LevelOne WCS-1090 User manual

Wireless Network Camera
WCS
-
1090
H/W ver: v1. x
one world_one brand_one level_
Wireless Day/Night IP Network Camera
Product Overview
The LevelOne WCS-1090 Day/Night Network Camera feature a high definition Sony
Progre ive CCD image en or capturing high quality live treaming video. The IP Camera
feature MPEG-4/MJPEG video compre ion, dual tream capability to multiple u er ,
day/night witching, audio capability for flexible deployment.
Wireless Camera with Day/Night Support
The WCS-1090 Day/Night Network Camera feature both Wirele and Day/Night upport.
The camera upport 11b/g wirele connectivity with tandard WEP, WPA/WPA2
encryption for ecured wirele connection . The auto day/night witching allow for
automatic camera adju tment to capture color image under normal light and black and
white image under low light condition . The high quality CCD en or enable u er to
enjoy high definition picture quality at full VGA quality at 30 frame per econd under
mo t light condition .
Multiple Video a d Bi-directio al Audio Compressio
With enhanced MPEG-4 and Motion-JPEG Video compre ion, u er can enjoy high-
quality image with minimum bandwidth. The WCS-1090 include G.726 audio
compre ion for ea y ynchronizing with live video tream .
Motio Detectio & E-mail Alerts
U er can etup 4 motion-detection region with the WCS-1090, each with adju table ize
and en itivity. When motion i detected at the pecified region , the y tem can end an
E-mail alert or end captured image via FTP upload to a de ignated torage erver.
Adva ced Features for Professio al Use
The LevelOne WCS-1090 include a range of advance feature for profe ional
urveillance u er . The e include a SYSLOG erver for remote log erver to log me age a
well a NTP (Network-Time-Protocol) Support for ynchronizing the camera’ internal clock
to an Internet Time-Server for a legitimate time- tamp on recorded video and picture .
Bu dled LevelO e IP CamSecure Lite
The WCS-1090 Wirele Day/Night Network Camera i bundled with the LevelOne IP
CamSecure Lite Surveillance Management Software package. It i an ea y to u e Web-
ba ed urveillance management tool that allow u er to monitor the camera locally over
the LAN or remotely over the Internet.
WCS-1090
Key Features
• Suitable for Home, Bu ine or Public Facilitie
• Feature a high-definition Sony progre ive CCD
en or for high-re olution image capturing
• Support MJPEG and MPEG-4 video
compre ion tandard
• Day/Night viewing with automatic IR filter
witching
• 4 Motion Detection Area with individual
en itivity et-up
• Wirele connectivity with WEP, WAP/WAP2
wirele ecurity upport
• Feature a bi-directional microphone for ea y
etup a an intercom with di play
• Dual live video treaming to multiple u er
• Support up to 30 frame per econd in full
VGA re olution
• Remote viewing over the Internet or via 3G*
Mobile phone * This feature depends on the local mobile
telecom system and the mobile phone model. LevelOne does
not guarantee that this feature will work in all countries.
• Feature Motion Detection and Event-
notification via E-mail
• Support UPnP for Ea y et-up and
in tallation and DDNS for dynamic IP
• Support Window XP/2000/VISTA
• Bundled with LevelOne IP CamSecure Lite
urveillance management oftware

Wireless Network Camera
WCS
-
1090
H/W ver: v1. x
one world_one brand_one level_
Technical Specification
Video Specificatio s
Image Se sor
• Sony ICX098BQ 1/4” CCD Sen or
Le s
• 6mm CS-Mount Type, Fixed Focu Len , F1.6
• 0.5 Lux minimum illumination
Compressio
• MPEG-4/M-JPEG Dual Stream
Resolutio Support
• 640x480, 320x240, 160x120 @ 30 fp NTSC
• 640x480, 320x240, 160x120 @ 25 fp PAL
IR Filter Switcher
• Motorized Switcher
• Manual trigger
• Scheduled
Image Co trol
• Auto-White-Balance
• Auto- Expo ure Control
• Auto Day/Night Switching
• Auto-Gain-Control
Video Optio s
• Time Stamp
• Text Overlay
• Motion detection
3GPP
• 160x120@15f ,
• MPEG-4 for mobile phone viewing
Audio Specificatio s
Compressio
• G.726, G.711
Micropho e/Speaker
• Built-in Microphone
• Microphone Input, 3.5mm Phone Jack
• Speaker Output*, 3.5 mm Phone Jack
* The audio out-port only supports G.7 6 compression
only
Hardware Specificatio s
Network I terface
• 1x 10/100 Ba eT (RJ45) port
• 2x antenna for 802.11b/g wirele connectivity
• WEP, WPA/WPA2 ecurity protocol
Network Protocols
• TCP/IP, DHCP, SMTP, NTP, HTTP, HTTPS, UPnP, FTP,
RTP, RTSP
I/O Ports
• Input Control x 2 (2 pin )
• Output Control x 2 (2 pin )
LED I dicators
• Ready, Activity, Device Off
Power Adapter
• 12V/1A DC External
Power Co sumptio
• Standard Power: 10W
E viro me tal Co ditio s
• Operating Temperature: 0°C ~ 40°C
• Operating Humidity: 10% ~ 80%
• Storage Temperature: -20°C to 70°C
• Storage Humidity: 10% ~ 90%
Dime sio s
• 80mm (W) x 50mm (H) x 132mm (D)
Alert
Motio Detectio
• 4 Detection Area with individual en itivity
E-Mail Alert
• 3 e-mail addre
FTP Uploadi g
• 2 FTP erver addre and login etting
I sta t Message
• 1 Jabber client and 1 HTTP notification for IM
notification
Software Specificatio s
• Bundled with LevelOne IP CamSecure Lite
• Camera Wizard Window -Ba ed for initial
In tallation
Browser Support
• Brow er Support Internet Explorer 6 and above
• ActiveX Support ActiveX 8.0 and above
Certificatio
FCC
CE

Wireless Network Camera
WCS
-
1090
H/W ver: v1. x
one world_one brand_one level_
Product Diagram
rder Information
WCS-1090 Wireless Day/Night IP Network Camera
Package Co te t
1. WCS-1090
2. Power Adapter
3. A te a
4. Le s
5. Camera Sta d
6. Alle Wre ch
7. CD Ma ual/ Utility
8. Quick i stallatio Guide
For more information, please contact your LevelOne representative, or visit www.level1.com
All technical specifications are subject to change without notice.
All mentioned brand names are registered trademarks and property of their owners
www.level1.com
