USeR MANUAL
www.myLevana.com
Model #:
Safe’N See
Additional Camera
for LV-TW501 Digital Baby Monitor
Model #: LV-TW501-C

We takequality very seriously.This is why all of our products come with a one year warranty from the original
purchase date against defects in workmanship and materials. If you have warranty or support issues please
contact us using any of the following methods:
Phone: [phone] LEVANA Canada LEVANA USA
Fax: [phone] Montrose Road 60 Industrial Parkway #Z64
Web: www.myLEVANA.com Niagara Falls, ON Cheektowaga NY 14227
Canada, L2H 1J9 USA 14305
Warranty Terms
1. LEVANA products are guaranteed for a period of one year from the date of purchase against defects in
workmanshipandmaterials.Thiswarrantyis limited tothe repair, replacement orrefundof thepurchase
price at LEVANA’s option.
2. This warranty becomes void if the product shows evidence of having been misused, mishandled or
tampered with contrary to the applicable instruction manual.
3. Routine cleaning, normal cosmetic and mechanical wear and tear are not covered under the terms of this
warranty.
4. The warranty expressly provided for herein is the sole warranty provided in connection with the product
itself and no other warranty, expressed or implied is provided. LEVANA assumes no responsibilities for
any other claims not specically mentioned in this warranty.
5. This warranty does not cover the shipping cost, insurance or any other incidental charges.
6. YouMUST call LEVANAbeforesending anyproduct backfor repair.You willbe sentaReturnAuthorization
form with return instructions. When returning the product for warranty service, please pack it carefully
in the original box with all supplied accessories, and enclose your original receipt or copy, and a brief
explanation of the problem (include RA #).
7. This warranty is valid only in Canada and the continental U.S.
8. This warranty cannot be re-issued.
PRODUCT WARRANTY
INFORMATION
Please visit our web site at www.myLEVANA.com for
information about your product’s warranty
2

3
INTRODUCTION
PRODUCT WARRANTY INFORMATION............................................................................................................ 2
INTRODUCTION ............................................................................................................................................ 3
WHAT’S INCLUDED........................................................................................................................................ 3
FEATURES..................................................................................................................................................... 4
BUTTONS AND CONNECTIONS - CAMERA....................................................................................................... 5
MOUNTINGTHE CAMERA.............................................................................................................................. 7
PLACINGTHE BABY CAMERA......................................................................................................................... 7
TO MOUNT ON ATALBLETOP SAFELY ............................................................................................................. 7
TO MOUNT ON AWALL SAFELY...................................................................................................................... 7
SETTING UP YOUR SYSTEM............................................................................................................................ 8
BATTERY OPERATION ................................................................................................................... 8
ATTACHING POWER TOTHE CAMERA ........................................................................................... 8
CAMERA OPERATION .................................................................................................................................... 9
SWITCHINGTHE CAMERA ON/OFF ............................................................................................... 9
NIGHTVISION .............................................................................................................................. 9
NIGHTLIGHT................................................................................................................................. 9
PAIRINGTHE DEVICES ................................................................................................................................. 10
TROUBLESHOOTING..................................................................................................................................... 11
SPECIFICATIONS .......................................................................................................................................... 12
FCC STATEMENT .......................................................................................................................................... 13
SAFETY INSTRUCTIONS................................................................................................................................ 13
TABLE OF CONTENTS
Congratulations on your purchase of the Levana
TW501-C additional camera!This camera uses advanced
Clearvu® digital technology that will deliver a crystal clear view of your
baby’s room no matter where you are in the house. Feel free to relax and
take comfort in knowing that your child is in good hands with Levana.
WHAT’S INCLUDED
NightVision
Camera
• Power Adapter
• User Manual
• 24/7 Lifetime Live
Customer Support

4
FEATURES
ClearVu® Digital Wireless Technology
ClearVu® technology ensures outstanding image and sound clarity so that
youcanwatchandlistentoyourchildup to450ft away!1With Levana,youwillnever missamoment.
Temperature Monitoring to Ensure Safety
Many studies indicate that your baby’s room should be between 61°-68° F (16°-20° C).This camera
is equipped so you can monitor the temperature in your baby’s room and know that they are always
safe and comfortable.
Talk to Baby™ Intercom
Soothe yourbabyfromadistancewiththeTalk to Baby™ intercom.Withthe simplepressof a button
youcanletyourbabyknow youare on yourwaytotheir nursery or simply talk tothemuntiltheyfall
back to sleep without having to go into his or her room.
Night Vision
The built-in night vision allows you to see your child, in complete darkness. When the lights go out
the system automatically adjusts to the level of light. With 10ft of night vision range, the camera
can be placed anywhere in your child’s room while still displaying a precise image of your baby.2
Relaxing Night Light
The camera has a gentle night light that you are able to turn on and o from the parent unit (not
included). Turn the light on if your baby is getting restless to calm them and turn it o when your
baby is asleep, all without going into the baby’s room.
Energy Ecient Power Adapter
The power adapter saves you on power all while saving the environment. It is rated with a Level V
eciency standard which means it is 30% more energy ecient than other conventional power
adapters.
Wall Mount for the Best Viewing Angle
The camera can be wall mounted so you can easily view your baby in its crib as well as see all other
parts of the nursery.
Lifetime Live Customer Support
Our customer support team can be reached by phone, by email and live web chat. Our experts will
be happy to assist you in English, French and Spanish.
Disclaimers
1. Optimum range is 150ft when signal is passing through walls or oors. Microwave ovens (when in use) may cause signal
disruption at close range. Buildings with metal frames may also cause signal disruption. Maximum transmission range is 450ft.
2. Night vision range up to 10ft under ideal conditions. Objects at or beyond this range may be partially or completely obscured,
depending on the camera application.

5
BUTTONS AND CONNECTIONS - CAMERA

6
1. Antenna
Transmits and receives signals
2. Night Vision IR LEDs
Allows you to see up to 10 feet in
complete darkness
3. Camera Lens
Point at what you would like to
view on the monitor
4. Microphone
Captures all sounds in the baby’s room
5. Night Light
Soothe baby to sleep with the built
in night light
6. CDS Light Sensor
Detects the absence of
light and turns on night vision
7. Power LED
Indicates that the camera is
powered on
8. Power Input
Plug the included adapter into
this jack
9. Temperature Sensor
Reads the temperature and
displays it on the monitor
10. Battery Compartment
Remove screw to install 4 AAA batteries
(not included) for a completely wireless
system
BUTTONS AND CONNECTIONS - CAMERA

7
MOUNTING THE CAMERA
Placing the Baby Camera
This camera can be placed on a tabletop or hung from a screw on the wall
above the area being monitored. Place the camera within ten feet of the area being monitored for
best picture, and to ensure that everything will be visible with the IR LEDs on.
Note: It is unsafe to mount the camera directly on the crib or anywhere within 3 feet of it.
Power cords should NEVER be left within baby’s reach.
To Mount on a Tabletop Safely:
1. Place the camera on a tabletop no less than 3 feet away from
your baby’s crib.
2. Feed the power cord down the back of the table or use wall
clips to secure the cord away so baby cannot reach.
3. Plug in the power cord, check to ensure that you are getting a
good view of your child and there are no obstructions.
To Mount on a Wall Safely:
Before drilling a hole, it is important to check the reception and camera positioning in the place that
you intend on hanging it to the wall. Ensure you are hanging the camera no less than 3 feet away
from baby’s crib.
1. Pre-drill a hole in the wall using a 3/16”, 4.8mm
drill bit.
2. Insert a wall anchor into the wall and tap gently with a
hammer until the anchor is ush with the wall.
3. Insert a screw into the wall anchor and tighten until the
screw only sticks out about 1/2 inch.
4. Plug the power cord into the power jack of the camera.
5. Locate the wall mounting hole on the bottom or back of
the camera.
6. Slide the hole over the screw sticking out of the wall.
7. Check to see that the camera is secure, if it is loose you may
have to tighten the screw more.
8. Use wall clips to secure the power cord away from the crib or
baby’s reach.

8
Battery Operation
The camera unit can be powered using 4 AAA batteries instead of the
included AC adapter.
1. Remove the battery compartment cover on the bottom of the camera base, using a small
phillips (cross) head screwdriver.
2. Place 4 AAA batteries (not included) in the compartment, paying attention to the labelled
polarity markings.
3. Replace the battery compartment cover using the small screwdriver.
Attaching Power to the Camera
1. Connect the AC adapter to the transmitter as shown in the diagram.
2. Connect the small end into the DC Jack on the back of the camera, connect the other end of the
adapter into an available wall outlet.
SETTING UP YOUR SYSTEM
Note: The power LED will ash when the battery charge is low.
Note:This camera is meant to be used in conjunction with the LV-TW501 Digital Baby Monitor
system.You cannot use this camera with any other system. For details on how to connect
your additional camera to a parent unit, please see the pairing instructions on page 10.
If you need to purchase a LV-TW501 system please visit www.mylevana.com or call our
support team at 1-866-946-7828.

9
CAMERA OPERATION
Switching the Camera ON/OFF
Position the camera to view the area you wish to monitor,
angle the camera lens for best view, by turning it up or
down.
1. Slide the power switch to the ON position.
2. The Power LED on the front of the camera will light
up green.The camera is now ready to operate.
3. To turn OFF the camera, ip the power switch
back to the OFF position
↑
Note: If you are using batteries to power the camera unit, and it does not start up when the
power switch is in the ON position, you may need to replace the batteries. The Power
LED will ash slowly when the batteries have low power.
Night Vision
Thecamera is equipped with eightIR(infrared) LEDs.TheseLEDs,locatedonthefront of the camera,
allow you to see up to ten feet in complete darkness. Allowing you to check your baby at any time
of night.The night vision LEDs will activate automatically when the camera detects that light levels
are low.
Night Light
The camera has a calming night light included, you must use the parent unit (sold separately) to
turn on this night light.You will nd detailed instructions on how to adjust the settings of your baby
monitor in the instruction manual included with the LV-TW501 system.

10
PAIRING THE DEVICES
The camera must be paired (connected) to a monitor (parent unit not
included).The monitor comes with the LV-TW501 packaged system. Please see
our website at www.mylevava.com or call our support team at 1-866-946-7828 if you cannot
connect your camera with a monitor, or if you need to purchase a monitor.
1. Slide the power switch on the right hand side
of the camera to the OFF position.
2. Cover the light sensor on the front of the camera with
your nger or a cloth.
3. Slide the power switch on the camera to the
ON position.
4. With the monitor switched on, press and hold the
play/pause button for two seconds.
5. The pair icon will appear on the screen and
the power LED on the camera will blink for a few
seconds.
6. Press the menu button on the monitor to
conrm the setting.
7. C1... OK! will appear when the camera and monitor
are paired successfully and then the video and audio
will be transmitted automatically.
Note: If“C1...X”appears (pair failed) instead of“C1...OK!”you will have to remove all sources
of power from the camera and monitor and start the pairing process over again.
Light Sensor

11
TROUBLESHOOTING
PROBLEM SOLUTION
Equipment does not function • Camera and/or monitor are not
switched on
• The battery is dead or defective
• The power adapters are not connected
No reception • Camera and monitor are not paired
• Camera is too far away from monitor
• TheVOX sensitivity is set too low
Reception Interference (static) • The camera and monitor are too far apart
• The battery power is too low
• Other electronic devices are interfering with the
signal
• The camera or monitor are placed near too many
metal objects
Feedback (screeching, static) • The camera and monitor are too close together
• The volume on the monitor is set too high
Picture works but there is no sound • Volume setting is too low
Picture is black and white • Night vision LEDs are ON
• Increase the amount of light in the room being
monitored
The rechargeable battery will not
charge
• The power adapters are not connected
• Battery pack is not plugged in inside the battery
compartment
• The monitor is not docked properly
Maintenance
• Clean the surfaces of the camera with a soft, u-free cloth
• If the units become dirty, use a lightly damp cloth to wipe surfaces, taking care to not allow
water into any openings
• Never use cleaning agents or solvents

12
SPECIFICATIONS
Camera Specications
Input Power...............................................................................100 - 240 VAC, 50 - 60 Hz ~ 200mA
Output Power ............................................................................6VDC ~ 800mA
IR LEDs and Range .....................................................................4 LEDs, 10 foot range
Range.........................................................................................450 Feet Maximum
Frequency Range .......................................................................2.4 GHz
OperableTemperature ...............................................................32 ˚ F to 104 ˚ F (0 ˚ C to 40 ˚ C)
Transmission Power ...................................................................15 ~17 dBm

13
FCC STATEMENT
SAFETY INSTRUCTIONS
Read and Keep Instructions: All the safety and operating instructions should be read before the
video baby monitor is operated.
Water and Moisture: This product is designed for indoor use only.The unit should not be exposed
to rain, moisture, dripping or splashing. No objects lled with liquid should be place on top of, or
beside the product, such as a glass or vase. This item should not be used near water.
This device complies with part 15 of
the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received,
including interference that may cause undesired
operation.
Any changes or modications not expressly approved by
the party responsible for compliance could void the user’s
authority to operate the equipment.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the
radiator and your body. This transmitter must not be co-located or operating in conjunction with
any other antenna or transmitter.
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This device and its antenna must not be co-located or operating in conjunction with
any other antenna or transmitter.This device has been tested for compliance with FCC RF Exposure
(SAR) limits in the typical laptop computer conguration and this device can be used in desktop or
laptop computers with side mounted USB slots. This device and its antenna must not be co-located
or operated in conjunction with any other antenna or transmitter.
IC STATEMENT:
Operation of this device is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device.
The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modications to this equipment. Such modications could void the user’s authority to operate the
equipment.

14
SAFETY INSTRUCTIONS
Non-Use Periods: Always unplug the AC adapters from the wall outlets
during long periods of non-use.
Ventilation: This baby monitor should not be used on a bed, sofa, rug or similar surface that may
block the ventilation openings, or be placed in an enclosed area, such as a bookcase or drawer that
may impede air ow.
Keep Away from Sources of Heat: This unit should not be exposed to direct heat sources such as
a candle, replace, radiator, heat register, stove or other appliance that emits heat. The unit should
not be left in direct sunlight.
Power Source: This unit should only be used with the AC power adapters included in this package
(rated 6V 800mA)
Damage Requiring Service: This unit should be serviced by qualied personnel only when:
a. Objects have fallen or liquid has been spilled into the product
b. The units have been exposed to rain
c. The units do not appear to operate normally or exhibits a distinct change in performance
d. The units have been dropped or the enclosure damaged
Caution:Thisproductcannotreplace responsibleadult supervision ofachild.Youshould personally
check your child’s activity at regular intervals.
STATEMENT ON REGULATION
These units are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy
and if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected
• Consult the dealer or an experienced radio/TV technician for help
Operation with non-approved equipment or unshielded cables is likely to result in interference to
radio orTV reception.The user is cautioned that changes and modications made to the equipment
without the approval of manufacturer could void the user’s authority to operate this equipment.

15
NOTES

please visit
www.MYLevana.com for:
, Warranty information
, Product Support
, Contact information
, User Manual Downloads
, and much more!

visiter
www.mylevana.com pour:
, Informations de garantie
, Support technique
, informations de contact
, Manuels d'utilisateur
téléchargeable
, et beaucoup plus!

NOTES
15

14
CONSIGNES DE SÉCURITÉ
Ventilation: Ce moniteur bébé ne devrait pas être utilisé sur un lit, un
divan, un tapis ou une surface similaire qui pourrait bloquer les ouvertures de
ventilation, ou être placés dans un espace clos, tel qu’une bibliothèque ou un tiroir qui peut
empêcher l’écoulement de l’air.
Éviter les sources de chaleur : Cette unité ne devrait pas être exposée à des sources directes de
chaleur comme une bougie, cheminée, radiateur, un registre de chaleur, poêle ou autre appareil qui
émet de la chaleur. L’unité ne doit pas être laissée en plein soleil.
Source d’alimentation : Cette unité devrait être seulement utilisée avec les adaptateurs CA inclus
dans cet ensemble (évalué à 6V 800mA).
Dommages Exigeant le Service : Cette unité devrait être entretenue par le personnel qualié
seulement quand :
A. Des objets ont tombés ou du liquide a été renversé dans/sur le produit
B. Les unités ont été exposées à la pluie
C. Les unités ne semblent pas fonctionner normalement ou présentent un changement
notable de performance
D. Les unités ont été échappées ou le boîtier est endommagé
Attention: Ce produit ne peut remplacer la surveillance d’adultes responsables d’un enfant. Vous
devez vérier personnellement l’activité de votre enfant à des intervalles régulières.
DÉCLARATION SUR LE RÈGLEMENT
Ces unités sont conçues pour fournir une protection raisonnable contre les interférences nuisibles
dans une installation résidentielle. Cet équipement génère, utilise et peut émettre des fréquences
radio et s’il n’est pas installé et utilisé conformément aux instructions, peut causer des interférences
nuisiblesauxcommunications radio. Cependant,iln’existeaucunegarantieque desinterférencesne
se produiront pas dans une installation particulière. Si cet équipement provoque des interférences
nuisiblesàlaréception radiooudetélévision,qui peuventêtredéterminésen mettant l’équipement
hors tension, l’utilisateur est encouragé à essayer de corriger l’interférence par une ou plusieurs des
mesures suivantes:
• Réorienter ou déplacer l’antenne
• Augmenter la séparation entre l’équipement et le récepteur
• Connecter l’équipement à une prise sur un circuit diérent de celui auquel le récepteur
est branché
• Consulter le revendeur ou un technicien radio /TV
L’utilisation d’équipement non approuvé ou de câbles non blindés risque d’entraîner des interférences dans la
réceptionradioouTV.L’utilisateurestavertiqueleschangementsetlesmodicationsapportéesàl’équipement
sansl’approbation du fabricantpeutannulerl’autorisation de l’utilisateurà utiliser cet équipement.

13
Cet appareil est conforme à la partie 15 des
règlements de la FCC. Son fonctionnement est
soumis aux deux conditions suivantes:
(1) Cet équipement ne doit pas causer d’interférences nuisibles et
(2) Cet équipement doit accepter toute interférence reçue, y
compris les interférences capables de causer un mauvais
fonctionnement.
Tout changement ou modication pas expressément approuvé par le parti responsable de la conformité
pourrait annuler l’autorité de l’utilisateur de faire fonctionner l’équipement.
Déclaration de la FCC de l’exposition aux radiations:
Cet équipement est conforme à l’exposition aux radiations dénies pour l’environnement non contrôlé.
Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre le radiateur
et votre corps. Cet émetteur ne doit pas être co-localisés ou fonctionner conjointement avec une
autre antenne ou transmetteur. Cet équipement est conforme aux limites établies par la FCC contre
l’exposition aux rayonnements RF pour un environnement non contrôlé. Cet appareil et son antenne ne
doivent pas être co-localisés ou fonctionner conjointement avec une autre antenne ou transmetteur. Ce
dispositif a été testé pour la conformité aux normes FCC d’exposition aux RF (SAR) des limites dans la
conguration typique ordinateur portableetcedispositifpeut êtreutilisédansde bureauou ordinateurs
portables avec ports USB latéraux montés. Cet appareil et son antenne ne doivent pas être co-localisé ou
fonctionné conjointement avec une autre antenne ou transmetteur.
DÉCLARATION IC:
Le fonctionnement de cet appareil est sujet aux conditions suivantes :
(1) Cet équipement ne doit pas causer d’interférences nuisibles et
(2) Cet équipement doit accepter toute interférence reçue, y compris les interférences capables de
causer un mauvais fonctionnement.
Remarque:Lefabricantn’estpasresponsabled’aucune interférenceradioouTVcausée pardes modications
non autorisées à cet équipement. De telles modications pourraient annuler l’autorité de l’utilisateur à
opérer l’équipement.
CONSIGNES DE SÉCURITÉ
Lisez et conservez les instructions : Toutes les consignes de sécurité et de fonctionnement doivent
être lues avant de faire fonctionner le moniteur vidéo.
Eauethumidité: Ce produitest conçupourune utilisationàl’intérieur.L’uniténe doitpasêtre exposée
à la pluie, l’humidité, des gouttes ou des éclaboussures. Aucun objet rempli de liquide ne doit être placé
sur le dessus ou à côté du produit, tel qu’un verre ou un vase. Ce produit ne doit pas être utilisé près de
l’eau
Periode de non utilisation : Débranchez les adaptateurs de la prise murale pendant de longues
périodes de non-utilisation.
DÉCLARATION DE LA FCC
