Lenovo Chromebook Duet 5 User manual

User Guide
Lenovo Chromebook Duet 5, IdeaPad Duet 5 Chromebook (13″, 6)

Read this first
Be ore using this documentation and the product it supports, ensure that you read and understand the
ollowing:
• Generic Safety and Compliance Notices
• Safety and Warranty Guide
• Setup Guide
First edition (September 2021)
© Copyright Lenovo 2021.
LIMITED AND RESTRICTED RIGHTS NOTICE: I data or so tware is delivered pursuant to a General Services
Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set orth in Contract No. GS-
35F-05925.

Abo t this doc mentation
• Illustrations in this documentation might look di erent rom your product.
• Depending on the model, some eatures and so tware programs might not be available on your computer.
• Documentation content is subject to change without notice. Lenovo makes constant improvement on the
documentation o your computer, including this User Guide. To get the latest documentation, go to https://
support.lenovo.com.
• This documentation applies to the ollowing product models:
Model Name Machine Type (MT)
IP Duet 5 Chromebook 13Q7C6 82QS
IP Duet 5 Chromebook 13Q7C61

Contents
About this documentation . . . . . . . . . . . . ii
Chapter 1. Meet yo r Chromebook . . . 1
Front . . . . . . . . . . . . . . . . . . . . 1
Rear . . . . . . . . . . . . . . . . . . . . 2
Top . . . . . . . . . . . . . . . . . . . . 3
Bottom . . . . . . . . . . . . . . . . . . . 4
Le t . . . . . . . . . . . . . . . . . . . . 5
Right . . . . . . . . . . . . . . . . . . . . 6
Folio keyboard . . . . . . . . . . . . . . . . 7
Features and speci ications . . . . . . . . . . . 8
Statement on USB trans er rate . . . . . . . . 9
Operating environment . . . . . . . . . . . . . 9
Chapter 2. Get started with yo r
Chromebook . . . . . . . . . . . . . . 11
Charge your Chromebook . . . . . . . . . . . 11
Connect to Wi-Fi . . . . . . . . . . . . . . 11
Combination o computer and olio keyboard . . . 12
Use the kickstand . . . . . . . . . . . . . . 12
Lenovo USI Pen ( or selected models) . . . . . . 13
Be ore irst use . . . . . . . . . . . . . 14
Use the power button . . . . . . . . . . . . 14
Connect to Bluetooth devices . . . . . . . . . 15
Set the power plan . . . . . . . . . . . . . 15
Chapter 3. Navigate the screen . . . . 17
Use the multi-touch screen . . . . . . . . . . 17
Use the special keys . . . . . . . . . . . . . 17
Use the touchpad . . . . . . . . . . . . . . 18
Chapter 4. Use m ltimedia . . . . . . 21
Use the camera . . . . . . . . . . . . . . . 21
Use audio . . . . . . . . . . . . . . . . . 21
Connect to an external display . . . . . . . . . 21
Chapter 5. Lenovo help and
s pport . . . . . . . . . . . . . . . . . 23
Frequently asked questions . . . . . . . . . . 23
Lenovo support Web site . . . . . . . . . . . 23
Call Lenovo customer support center . . . . . . 24
Be ore calling customer support . . . . . . 24
Services supported by Lenovo customer
support center . . . . . . . . . . . . . 24
Services not supported by Lenovo customer
support center . . . . . . . . . . . . . 24
Support phone numbers . . . . . . . . . 24
Get help rom Google. . . . . . . . . . . 24
Appendix A. Important safety
information . . . . . . . . . . . . . . . 27
Appendix B. Compliance
information . . . . . . . . . . . . . . . 29
Appendix C. Accessibility,
ergonomic, and maintenance
information . . . . . . . . . . . . . . . 31
Notices and trademarks . . . . . . . . . . . xxxv
© Copyright Lenovo 2021 i

ii User Guide

Chapter 1. Meet yo r Chromebook
Note: Your computer might look di erent rom the illustrations in this chapter.
Front
1. Antennas 2. Front camera
3. Camera light 4. Touch screen
© Copyright Lenovo 2021 1

Rear
1. Rear camera 2. Kickstand hinges
3. Kickstand 4. USI pen* + USI pen pouch*
* or selected models
2 User Guide

Top
1. Volume buttons 2. Microphones
Chapter 1.Meet your Chromebook 3

Bottom
1. Pogo pin with guide pin
4 User Guide

Left
1. Power button 2. Speakers
3. Power indicator 4. Power connector/USB-C® connector
Chapter 1.Meet your Chromebook 5

Right
1. Power connector/USB-C connector 2. Speakers
6 User Guide

Folio keyboard
1. Pogo pin with guide pin 2. Keyboard
3. Touchpad
Chapter 1.Meet your Chromebook 7

Feat res and specifications
Dimensions • Tablet: approximately 305.86 mm x 186.79 mm x 7.23 mm (12.0 inches x 7.4
inches x 0.3 inches)
• Tablet, olio keyboard and kickstand: approximately 305.93 mm x 186.81 mm x
15.83 mm (12.0 inches x 7.4 inches x 0.6 inches)
Weight • Tablet: approximately 0.70 kg (1.54 lb)
• Tablet, olio keyboard and kickstand: approximately 1.18 kg (2.60 lb)
Screen • Multi-touch screen
• Resolution: 1920 x 1080 pixels FHD
• Size: 337.8 mm (13.3 inches)
Memory • Type: Low Power Double data rate 4x (LPDDR4x)
• Capacity: 4 GB or 8 GB
Storage device • Type: Solid-state drive, embedded multi media card (eMMC)
• Capacity: 64 GB or 128 GB or 256 GB
Note: The capacity o the storage device displayed in the operating system is
typically lower than the nominal capacity.
Connectors and slots • USB-C connectors x 2
– Power input up to 30 W/45 W using the included power adapter
– Power output up to 5 V and 3 A
– USB data trans er rate up to 5 Gbps or USB 3.2 Gen 1
– DisplayPortTM 1.4 supports maximum output resolution o 2560 × 1440, at 60
Hz rame rate and color depth o 24 bpp (bits per pixel).
Wireless eatures • Bluetooth
• Wireless LAN
Others • Camera
• Microphones
• Speakers
Battery pack • Type: Built-in Li-Polymer battery
• Number o cells: 4
• Capacity: 42 Wh
Note: The capacity listed here is the typical or average capacity as measured in a
speci ic test environment. Capacities measured in other environments may di er
but are no lower than the rated capacity (see product label).
ac power adapter • Input: 100 V to 240 V, 50 Hz to 60 Hz
• Output:
– 10 V/3 A ( or 30 W)
– 20 V/2.25 A or 15 V/3 A ( or 45 W)
• Power: 30 W/45 W
8 User Guide

Note: Speci ications might change without notice. Some speci ications are model-speci ic and might not
apply to the computer model that you purchased.
Statement on USB transfer rate
Depending on many actors such as the processing capability o the host and peripheral devices, ile
attributes, and other actors related to system con iguration and operating environments, the actual trans er
rate using the various USB connectors on this device will vary and will be slower than the data rate listed
below or each corresponding device.
USB device Data rate (Gbit/s)
3.2 Gen 1 5
3.2 Gen 2 10
Operating environment
Maxim m altit de
3048 m (10 000 t) (without pressurization)
Temperat re
• Operating : 5 ℃ – 35 ℃ (41 ℉ – 95 ℉)
• Storage: 5 ℃ – 43 ℃ (41 ℉ – 109 ℉)
Note: When charging the battery pack, the environment temperature must be no lower than 10 ℃ (50 ℉).
Relative h midity
• Operating: 8% – 95% at wet-bulb temperature 23 ℃ (73 ℉)
• Storage: 5% – 95% at wet-bulb temperature 27 ℃ (81 ℉)
The olio keyboard bottom cover and kickstand cover are abric. Handle your keyboard and kickstand cover
with care so that you can enjoy this product or a long time. I possible, place your computer in a well-
ventilated and dry area without direct exposure to sunshine. Do not use or store your computer in dusty, dirty
areas, or extremely hot or cold areas.
Chapter 1.Meet your Chromebook 9

10 User Guide

Chapter 2. Get started with yo r Chromebook
Charge yo r Chromebook
The USB-C connector on your Chromebook works as the power connector. Plug in the ac power adapter to
charge the built-in battery pack and provide power to the Chromebook.
Connect to ac power
CAUTION:
All pl gs m st be firmly and sec rely inserted into receptacles.
1. Connect the power cord to the ac power adapter.
2. Plug the power cord into the USB-C connector o the Chromebook.
3. Plug the power adapter into an electrical outlet.
AC power stat s indicator behavior
The ac power status indicator is next to the USB-C connector. The ollowing table shows the indicator
behaviors and the indicated power and battery status.
AC power stat s indicator Power stat s Battery stat s
on (red) plugged in being charged, remaining power is
less than 5%
on (amber) plugged in being charged, remaining power is
between 5% and 97%
on (green) plugged in ully charged (97% to 100%)
o unplugged discharging
Connect to Wi-Fi
To connect your Chromebook to Wi-Fi:
1. Click your account picture.
© Copyright Lenovo 2021 11

2. Click the network icon and turn on the wireless eature.
3. Select an available network to connect. Provide required in ormation i needed.
Combination of comp ter and folio keyboard
Align the connector o the keyboard with the computer and then attach the computer in the direction shown
by the arrow.
Use the kickstand
Your computer has a stand cover that is built in with a kickstand. Pivot the kickstand rom the pits on both
sides o the computer to open position as shown.
12 User Guide

With the kickstand open, you can use the computer in the ollowing modes.
• Stand mode without olio keyboard attached
• Stand mode with olio keyboard attached
• Stylus mode
The kickstand is multi-positional. You can adjust the kickstand to various angles or a com ortable user
experience.
Attention: The appropriate kickstand angle is 45º–135º. Using the kickstand at an improper angle or under
the load may damage the kickstand.
Lenovo USI Pen (for selected models)
Your computer might come with a Lenovo USI Pen (re erred to as the pen in this section). The pen enables
you to write and draw in a natural manner.
Notes:
• The pen is not waterproo . Take care not to drop the pen in water.
• The pen contains pressure sensors. Do not push the tip o the pen or an extended period o time. Do not
subject the pen to shock or vibration.
Pen overview
Chapter 2.Get started with your Chromebook 13

Name Description
1. End cap Unscrew the end cap to install or replace a battery.
2. Pen tip To click, tap on the screen with the tip. To double-click, tap twice.
Before first se
An insulation pad may be included in the Lenovo USI Pen to prevent capacity loss during shipping. The irst
time you use the pen, check and remove the insulation pad.( 2)
CAUTION:
The Lenovo USI Pen ses AAAA battery. Replace with the right battery.
Use the power b tton
When you open the computer screen, the Chromebook automatically starts. I it doesn’t, press the power
button. You also can use the power button to put your Chromebook to sleep or wake your Chromebook.
14 User Guide
