Lenovo IdeaTab S2110A User manual

Lenovo IdeaTab
S2110A
User Guide V1.0
Readthe
safety notices and important tips in the
included manuals before using yourcomputer.















FirstEdition(June2011)
©CopyrightLenovo2011.

LENOVOproducts,data,computersoftware,andserviceshavebeendevelopedexclusivelyatprivate
expenseandaresoldtogovernmentalentitiesascommercialitemsasdefinedby48C.F.R.2.101with
limitedandrestrictedrightstouse,reproductionanddisclosure.LIMITEDANDRESTRICTED
RIGHTSNOTICE:Ifproducts,data,computersoftware,orservicesaredeliveredpursuantaGeneral
ServicesAdministration“GSA”contract,use,reproduction,ordisclosureissubjecttorestrictionsset
forthinContractNo.GS‐35F‐05925.

Contents
i



Chapter 1. Getting to know your
computer...................................
1
Frontview .......................................1

Left‐sideview
.................................2

Right‐side
view...............................3

Top
view  ..........................................4

Bottom
view  ....................................5

Rear
view  .........................................6

Dockingfrontview
(optional)  ......7

Dockingtopview
(optional).........8

Dockingleftview
(optional)  .........9

Chapter 2. Learning the
basics ...................................... 10
First use..........................................10

UsingACadapterandbattery
...11

Connectingexternal
devices  .......13

Chapter 3. Connecting to the
Internet .................................... 15
Wiredconnection .........................15

Wireless
connection.....................16

Specifications......................... 17

Chapter 1. Getting to know
y
our computer
1
Front view-----------------------------------------------------------------------------------------------
b a
No tes: Theillustrationsinthismanualmaydifferfromtheactualproduct.Pleasereferto
theactualproduct.

a Front camera Usethecameraforvideocommunication.

b Screen Thetouchscreenallowsyoutooperatethepadusing
multi‐touchfingers.

Chapte
r
1. Getting to know
y
ou
r
compute
r
2



Left-side view --------------------------------------------------------------------------------------
a b c d
a Speaker Thestereospeakersproviderichandpowerfulsound.

b Combo audio
jack Connectstoheadphonesorheadsets.Thecomboaudio
jackdoesnotsupportconventionalmicrophones.

c Micro HDMI port ConnectstodeviceswithHDMIinputsuchasaTVora
display.

d SIM card slot (On
select models) InsertaSIMcard(notsupplied)forusingMobile
Broadband.

3
Chapte
r
1. Getting to know
y
ou
r
compute
r



Right-side view ----------------------------------------------------------------------------------
b a
a Speaker Thestereospeakersproviderichandpowerfulsound.

b Volume Button Adjuststhevolume.

4
Chapte
r
1. Getting to know
y
ou
r
compute
r



Top view ---------------------------------------------------------------------------------------------------
a
a
Power button PressthisbuttontoturnontheIdeaTab.

5
Chapte
r
1. Getting to know
y
ou
r
compute
r



Bottom view------------------------------------------------------------------------------------------
a
a Position-limit
hole
b Docking
connector
(compatible with
micro USB)
b
InserttheIdeaTabintothedockthroughthisholetofix
thescreenpanel.

Insertthepoweradapter,USBcableorconnecttothe
dockthroughthisport.

6
Chapte
r
1. Getting to know
y
ou
r
compute
r



Rear view-------------------------------------------------------------------------------------------------
a b
a Flash
b Back Camera Usethecameraforvideocommunication.

7
Chapte
r
1. Getting to know
y
ou
r
compute
r



Docking front view (optional)------------------------------------------------
a
c b
a Position-limit
hole
b Docking
connector
InserttheIdeaTabintothedockthroughthisholetofix
thescreenpanel.

InserttheIdeaTabintothedockthroughthisconnector.

c Memory card slot Insertmemorycards(notsupplied)here.

8
Chapte
r
1. Getting to know
y
ou
r
compute
r



Docking top view (optional) ----------------------------------------------------
a
b
a Keypad TheKeypadfunctionsasaconventionalkeyboard.

b Touch pad TheTouchpadfunctionsasaconventionalmouse.

9
Chapte
r
1. Getting to know
y
ou
r
compute
r



Docking left view (optional) ----------------------------------------------------
a b
a
Micro HDMI port ConnectstothedockstochargetheIdeaTab.

b USB port ConnecttoUSBdevices.

10
Chapter 2. Learning the basics
First use -------------------------------------------------------------------------------------------------------
Reading the manuals
Readthesuppliedmanualsbeforeusingyourcomputer.

Connecting to the power
Thesuppliedbatterypackisnotfullychargedatpurchase.
Tochargethebatteryandbeginusingyourcomputer,insertthebatterypack
andconnectthecomputertoanelectricaloutlet.Thebatteryisautomatically
chargedwhilethecomputerisrunningonACpower.

Installing the battery pack
RefertothesuppliedSetupPostertoinstallthebatterypack.

Connecting the computer to an electrical outlet
1 ConnectthepowercordtotheACadapter.
2 ConnecttheACadaptertotheACpoweradapterjackofthecomputer
firmly.
3 Plugthepowercordintoanelectricaloutlet.

Turning on the computer
Pressthepowerbuttontoturnonthecomputer.

Configuring the operating system
Youmayneedtoconfiguretheoperatingsystemwhenitisfirstused.The
configurationprocessmayincludetheproceduresbelow.
•Acceptingtheenduserlicenseagreement
•ConfiguringtheInternetconnection
•Registeringtheoperatingsystem
•Creatingauseraccount





11
Chapte
r
2. Lea
r
ning the basics



Using AC adapter and battery ----------------------------------------------------------
Checking battery status
Youcandeterminethepercentageofbatterypowerremainingbychecking
thebatteryiconinthenotificationarea.
Note: Aseachcomputeruserhasdifferenthabitsandneeds,itisdifficulttopredicthow
longabatterychargewilllast.Therearetwomainfactors:
•Theamountofenergystoredinthebatterywhenyoucommencework.
•Thewayyouuseyourcomputer:forexample,howoftenyouaccesstheharddisk
driveandhowbrightyoumakethecomputerdisplay.


Charging the battery
Whenyoufindthatthebatterypowerislow,youneedtochargethebattery
orreplaceitwithafullychargedone.


Youneedtochargethebatteryinanyofthefollowingsituations:
•Whenyoupurchaseanewbattery
•Ifthebatterystatusindicatorstartsblinking
•Ifthebatteryhasnotbeenusedforalongtime
Notes:
• Youareadvisedtoinsertthebatterypackwhenusingyourcomputertopreventsmall
particlesfromenteringtheinsideofyourcomputer.
• Toincreasethelifeofthebatterypack,thecomputerdoesnotstartrechargingthe
batteryimmediatelyafteritdropsfromfullycharged.
• Chargethebatteryatatemperaturebetween50°Fand86°F(10°C‐30°C).
• Fullchargeordischargeisnotrequired.



12
Chapte
r
2. Lea
r
ning the basics



Removing the battery pack
Ifyouarenotgoingtousethecomputerforanextendedperiodoftime,orif
youneedtosendyourcomputertoLenovoforservice,etc.removethe
batterypackfromthecomputer.Beforeremovingthebatterypack,
make
sure
thecomputerhasbeenshutdown.

Handling the battery
Iftherechargeablebatterypackisreplacedwithanincorrecttype,theremay
bedangerofanexplosion.Thebatterypackcontainsasmallamountof
harmfulsubstances.Toavoidpossibleinjuryanddetrimenttothe
environment,payattentiontothefollowingpoints:
•ReplaceonlywithabatteryofthetyperecommendedbyLenovo.
•Keepthebatterypackawayfromfire.
•Donotexposethebatterypacktowaterorrain.
•Donotattempttodisassemblethebatterypack.
•Donotshort‐circuitthebatterypack.
•Keepthebatterypackawayfromchildren.
•Donotputthebatterypackintrashthatisdisposedofinlandfills.When
disposingofthebattery,complywithlocalordinancesorregulationsand
yourcompany’ssafetystandards.



13
Chapte
r
2. Lea
r
ning the basics



Connecting external devices ------------------------------------------------------------
Yourcomputerhasawiderangeofbuilt‐infeaturesandconnection
capabilities.

Using memory cards (not supplied)
Yourcomputersupportsthefollowingtypesofmemorycards:
•SecureDigital(SD)card
•MultiMediaCard(MMC)
•SecureDigitalHighCapacity(SDHC)card
Notes:
• InsertONLYonecardintheslotatatime.
• ThiscardreaderdoesnotsupportSDIOdevices(e.g.,SDIOBluetooth,etc.).

Inserting a memory card
1 Pushthedummycarduntilyouhearaclick.Gentlypullthedummycard
outofthememorycardslot.

Note: Thedummycardisusedforpreventingdustandsmallparticlesfromenteringthe
insideofyourcomputerwhenthememorycardslotisnotinuse.Retainthedummy
cardforfutureuse.
2 Slidethememorycardinuntilitclicksintoplace.
Removing a memory card
1 Pushthememorycarduntilyouhearaclick.
2 Gentlypullthememorycardoutofthememorycardslot.

Note: Beforeremovingthememorycard,disableitviaWindowssafelyremovehardware
andejectmediautilitytoavoiddatacorruption.


14
Chapte
r
2. Lea
r
ning the basics



Connecting a universal serial bus (USB) device
YourcomputercomeswiththreeUSBportscompatiblewithUSBdevices.
Note: WhenusingahighpowerconsumptionUSBdevicesuchasUSBODD,usethe
externaldevice’spoweradapter.Otherwise,thedevicemaynotberecognized,and
systemshutdownmayresult.

Connecting Bluetooth enabled devices (on select models)
IfyourcomputerhasanintegratedBluetoothadaptercard,itcanconnectto
andtransferdatawirelesslywithotherBluetoothenableddevices,suchas
notebookcomputers,PDAsandcellphones.Youcantransferdatabetween
thesedeviceswithoutcablesandupto10metersrangeinopenspace.
Note: Theactualmaximumrangemayvaryduetointerferenceandtransmissionbarriers.To
getthebestpossibleconnectionspeed,placethedeviceasnearyourcomputeras
possible.


Enabling Bluetooth communicationson your computer
1 Slidetheintegratedwirelessdeviceswitchfromto.
2 PressFn+F5tomakeconfiguration.
Notes:
• WhenyoudonotneedtousetheBluetoothfunction,turnitofftosavebatterypower.
• YouneedtopairtheBluetoothenableddevicewithyourcomputerbeforeyoucantransfer
databetweenthem.ReadthedocumentationsuppliedwiththeBluetoothenableddevice
fordetailsonhowtopairthedevicewithyourcomputer.



15
Chapter 3. Connecting to the Internet



Asaglobalnetwork,theInternetconnectscomputersworldwide,providing
servicessuchase‐mailing,informationsearching,electroniccommerce,Web
browsingandentertainment.

YoucanconnectthecomputertotheInternetinthefollowingways:
Wiredconnection:usephysicalwiringtoconnect.
Wirelessnetworktechnology:connectwithoutwiring.
Wired connection-----------------------------------------------------------------------------
Wiredconnectionsareareliableandsafewaytoconnectthecomputertothe
Internet.
Cable CableInternetservicesuseacablemodemconnectedto
theresidentialcableTVline.
DSL DSLisafamilyofrelatedtechnologiesthatbringhigh‐
speednetworkaccesstohomesandsmallbusinesses
overordinarytelephonelines.
Software configuration
ConsultyourInternetServiceProvider(ISP)fordetailsonhowtoconfigure
yourcomputer.


16
Chapte
r
3. Connecting to the Inte
r
net



Wireless connection----------------------------------------------------------------------------
WirelessconnectionsprovidemobileaccesstotheInternet,allowingyouto
stayonlineanywherethewirelesssignalcovers.
Dividedbythesignalscales,wirelessconnectiontotheInternetcanbebuilt
basedonthefollowingstandards.

Wi-Fi Wi‐Finetworkscoverasmallphysicalarea,likeahome,
office,orsmallgroupofbuildings.Anaccesspointis
necessaryfortheconnection.
WiMAX WiMAXnetworksconnectseveralWirelessLAN
systemstocoverametropolitanarea,providinghigh‐
speedbroadbandaccesswithouttheneedforcables.
Note: Yourcomputermaynotsupportallwirelessconnectionmethods.


Using Wi-Fi/WiMAX (on select models)
Enabling wireless connection
Toenablewirelesscommunications,dothefollowing:
1 Slidetheintegratedwirelessdeviceswitchfromto.
2 PressFn+F5tomakeconfiguration.
Software configuration
ConsultyourInternetServiceProvider(ISP)andsearchWindowsHelpand
SupportCenterfordetailsonhowtoconfigureyourcomputer.

