Levenhuk 74246 User manual

Levenhuk MED 5M Microscope Digital Camera
with 9.4" LCD Screen
User manual

2
Never look at the sources of bright light or lasers through the camera or the microscope, as this may cause
permanent eye damage and even blindness.
General information
Levenhuk MED Digital Camera is a professional accessory for trinocular microscopes. Its 9.4" color LCD touch screen
and 5Mpx digital camera allow you to conduct high-precision research in real time, and save images and video for
further use.
DC-12V
2
4
1
3
5
6
7
8
DC-12V
2
4
1
3
5
6
7
8
Parts of digital camera:
1. Microphone
2. USB port
3. USB mouse port
4. Headphone jack
5. AC adapter socket
6. MicroSD (TF card) slot
7. MiniHDMI out
8. Power on/o
Caution! Remember that mains voltage in the U.S. and Canada is 110V and 220—240V in most
European countries. Please refer to the specications table for the correct mains voltage and never
attempt to plug a 110V device into 220V outlet and vice versa without using a converter.
!
Installing a digital camera
LCD screen digital camera is installed on the third vertical tube of trinocular microscopes. Assemble and set up
your microscope. Insert the digital camera into the camera connector, and then insert the camera connector into
the trinocular tube and x. Connect the supplied AC adapter to the camera and to the AC network. Press the power
button and the camera will be ready to work.
Embedded software
The embedded application is designed for using Android digital cameras with microscopes. With this application,
you can change image parameters, measure objects as well as save images and videos for further use. In addition,
you can perform particle analysis with its image processing feature. Like all Android applications, this application
features a user-friendly multilanguage interface.

3
Camera display interface
The screen is divided into two parts:
1. The left part is the Preview Image. It displays the current image provided by the camera.
2. The right part is the Tool Panel. It contains a number of tools for image capturing, changing parameters,
measuring, etc. Use the right side of the screen to perform the following actions:
• Eect: Settings of the camera parameters
• Measure: Measuring tool
• Playback: Images and video playback
• Snap: Image capturing
• Record: Video recording
• Setting: Setting and changing parameters
Capturing and playback tools
Press the Snap button to take a photo. Select the image size in the Settings section.
Press the Record button to start video recording. To stop recording, press the same button
once again.
If the original size of the video is smaller than 1080p, then the size of the recorded video will
be the same as the original. If the original size is bigger than 1080p, the recorded video size
will be reduced to a size smaller than 1080p.
Press the Playback button to open the last image captured or to play the last video recorded.
The image will be opened in the Image Analysis window.

4
Camera settings
Measurements
The Eect panel allows you to edit the captured image, if necessary.
Exposure
Auto Exposure: If you enable the checkbox next to “Auto Exposure”, the
brightness of the image will be automatically adjusted.
Manual mode: You can set the exposure time and gain.
Color temperature (White balance)
Auto mode: If you enable the checkbox next to “Auto WB”, the white balance
will be automatically set.
Manual mode: For manual settings, use the “Color temperature” slider tool.
Brightness: Use the slider tool to adjust the brightness.
Contrast: Use the slider tool to adjust the contrast.
Saturation: Use the slider tool to adjust the saturation.
Sharpness: Use the slider tool to adjust the sharpness.
Gamma: Use the slider tool for the gamma correction.
Flip image: These icons are used to ip the image vertically or
horizontally.
This icon is for saving the settings or resetting all of the settings to the
default parameters. You can save up to four dierent parameter sets
as well as return to the factory settings.
On the Measure panel, you can select a tool to conduct a measurement.
Before you start, you need to calibrate the ruler. You also need to calibrate it
after changing the microscope objective and/or camera resolution.
1. Calibrations
Go to the Measure panel, and press Add button to start a new calibration
process. Press Edit button to make changes in previous calibrations.

5
Open calibration menu:
Follow the instructions:
Adjust the ruler to where its ends are on the physical ruler’s scales. The ruler on the screenshot has 0.01mm scales,
with each big grid equaling 10µm, and the whole ruler equals 1,000µm.
Enter the name for the calibration and actual length of the ruler. In the example, the name of the calibration is
“4x”, which corresponds to the magnication value of the chosen eyepiece, and “1000µm” is the actual length of
the chosen ruler.
Press Calculate to get the calibration value for the current eyepiece and image size. Press Add to save the
calibration.

6
2. Measure tool
You can use a wide range of measure tools (rulers).
Icon Measure tool Action
Point counting Set the starting point of measuring on the photo
Line Measure the distance between two points
Rectangle Measure the width, length, and area of the rectangle
Circle Measure the area of a circle
Cross Measure the cross hair
Angle Measure the angle
Two circles Measure the distance between the centers of two circles
Perpendicular Measure the length of a perpendicular line
Concentric circles Measure the radius of two concentric circles
Text annotation Add a comment to an image
Option Change the width or the color of the ruler’s scale, and the
size or the color of the text
Export Export the image with measure marking
Delete Delete the chosen ruler
Delete Delete all
3. Use of the measuring ruler
Choose a calibration (the chosen option will be displayed as a black print on the white background).

7
Choose a ruler from the side menu, and it will appear in the image.
Use the measuring ruler to measure the physical ruler.
In this example, 6 large grids were measured: the measuring ruler shows 597.472µm, which conrms the
correctness of the measurements.

8
Image analysis
The images are analyzed with the Android application YWImage, which uses OpenCV (Open Source Computer Vision
Library). The application version 1.0 supports such functions as gray scale, contrast, binarization, and particle
analysis.
To enable this feature, select the Enable built-in image viewer option in the settings dialog box.
Let us consider an example of particle analysis.
Image uploading. Click the camera icon in the upper right corner of the screen. You can select an existing image or
take a picture with the camera.

9
Convert a color photo to Grayscale mode. Choose Grayscale from the left menu and press Apply to conrm
converting.
Contrast and brightness adjustment.Adjust the contrast and brightness of the black and white image, increasing
the dierence between objects and the background.

10
Particle analysis. After executing the binarization, open the particle analysis tool.
First of all, if some noises were not deleted during binarization, you need to specify a particle size range. The
designation of the particle size range will make the result more accurate.
Binarization. Using the binarization function, you can convert a color image or an image in grayscale to two-color
(black and white) by setting the minimum and maximum thresholds with which the brightness of each pixel will be
compared.
All pixels within the threshold range will be highlighted in red. After executing the binarization, the RGB-value of
the red areas will be set to (0, 0, 0), the RGB-value of the other sections will be (255, 255, 255).
Note: Red areas should not overlap.

11
Press the button , to set the maximum value to innity. Select the Show Outlines check box to show the
boundaries and number of particles after the analysis. Click Analyze Particles to begin the analysis. The result will
be shown below.
Click the CSV button to export the data to the report le, which will be saved here by default:
/mnt/sdcard/Image/Reports.

12
LCD display 9.4" color touch screen
Megapixels 5
Maximum resolution (for still images) 2048x1536px
Sensor 1/2.5"
Pixel size 2.2x2.2µm
Frame rate 15 frames per second
Exposure control auto/manual
Video recording +
Image format *.jpg
Video format 1080p, *.3gp
White balance auto/manual
Output USB 2.0 (2pcs.), miniHDMI, Wi-Fi, TF card slot
Power supply 12V / 2A; via AC adapter
Software features measuring, brightness, exposure time, particle analysis, etc.
Mounting location third eyepiece tube of a diameter of 23.2mm; via camera connector
OS Android 5.1 (multilingual)
Embedded memory 4GB
Ability to connect additional equipment
(not included in the kit)
support of microSD cards with capacity up to 32GB;
monitor/TV (with a HDMI port);
ash disk, mouse, keyboard (with a USB port); headphones (3.5mm)
The kit includes digital camera with LCD screen, AC adapter
Specications:
Supplied with Levenhuk MED microscopes:
73987 Levenhuk MED D10T LCD, 73991 Levenhuk MED D20T LCD, 73995 Levenhuk MED D25T LCD, 73999 Levenhuk MED D30T LCD,
74003 Levenhuk MED D35T LCD, 74007 Levenhuk MED D40T LCD, 74011 Levenhuk MED D45T LCD.
Levenhuk reserves the right to modify or discontinue any product without prior notice.
Care and maintenance
• Never look at the sources of bright light or lasers through the camera or the microscope: it will cause PERMANENT
DAMAGE TO YOUR EYES!
• Do not disassemble the camera on your own.
• Keep the camera away from moisture; do not use it in rainy weather.
• Keep the camera away from shock or excessive pressure.
• Do not overtighten the locking screws.
• Keep the camera away from hazardous environment, home and car heaters, incandescent lamps or open re.
• When cleaning the lenses, rst blow any dust or debris o the surface or wipe them o with a soft brush. Then wipe the
lens with a soft cleaning cloth slightly damp with spirits or ether.
• Seek medical advice immediately if a small part or a battery is swallowed.
