
Interact with your com uter . . . . . . . . . . 13
Keyboard hotkeys . . . . . . . . . . . . 13
Chapter 3 Explore your computer 15
Manage ower . . . . . . . . . . . . . . . 15
Check the battery status . . . . . . . . . 15
Charge the battery . . . . . . . . . . . . 15
Check the battery tem erature . . . . . . . 15
Set ower button behavior. . . . . . . . . 15
Change or create a ower lan . . . . . . . 15
Change settings in UEFI/BIOS setu utility . . . . 16
What is UEFI/BIOS setu utility . . . . . . . 16
O en the UEFI/BIOS setu utility . . . . . . 16
Change the startu sequence . . . . . . . 16
Change hotkey mode. . . . . . . . . . . 16
Enable or disable always-on . . . . . . . . 16
Set asswords in UEFI/BIOS setu utility . . . . . 16
Password ty es . . . . . . . . . . . . . 17
Set administrator assword . . . . . . . . 17
Change or remove administrator assword . . 17
Set user assword . . . . . . . . . . . . 18
Enable ower-on assword . . . . . . . . 18
Set hard disk assword . . . . . . . . . . 18
Change or remove hard disk assword . . . . 18
Reset or restore Windows . . . . . . . . . . . 19
Windows 10 recovery o tions . . . . . . . 19
Windows System Restore . . . . . . . . . 19
Reset Windows . . . . . . . . . . . . . 20
Create a recovery drive . . . . . . . . . . 20
Use a recovery drive to restore or reset
Windows . . . . . . . . . . . . . . . 20
Chapter 4 Help and support 23
Frequently asked questions . . . . . . . . . . 23
Self-hel resources . . . . . . . . . . . . . 23
Call Lenovo . . . . . . . . . . . . . . . . 25
Before you contact Lenovo . . . . . . . . 25
Lenovo Customer Su ort Center . . . . . . 25
Purchase additional services. . . . . . . . . . 26
Appendix A Important safety
information 27
Appendix B Accessibility and
ergonomic information 39
Appendix C Compliance
information 43
Appendix D Notices and
trademarks 57
© Co yright Lenovo 2019 i

ii IdeaPad 1 (11", 05) and IdeaPad 1 (14", 05) IdeaPad Slim 1 (11", 05) and IdeaPad Slim 1 (14", 05) User Guide

About this guide
• This guide a lies to Lenovo roduct model(s) listed below. Illustrations in this guide may look slightly
different from your roduct model.
Model name Machine type (MT)
Lenovo IdeaPad 1 11IGL05 81VT
Lenovo IdeaPad 1 14IGL05 81VU
• This guide may contain information about accessories, features, and software that are not available on all
models.
• This guide contains instructions that are based on the Windows 10 o erating system. These instructions
are not a licable if you install and use other o erating systems.
• Microsoft® makes eriodic feature changes to the Windows® o erating system through Windows U date.
As a result, the o erating system related instructions may become outdated. Refer to Microsoft resources
for the latest information.
• The content of the guide is subject to change without notice. To obtain the latest version, go to htt s://
su ort.lenovo.com.
© Co yright Lenovo 2019 iii

iv IdeaPad 1 (11", 05) and IdeaPad 1 (14", 05) IdeaPad Slim 1 (11", 05) and IdeaPad Slim 1 (14", 05) User Guide

Chapter 1 Meet your computer
Front
1. Wireless antennas Send and receive radio waves for the built-in wireless LAN (local area
network) and Bluetooth module.
Note: The antennas are not visible from the outside of the com uter.
2. Micro hones Ca ture or record sound and voice.
3. Camera Ca ture still and moving images for taking hotos, recording videos,
and video chatting.
4. Camera light If the light is on, the camera is in use.
5. Screen Dis lay text, gra hics, and videos.
© Co yright Lenovo 2019 1

Base
1. Keyboard Enter characters and interact with rograms.
Note: The keyboard also includes hotkeys and function keys for
changing settings and erforming tasks quickly.
2. Touch ad Perform finger touch and all the functions of a traditional mouse.
Note: The touch ad also su orts multi-touch function.
2IdeaPad 1 (11", 05) and IdeaPad 1 (14", 05) IdeaPad Slim 1 (11", 05) and IdeaPad Slim 1 (14", 05) User Guide

Left
1. Power connector Connect to ower with the included ower cord and ac ower
ada ter.
2. Charging light Indicate whether the com uter is connected to ac ower.
• Solid white: connected to ac ower; battery ca acity 91%–100%
• Solid amber: connected to ac ower; battery ca acity 1%–90%
• Off: not connected to ac ower
3. USB 3.2 Gen 1 Ty e-A connectors Connect a USB-com atible device, such as a USB keyboard, a USB
mouse, a USB storage device, or a USB rinter.
4. HDMITM connector Connect to a com atible digital audio device or video monitor, such
as an HDTV.
5. microSD card slot Insert a microSD card into the slot for data transfer or storage.
6. Novo button hole
Press the Novo button to o en the Novo Button menu. From the
menu, you can choose to o en the UEFI/BIOS setu utility, the Boot
menu, or the Windows startu o tions screen.
7. Power light • On: the com uter is turned on.
• Off: the com uter is turned off or in hibernation mode.
• Blinking: the com uter is in slee mode.
Cha ter 1.Meet your com uter 3

Right
1. Combo audio jack Connect head hones or headsets with a 3.5 mm (0.14 inch), 4- ole
lug.
Note: This jack does not su ort standalone external micro hones. If
you use headsets, choose one with a single lug.
4IdeaPad 1 (11", 05) and IdeaPad 1 (14", 05) IdeaPad Slim 1 (11", 05) and IdeaPad Slim 1 (14", 05) User Guide

Bottom
1. S eakers Produce sound.
Cha ter 1.Meet your com uter 5

Features and specifications
Dimensions • 11–inch models
– Width: 288 mm (11.33 inches)
– De th: 200 mm (7.87 inches)
– Thickness
– Thinnest: 17.7 mm (0.69 inches)
– Thickest: 17.9 mm (0.70 inches)
• 14–inch models
– Width: 327.1 mm (12.87 inches)
– De th: 235 mm (9.25 inches)
– Thickness
– Thinnest: 17.7 mm (0.69 inches)
– Thickest: 17.9 mm (0.70 inches)
ac ower ada ter • In ut: 100 V ac–240 V ac, 50 Hz–60 Hz
• Out ut: 20 V dc, 2.25 A
• Power: 45 W
Battery ack • Ca acity: 32 Wh
• Number of cells: 2
Micro rocessor To view the micro rocessor information of your com uter, right-click the Start button
and then select System.
Memory • Ty e: On-board double data rate 4 synchronous dynamic random access memory
(DDR4 SDRAM)
• Number of slots: 0
Secondary storage device • M.2 solid-state drive (SSD)
• eMMC
The storage ca acity might be different in different models. To view more details about
storage device, right-click the Start button and then select Device Manager.
Screen • Size: 294.6 mm (11.6 inches) or 355.6 mm (14 inches)
• Dis lay resolution
– 11-inch models: 1366 × 768 ixels (HD model)
– 14-inch models
– 1366 × 768 ixels (HD model)
– 1920 × 1080 ixels (FHD model)
Keyboard • Function keys
• Hotkeys
Connectors and slots • Combo audio jack
• USB 3.2 Gen 1 Ty e-A connector × 2
• HDMI connector
• microSD card slot
6IdeaPad 1 (11", 05) and IdeaPad 1 (14", 05) IdeaPad Slim 1 (11", 05) and IdeaPad Slim 1 (14", 05) User Guide

Security features • UEFI/BIOS asswords
– Administrator assword
– User assword
– Master hard disk assword
– User hard disk assword
• Trusted latform module (TPM)
Wireless features • Bluetooth
• Wireless LAN
Note: The battery ca acity is the ty ical or average ca acity as measured in a s ecific test environment.
Ca acities measured in other environments may differ but are no lower than the rated ca acity (see roduct
label).
Statement on USB transfer rate
De ending on many factors such as the rocessing ca ability of the host and eri heral devices, file
attributes, and other factors related to system configuration and o erating environments, the actual transfer
rate using the various USB connectors on this device will vary and will be slower than the data rate listed
below for each corres onding device.
USB device Data rate (Gbit/s)
3.2 Gen 1 5
3.2 Gen 2 10
Operating environment
Maximum altitude (without pressurization)
3048 m (10 000 ft)
Temperature
• At altitudes u to 2438 m (8000 ft)
– O erating: 5°C to 35°C (41°F to 95°F)
– Storage: 5°C to 43°C (41°F to 109°F)
• At altitudes above 2438 m (8000 ft)
– Maximum tem erature when o erating under the un ressurized condition: 31.3°C (88°F)
Note: When you charge the battery, its tem erature must be no lower than 10°C (50°F).
Relative humidity
• O erating: 8% to 95% at wet-bulb tem erature 23°C (73°F)
• Storage: 5% to 95% at wet-bulb tem erature 27°C (81°F)
Cha ter 1.Meet your com uter 7

8IdeaPad 1 (11", 05) and IdeaPad 1 (14", 05) IdeaPad Slim 1 (11", 05) and IdeaPad Slim 1 (14", 05) User Guide

Chapter 2 Get started with your computer
Get started with Windows 10
Learn the basics of Windows 10 and start working with it right away. For more information about Windows
10, see the Windows hel information.
Windows account
You must create at least one account to use the Windows o erating system. It can be either a local account
or a Microsoft account.
Local accounts
A local account is created on a articular Windows-enabled device and it can only be used on that device. It
is recommended that you set a assword for each local account to revent unauthorized access to the
device.
Microsoft accounts
A Microsoft account is a user account that you use to sign in to Microsoft software and services. If you use
Microsoft services like OneDrive, Outlook.com, Xbox Live, Office 365, and Sky e, you might already have
one. If you don't have it, you can create one for free.
There are two main benefits of using a Microsoft account:
• Sign in only once. If you use a Microsoft account to sign in to Windows 10, you don’t need to sign in again
to use OneDrive, Sky e, Outlook.com, and other Microsoft services.
• Settings can be synced. If you use your Microsoft account to sign in to multi le Windows-enabled
devices, certain Windows settings can be synced among the devices.
Switch between a local and a Microsoft account
If you are using a local account to sign in to Windows 10, you can switch to use a Microsoft account instead.
Ste 1. O en the Start menu and select Settings ➙ Accounts.
Ste 2. Select Sign in with a Microsoft account instead.
Ste 3. If you already have a Microsoft account, enter the account name and assword to sign in.
Otherwise, select Create one to create a new Microsoft account.
Note: The device must have Internet access the first time you use a Microsoft account on that
device.
If you want to switch back to use a local account, o en the Start menu and select Settings ➙ Accounts ➙
Sign in with a local account instead.
Add additional user accounts
Your user account must be of the “Administrator” ty e to add additional user accounts to Windows.
Add additional user accounts if you need to share your com uter with family members or other users.
Ste 1. O en the Start menu and select Settings ➙ Accounts ➙ Family & other users.
Ste 2. Select Add someone else to this PC.
© Co yright Lenovo 2019 9

Note: To add family members, you need to sign in with a Microsoft account.
Ste 3. Set the user name and assword for the user account.
10 IdeaPad 1 (11", 05) and IdeaPad 1 (14", 05) IdeaPad Slim 1 (11", 05) and IdeaPad Slim 1 (14", 05) User Guide

Windows desktop
1. Account Change account settings, lock the com uter, or sign out of the
current account.
2. Documents O en the Documents folder, a default folder to save your received
files.
3. Pictures O en the Pictures folder, a default folder to save your received
ictures.
4. Settings O en Settings.
5. Power Shut down, restart, or ut the com uter into slee mode.
6. Start button O en the Start menu.
7. Windows Search Enter what you are looking for in the search box and get search
results from your com uter and the Web.
8. Task View Dis lay all o ened a s and switch between them.
9. Windows notification area Dis lay notifications and status of some features.
10. Battery status icon Dis lay ower status and change battery or ower settings.
11. Network icon Connect to an available wireless network and dis lay the network
status.
12. Action center Dis lay the latest notifications from a s and rovide quick access to
some features.
Open the Start menu
• Click the Start button.
• Press the Windows logo key on the keyboard.
Open Control Panel
• O en the Start menu and select Windows System ➙ Control Panel.
Cha ter 2.Get started with your com uter 11

• Use Windows Search.
Open an app
• O en the Start menu and select the a you want to o en.
• Use Windows Search.
Lenovo Vantage and Lenovo PC Manager
Lenovo Vantage and Lenovo PC Manager is software develo ed by Lenovo. Using the software, you can:
• View roduct information
• View warranty and su ort information
• Run hardware scan and diagnose roblems
• Change hardware settings
• U date Windows, drivers, and UEFI/BIOS
Lenovo Vantage or PC Manager may be re-installed on your com uter. To o en it, enter the software name
in Windows Search and select the matched result.
Note: If Lenovo Vantage is not re-installed, you can download it from Microsoft Store.
Connect to Wi-Fi networks
If your com uter includes a wireless ada ter, you can connect your com uter to Wi-Fi networks.
Ste 1. Click the network icon in the Windows notification area. A list of nearby networks is dis layed.
Note: If no network is dis layed, check to ensure that the air lane mode is not turned on.
Ste 2. Select a network and click Connect. Provide security key if rom ted.
Note: The network key is usually managed by the network administrator.
Forget a Wi-Fi network
Windows saves a list of Wi-Fi networks you have connected to, along with their asswords and other
settings. By doing this, your com uter is automatically connected when it is in the range of a reviously
connected network. However, if the network assword has been changed, you need to forget the network in
order to enter a new assword.
Ste 1. Select Start ➙ Settings ➙ Network & Internet ➙ Wi-Fi.
Ste 2. Click Manage known networks.
Ste 3. Click the network name and click Forget.
Turn airplane mode on and off
Air lane mode is a convenient setting to turn all wireless communications of your com uter on and off. You
may need to turn it on when boarding an air lane.
Ste 1. Click the action center icon in the Windows notification area.
Ste 2. Click the Airplane mode icon to turn it on or off.
Note: Click Expand if you cannot find the air lane mode icon.
12 IdeaPad 1 (11", 05) and IdeaPad 1 (14", 05) IdeaPad Slim 1 (11", 05) and IdeaPad Slim 1 (14", 05) User Guide

The Novo Button menu
The Novo Button menu can be dis layed before the o erating system starts. From the menu, you can
choose to
• O en the BIOS/UEFI setu utility
• O en the boot device selection menu
• O en the Windows startu o tions screen
Note: From the Windows startu o tions screen, you can then choose to
Start your com uter using a recovery drive
Reset your com uter
O en advanced o tions screen
Open the Novo Button menu
For Lenovo com uters with a Novo button, you can ress the button to o en the Novo Button menu.
Ste 1. Turn off the com uter.
Ste 2. O en the LCD screen and ress the Novo button.
Note: Alternatively, turn off the com uter. Press Fn and the ower button to o en the Novo Button menu.
Interact with your computer
Keyboard hotkeys
Some keys on the keyboard are rinted with icons. These keys are called hotkeys and can be ressed alone
or in combination with the Fn key to access certain Windows functions or settings quickly. The functions of
hotkeys are symbolized by the icons rinted on them.
Hotkey Function
Mute/Unmute sound.
Decrease/Increase system volume.
Mute/Unmute the micro hone.
Reload Web ages or refresh the screen.
Enable/Disable the touch ad.
Turn air lane mode on and off.
Enable/Disable the integrated camera.
Lock the screen.
Cha ter 2.Get started with your com uter 13

Hotkey Function
Switch dis lay devices.
Increase/Decrease screen brightness.
Hotkey mode
Some hotkeys share keys with function keys (F1 to F12). The hotkey mode is a UEFI/BIOS setting that
changes how hotkeys (or function keys) are used.
Hotkey mode setting How to use hotkeys How to use function keys
Disabled Hold down the Fn key and ress one
of the hotkeys.
Press the function keys directly.
Enabled Press the hotkeys directly. Hold down the Fn key and ress one
of the function keys.
Note: Hotkeys that do not share keys with function keys are not affected by the hotkey mode setting. They
should always be used with the Fn key.
14 IdeaPad 1 (11", 05) and IdeaPad 1 (14", 05) IdeaPad Slim 1 (11", 05) and IdeaPad Slim 1 (14", 05) User Guide
