Levoit LV-H134 User manual

Tower Pro True HEPA Air Purifier
Model: LV-H134 Series
USER MANUAL
Questions or Concerns?
Please contact us Mon–Fri, 9:00 am–5:00 pm PST/PDT
at [email protected] or at [phone].

2
2
2
3
4
6
7
9
11
12
14
16
17
Table of Contents Package Contents
Specifications
1 x Air Purifier
1 x True HEPA Combination Filter
(Pre-Installed)
1 x Power Cord
1 x User Manual
Power Supply AC 120V, 60Hz
Rated Power 45W
Ideal Room
Size
710 ft² / 66 m²
Note: Eective for
larger rooms, but
purification will take
longer.
Operating
Conditions
Temperature:
14°–104°F / -10°–40°C
Humidity: ≤ 85% RH
Noise Level 23–57dB
CADR (Clean
Air Delivery
Rate)
312 CFM / 530 m³/h
Standby Power < 0.8W
Dimensions 12.8 x 12.8 x 29.2 in /
32.6 x 32.6 x 74.2 cm
Weight 18.6 lb / 8.44 kg
Package Contents
Specifications
Safety Information
Getting to Know Your Air Purifier
Controls
Getting Started
Using Your Air Purifier
About the FIlter
Care & Maintenance
Troubleshooting
Warranty Information
Customer Support

3
SAFETY INFORMATION
• Only use your air purifier as
described in this manual.
• Do not use your air purifier
outdoors.
• Keep your air purifier away from
water, and wet or damp areas.
Never place in water or other
liquids.
• Keep your air purifier away from
heat sources.
• Do not use where combustible
gases or vapors, metallic dust,
aerosol (spray) products, or fumes
from industrial oil are present.
• Keep 5 ft / 1.5 m away from where
oxygen is being administered.
• Supervise children when they are
near the air purifier.
• Do not place anything into any
opening on the air purifier.
• Do not sit or place heavy objects
on the air purifier.
• Keep the inside of the air purifier
dry. To prevent moisture buildup,
avoid placing in rooms with major
temperature changes.
• Always unplug your air purifier
before servicing (for example,
changing the filter).
• Do not use your air purifier if it is
damaged or not working correctly,
or if the cord or plug is damaged.
To reduce the risk of fire, electric shock, or other injury, follow all instructions and
safety guidelines.
General Safety
• Keep the air purifier near the outlet
it is plugged into.
• Never place the cord near any heat
source.
• Do not cover the cord with a rug,
carpet, or other covering. Do not
place the cord under furniture or
appliances.
• Keep the cord out of areas where
people walk often. Place the cord
where it will not be tripped over.
• Your air purifier has a polarized
plug (one prong is wider than the
other), which fits into a polarized
outlet only one way. This is a
safety feature to reduce the risk of
electric shock. If the plug does not
fit, reverse the plug. If it still does
not fit, do not use the plug in that
outlet. Do not bypass this safety
feature.
Plug & Cord
READ AND SAVE THESE
INSTRUCTIONS
Do not try to repair it yourself.
Contact Customer Support (see
page 17).
• WARNING: To reduce the risk of
fire or electric shock, do not use
this air purifier with solid-state
speed controls (such as a dimmer
switch).
• Not for commercial use.
Household use only.

4
GETTING TO KNOW YOUR AIR PURIFIER
F. Dust Sensor
G. Filter
H. Power Cord Port
I. Filter Cover
A. LED Display / Control Panel
B. Air Outlet
C. Housing
D. Power Cord
E. Air Intake
(triangles at the bottom)
Front Back
A
C
D
B
F
G H
I
E

5
A. Fan Speed Button
B. Auto Mode Button
C. Sleep Mode Button
D. PM2.5 Value (µg/m³)
E. Display O Button
F. Check Filter Indicator
A G
I
B F
C
D
E
K
LED Display
GETTING TO KNOW YOUR AIR PURIFIER (CONT.)
G. Timer Button
H. Air Quality Indicator
I. On/O Button
J. Timer Display
K. Fan Speed Indicator
J H

6
CONTROLS
On/O Button
Turns the air purifier on/o.
Fan Speed Button
Cycles through fan speeds:
low, medium, and high.
Auto Mode Button
Turns Auto Mode on/o
(see page 9).
Sleep Mode Button
Turns Sleep Mode on/o
(see page 9).
Display O Button
• Turns the display o.
• Press any button
(except ) to turn the
display back on.
Fan Speed Indicator Chart
Fan Speed Fan Speed
Indicator
Low
Medium
High
Check Filter Indicator
Lights up red to remind you to
check the filter (see page 12).
Timer Button
Sets the timer (see page 10).

7
Figure 1.1
Figure 1.4
Figure 1.3
Figure 1.2
3. Replace the filter cover by lining up the
cover’s feet with the matching slots on
the bottom of the housing. [Figure 1.3]
4. Push the cover securely closed.
[Figure 1.4]
5. Remove the “ATTENTION” notice that
covers the display on top of the air
purifier.
GETTING STARTED
1. Remove the filter cover. Pull the filter
from the housing. [Figure 1.1]
2. Take the filter out of its plastic
packaging, then reinstall it into the
housing. Make sure the handle on the
filter is facing out. [Figure 1.2]

8
6. Attach the power cord to the port
underneath the filter cover at the bottom
of the air purifier. [Figure 1.5]
Note: If you are not planning to use
the air purifier for a long period of time,
keep the filter clean by leaving it inside
its plastic packaging until it is ready to
be used.
Figure 1.5
GETTING STARTED (CONT.)

9
Auto Mode adjusts the fan speed
automatically based on air quality. For
example, if the air quality is bad, the fan will
be set to high speed.
• Tap to turn Auto Mode on/o.
• Tapping or will also exit Auto
Mode.
This indicator uses an automatic sensor to
display the air quality.
Auto Mode
Air Quality Indicator
Sleep Mode uses the lowest possible fan
speed to operate quietly.
• Tap to turn Sleep Mode on/o.
• Tapping or will also exit Sleep
Mode.
Sleep Mode
Air Quality Indicator Chart
Indicator
Color Air Quality Fan Speed
Blue Very Good Sleep Mode
Green Good Low
Orange Moderate Medium
Red Bad High
USING YOUR AIR PURIFIER
1. Place the air purifier on a level surface.
Leave 15 in / 38 cm of clearance on all
sides of the air purifier. [Figure 2.1]
2. Plug in. Tap to turn on the air
purifier. The fan will start automatically.
3. Optionally, tap to change the fan
speed. You can also select Auto Mode
or Sleep Mode, or set a timer.
a. For best results, or to address a
specific air quality issue such as
smoke, run the air purifier at high
speed for 15–20 minutes before
using a lower speed or Auto Mode.
b. To eectively clean air, keep
windows and doors closed while the
air purifier is on.
4. Tap to turn o the air purifier.
General Operation
Figure 2.1
15 in / 38 cm

10
USING YOUR AIR PURIFIER (CONT.)
The air purifier will remember its
programmed settings when turned o,
and will resume these settings when it is
turned back on. The air purifier must remain
plugged in for the memory function to work.
Memory Function
The PM2.5 value on the display shows the
amount of particles (µg) that are detected
within 1 cubic meter (m³).
PM2.5 refers to particulate matter (PM) that
is less than or equal to 2.5 micrometers
(µm) in diameter. These particles, also
known as “fine particles”, are so small that
they can only be detected with an electron
microscope, and stay in the air longer than
heavier air particles such as dust and mold.
Your air purifier is equipped with a laser dust
sensor that detects the amount of PM2.5
particles that are in a given space (µg/m³).
Generally, the lower the number, the better
your air quality. A number above 135 indicates
that there is an unhealthy amount of fine
particles in the air.
You can set a timer between 1– 12 hours.
1. Tap repeatedly (or press and
hold ) to set a time.
2. Once you choose a time, the timer will
flash 5 times and start counting down.
3. The air purifier will automatically turn o
once the timer is finished.
4. To cancel a timer, tap repeatedly
until the timer reads “- - - -”. The timer
will flash 5 times to confirm cancellation.
PM2.5 Value & Air Quality
Timer
Note:
• You can change the fan speed at
any time while the timer is counting
down. The timer will work with any
mode.
• Pressing or unplugging the air
purifier will cancel the timer.
Note: The air purifier will not
remember timers.

11
ABOUT THE FILTER
The True HEPA Combination Filter uses a 3-stage filtration system to purify air.
A. Nylon Pre-Filter
• Captures large particles such as
dust, lint, fibers, hair, and pet fur.
• Maximizes the life of the True
HEPA Filter by protecting it.
B. H13 True HEPA Filter
• Removes at least 99.97%
of airborne particles 0.3
micrometers (µm) in diameter.
• Filters small particles such as
fine dust, smoke particles, and
allergens such as pollen and pet
dander.
C. High-Eciency Activated Carbon Filter
• Physically adsorbs smoke, odors,
and fumes.
• Filters compounds such as
formaldehyde, benzene,
ammonia, hydrogen sulfide, and
volatile organic compounds
(VOCs).
Note: Levoit air purifiers filter airborne
particles 0.3 microns in size. Arovast
Corporation makes no claims that this air
purifier helps reduce the COVID-19 virus.

12
CARE & MAINTENANCE
Cleaning the Air Purifier
Resetting the Check Filter
Indicator
Check Filter Indicator
1. Wipe the outside of the air purifier with
a dry cloth. Do not clean with water or
any other liquid to avoid risk of electric
shock.
2. Clean the outside of the filter with a
brush or vacuum hose each month
to prevent buildup of hair or dust. Do
not clean the filter with water or other
liquids.
Reset the Check Filter Indicator when:
• lights up.
1. Replace the filter (see page 13).
2. Turn on the air purifier.
3. Press and hold for 3 seconds.
4. The light will turn o after the filter
indicator is successfully reset.
• The filter was changed before lit up.
1. Press and hold for 3 seconds
until lights up.
2. Press and hold again for 3
seconds.
3. The light will turn o after the filter
indicator is successfully reset.
will light up as a reminder to check the
filter. The indicator is automatic. You may
not need to change your filter yet, but you
should check it when lights up.
Storage
If not using the air purifier for an extended
period of time, wrap the filter in plastic
packaging and store in a dry place to avoid
moisture damage.
When Should I Replace the
Filter?
The filter should be replaced every 6–8
months. You may need to replace your filter
earlier or later depending on how often you
use your air purifier. Using your air purifier in
an environment with relatively high pollution
may mean you will need to change the filter
more often (even if the is o).
You may need to replace your filter if you
notice:
• Increased noise when the air
purifier is on
• Decreased airflow
• Unusual odors
• A visibly clogged filter
Note: To maintain the performance of
your air purifier, only use ocial Levoit
filters. To buy replacement filters, visit
Levoit’s online store. Go to levoit.com
for more information.

13
CARE & MAINTENANCE (CONT.)
Replacing the Filter
1. Unplug the air purifier and remove the
filter cover. [Figure 3.1]
2. Remove the old filter. [Figure 3.2]
3. Clean any dust or dirt from inside the
housing. [Figure 3.3]
4. Unwrap the new filter and place it into
the housing. Make sure the filter handle
is facing out. [Figure 3.4]
5. Replace the filter cover onto the
housing. [Figure 3.5]
6. Plug in and turn on the air purifier. Press
and hold for 3 seconds to reset it.
Figure 3.1
Figure 3.2
Figure 3.3
Figure 3.4
Figure 3.5

14
TROUBLESHOOTING
Problem Possible Solution
Air purifier will not turn on or
respond to button controls.
Plug in the air purifier.
Check to see if the power cord is damaged. If it is, stop
using the air purifier and contact Customer Support (see
page 17).
Plug the air purifier into a dierent outlet.
Air purifier may be malfunctioning. Contact Customer
Support (see page 17).
Air purifier makes an unusual
noise when the fan is on.
Make sure the filter is properly in place with plastic
packaging removed (see page 7).
Replace the filter (see page 13).
Air purifier may be damaged, or a foreign object may be
inside. Stop using the air purifier and contact Customer
Support (see page 17). Do not try to repair the air
purifier.
Airflow is significantly
reduced.
Make sure the filter’s plastic packaging is removed.
Tap to increase the fan speed.
Leave at least 15 in / 38 cm of clearance on all sides of the
air purifier.
Replace the filter (see page 13).
Poor air purification quality. Tap to increase the fan speed.
Make sure no objects are blocking the top or sides of the
air purifier for proper airflow.
Close doors and windows while running the air purifier.
Make sure the filter is removed from its plastic packaging
and properly in place (see page 7).
If the room is larger than 710 ft² / 66 m², air purification
will take longer. The air purifier may not be as eective in
significantly larger rooms.
Replace the filter (see page 13).

15
If your problem is not listed, please contact Customer Support (see page 17).
TROUBLESHOOTING (CONT.)
Problem Possible Solution
The air purifier is producing
an unpleasant odor.
Replace the filter (see page 13).
Make sure that the air purifier is in a room where the
relative humidity is less than 85% RH. Higher humidity
levels may cause mildew to grow on the filter.
is still illuminated after
replacing the filter. Reset (see page 12).
has not turned on within
8 months.
is a reminder for you to check the filter and will light
up based on how much the air purifier has been used
(see page 12). If you don’t use your air purifier often,
will take longer to turn on.
turned on before 6
months.
is a reminder for you to check the filter and will light
up based on how much the air purifier has been used
(see page 12). If you run your air purifier frequently,
will turn on sooner.
