LevelOne GNC-0111 User manual

2
Fiber Optic PCI
Express Card GNC-0111
Product Overview
The LevelOne GNC-0111 Fiber Gigabit Ethernet
Network Interface Card provides network connectivity
within high-speed Fiber-Optic networks. The high
bandwidth network interface card provides full-
duplex network data speeds of up to 2000Mbps
and support an array of advanced network interface
functionality.
High-Speed Network Interface
The GNC-0111 Gigabit Fiber PCI Express Card supports
PCI Express-bus architecture for servers that require a
high-bandwidth environment. The PCI Express is IEEE
802.3x compliant, providing full-duplex ow control
for 2Gbps network data transfer speeds over a 550
meter ber connection. It also requires less server
resources by providing on-board verication of IP
headers and TCP/UDP checksums for received data.
Advanced Networking
The Gigabit Fiber PCI-Express Card provides high-level
VLAN ltering and onboard screening of IEEE 802.3Q
VLAN tagged Ethernet frames for secured and exible
network. The GNC-0111 Gigabit Fiber PCI Card further
supports a 9K Jumbo Frame Rate, Pre-Boot Execution
Environment (PXE), Multi-Boot Agent (MBA), Remote
Program Load (RPL) and Bootstrap Protocol (BOOTP).
Key Features
- High-Speed Fiber-Optic PCI-Express card
- Supports 2Gbps Full-Duplex mode
- Compliant with IEEE 802.1Q VLAN
- Full-Duplex Switching: 550m
- Supports on-board IP header verication and TCP/
UDP checksum ooad
- Supports Multiple Operating Systems
GNC-0107
1000 BASE-SX Fiber Optic PCI
Card (SC)
Related Products
1. Full Duplex Indicator
2. LED (LINK/ Activity)
3. 1000SX SC-Type Fiber Port
H/W Version: 1
2
FNC-0115
100FX Multi-mode SC Fiber
Optic PCI Express Card
31

www.level1.com
I
one world_one brand_one level_ Network Adapters
3
Technical Specications
Product Diagram
Server
Physical Specications
Power Requirement
5W
3.3V DC, 1.5A
Operating Parameters
Temperature: 0°C to 50°C
Humidity: 5% to 90%
Dimensions
108mm (L) x 68.5mm (H)
Weight
60g
Certications
FCC Class B
CE Mark
RoHS
Software Support
Windows 98/ME/2000/NT4.0/2003/XP/Vista/7
Novel Netware 4.x, 5.x, 6.x
Linux
PXE & RPL Boot ROM
Network Interface
Standards Compliant
IEEE 802.3z Gigabit Ethernet 1000Base-SX
IEEE 802.3x Full-Duplex Flow Control
IEEE 802.1Q VLAN
Connector
850nm SC multi-mode
Fiber Optic Cable and Length
62.5/125μm, 50/125μm Multi-Mode up to 550m
Data Transfer Mode/Speed
Full duplex with NWay ow control
100Mbps speed
Bus Slot
PCI-e x1 bus (PCI-e Rev. 1.1 Interface)
Diagnostics LEDs
Link/Activity
Full-duplex Activity
GNC-0111
Server
GNC-0111
GSW-2494
Order Information GNC-0111: 1000SX Multi-mode SC Fiber Optic PCI Express Card
Package Contents GNC-0111
CD Manual
