Lenovo IdeaPad 3 Series User manual

User Guide
IdeaPad 3/IdeaPad 3i/IdeaPad Slim 3/IdeaPad Slim 3i series

Read this first
Before using this documentation and the product it supports, ensure that you read and understand the
following:
• Generic Safety and Compliance Notices
• Safety and Warranty Guide
• Setup Guide
First Edition (July 2021)
© Copyright Lenovo 2021.
IMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services
Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-
35F-05925.

Contents
bout this guide . . . . . . . . . . . . . iii
Chapter 1. Meet your computer . . . . . 1
Front . . . . . . . . . . . . . . . . . . . . 1
Base . . . . . . . . . . . . . . . . . . . . 2
eft . . . . . . . . . . . . . . . . . . . . 4
Right . . . . . . . . . . . . . . . . . . . . 5
Bottom . . . . . . . . . . . . . . . . . . . 6
Features and specifications . . . . . . . . . . . 7
Statement on USB transfer rate . . . . . . . . 8
Operating environment . . . . . . . . . . . 8
Avoid constant body contact with specific hot
sections . . . . . . . . . . . . . . . . . 9
Chapter 2. Get started with your
computer . . . . . . . . . . . . . . . . 11
Work with Windows . . . . . . . . . . . . . 11
Windows help information . . . . . . . . . 12
enovo Vantage and enovo PC Manager . . . . 12
The Novo Button menu . . . . . . . . . . . . 12
Open the Novo Button menu . . . . . . . . 13
Interact with your computer . . . . . . . . . . 13
Keyboard hotkeys . . . . . . . . . . . . 13
Numeric keypad . . . . . . . . . . . . . 14
Chapter 3. Explore your computer . . 15
Manage power . . . . . . . . . . . . . . . 15
Check the battery status . . . . . . . . . 15
Charge the battery . . . . . . . . . . . . 15
Set power button behavior. . . . . . . . . 15
A power plan . . . . . . . . . . . . . . 15
Set performance mode . . . . . . . . . . 16
Change settings in UEFI/BIOS setup utility . . . . 16
What is UEFI/BIOS setup utility . . . . . . . 16
Open the UEFI/BIOS setup utility . . . . . . 16
Change the startup sequence . . . . . . . 16
Change hotkey mode . . . . . . . . . . . 16
Enable or disable always-on . . . . . . . . 17
Set passwords in UEFI/BIOS setup utility . . . . . 17
Password types . . . . . . . . . . . . . 17
Set administrator password . . . . . . . . 17
Change or remove administrator password . . 18
Set user password . . . . . . . . . . . . 18
Enable power-on password . . . . . . . . 18
Set hard disk password . . . . . . . . . . 19
Change or remove hard disk password . . . . 19
Chapter 4. Help and support . . . . . 21
Frequently asked questions . . . . . . . . . . 21
Self-help resources . . . . . . . . . . . . . 21
What is a CRU? . . . . . . . . . . . . . . . 22
CRUs for your product model . . . . . . . . . 23
Call enovo . . . . . . . . . . . . . . . . 24
Before you contact enovo . . . . . . . . 24
enovo Customer Support Center . . . . . . 24
Purchase additional services. . . . . . . . . . 25
ppendix . Notices and
trademarks . . . . . . . . . . . . . . . 27
© Copyright enovo 2021 i

ii User Guide

bout this guide
• This guide applies to enovo product model(s) listed below. Illustrations in this guide may look slightly
different from your product model.
Model name Machine type (MT)
IdeaPad 3 14ADA6 82KQ
IdeaPad 3 14A C6 82KT
IdeaPad 3 14IT 6 82H7
IdeaPad 3 15ADA6 82KR
IdeaPad 3 15A C6 82KU
IdeaPad 3 15IT 6 82H8
IdeaPad 3 17ADA6 82KS
IdeaPad 3 17A C6 82KV
IdeaPad 3 17IT 6 82H9
• For further compliance information, refer to the Generic Safety and Compliance Notices at https://
pcsupport.lenovo.com/docs/generic_notices.
• This guide may contain information about accessories, features, and software that are not available on all
models.
• This guide contains instructions that are based on the Windows operating system. These instructions are
not applicable if you install and use other operating systems.
• Microsoft® makes periodic feature changes to the Windows® operating system through Windows Update.
As a result, the operating system related instructions may become outdated. Refer to Microsoft resources
for the latest information.
• The content of the guide is subject to change without notice. To obtain the latest version, go to https://
support.lenovo.com.
© Copyright enovo 2021 iii

iv User Guide

Chapter 1. Meet your computer
Front
1. Microphones Capture or record sound and voice.
2. Camera • Capture still and moving images for taking photos, recording
videos, and video chatting.
• Capture your face images for face authentication.
Note: Use Windows Hello to enroll your face for face
authentication.
3. Camera cover slider Move the slider to cover or uncover the camera lens.
Note: The camera cover helps you better protect your privacy.
4. Camera light If the light is on, the camera is in use.
5. Screen Display text, graphics, and videos. Selected models support multi-
touch function.
6. Wireless antennas Send and receive radio waves for the built-in wireless AN (local area
network) and Bluetooth module.
Notes:
• The antennas are not visible from the outside of the computer.
• If the location of the antennas is close to the user’s body (< 20 cm),
you can find the Specific Absorption Rate (SAR) values in the Setup
Guide that comes with your computer.
© Copyright enovo 2021 1

Base
14–inch models:
1. Power light/Fingerprint reader* light The light shows power status of the computer and the status of
fingerprint reader.
2. Power button/Fingerprint reader* Press the button to turn on the computer or put the computer into
sleep mode. Fingerprint reader* is available on power button. Enroll
and read your fingerprint for user authentication.
3. Keyboard Enter characters and interact with programs.
Note: The keyboard also includes hotkeys and function keys for
changing settings and performing tasks quickly.
4. Touchpad Perform finger touch and all the functions of a traditional mouse.
Note: The touchpad also supports multi-touch function.
* for selected models
2User Guide

15–inch and 17–inch models:
1. Power button/Finger print reader* Press the button to turn on the computer or put the computer into
sleep mode. Fingerprint reader* is available on power button. Enroll
and read your fingerprint for user authentication.
2. Power light/Finger print reader* light The light shows power status of the computer and the status of
fingerprint reader.
3. Numeric keyboard To enable or disable the numeric keypad, press the Num ock key.
Note: If the Num ock key light is on, the numeric keypad is in use.
4. Keyboard Enter characters and interact with programs.
Note: The keyboard also includes hotkeys and function keys for
changing settings and performing tasks quickly.
5. Touchpad Perform finger touch and all the functions of a traditional mouse.
Note: The touchpad also supports multi-touch function.
* for selected models
Chapter 1.Meet your computer 3

Left
1. Power connector Connect to power with the included power cord and ac power
adapter.
2. Charging light Indicate whether the computer is connected to ac power.
• Solid white: connected to ac power; battery capacity 91%–100%
• Solid amber: connected to ac power; battery capacity 1%–90%
• Off: not connected to ac power
3. USB (3.2 Gen 1) Type-A connector Connect a USB-compatible device, such as a USB keyboard, a USB
mouse, a USB storage device, or a USB printer.
4. HDMI™ connector Connect to a compatible digital audio device or video monitor, such
as an HDTV.
5. USB-C® connector Connect external storage or data devices.
Note: An appropriate adapter may be needed for connecting external
devices. This connector cannot be used to connect external display
devices.
6. Combo audio jack Connect headphones or headsets with a 3.5 mm (0.14 inch), 4-pole
plug.
Note: This jack does not support standalone external microphones. If
you use headsets, choose one with a single plug.
4User Guide

Right
1. Power light • On: the computer is turned on.
• Off: the computer is turned off or in hibernation mode.
• Blinking: the computer is in sleep mode.
2. Novo button Press the Novo button to open the Novo Button menu. From the
menu, you can choose to open the UEFI/BIOS setup utility, the Boot
menu, or the Windows startup options screen.
3. SD card slot Insert an SD card or a MultiMediaCard (MMC) into the slot for data
transfer or storage.
4. USB 2.0 connector Connect USB-compatible devices, such as a USB keyboard, USB
mouse, USB storage device ,or USB printer.
Chapter 1.Meet your computer 5

Bottom
14–inch models:
1. Speakers Produce sound.
15–inch and 17–inch models:
1. Speakers Produce sound.
6User Guide

Features and specifications
Dimensions • Width:
– 14–inch models: 324.2 mm (12.76 inches)
– 15–inch models: 359.2 mm (14.14 inches)
– 17–inch models: 399 mm (15.71 inches)
• Depth:
– 14–inch models: 215.7 mm (8.49 inches)
– 15–inch models: 236.5 mm (9.31 inches)
– 17–inch models: 274 mm (10.79 inches)
• Thickness: 19.9 mm (0.78 inches)
ac power adapter • Input: 100 V ac–240 V ac, 50 Hz–60 Hz
• Output: 20 V dc, 3.25 A
• Power: 65 W
Battery pack • Capacity: 38 Wh
• Number of cells: 2
• Capacity: 45 Wh
• Number of cells: 3
Microprocessor To view the microprocessor information of your computer, type system information in the
Windows search box and then press Enter.
Memory • Type: On-board memory module and Double data rate 4 (DDR4) dual in-line memory
module (DIMM)
• Number of slots: 1
Secondary storage
device • Type: solid-state drive
• Form factor: M.2 (2242/2280)
• Bus: PCI Express
Screen • Size:
– 355.6 mm (14 inches)
– 381 mm (15 inches)
– 431.8 mm (17 inches)
• Display resolution
– 1920 × 1080 pixels (FHD)
– 1600 × 900 pixels (HD + TN)*
– 1366 × 786 pixels (HD)
Keyboard • Function keys
• Hotkeys
• Numeric keypad*
• Keyboard backlight*
Chapter 1.Meet your computer 7

Connectors and slots • Combo audio jack
• USB-C connector
– Support data transfer rates up to 5 Gbps for USB 3.2 Gen 1
– Provide power output up to 5 V and 3 A*
• USB 3.2 Gen 1 Type-A connector
– Support data transfer rates up to 5 Gbps for USB 3.2 Gen 1
• USB 2.0 connector
• HDMI connector
• SD card reader
Security features • Fingerprint reader*
• UEFI/BIOS passwords
– Administrator password
– User password
– Master hard disk password
– User hard disk password
Wireless features • Bluetooth
• Wireless AN
* for selected models
*USB-C connector provides power up to 5 V and 1.5 A for 38 Wh battery pack when the computer is not
connected to ac power.
Note: The battery capacity is the typical or average capacity as measured in a specific test environment.
Capacities measured in other environments may differ but are no lower than the rated capacity (see product
label).
Statement on USB transfer rate
Depending on many factors such as the processing capability of the host and peripheral devices, file
attributes, and other factors related to system configuration and operating environments, the actual transfer
rate using the various USB connectors on this device will vary and will be slower than the data rate listed
below for each corresponding device.
USB device Data rate (Gbit/s)
3.2 Gen 1 5
3.2 Gen 2 10
Operating environment
Maximum altitude (without pressurization)
3048 m (10 000 ft)
Temperature
• At altitudes up to 2438 m (8000 ft)
8User Guide

– Operating: 5°C to 35°C (41°F to 95°F)
– Storage: 5°C to 43°C (41°F to 109°F)
• At altitudes above 2438 m (8000 ft)
– Maximum temperature when operating under the unpressurized condition: 31.3°C (88°F)
Note: When you charge the battery, its temperature must be no lower than 10°C (50°F).
Relative humidity
• Operating: 8% to 95% at wet-bulb temperature 23°C (73°F)
• Storage: 5% to 95% at wet-bulb temperature 27°C (81°F)
void constant body contact with specific hot sections
C UTION:
When the computer is operating, it should be placed on a hard and flat surface with its bottom area
not in contact with user’s bare skin. Under normal operating conditions, the temperature of the
bottom surface will remain within an acceptable range as defined in IEC 62368-1, but such
temperatures can still be high enough to cause discomfort or harm to the user if directly touched for
over xx at a time. s such, it is recommended that users avoid prolonged direct contact with the
bottom of the computer.
Note: Some enovo computers include a display that can be rotated 360 degrees. When those products are
used as a tablet computer, the temperatures of all the accessible parts are within an acceptable range as
defined in IEC 62368-1.
Chapter 1.Meet your computer 9

10 User Guide

Chapter 2. Get started with your computer
Work with Windows
The following table contains Windows frequently used settings. You can learn the basics and start working
with Windows right away.
To configure settings, type the corresponding keywords in the Windows search box and select the best
match. Follow the on-screen instructions to customize settings.
Ta le 1. Basic settings
Functions Descriptions Search by
keywords
Control Panel View or change Windows settings, including hardware and software setup
and configuration.
Control Panel
Connect to Wi-Fi
networks
For models with a wireless AN module, you can connect your computer to
a Wi-Fi® network. Click the network icon in the Windows notification area,
and then select a network for connection.
Note: The wireless AN module on your computer may support different
standards. For some countries or regions, use of 802.11ax may be disabled
according to local regulations.
Wi-Fi
Connect to wired
networks
For models with an Ethernet (RJ-45) connector, you can use an Ethernet
cable to connect your computer to a wired network.
—
Airplane mode Airplane mode is a convenient setting to turn all wireless communications of
your computer on and off. You may need to turn it on when boarding an
airplane.
Airplane mode
Night light mode Night light is a switch in Windows that you can turn on and off. When it is
turned on, your screen shows warmer colors and the amount of emitted
blue light is reduced. Enabling night light reduces the chances of developing
eye fatigue or eye strain.
Note: For more guidance on reducing eye fatigue or eye strain, go to
https://www.lenovo.com/us/en/compliance/visual-fatigue.
Night light
Adjust color
temperature
If night light mode is turned on, you can adjust the color temperature of the
screen.
Note: Selected enovo computers are low blue light certified. These
computers are tested with night light turned on and color temperature set to
the default value of 48.
Night light
Windows
Updates
Microsoft periodically releases feature and security updates to the Windows
operating system. Updates that are applicable to your Windows version are
downloaded automatically when your computer is connected to the
Internet. When updates are downloaded, you are prompted to restart the
computer to install these updates. You can also manually check if there are
available updates for the installed version of Windows.
ttention: Only use Windows Update to download and install updates.
Updates downloaded from other sources may include security risks.
Windows Updates
© Copyright enovo 2021 11

Ta le 2. Optional settings
Functions Descriptions Search by
keywords
Set up face
recognition
For models with a Windows Hello-compatible infrared camera, you can set
up face recognition to sign in with your face.
Sign-in options
Enroll your
fingerprint
For models with a fingerprint reader, you can enroll your fingerprint for
Windows sign-in.
Sign-in options
Touch keyboard In stand, tent, or tablet mode, the physical keyboard of your computer is
disabled to prevent inadvertent typing. In these three modes, Windows
touch keyboard is automatically displayed when text input is required. If not,
select the touch keyboard icon ( ) in the Windows notification area.
Touch keyboard
Windows help information
If the on-screen instructions cannot solve your problem, refer to the following to get the online Windows help
information.
• Type Get Help or Tips in the Windows search box and then press Enter. When the app opens, type the
problem description and select the matched result.
• Visit Microsoft support Web site: https://support.microsoft.com. Enter what you are looking for in the
search box and get search results.
Lenovo Vantage and Lenovo PC Manager
They are both apps developed by enovo. Using either of them, you can:
• View product information and system status
• Manage and change device settings
• Check for and perform system update
Note: This feature is only available on enovo Vantage. In enovo PC Manager, you can check for and
perform driver update.
Depending on the country or region in which your computer is purchased, one of the apps may be pre-
installed on your computer. To open it, type its name in the Windows Search box and select the matched
result. If neither of the apps is pre-installed, you may install one on your own. enovo Vantage is available for
download free of charge from the Microsoft Store.
Note: App features are subject to change with updates and specific features may not be available on all
enovo products.
The Novo Button menu
The Novo Button menu can be displayed before the operating system starts. From the menu, you can
choose to
• Open the BIOS/UEFI setup utility
• Open the boot device selection menu
• Open the Windows startup options screen
Note: From the Windows startup options screen, you can then choose to
Start your computer using a recovery drive
12 User Guide

Reset your computer
Open advanced options screen
Open the Novo Button menu
For enovo computers with a Novo button, you can press the button to open the Novo Button menu.
Step 1. Turn off the computer.
Step 2. Open the CD screen and press the Novo button.
Note: Alternatively, turn off the computer. Press Fn and the power button to open the Novo Button menu.
Interact with your computer
Keyboard hotkeys
Some keys on the keyboard are printed with icons. These keys are called hotkeys and can be pressed alone
or in combination with the Fn key to open certain apps or change certain settings quickly. The functions of
the hotkeys are symbolized by the icons printed on them.
Hotkey Function
Mute/Unmute sound.
Decrease/Increase system volume.
Mute/Unmute the microphone.
Increase/Decrease screen brightness.
Switch display devices.
Turn airplane mode on and off.
Open the Windows Settings app.
ock the screen.
Display thumbnails of all open app.
Open the Windows Calculator app.
Open enovo Vantage, enovo PC Manager, or an app launch bar.
Open the Windows snipping tool.
Play or pause playback of media.
Stop playback of media.
Go to the previous media file in the playlist or folder.
Go to the next media file in the playlist or folder.
Turn on/off or adjust the brightness of the keyboard backlight.
Note: This hotkey must be used with the Fn key.
Chapter 2.Get started with your computer 13

Hotkey mode
Some hotkeys share keys with function keys (F1 to F12). The hotkey mode is a UEFI/BIOS setting that
changes how hotkeys (or function keys) are used.
Hotkey mode setting How to use hotkeys How to use function keys
Disabled Hold down the Fn key and press one
of the hotkeys.
Press the function keys directly.
Enabled Press the hotkeys directly. Hold down the Fn key and press one
of the function keys.
Note: Hotkeys that do not share keys with function keys are not affected by the hotkey mode setting. They
should always be used with the Fn key.
Numeric keypad
Some enovo computers includes a dedicated numeric keypad on the far right of the keyboard. The keypad
is used for entering numbers and operators quickly.
Press the NumLock key to enable or disable the numeric keypad.
14 User Guide
