Lenovo TAB 2 A8-50F How to use

Lenovo TAB 2 A8-50
Safety, Warranty & Quick Start
Guide V1.0
Lenovo TAB 2 A8-50F
Lenovo TAB 2 A8-50L
Lenovo TAB 2 A8-50LC
English/Bahasa IndonesiaEnglish/영어
English/繁體中文/简体中文

125.00
English
Electronic emission
notices
Learn more
Legal notices Lenovo and the Lenovo logo are trademarks of Lenovo in
the United States, other countries, or both.
Other company, product, or service names may be
trademarks or service marks of others.
Manufactured under license from Dolby Laboratories.
Dolby, Dolby Atmos, and the double-D symbol are
trademarks of Dolby Laboratories.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or
software is delivered pursuant a General Services
Administration “GSA” contract, use, reproduction, or
disclosure is subject to restrictions set forth in Contract
No. GS-35F-05925.
To learn more information about your Lenovo TAB 2
A8-50 functions, please access “User Guide” from the
Browser favorites in your tablet.
To obtain the “Regulatory Notices”, go to
http://support.lenovo.com/.
Getting support For support on network service and billing, contact your
wireless network operator. For instructions on how to
use your Lenovo TAB 2 A8-50, go to
http://support.lenovo.com/.
Read this guide carefully before using your Lenovo TAB 2 A8-50.
All information labeled with * in this guide refers only to the LTE model
(Lenovo TAB 2 A8-50L/Lenovo TAB 2 A8-50LC).
Radio and Telecommunications Terminal Equipment
Directive
This product is in compliance with the essential
requirements and other relevant provisions of the Radio
and Telecommunications Terminal Equipment Directive,
1999/5/EC.
European Union conformity
0560

Technical specifications
MTK MT8161, Quad Core 1.3 GHz
*MTK MT8735, Quad Core 1.3 GHz
4290 mAh
Model & version
Camera
Battery
Display
Wireless
communication
5 megapixels AF (back) + 2 megapixels FF (front)
Size: 8 inches
Resolution: 1280 × 800
Bluetooth 4.0 WLAN 802.11 b/g/n GPS/GLONASS
①*LTE, WCDMA, GSM
① Your Lenovo TAB 2 A8-50L/Lenovo TAB 2 A8-50LC supports LTE Band 1, 3, 7,
8 and 20. But in some countries,LTE is not supported. To know if your Lenovo
TAB 2 A8-50L/Lenovo TAB 2 A8-50LC works with LTE networks in your
country, contact your carrier.
CPU
Lenovo TAB 2 A8-50
Version: WLAN
Android
*Version: LTE (Voice)*Model: Lenovo TAB 2 A8-50LC;
*Version: LTE*Model: Lenovo TAB 2 A8-50L;
Model: Lenovo TAB 2 A8-50F;
System

5
10
Speaker/*Receiver
2
6
3
789
4
1
11
Volume key
On/Off button Speaker Back camera
Micro USB Earphone jack *Micro SIM card slot
MicrophoneMicro SD card slot
The WLAN model (Lenovo TAB 2 A8-50F) does not have a Micro SIM card slot.
Only LTE (Voice) model (Lenovo TAB 2 A8-50LC) has a receiver.
11
78
6
2
5
1
3
4
9
10
First glance
Front camera

You can use cellular services with the LTE model (Lenovo TAB 2 A8-50L/Lenovo TAB 2
A8-50LC) by inserting the Micro SIM card provided by your carrier.
Install the Micro SIM card and the Micro SD card as shown.
Step 1. Open the card slot cover.
Step 2.
Step 3. Carefully replace the slot cover.
Only Micro SIM card works with your Lenovo TAB 2 A8-50L/Lenovo TAB 2 A8-50LC .
Micro
SD
SIM 2
SIM 1
Pull out the Micro-SIM-card tray
and position the Micro SIM card
into the tray in correct orientation,
then carefully insert the tray with
the installed Micro SIM card back
into the Micro SIM card slot.
Insert the Micro SD card into the
Micro SD slot.
Preparing your Lenovo TAB 2 A8-50

Turning on/off
Before using your Lenovo TAB 2 A8-50, you might need to charge the battery.
Charge the battery as shown.
Method 1. Connect your Lenovo TAB 2 A8-50 to a power outlet using the included
cable and USB power adapter.
Method 2. Charge the battery using a computer.
Low battery Fully charged Charging
Turn on: Press and hold the On/Off button until the
Lenovo logo appears.
Turn of f: Press and hold the On/Off button for a few
seconds, then tap Power off.
2
1
Starting to use your Lenovo TAB 2 A8-50
Taking screenshots
Press and hold the On/Off button and the volume down button at the same time.

10.00
Read before using your tablet
Read rst-Regulatory information
The following sections provide critical safety and regulatory information for Lenovo
tablets and instructions on how to access electronic versions of the publications
developed for your tablet.
Downloading publications
Accessing your User Guide
The following information describes the technical support that is available for your
product, during the warranty period or throughout the life of your product. Refer to the
Lenovo Limited Warranty for a full explanation of Lenovo warranty terms. See “Lenovo
Limited Warranty notice” later in this document for details on accessing the full
warranty.
Online technical support
Online technical support is available during the lifetime of a product at
http://www.lenovo.com/support.
You can get help and information from the Customer Support Center by telephone.
Before contacting a Lenovo technical support representative, please have the following
information available: model and serial number, the exact wording of any error
message, and a description of the problem.
Your technical support representative might want to walk you through the problem
while you are at your device during the call.
Device models equipped with wireless communications comply with the radio frequency
and safety standards of any country or region in which it has been approved for wireless
use. In addition, if your product contains a telecom modem, it complies with the
requirements for connection to the telephone network in your country.
Be sure to read the Regulatory Notice for your country or region before using the wireless
devices contained in your device. To obtain a PDF version of the Regulatory Notice, refer
to the “Downloading publications” section below.
Electronic versions of your publications are available from the http://support.lenovo.com.
To download the publications for your device, go to: http://support.lenovo.com and follow
the instructions on the screen.
Your User Guide contains detailed information about your device. To access your User
Guide, go to: http://support.lenovo.com and follow the instructions on the screen.
Service and Support information
Telephone technical support

WARNING: Handling the cord on this product or cords associated with accessories
sold with this product will expose you to lead, a chemical known to the State of
California to cause cancer, and birth defects or other reproductive harm. Wash hands
after handling.
Polyvinyl Chloride (PVC) cable and cord notice
Built-in rechargeable battery notice
Prevent hearing damage
Your device has a headphone connector. Always use the headphone connector for
headphones (also called a headset) or earphones.
Worldwide Lenovo Support telephone list
DANGER:
Do not attempt to replace the internal rechargeable lithium ion battery. Contact Lenovo
Support for factory replacement.
CAUTION:
Excessive sound pressure from earphones and headphones can cause hearing loss.
Adjustment of the equalizer to maximum increases the earphone and headphone
output voltage and the sound pressure level. Therefore, to protect your hearing, adjust
the equalizer to an appropriate level.
Excessive use of headphones or earphones for a long period of time at high volume
can be dangerous if the output of the headphone or earphone connectors do not
comply with specications of EN 50332-2.
The headphone output connector of your device complies with EN 50332-2 Sub
clause 7. This specication limits the device's maximum wide band true RMS output
voltage to 150 mV. To help protect against hearing loss, ensure that the headphones or
earphones you use also comply with EN 50332-2 (Clause 7 limits) for a wide band
characteristic voltage of 75 mV. Using headphones that do not comply with EN
50332-2 can be dangerous due to excessive sound pressure levels.
If the telephone number for your country or region is not listed, contact your Lenovo
reseller or Lenovo marketing representative.
Important safety and handling information
Plastic bag notice
DANGER:
Plastic bags can be dangerous. Keep plastic bags away from babies and children to
avoid danger of suffocation.
Important: Telephone numbers are subject to change without notice. The most
up-to-date telephone list for the Customer Support Center is always available at
http://www.lenovo.com/support/phone.

Warning statement:
To prevent possible hearing damage, do not listen at high volume levels for a long
period of time.
Lenovo Limited Warranty notice
This product is covered by the terms of the Lenovo Limited Warranty, version
L505-0010-02 08/2011. Read the Lenovo Limited Warranty (LLW) at
http://www.lenovo.com/warranty/llw_02. You can view the LLW in a number of
languages from this Web site. If you cannot view the LLW from the Web site, contact
your local Lenovo ofce or reseller to obtain a printed version of the LLW.
Lenovo TAB 2 A8-50
Model & Version
Model Version
WLAN
LTE
Lenovo TAB 2 A8-50F
Lenovo TAB 2 A8-50L
Lenovo TAB 2 A8-50LC LTE (Voice)
Sound pressure warning statement
For the device that is tested in accordance with EN 60950-1:
2006+A11:2009+A1:2010+A12:2011, it is mandatory to perform audio tests for
EN50332.
This device has been tested to comply with the Sound Pressure Level requirement laid
down in the applicable EN 50332-1 and/or EN 50332-2 standards. Permanent hearing
loss may occur if earphones or headphones are used at high volume for prolonged
periods of time.
Warranty information
If your device came with headphones or earphones in the package, as a set, the
combination of the headphones or earphones and the device already complies with
the specications of EN 50332-1. If different headphones or earphones are used,
ensure that they comply with EN 50332-1 (Clause 6.5 Limitation Values). Using
headphones that do not comply with EN 50332-1 can be dangerous due to excessive
sound pressure levels.

* Excludes some components. 90-day limited warranty for power adapters, keyboards,
plastics and hinges.
Warranty period and type of Warranty service
Country or Region Purchase Warranty Period
France, Germany, Italy, Austria,
United Kingdom, Israel, Australia,
New Zealand
parts and labor - 1 year
Battery Pack - 1 year 1,3
Serbia, Costa Rica, Venezuela, Peru,
Uruguay, Ecuador, Colombia, Chile, Argentina,
Indonesia, Vietnam, India, Malaysia, Thailand,
Philippines, Singapore, Hong Kong
parts and labor - 1 year
Battery Pack - 1 year 1,4
Russia, Ukraine, Egypt, Lebanon, Morocco,
South Africa, Tunisia, Mauritius, Mozambique,
United Arab Emirates, Jordan, Kenya, Nigeria,
Uganda, Ghana, Oman,Tanzania, Namibia
parts and labor - 1 year
Battery Pack - 1 year 4
Poland, Hungary, Romania, Bulgaria, Greece,
Croatia, Slovenia, Slovakia, Cyprus, United
States of America, Canada, Mexico, Japan
parts and labor - 1 year
Battery Pack - 1 year 1,5
Panama
parts and labor - 1 year
Battery Pack - 1 year 2,4
Taiwan, South Korea parts and labor - 1 year
Battery Pack - 1 year 3,4
Brazil parts and labor - 1 year
Battery Pack - 1 year 2,5
Spain, Switzerland, Portugal, Netherlands,
Belgium, Sweden, Denmark, Norway, Finland,
Estonia, Latvia, Lithuania, Iceland
parts and labor - 2 year
Battery Pack - 1 year 1,3
Czech Republic parts and labor - 2 year
Battery Pack - 1 year 1,5
Turkey parts and labor - 2 year
Battery Pack - 1 year 3,4
parts and labor - 2 year
Battery Pack - 1 year4
Saudi Arabia
Type of Warranty
Service

Types of Warranty Service
1. Customer Replaceable Unit (“CRU”) Service
2. On-site Service
3. Courier or Depot Service
4. Customer Carry-In Service
5. Mail-in Service
6. Customer Two-Way Mail-in Service
7. Product Exchange Service
For a full explanation of the types of warranty service, refer to the full warranty. See
“Lenovo Limited Warranty notice” for details on accessing the full warranty.
Environmental, recycling, and disposal information
General recycling statement
Lenovo encourages owners of information technology (IT) equipment to responsibly
recycle their equipment when it is no longer needed. Lenovo offers a variety of
programs and services to assist equipment owners in recycling their IT products. For
information on recycling Lenovo products, go to: http://www.lenovo.com/recycling.
Important WEEE information
Recycling information for Japan
Recycling and disposal information for Japan is available at:
http://www.lenovo.com/recycling/japan.
Additional recycling statements
Additional information about recycling device components and batteries is in your User
Guide. See “Accessing your User Guide” for details.
Battery recycling marks
The battery recycling information of Taiwan
Battery recycling information for the United States and Canada
Electrical and electronic equipment marked with the symbol of a crossed-out
wheeled bin may not be disposed as unsorted municipal waste. Waste of
electrical and electronic equipment (WEEE) shall be treated separately using
the collection framework available to customers for the return, recycling, and
treatment of WEEE.
Country-specic information is available at：
http://www.lenovo.com/recycling.

Battery recycling information for the European Union
Energy efciency mark
EurAsia compliance mark
Ukraine
India
RoHS compliant as per E-Waste (Management & Handling) Rules, 2011.
European Union
Lenovo products sold in the European Union, on or after 3 January 2013 meet the
requirements of Directive 2011/65/EU on the restriction of the use of certain hazardous
substances in electrical and electronic equipment (“RoHS recast” or “RoHS 2”).
For more information about Lenovo progress on RoHS, go to:
http://www.lenovo.com/social_responsibility/us/en/RoHS_Communication.pdf
Notice for users in Mexico
La operación de este equipo está sujeta a las siguientes dos condiciones:
(1) es posible que este equipo o dispositivo no cause interferencia perjudicial y
(2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la
que pueda causar su operación no deseada.
Restriction of Hazardous Substances Directive (RoHS)
Turkish
The Lenovo product meets the requirements of the Republic of Turkey Directive on the
Restriction of the Use of Certain Hazardous Substances in Waste Electrical and
Electronic Equipment (WEEE).
Atık Elektrikli ve
AEEE
AEEE
AEEE
Elektronik Eşya
Vietnam
Lenovo products sold in Vietnam, on or after September 23, 2011, meet the
requirements of the Vietnam Circular 30/2011/TT-BCT (“Vietnam RoHS”).

125.00
繁體中文
電子輻射
注意事項
了解詳情
法律注意事項 Lenovo 及Lenovo 標誌為美國、其他國家或美國及其他國
家的 Lenovo 商 標。
其他公司、產品或服務名稱可能是其他公司的商標或服務
商 標。
在Dolby Laboratories 的 許 可 下 製 造。Dolby、Dolby
Atmos 及雙 D 符號為 Dolby Laboratories 的 商 標。
有限及限制權利注意事項：若數據或軟件根據一般服務管理
「GSA」合約提供，使用、再製作或披露，均受合約號碼
GS-35F-05925 所 限。
如要了解更多有關 Lenovo TAB 2 A8-50 的 功 能，請 瀏 覽 平
板 電 腦 瀏 覽 器 最 愛 的「User Guide」。
如要獲得「監管通知」，請前往 http://support.lenovo.com/。
取得支援 如需關於網絡服務和收費的支援，請聯絡您的無線網絡營運
商。如 需 關 於 使 用 Lenovo TAB 2 A8-50 的 指 示，請 前 往
http://support.lenovo.com/。
在使用 Lenovo TAB 2 A8-50 前小心閱讀此指引。
此指引標記 * 的資訊僅適用於 LTE 型號 (Lenovo TAB 2 A8-50L/Lenovo TAB 2
A8-50LC)。
無線電及電信終端設備指令
此產品符合必要的要求及無線電及通訊終端設備指令
1999/5/EC 的 其 他 相 關 條 款。
歐盟符合性
0560

技術規格
MTK MT8161，四核心 1.3 GHz
*MTK MT8735，四核心 1.3 GHz
4290 mAh
型號及版本
相機
電池
顯示器
無線通訊
500 萬像素自動對焦 (後置) + 200 萬像素 FF (前置)
大小:8 吋
解像度：1280 × 800
藍牙 4.0 WLAN 802.11 b/g/n GPS/GLONASS
①*LTE, WCDMA, GSM
①您的 Lenovo TAB 2 A8-50L/Lenovo TAB 2 A8-50LC支援 LTE 頻段 1, 3, 7, 8 及
20。* LTE 在部分國家/地區並不受支援。可聯絡營運商查詢您的 Lenovo TAB 2
A8-50L/Lenovo TAB 2 A8-50LC 可否使用您所在國家的 LTE 網 絡。
CPU
Lenovo TAB 2 A8-50
版本：WLAN
Android
* 版本：LTE (語音)* 型號：Lenovo TAB 2 A8-50LC;
* 版本：LTE* 型號：Lenovo TAB 2 A8-50L;
型號：Lenovo TAB 2 A8-50F;
系統

5
10
喇叭/*接收器
2
6
3
789
4
1
11
音量鍵
開/關按鈕 揚聲器 後相機
Micro USB 耳機插孔 *Micro SIM 卡插槽
麥克風Micro SD 卡插槽
WLAN 型號 (Lenovo TAB 2 A8-50F) 不設 Micro SIM 卡插槽。
只有 LTE （語音） 型號 (Lenovo TAB 2 A8-50LC) 擁有接收器。
11
78
6
2
5
1
3
4
9
10
概覽
前相機

您可透過插入由您營運商提供的 Micro SIM 卡，使用 LTE 型號 (Lenovo TAB 2
A8-50L/Lenovo TAB 2 A8-50LC) 的手機服務。
如圖所示安裝 Micro SIM 卡及 Micro SD 卡。
步驟 1. 開啟卡插槽蓋。
步驟 2.
步驟 3. 小心蓋好插槽蓋。
Lenovo TAB 2 A8-50L/Lenovo TAB 2 A8-50LC 只可使用 Micro SIM 卡。
Micro
SD
SIM 2
SIM 1
拉出 Micro SIM 卡卡架，並把
Micro SIM 卡以正確的方向放入
卡架，然後小心地將已裝入
Micro SIM 卡的卡架插回 Micro
SIM 卡槽內。
把Micro SD 卡插入 Micro SD
卡槽。
準備 Lenovo TAB 2 A8-50

開啟/關閉
使用 TAB 2 A8-50 前，您可能需要充電。
請根據圖示為電池充電。
方法 1. 使用隨附的纜線及 USB 電源適配器將您的 Lenovo TAB 2 A8-50 連接至電源。
方法 2. 使用電腦充電。
低電量 已完全充電 充電中
開啟
：按 住 開 /關按鈕直至出現 Lenovo 標 誌。
關閉
：按 住 開 /關 按 鈕 數 秒，然 後 輕 按「關機」。
2
1
開始使用 Lenovo TAB 2 A8-50
螢幕截圖
同時按住開/關按鈕及降低音量鍵。

10.00
使用平板電腦前先閱讀
請先閱讀規管資訊
下列部分提供 Lenovo 平板電腦的重要安全及監管資訊和如何獲得平板電腦相關指引的電子
版本。
下載刊物
獲得用戶指南
以下資訊說明您的產品在保養期內或產品使用期間可得到的技術支援。請參閱 Lenovo 有限
保養期以獲得有關 Lenovo 保養細則的詳細解釋。參閱本文件後部的「 Lenovo 有限保養通
知」以獲得完全保養的詳情。
網上技術支援
您 可 在 產 品 的 使 用 期 間 享 用 網 上 技 術 支 援，網 址 http://www.lenovo.com/support。
您可透過電話獲得客戶支援中心的協助及資訊。在聯絡 Lenovo 技術支援代表前，請預先準備
下列資料：產品型號及序號，產品錯誤訊息的確切字眼，以及對問題的描述。
您的技術支援代表可能需要您在通話期間於裝置旁，才可指導您解決問題。
配備無線通訊的裝置型號符合任何需批准作無線使用的國家或地區之電台頻率及安全標
準。此外，若您的產品包含電訊數據機，其符合連接您國家電話網絡的要求。
請務必先閱讀您所屬國家或地區的規管注意事項，然後才使用裝置內的無線裝置。如要
取得規管注意事項的PDF 版本，請參閱以下的「下載刊物」部分。
電子版公佈說明文件可從 http://support.lenovo.com 獲取。如要下載裝置的刊物，請前
往：http://support.lenovo.com 並根隨螢幕指示。
您的用戶指南包含裝置的詳細資訊。如要獲得用戶指南，請前往
http://support.lenovo.com 並根隨螢幕指示。
服務及支援資訊
電話技術支援

警 告：處理產品纜線或產品隨附配件纜線會令您接觸鉛，加利福尼亞州已知鉛會導致癌症、
嬰 兒 先 天 缺 陷 或 其 他 生 殖 系 統 損 害。處 理 纜 線 後 請 洗 手。
聚氯乙烯 (PVC) 纜線和電線注意事項
內置充電式電池注意事項
避免聽力受損
您的裝置提供耳機連接器。使用耳機插孔連接耳機或耳筒。
Lenovo 環球支援熱線清單
危 險：
請 勿 自 行 更 換 內 置 充 電 式 鋰 離 子 電 池。聯 絡 Lenovo 支 援 以 替 換 電 池。
警 告：
耳機和耳筒的聲壓過大可能導致聽力受損。將等化器調至最大將會提高耳機和耳筒的輸出電
壓和聲壓。因此，為保護您的聽力，請將等化器調至適當的水平。
如果耳機或耳筒不符合 EN 50332-2 的規格，長時間以高音量使用耳機或耳筒可能會有危險。
裝置的耳筒輸出連接器符合 EN 50332-2 子條款第 7 條。此規格限制裝置的最大寬帶真正
RMS 輸出電壓至 150 mV。為保護您的聽力，確保您使用的耳機或耳筒亦符合 EN 50332-2
（第 7 條 ）所 述 的 75 mV 寬 帶 電 壓 規 格。使 用 不 符 合 EN 50332-2 的耳機可能會由於聲壓
過 大 造 成 危 險。
如果熱線清單上沒有您國家或地區的號碼，請聯絡您的 Lenovo 分銷商或 Lenovo 市場策劃
代 表。
重要安全及處理資訊
塑膠袋注意事項
危 險：
塑膠袋可能構成危險。請勿讓嬰兒和小孩接觸塑膠袋，以免塑膠袋導致窒息。
重 要 資 訊：電話號碼隨時更改，恕不另行通知。最新的客戶支援中心熱線清單可於下列網址
找 到：http://www.lenovo.com/support/phone。

警告聲明
為避免聽力受損，請勿長時間以高音量使用耳機或耳筒。
Lenovo 有限保養通知
此產品由 Lenovo 有限保養條款保障，版本 L505-0010-02 08/2011。請 於
http://www.lenovo.com/warranty/llw_02 閱讀 Lenovo 有限保養 (LLW) 詳 情。您 可 在 該 網
址閱讀 Lenovo 有限保養通知的不同語言版本。如未能於該網站檢視 LLW，請 聯 絡 您
Lenovo 的本地辦公室或分銷商，以獲取 LLW 的 列 印 版 本。
Lenovo TAB 2 A8-50
型號及版本
型號 版本
WLAN
LTE
Lenovo TAB 2 A8-50F
Lenovo TAB 2 A8-50L
Lenovo TAB 2 A8-50LC LTE (語音)
裝置聲壓警告聲明
對於按照 EN 60950-1: 2006+A11:2009+A1:2010+A12:2011 進行測試的裝置，進行
EN50332 音 訊 測 試 必 須。
此裝置已通過測試，以符合適用的 EN 50332-1 及/或EN 50332-2 標準的音壓水平要求。如
果長時間以高音量使用耳機或耳筒可能會導致聽力永久受損。
保養資訊
若您的裝置套裝連同耳筒或耳機為一組產品，耳筒或耳機及裝置組合均已符合 EN 50332-1
規格。如果您使用其他耳機或耳筒，確保它們符合 EN 50332-1（第 6.5 條 限 制 值 ）的 規 格。
使用不符合 EN 50332-1 的耳機可能會由於聲壓過大造成危險。
