Lenovo YOGA Tab 3 8 How to use

YOGA Tab 3 8”
Safety, Warranty & Quick
Start Guide
Lenovo YT3-850F
Lenovo YT3-850L
Lenovo YT3-850M
English/Indonesia
I.40.LENOVO4.12626.0715
PT.LENOVO INDONESIA
WISMA KOTA BNI46, 19 FLOOR, SUITE 19-05
JL.JEND SUDIRMAN KAV.1, JAKARTA PUSAT 10220 INDONESIA
TEL: [phone], FAX: [phone]

Read this guide carefully before using your YOGA Tab 3 8”.
All information labeled with * in this guide refers only to the LTE model (Lenovo
YT3-850L/Lenovo YT3-850M).
English
Electronic emission
notices
Learn more
Legal notices Lenovo and the Lenovo logo are trademarks of Lenovo in
the United States, other countries, or both.
Other company, product, or service names may be
trademarks or service marks of others.
Manufactured under license from Dolby Laboratories.
Dolby, Dolby Atmos, and the double-D symbol are
trademarks of Dolby Laboratories.
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or
software is delivered pursuant a General Services
Administration “GSA” contract, use, reproduction, or
disclosure is subject to restrictions set forth in Contract
No. GS-35F-05925.
The Declaration of Conformity information is located in the
Regulatory Notice. To obtain a PDF version of the
Regulatory Notice, go to : http://support.lenovo.com/
Getting support For support on network service and billing, contact your
wireless network operator. For instructions on how to use
your YOGA Tab 3 8”,go to : http://support.lenovo.com/
Radio and Telecommunications Terminal Equipment
Directive
Lenovo declares that this product is in compliance with:
● The essential requirements and other relevant
provisions of the Radio and Telecommunications
Terminal Equipment Directive, 1999/5/EC
● All other relevant EU directives
European Union conformity
0560
1

Technical specifications
Qualcomm APQ8009
*Qualcomm MSM8909
6200 mAh
Camera
Battery
Display
①Wireless
communication
8 megapixels
Size: 20.32 cm (8 inches)
Resolution: 800 × 1280
Bluetooth 4.0; WLAN 802.11 b/g/n;
GPS/GLONASS; *LTE/WCDMA/GSM
Your YOGA Tab 3 8” supports LTE Band 1, 3, 4, 5, 7, 8, 19, 20, 38 and 40. But in
some countries,LTE is not supported. To know if your YOGA Tab 3 8” works with
LTE networks in your country, contact your carrier.
①
Model & version
CPU
YOGA Tab 3 8”
Version: WLAN
Android
*Version: LTE (Voice)*Model: Lenovo YT3-850M;
*Version: LTE*Model: Lenovo YT3-850L;
Model: Lenovo YT3-850F;
System
2

The WLAN model (Lenovo YT3-850F) does not have a Micro SIM card slot.
You can use pencils or metal-tipped pens with a tip diameter of 0.7 mm or above,
including fountain pens, rollerball pens, and some ballpoint pens, to write and draw
on the screen or perform auxiliary touch operations. Special tip: There is a risk of
scratching the screen slightly if you apply too much pressure when writing or use
a pen tip that is too hard.
!!! Do not insert your finger into the hanging hole. Doing so might hurt your finger.
First glance
5
10
Micro USB connector2
6
3
789
4
1On/Off button
Speakers Microphone Earphone jack
Kickstand Hanging hole Kickstand push button
Rotating camera
8
1
2
3
44
5
67
10
11
12
Volume button
8
11 MicroSD card slot
9
12 *Micro SIM card slot
3

You can use cellular services with the LTE model ( Lenovo YT3-850L/Lenovo YT3-850M )
by inserting the Micro SIM card provided by your carrier.
Install the Micro SIM card and the microSD card as shown.
Step 3. Push back the kickstand.
Only Micro SIM card works with your tablet.
!!! DO not insert or remove the Micro SIM card while your tablet is turned on. Doing
so can permanently damage your Micro SIM card or tablet.
1
2
1
2
2
1
Step 1. Press the push button to open
the kickstand.
Step 2. Open the card slot cover.
Insert the Micro SIM card and
microSD card and then install
the card slot cover back.
Preparing your tablet
4

Turning on/off
Connect your tablet to a power outlet using the included cable and USB power adapter.
Low battery Fully charged Charging
Turn on: Press and hold the On/Off button until the
Lenovo logo appears.
Turn off: Press and hold the On/Off button for a few
seconds, then tap Power off.
Restart: Press and hold the On/Off button for a few
seconds, then tap Restart. To force restart your tablet,
press and hold the power button until the tablet vibrates.
Before using your tablet, you might need to charge the battery. Charge the battery as
shown.
Using the rotating camera
Allowable functional range of the rotating camera is
shown on the left.
Don't over-rotate the camera to avoid its damage.
Starting to use your tablet
Taking screenshots
Press and hold the On/Off button and the volume down button at the same time.
5

125.00
Read before using your tablet
The following sections provide critical safety and regulatory information for the Lenovo
tablets and instructions on how to access electronic versions of the publications
developed for your tablet.
Read first-Regulatory information
Device models equipped with wireless communications comply with the radio frequency
and safety standards of any country or region in which it has been approved for wireless
use. In addition, if your product contains a telecom modem, it complies with the
requirements for connection to the telephone network in your country.
Be sure to read the Regulatory Notice for your country or region before using the
wireless devices contained in your device. To obtain a PDF version of the Regulatory
Notice, refer to the “Downloading publications” section below.
Downloading publications
Electronic versions of your publications are available from http://support.lenovo.com. To
download the publications for your device, go to http://support.lenovo.com and follow the
instructions on the screen.
Accessing your User Guide
Your User Guide contains detailed information about your device. To access your User
Guide, use one of the following methods:
●Go to http://support.lenovo.com and follow the instructions on the screen.
Service and Support information
The following information describes the technical support that is available for your
product, during the warranty period or throughout the life of your product. Refer to the
Lenovo Limited Warranty for a full explanation of Lenovo warranty terms. See “Lenovo
Limited Warranty notice” later in this document for details on accessing the full
warranty.
Online technical support
Online technical support is available during the lifetime of a product at:
http://www.lenovo.com/support
Telephone technical support
You can get help and information from the Customer Support Center by telephone.
Before contacting a Lenovo technical support representative, please have the following
information available: model and serial number, the exact wording of any error
message, and a description of the problem.
Your technical support representative might want to walk you through the problem
while you are at your device during the call.
6

10.00
Worldwide Lenovo Support telephone list
Important: Telephone numbers are subject to change without notice. The most
up-to-date telephone list for the Customer Support Center is always available at:
http://www.lenovo.com/support/phone
If the telephone number for your country or region is not listed, contact your Lenovo
reseller or Lenovo marketing representative.
Important safety and handling information
Plastic bag notice
DANGER:
Plastic bags can be dangerous. Keep plastic bags away from babies and children to
avoid danger of suffocation.
Built-in rechargeable battery notice
DANGER:
Do not attempt to replace the internal rechargeable lithium ion battery. Contact Lenovo
Support for factory replacement.
Polyvinyl Chloride (PVC) cable and cord notice
WARNING: Handling the cord on this product or cords associated with accessories
sold with this product will expose you to lead, a chemical known to the State of
California to cause cancer, and birth defects or other reproductive harm. Wash hands
after handling.
Prevent hearing damage
Your device has a headphone connector. Always use the headphone connector for
headphones (also called a headset) or earphones.
CAUTION:
Excessive sound pressure from earphones and headphones can cause hearing
loss. Adjustment of the equalizer to maximum increases the earphone and
headphone output voltage and the sound pressure level. Therefore, to protect
your hearing, adjust the equalizer to an appropriate level.
Excessive use of headphones or earphones for a long period of time at high volume
can be dangerous if the output of the headphone or earphone connectors do not
comply with specifications of EN 50332-2.
The headphone output connector of your device complies with EN 50332-2 Sub
clause 7. This specification limits the device's maximum wide band true RMS output
voltage to 150 mV. To help protect against hearing loss, ensure that the headphones or
earphones you use also comply with EN 50332-2 (Clause 7 limits) for a wide band
characteristic voltage of 75 mV. Using headphones that do not comply with
EN 50332-2 can be dangerous due to excessive sound pressure levels.
7

Warning statement:
To prevent possible hearing damage, do not listen at high volume levels for a long
period of time.
Warranty information
Lenovo Limited Warranty notice
This product is covered by the terms of the Lenovo Limited Warranty, version
L505-0010-02 08/2011. Read the Lenovo Limited Warranty (LLW) at
http://www.lenovo.com/warranty/llw_02. You can view the LLW in a number of
languages from this Web site. If you cannot view the LLW from the Web site, contact
your local Lenovo office or reseller to obtain a printed version of the LLW.
YOGA Tab 3 8”
Model & Version
Model Version
WLAN
LTE
Lenovo YT3-850F
Lenovo YT3-850L
Lenovo YT3-850M LTE (Voice)
If your device came with headphones or earphones in the package, as a set, the
combination of the headphones or earphones and the device already complies with
the specifications of EN 50332-1. If different headphones or earphones are used,
ensure that they comply with EN 50332-1 (Clause 6.5 Limitation Values). Using
headphones that do not comply with EN 50332-1 can be dangerous due to excessive
sound pressure levels.
Sound pressure warning statement
For the device that is tested in accordance with EN 60950-1:
2006+A11:2009+A1:2010+A12:2011, it is mandatory to perform audio tests for
EN 50332.
This device has been tested to comply with the Sound Pressure Level requirement laid
down in the applicable EN 50332-1 and/or EN 50332-2 standards. Permanent hearing
loss may occur if earphones or headphones are used at high volume for prolonged
periods of time.
8

* Excludes some components. 90-day limited warranty for power adapters, keyboards,
plastics and hinges.
Warranty period and type of Warranty service
1,3
1,4
4
1,5
Panama 2,4
Taiwan, South Korea 3,4
Brazil 2,5
1,3
1,5
Turkey 3,4
4Saudi Arabia
Serbia 1,4
Country or Region Purchase Warranty Period Type of Warranty
Service
France, Germany, Italy, Austria,
United Kingdom, Israel, Australia,
New Zealand
Guatemala, Costa Rica, Venezuela, Peru,
Uruguay, Ecuador, Colombia, Chile,
Argentina, Indonesia, Vietnam, India,
Malaysia, Thailand, Philippines, Singapore,
Hong Kong, El Salvador
Russia, Ukraine, Egypt, Lebanon, Morocco,
South Africa, Tunisia, Mauritius, Mozambique,
United Arab Emirates, Jordan, Kenya,
Nigeria,Uganda, Ghana, Oman,Tanzania,
Namibia
Poland, United States of America, Canada,
Mexico, Japan
Spain, Switzerland, Portugal, Netherlands,
Belgium, Sweden, Denmark, Norway,
Finland, Estonia, Latvia, Lithuania, Iceland
Czech Republic, Hungary, Romania, Bulgaria,
Greece, Croatia, Slovenia, Slovakia, Cyprus
Parts and labor - 1 year
Battery Pack - 1 year
Parts and labor - 1 year
Battery Pack - 1 year
Parts and labor - 1 year
Battery Pack - 1 year
Parts and labor - 1 year
Battery Pack - 1 year
Parts and labor - 1 year
Battery Pack - 1 year
Parts and labor - 1 year
Battery Pack - 1 year
Parts and labor - 1 year
Battery Pack - 1 year
Parts and labor - 2 years
Battery Pack - 1 year
Parts and labor - 2 years
Battery Pack - 1 year
Parts and labor - 2 years
Battery Pack - 1 year
Parts and labor - 2 years
Battery Pack - 1 year
Parts and labor - 2 years
Battery Pack - 1 year
9

Types of Warranty Service
1. Customer Replaceable Unit (“CRU”) Service
2. On-site Service
3. Courier or Depot Service
4. Customer Carry-In Service
5. Mail-in Service
6. Customer Two-Way Mail-in Service
7. Product Exchange Service
For a full explanation of the types of warranty service, refer to the full warranty. See
“Lenovo Limited Warranty notice” for details on accessing the full warranty.
Environmental, recycling, and disposal information
General recycling statement
Lenovo encourages owners of information technology (IT) equipment to responsibly
recycle their equipment when it is no longer needed. Lenovo offers a variety of
programs and services to assist equipment owners in recycling their IT products. For
information on recycling Lenovo products, go to http://www.lenovo.com/recycling.
Important WEEE information
Recycling information for Japan
Recycling and disposal information for Japan is available at:
http://www.lenovo.com/recycling/japan
Additional recycling statements
Additional information about recycling device components and batteries is in your
User Guide. See “Accessing your User Guide” for details.
Battery recycling marks
Battery recycling information for Taiwan
Battery recycling information for the United States and Canada
Electrical and electronic equipment marked with the symbol of a crossed-out
wheeled bin may not be disposed as unsorted municipal waste. Waste of
electrical and electronic equipment (WEEE) shall be treated separately using
the collection framework available to customers for the return, recycling, and
treatment of WEEE.
Country-specific information is available at:
http://www.lenovo.com/recycling
10

India
RoHS compliant as per E-Waste (Management & Handling) Rules, 2011.
Vietnam
Lenovo products sold in Vietnam, on or after September 23, 2011, meet the requirements
of the Vietnam Circular 30/2011/TT-BCT (“Vietnam RoHS”).
European Union
Lenovo products sold in the European Union, on or after 3 January 2013 meet the
requirements of Directive 2011/65/EU on the restriction of the use of certain hazardous
substances in electrical and electronic equipment (“RoHS recast” or “RoHS 2”).
For more information about Lenovo progress on RoHS, go to:
http://www.lenovo.com/social_responsibility/us/en/RoHS_Communication.pdf
Battery recycling information for the European Union
Energy efficiency mark
EurAsia compliance mark
Ukraine
Restriction of Hazardous Substances Directive (RoHS)
Turkey
The Lenovo product meets the requirements of the Republic of Turkey Directive on the
Restriction of the Use of Certain Hazardous Substances in Waste Electrical and
Electronic Equipment (WEEE).
Atık Elektrikli ve
AEEE
AEEE
AEEE
Elektronik Eşya
11

Baca panduan ini secara saksama sebelum menggunakan YOGA Tab 3 8”.
Semua informasi yang ditandai dengan * dalam panduan ini hanya mengacu pada
model LTE (Lenovo YT3-850L/Lenovo YT3-850M).
Indonesia
Pemberitahuan emisi
elektronik
Pelajari lebih lanjut
Pemberitahuan
hukum
Lenovo dan logo Lenovo adalah merek dagang dari
Lenovo di Amerika Serikat, negara lain, atau keduanya.
Perusahaan, produk, atau nama layanan lainnya mungkin
merek dagang atau merek layanan dari pihak lain.
Diproduksi di bawah lisensi dari Dolby Laboratories.
Dolby, Dolby Atmos, dan simbol D dobel adalah merek
dagang milik Dolby Laboratories.
PEMBERITAHUAN TENTANG HAK YANG TERBATAS
DAN TIDAK BEBAS: Jika data atau perangkat lunak
diberikan sesuai dengan kontrak Administrasi Layanan
Umum/General Services Administration “GSA”, maka
penggunaan, penggandaan, atau pengungkapannya
tunduk terhadap pembatasan yang ditetapkan dalam
Kontrak No. GS-35F-05925.
Informasi Deklarasi Konformitas terletak di dalam
Pemberitahuan Peraturan. Untuk mendapatkan versi PDF
dari Pemberitahuan Peraturan, kunjungi:
http://support.lenovo.com/
Mendapatkan
dukungan
Untuk dukungan penagihan dan layanan jaringan,
hubungi operator jaringan nirkabel Anda. Untuk petunjuk
cara menggunakan YOGA Tab 3 8”, kunjungi:
http://support.lenovo.com/
Peraturan Perlengkapan Terminal Telekomunikasi
dan Radio
Lenovo menyatakan bahwa produk ini tidak memenuhi
syarat terhadap:
● Persyaratan penting dan ketentuan yang relevan
lainnya dari Peraturan Perlengkapan Terminal
Telekomunikasi dan Radio, 1999/5/EC
● Semua petunjuk di EU yang relevan lainnya
Kesesuaian dengan Uni Eropa
0560
12

Spesifikasi teknis
Qualcomm APQ8009
*Qualcomm MSM8909
6200 mAh
Kamera
Baterai
Layar
①Komunikasi
nirkabel
8 megapiksel
Ukuran: 20,32 cm (8 inci)
Resolusi: 800 × 1280
Bluetooth 4.0; WLAN 802.11 b/g/n;
GPS/GLONASS; *LTE/WCDMA/GSM
YOGA Tab 3 8” Anda mendukung LTE Band 1, 3, 4, 5, 7, 8, 19, 20, 38 dan 40.
Tetapi di beberapa negara, LTE tidaklah didukung. Untuk mengetahui apakah
YOGA Tab 3 8” dapat berfungsi dengan jaringan LTE di negara Anda, hubungi
operator Anda.
①
Model & versi
CPU
YOGA Tab 3 8”
Versi: WLAN
Android
*Versi: LTE (Suara)*Model: Lenovo YT3-850M;
*Versi: LTE*Model: Lenovo YT3-850L;
Model: Lenovo YT3-850F;
Sistem
13

Model WLAN (Lenovo YT3-850F) tidak memiliki slot kartu SIM Mikro.
Anda dapat menggunakan pensil atau pena berujung logam berdiameter 0,7 mm
atau lebih, termasuk pena fountain, pena rollerball, dan beberapa pena ballpoint,
untuk menulis dan menggambar pada layar atau melakukan operasi sentuh
tambahan. Tips khusus: Terdapat risiko menggores layar jika Anda memberi tekanan
terlalu besar ketika menulis atau menggunakan ujung pensil yang terlalu keras.
!!! Jangan memasukkan jari Anda ke dalam lubang kait. Jari Anda bisa terluka.
Tampilan sekilas
5
10
Konektor USB Mikro2
6
3
789
4
1Tombol On/Off
Speaker Mikrofon Jack earphone
Penyangga Lubang kait Tombol tekan penyangga
Kamera berputar
8
1
2
3
44
5
67
10
11
12
Tombol volume
8
11 Slot kartu MicroSD
9
12 *Slot kartu SIM Mikro
14

Anda dapat menggunakan layanan seluler dengan model LTE (Lenovo YT3-850L/Lenovo
YT3-850M) dengan memasukkan kartu SIM Mikro yang disediakan oleh operator Anda.
Pasang kartu SIM Mikro dan kartu microSD seperti pada gambar.
Langkah 3. Tekan kembali penyangga.
Hanya kartu SIM Mikro yang kompatibel dengan tablet Anda.
!!! JANGAN masukkan atau lepaskan kartu SIM Mikro saat tablet Anda dalam keadaan
hidup. Hal ini dapat merusak kartu SIM Mikro atau tablet Anda secara permanen.
1
2
1
2
2
1
Langkah 1. Tekan tombol tekan untuk
membuka penyangga.
Langkah 2. Buka penutup slot kartu.
Masukkan kartu SIM Mikro dan
kartu microSD lalu pasang
penutup belakang slot kartu.
Menyiapkan tablet Anda
15

Menghidupkan/mematikan
Sambungkan tablet ke outlet daya menggunakan kabel dan adaptor daya USB yang
disertakan.
Daya baterai rendah Terisi penuh Mengisi daya
Menghidupkan: Tekan dan tahan tombol On/Off hingga
logo Lenovo muncul.
Mematikan: Tekan dan tahan tombol On/Off selama
beberapa detik, lalu ketuk Matikan-daya.
Mulai ulang: Tekan dan tahan tombol On/Off selama
beberapa detik, lalu ketuk Mulai ulang. Untuk memulai
ulang paksa tablet Anda, tekan lalu tahan tombol daya
sampai tablet bergetar.
Sebelum menggunakan tablet, Anda mungkin perlu mengisi baterainya. Isi baterai
seperti yang ditunjukkan pada gambar.
Menggunakan kamera berputar
Kisaran fungsional yang diperbolehkan untuk kamera
berputar ditampilkan di sebelah kiri.
Jangan memutar kamera secara berlebihan untuk
menghindari kerusakan.
Memulai penggunaan tablet
Mengambil screenshot
Tekan dan tahan tombol On/Off dan tombol Volume turun pada saat yang bersamaan.
16

125.00
Baca sebelum menggunakan tablet
Bagian ini berisi informasi keselamatan dan pengaturan yang penting untuk tablet
Lenovo dan petunjuk tentang cara mengakses dokumen versi elektronik yang dibuat
untuk tablet Anda.
Baca dahulu - Informasi peraturan
Model perangkat yang dilengkapi dengan komunikasi nirkabel telah sesuai dengan frekuensi
radio dan standar keamanan dari negara atau kawasan yang mengizinkan penggunaan fitur
nirkabel. Selain itu, jika produk Anda memiliki modem telekomunikasi, modem tersebut juga
memenuhi persyaratan untuk koneksi ke jaringan telepon di negara Anda.
Pastikan Anda membaca Pemberitahuan Peraturan funtuk negara atau kawasan Anda
sebelum menggunakan perangkat nirkabel yang ada di perangkat Anda. Untuk
mendapatkan Pemberitahuan Peraturan versi PDF, lihat bagian “Mengunduh publikasi”
berikut ini.
Mengunduh publikasi
Versi elektronik dari publikasi Anda tersedia dari http://support.lenovo.com. Untuk
mengunduh aplikasi untuk perangkat Anda, buka http://support.lenovo.com dan ikuti
petunjuk di layar.
Mengakses Panduan Pengguna Anda
Panduan Pengguna Anda berisi informasi terperinci tentang perangkat Anda. Untuk
mengakses Panduan Pengguna, gunakan salah satu cara berikut:
●Kunjungi http://support.lenovo.com dan ikuti petunjuk di layar.
Informasi Layanan dan Dukungan
Informasi berikut ini menjelaskan dukungan teknis yang tersedia untuk produk Anda
selama masa garansi atau sepanjang masa pakai produk Anda. Untuk penjelasan
lengkap mengenai ketentuan garansi Lenovo, lihat Garansi Terbatas Lenovo. Lihat
“Pemberitahuan Garansi Terbatas Lenovo” di bagian berikutnya dalam dokumen ini
untuk rincian tentang cara mengakses garansi lengkap.
Dukungan teknis online
Dukungan teknis online selalu tersedia selama masa pakai produk tersebut dan dapat
dilihat di: http://www.lenovo.com/support
Dukungan teknis melalui telepon
Anda dapat memperoleh bantuan dan informasi dari Pusat Dukungan Pelanggan
melalui telepon. Sebelum menghubungi perwakilan dukungan teknis Lenovo,
persiapkan informasi berikut ini: model dan nomor seri, seluruh kata seperti yang
ditampilkan di pesan kesalahan, dan uraian masalah.
Staf perwakilan dukungan teknis mungkin akan memandu Anda mengatasi masalah
tersebut lewat perangkat selama panggilan berlangsung.
17

10.00
Daftar nomor telepon Dukungan Lenovo di seluruh dunia
Penting: Nomor telepon dapat berubah tanpa pemberitahuan. Daftar terbaru nomor
telepon untuk Pusat Dukungan Pelanggan selalu tersedia di:
http://www.lenovo.com/support/phone
Jika tidak ada nomor telepon untuk negara atau wilayah Anda, hubungi dealer Lenovo
atau perwakilan pemasaran Lenovo.
Informasi penting tentang keamanan dan penanganan
Pemberitahuan tentang kantung plastik
BAHAYA:
Kantung plastik dapat berbahaya. Jauhkan kantung plastik dari bayi atau anak-anak
untuk menghindari bahaya tercekik.
Pemberitahuan tentang baterai isi ulang terintegrasi
BAHAYA:
Jangan coba-coba untuk mengganti baterai ion lithium isi ulang internal. Hubungi
Dukungan Lenovo untuk penggantian pabrik.
Pemberitahuan tentang kabel dan kawat Polyvinyl Chloride (PVC)
PERINGATAN: Memegang kawat dalam produk ini atau kawat yang terkait dengan
aksesori yang dijual bersama produk ini akan menyebabkan Anda terpapar timbal, zat
kimia yang menurut Negara Bagian California dapat menyebabkan kanker, cacat lahir,
atau gangguan reproduktif lainnya. Cuci tangan Anda setelah memegangnya.
Pencegahan gangguan pendengaran
Perangkat Anda memiliki konektor headphone. Selalu gunakan konektor headphone
untuk headphone (disebut juga headset) atau earphone.
HATI-HATI:
Tekanan suara yang berlebihan dari earphone dan headphone dapat
menyebabkan gangguan pendengaran. Penyetelan equalizer ke maksimum akan
meningkatkan tegangan output earphone dan headphone serta tingkat tekanan
suara. Oleh karena itu, untuk melindungi pendengaran Anda, setel equalizer ke
tingkat yang sesuai.
Penggunaan headphone atau earphone yang berlebihan dalam waktu yang lama
dengan volume suara yang tinggi dapat berbahaya jika output konektor headphone
atau earphone tidak sesuai dengan spesifikasi EN 50332-2.
Konektor output headphone perangkat Anda sesuai dengan EN 50332-2 Subklausul
7. Spesifikasi ini membatasi tegangan output maksimum true RMS pita lebar pada
perangkat ke 150 mV. Untuk membantu melindungi dari kerusakan pendengaran,
pastikan headphone atau earphone yang Anda pakai sesuai dengan EN 50332-2
(batas-batas Klausul 7) untuk tegangan karakteristik pita lebar sebesar 75 mV.
Menggunakan headphone yang tidak mematuhi EN 50332-2 bisa berbahaya karena
tingkat tekanan suara yang berlebihan.
18

Pernyataan peringatan:
Untuk mencegah kemungkinan gangguan pendengaran, jangan dengarkan pada
tingkat volume tinggi dalam waktu yang lama.
Informasi garansi
Pemberitahuan Garansi Terbatas Lenovo
Produk ini dicakup oleh Garansi Terbatas Lenovo, versi L505-0010-02 08/2011. Baca
Garansi Terbatas Lenovo (LLW) di http://www.lenovo.com/warranty/llw_02. Anda
dapat melihat LLW dalam berbagai bahasa dari situs web ini. Jika Anda tidak dapat
melihat LLW dari Situs web tersebut, hubungi kantor atau dealer lokal Lenovo untuk
mendapatkan versi cetak LLW.
YOGA Tab 3 8”
Model & Versi
Model Versi
WLAN
LTE
Lenovo YT3-850F
Lenovo YT3-850L
Lenovo YT3-850M LTE (Suara)
Jika perangkat Anda dikirimkan bersama headphone atau earphone, sebagai satu set,
kombinasi headphone atau earphone dan perangkat tersebut sudah sesuai dengan
spesifikasi EN 50332-1. Jika digunakan headphone atau earphone yang berbeda,
pastikan mereka sesuai dengan EN 50332-1 (Klausul 6.5 Nilai Batasan). Menggunakan
headphone yang tidak mematuhi EN 50332-1 bisa berbahaya karena tingkat tekanan
suara yang berlebihan.
Peringatan tentang tekanan suara
Untuk perangkat yang diuji sesuai dengan EN 60950-1:
2006+A11:2009+A1:2010+A12:2011, wajib dilakukan uji audio untuk EN 50332.
Perangkat ini telah diuji memenuhi persyaratan Level Tekanan Suara yang ditetapkan
dalam standar EN 50332-1 dan/atau EN 50332-2 yang berlaku. Kehilangan
pendengaran secara permanen dapat terjadi jika earphone atau headphone digunakan
pada volume tinggi dalam waktu yang lama.
19
