LevelOne FCS-4010 User manual

LevelOne
FCS-4010
Day/Night Speed Dome Pro Network Camera
User’s Manual
Ver 1.0.0 – 0811

TableofContents
OVERVIEW......................................................................................................4
Package contents ....................................................................................5
Physical description................................................................................6
INSTALLATION.............................................................................................10
Hardware installation.............................................................................10
Network deployment..............................................................................11
How to Use Installation Wizard.............................................................14
ACCESSING THE NETWORK CAMERA .....................................................30
Using RTSP players...............................................................................32
Using 3GPP-compatible mobile devices..............................................33
Using recording software......................................................................34
MAIN PAGE...................................................................................................35
CLIENT SETTINGS.......................................................................................39
CONFIGURATION.........................................................................................41
System....................................................................................................41
Security...................................................................................................43
HTTPS.....................................................................................................44
Network...................................................................................................46
DDNS.......................................................................................................53
Access list..............................................................................................54
Audio and video.....................................................................................55
Motion detection ....................................................................................61
Camera control.......................................................................................63
Application .............................................................................................65
Recording...............................................................................................72
System log..............................................................................................73
View parameters ....................................................................................74
Maintenance...........................................................................................75

JOYSTICK SETTINGS..................................................................................79
APPENDIX.....................................................................................................83
URL Commands of the Network Camera.............................................83
Technical Specifications.....................................................................109
Technology License Notice.................................................................110
GNU GENERAL PUBLIC LICENSE......................................................112

Overview
LevelOne FCS-4010, equipped with an 18x optical zoom lens, is a high
performance day/night speed dome network suitable for professional
surveillance applications. It is another significant addition to LevelOne’s
high-end network camera portfolio of progressive-series.
Adopting Sony 18x optical zoom lens plus progressive CCD sensor, this
network camera allows you not only to have close-up images with exceptional
detail from a long distance when enlarged but also get crystal-clear,
razor-sharp images of fast-moving objects without jagged edges. With
sophisticated pan/tilt mechanism, it provides fast, precise movement with
continuous 360-degree pan and 90-degree tilt.You can easily control the lens
position by a mouse or a joystick to track the object you are interested in and
have up to 128 presets for patrolling.
The day and night function makes this camera ideal for operating under
diverse lighting conditions. When light conditions turns poor, the IR cut filter
will be automatically removed to accept IR illumination.Meanwhile, the
camera switches itself automatically from color to black and white, assuring
optimal image quality at all times.
More advanced features including 3GPP mobile surveillance, two-way audio
by SIP protocol, and digital I/O for external sensor and alarm make LevelOne
FCS-4010 a full-featured speed dome. It is the best solution for various
enterprise projects such as airports, highways, parking lots, and shopping
malls, where high-level reliability and precision is always required.
Read before use
The use of surveillance devices may be prohibited by law in your country.The
Network Camera is not only a high-performance web-ready camera but also
can be part of a flexible surveillance system. It is the user’s responsibility to
ensure that the operation of such devices is legal before installing this unit for
its intended use.
It is important to first verify that all contents received are complete according
to the Package contents listed below.Take notice of the warnings in Quick
Installation Guide before the Network Camera is installed; then carefully read

and follow the instructions in the Installation chapter to avoid damages due to
faulty assembly and installation.This also ensures the product is used
properly as intended.
The Network Camera is a network device and its use should be
straightforward for those who have basic network knowledge.It is designed
for various applications including video sharing, general security/surveillance,
etc. The Configuration chapter suggests ways to best utilize the Network
Camera and ensure proper operations.For the creative and professional
developers, the URL Commands of the Network Camera section serves to be
a helpful reference to customize existing homepages or integrating with the
current web server.
Package contents
■FCS-4010
■Power adapter
■Wall mount bracket
■Dome cover
■Inner cover
■Silica gel
■Metal ring
■Screw kit
■Alignment sticker
■RJ45 female/female coupler
■CD manual/utility
■Quick installation guide

Physical description
Inner view
Outer view

General I/O Terminal Block
This Network Camera provides a general I/O terminal block which is used to
connect external input / output devices. The pin definitions are described
below.
GND: Ground
DI4: Digital Input
DI3: Digital Input
DI2: Digital Input
DI1: Digital Input
GND: Ground
N.O. : RELAY_NO
COM. : RELAY_COM
+12V : Power, 12V DC
Pin Name Specification Remarks
GND Ground
DI4 Digital Input OPEN/Short-to-GND, isolation 2KV Internal pull-up
DI3 Digital input OPEN/Short-to-GND, isolation 2kV Internal pull-up
DI2 Digital Input OPEN/Short-to-GND, isolation 2KV Internal pull-up
DI1 Digital Input OPEN/Short-to-GND, isolation 2KV Internal pull-up
GND Ground
N.O. Relay_NO Normal Open pin, Max 30VDC, 1A
COM. Relay_COM Common Pin , Max 30VDC, 1A
+12V Power +12V 12VDC ± 10%, max. 0.8A Max. rating 1.2A

DI/DO Diagram
Refer to the following illustration for connection method.
Status LED
The color of LED indicates the status of the Network Camera.

Hardware Reset
There is a reset button on the inner side of the Network Camera.It is used to
reboot the Network Camera or restore the Network Camera to factory default.
Sometimes rebooting the Network Camera could set the Network Camera
back to normal state.If the problems remain after rebooted, restore the
Network Camera to factory default and install again.
Reboot: Press and release the reset button with a needle.Wait for the
Network Camera to reboot.
Restore: Press the indented reset button continuously for over 30 seconds
until the status LED rapidly blinks red and green simultaneously.Note that all
settings will be restored to factory default.

Installation
Hardware installation
Follow the steps below to install the Network Camera to the ceiling:
1. Attach the alignment sticker to the wall.
2. Drill four pilot holes into the wall.
3. Attach the black cover to the Network Camera using the supplied four
black screws.
4. Stick the supplied two pieces of silica gel symmetrically to the inner side
of the dome cover. Then place the metal ring into the dome cover to fix the
silica gel.
5. Fix the dome cover to the Network Camera and secure it by rotating it
clockwise.
6. Loosen the three screws on the front opening of the wall mount bracket.
7. Place the O-ring on the front opening of the wall mount bracket.
8. Feed the cables through the front opening of the wall mount bracket and
pull them from wall outlet.
9. Attach the Network Camera to the wall mount bracket by tightening the
three screws on the front opening of the wall mount bracket.
10. Fasten the wall mount bracket to the wall.

Network deployment
Setup the Network Camera over the Internet
This section explains how to configure the Network Camera to Internet
connection.
1. If you have external devices such as sensors and alarms, make connection
from general I/O terminal block.
2. Use the supplied RJ45 female/female coupler to connect the Network
Camera to a switch. Use Catagory 5 Cross Cable when Network Camera is
directly connected to PC.
3. Connect the power cable from the Network Camera to a power outlet (AC
24V 2A).
There are several ways to setup the Network Camera over the Internet. The
first way is to setup the Network Camera behind a router. The second way is
to utilize a static IP. The third way is to use PPPoE.

Internet connection via a router
Before setting up the Network Camera over the Internet, make sure you have
a router and follow the steps below.
1. Connect your Network Camera behind a router, the Internet environment is
illustrated as below. About how to get your IP address, please refer to
Software installation section for details.
2. In this case, if the Local Area Network (LAN) IP address of your Network
Camera is 192.168.0.3, please forward the following ports for the Network
Camera on the router.
■HTTP port
■RTSP port
■RTP port for audio
■RTCP port for audio
■RTP port for video
■RTCP port for video

If you have changed the port numbers on the Network section, please open
the ports accordingly on your router.For information on how to forward ports
on the router, please refer to the user’s manual of your router.
3. Find out the public IP address of your router provided by your ISP (Internet
Service Provider). Use the public IP and the secondary HTTP port to access
the Network Camera from the Internet. Please refer to Network Type section
for details.
Internet connection with static IP
Choose this connection type if you are required to use a static IP for the
Network Camera and follow the steps below.
1. Set up the Network Camera in a LAN. Please refer to Software installation
section for details.
2. Go to Configuration > Network > Network Type. Select LAN > Use fixed IP
address.
3. Enter the static IP, Subnet mask, Default router, Primary DNS provided by
your ISP.

Internet connection via PPPoE (Point-to-Point over Ethernet)
Choose this connection type if you are connected to the Internet via a DSL
Line. Please refer to PPPoE section for details.
Software installation
At the end of the hardware installation, users can use Installation Wizard
program included in the product CDROM to find the location of the Network
Camera. There may be many Network Cameras in the local network. Users
can differentiate the Network Cameras with the MAC address. The MAC
address is printed on the label which is on the bottom of the Network
Camera body.
How to Use Installation Wizard
Installation
The following are steps for the software installation.
STEP 1: Put the Installation disk into the CD-ROM drive, and the installation
should start automatically. If the installation does not start, click on “Start” on
the lower left corner of your screen, open “My Computer” and double click
on the CD-ROM->Installation_Wizard.exe. The Installation Wizard
Installation Window will appear.
Installation Wizard Installation Window

STEP 2: Please read the license agreement first, and then click on “I Agree”
to continue the installation process. The install process will go on and then
the below window will appear. This page is for you to select the additional
component you want to install. The component “Create shortcut on desktop”
will create a shortcut on the desktop. It is more convenient for you to launch
Install Wizard 2. After selecting the components, please click on the “Next”
Button to continue.
Select components to install for the Installation Wizard
STEP 3: Select the installation directory for this application software and
click on “Install” button. You can also change the installation directory by
clicking on “Browse…” button. After the proper directory chose, please click
on the “Install” button to continue.
Destination Location for Installation
STEP 4: After clicking “Install” button, the install system will install the
Installation Wizard to your computer, and a progress bar will display on the

dialog. After completed the installation, please click on the “Close” button.
Completed
Using Installation Wizard
User Interface
Once you run the Installation Wizard, after a short searching time, you will
see the user interface as below. “Manual Setup” button, a “Refresh
Devices” button and an arrow button on the left panel of your user interface.
When you click on the arrow button, you will see more advanced functional
buttons: “Firmware Upgrade”,“Restore Default” and “About IW”. You
can select your device by double-clicking it in the device list. The left three
buttons (“Manual Setup”, “Firmware Upgrade”, and “Restore Default”)
won’t be enabled until you select at least one device.

User interface of Installation Wizard
Installation Wizard allows you to setup one device at one time and upgrade
multiple devices (of the same model) at the same time. If you selected
different models, then the “Firmware Upgrade” button would be disabled.

User interface of Installation Wizard after clicking on the arrow button

Action buttons
Refresh devices
Clicking on the “Refresh Devices” button will refresh the device list and
search all devices on the LAN again. Refreshing the device list will take
several seconds.
If you want to link to your device, double-clicking it on your device list will
lead you to the browser for operating your device.

Function buttons
Function buttons
Click on this button to modify the setting of the selected devices. For more
detail, please refer to 0 Manual Setup.
Click on this button to upgrade the firmware of the selected devices. For
more detail, please refer to 0 Upgrade
Click on this button to restore the selected device to factory default.
Click on this button to get version information of the Installation Wizard .
