Levoit LV-PUR131 User manual

True HEPA Air Purifier
Model: LV-PUR131
Questions or Concerns?
[email protected]
USER MANUAL

2
Thank you for purchasing the
LVPUR131 TRUE
HEPA AIR PURIFIER
BY LEVOIT.
If you have any questions or concerns, please
reach out to us at [email protected].
We hope you enjoy your new air purifier!
Share the Levoit Love
Find @LevoitUK on social media for wellness
+ style inspiration. We make every space
mindful and chic.

3
Table of Contents
Package Contents
Specifications
Safety Information
Getting to Know Your Air Purifier
Controls
Getting Started
Using Your Purifier
About the Filters
Keeping Things Clean
Troubleshooting
Warranty Information
Customer Support
3
3
4
5
6
7
8
9
10
13
15
15
Package Contents
1 x Air Purifier
1 x Activated Carbon Filter (Pre-Installed)
1 x Preliminary/True HEPA Combination Filter
(Pre-Installed)
1 x User Manual
Specifications
Power Supply AC 220V–240V,
50/60Hz
Rated Power 40W
Eective Range ≤ 48 m² / 516 ft²
Operating
Conditions
-10°–40°C / 14°–104°F
Noise Level 23–52dB
Clean Air
Delivery Rate
(CADR)
230 m³/h / 135 CFM
Standby Power < 0.8W
Dimensions 37.1 x 18.3 x 47 cm /
14.6 x 7.2 x 18.5 in
Weight 5.21 kg / 11.49 lb

4
SAFETY INFORMATION
• Only use your air purifier as described
in this manual.
• Do not use your air purifier outdoors.
• Keep your air purifier away from water,
and wet or damp areas. Never place in
water or liquid.
• Keep your air purifier away from heat
sources.
• Do not use where combustible gases,
vapours, metallic dust, aerosol (spray)
products, or fumes from industrial oil are
present.
• Keep 1.5 m / 5 ft away from where
oxygen is being administered.
• Supervise children when they are near
the air purifier.
• Do not place anything into any opening
on the air purifier, unless directed by the
manual.
• Do not sit or place heavy objects on the
air purifier.
• Keep the inside of the air purifier dry.
To prevent moisture buildup, avoid
placing in rooms with major temperature
changes or underneath air conditioners.
• Always unplug your air purifier before
servicing (such as when changing
filters).
To reduce the risk of fire, electric shock, or other injury, follow all instructions and
safety guidelines.
General Safety
READ AND SAVE THESE
INSTRUCTIONS
• Keep air purifier near the outlet it is
plugged into.
• Never place the cord near any heat
source.
• Do not cover the cord with a rug,
carpet, or other covering. Do not place
the cord under furniture or appliances.
• Keep the cord out of areas where
people walk often. Place the cord
where it will not be tripped over.
Power and Cord
• Do not use your air purifier if it is
damaged or not working correctly, or if
the cord or plug is damaged. Do not try
to repair it yourself. Contact Customer
Support (see page 15).
• WARNING: Do not use this air purifier
with solid-state speed controls (such as
a dimmer switch).
• Not for commercial use. Household use
only.

5
GETTING TO KNOW YOUR AIR PURIFIER
LED DISPLAY
A. LED Display
B. Touch-Control Panel
C. Dust Sensor Lens
D. Dust Sensor Cover
A. On/O Indicator
B. Check Filter Indicator
C. Timer Display
D. Air Quality Indicator
E. Auto Mode
F. Sleep Mode
G. Fan Speed
E. Button Vent
F. Filter Indicator Reset Button
G. Housing
H. Safety Switch
AB
G
H
I
A
C
G
E
B
F
D
J
L
K
C
D
F
E
I. Activated Carbon Filter
J. Fine Preliminary Filter
K. True HEPA Filter
L. Back Cover

6
CONTROLS
On/O Button
• Turns the air purifier on
or o.
Display O Button
• Turns the display o.
• Press any button (except
) to turn the display
back on.
Sleep Mode Button
• Turns Sleep Mode on or
o (see page 8).
Timer Button
• Sets or cancels a timer
(see page 8).
Auto Button
• Turns Auto Mode on or o
(see page 8).
Air Quality Indicator
• Displays air quality using the automatic
sensor inside the air purifier.
• The air purifier may take up to 1 minute
to detect air quality.
Fan Speed Button
• Cycles through fan
speeds: low, medium, and
high.
• The fan speed cannot be
changed during Auto or
Sleep Modes.
Air Quality Indicator Chart
Colour Air Quality
Bad
Moderate
Good
Very Good

7
GETTING STARTED
1. Open the back cover of the air purifier
and remove both filters from their plastic
packaging. [Figure 1.1]
2. First, place the Activated Carbon Filter
back into the air purifier. Then, place
the Preliminary/True HEPA Combination
Filter. Make sure the pull tabs on both
filters are facing out. [Figure 1.2]
3. Replace the back cover by lining up the
cover’s feet with the matching slots on
the bottom of the housing. Make sure
that the triangular piece at the bottom of
the cover is touching the safety switch.
[Figure 1.3]
4. Push the cover closed.
5. Place the air purifier on a hard,
flat surface. Leave 38 cm / 15 in of
clearance on all sides of the air purifier.
[Figure 1.4]
Note: Do not remove the foam
piece attached to the dust sensor
cover unless instructed by Customer
Support. [Figure 1.5]
Figure 1.1
Figure 1.4
Figure 1.5
Figure 1.2
Figure 1.3
Tabs facing
outward
38 cm /
15 in
Safety
switch
38 cm /
15 in

8
Note:
• For best results, run the air purifier
at maximum speed for 15-20
minutes before using a lower speed
or Auto Mode.
• To eectively clean air, keep
windows closed while the air
purifier is operating.
USING YOUR PURIFIER
General Operation
Sleep Mode
Auto Mode
Timer
Automatic Shutoff
Memory Function
1. Press to turn the air purifier on/
o. The air purifier fan will start
automatically at low speed.
2. Optionally, press to increase fan
speed. You can also select Auto or
Sleep Mode, or set a timer.
Auto Mode uses the sensor inside the air
purifier to adjust the fan speed automatically
based on air quality. For example, if the air
quality is bad, the fan will automatically be
set to high speed. See chart.
• Press to turn Auto Mode on/o.
• Pressing or will also exit Auto
Mode.
You can set a timer between 1 and 12 hours.
• Press repeatedly to choose a time
in increments of 1 hour. When you stop
pressing , the display will flash 3 times
and the timer will start.
• The air purifier will automatically power o
once the timer is finished.
• To cancel a timer, press repeatedly
until the display reads “-:--” and flashes
3 times.
As a safety feature, the air purifier will
automatically turn o if the back cover is
removed.
When the air purifier is plugged in, it will
remember its programmed settings when
turned o, and will resume these settings
when turned back on.
Sleep Mode uses the lowest possible fan
speed to create a quiet environment.
• Press to turn Sleep Mode on/o.
• Pressing or will also exit Sleep
Mode.
Auto Mode Chart
Colour Air Quality Fan Speed
Bad High
Moderate Medium
Good Low
Very Good Sleep Mode

9
ABOUT THE FILTERS
A. Fine Preliminary Filter
• Captures large particles such as
dust, lint, fibres, hair, and pet fur.
• Maximizes the life of the True
HEPA Filter by protecting it.
B. True HEPA Filter
• Removes at least 99.97% of
airborne particles 0.3 micrometres
(µm) in diameter.
• Filters small particles such as
mould spores, tiny dust particles,
parts of smoke, and allergens such
as pollen, dander, and mites.
C. High-Eciency Activated Carbon Filter
• Physically adsorbs smoke, odours,
and fumes.
• Filters compounds such as
formaldehyde, benzene, ammonia,
hydrogen sulfide, and volatile
organic compounds (VOCs).
This air purifier uses a 3-stage filtration system to purify air.

10
KEEPING THINGS CLEAN
Check Filter Indicator
Cleaning the Filters
Cleaning the Air Purifier
The Check Filter Indicator will light up as a
reminder to check the air filters. Depending
on how often you use the air purifier, the
indicator should turn on within 6–8 months.
You may not need to change your filters
yet, but you need to check them when the
indicator light turns on.
Reset the Check Filter Indicator by pressing
the reset button inside the vent on the side of
the air purifier (see page 12).
A. The Fine Preliminary Filter should be
cleaned once a month to increase
eciency and extend the life of your
filter. Clean the Fine Preliminary Filter
using a brush or vacuum hose to
remove hair, dust, and large particles.
B. Do not clean the True HEPA Filter. Fine
dust or bacteria may be released back
into the air if cleaning is attempted. Only
clean the Fine Preliminary Filter.
C. The Activated Carbon Filter does not
require cleaning.
Wipe the outside of the air purifier with a dry
cloth. Do not clean with water or any other
liquid, to avoid risk of electric shock.
A B
C
Replacing the Filters
1. Unplug the air purifier and remove the
back cover.
2. Remove the old filters and properly
dispose of them.
3. Unwrap the new filters. Place the
Activated Carbon Filter inside the
housing. Make sure the pull tabs are
facing out.
4. Install the Preliminary/True HEPA
Combination Filter into the housing.
Make sure the pull tabs are facing out.
5. Replace the back cover. The air purifier
will not power on unless the back cover
is replaced correctly.
6. Press the Filter Indicator Reset Button
inside the vent (see page 12).

11
When Should I Replace the
Filters?
The filters should be replaced every 6–8
months. You may need to replace your filters
sooner or later depending on how often you
use your air purifier. Using your air purifier in
an environment with relatively high pollution
may mean you will need to change the filters
more often (even if the Check Filter Indicator
is o).
You may need to replace your filters if you
notice:
• Increased noise when the air purifier is on
• Decreased airflow
• Unusual odours
• Visibly clogged filters
Cleaning the Dust Sensor Lens
1. Turn o and unplug the air purifier.
2. Open the dust sensor cover. [Figure 2.1]
3. Use a cotton swab, dipped in water, to
clean the dust sensor lens. [Figure 2.2]
4. Wipe the lens dry with a dry cotton
swab.
Note: Do not remove the foam
piece attached to the dust sensor
cover unless instructed by Customer
Support. [Figure 2.3]
Figure 2.1
Figure 2.2
Figure 2.3
To maintain the performance of
your air purifier, only use ocial
Levoit filters. To buy replacement
filters, go to Amazon and search
B077GQ6PW8.
KEEPING THINGS CLEAN (CONT.)

12
Resetting the Check Filter
Indicator
Reset the Check Filter Indicator after
changing the filters.
1. Plug in the air purifier and turn it on.
2. Locate the button vent on the side of
the air purifier. [Figure 3.1]
3. Use a paperclip, small flathead
screwdriver, or other small object to
press the black Filter Indicator Reset
Button inside the vent. [Figure 3.1]
4. The Check Filter Indicator will turn o,
indicating that the reset is complete.
If not using the air purifier for an extended
period of time, wrap the filter in plastic
packaging and store in a dry place to avoid
moisture damage.
Storage
Figure 3.1
KEEPING THINGS CLEAN (CONT.)

13
Problem Possible Solution
Air purifier will not turn on or
respond to button controls.
Plug in the air purifier.
Check to see if the power cord is damaged. If so, stop using
the air purifier and contact Customer Support (see page
15).
Properly place the filter cover on the air purifier, so that the
safety switch is activated (see page 7).
Plug the air purifier into a dierent outlet.
Air purifier is malfunctioning. Contact Customer Support (see
page 15).
The air quality indicator always
stays red, and the air purifier is
running on high speed.
Clean the dust sensor lens (see page 11).
The air quality indicator always
stays blue, even though air
quality is poor.
Air purifier makes an unusual
noise while the fan is on.
Make sure the filters are removed from their packaging and
properly in place (see page 7).
Replace the filters (see page 10).
The air purifier may be damaged, or a foreign object may
be inside. Stop using the air purifier and contact Customer
Support (see page 15). Do not try to repair the air purifier.
Airflow is significantly reduced. Make sure the filters are removed from their packaging.
Press to increase the fan speed.
Leave 38 cm / 15 in of clearance on all sides of the air purifier.
Replace the filters (see page 10).
Check Filter Indicator is still on
illuminated after replacing the
air filters.
Reset the Check Filter Indicator (see page 12).
TROUBLESHOOTING

14
Problem Possible Solution
Poor air purification quality. Press to increase the fan speed.
Make sure no objects are blocking the top or sides of the air
purifier (the inlet or outlet).
Make sure the filters are removed from their packaging and
properly in place (see page 7).
Close doors and windows while running the air purifier.
Make sure the room is smaller than 48 m² / 516 ft². The air
purifier may not be as eective in larger rooms.
Clean the dust sensor lens (see page 11).
Replace the filters (see page 10).
The Check Filter Indicator has
not turned on within 8 months.
The Check Filter Indicator is a reminder for you to check the
filters and will light up based on how long the air purifier has
been used (see page 11). If you don’t use your air purifier
often, the indicator will take longer to turn on.
The Check Filter Indicator
turned on before 6 months.
The Check Filter Indicator is a reminder for you to check
the filters and will light up based on how long the air purifier
has been used (see page 11). If you run your air purifier
frequently, the indicator will turn on sooner.
Air purifier randomly turns o. Air purifier is malfunctioning. Stop using the air purifier and
contact Customer Support (see page 15).
If your problem is not listed, please contact Customer Support (see page 15).
TROUBLESHOOTING (CONT.)

15
WARRANTY INFORMATION
Terms & Policy
Arovast Corporation warrants all products to be of
the highest quality in material, craftsmanship and
service for a minimum of 2 years, eective from
the date of purchase. Warranty lengths may vary
between product categories. Should you encounter
any issues or have any questions regarding your
new product, feel free to contact our helpful
Customer Support Team.
CUSTOMER SUPPORT
Arovast Corporation
1202 N. Miller St., Suite A
Anaheim, CA 92806
USA
Email: [email protected]
*Please have your order invoice and order ID
ready before contacting Customer Support.

Connect with us @LevoitUK
levoit.com
JJ1019MC-M1.1_0819LV-PUR131_uk
