tLervia Fan Heater KH 1149 Operating Instructions
IDNr.: KH 1149-10/03
Kompernaß Handelsgesellschaft mbH · Burgstraße 21 · D-44867 Bochum
www.kompernass.com
UK

 
 

3

Safety instructions........................................................................................................4
Danger of electric shock ................................................................................................4
Fire hazard......................................................................................................................5
Danger of injury..............................................................................................................5
Danger of burning ..........................................................................................................5
Danger of tripping ..........................................................................................................6
Proper use......................................................................................................................6
Description....................................................................................................................6
Operation ......................................................................................................................7
Setting the direction of air flow......................................................................................7
Switching on the appliance and setting a time of operation ........................................7
Setting the room temperature........................................................................................8
Oscillating function ........................................................................................................8
Switching off the device ................................................................................................8
Transportation ................................................................................................................8
Cleaning ........................................................................................................................9
Rectifying malfunctions ............................................................................................10
Disposal ......................................................................................................................10
Technical data ............................................................................................................11
Guarantee and service ..............................................................................................11
Manufacturer and declaration of conformity ..........................................................11
Table of Contents
KH1149_Heizluefter_UK.qxd 06.05.2004 15:10 Uhr Seite 3

4
t
Safety instructions
Danger of electric shock!
•Plug the fan heater only in a properly installed, earthed
power socket with a voltage of 230 V~, with 50 Hz.
•Do not fold or squeeze the power cord.
•Always unplug the power cord by grasping the plug,
do not pull on the cord itself.
•Never touch the fan heater, power cord or plug when your hands are wet.
•Do not use an extension cord.
•Do not wrap the power cord around the casing of the fan heater.
Please use the hooks which have been provided for this purpose.
•Disconnect your fan heater from the power supply immediately after use.
It is only completely switched off after having been unplugged.
•Do not at any time submerge the fan heater in liquid and do not allow any
liquid to get into the casing of the fan heater. Do not expose the appliance
to dampness or use it outdoors. There is danger of electric shock. Should
liquid happen to find its way into the appliance's casing, unplug the appli-
ance immediately and have it repaired by a qualified professional.
•Do not at any time use the fan heater near water in,
for example, bathtubs, showers, sinks or damp cellars. Being close to
water poses a danger even when the appliance
is turned off.
•Unplug the fan heater in case of malfunction and before cleaning.
•Should the power cord be damaged, have the fan heater repaired by a
qualified professional before using it again.
•Should the fan heater be dropped or become damaged, do not
use it anymore. Have the appliance inspected by a qualified professional
and repaired if necessary.
•Do not open or repair the fan heater's casing.
Safety cannot be ensured in this case, and the guarantee is no longer
valid. Have the defective fan heater repaired only by authorised
professionals.
•Do not place the fan heater close to heat sources and protect the power
cord from being damaged.
KH1149_Heizluefter_UK.qxd 06.05.2004 15:10 Uhr Seite 4

5
t
Fire hazard!
•Never place the fan heater near combustible materials, liquids, gases or
directly under a wall socket. Leave room on all sides and at least one
meter above the appliance.
•Do not cover the appliance while it is in operation. Clean it at regular inter-
vals.
•Keep a suitable distance from the fan heater to avoid hair or clothing being
drawn in by the appliance.
•Never leave the fan heater unattended.
•Do not allow children to use the fan heater unless under the supervision of
an adult. Explain the dangers associated with using the appliance.
•Always place the fan heater on a flat surface. Otherwise the fan heater
could tip over and start a fire.
•Take care that the fan heater can oscillate in both directions when the
oscillating function is turned on.
•Do not at any time use the fan heater near water in, for example, bathtubs,
showers, sinks or damp cellars. Being close to water poses a danger even
when the appliance is turned off.
•Do not place the fan heater close to heat sources and protect the power
cord from being damaged.
Danger of injury!
•Do not at any time poke objects or body parts, for instance fingers,
through the grill into the inside of the fan heater.
•Keep a suitable distance from the fan heater to avoid hair or clothing being
drawn in by the appliance.
•Do not allow children to use the fan heater unless under the supervision of
an adult. Explain the dangers associated with using the appliance.
Danger of burning!
•The fan heater will heat up during operation. Therefore, never carry it when
it in a hot condition;
carry only using the handle provided for this purpose.
•Do not allow children to use the fan heater unless under the supervision of
an adult. Explain the dangers associated with using the appliance.
KH1149_Heizluefter_UK.qxd 06.05.2004 15:10 Uhr Seite 5

6
t
Danger of tripping
•Place the power cord in such a way that no one will step or trip on it.
•Do not use an extension cord.
Proper use
The fan heater serves the purpose of heating and ventilating living spaces. This
fan heater is designed solely for use in private households and may only be
used in such. This also includes observance of all information in these operating
instructions, particularly the safety instructions. All other uses are deemed to be
improper and can result in property damage or even in personal injury.
Kompernaß does not assume liability for damage caused by improper use.
You can heat and ventilate living spaces using the fan heater.
Figure A
Description
1Carrying handle
3Heating grill
5Base
7Timer
2Thermostat controller
4Switch for the oscillating function
6Control light
8Function switch
KH1149_Heizluefter_UK.qxd 06.05.2004 15:10 Uhr Seite 6

7
t
Operation
➩Remove the electric fan heater from the transportation packaging.
➩Place the fan heater on a flat surface.
➩Plug in the power cord.
➩Turn the function switch (centre) to the right.
The fan will turn on and the control light will illuminate in red.
The fan heater is equipped with five switchable settings:
Setting the direction of air flow
➩Tip the fan heater forwards in order to direct the air flow downwards.
(Figure B, position a)
or
➩Tip the fan heater backwards in order to direct the air flow upwards.
(Figure B, position b)
Switching on the appliance and setting a time of operation
With the aid of the timer you can automatically shut off the appliance after a sel-
ected time.
➩Should you not wish to automatically shut off the appliance, set the timer
to “on”.
➩Should you wish the fan heater to automatically shut off after
a certain period of time, set the timer to the desired time in minutes.
Setting Condition of the fan heater
0off
warm air flow
 hot air flow
fan, no heat output
 very warm air flow
Caution!
Using the timer set the fan heater to “0” before plugging in the appliance.
Otherwise you could damage the appliance.
KH1149_Heizluefter_UK.qxd 06.05.2004 15:10 Uhr Seite 7

8
t
Setting the room temperature
➩Set the timer to the desired period of operation or to “on” (see above).
➩Turn the thermostat controller to maximum position.
Once the required room temperature is reached...
➩Turn back the thermostat controller until a „click“ can be heard and the fan
heater is switched off.
Should the room temperature sink below the set temperature, the fan hea-
ter will automatically turn on again. The fan heater will shut off automatical-
ly once the set room temperature has been reached.
Frost protection
➩Set the timer to the desired period of operation or to “on” (see above).
➩Turn the thermostat controller to minimum position.
If the room temperature falls below +4°C~+8°C the appliance switches on auto-
matically.
Oscillating function
The fan heater is equipped with an automated oscillating function.
➩Press the switch for the oscillating function" until it engages.
The fan heater will slowly sway left and right on its own.
➩Should you wish to end the oscillating function, press the switch for the
oscillating function again until it stops.
Switching off the appliance
➩Should you wish to shut off the fan heater, set the function switch to the
position “0”.
➩Unplug the appliance after every use.
Transportation
The fan heater is provided with hooks on its back side which may be unfolded;
the cord can be winded around them.
➩Pull out both hooks to wind the cord around them.
Figure C
➩Wind the power cord around the hooks.
Figure D
KH1149_Heizluefter_UK.qxd 06.05.2004 15:10 Uhr Seite 8

9
t
Danger of burning!
Carry the fan heater only by the handle provided for this purpose.
➩Should you wish to transport the fan heater, carry it only by the handle
provided for this purpose. .
➩Should you wish to store the appliance for a longer period of time or to
send it by post, always use the original packaging.
➩Clean the casing with mild soapsuds using a slightly damp cloth.
Caution!
Pack the fan heater only when it has cooled. Otherwise you could burn yourself
and damage objects.
Danger of electric shock!
Always unplug the fan heater before cleaning it. While cleaning, do not at any time
submerge it in water.
Danger of electric shock!
After having been cleaned, the fan heater must dry completely before being used
again.
Fire hazard!
Allow the fan heater to cool before cleaning it. Do not at any time use household
cleaning agents or flammable liquids or materials to remove stains.
Fire hazard!
Clean the air grill at regular intervals with a soft brush. Hold the appliance with its
back side facing down so that no filth can fall into the inside of the casing.
Cleaning
KH1149_Heizluefter_UK.qxd 06.05.2004 15:10 Uhr Seite 9

10
t
Rectifying malfunctions
Disposal
Symptom Possible cause and remedy
The fan heater
will not
turn on
The fan heater cannot be
shut off.
The fan heater shuts off. The time of operation set using the timer has elapsed.
Set the timer to “on” or select a new time setting.
An electronic component is defective. Unplug the fan
heater and have it inspected by a qualified professional.
The room temperature is higher than that which hasbeen
set with the thermostat controller. Set the thermostat
controller to a higher setting.
A household fuse is defective. Check the fuses and
reset them if necessary.
The power socket is defective. Try another power
socket.
The fan heater is possibly defective. Have the
fan heater inspected by a qualified professional.
Dispose the fan heater using an approved waste disposal service or your muni-
cipal waste disposal facilities. Do not on any account throw the fan heater away
with the normal household rubbish.
Please observe the current regulations in effect. In case of doubt, please contact
your waste disposal facilities.
KH1149_Heizluefter_UK.qxd 06.05.2004 15:10 Uhr Seite 10

11
t
Technical data
Guarantee and service
Voltage 230V~, 50 Hz
Rated power 2000 W
Kindly consult the supplementary sheet Guarantee for the conditions of the gua-
rantee and the service address.
Kompernaß Handelsgesellschaft mbH,
Burgstraße 21, D-44867 Bochum, Germany,
hereby declares this product to be in accordance with the following standards
and directives:
•Low Voltage Directive 73/23/EEC
•EN 60,335-1
•EN 60,335-2-30
•Electromagnetic Compatibility (EMC) Directive 89/336/EEC
•EN 55,014-1
•EN 55,014-2
•EN 61,000-3-2
•EN 61,000-3-3
Type of Appliance/Type: KH 1149
Bochum, 20 October 2003,
Hans Kompernaß, Managing Director
Manufacturer and declaration of conformity
KH1149_Heizluefter_UK.qxd 06.05.2004 15:10 Uhr Seite 11

Fold out page
AB
CD
a b
0
1
2
7
8
3
6
4
5
Heizlfter KH 1149.qxd 27.10.2003 15:40 Seite 12
