Lenovo K14 Gen 1
User Guide

Read this first
Before using this documentation and the product it supports, ensure that you read and understand the
following:
• Safety and Warranty Guide
• Setup Guide
• Generic Safety and Compliance Notices
First Edition (September 2021)
© Copyright Lenovo 2021.
L M TED AND RESTR CTED R GHTS NOT CE: f data or software is delivered pursuant to a General Services
Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-
35F-05925.

Contents
iscover your Lenovo notebook. . . . . iii
Chapter 1. Meet your computer. . . . . 1
Front . . . . . . . . . . . . . . . . . . . . 1
Base . . . . . . . . . . . . . . . . . . . . 2
Left . . . . . . . . . . . . . . . . . . . . 3
Right . . . . . . . . . . . . . . . . . . . . 4
Bottom . . . . . . . . . . . . . . . . . . . 5
Specifications . . . . . . . . . . . . . . . . 5
USB specifications. . . . . . . . . . . . . 5
Chapter 2. Get started with your
computer . . . . . . . . . . . . . . . . . 7
Access networks . . . . . . . . . . . . . . . 7
Connect to Wi-Fi networks. . . . . . . . . . 7
Connect to the wired Ethernet . . . . . . . . 7
nteract with your computer . . . . . . . . . . . 7
Use Hotkeys . . . . . . . . . . . . . . . 7
Connect to an external display . . . . . . . . 8
Chapter 3. Explore your computer . . 11
Lock the computer . . . . . . . . . . . . . 11
Use the Vantage app . . . . . . . . . . . . . 11
Manage power . . . . . . . . . . . . . . . 12
Check the battery status . . . . . . . . . 12
Charge the battery . . . . . . . . . . . . 12
Change the power settings . . . . . . . . 13
Transfer data . . . . . . . . . . . . . . . . 13
Set up a Bluetooth connection . . . . . . . 13
Chapter 4. Configure advanced
settings. . . . . . . . . . . . . . . . . 15
UEF B OS . . . . . . . . . . . . . . . . . 15
Enter the UEF B OS menu. . . . . . . . . 15
Navigate in the UEF B OS interface . . . . . 15
Set the system date and time. . . . . . . . 15
Change the startup sequence . . . . . . . 15
Update UEF B OS . . . . . . . . . . . . 15
UEF B OS passwords . . . . . . . . . . . . 16
Password types . . . . . . . . . . . . . 16
Set, change, or remove a password . . . . . 17
nstall a Windows operating system and drivers . . 18
Use firewalls and antivirus programs. . . . . . . 19
Chapter 5. Help and support . . . . . 21
Frequently asked questions . . . . . . . . . . 21
Self-help resources . . . . . . . . . . . . . 22
Windows label . . . . . . . . . . . . . . . 23
What are CRUs . . . . . . . . . . . . . . . 23
Call Lenovo . . . . . . . . . . . . . . . . 24
Before you contact Lenovo . . . . . . . . 24
Lenovo Customer Support Center . . . . . . 25
Appendix A. Compliance
information . . . . . . . . . . . . . . . 27
Appendix B. Notices and
trademarks . . . . . . . . . . . . . . . 29
© Copyright Lenovo 2021 i

ii Lenovo K14 Gen 1 User Guide

iscover your Lenovo notebook
Thank you for choosing a Lenovo® notebook! We are dedicated to delivering the best solution to you.
Before starting your tour, please read the following information:
• llustrations in this documentation might look different from your product.
• Depending on the model, some optional accessories, features, software programs, and user interface
instructions might not be applicable to your computer.
• Documentation content is subject to change without notice. To get the latest documentation, go to https://
pcsupport.lenovo.com.
© Copyright Lenovo 2021 iii

iv Lenovo K14 Gen 1 User Guide

Chapter 1. Meet your computer
Front
Microphone Camera
Webcam privacy shutter
Webcam privacy shutter
Slide the webcam privacy shutter to cover or uncover the camera lens. t is designed to protect your privacy.
© Copyright Lenovo 2021 1

Base
Power button / Fingerprint reader
power button * Trackpad
* for selected models
2Lenovo K14 Gen 1 User Guide

Left
Power connector / USB-C® connector Always On USB 3.0 connector
HDM ™ connector USB-C connector1
Audio connector
1 This USB-C connector supports USB data transfer only. t does not support power delivery.
Related topics
• “Charge the battery” on page 12
• “USB specifications” on page 5
Chapter 1.Meet your computer 3

Right
USB 2.0 connector Ethernet connector
Nano security-lock slot
Related topics
• “USB specifications” on page 5
• “Access networks” on page 7
• “Lock the computer” on page 11
4Lenovo K14 Gen 1 User Guide

Bottom
Speakers
CAUTION:
When the computer is operating, it should be placed on a hard and flat surface with its bottom area
not in contact with user’s bare skin. Under normal operating conditions, the temperature of the
bottom surface will remain within an acceptable range as defined in IEC 62368-1, but such
temperatures can still be high enough to cause discomfort or harm to the user if directly touched for
over one minute at a time. As such, it is recommended that users avoid prolonged direct contact with
the bottom of the computer.
Specifications
For detailed specifications of your computer, go to https://psref.lenovo.com and search by product.
Microprocessor To view the microprocessor information of your computer, right-click the Start
button and then click System.
Memory Double data rate 4 (DDR4), up to 32 GB
Storage device • 2242 M.2 solid-state drive, up to 1 TB
• 2.5-inch 7 mm hard disk drive, up to 1 TB *
Audio • Dolby Audio
isplay
• Color display with n-Plane Switching ( PS) or Twisted Nematic (TN) technology
• Display ratio: 16:9
• Display resolution: 1920 x 1080 pixels
Security features • Trusted Platform Module (TPM) *
Wireless features • Bluetooth
• Wireless LAN
* for selected models
USB specifications
Note: Depending on the model, some USB connectors might not be available on your computer.
Chapter 1.Meet your computer 5

Connector name escription
• USB 2.0 connector
• USB 3.2 connector Gen 1
• USB 3.2 connector Gen 2
Connect USB-compatible devices, such as a USB keyboard, USB
mouse, USB storage device, or USB printer.
• USB-C (3.2 Gen 1) connector
• USB-C (3.2 Gen 2) connector
• USB-C (Thunderbolt 3) connector
• USB-C (Thunderbolt 4) connector
• Charge USB-C compatible devices with the following output
voltage and current:
– AC mode: 5 V and 3 A
– DC mode:
– 5 V and 1.5 A (45 W built-in battery)
– 5 V and 1.0 A (38 W built-in battery)
• Connect to an external display:
– USB-C to VGA: up to 1920 x 1200 pixels, 60 Hz
– USB-C to DP: up to 5120 x 3200 pixels, 60 Hz
• Connect to USB-C accessories to help expand your computer
functionality. To purchase USB-C accessories, go to https://
www.lenovo.com/accessories.
Statement on USB transfer rate
Depending on many factors such as the processing capability of the host and peripheral devices, file
attributes, and other factors related to system configuration and operating environments, the actual transfer
rate using the various USB connectors on this device will vary and will be slower than the data rate listed
below for each corresponding device.
USB device ata rate (Gbit/s)
3.2 Gen 1 / 3.1 Gen 1 5
3.2 Gen 2 / 3.1 Gen 2 10
3.2 Gen 2 × 2 20
Thunderbolt 3 40
Thunderbolt 4 40
6Lenovo K14 Gen 1 User Guide

Chapter 2. Get started with your computer
Access networks
This section helps you connect to a wireless or wired network.
Connect to Wi-Fi networks
Click the network icon in the Windows® notification area, and then select a network for connection. Provide
required information, if needed.
Connect to the wired Ethernet
Connect your computer to a local network through the Ethernet connector on your computer with an
Ethernet cable.
Interact with your computer
Your computer provides you various ways to navigate the screen.
Use Hotkeys
Some keys on the keyboard are printed with icons. These keys are called hotkeys and can be pressed alone
or in combination with the Fn key to access certain functions or settings quickly. The functions of hotkeys are
symbolized by the icons printed on them.
© Copyright Lenovo 2021 7

Hotkey Function
Mute / unmute the speakers.
f you mute the speakers and turn off your computer, the speakers remain muted when
you turn on your computer.
/ Decrease / increase the volume.
Mute / unmute the microphones.
/ Decrease / increase display brightness.
Manage external displays.
Turn on / turn off the airplane mode.
Open the Windows Settings.
Answer incoming calls on Microsoft Teams.
Decline incoming calls on Microsoft Teams.
Open the Windows Calculator.
Open Lenovo Vantage, Lenovo PC Manager, or an app launch bar.
Open the Windows snipping tool.
nvoke the special function printed as an icon on each key or standard function of F1–
F12 function keys.
• FnLock indicator on: standard function
• FnLock indicator off: special function
Connect to an external display
Connect your computer to a projector or a monitor to give presentations or expand your workspace.
Connect to a wired display
f your computer cannot detect the external display, right-click a blank area on the desktop and select
display settings. Then follow the on-screen instructions to detect the external display.
8Lenovo K14 Gen 1 User Guide

Supported resolution
The following table lists the supported maximum resolution of the external display.
Connect the external display to Supported resolution
USB-C connector Up to 3840 x 2160 pixels / 60 Hz
HDM ™ connector Up to 3840 x 2160 pixels / 30 Hz
Connect to a wireless display
To use a wireless display, ensure that both your computer and the external display support the Miracast®
feature.
Press Windows logo key + K and then select a wireless display to connect with.
Set the display mode
Press or Fn + and then select a display mode of your preference.
Change display settings
1. Right-click a blank area on the desktop and select display settings.
2. Select the display that you want to configure and change display settings of your preference.
You can change the settings for both the computer display and the external display. For example, you can
define which one is the main display and which one is the secondary display. You also can change the
resolution and orientation.
Chapter 2.Get started with your computer 9

10 Lenovo K14 Gen 1 User Guide

Chapter 3. Explore your computer
Lock the computer
Lock your computer to a desk, table, or other fixtures through a compatible security cable lock.
Note: The slot supports cable locks that conform to the Kensington NanoSaver® lock standards using
Cleat™ locking technology. You are responsible for evaluating, selecting, and implementing the locking
device and security feature. Lenovo is not responsible for the locking device and security feature. You can
purchase the cable locks at https://smartfind.lenovo.com.
Use the Vantage app
The preinstalled Vantage app is a customized one-stop solution to help you maintain your computer with
automated updates and fixes, configure hardware settings, and get personalized support.
To access the Vantage app, type Vantage in the Windows search box.
Key features
The Vantage app enables you to:
• Know the device status easily and customize device settings.
• Download and install UEF B OS, firmware, and driver updates to keep your computer up-to-date.
• Monitor your computer health, and secure your computer against outside threats.
• Scan your computer hardware and diagnose hardware problems.
• Look up warranty status (online).
• Access User Guide and helpful articles.
Notes:
• The available features vary depending on the computer model.
© Copyright Lenovo 2021 11

• The Vantage app makes periodic updates of the features to keep improving your experience with your
computer. The description of features might be different from that on your actual user interface.
Manage power
Use the information in this section to achieve the best balance between performance and power efficiency.
Check the battery status
Click the battery icon in the Windows notification area to check the battery status, view the current power
plan, change the power mode, and access battery settings quickly. For more details about your battery, refer
to the Vantage app.
Charge the battery
Power source of the ac power adapter:
• Power: 65 W
• Sine-wave input at 50 Hz to 60 Hz
• nput rating of the ac power adapter: 100 V to 240 V ac, 50 Hz to 60 Hz
When the battery power is low, charge your battery by connecting your computer to ac power. The 65 W ac
power adapter supports the rapid charge function, the battery is 80% charged in about one hour when the
computer is turned off. The actual charging time depends on the battery size, the physical environment, and
whether you are using the computer.
Notes: To maximize the life of the battery:
• Use the battery until the charge is depleted and recharge the battery completely before using it. Once the
battery is fully charged, it must discharge to 94% or lower before it will be allowed to recharge again.
• The battery may optimize its full charge capacity based on your usage. After prolonged periods of limited
use, full battery capacity may not be available until you discharge to as low as 20% and recharge
completely. For more information, refer to the power section of the Vantage app.
12 Lenovo K14 Gen 1 User Guide

Change the power settings
For ENERGY STAR® compliant computers, the following power plan takes effect when your computer has
been idle for a specified duration:
• Turn off the display: After 10 minutes
• Put the computer to sleep: After 10 minutes
To reset the power plan:
1. Right-click the battery status icon and select Power Options.
2. Choose or customize a power plan of your preference.
To reset the power button function:
1. Right-click the battery status icon and select Power Options ➙ Change what the power buttons do.
2. Change the settings as you prefer.
Transfer data
Quickly share your files using the built-in Bluetooth technology among devices with the same features.
Set up a Bluetooth connection
You can connect all types of Bluetooth-enabled devices to your computer, such as a keyboard, a mouse, a
smartphone, or speakers. To ensure successful connection, place the devices at most 10 meters (33 feet)
from the computer.
1. Type Bluetooth in the Windows search box and then press Enter.
2. Turn on Bluetooth, if it is off.
3. Select a Bluetooth device, and then follow the on-screen instructions.
Chapter 3.Explore your computer 13

14 Lenovo K14 Gen 1 User Guide
