Lenovo 82NX00FBIX User manual

User Guide
Lenovo V14 Gen1
i , Lenovo V15 Gen1 i , Lenovo V17–IIL
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Lenovo V17 Gen 2
82NX00FBIX o cerca il tuo prodotto tra le migliori offerte di Notebook

Read this first
Before using this documentation and the product it supports, ensure that you read and understand the
fo owing:
• Appendix A “Important safety information” on page 31
• Safety and Warranty Guide
• Setup Guide
First Edition (November 2020)
© Copyright Lenovo 2020.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is de ivered pursuant to a Genera Services
Administration “GSA” contract, use, reproduction, or disc osure is subject to restrictions set forth in Contract No. GS-
35F-05925.

Contents
Abo t this g ide . . . . . . . . . . . . . iii
Chapter 1. Meet yo r comp ter . . . . . 1
Front . . . . . . . . . . . . . . . . . . . . 1
Top . . . . . . . . . . . . . . . . . . . . 2
Left . . . . . . . . . . . . . . . . . . . . 5
Right . . . . . . . . . . . . . . . . . . . . 6
Bottom . . . . . . . . . . . . . . . . . . . 7
Features and specifications . . . . . . . . . . . 9
Statement on USB transfer rate . . . . . . . 10
Operating environment . . . . . . . . . . 10
Chapter 2. Get started with yo r
comp ter . . . . . . . . . . . . . . . . 13
Get started with Windows 10 . . . . . . . . . 13
Windows account . . . . . . . . . . . . 13
Windows desktop . . . . . . . . . . . . 15
Lenovo Vantage and Lenovo PC Manager . . . . 16
Connect to Wi-Fi networks . . . . . . . . . . 16
Forget a Wi-Fi network . . . . . . . . . . 16
Turn airp ane mode on and off . . . . . . . 16
The Novo Button menu . . . . . . . . . . . . 17
Open the Novo Button menu . . . . . . . . 17
Interact with your computer . . . . . . . . . . 17
Keyboard hotkeys . . . . . . . . . . . . 17
Numeric keypad . . . . . . . . . . . . . 18
Chapter 3. Explore yo r comp ter . . 19
Manage power . . . . . . . . . . . . . . . 19
Check the battery status . . . . . . . . . 19
Charge the battery . . . . . . . . . . . . 19
Check the battery temperature . . . . . . . 19
Set power button behavior. . . . . . . . . 19
Change or create a power p an . . . . . . . 19
Change settings in UEFI/BIOS setup uti ity . . . . 20
What is UEFI/BIOS setup uti ity . . . . . . . 20
Open the UEFI/BIOS setup uti ity . . . . . . 20
Change the startup sequence . . . . . . . 20
Change hotkey mode. . . . . . . . . . . 20
Enab e or disab e a ways-on . . . . . . . . 20
Set passwords in UEFI/BIOS setup uti ity . . . . . 20
Password types . . . . . . . . . . . . . 21
Set administrator password . . . . . . . . 21
Change or remove administrator password . . 21
Set user password . . . . . . . . . . . . 22
Enab e power-on password . . . . . . . . 22
Set hard disk password . . . . . . . . . . 22
Change or remove hard disk password . . . . 22
Reset or restore Windows . . . . . . . . . . . 23
Windows 10 recovery options . . . . . . . 23
Windows System Restore . . . . . . . . . 23
Reset Windows . . . . . . . . . . . . . 24
Create a recovery drive . . . . . . . . . . 24
Use a recovery drive to restore or reset
Windows . . . . . . . . . . . . . . . 24
Chapter 4. Help and s pport . . . . . 27
Frequent y asked questions . . . . . . . . . . 27
Se f-he p resources . . . . . . . . . . . . . 27
Ca Lenovo . . . . . . . . . . . . . . . . 29
Before you contact Lenovo . . . . . . . . 29
Lenovo Customer Support Center . . . . . . 29
Purchase additiona services. . . . . . . . . . 30
Appendix A. Important safety
information . . . . . . . . . . . . . . . 31
Appendix B. Accessibility and
ergonomic information . . . . . . . . 43
Appendix C. Compliance
information . . . . . . . . . . . . . . . 47
Appendix D. Notices and
trademarks . . . . . . . . . . . . . . . 59
© Copyright Lenovo 2020 i

ii User Guide

Abo t this g ide
• This guide app ies to Lenovo product mode (s) isted be ow. I ustrations in this guide may ook s ight y
different from your product mode .
Model name Machine type (MT)
Lenovo V14 G1 IML 82NA
Lenovo V15 G1 IML 82NB
82NQ
Lenovo V17–IIL 82GX
• This guide may contain information about accessories, features, and software that are not avai ab e on a
mode s.
• This guide contains instructions that are based on the Windows 10 operating system. These instructions
are not app icab e if you insta and use other operating systems.
• Microsoft® makes periodic feature changes to the Windows® operating system through Windows Update.
As a resu t, the operating system re ated instructions may become outdated. Refer to Microsoft resources
for the atest information.
• The content of the guide is subject to change without notice. To obtain the atest version, go to https://
support. enovo.com.
© Copyright Lenovo 2020 iii

iv User Guide

Chapter 1. Meet yo r comp ter
Front
1. Microphones Capture or record sound and voice.
2. Camera Capture sti and moving images for taking photos, recording videos,
and video chatting.
3. Camera cover s ider Move the s ider to cover or uncover the camera ens.
Note: The camera cover he ps you better protect your privacy.
4. Camera ight If the ight is on, the camera is in use. If there is a red ight in the
midd e, the camera is covered.
5. Wire ess antennas Send and receive radio waves for the bui t-in wire ess LAN ( oca area
network) and B uetooth modu e.
Note: The antennas are not visib e from the outside of the computer.
6. Screen Disp ay text, graphics, and videos.
© Copyright Lenovo 2020 1

Top
Lenovo V14 Gen1 i
1. Venti ation s ots Dissipate heat.
2. Keyboard Enter characters and interact with programs.
Note: The keyboard a so inc udes hotkeys and function keys for
changing settings and performing tasks quick y.
3. Power button Press the button to turn on the computer or put the computer in s eep
mode.
4. Power button ight The ight shows power status of the computer.
Note: It is positioned in the center of the button for devices without
fingerprint reader.
5. Touchpad Perform finger touch and a the functions of a traditiona mouse.
Note: The touchpad a so supports mu ti-touch function.
Table 1. Indication of the Power light
Light stat s Comp ter Fingerprint reader
So id white Turn on /
B inking s ow y in white In s eep mode /
Off Turn off or in hibernation mode /
B inking amber / Launching
2User Guide

Lenovo V15 Gen1 i
1. Venti ation s ots Dissipate heat.
2. Power button Press the button to turn on the computer or put the computer in s eep
mode.
3. Power button ight The ight shows power status of the computer.
Note: It is positioned in the center of the button for devices without
fingerprint reader.
4. Keyboard Enter characters and interact with programs.
Note: The keyboard a so inc udes hotkeys and function keys for
changing settings and performing tasks quick y.
5. Numeric keypad To enab e or disab e the numeric keypad, press the Num Lock key.
Note: If the Num Lock key ight is on, the numeric keypad is in use.
6. Touchpad Perform finger touch and a the functions of a traditiona mouse.
Note: The touchpad a so supports mu ti-touch function.
Table 2. Indication of the Power light
Light stat s Comp ter Fingerprint reader
So id white Turn on /
B inking s ow y in white In s eep mode /
Off Turn off or in hibernation mode /
B inking amber /Launching
Chapter 1.Meet your computer 3

Lenovo V17–IIL
1. Venti ation s ots Dissipate heat.
2. Power button/Fingerprint reader* Press the button to turn on the computer or put the computer in s eep
mode. Fingerprint reader* is avai ab e on power button. Enro and
read your fingerprint for user authentication.
3. Power button/Fingerprint reader* ight The ight shows power status of the computer.
Note: It is positioned in the center of the button for devices without
fingerprint reader.
4. Keyboard Enter characters and interact with programs.
Note: The keyboard a so inc udes hotkeys and function keys for
changing settings and performing tasks quick y.
5. Numeric keypad To enab e or disab e the numeric keypad, press the Num Lock key.
Note: If the Num Lock key ight is on, the numeric keypad is in use.
6. Touchpad Perform finger touch and a the functions of a traditiona mouse.
Note: The touchpad a so supports mu ti-touch function.
Table 3. Indication of the Power/Fingerprint reader light
Light stat s Comp ter Fingerprint reader
So id white Turn on /
B inking s ow y in white In s eep mode /
Off Turn off or in hibernation mode /
B inking amber /Launching
*for se ected mode s
4User Guide

Left
1. Power connector Connect to power with the inc uded power cord and ac power
adapter.
2. Charging ight Indicate whether the computer is connected to ac power.
• So id white: connected to ac power; battery capacity 91%–100%
• So id amber: connected to ac power; battery capacity 1%–90%
• Off: not connected to ac power
3. HDMI™ connector Connect to a compatib e digita audio device or video monitor, such
as an HDTV.
4. USB 2.0 connector Connect USB-compatib e devices, such as a USB keyboard, USB
mouse, USB storage device, or USB printer.
5. USB (3.2 Gen 1) Type-A connectors (2) Connect a USB-compatib e device, such as a USB keyboard, a USB
mouse, a USB storage device, or a USB printer.
6. Power ight • On: the computer is turned on.
• Off: the computer is turned off or in hibernation mode.
• B inking: the computer is in s eep mode.
Chapter 1.Meet your computer 5

Right
1. Combo audio jack Connect headphones or headsets with a 3.5-mm (0.14-inch), 4-po e
p ug.
Note: This jack does not support standa one externa microphones. If
you use headsets, choose one with a sing e p ug.
2. Novo button ho e Press the Novo button to open the Novo B tton menu. From the
menu, you can choose to open the UEFI/BIOS setup uti ity, the Boot
menu, or the Windows startup options screen.
3. SD card s ot Insert an SD card or a Mu tiMediaCard (MMC) into the s ot for data
transfer or storage.
6User Guide

Bottom
Lenovo V14 Gen1 i and Lenovo V15 Gen1 i
1. Speakers Produce sound.
Chapter 1.Meet your computer 7

Lenovo V17–IIL
1. Speakers Produce sound.
8User Guide

Feat res and specifications
Lenovo V14 Gen1 i Lenovo V15 Gen1 i Lenovo V17–IIL
Dimen-
sions
• Width: 327.1 mm (12.88
inches)
• Depth: 241 mm (9.49 inches)
• Thickness: 19.9 mm (0.78
inches)
• Width: 362.2 mm (14.26
inches)
• Depth: 253.4 mm (9.98 inches)
• Thickness: 19.9 mm (0.78
inches)
• Width: 402 mm (15.83 inches)
• Depth: 281.25 mm (11.07
inches)
• Thickness: 19.9 mm (0.78
inches)
ac power
adapter
• Input: 100 V ac-240 V ac, 50 Hz-60 Hz
• Output: 20 V dc, 2.25 A
• Power: 45 W
• Output: 20 V dc, 3.25 A
• Power: 65 W
Battery
pack
• Capacity: 30/35 Wh
• Number of ce s: 2
• Capacity: 45 Wh
• Number of ce s: 3
• Capacity: 30/35 Wh
• Number of ce s: 2
• Capacity: 45 Wh
• Number of ce s: 3
• Capacity: 42 Wh
• Number of ce s: 3
• Capacity: 56 Wh
• Number of ce s: 3
To have better game performance, p ease insert ac adapter.
Micro-
process-
or
To view the microprocessor information of your computer, right-c ick the Start button and then c ick
System.
Memory • Type: On board memory modu e and Doub e data rate 4 (DDR4) dua in- ine memory modu e (DIMM)*
• Number of s ots: 1*
Secon-
dary
storage
device
• Type: Hard disk drive
• Form factor: 2.5-inch 7 mm
• Bus: Seria ATA
• Type: So id-state drive
• Form factor: M.2
• Bus: PCI Express
• Type: Inte Optane*
• Form factor: M.2
• Bus: PCI Express
Screen
• Size: 355.6 mm (14.0 inches)
• Disp ay reso ution:
– 1920 x 1080 pixe s (FHD
mode )
– 1366 x 768 pixe s (HD
mode )
• Size: 396.2 mm (15.6 inches)
• Disp ay reso ution:
– 1920 x 1080 pixe s (FHD
mode )
– 1366 x 768 pixe s (HD
mode )
• Size: 431.8 mm (17.0 inches)
• Disp ay reso ution:
– 1920 x 1080 pixe s (FHD
mode )
– 1600 x 900 pixe s (HD+
mode )
Chapter 1.Meet your computer 9

Lenovo V14 Gen1 i Lenovo V15 Gen1 i Lenovo V17–IIL
Keyboard • Function keys
• Hotkeys
• Function keys
• Hotkeys
• Numeric keypad
• Function keys
• Hotkeys
• Numeric keypad
Connec-
tors and
s ots
• Combo audio jack
• USB 2.0 connector
• USB (3.2 Gen 1) Type-A connector x 2
• HDMI connector
• SD card s ot
Security
features
• Fingerprint reader*
• UEFI/BIOS passwords
– Administrator password
– User password
– Master hard disk password
– User hard disk password
Wire ess
features
• B uetooth
• Wire ess LAN
* for se ected mode s
Note: The battery capacity is the typica or average capacity as measured in a specific test environment.
Capacities measured in other environments may differ but are no ower than the rated capacity (see product
abe ).
Statement on USB transfer rate
Depending on many factors such as the processing capabi ity of the host and periphera devices, fi e
attributes, and other factors re ated to system configuration and operating environments, the actua transfer
rate using the various USB connectors on this device wi vary and wi be s ower than the data rate isted
be ow for each corresponding device.
USB device Data rate (Gbit/s)
3.2 Gen 1 5
3.2 Gen 2 10
Operating environment
Maxim m altit de (witho t press rization)
3048 m (10000 ft)
Temperat re
• At a titudes up to 2438 m (8000 ft)
– Operating: 5°C to 35°C (41°F to 95°F)
– Storage: 5°C to 43°C (41°F to 109°F)
10 User Guide

• At a titudes above 2438 m (8000 ft)
– Maximum temperature when operating under the unpressurized condition: 31.3°C (88°F)
Note: When you charge the battery, its temperature must be no ower than 10°C (50°F).
Relative h midity
• Operating: 8% to 95% at wet-bu b temperature 23°C (73°F)
• Storage: 5% to 95% at wet-bu b temperature 27°C (81°F)
Chapter 1.Meet your computer 11

12 User Guide

Chapter 2. Get started with yo r comp ter
Get started with Windows 10
Learn the basics of Windows 10 and start working with it right away. For more information about Windows
10, see the Windows he p information.
Windows acco nt
You must create at east one account to use the Windows operating system. It can be either a oca account
or a Microsoft account.
Local acco nts
A oca account is created on a particu ar Windows-enab ed device and it can on y be used on that device. It
is recommended that you set a password for each oca account to prevent unauthorized access to the
device.
Microsoft acco nts
A Microsoft account is a user account that you use to sign in to Microsoft software and services. If you use
Microsoft services ike OneDrive, Out ook.com, Xbox Live, Office 365, and Skype, you might a ready have
one. If you don't have it, you can create one for free.
There are two main benefits of using a Microsoft account:
• Sign in on y once. If you use a Microsoft account to sign in to Windows 10, you don’t need to sign in again
to use OneDrive, Skype, Out ook.com, and other Microsoft services.
• Settings can be synced. If you use your Microsoft account to sign in to mu tip e Windows-enab ed
devices, certain Windows settings can be synced among the devices.
Switch between a local and a Microsoft acco nt
If you are using a oca account to sign in to Windows 10, you can switch to use a Microsoft account instead.
Step 1. Open the Start menu and se ect Settings ➙ Acco nts.
Step 2. Se ect Sign in with a Microsoft acco nt instead.
Step 3. If you a ready have a Microsoft account, enter the account name and password to sign in.
Otherwise, se ect Create one to create a new Microsoft account.
Note: The device must have Internet access the first time you use a Microsoft account on that
device.
If you want to switch back to use a oca account, open the Start menu and se ect Settings ➙ Acco nts ➙
Sign in with a local acco nt instead.
Add additional ser acco nts
Your user account must be of the “Administrator” type to add additiona user accounts to Windows.
Add additiona user accounts if you need to share your computer with fami y members or other users.
Step 1. Open the Start menu and se ect Settings ➙ Acco nts ➙ Family & other sers.
Step 2. Se ect Add someone else to this PC.
© Copyright Lenovo 2020 13

Note: To add fami y members, you need to sign in with a Microsoft account.
Step 3. Set the user name and password for the user account.
Enroll yo r fingerprint
If your computer inc udes a fingerprint reader, you can enro your fingerprint for Windows sign-in.
Step 1. Open the Start menu and se ect Settings ➙ Acco nts ➙ Sign-in options.
Note: If you are using a oca account, the account must be password protected. Otherwise, you
cannot enro fingerprints.
Step 2. Se ect Windows Hello Fingerprint ➙ Set p ➙ Get started.
Step 3. Fo ow on-screen instructions to comp ete the enro ment. Create a PIN when prompted, in case
your fingerprint cannot be recognized at Windows sign-in.
Note: You can enro more than one fingerprint.
14 User Guide
