Leonton PG5-1600-M12XB-110-67 Instructions for use

⚫PG5-1600-M12XB-110-67
⚫PG5-1600-M12XB-110-T67

© Copyright 2021 Leonton Technologies Co., Ltd. All Rights Reserved
This document contains information, which is protected by copyright. Reproduction, adaptation or
translation without prior permission is prohibited, except as allowed under the copyright laws.
Disclaimer
Leonton Technologies, Co. Ltd. provides this manual without warranty of any kind, expressed or
implied, including but not limited to the implied warranties of merchantability and fitness for a
particular purpose. Leonton Technologies, Co. Ltd. may make improvements and/or changes to the
product and/or specifications of the product described in this manual, without prior notice.
Leonton Technologies, Co. Ltd. will not be liable for any technical inaccuracies or typographical
errors found in this guide. Changes are periodically made to the information contained herein and
will be incorporated into later versions of the manual. The information contained is subject to
change without prior notice.

FCC Notice
This equipment has been tested and found to comply with the limits for a Class-A digital device, pursuant
to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy. It may cause harmful interference to radio communications if the equipment is not installed and
used in accordance with the instructions. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
⚫Reorient or relocate the receiving antenna.
⚫Increase the separation between the equipment and receiver.
⚫Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
⚫Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the grantee of this device could void
the user's authority to operate the equipment.
Déclaration FCC
Cet équipement a été testé et reconnu conforme aux limites de la classe A pour les équipements
numériques, conformément à la section 15 des Réglementations FCC. Ces limites sont conçues pour fournir
une protection raisonnable contre toutes interférences nuisibles dans un milieu résidentiel. Cet
équipement génère, utilise, et peut émettre de l’énergie de fréquence radio et, s’il n’est pas installé et
utilisé conformément au manuel d’instruction, peut perturber la réception radio. Cependant, il n’est pas
garanti que l’équipement ne produira aucune interférence dans une installation particulière. Si cet
équipement cause des interférences nuisibles à la réception radio ou télévisée, qui peuvent être
déterminées en l’éteignant et le rallumant, l’utilisateur est encouragé à essayer de remédier au problème
en prenant les mesures suivantes:
⚫Réorienter ou déplacer l’antenne réceptrice.
⚫Augmenter la distance entre l’équipement et le récepteur.
⚫Connecter l’équipement à une prise secteur sur un circuit différent de celui utilisé par le récepteur.
⚫Consulter le négociant ou un technicien radio/TV expérimenté.
Attention: Tout changement ou modification non expressément approuvé par le concessionnaire de cet
appareil pourrait annuler l'autorité de l'utilisateur à utiliser l'équipement.
CE Mark Warning
This is a Class-A product. In a domestic environment this product may cause radio interference in which
case the user may be required to take adequate measures.
CE Mark Avertissement
Ceci est un produit de classe A. Dans un environnement domestique, ce produit peut être utilisé en
présence d'interférences radio.
This document is the current official release manual. Please check our website (www.leonton.com) for
any updated manual or contact us by e-mail ([email protected]om).

CONTENT
OVERVIEW ................................................................................................................................... 1
Key Features.................................................................................................................................................................1
Package Contents.......................................................................................................................................................2
Safety Precaution........................................................................................................................................................2
HARDWARE DESCRIPTION...................................................................................................... 3
Physical Dimensions ..................................................................................................................................................3
Front Panel....................................................................................................................................................................4
LED Indicators..............................................................................................................................................................5
Ethernet Ports..............................................................................................................................................................6
USB Port ........................................................................................................................................................................7
Console Port.................................................................................................................................................................7
Power Inputs ................................................................................................................................................................8
Relay Contact and Digital Input..............................................................................................................................9
Grounding Note........................................................................................................................................................11
Bypass Function ........................................................................................................................................................11
Reset to Default.........................................................................................................................................................11
MOUNTING INSTALLATION..................................................................................................12
Wall Mounting...........................................................................................................................................................12
HARDWARE INSTALLATION..................................................................................................13
Installation Steps ......................................................................................................................................................13
TROUBLE SHOOTING ..............................................................................................................15

1
OVERVIEW
This series is rated IP67 and installation by Wall Mounting. Each unit of this industrial gigabit managed
Ethernet switch provided 16*10/100/1000Base-Tx with IEEE 802.3at compliant ports (30W/port), suitable
for Ethernet conversion applications.
In order to prevent unregulated voltage, this series provides high EFT and ESD protection. This also allows
it to function in harsh environments, as well as support power redundancy with a dual power input design
with reverse polarity protection.
With one model having an operating temperature of -10°C ~ 65° C , and another with a wide operating
temperature of -40°C ~ 70°C, this series is designed to meet any needs for industrial automation
application and harsh environments.
Key Features
Interface & Performance
⚫Copper port support auto MDI/MDI-X function
⚫Embedded 16*10/100/1000Base-T(X) with PoE-PSE (30W/Port)
⚫Store-and-forward switching architecture
⚫32K MAC Address Table
⚫Supports 9.6Kbytes Jumbo Frame
⚫32Mbits memory buffer
Power Input
⚫Dual 24-110VDC redundant power inputs through M12 5-Pin K-Coded male connector, with SELV
output certified by UL61010-2-201
⚫Max. current 7A
⚫Max. PoE output: 120W
Certification
⚫CE/FCC
Operating Temperature
⚫Standard operating temperature model: -10°C ~ 65° C
⚫Extended operating temperature model (–T): -40°C ~ 70° C
Case/Installation
⚫IP67 protection
⚫Wall mount design
⚫Installation in a pollution degree 2 industrial environment
⚫Aluminum case
