Lenovo ThinkServer RD120 Original instructions

Safety Information

Safety Information

First Edition (September 2008)
©Copyright Lenovo 2008.
Portions ©Copyright International Business Machines Corporation 2006.
All rights reserved.
LENOVO products, data, computer software, and services have been developed exclusively at private expense and
are sold to governmental entities as commercial items as defined by 48 C.F.R. 2.101 with limited and restricted
rights to use, reproduction and disclosure.
LIMITED AND RESTRICTED RIGHTS NOTICE: If products, data, computer software, or services are delivered
pursuant aGeneral Services Administration ″GSA″contract, use, reproduction, or disclosure is subject to restrictions
set forth in Contract No. GS-35F-05925.

Contents
Chapter 1. English ......... 1-1
Chapter 2. Arabic .......... 2-1
Chapter 3. Brazilian Portuguese ... 3-1
Chapter 4. Bulgarian ........ 4-1
Chapter 5. (Simplified) Chinese .... 5-1
Chapter 6. (Traditional) Chinese.... 6-1
Chapter 7. Croatian ......... 7-1
Chapter 8. Czech .......... 8-1
Chapter 9. Danish.......... 9-1
Chapter 10. Dutch ......... 10-1
Chapter 11. Finnish ........ 11-1
Chapter 12. French......... 12-1
Chapter 13. German ........ 13-1
Chapter 14. Greek ......... 14-1
Chapter 15. Hebrew ........ 15-1
Chapter 16. Hungarian ....... 16-1
Chapter 17. Italian ......... 17-1
Chapter 18. Japanese ....... 18-1
Chapter 19. Korean ........ 19-1
Chapter 20. Macedonian ...... 20-1
Chapter 21. Norwegian ....... 21-1
Chapter 22. Polish ......... 22-1
Chapter 23. Portuguese....... 23-1
Chapter 24. Romanian ....... 24-1
Chapter 25. Serbian-Latin ...... 25-1
Chapter 26. Slovakian ....... 26-1
Chapter 27. Slovenian ....... 27-1
Chapter 28. Spanish ........ 28-1
Chapter 29. Swedish ........ 29-1
Chapter 30. Turkish ........ 30-1
Chapter 31. Ukrainian ....... 31-1
©Lenovo 2008. Portions ©IBM Corp. 2006. iii

iv Safety Information

Chapter 1. English
Important:
Each caution and danger statement in this document is labeled with a
number. This number is used to cross reference an English-language
caution or danger statement with translated versions of the caution or
danger statement in the Safety Information document.
For example, if acaution statement is labeled “Statement 1”,
translations for that caution statement are in the Safety Information
document under “Statement 1”.
Be sure to read all caution and danger statements in this document
before you perform the procedures. Read any additional safety
information that comes with the server or optional device before you
install the device.
©Lenovo 2008. Portions ©IBM Corp. 2006. 1-1

Statement 1:
DANGER
Electrical current from power, telephone, and communication cables is
hazardous.
To avoid ashock hazard:
vDo not connect or disconnect any cables or perform installation,
maintenance, or reconfiguration of this product during an electrical storm.
vConnect all power cords to aproperly wired and grounded electrical outlet.
vConnect to properly wired outlets any equipment that will be attached to
this product.
vWhen possible, use one hand only to connect or disconnect signal cables.
vNever turn on any equipment when there is evidence of fire, water, or
structural damage.
vDisconnect the attached power cords, telecommunications systems,
networks, and modems before you open the device covers, unless
instructed otherwise in the installation and configuration procedures.
vConnect and disconnect cables as described in the following table when
installing, moving, or opening covers on this product or attached devices.
To Connect: To Disconnect:
1. Turn everything OFF.
2. First, attach all cables to devices.
3. Attach signal cables to connectors.
4. Attach power cords to outlet.
5. Turn device ON.
1. Turn everything OFF.
2. First, remove power cords from outlet.
3. Remove signal cables from connectors.
4. Remove all cables from devices.
1-2 Safety Information

Statement 2:
CAUTION:
When replacing the lithium battery, use only the battery recommended by the
manufacturer. If your system has amodule containing alithium battery, replace
it only with the same module type made by the same manufacturer. The battery
contains lithium and can explode if not properly used, handled, or disposed of.
Do not:
vThrow or immerse into water
vHeat to more than 100°C (212°F)
vRepair or disassemble
Dispose of the battery as required by local ordinances or regulations.
Statement 3:
CAUTION:
When laser products (such as CD-ROMs, DVD drives, fiber optic devices, or
transmitters) are installed, note the following:
vDo not remove the covers. Removing the covers of the laser product could
result in exposure to hazardous laser radiation. There are no serviceable parts
inside the device.
vUse of controls or adjustments or performance of procedures other than those
specified herein might result in hazardous radiation exposure.
DANGER
Some laser products contain an embedded Class 3A or Class 3B laser diode.
Note the following.
Laser radiation when open. Do not stare into the beam, do not view directly
with optical instruments, and avoid direct exposure to the beam.
Chapter 1. English 1-3

Statement 4:
≥18 kg (39.7 lb) ≥32 kg (70.5 lb) ≥55 kg (121.2 lb)
CAUTION:
Use safe practices when lifting.
Statement 5:
CAUTION:
The power control button on the device and the power switch on the power
supply do not turn off the electrical current supplied to the device. The device
also might have more than one power cord. To remove all electrical current from
the device, ensure that all power cords are disconnected from the power source.
1
2
Statement 6:
CAUTION:
If you install astrain-relief bracket option over the end of the power cord that is
connected to the device, you must connect the other end of the power cord to an
easily accessible power source.
1-4 Safety Information

Statement 7:
CAUTION:
If the device has doors, be sure to remove or secure the doors before moving or
lifting the device to avoid personal injury. The doors will not support the
weight of the device.
Statement 8:
CAUTION:
Never remove the cover on apower supply or any part that has the following
label attached.
Hazardous voltage, current, and energy levels are present inside any component
that has this label attached. There are no serviceable parts inside these
components. If you suspect aproblem with one of these parts, contact aservice
technician.
Statement 9:
CAUTION:
To avoid personal injury, disconnect the hot-swap fan cables before removing
the fan from the device.
Chapter 1. English 1-5

Statement 10:
CAUTION:
Do not place any object weighing more than 82 kg (180 lb) on top of
rack-mounted devices.
>82 kg (180 lb)
Statement 11:
CAUTION:
The following label indicates sharp edges, corners, or joints nearby.
Statement 12:
CAUTION:
The following label indicates ahot surface nearby.
1-6 Safety Information

Statement 13:
DANGER
Overloading abranch circuit is potentially afire hazard and ashock hazard
under certain conditions. To avoid these hazards, ensure that your system
electrical requirements do not exceed branch circuit protection requirements.
Refer to the information that is provided with your device for electrical
specifications.
Statement 14:
CAUTION:
Hazardous voltage, current, and energy levels might be present. Only aqualified
service technician is authorized to remove the covers where the following label
is attached.
Statement 15:
CAUTION:
Make sure that the rack is secured properly to avoid tipping when the server
unit is extended.
Statement 16:
CAUTION:
Some accessory or option board outputs exceed Class 2or limited power source
limits and must be installed with appropriate interconnecting cabling in
accordance with the national electric code.
Chapter 1. English 1-7

Statement 17:
CAUTION:
The following label indicates moving parts nearby.
Statement 18:
CAUTION:
To reduce the risk of electric shock or energy hazards:
vThis equipment must be installed by trained service personnel in a
restricted-access location, as defined by the NEC and IEC 60950, Third Edition,
The Standard for Safety of Information Technology Equipment.
vConnect the equipment to areliably grounded safety extra low voltage (SELV)
source. An SELV source is asecondary circuit that is designed so that normal
and single fault conditions do not cause the voltages to exceed asafe level (60
Vdirect current).
vThe branch circuit overcurrent protection must be rated at aminimum of 5A
to amaximum of 15 A.
vUse 14 American Wire Gauge (AWG) or 2.5 mm2copper conductor only, not
exceeding 3meters in length.
vTorque the wiring-terminal screws to 12 inch-pounds (1.4 newton-meters).
vIncorporate areadily available approved and rated disconnect device in the
field wiring.
Statement 19:
CAUTION:
The power-control button on the device does not turn off the electrical current
supplied to the device. The device also might have more than one connection to
dc power. To remove all electrical current from the device, ensure that all
connections to dc power are disconnected at the dc power input terminals.
OFF
1-8 Safety Information

Statement 20:
CAUTION:
To avoid personal injury, before lifting the unit, remove all the blades to reduce
the weight.
Statement 21:
CAUTION:
Hazardous energy is present when the blade is connected to the power source.
Always replace the blade cover before installing the blade.
Statement 22:
CAUTION:
To reduce the risk of electric shock or energy hazards:
vThis equipment must be installed by trained service personnel in a
restricted-access location, as defined by the NEC and IEC 60950, Third Edition,
The Standard for Safety of Information Technology Equipment.
vConnect the equipment to areliably grounded safety extra low voltage (SELV)
source. An SELV source is asecondary circuit that is designed so that normal
and single fault conditions do not cause the voltages to exceed asafe level (60
Vdirect current).
vThe branch circuit overcurrent protection must be rated at aminimum of 13 A
to amaximum of 15 A.
vUse 16 American Wire Gauge (AWG) or 1.3 mm2copper conductor only, not
exceeding 3meters in length.
vTorque the wiring-terminal screws to 12 inch-pounds (1.4 newton-meters).
vIncorporate areadily available approved and rated disconnect device in the
field wiring.
Chapter 1. English 1-9

Statement 23:
CAUTION:
Do not place any object weighing more than 50 kg (110 lb) on top of
rack-mounted devices.
>50 kg (110 lb)
Statement 24:
CAUTION:
To reduce the risk of electric shock or energy hazards:
vThis equipment must be installed by trained service personnel in a
restricted-access location, as defined by the NEC and IEC 60950, Third Edition,
The Standard for Safety of Information Technology Equipment.
vConnect the equipment to areliably grounded safety extra low voltage (SELV)
source. An SELV source is asecondary circuit that is designed so that normal
and single fault conditions do not cause the voltages to exceed asafe level (60
Vdirect current).
vThe branch circuit overcurrent protection must be rated at aminimum of 12 A
to amaximum of 15 A.
vUse 14 American Wire Gauge (AWG) or 2.5 mm2copper conductor only, not
exceeding 3meters in length.
vTorque the wiring-terminal screws to 12 inch-pounds (1.4 newton-meters).
vIncorporate areadily available approved and rated disconnect device in the
field wiring.
Statement 25:
CAUTION:
This product contains aClass 1M laser. Do not view directly with optical
instruments.
1-10 Safety Information

Statement 26:
CAUTION:
Do not place any object on top of rack-mounted devices.
Statement 27:
CAUTION:
Hazardous moving parts are nearby.
Statement 28:
CAUTION:
The battery is alithium ion battery. To avoid possible explosion, do not burn the
battery. Exchange it only with the Lenovo-approved part. Recycle or discard the
battery as instructed by local regulations.
Chapter 1. English 1-11

Statement 29:
CAUTION:
This equipment is designed to permit the connection of the earthed conductor of
the dc supply circuit to the earthing conductor at the equipment. If this
connection is made, all of the following conditions must be met:
vThis equipment shall be connected directly to the dc supply system earthing
electrode conductor or to abonding jumper from an earthing terminal bar or
bus to which the dc supply system earthing electrode conductor is connected.
vThis equipment shall be located in the same immediate area (such as, adjacent
cabinets) as any other equipment that has aconnection between the earthed
conductor of the same dc supply circuit and the earthing conductor, and also
the point of earthing of the dc system. The dc system shall not be earthed
elsewhere.
vThe dc supply source shall be located within the same premises as this
equipment.
vSwitching or disconnecting devices shall not be in the earthed circuit
conductor between the dc source and the point of connection of the earthing
electrode conductor.
Statement 30:
CAUTION:
To reduce the risk of electric shock or energy hazards:
vThis equipment must be installed by trained service personnel in a
restricted-access location, as defined by the NEC and IEC 60950-1, First
Edition, The Standard for Safety of Information Technology Equipment.
vConnect the equipment to areliably grounded safety extra low voltage (SELV)
source. An SELV source is asecondary circuit that is designed so that normal
and single fault conditions do not cause the voltages to exceed asafe level (60
Vdirect current).
vThe branch circuit overcurrent protection must be rated 20 A.
vUse 12 American Wire Gauge (AWG) or 2.5 mm2copper conductor only, not
exceeding 4.5 meters in length.
vIncorporate areadily available approved and rated disconnect device in the
field wiring.
1-12 Safety Information

Chapter 2. Arabic 2-1
ﻞﺼﻔﻟا٢.ﺔﻴﺑﺮﻌﻟا
مﺎه:
ﻢﻗر ﺔﻘﻴﺛﻮﻟا ﻩﺬه ﻲﻓ ةدﻮﺟﻮﻤﻟا ،ﺮﻄﺨﻟا وأ ﻪﻴﺒﻨﺘﻟا تارﺎﺒﻋ ءاﻮﺳ ،ةرﺎﺒﻋ ﻞﻜﻟ نﻮﻜﻳﻦﻴﻌﻣ.ﻰﻟا لﻮﺻﻮﻠﻟ ﻢﻗﺮﻟا اﺬه ماﺪﺨﺘﺳا ﻢﺘﻳو
ﺮﻄﺨﻟا وأ ﻪﻴﺒﻨﺘﻟا تارﺎﺒﻋ ﻦﻣ ﺔﻤﺟﺮﺘﻤﻟا ﺦﺴﻨﻟاﺔﻘﻴﺛو ﻲﻓ ةدﻮﺟﻮﻣ نﻮﻜﺗ ﻲﺘﻟاو ﺔﻳﺰﻴﻠﺠﻧﻻا ﺔﻐﻠﻟﺎﺑ ﺔﺑﻮﺘﻜﻤﻟا
تﺎﻈﺣﻼﻤﻟا ﺔﻴﻨﻣﻷا .
ﻢﺳﻻﺎﺑ ﻪﻴﺒﻨﺗ ةرﺎﺒﻋ دﻮﺟو ﺔﻟﺎﺣ ﻲﻓ ،لﺎﺜﻤﻟا ﻞﻴﺒﺳ ﻰﻠﻋ"ةرﺎﺒﻌﻟا١"دﻮﺟﻮﻣ ﺎﻬﺑ ﺔﺻﺎﺨﻟا ﺔﻤﺟﺮﺘﻟا ﺬﺋﺪﻨﻋ نﻮﻜﺘﺳ ،ﺔﻘﻴﺛو ﻲﻓ ة
ﺔﻴﻨﻣﻷا تﺎﻈﺣﻼﻤﻟا ﻮهو ﻢﺳﻻا ﺲﻔﻨﺑ"ةرﺎﺒﻌﻟا١".
ﺬﻴﻔﻨﺗ ﻲﻓ ءﺪﺒﻟا ﻞﺒﻗ ﺔﻘﻴﺛﻮﻟا ﻩﺬه ﻲﻓ ةدﻮﺟﻮﻤﻟا ﺮﻄﺨﻟاو ﻪﻴﺒﻨﺘﻟا تارﺎﺒﻋ ﻞآ ةءاﺮﻗ ﺐﺠﻳتاءاﺮﺟﻻا.ﺔﻴﻓﺎﺿا ﺔﻴﻨﻣأ تﺎﻈﺣﻼﻣ يأ أﺮﻗا
زﺎﻬﺠﻟا ﻊﻣ وأ ﺔﻣﺪﺨﻟا ةﺪﺣو ﻊﻣ ﺎﻬﻟﺎﺳرا ﻢﺘﻳزﺎﻬﺠﻟا ﺐﻴآﺮﺗ ﻲﻓ ءﺪﺒﻟا ﻞﺒﻗ ﻚﻟذو يرﺎﻴﺘﺧﻻا.

Safety Information2-2
ةرﺎﺒﻌﻟا١
ﺮﻄﺧ
نﻮﻔﻴﻠﺘﻟاو ﺔﻗﺎﻄﻟا تﻼﺑﺎآ ﻦﻣ ﺞﺗﺎﻨﻟا ﻲﺋﺎﺑﺮﻬﻜﻟا رﺎﻴﺘﻟاو ﺪﻬﺠﻟاﺔﻐﻟﺎﺑ ةرﻮﻄﺧ ﻪﺑ تﻻﺎﺼﺗﻻاو.
تﺎﻣﺪﺼﻟا ﺮﻃﺎﺨﻣ يدﺎﻔﺘﻟو:
•ﺎﻴﻘﻟا وأ كﻼﺳأ يأ ﻞﺼﻓ وأ ﻞﻴﺻﻮﺗ لوﺎﺤﺗ ﻻ،ﺐﻴآﺮﺗ تﺎﻴﻠﻤﻋ يﺄﺑ موأ ﺔﻧﺎﻴﺻ وأﺔﻴﺋﺎﺑﺮﻬآ ﺔﻔﺻﺎﻋ دﻮﺟو ءﺎﻨﺛأ ﺞﺘﻨﻤﻟا اﺬﻬﻟ ﻒﻴﺻﻮﺗ ةدﺎﻋا. •تﻼﻴﺻﻮﺗ ﺎﻬﻟو ﺔﺤﻴﺤﺻ تﻼﻴﺻﻮﺗ تاذ ءﺎﺑﺮﻬآ جرﺎﺨﻣ ﻰﻟا ﺔﻗﺎﻄﻟا كﻼﺳأ ﻞآ ﻞﻴﺻﻮﺘﺑ ﻢﻗﺔﺤﻴﺤﺻ ﺔﻴﺿرأ. •جرﺎﺨﻣ ﻰﻟا ﺞﺘﻨﻤﻟا اﺬﻬﺑ ﺎﻬﻠﻴﺻﻮﺗ ﻢﺘﻴﺳ ﻲﺘﻟا ةﺰﻬﺟﻷا ﻦﻣ زﺎﻬﺟ يأ ﻞﻴﺻﻮﺘﺑ ﻢﻗكﻼﺳﻷا. •ﻜﻣأ ناوﺔﻗﺎﻄﻟا كﻼﺳأ ﻞﺼﻓ وأ ﻞﻴﺻﻮﺘﻟ ﻂﻘﻓ ةﺪﺣاو ﺪﻳ ماﺪﺨﺘﺳا ﺐﺠﻳ ،ﻦ. •ﻪﻠﻜﻴه ﻲﻓ ﻒﻠﺗ ثوﺪﺣ وأ ءﺎﻤﻟا وأ ﻖﻳﺮﺤﻠﻟ ضﺮﻌﺗ زﺎﻬﺟ يأ ﻞﻴﻐﺸﺘﺑ ﺎﻘﻠﻄﻣ ﻢﻘﺗ ﻻ. •تﻻﺎﺼﺗﻻا تﺎﻜﺒﺷو ﺪﻌﺑ ﻦﻋ لﺎﺼﺗﻻا ﺔﻤﻈﻧأ ﻞﺼﻓو ﺔﻠﺼﺘﻤﻟا ءﺎﺑﺮﻬﻜﻟا كﻼﺳأ عﺰﻨﺑ ﻢﻗﺢﺘﻓ ﻞﺒﻗ ﻚﻟذو ،مدﻮﻤﻟا ﻰﻟا ﺔﻓﺎﺿﻻﺎﺑ
ﺎﺸﻳ ﻢﻟ ﺎﻣ ،ﺔﻟﻵا ءﺎﻄﻏتﺎﻤﻴﻠﻌﺗ ﻲﻓ ﻚﻟذ ﺮﻴﻏ ﻰﻟا رﻒﻴﺻﻮﺘﻟاو ﺐﻴآﺮﺘﻟا. •وأ ﺐﻴآﺮﺗ ءﺎﻨﺛأ ﻚﻟذو ﻲﻟﺎﺘﻟا لوﺪﺠﻟا ﻲﻓ ﺢﺿﻮﻣ ﻮه ﺎﻤآ تﻼﺑﺎﻜﻟا عﺰﻧو ﻞﻴﺻﻮﺘﺑ ﻢﻗوأ زﺎﻬﺠﻟا اﺬه ءﺎﻄﻏ ﺢﺘﻓ وأ ﻞﻘﻧ
ﻪﺑ ﺔﻠﺼﺘﻤﻟا ةﺰﻬﺟﻷا.
ءﺎﺑﺮﻬﻜﻟا ﻞﻴﺻﻮﺘﻟ:
ءﺎﺑﺮﻬﻜﻟا ﻞﺼﻔﻟ:
١.ءﻲﺷ يأ ﻞﻴﻐﺸﺗ فﺎﻘﻳﺎﺑ ﻢﻗ. ٢.ﺎﺑ تﻼﺑﺎﻜﻟا ﻞآ ﻞﻴﺻﻮﺘﺑ ،ﻻوأ ،ﻢﻗةﺰﻬﺟﻷ. ٣.تﻼﺻﻮﻤﻠﻟ ةرﺎﺷﻻا تﻼﺑﺎآ ﻞﻴﺻﻮﺘﺑ ﻢﻗ. ٤.جرﺎﺨﻤﻟا ﻰﻟا ءﺎﺑﺮﻬﻜﻟا كﻼﺳأ ﻞﻴﺻﻮﺘﺑ ﻢﻗ. ٥.زﺎﻬﺠﻟا ﻞﻴﻐﺸﺘﺑ ﻢﻗ. ١.ءﻲﺷ يأ ﻞﻴﻐﺸﺗ فﺎﻘﻳﺎﺑ ﻢﻗ. ٢.ﺎﻬﺟرﺎﺨﻣ ﻦﻣ ءﺎﺑﺮﻬﻜﻟا كﻼﺳأ عﺰﻨﺑ ،ﻻوأ ،ﻢﻗ. ٣.تﻼﺻﻮﻤﻟا ﻦﻣ ةرﺎﺷﻻا تﻼﺑﺎآ عﺰﻨﺑ ﻢﻗ. ٤.ةﺰﻬﺟﻷا ﻦﻣ تﻼﺑﺎﻜﻟا ﻞآ عﺰﻨﺑ ﻢﻗ.
