Meet the new star in Lexmark’s color laser printer lineup for midsize workgroups.
The Lexmark CS510 Series color laser printer provides spot-on PANTONE® color
matching, smart print management and super-fast speeds that make it a workhorse
winner. Want more capacity? Get the CS510dte.
Present your brand with accurate color.
Produce beautiful, vibrant tones and print your
branded materials in-house. This all-new model packs
advanced productivity capabilities to help you work faster
and smarter.
Professional color matching – Lexmark Named Color
Replacement and PANTONE® calibration make it easy to
develop a consistent brand image by accurately matching
your colors.
High resolution graphics – With up to true 1,200x1,200
dpi resolution, images and graphics stay crisp. Lexmark’s
Unison™ Toner ensures consistent quality, too.
Super fast and quiet output – Power through projects
with print speeds up to 32 pages per minute in black and
color—plus produce a 1-page color document in as little
as 10 seconds.
Print complex documents even faster – Even complex
color documents print fast, thanks to its new, high-speed
dual-core processor, 512 MB of upgradable memory and
Gigabit Ethernet.
More performance. Less hassle.
In a tough, deadline-driven environment, this system
really performs. With a bright color touch screen,
convenient USB port, large paper input capacity and
more, our solution makes printing a pleasure.
advantage of up to 2.5 GB of upgradable memory,
an 800 MHz dual-core processor and Gigabit Ethernet.
It delivers the power you need to react quickly to a
competitor’s price move by printing locally on demand.
Professional quality color. Peak performance.
Lexmark CS510 Series
Color Laser Printers
Reliable high performance – Easily print up to 7,000
pages per month, plus enjoy fewer maintenance hassles,
thanks to our state-of-the-art paper handling.
Bright touch screen – Our easy-to-use 4.3-inch color
touch screen allows you to preview and make post job
changes fast.
Run larger jobs without interruption – With an input
capacity of up to 1,450 sheets and extra high yield toner
cartridge options, you won’t have to add paper or change
cartridges as often.
Innovative toner that optimizes performance – Get
greater system performance with Lexmark’s Unison™
Toner, which delivers consistent image quality from first
print to last.
Network intelligent. Management wise.
Quickly respond to changing business needs with our
eco-friendly printers that help streamline your workflow
using productivity solutions.
Print anytime and anywhere6– With this system, you
can print from desktops as well as mobile devices that
can run applications.
Better manage print jobs – Take advantage of smart
functions like job waiting, custom messaging and
programmable alerts.
Enjoy enterprise-level security – Now you can
authenticate, authorize and audit employee usage.
Plus, protect sensitive data using standard network
security protocols.
Save resources and the planet – An instant
warm-up fuser and built-in 2-sided printing plus Quiet,
Hibernate and Eco modes minimize noise and save
paper and energy.
CS510de

13WWM2561
¹ Average continuous black or continuous composite CMY declared cartridge yield up to this number of standard pages in accordance with ISO/IEC 19798.
2
“Maximum Monthly Duty Cycle” is defined as the
maximum number of pages a device could deliver in a month using a multishift operation. This metric provides a comparison of robustness in relation to other Lexmark printers and MFPs.
3
“Recommended
Monthly Page Volume” is a range of pages that helps customers evaluate Lexmark’s product oerings based on the average number of pages customers plan to print on the device each month. Lexmark
recommends that the number of pages per month be within the stated range for optimum device performance, based on factors including: supplies replacement intervals, paper loading intervals, speed, and
typical customer usage.
4
Print and copy speeds measured in accordance with ISO/IEC 24734, excludes first set of test documents. For more information see: www.lexmark.com/ISOspeeds.
5
Product functions
only with replacement cartridges designed for use in a specific geographical region. See www.lexmark.com/regions for more details.
6
For more information on Lexmark Mobile Solutions see: http://www1.
lexmark.com/en_US/solutions/business-solutions/mobile-print/index.shtml
7
Printers are sold subject to certain license/agreement conditions. See www.lexmark.com/printerlicense for details.
8
Duplex (2-sided
printing) models are ENERGY STAR compliant.
Lexmark CS510 Series Product Specification
Unison is a trademark of Lexmark International, Inc. Information in this document is subject to change without notice. ENERGY STAR® is a U.S. registered mark. All other trademarks are the
property of their respective owners. Lexmark and Lexmark with the diamond design are trademarks of Lexmark International, Inc., registered in the United States and/or other countries.
AirPrint and the AirPrint logo are trademarks of Apple Inc.
Standard
Optional
CS510 Series Product Features
Product specification
Lexmark MS710dn Lexmark MS711dn
Printing
Display Lexmark e-Task 10.9 cm (4.3-inch) color touch screen
Print Speed: Up to4Black: 32 ppm / Color: 32 ppm
Time to First Page: As fast as Black: 9 seconds / Color: 10 seconds
Print Resolution Black: 4,800 Color Quality (2,400 x 600 dpi), 1,200 x 1,200 dpi / Color: 4,800 Color Quality (2,400 x 600 dpi), 1,200 x 1,200 dpi Memory /
Memory / Processor Standard: 512 MB / Maximum: 2560 MB / Processor: Dual Core, 800 MHz
Hard Disk Option available
Recommended Monthly Page Volume21,500 - 7,000 pages
Maximum Monthly Duty Cycle: Up to38,5000 pages per month
Supplies
Laser Cartridge Yields 8,000¹-page Black Extra High Yield Cartridge, 4,000¹-page Color (CMY) Extra High Yield Cartridges, 4,000¹-page Black High Yield Cartridge,
3,000¹-page Color (CMY) High Yield Cartridges, 1,000¹-page Black and Color (CMYK) Cartridges
Cartridge(s) Shipping with Product 4,000¹-page Color (CMY) Extra High Yield Return Program Toner Cartridges, 6,000¹-page Black starter Return Program Toner Cartridge
Paper Handling
Included Paper Handling Single-Sheet Manual Feed, 250-Sheet Input,
Integrated Duplex, 125-Sheet Output Bin
Single-Sheet Manual Feed, 125-Sheet Output Bin, 250-Sheet Input,
550-Sheet Duo Tray with 100-Sheet Feeder, Integrated Duplex
Optional Paper Handling 550-Sheet Duo Tray with 100-Sheet Feeder, 550-Sheet Tray 550-Sheet Tray
Paper Input Capacity: Up to Standard: 250+1 pages 20 lb or 75 gsm bond /
Maximum: 1,450+1 pages 20 lb or 75 gsm bond
Standard: 250+1 pages 20 lb or 75 gsm bond /
Maximum: 1,450+1 pages 20 lb or 75 gsm bond
Paper Output Capacity: Up to Standard: 125 pages 20 lb or 75 gsm bond / Maximum: 125 pages 20 lb or 75 gsm bond
Media Types Supported Refer to the Card Stock & Label Guide, Paper Labels,
Card Stock, Transparencies, Plain Paper
Refer to the Card Stock & Label Guide, Plain Paper, Envelopes,
Card Stock, Paper Labels, Transparencies
Media Sizes Supported Oficio, Universal, Letter, Legal, A5, A4, Executive, Folio, JIS-B5 Oficio, Universal, Letter, Legal, DL Envelope, B5 Envelope, A4, 7 3/4
Envelope, 10 Envelope, 9 Envelope, A5, C5 Envelope, Executive, Folio, JIS-B5
General7
Standard Ports Rear USB 2.0 Specification Hi-Speed Certified Port (Type A), USB 2.0 Specification Hi-Speed Certified (Type B), Gigabit Ethernet (10/100/1000), Front USB 2.0
Specification Hi-Speed Certified Port (Type A)
Optional Network Ports / Optional Local
Ports MarkNet N8352 802.11b/g/n Wireless
Noise Level, Operating Printing: 50 dBA
Product Warranty 1-Year Exchange Service, Next Business Day
Size (in. - H x W x D) / Weight (lb.) 12.1 x 17.4 x 16.0 in. / 46.1 lb. 17.2 x 17.4 x 16.4 in. / 55.3 lb.
Lexmark CS510de Lexmark CS510dte
— 2 —
10.9 cm (4.3-Inch) Touch Screen
550-Sheet Duo Tray with 100-Sheet Feeder
250-Sheet Input
Single-Sheet Manual Feed
550-Sheet Tray
Swivel Cabinet
Solutions
Up to 32
ppm
Color 2.4" LCD Standard
Pages
Up to 35ppm Network Eco-mode USBSecurity
Color 2.4" LCD Standard
Pages
Up to 35ppm Network Eco-mode USBSecurity
7-In. Touch
Screen
Color
Adjustable Printer Stand
