LEUCHTWURM 43LED/526 User manual

43LED/526
43LED/526 is a convertor which works with Surnicher’s receiver 43LED/520 series to be controlled by
IOS or Android system via WIFI. IOS and Android application is similar, we will use IOS as an example in this
manual.
WIFI CONTROLLER
für Gleichspannung oder Gleichstrom
verwendbar mit Empfänger 43LED/520 oder 43LED/521
Parameter
Wiring diagram
Brief introduction of buttons
Feature
Safety & Warnings
Warranty Agreement
1) The product shall be installed and serviced by a qualified person.
2) IP20.Please avoid the sun and rain. When installed outdoors, please ensure it is mounted in a water proof
enclosure.
3) Always be sure to mount this unit in an area with proper ventilation to avoid overheating.
4) Please check if the output voltage of any LED power supplies used comply with the working voltage of the
product.
5) Never connect any cables while power is on and always assure correct connections to avoid short circuits
before switching on.
6)
7) For update information please consult your supplier.
Please ensure that the cable is secured tightly in the connector
1) We provide lifelong technical assistance with this product:
3-year warranty. We print date on every products, for example :1125 means year 2011,week 25.The
warranty is for free repair or replacement and covers manufacturing faults only.
For faults beyond the 3-year warranty we reserve the right to charge for time and parts.
2) Limited Warrenty
Any defects caused by wrong operation.
Any damages caused by unauthorized removal, maintenance, modifying, incorrect connection and
replacement of chips.
Any damages due to transportation, vibration etc. after purchase.
Any damages caused by earthquake, fire, lightning, pollution and abnormal voltage.
Any damages caused by negligence, inappropriate storing at high temperatures and humidity or near
harmful chemicals.
Product has been updated
3) Repair or replacement as provided under this warranty is the exclusive remedy to the customer.
Part No. Operation Voltage
43LED/526 12-24VDC
Output
RF Signal
Operation frequency
2.4G
Tx
Link
Ready
43LED/526
ANT2
ANT1
(12-24VDC)
(12-24VDC)
Configure &
Reset button
Tx
Link
Ready
43LED/526
ANT2
ANT1
(12-24VDC)
(12-24VDC)
Configure &
Reset button
Power Supply
12-24VDC
LN
110V-230VAC
Short press to learn to controller
Long press to delete controller
Bedienungsanleitungen und Schaltdiagramme finden Sie
unter www.leuchtwurm.at mittels Suche der jeweiligen Artikelnummer.
Bedienungsanleitungen und Schaltdiagramme finden Sie
unter www.leuchtwurm.at mittels Suche der jeweiligen Artikelnummer.

43LED/526
Technische Daten:
U in 12 - 24VDC
I in 0,3 A (max)
RF Out 10 dBm (max)
RF Frequenz 869,5 MHz
Verwendbar mit 43LED/520 + 43LED/521
Für Android und IOS- Betriebssysteme geeignet
App downloadbar unter: www.sunricher.com
App-Name in Play-Store:
„Easycolor“- 1-Zonen Bedienung
„Realcolor“- 4-Zonen Bedienung
koppelbar mit 43LED/520 + 43LED/521
Einlernen-/Programmierung:
1. WIFI-Controller (43LED/526) und Empfänger (43LED/520) zurücksetzen auf Werkseinstellung
Taste auf dem jeweiligen Controller mind. 5sec. gedrückt halten
2. APP von www.sunricher.com oder App-Store : App-Name: „Easycolor, „Realcolor“oder
„Easylighting Pro“ downloaden und installieren
3. App einschalten und mit WIFI-Controller koppeln
(WLAN einschalten, aktive WLAN-Verbindungen trennen !)
4. Einlerntaste am Empfänger kurz betätigen, unmittelbar danach Einlerntaste am WIFI-Controller
betätigen, beliebige Taste an der Fernbedienung (app) und gleich danach Farbrad betätigen.
(erfolgreiches Koppeln bestätigt Reaktion des LED-Strips)
