Leviton Touch Screen User manual

User Manual
43BTouch Screen
Document Release March 2012

Leviton Touch Screen
Warranty
Leviton Manufacturing Co Inc. warrants this control touch screen to be free of material and workmanship
defects for a period of two years after system acceptance or 26 months after shipment, whichever comes
first. This Warranty is limited to repair or replacement of defective equipment returned Freight Pre-Paid
to Leviton Lighting & Energy Solutions Division at PO Box 2210, Tualatin, Oregon 97062, USA. User shall
call 1-800-959-6004 and request a return authorization number to mark on the outside of the returning
carton, to assure that the returned material will be properly received at Leviton. All equipment shipped
back to Leviton must be carefully and properly packaged to avoid shipping damage. Replacements or
repaired equipment will be returned to sender freight prepaid, F.O.B factory. Leviton is not responsible
for removing or replacing equipment on the job site, and will not honor charges for such work. Leviton
will not be responsible for any loss of use time or subsequent damages should any of the equipment fail
during the warranty period, but agrees only to repair or replace defective equipment returned to its plant
in Tualatin, Oregon. This warranty is void on any product that has been improperly installed, overloaded,
short circuited, abused, or altered in any manner. Neither the seller nor Leviton shall be liable for any
injury, loss or damage, direct or consequential arising out of the use of or inability to use the equipment.
This warranty does not cover lamps, ballasts, and other equipment which is supplied or warranted
directly to the user by their manufacturer. Leviton makes no warranty as to the Fitness for Purpose or
other implied Warranties.
Notice
Although the information contained within this user guide is believed to be accurate at the time of
printing, it is not guaranteed to be without fault and is subject to change without notice. Future software
releases may change the features or operation of this product. For current information contact:
Leviton Lighting & Energy Solutions Division
20497 SW Teton, Tualatin, OR 97062
Mailing Address:
PO Box 2210
Tualatin, OR 97062
Customer Service: [phone]
Technical Support: [phone]
Fax: [phone]
Email: [e-mail]
Internet: www.leviton.com
Copyright © 2012
Leviton Manufacturing Company Incorporated.
All Rights Reserved.

User Manual
Contents
User Manual...................................................................................................................................1
1. Introduction ...............................................................................................................................1
1.1. Features....................................................................................................................................... 1
1.2. Specifications............................................................................................................................... 1
1.3. Port Introduction......................................................................................................................... 2
1.4. Dimensions.................................................................................................................................. 3
2. Installation .................................................................................................................................5
2.1. System Diagram.......................................................................................................................... 5
2.2. Hardware Installation................................................................................................................. 7
3. Programmable Software .............................................................................................................7
3.1. Features....................................................................................................................................... 7
3.2. Software Installation.................................................................................................................. 8
3.3. Device Driver Installation.......................................................................................................... 9
4. Programmable Software Introduction .......................................................................................11
4.1. Connection between Device and Programmable Software................................................ 11
4.2. Menu Introduction.................................................................................................................... 12
4.3. Interface Introduction.............................................................................................................. 17
4.4. Component (Button, Label, Bar, Picture, Clock, Value) Setting ........................................ 18
4.4.1. Button Setting................................................................................................................... 20
4.4.1.1. Add Button................................................................................................................. 20
4.4.1.2. Button Property......................................................................................................... 21
4.4.1.1. Copy Button............................................................................................................... 30
4.4.2. Label Setting...................................................................................................................... 33
4.4.2.1. Add Label................................................................................................................... 33
4.4.2.2. Label Property........................................................................................................... 34
4.4.3. Bar Setting......................................................................................................................... 36
4.4.3.1. Add Bar....................................................................................................................... 36
4.4.3.2. Bar Property............................................................................................................... 37
4.4.4. Clock Setting...................................................................................................................... 37
4.4.4.1. Add Clock................................................................................................................... 37

Leviton Touch Screen
4.4.5. Picture Setting................................................................................................................... 38
4.4.5.1. Add Picture ................................................................................................................ 38
4.4.5.2. Picture Property ........................................................................................................39
4.4.6. Value Setting..................................................................................................................... 41
4.4.6.1. Add Value................................................................................................................... 41
4.4.6.2. Value Property........................................................................................................... 42
4.5. Album Setting............................................................................................................................ 43
4.6. Button, Picture’s IR Remote Control...................................................................................... 45
4.7. Page Setting.............................................................................................................................. 47
4.8. Built-in Function (Special Page) Setting................................................................................ 50
4.9. Button’s Advanced Setting ......................................................................................................55
4.10. Scene Setting ........................................................................................................................ 59
4.10.1. Scene Editing................................................................................................................. 59
4.10.2. Scene Recall .................................................................................................................. 67
4.11. Schedule Setting................................................................................................................... 68
4.12. Component Configuration.................................................................................................... 71
4.13. File Download........................................................................................................................ 76

User Manual
1
Rev. B
1. Introduction
Leviton’s DMX Touch Screen offers a fully flexible user interface to Leviton’s control systems.
Implementing touch screen style controls allow for a multi-page user experience specifically tailored to
your application. This product is manufactured for Leviton by Liteputer and as such you may find
references to either throughout the product documentation.
1.1. 0BFeatures
Software for designing the customized touch screen interface.
USB port or Ethernet connection, data download and remote monitoring.
Built-in functions include backlight setting, sound setting, clock setting, digital photo
frame, and password protection.
Built-in loudspeaker.
IR remote controller.
2W power consumption.
DC 12V external power.
1.2. 1BSpecifications
Power Supply
DC: 12V
Signal Output –EDX
EDX-485 (reference application diagrams for allowed cable
types and wiring methods.
Signal Output –DMX
DMX512/1990 (reference application diagrams for allowed
cable types and wiring methods.
Signal Connector
4 PIN green terminal
Connection Port
USB/Ethernet
RAM Memory
256MB
Screen Size
5.7 inch
Screen Resolution
320*240 pixels
Color
262K Colors
Screen
4-wire resistive touch panel
Size
8.47(W) x 5.51(H) x 1.54(D) inch
215(W) x 140(H) x 39 (D) mm

Leviton Touch Screen
1.3. 2BPort Introduction
1
USB Port
2
Ethernet Port
3
EDX Port –Used for communication between touch screens
3a
Common
3b
Data -
3c
Data +
3d
+12Vdc
4
DMX Port –Used for output to dimmers
4a
Common
4b
Data -
4c
Data +
4d
+12DC

User Manual
3
Rev. B
1.4. 3BDimensions
Back Side
Installation
back box
included

Leviton Touch Screen
Front Side
Wall box

User Manual
5
Rev. B
2. Installation
2.1. 4BSystem Diagram
The diagram below shows you one typical installation
System Example #1
This system shows multiple touch screens interconnect via EDX which is useful when you need presets to
be linked between controllers. As always, final output is via DMX to the load control devices.

Leviton Touch Screen
System Example #2
Shown is a basic system where DMX passes through a controller. Be wary however of this style of
system as if the console is turned off, the touch-screen will not work. A better application would be the
DMX outputs from the touch screen + console being merged at the NPC or other DMX merger.
System Example #3
This shows a basic system where the touch screen is the only controller.

User Manual
7
Rev. B
2.2. 5BHardware Installation
1. Rough In Back box
2. Terminate data wires (reference project application drawings)
3. Terminate power wires (reference project application drawings)
4. Apply power to touch-screen
5. Configure touch-screen from PC
3. Programmable Software
3.1. 6BFeatures
Page
The components in a page include button, label, bar, picture, clock and value. The style and
function of these buttons can be configured with the software.
The configurations can be transmitted from PC to the device by USB/Ethernet.
The button component can include a photo (there are photo icons available in the software). The
picture component can add a photo that the user selects and has text, shape and style options to
choose from.
Timer
50 timers.

Leviton Touch Screen
Built-in Functions
Clock setting (can be synchronized with PC).
3 Backlight settings (normal, turn off in 5 minutes, and turn off in 20 minutes).
Voice setting (turn on/off screen tap sound).
Schedule setting/Preview function.
Password protection.
The above functions can be linked to the buttons on the page.
3.2. 7BSoftware Installation
Step-1 Copy the ECP-T04/TS005-DI5 installation program from the CD to desktop as shown
below
Step-2 Double Click the icon
Select the default language from the list.
Step-3 After language selection press Next,
Press Next again

User Manual
9
Rev. B
Step-4 The license agreement will display, after reading, press Yes.
Continue to press Next and the software will finish installing.
Once installed a shortcut will appear on your desktop as shown below
3.3. 8BDevice Driver Installation
After the software has been installed, the next step is to install the device driver.
Step-1 After installing the software, copy the driver folder in C:\Program Files\Touch
Screen\ECP-T04\Driver\ to the desktop
Step-2 Connect the device to your PC using a USB cable. The below dialogue box should appear

Leviton Touch Screen
Select “no, not this time”
Press Next
Select the driver folder on the desktop
Step-3 Press Next again
Step-4 Press finish and the driver is now installed

User Manual
11
Rev. B
4. Programmable Software Introduction
4.1. 9BConnection between Device and Programmable Software
When the user opens the software the screen should look like figure 1.
Figure 1: Device is not connected
Once the device is connected the screen should look like figure 2.
Figure 2: Device is connected
The device can be connected by USB or Ethernet, select from drop down list as shown below
22B

Leviton Touch Screen
4.2. 10BMenu Introduction
File menu is used to create, open and save a file
Component menu adds a button, a label, a value, a clock, a picture and a bar
Format menu modifies the components’ position, size and spacing
New Project
Create a new project
Open
Open a file
Save
Save a file
Save As
Save As file
Exit
Exit the program
Button
Add a button
Label
Add a label
Value
Add a value
Clock
Add a clock
Add a picture
Bar
Add a bar

User Manual
13
Rev. B
Align submenu options
Make same size submenu options
Horizontal spacing submenu options
Lefts
Align Left
Centers
Align Center
Rights
Align Right
Tops
Align Top
Middles
Align Middle
Bottoms
Align Bottom
Width
Make same width
Height
Make same height
Both
Make same width and height
Make Equal
Make horizontal spacing equal

Leviton Touch Screen
Vertical spacing submenu options
Download menu –download data from the software to the device
Device-Set Setting Includes: IP setting, device description, password setting and MAC address setting
Make Equal
Make vertical spacing equal
All Page
Download all pages
Now Page
Download current page
Now Time
Download the current time

User Manual
15
Rev. B
Language Menu allows the user to select the preferred language. Three languages are available; English,
simplified Chinese and traditional Chinese
Help Menu

Leviton Touch Screen
A software introduction can be found in the Help Menu.
Contacting Technical Support
If you cannot find answers in this User Manual, please contact Technical Support and we will be glad to
answer your questions.
You can also call us during regular business hours at 1-800-959-6004. Please have the model number
information available when you call.
Contact Information:
Leviton Lighting & Energy Solutions
20497 SW Teton, Tualatin, OR 97062
Mailing Address:
PO BOX 2210
Tualatin, OR 97062
Customer Service: [phone]
Technical Support: [phone]
Fax: [phone]
Email: [e-mail]
Internet: www.leviton.com
