Lenovo Tab M10 Gen3
Lenovo Tab M10 Gen3
Level 2 –Service and Repair Manual

Lenovo Tab M10 Gen3
Level 2 –Service and Repair Manual
Lenovo Confidential Restricted:
Page 1 / 72 Do not share without consent from Lenovo
DISCLAIMER
INFORMATION CONTAINED IN THIS DOCUMENT IS STRICTLY PRIVATE, PROPRIETARY, CONFIDENTIAL AND PERSONAL TO
RECIPIENT (“CONFIDENTIAL INFORMATION”) AND SHOULD NOT BE COPIED, DISTRIBUTED OR REPRODUCED IN WHOLE
OR IN PART, OR DISCLOSED IN ANY MANNER TO ANY THIRD PARTY WITHOUT THE PRIOR WRITTEN CONSENT OF
LENOVO.
RECIPIENT OF THIS DOCUMENT SHALL (A) ONLY USE CONFIDENTIAL INFORMATION FOR REPAIRING LENOVO OR
MOTOROLA PRODUCTS (“THE PURPOSE”); (B) ONLY SHARE CONFIDENTIAL INFORMATION WITH INDIVIDUALS WHO NEED
TO KNOW AND WHO AGREE IN WRITING TO KEEP THE INFORMATION CONFIDENTIAL ON SUBSTANTIALLY THE SAME
TERMS AS THOSE CONTAINED IN THIS DISCLAIMER; (C) PROTECT AND PREVENT UNAUTHORIZED USE OR DISCLOSURE
OF CONFIDENTIAL INFORMATION WITH THE SAME DEGREE OF CARE RECIPIENT USES FOR RECIPIENT’S OWN
SENSITIVE INFORMATION, AND NO LESS THAN REASONABLE CARE BASED ON THE TYPE OF CONFIDENTIAL
INFORMATION; (D) FULLY COOPERATE WITH LENOVO TO INVESTIGATE ANY UNAUTHORIZED USE OR DISCLOSURE OF
THE CONFIDENTIAL INFORMATION, INCLUDING PROVIDING A LIST OF INDIVIDUALS WHO HAD ACCESS TO THE
CONFIDENTIAL INFORMATION; AND RETURN OR DESTROY THE CONFIDENTIAL INFORMATION UPON LENOVO’S WRITTEN
REQUEST.
RECIPIENT HEREBY ACKNOWLEDGES THAT UNAUTHORIZED DISCLOSURE OR USE OF CONFIDENTIAL INFORMATION
MAY CAUSE IRREPARABLE HARM AND SIGNIFICANT INJURY TO LENOVO, THE EXTENT OF WHICH MAY BE DIFFICULT TO
ASCERTAIN AND FOR WHICH MONEY DAMAGES MAY NOT BE AN ADEQUATE REMEDY. ACCORDINGLY, LENOVO SHALL
BE ENTITLED TO IMMEDIATE INJUNCTIVE RELIEF TO ENFORCE THE OBLIGATIONS OF RECIPIENT UNDER THIS
DISCLAIMER, IN ADDITION TO ANY OTHER RIGHTS AND REMEDIES IT MAY HAVE AT LAW.
CONFIDENTIAL INFORMATION REMAINS THE PROPERTY OF LENOVO. EXCEPT FOR THE RIGHT TO ACCESS AND USE
CONFIDENTIAL INFORMATION IN FURTHERANCE OF THE PURPOSE, NO LICENSE OR OTHER RIGHT TO CONFIDENTIAL
INFORMATION OR TO LENOVO’S INTELLECTUAL PROPERTY IS GRANTED OR IMPLIED BY THIS DISCLAIMER.
ALL INFORMATION IN THIS DOCUMENT IS PROVIDED “AS IS” AND WITHOUT ANY WARRANTY WHATSOEVER, WHETHER
EXPRESS, STATUTORY, OR IMPLIED, AS TO ITS ACCURACY, COMPLETENESS, OR PERFORMANCE.
BY ACCESSING THIS DOCUMENT, RECIPIENT ACKNOWLEDGES, ACCEPTS AND AGREES TO THE

Lenovo Tab M10 Gen3
Level 2 –Service and Repair Manual
Lenovo Confidential Restricted:
Page 2 / 72 Do not share without consent from Lenovo
REVISION HISTORY
Revision
Date
Notes
1
2022/11/10
Initial Release.

Lenovo Tab M10 Gen3
Level 2 –Service and Repair Manual
Lenovo Confidential Restricted:
Page 3 / 72 Do not share without consent from Lenovo
TABLE OF CONTENTS
DISCLAIMER............................................................................................................................................... 1
REVISION HISTORY......................................................................................................................................... 2
TABLE OF CONTENTS..................................................................................................................................... 3
SAFETY INFORMATION.................................................................................................................................... 5
INTRODUCTION............................................................................................................................................... 6
Main Exploded Views.............................................................................................................................. 8
DISASSEMBLY AND RECOVERY ........................................................................................................... 10
Disassembly and Recovery Map......................................................................................................10
SIM Tray Removal..............................................................................................................................13
SN Label Removal..............................................................................................................................14
Display Removal ................................................................................................................................15
LCM FPC Removal.............................................................................................................................18
Battery Connector Steel Removal....................................................................................................19
Middle Frame Removal......................................................................................................................20
Side Key FPC Removal......................................................................................................................21
Front-Facing Imager Removal..........................................................................................................22
Left Speaker Removal .......................................................................................................................23
Right Speaker Removal.....................................................................................................................24
Light Sensor Grommet Removal......................................................................................................25
Rear-Facing Imager Removal...........................................................................................................26
Main Board Removal .........................................................................................................................27
USB Board Steel Removal ................................................................................................................28
Main FPC Removal.............................................................................................................................29
USB Board Removal..........................................................................................................................30
Battery Removal.................................................................................................................................31
Volume Key Removal ........................................................................................................................32
Power Key Removal...........................................................................................................................33
PARTS REFRESH.......................................................................................................................................... 34
Middle Frame Cleaning......................................................................................................................35
ASSEMBLY................................................................................................................................................... 36
Assembly Map....................................................................................................................................36
Tools Required for Assembly...........................................................................................................37
Water Detection Label Assembly.....................................................................................................38
Main Board Assembly........................................................................................................................39
USB Board Assembly........................................................................................................................40
Main FPC Assembly...........................................................................................................................41
USB Board Steel Assembly ..............................................................................................................42
Rear-Facing Camera Assembly........................................................................................................43
Left Speaker Assembly .....................................................................................................................44
Right Speaker Assembly...................................................................................................................45
Light Sensor Grommet Assembly....................................................................................................46
Front-Facing Imager Assembly........................................................................................................47

Lenovo Tab M10 Gen3
Level 2 –Service and Repair Manual
Lenovo Confidential Restricted:
Page 4 / 72 Do not share without consent from Lenovo
Battery Assembly...............................................................................................................................49
Battery Connector Metal Assembly.................................................................................................52
Power Key Assembly.........................................................................................................................53
Power Key Assembly.........................................................................................................................54
Side Key FPC Assembly....................................................................................................................55
TP Adhesive Assembly......................................................................................................................56
Middle Frame Assembly....................................................................................................................57
LCD FPC Assembly............................................................................................................................59
Display Assembly ..............................................................................................................................61
SN Label Assembly............................................................................................................................65
SD Tray Assembly..............................................................................................................................66
ASSEMBLY QUALITY CHECK......................................................................................................................... 67
Battery Quality Check........................................................................................................................67
Grommets and Connectors Quality Check.....................................................................................68
Screws Quality Check .......................................................................................................................71

Lenovo Tab M10 Gen3
Level 2 –Service and Repair Manual
Lenovo Confidential Restricted:
Page 5 / 72 Do not share without consent from Lenovo
SAFETY INFORMATION
Cautions and Warnings
Electrostatic Discharge
The tablet components may be damaged by electrostatic discharge (ESD). Always use an ESD mat and ground
strap when working with internal components.
Battery Safety Guidelines
Handle Battery with care. Ensure Battery edges and surfaces are not dented or deformed. If the Battery Pack
is dropped to the floor, it may be internally damaged and must be scrapped.
Ensure all surfaces, fixtures, and tablet components contacting the Battery are smooth and clean.
Ensure Battery and its insulation are not damaged (e.g. scratched, dented, punctured) prior to and throughout
assembly.
Prior to assembly, ensure Battery edges and surfaces are not dented or deformed, and that fixtures and parts
that will contact the Battery are free of foreign material.
Ensure screws and screwdrivers do not contact the Battery.
Failure to adhere to Safety Critical Note(s) may increase risk of rupture, burning, or failure to function safely
when used by the customer.

Lenovo Tab M10 Gen3
Level 2 –Service and Repair Manual
Lenovo Confidential Restricted:
Page 6 / 72 Do not share without consent from Lenovo
INTRODUCTION
External Views
Figure 1. External Views
1
2
6
8
9
10
5
7
4
3
3
11
12

Lenovo Tab M10 Gen3
Level 2 –Service and Repair Manual
Lenovo Confidential Restricted:
Page 7 / 72 Do not share without consent from Lenovo
Table 1. External Views Parts List
Reference #
Description
1
Power Key
2
Volume Key
3
Loudspeaker
4
Mic
5
Audio Jack
6
USB Type C
7
Card Tray
8
Display Screen
9
Middle Frame
10
Rear Cover
11
Rear-Facing Camera
12
Front-Facing Camera

Lenovo Tab M10 Gen3
Level 2 –Service and Repair Manual
Lenovo Confidential Restricted:
Page 8 / 72 Do not share without consent from Lenovo
Main Exploded Views
Figure 2. Assembly Exploded View

Lenovo Tab M10 Gen3
Level 2 –Service and Repair Manual
Lenovo Confidential Restricted:
Page 9 / 72 Do not share without consent from Lenovo
Table 2. Assembly Exploded View Parts List
Reference #
Description
Recovery Part
1
TB328 Vol key&*CL5040AA000517 CS
Yes
2
TB328 PWR key&*CL5040AA000516 CS
Yes
3
TB328 Side key FPC&*CL6680AA001024 CS
No
4
TB328 Batt conn metal&*CL5090AA000527 CS
Yes
5
TB328 LCD conn metal&*CL5090AA000526 CS
Yes
6
TB328 LCD FPC&*CL6680AA001022 CS
Yes
7
TB328 Rear camera_8M&*CL2640AA000496 CS
Yes
8
TB328 F_camera rubber&*CL5061AA000890CS
Yes
9
TB328 Front camera_5M&*CL2640AA000555 CS
Yes
10
TB328FU MB_4+64G&*21201-03315 CS
Yes
11
TB328 Lsensor rubber&*CL5061AA000889 CS
Yes
12
TB328 Speaker box_L&*CL5016AA000262 CS
Yes
13
TB328 Speaker box_R&*CL5016AA000264 CS
Yes
14
TB328FU Sub board&*21201-03318 CS
Yes
15
NVT-A L19D1P32 3.86V5000mAh19.3Wh1cell
Yes
16
TB328 USB board metal&*CL5090AA000528 CS
Yes
17
TB328 Main FPC&*CL6680AA001020 CS
Yes
19
TB328 Screw_1.4*2.2mm&**CL4610AA000524CS
No
20
TB328 Screw_1.4*3.5mm&**CL4610AA000525CS
No
21
TB328 TP+LCM Assy&*24011-00028 CS
Yes
22
TB328FU Middle frame Assy&*22002-08031CS
Yes
23
TB328FU RearCover Assy&*22002-08029 CS
Yes
/
TB328FU SIM tray_ss&*CL5017AA000796 CS
No
/
TB328 Batt Pull Tape&*CL5420AA001509 CS
No
/
TB328 TP Adhesive&*CL5420AA001512 CS
No
/
TB328 LCD ZIF mylar&*CL5480AA000578 CS
No
/
TB328 Front cam mylar&*CL5480AA000579 CS
No
/
TB328 LCD FPC cloth&*CL5450AA001159 CS
No
/
TB328 Waterproof label&*CL7015AA001336CS
No

Lenovo Tab M10 Gen3
Level 2 –Service and Repair Manual
Lenovo Confidential Restricted:
Page 10 / 72 Do not share without consent from Lenovo
DISASSEMBLY AND RECOVERY
Disassembly and Recovery Map
*Shaded parts may be eligible for parts recovery.
··
Main FPC
SD Tray
TP LCM
ASSY
LCM FPC
Middle
Frame
Side Key
FPC
Battery
Connector
Metal
Battery
Connector
Metal
Middle
Frame
Front-
Facing
Imager
Light
Sensor
Grommet
Left
Speaker
Box
Right
Speaker
Box
Sub Board
Metal
Rear
Facing
Imager
Battery
Power Key
Main
Board
Sub Board
Volume
Key
WDL

Lenovo Tab M10 Gen3
Level 2 –Service and Repair Manual
Lenovo Confidential Restricted:
Page 11 / 72 Do not share without consent from Lenovo
Tools Required for Disassembly
Description
Part #
Picture/Drawing
7″ x 7″ Hot Plate
-
SIM/SD Tray Removal Tool
4-00-U2-10000
Blackstick
-
JCIS #0 Bit
-
Torque Driver (Adjustable)
-
Shim
-
Tweezers
-

Lenovo Tab M10 Gen3
Level 2 –Service and Repair Manual
Lenovo Confidential Restricted:
Page 12 / 72 Do not share without consent from Lenovo
Suction Cup
-

Lenovo Confidential Restricted:
Page 13 / 72 Do not share without consent from Lenovo
SIM Tray Removal
1. Power off the device before beginning with the
procedure. Insert the SIM/SD Tray Removal
Tool into the SIM/SD Tray hole.
2. Push the SIM/SD Tray Removal Tool into the
SIM/SD Tray hole until the SIM/SD Tray ejects
from the tablet
3. Remove the SIM/SD Tray from the tablet
NOTE
The SIM/SD Tray can be recovered
and reused after removal.

Lenovo Tab M10 Gen3
Level 2 –Service and Repair Manual
Lenovo Confidential Restricted:
Page 14 / 72 Do not share without consent from Lenovo
SN Label Removal
Use the Tweezers to peel the SN Label from the
SIM/SD Tray
NOTE
Remove the SN Label only if necessary.
After you remove it, you cannot reuse it.

Lenovo Tab M10 Gen3
Level 2 –Service and Repair Manual
Lenovo Confidential Restricted:
Page 15 / 72 Do not share without consent from Lenovo
Display Removal
NOTE
The Display can be recovered and
reused after removal if it is undamaged.
1. Preheat the heating platform* to 75to 75℃℃,
then put the device on, then put the device on
the heating platform with the heating platform
with the screen facing down. screen facing
down.
2. Heat for 5 minutes.
3. Remove the Tablet from the platform.
// CAUTION //
Wear protective gloves when handling heated
Tablet.
NOTE
Perform the Display removal procedure before the
Tablet starts to cool off.

Lenovo Tab M10 Gen3
Level 2 –Service and Repair Manual
Lenovo Confidential Restricted:
Page 16 / 72 Do not share without consent from Lenovo
4. Use suction cup to suck display and Rear cover
to create a snap between display and middle
frame.
NOTE
Make sure to start at the Volume Key
position as shown.
5. Use the Shim to disengage the snaps on the
display. Work your way around the edges of
the tablet in the direction as shown.
NOTE
Care to avoid damaging the display,
middle frame and rear cover.
NOTE
Care while doing this step do not open
the display to avoid damage LCM FPC
NOTE
If needed, reheat the tablet for no more than 5 min
and repeat.

Lenovo Tab M10 Gen3
Level 2 –Service and Repair Manual
Lenovo Confidential Restricted:
Page 17 / 72 Do not share without consent from Lenovo
6. Carefully open the display to 45 degrees from
the bottom side,
NOTE
The side with front camera is top side, and the
opposite is bottom side
7. Use the Torque Driver and JCIS #0 Bit to
remove the 1 green screws from the LCM FPC
steel.
8. Use the Tweezers to remove the LCM FPC
steel from the tablet.
9. Use the flat end of the Black stick to disengage
the Battery BtB Connector from the Main PCB.
10. Use your fingers to remove the Display
NOTE
The LCM FPC steel can be recovered
and reused after removal.

Lenovo Tab M10 Gen3
Level 2 –Service and Repair Manual
Lenovo Confidential Restricted:
Page 18 / 72 Do not share without consent from Lenovo
LCM FPC Removal
1. Use the Tweezers to remove the LCD ZIF
Connector Mylar and conductive Cloth from
the LCM FPC connector.
2. Use the flat end of the Black stick to open LCD
ZIF connector and remove the LCM FPC by the
handle
NOTE
The LCM FPC can be recovered and reused
after removal.
3. Use your fingers remove the LCM FPC by
handle as shown
NOTE
Remove the LCD ZIP Connector Mylar and
LCM FPC Conductive Fabric only if necessary,
After you remove them, you cannot reuse them

Lenovo Tab M10 Gen3
Level 2 –Service and Repair Manual
Lenovo Confidential Restricted:
Page 19 / 72 Do not share without consent from Lenovo
Battery Connector Steel
Removal
1. Use the Torque Driver and JCIS #0 Bit to
remove the 2 Green Screws from the Battery
Connector steel.
2. Use the Tweezers to remove the Battery
Connector Steel from the tablet.
NOTE
The Battery Connector steel can be
recovered and reused after removal.
3. Use the flat end of the Black stick to disengage
Battery BtB connector from the Main board as
shown
