Lenovo Yoga Duet 7 User manual

User Guide
Yoga Duet 7 (13″, 05)

Read this first
Before using this documentation and the product it supports, ensure that you read and understand the
fo owing:
• Appendix A “Important safety information” on page 33
• Safety and Warranty Guide
• Setup Guide
First Edition (July 2021)
© Copyright Lenovo 2021.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is de ivered pursuant to a Genera Services
Administration “GSA” contract, use, reproduction, or disc osure is subject to restrictions set forth in Contract No. GS-
35F-05925.

Contents
bout this guide . . . . . . . . . . . . . iii
Chapter 1. Meet your computer . . . . . 1
Front . . . . . . . . . . . . . . . . . . . . 1
Left . . . . . . . . . . . . . . . . . . . . 3
Right . . . . . . . . . . . . . . . . . . . . 4
Rear . . . . . . . . . . . . . . . . . . . . 5
Bottom . . . . . . . . . . . . . . . . . . . 5
B uetooth fo io keyboard . . . . . . . . . . . . 6
Features and specifications . . . . . . . . . . . 7
Statement on USB transfer rate . . . . . . . . 8
Operating environment . . . . . . . . . . . 8
Chapter 2. Get started with your
computer . . . . . . . . . . . . . . . . . 9
Work with Windows . . . . . . . . . . . . . . 9
Windows he p information . . . . . . . . . 10
Lenovo Vantage and Lenovo PC Manager . . . . 10
Use a nano SIM card (for se ected mode s) . . . . 10
Insta a nano SIM card . . . . . . . . . . 10
Use a microSD card . . . . . . . . . . . . . 11
Insta a microSD card . . . . . . . . . . 11
Combination of computer and B uetooth fo io
keyboard . . . . . . . . . . . . . . . . . 12
Use the kickstand . . . . . . . . . . . . . . 12
Use a pen . . . . . . . . . . . . . . . . . 13
Lenovo Digita Pen (for se ected mode s) . . . 14
Lenovo E-Co or Pen (for se ected mode s). . . 15
Interact with your computer . . . . . . . . . . 17
Keyboard hotkeys . . . . . . . . . . . . 17
Use the mu ti-touch screen . . . . . . . . 18
Chapter 3. Explore your computer . . 21
Manage power . . . . . . . . . . . . . . . 21
Check the battery status . . . . . . . . . 21
Charge the battery . . . . . . . . . . . . 21
Check the battery temperature . . . . . . . 21
Set power button behavior. . . . . . . . . 21
Change or create a power p an . . . . . . . 21
Set performance mode . . . . . . . . . . 22
Change settings in UEFI/BIOS setup uti ity . . . . 22
What is UEFI/BIOS setup uti ity . . . . . . . 22
Open the UEFI/BIOS setup uti ity . . . . . . 22
Change the startup sequence . . . . . . . 22
Change hotkey mode. . . . . . . . . . . 22
Enab e or disab e a ways-on . . . . . . . . 22
Set passwords in UEFI/BIOS setup uti ity . . . . . 23
Password types . . . . . . . . . . . . . 23
Set administrator password . . . . . . . . 23
Change or remove administrator password . . 23
Set user password . . . . . . . . . . . . 24
Enab e power-on password . . . . . . . . 24
Set hard disk password . . . . . . . . . . 24
Change or remove hard disk password . . . . 25
Chapter 4. Help and support . . . . . 27
Frequent y asked questions . . . . . . . . . . 27
Se f-he p resources . . . . . . . . . . . . . 27
What is a CRU? . . . . . . . . . . . . . . . 28
CRUs for your product mode . . . . . . . . . 29
Ca Lenovo . . . . . . . . . . . . . . . . 30
Before you contact Lenovo . . . . . . . . 30
Lenovo Customer Support Center . . . . . . 30
Purchase additiona services. . . . . . . . . . 31
ppendix . Important safety
information . . . . . . . . . . . . . . . 33
ppendix B. ccessibility and
ergonomic information . . . . . . . . 45
ppendix C. Compliance
information . . . . . . . . . . . . . . . 47
ppendix D. Notices and
trademarks . . . . . . . . . . . . . . . 59
© Copyright Lenovo 2021 i

ii User Guide

bout this guide
• This guide app ies to Lenovo product mode (s) isted be ow. I ustrations in this guide may ook s ight y
different from your product mode .
Model name Machine type (MT)
Yoga Duet 7 13IML05 82AS
• For further comp iance information, refer to the Generic Safety and Compliance Notices at https://
pcsupport. enovo.com/docs/generic_notices.
• This guide may contain information about accessories, features, and software that are not avai ab e on a
mode s.
• This guide contains instructions that are based on the Windows operating system. These instructions are
not app icab e if you insta and use other operating systems.
• Microsoft® makes periodic feature changes to the Windows® operating system through Windows Update.
As a resu t, the operating system re ated instructions may become outdated. Refer to Microsoft resources
for the atest information.
• The content of the guide is subject to change without notice. To obtain the atest version, go to https://
support. enovo.com.
© Copyright Lenovo 2021 iii

iv User Guide

Chapter 1. Meet your computer
Front
1. Venti ation s ots Dissipate interna heat.
Note: Do not b ock the venti ation s ots. Otherwise, the computer
might overheat.
2. Infrared LED Emit infrared ight for face authentication.
3. Front camera • Capture sti and moving images for taking photos, recording
videos, and video chatting.
• Capture your face images for face authentication.
Note: Use Windows He o to enro your face for face
authentication.
4. Camera ight If the ight is on, the camera is in use.
5. Wi-Fi antennas Send and receive radio waves for the bui t-in wire ess LAN ( oca area
network) and B uetooth modu e.
Notes:
• The antennas are not visib e from the outside of the computer.
• If the ocation of the antennas is c ose to the user’s body (< 20 cm),
you can find the Specific Absorption Rate (SAR) va ues in the Setup
Guide that comes with your computer.
6. Wire ess WAN antennas * Send and receive radio waves for the bui t-in wire ess WAN (wide area
network) modu e.
Note: The antennas are not visib e from the outside of the computer.
© Copyright Lenovo 2021 1

7. Screen Disp ay text, graphics, and videos. The screen supports mu ti-touch
function.
8. ToF sensor Detect user behavior and adjust settings automatica y.
Note: If your computer is in Tab et, Stand or Detached mode, the
sensor works at the appropriate ang e.
9. Microphones Capture or record sound and voice.
* for se ected mode s
2User Guide

Left
1. Speaker Produce sound.
2. Nano SIM card s ot* /microSD card s ot • Use the nano Subscriber Identity Modu e (SIM) card (so d
separate y) to connect to a mobi e broadband network.*
• Use the microSD card (so d separate y) to transfer or store fi es.
3. Combo audio jack Connect to headphones or headsets with a 3.5 mm (0.14 inch), 4-po e
p ug.
Note: This jack does not support standa one externa microphones. If
you use headsets, choose one with a sing e p ug.
4. Power connector/USB-CTM connector (2) • P ug the ac power adapter into the connector to provide power to
the computer and charge the interna battery.
• Connect externa disp ay, storage, or data devices.
Note: An appropriate adapter may be needed for connecting
externa devices.
* for se ected mode s
Chapter 1.Meet your computer 3

Right
1. USB-CTM connector (a ways-on) The a ways-on connector can charge externa devices when the
computer is turned off, in s eep or hibernation mode. The a ways-on
function can be turned on or off in the UEFI/BIOS setup uti ity.
Note: If Lenovo Vantage is pre-insta ed on your computer, you can
a so set a ways-on function from within that software.
2. Vo ume buttons Press the button to increase or decrease the system vo ume.
3. Power button (with a ight) • Press the button to turn on the computer or put the computer into
s eep mode.
• The power button has an integrated ight to show the power status.
– On: The computer is turned on.
– Off: The computer is turned off or in hibernation mode.
– B inking: The computer is in s eep mode.
4. Speaker Produce sound.
4User Guide

Rear
1. Rear camera Capture sti and moving images for taking photos, recording videos, and video
chatting.
2. Kickstand hinges Pivot the kickstand.
3. Kickstand Support your computer when it is p aced on a surface.
Bottom
1. Pogo pin with guide pin The pogo pin with guide pin enab es you to attach the keyboard to
your computer magnetica y.
Chapter 1.Meet your computer 5

Bluetooth folio keyboard
1. Pogo pin with guide pin The pogo pin with guide pin enab es you to attach the keyboard to your computer
magnetica y.
2. B uetooth fo io keyboard
switch
Push the switch to a different position to enab e the fo owing functions.
• Off position: Keyboard is turned off.
• Midd e position: Keyboard is turned on and wi connect with the atest
connected device.
• B uetooth icon position: Press and ho d the B uetooth fo io keyboard switch to
the B uetooth icon position for three seconds. The keyboard wi enab e
B uetooth pairing.
Note: The spring switch wi move back to the midd e position automatica y
after re easing the switch.
3. B uetooth ight • So id amber: Keyboard is charging through the pogo pin.
• Continuous y b inking white (up to 1 min): Pairing
• So id white (for three seconds) and then off: Paired
• S ow y b inking white: Keyboard is working and connected with pogo pin.
• B inking amber: Battery power is ow.
• Off:
– Keyboard is fu y charged and connected with pogo pin.
– The keyboard battery has no power.
4. Keyboard Enter characters and interact with programs.
Note: The keyboard a so inc udes hotkeys and function keys for changing
settings and performing tasks quick y.
5. Touchpad Perform finger touch and a the functions of a traditiona mouse.
Note: The touchpad a so supports mu ti-touch function.
6User Guide

Features and specifications
Dimensions • Width: 297.4 mm (11.71 inches)
• Depth: 207.36 mm (8.16 inches)
• Thickness: 9.19 mm (0.36 inches)
ac power adapter • Input: 100 V ac–240 V ac, 50 Hz–60 Hz
• Output: 20 V dc, 2.25 A
• Power: 45 W
Battery pack • Capacity: 41 Wh
• Number of ce s: 4
Microprocessor To view the microprocessor information of your computer, type system information in the
Windows search box and then press Enter.
Memory • Type: Onboard
• Number of s ots: 0
Storage device • Type: so id-state drive
• Form factor: M.2 (2242)
• Bus: PCI Express
Screen • Size: 13 inches
• Disp ay reso ution: 2160 × 1350 pixe s (WQHD mode )
B uetooth fo io
keyboard • Function keys
• Hotkeys
• Keyboard back ight
• B uetooth fo io keyboard switch
Connectors and s ots • Combo audio jack
• USB-C connector × 3 (one connector with A ways-On function)
• microSD card s ot
• Nano SIM card s ot*
Security features • UEFI/BIOS passwords
– Administrator password
– User password
– Master hard disk password
– User hard disk password
Wire ess features • B uetooth
• Wire ess LAN
• Wire ess WAN *
* for se ected mode s
Chapter 1.Meet your computer 7

Note: The battery capacity is the typica or average capacity as measured in a specific test environment.
Capacities measured in other environments may differ but are no ower than the rated capacity (see product
abe ).
Statement on USB transfer rate
Depending on many factors such as the processing capabi ity of the host and periphera devices, fi e
attributes, and other factors re ated to system configuration and operating environments, the actua transfer
rate using the various USB connectors on this device wi vary and wi be s ower than the data rate isted
be ow for each corresponding device.
USB device Data rate (Gbit/s)
3.2 Gen 1 5
3.2 Gen 2 10
3.2 Gen 2 × 2 20
Operating environment
Maximum altitude (without pressurization)
3048 m (10 000 ft)
Temperature
• At a titudes up to 2438 m (8000 ft)
– Operating: 5°C to 35°C (41°F to 95°F)
– Storage: 5°C to 43°C (41°F to 109°F)
• At a titudes above 2438 m (8000 ft)
– Maximum temperature when operating under the unpressurized condition: 31.3°C (88°F)
Note: When you charge the battery, its temperature must be no ower than 10°C (50°F).
Relative humidity
• Operating: 8% to 95% at wet-bu b temperature 23°C (73°F)
• Storage: 5% to 95% at wet-bu b temperature 27°C (81°F)
The B uetooth fo io keyboard bottom cover is fabric. Hand e your keyboard with care so that you can enjoy
this product for a ong time. If possib e, p ace your computer in a dry, we -venti ated area without direct
exposure to sunshine. Do not use or store your computer in dusty, dirty areas, or extreme y hot or co d areas.
8User Guide

Chapter 2. Get started with your computer
Work with Windows
The fo owing tab e contains Windows frequent y used settings. You can earn the basics and start working
with Windows right away.
To configure settings, type the corresponding keywords in the Windows search box and se ect the best
match. Fo ow the on-screen instructions to customize settings.
Table 1. Basic settings
Functions Descriptions Search by
keywords
Contro Pane View or change Windows settings, inc uding hardware and software setup
and configuration.
Contro Pane
Connect to Wi-Fi
networks
For mode s with a wire ess LAN modu e, you can connect your computer to
a Wi-Fi® network. C ick the network icon in the Windows notification area,
and then se ect a network for connection.
Note: The wire ess LAN modu e on your computer may support different
standards. For some countries or regions, use of 802.11ax may be disab ed
according to oca regu ations.
Wi-Fi
Connect a
B uetooth device
B uetooth is a short-range wire ess communications techno ogy. Use
B uetooth to estab ish a wire ess connection between your computer and
another B uetooth-enab ed device within a distance of about 10 m (32.8 ft).
Notes:
• If the B uetooth device supports Swift Pair, you wi receive a notification
when it is nearby.
• For more information, see the document that comes with the B uetooth
device.
B uetooth
Airp ane mode Airp ane mode is a convenient setting to turn a wire ess communications of
your computer on and off. You may need to turn it on when boarding an
airp ane.
Airp ane mode
Night ight mode Night ight is a switch in Windows that you can turn on and off. When it is
turned on, your screen shows warmer co ors and the amount of emitted
b ue ight is reduced. Enab ing night ight reduces the chances of deve oping
eye fatigue or eye strain.
Note: For more guidance on reducing eye fatigue or eye strain, go to
https://www. enovo.com/us/en/comp iance/visua -fatigue.
Night ight
Windows
Updates
Microsoft periodica y re eases feature and security updates to the Windows
operating system. Updates that are app icab e to your Windows version are
down oaded automatica y when your computer is connected to the
Internet. When updates are down oaded, you are prompted to restart the
computer to insta these updates. You can a so manua y check if there are
avai ab e updates for the insta ed version of Windows.
ttention: On y use Windows Update to down oad and insta updates.
Updates down oaded from other sources may inc ude security risks.
Windows Updates
© Copyright Lenovo 2021 9

Table 2. Optional settings
Functions Descriptions Search by
keywords
Set up face
recognition
For mode s with a Windows He o-compatib e infrared camera, you can set
up face recognition to sign in with your face.
Sign-in options
Windows help information
If the on-screen instructions cannot so ve your prob em, refer to the fo owing to get the on ine Windows he p
information.
• Type Get He p or Tips in the Windows search box and then press Enter. When the app opens, type the
prob em description and se ect the matched resu t.
• Visit Microsoft support Web site: https://support.microsoft.com. Enter what you are ooking for in the
search box and get search resu ts.
Lenovo Vantage and Lenovo PC Manager
Lenovo Vantage and Lenovo PC Manager is software deve oped by Lenovo. Using the software, you can:
• View product information
• View warranty and support information
• Run hardware scan and diagnose prob ems
• Change hardware settings
• Update Windows, drivers, and UEFI/BIOS
Lenovo Vantage or PC Manager may be pre-insta ed on your computer. To open it, enter the software name
in Windows Search and se ect the matched resu t.
Note: If Lenovo Vantage is not pre-insta ed, you can down oad it from Microsoft Store.
Use a nano SIM card (for selected models)
If your computer has a nano SIM card s ot on the eft side of the computer, you can insert a nano SIM card
into the nano SIM card s ot to estab ish wire ess WAN connections.
Install a nano SIM card
Step 1. Use an ejection too to eject the card tray, and then s ide the tray out of the computer.
Step 2. Insta a new nano SIM card into the tray and insert the tray into the card s ot. Ensure that the new
nano SIM card is insta ed in the correct orientation.
10 User Guide

Use a microSD card
Your computer has a microSD card s ot on the eft side of the computer. You can insert a microSD card into
the microSD card s ot to expand the computer oca storage capacity.
ttention:
• Before hand ing the microSD card, touch a meta tab e or a grounded meta object. Otherwise the card
might get damaged by the static e ectricity from your body.
• During data transfer, do not put your computer into s eep mode; otherwise, your data cou d get damaged.
Install a microSD card
Step 1. Use an ejection too to eject the card tray, and then s ide the tray out of the computer.
Step 2. Insta a new microSD card into the tray and insert the tray into the card s ot. Ensure that the new
microSD card is insta ed in correct orientation.
Chapter 2.Get started with your computer 11

Combination of computer and Bluetooth folio keyboard
A ign the connector of the keyboard with the computer and then attach the computer in the direction shown
by the arrow.
Note: Pair the B uetooth fo io keyboard with the computer the first time you use the keyboard. The B uetooth
fo io keyboard supports swift pair.
Use the kickstand
Your computer has a bui t-in kickstand. Pivot the kickstand from the pits on both sides of the computer to
the open position as shown.
12 User Guide

With the kickstand open, you can use the computer in the fo owing modes.
• Stand mode without B uetooth fo io keyboard attached
• Stand mode with B uetooth fo io keyboard attached
• Sty us mode
The kickstand is mu ti-positiona . You can adjust the kickstand to various ang es for a comfortab e user
experience.
ttention: The appropriate kickstand ang e is 45º–150º. Using the kickstand at an improper ang e may
damage the computer.
Use a pen
Depending on the mode , your computer might come with a pen. The pen enab es you to write and draw in a
natura manner.
Chapter 2.Get started with your computer 13

You can view or change functions of pen buttons in the Lenovo Pen Settings. For more information, refer to
the User Guide of the software.
Notes:
• The pen is not waterproof. Take care not to drop the pen in water.
• The pen contains pressure sensors. Do not push the tip of the pen for an extended period of time. Do not
subject the pen to shock or vibration.
• The defau t function of each pen button might vary in different apps.
• The Lenovo Pen Settings may be pre-insta ed on your computer. To open it, enter the software name in
Windows Search and se ect the matched resu t. If the software is not pre-insta ed, you can down oad and
insta the atest drivers from https://support. enovo.com.
Lenovo Digital Pen (for selected models)
The Lenovo Digita Pen referred to as the pen in this section.
1. Pen cap Unscrew the pen cap to insta or rep ace a battery.
2. Top barre button To right-c ick, ho d the button and tap the screen in supported app ications.
3. Bottom barre button To erase text or drawings, ho d the button to erase the object in supported
app ications.
4. Pen tip Write or draw on the touch screen.
14 User Guide
