Lenovo ThinkPad 18384PU User manual

For more information
www.lenovo.com
From the makers of the ThinkPad®comes an exciting Android
3.1 Tablet that oers a superior multimedia and entertainment
experience. The Lenovo®ThinkPad Tablet. Unlike the other
Tablets, it comes with additional features to help business
professionals to do more on the go and also allows IT managers
support them easily, no matter where they go. This means,
better management of multiple devices, more customization
options, higher productivity, and more importantly, enhanced
security. So, if you are looking for a Tablet built for business,
then it has to be the ThinkPad Tablet. For IT Managers:
• EasilydeployandprovisionmultipledeviceswithLenovo’s
custom imaging service and zero touch deployment solution
• Provideeasyandsecuree-mailaccesswithGood 
Technologies (certified) and Cisco VPN support
Control device security with Active Directory Password,
Microso®ActiveSync integration, encrypted
user data and SD Cards
• Purchaseanddeploycorporateapplicationsviacompany
unique Application Shops (supported by Lenovo)
*May not be available on all models.
For Business Professionals:
• Stayconnectedtocolleaguesandfriendswitheasy
 e-mail,pre-installedsocialnetworkingapplications;
 a2MPfront-facingcameraforvideocallsandSocial
Touch—a unique application that pulls it all together in an
easy to use widget
• ViewandeditMicroso®Oce documents with
 DocumentstoGobyDataViz
• Writenaturallyandjotdownhandwrittennotes,that
automatically convert to handwritten text, mark
IT HAS THE BODY OF A TABLET.
AND A HEAD FOR BUSINESS.
View and edit MS Oce documents
Project 1080 video to External Displays Jot down handwritten notes
Securely connect to corporate e-mail
Handwriting to text conversion
Transfer media files and documents
from USB keys and SD cards
up documents, and draw pictures with the accurate pressure
sensitive ThinkPad Tablet Pen*
• Comfortablytypelonge-mails,createdocumentsandenter 
data in forms or spreadsheets, thanks to the convenient
ThinkPad Tablet Keyboard Folio*withbuilt-inoptical  
TrackPoint®

For more information
www.lenovo.com
*Specific view per benchmark shows 31% improvement over previous model. All products and offers are subject to availability. Lenovo reserves the right to alter product offerings and specifications at
any time, without notice. Lenovo makes every effort to ensure accuracy of all information but is not liable or responsible for any editorial, photographic or typographic errors. All images are for illustration
purposes only. For full Lenovo product, service and warranty specifications visit www.lenovo.com The following are registered trademarks of Lenovo: Lenovo, the Lenovo logo, ThinkPad, ThinkPlus and
TrackPoint. Microsoft and Windows are registered trademarks of Microsoft Corporation in the U.S. or other countries. Intel, Core Inside, Intel Inside and the Intel Inside logo are registered trademarks of
the Intel Corporation in the U.S. or other countries. Other company, product and service names may be trademarks or service marks of others. ©2011 Lenovo. All rights reserved.
THINKPAD KEYBOARD
FOLIO 0A36370
•Travel-readyfoliowitha
wired keyboard
•OptimizedforAndroid
•Easynavigationwiththe
optical TrackPoint®
THINKPAD TABLET DOCK (0A33953)
•Instantcharging,datasynchronization,
and device expansion
•HoldsTabletinanergonomic,verticalreadingposition
•Portsinclude:MicroUSB,HDMI,Stereoout,   
 MicrophoneinandaUSB2.0
•EasilyconguredwithThinkPadUSBKeyboardor  
 ThinkPadEdgewirelesskeyboardmousecombo
RECOMMENDED ACCESSORIES
LENOVO THINKPLUS®SERVICES
Operating System WiFi Options Display
Android 3.1 WiFiorWiFiand3G
Size:10.1"(257mm),Screenresolution:1280x800,
Automatic brightness control, multitouch technology, Thin
Film Transistor Liquid Crystal Display (TFT LCD) technology,
Supports for ThinkPad Tablet Pen input
Battery Life Processor Display Technology
8.7hrswithWiFi NVIDIA®Tegra™2dual-core
ARM processor IPSTechnology(178ºviewingangle),Corning®Gorilla®glass
Memory Internal Storage Integrated Camera Connectors
1GB 16GB,32GBor64GB
(depending on Tablet)
Front-facingcamera–2MP,
Rear-facingcamera–5MP
OneminiHDMIconnector,
OneUSB2.0connector,One
microUSBconnector,One
dock connector
Wireless Features Specs and Dimensions Size Battery
WirelessLAN,
Bluetooth®2.0,3G
on some Tablets
Weight:742.2gmWiFi,
756.1gm3G
Thickness:14.5mm
Width:260.4mm(10.3)
Depth:181.7mm(7.2) 24.1W3250mAhLi-Polymer
battery
Sensors Card Slot or Card Reader
Accelerometer,Gyroscope,AssistedGPS,
Ambient light sensor SIMcardslot,3-in-1mediacardreader
Preloaded Soware*
•Documents To Go:ViewandeditMSWord,PowerPoint,Exceldocuments.ViewAdobe®Acrobat®documents.
•MyScript Notes Mobile: Takes advantage of the ThinkPad Tablet Pen to convert handwriting to typed text.
•USB Data Transfer Utility:Easilytransferlesfromexternalstorageviathebuilt-infull-sizeUSBport
and this easy to use soware.
•Lenovo Launch Zone: Provides access points to commonly used applications.
•Lenovo SocialTouch: View events conducted through various widgets and applications on your Tablet, such
asPopMail,GoogleMapsandGoogleCalendar.
•Favorite Apps:Enablesyoutomanageyourfavoriteapplications.
•User Data and SD Card Encryption: Protects your confidential information stored on your flash media card.
•WiFi Import or Export
SPECIFICATIONS
*Not all soware available in all countries.
Protect Your ThinkPad Tablet with a true commercial portfolio of services that
let’s you concentrate on getting things DONE
•Fixedterm,xedcostcoveragethatmeetsyourrefreshcyclesandcritical
support needs
•24x7accesstoadvancedleveltechnicians,makingyourpriorityourpriority
•Protectionagainstunexpectedoperationalorstructuraldamageduetodrops,minor
 spillsorintegratedscreendamagesoyourTabletisprotectedwhileyou’reon-the-go
Services Options
•CustomImaging/AssetTagging
•2yrand3yrWarrantyExtensions(totalduration)
•PrioritySupport
•ThinkPadProtection
•On-siteServiceDelivery(whereavailable)
WW_WW_DS_Q2_12_23191
