LG L704I User manual

Part 15.21 statement
" Change or Modifications that are not expressly approved by the manufacturer could void
the user's authority to operate the equipment. "
Part 15.105 statement
This equipment has been tested and found to comply with the limits for a class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. if this
equipment does cause harmful interference or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected
- Consult the dealer or an experienced radio/TV technician for help.

LIMITED WARRANTY STATEMENT
1. WHAT THIS WARRANTY COVERS:
LG offers you a limited warranty that the enclosed subscriber unit and its enclosed accessories will be
free from defects in material and workmanship, according to the following terms and conditions:
(1) The limited warranty for the product extends for ONE (1) year beginning on the data of purchase
of the product.
(2) The limited warranty extends on to the original purchaser of the product and is not assignable or
transferable to any subsequent purchaser/end user.
(3) This warranty is good only to the original purchaser of the product during the warranty period as
long as it is in the U.S., including Alaska, Hawaii, U.S. Territories and Canada.
(4) The external housing and cosmetic parts shall not be covered under these limited warranty terms.
(5) Upon request from LG, the consumer must provide information to reasonably prove the date of
purchase.
(6) The customer shall bear the cost of shipping the product to the Customer Service Department of
LG. LG shall bear the cost of shipping the product back to the consumer after the completion of
service under this limited warranty.
2. WHAT THIS WARRANTY DOES NOT COVER:
(1) Defects or damages resulting from use of the product in other than its normal and customary
manner.
(2) Defects or damages from abnormal use, abnormal conditions, improper storage, exposure to
moisture or dampness, unauthorized modifications, unauthorized connections, unauthorized repair,
misuse, neglect, abuse, accident, alteration, improper installation, or other acts which are not the
fault of LG, including damage caused by shipping blown fuses spills of food or liquid.
(3) Breakage or damage to antennas unless caused directly by defects in material or workmanship.
(4) That the Customer Service Department at LG was net notified by consumer of the alleged defect
or malfunction of the product during the applicable limited warranty period.
(5) Products which have had the serial number removed or made illegible.
(6) The limited warranty is in lieu of all other warranties, express or implied either in fact or by
operations law, statutory or otherwise, including, but limited to any implied warranty of
marketability or fitness for a particular use.
(7) Damage resulting from use of non-LG approved accessories.
(8) All plastic surfaces and all other externally exposed parts that are scratched or damaged due to
normal customer use.
(9) Products operated outside published maximum ratings.
3
(10) Products used or obtained in a rental program.
(11) Consumables (such as fuses).
3. STATE LAW RIGHTS:
No other express warranty is applicable to this product. THE DURATION OF ANY IMPLIED
WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY, IS LIMITED
TO THE DURATION OF THE EXPRESS WARRANTY HEREIN. LG INFOCOMM INC. SHALL
NOT BE LIABLE FOR THE LOSS OF THE USE OF THE PRODUCT, INCONVENIENCE, LOSS
OR ANY OTHER DAMAGES, DIRECT OR CONSEQUENTIAL, RISING OUT OF THE USE OF,
OR INABILITY TO USE, THIS PRODUCT OR FOR ANY BREACH OF ANY EXPRESS OR
IMPLIED WARRANTY, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY
APPLICABLE TO THIS PRODUCT. Some states do not allow the exclusive of imitation of incidental
or consequential damages or limitations on how long an implied warranty lasts; so these limitations or
exclusions may not apply to you. This warranty gives you specific legal rights and you may also have
other rights which vary from state to state.
4. HOW TO GET WARRANTY SERVICE:
To obtain warranty service, please call the following web address:
www.lgeservice.com

8
For Your Safety
Important Information
This user guide contains important information on the use and
operation of this phone. Please read all the information
carefully for optimal performance and to prevent any damage
to or misuse of the phone. Any changes or modifications not
expressly approved in this user guide could void your warranty
for this equipment.
Before You Start
Safety Instructions
WARNING! To reduce the possibility of electric shock, do not
expose your phone to high humidity areas, such as the
bathroom, swimming pool, etc.
Always store your phone away from heat. Never store your
phone in settings that may expose it to temperatures less than
32°F or greater than 104°F, such as outside during extreme
weather conditions or in your car on a hot day. Exposure to
excessive cold or heat will result in malfunction, damage
and/or catastrophic failure.
Be careful when using your phone near other electronic
devices. RF emissions from your mobile phone may affect
nearby in adequately shielded electronic equipment. You
should consult with manufacturers of any personal medical
devices such as pacemakers and hearing aides to determine if
they are susceptible to interference from your mobile phone.
Turn off your phone in a medical facility or at a gas station.
Never place your phone in a microwave oven as this will
cause the battery to explode.
IMPORTANT! Please read the TIA SAFETY INFORMATION on
page 78 before using your phone.
Safety Information
Read these simple guidelines. Breaking the rules may be
dangerous or illegal. Further detailed information is given in this
user guide.
]Never use an unapproved battery since this could damage
the phone and/or battery and could cause the battery to
explode.
]Never place your phone in a microwave oven as it will
cause the battery to explode.
]Do not dispose of your battery by fire or with hazardous or
flammable materials.
]Make sure that no sharp-edged items come into contact
with the battery. There is a risk of this causing a fire.
]Store the battery in a place out of reach of children.
]Be careful that children do not swallow any parts such as
rubber plugs (earphone, connection parts of the phone,
etc.). This could cause asphyxiation or suffocation.

9
For Your Safety
]Unplug the power cord and charger during lightning storms
to avoid electric shock or fire.
]When riding in a car, do not leave your phone or set up the
hands-free kit near to the air bag. If wireless equipment is
improperly installed and the air bag is activated, you may be
seriously injured.
]Do not use a hand-held phone while driving.
]Do not use the phone in areas where its use is prohibited.
(For example: aircraft).
]Do not expose the battery charger or adapter to direct
sunlight or use it in places with high humidity, such as a
bathroom.
]Never store your phone in temperatures less than- 4°F or
greater than 122°F.
]Do not use harsh chemicals (such as alcohol, benzene,
thinners, etc.) or detergents to clean your phone. There is a
risk of this causing a fire.
]Do not drop, strike, or shake your phone severely. Such
actions may harm the internal circuit boards of the phone.
]Do not use your phone in high explosive areas as the phone
may generate sparks.
]Do not damage the power cord by bending, twisting, pulling,
or heating. Do not use the plug if it is loose as it may cause
a fire or electric shock.
]Do not place any heavy items on the power cord. Do not
allow the power cord to be crimped as it may cause fire or
electric shock.
]Do not handle the phone with wet hands while it is being
charged. It may cause an electric shock or seriously
damage your phone.
]Do not disassemble the phone.
]Do not place or answer calls while charging the phone as it
may short-circuit the phone and/or cause electric shock or
fire.
]Only use the batteries, antennas, and chargers provided by
LG. The warranty will not be applied to products provided by
other suppliers.
]Only authorized personnel should service the phone and its
accessories. Faulty installation or service may result in
accidents and consequently invalidate the warranty.
]Do not hold or let the antenna come in contact with your
body during a call.
]An emergency call can be made only within a service area.
For an emergency call, make sure that you are within a
service area and that the phone is turned on.

10
For Your Safety
FCC RF Exposure Information
WARNING! Read this information before operating the phone.
In August 1996, the Federal Communications (FCC) of he United
States, with its action in Report and Order FCC 96-326, adopted
an updated safety standard for human exposure to radio
frequency (RF) electromagnetic energy emitted by FCC
regulated transmitters. Those guidelines are consistent with
the safety standard previously set by both U.S. and
international standards bodies.
The design of this phone complies with the FCC guidelines and
these international standards.
CAUTION
Use only the supplied and approved antenna. Use of
unauthorized antennas or modifications could impair call
quality, damage the phone, void your warranty and/or result in
violation of FCC regulations. Do not use the phone with a
damaged antenna. If a damaged antenna comes into contact
with skin, a minor burn may result. Contact your local dealer
for a replacement antenna.
Body-worn Operation
This device was tested for typical body-worn operations with
the back of the phone kept 0.79 inches (2cm) between the
user’s body and the back of the phone. To comply with FCC RF
exposure requirements, a minimum separation distance of 0.79
inches(2cm) must be maintained between the user's body
and the back of the phone. Third-party belt-clips, holsters, and
similar accessories containing metallic components should not
be used. Body-worn accessories that cannot maintain 0.79
inches(2cm) separation distance between the user's body
and the back of the phone, and have not been tested for typical
body-worn operations may not comply with FCC RF exposure
limits and should be avoided.

11
For Your Safety
Vehicle Mounted External Antenna
(optional, if available)
A minimum separation distance of 8 inches (20cm) must be
maintained between the user/bystander and the vehicle
mounted external antenna to satisfy FCC RF exposure
requirements. For more information about RF exposure, visit
the FCC website at www.fcc.gov
FCC Part 15 Class B Compliance
This device and its accessories comply with part 15 of FCC
rules. Operation is subject to the following two conditions:
(1) This device and its accessories may not cause harmful
interference, and (2) this device and its accessories must
accept any interference received, including interference that
may cause undesired operation.
Cautions for Battery
]Do not disassemble.
]Do not short-circuit.
]Do not expose to high temperature: 60°C (140°F).]
]Do not incinerate.
Battery Disposal
]Please dispose of your battery properly or bring to your
local wireless carrier for recycling.
]Do not dispose in fire or with hazardous or flammable
materials.
Adapter (Charger) Cautions
]Using the wrong battery charger could damage your phone
and void your warranty.
]The adapter or battery charger is intended for indoor use
only.
Do not expose the adapter or battery charger to direct sunlight
or use it in places with high humidity, such as the bathroom.

27
Confirming before use
Phone Parts and Functions ...................28
Display ....................................................32
Menu Operations....................................34
Soft Key Operations...............................34
Side Button Main Operations ................35
Using the UIM ..................36
Attaching/Removing the Battery Pack..38
Charging the Phone....................40
Turning Power ON..................................44
Turning Power OFF ................................44
Date/Time ...............................................45
Using Caller ID Notification Service ......45
Own Number...........................................45

28
Confirming before use
Ç≤égópëOÇÃämîF
Confirming before use
Phone Parts and Functions
The Name and function of each part of the phone are as follows.
• This manual describes operation of each button using an illustration of the button.

29
Confirming before use
Confirming before use
Next Page
1Earpiece
While talking over a call, the other party’s voice is
heard from here.
2LED display
Lights up and flashes during incoming call or battery
charging. You cannot change the light up/flash method.
3In camera
You can use this camera for shooting yourself or
sending movie by Video-phone call.
4Display >P32
5Earphone/Microphone terminal
For connecting a Flat-plug Earphone/Microphone Set
with Switch (option), etc. Do not forcibly pull the
earphone/microphone cover※.
※: You can rotate it forward or backward when it is open.
6MMail button
Press from the Stand-by display to bring up the Mail
menu. >P140
Press from the Stand-by display for 2 or more seconds
to check new message. >P129, P156
Press this key during auto key lock to cancel the auto
lock. >P101
You can execute the items shown on the soft key area.
>P34
7KNavigation button
For selecting an item and scrolling the display.
The following operations can be performed from the
Stand-by display:
UUp button : The phonebook list screen appears.
>P67
DDown button : The custom menu screen appears.
>P186
LLeft button : Received call screen appears.
>P86
Press for 1 or more seconds to
display the received mail list. >P88
RRight button : Redialed call screen appears.
>P87
Press for 1 or more seconds to
display the sent mail list. >P88
8CMenu/Select button
Press on the Stand-by display to bring up the Main menu.
> P34
An operation displayed in the soft key area can be
performed.
> P34

30
Confirming before use
Ç≤égópëOÇÃämîF
Confirming before use
9TVideo-phone button
Press to make/receive video-phone calls. >P58, P60
Press on the Stand-by display to view the other party that
you made the latest call.
Press to switch modes, etc. in entering mode
(Pictograph/Symbol/Emoticon). >P223
Press to switch in camera and out camera when
camera is started.
!AStart button
Press to make/receive voice calls. >P48, P50
Press on the Stand-by display to view the other party
that you made the latest call. Press for 1 or more
seconds to display all received/sent mail history.
Press while characters are entered to switch between
full-pitch and half-pitch. >P222
"FEVolume buttons
Press to adjust the volume, etc. >P35
Press these buttons on the Stand-by display for 1 or
more seconds to turn on the photo light. >P192
#Dial button
$**(asterisk) button/Public mode (drive mode)
button
Press to enter “*” and to switch between upper case
and lower case while characters are entered. >P224
On the stand-by display, press this key for 1 or more
seconds to set or cancel Public mode (drive mode).
>P52
%Microphone
For speaking to the other party.
For recording sound when shooting moving images by
the camera.
&Ii-mode button
Press from the Stand-by display to bring up the
i-mode menu. >P122
Press for 2 or more seconds from the Stand-by display
to bring up software list screen of i-appli. >P163
Press from the entering character mode to switch the
mode (Hiragana/Katakana/English/ Number)
An operation displayed in the soft key area can be
performed. >P34
(NMultitask button
Press to bring up the Task Manager.
Press for 1 or more seconds to bring up the New Task
screen.
>P284
)PPower/End button
Press for 2 or more seconds to turn the power on.
Press for 2 or more seconds to turn the power off.
>P44
Press to end calls and end functions.
~QClear button
Press to return to the previous operation.
Press this button on the Stand-by display (when the
phone is closed) for 1 or more seconds to enable
the auto key lock
>P100
Press to cancel the operation depending on the function
such as sending mails or downloading data.※

31
Confirming before use
Confirming before use
Next Page
Also, press to delete entered text.
※
: Note that the operation may not be canceled
depending on the timing of canceling※.
+#(Sharp)/ Manner Mode button
Press for 1 or more seconds from the Stand-by display
to activate/deactivate the Manner Mode.
>P78
Also, press to enter “#” and to start a new line while
characters are entered.
,Connector terminal
For connecting adapters and cables.
-Infrared data port
Point this port to the other device for infrared
communication. >P186
.Strap hole
/Speaker
Ring tone and alarm can be heard from here.
The voice of the other partner can be heard from here
when you are calling using the speaker phone.
:Rear cover
;GCamera button
Press this button on the Stand-by display to activate
the photo mode and press this for 1 or more seconds
to activate the movie mode. >P111, >P117
<Out camera
You can use this camera for shooting still image or
moving images or sending movie by Video-phone call.
=Photo light
You can turn on this light when the out camera is used.
This lights up/flashes in red during shooting still image
or moving images. >P111, >P117
You can also use this light as a flashlight. >P192
Opening/closing phone
Slide the body front portion where the Stand-by display
exists upward to open the phone. Slide it downward to
close the phone.
Information
• Note that sliding it roughly results in a failure.

32
Confirming before use
Ç≤égópëOÇÃämîF
Confirming before use
Display
1~ : Shows the level of the received radio waves.
Strong Weak
: Out of the service area.
2: Displayed during a voice call.
: Displayed during a video-phone call.
: Displayed during a voice call using the speaker phone.
3(Blinks): while i-mode is activated.
(Blinks): during i-mode communication.
: Displayed during trying dialup connection.
: Displayed during dialup connection.
: Displayed while an SSL-enabled page is displayed or
obtained.
4: Displayed while “All Call Rejection” is activated.
5: Displayed while a function (Task) is activated.
: Performing multiple functions (Task).
(Blinking): Alarm starts while talking, activating camera
or setting public mode (drive mode).
6(White): Displayed when the i-mode Center holds a mail.
(Pink): Displayed when the box for i-mode mail at the
i-mode Center is full.
(White): Displayed when the i-mode Center holds a
MessageR.
(Pink): Displayed when the box for MessageR at the
i-mode Center is full.
(White): Displayed when the i-mode center holds a
MessageF.
(Pink): Displayed when the box for MessageF at the
i-mode Center is full.
(White): Displayed when the i-mode Center holds mail,
a messageR and a messageF.
(Pink): Displayed when the boxes for i-mode mail,
MessageR and MessageF at the i-mode Center are full.
7(White): Displayed when an unread mail exists.
(White): Displayed when an unread SMS message exists.
Mail Menu i-mode
1 23456 789!" #
$%&()
~
+
Remain 8
TV viewing

33
Confirming before use
Confirming before use
(White): Displayed when an unread mail and SMS
message exist.
(Pink): Displayed when the inbox is full.
: Displayed when the area for SMS messages in the
UIM is full.
: The inbox and the SMS in card are full.
8(Yellowish green): Displayed when a Voice Mail
message exists.
(Orange): Displayed when the box for Voice Mail
messages is full.
9(White): Displayed when an unread MessageR exists.
(Pink): Displayed when the box for MessageR is full.
!(White): Displayed when an unread MessageF exists.
(Pink): Displayed when the box for MessageF is full.
": Displayed when i-appli is being started.
: Displayed when i-appli auto start failed.
#~ : Shows the battery level.
$(Pink): Displayed during Manner mode.
(Blue): Displayed during Original manner mode.
%: Displayed when the ringtone for incoming voice
call or video-phone call sounds, not operating a
vibration.
: Displayed when the vibration for incoming call is
activated to “Pattern 1” or “Pattern 2” when the
alarm for incoming voice call or video-call is muted,
and the vibration operate linked with a melody.
: Displayed when a vibration and a ringtone for
incoming voice call and video-phone call sounds
at the same time and the vibration is set to
operate linked with a melody.
: Displayed when a vibration and a ringtone from
incoming voice call or video-phone call do not
operate.
&: Public mode (Drive mode) active.
(: Displayed while an alarm is set.
: Displayed when today’s schedule exists.
: Displayed when an alarm is set and today’s
schedule exists.
):Displayed when UIM is not inserted or an error
occurs on the UIM.
~Date counter >P200
Displays the number of days till the registered event.
+Stand-by memo >P198
Displays the stand-by memo you create.

34
Confirming before use
Ç≤égópëOÇÃämîF
Confirming before use
Menu Operations
This section describes the operation using an example for
setting a wall paper on the Stand-by display.
aSelecting a function by a K
1. On the Stand-by display, C[Menu] ]Highlight
using K]C]HMove the cursor to the
Stand-by display ]C]HMove the cursor to the
Wallpaper ]C
aSelecting a function by pressing the key
corresponding to the menu number
1. On the Stand-by display, C[Menu] ]Highlight
using K]C]1]1
Soft Key Operations
To perform an operation displayed in the soft key area on
the 待受画面, press the corresponding button as below.
Information
• (Navigation icon) that indicates the directions in which you
can scroll and select items using Kis also displayed in the
soft key area.
• Items displayed in the soft key area vary depending on the
display.
K C1 1
Stand-by display
Display
Select
Wallpaper
Clock/Calender
Wallpaper memo
Select
Stand-by display
Select
Call display
Font
Menu style
Backlight
Color scheme
K CH CH C
Stand-by display
Display
Select
Wallpaper
Clock/Calender
Wallpaper memo
Select
Stand-by display
Select
Call display
Font
Menu style
Backlight
Color scheme

Side Button Main Operations
• If auto key lock (P100) is enabled with phone
closed, the operations are as follows:
FE : the auto lock can be cancelled temporarily. Refer to
the table below.
G: Cannot be operated.
35
Confirming before use
Confirming before use
How to operate
phone
operation
Operation of
phone
During voice phone/
Video-phone call
]
FE Open/
Close
Call rejection
Press ]Gfor 1 or more
seconds during incoming call
Close
Stopping alarm
During the alarm/ schedule
alarm is ringing ]E
Open/
Close
Scrolling the listing
display or site
display by page※1
During displaying each
screen
]
FE Open/
Close
Switch the one
moth schedule
display by month
During displaying the one
month display in the
Scheduler
]
FE
Open/
Close
Starting camera During stand-by
]
G
(Photo mode)
Press
]
Gfor 1 or more
seconds during stand-by
(Movie mode)
Open/
Close
During the auto key lock
]
FE
]
C
When the display is turned
off
]
FE
/
G
Operation of
phone
How to operate
phone
operation
When the display is
turned on
Open/
Close
Cancel temporarily
the auto key lock
Close
During the still image/moving
images shooting display is
displayed ]FE
Zoom Open/
Close
During stand-by, press ]
For Efor 1 or more
seconds (light up)
When the photo light
lights up, press
]
For E
(light off)
Photo light on/off※2Open/
Close
During stand-by
]
FE
Adjust phone
volume
Adjust the button
check volume
Open/
Close
Adjust ring tone
volume During incoming call
]
FE
Open/
Close

36
Confirming before use
Ç≤égópëOÇÃämîF
Confirming before use
※1 : Depending on the display type, you can move the cursor up
and down.
※2 : “Flashlight” (P192 ) is set to “Not use”, this does not function.
Using the UIM ( Card)
Your phone number and contracted contents for the
service, etc. are recorded in the UIM. You need to insert it
into the phone to make/receive calls or perform
communication.
Refer to the UIM manual for details of how to use it.
Inserting/Removing UIM ( Card)
Insert/remove the UIM after you turn off the power of the
phone and remove the rear cover and battery pack
beforehand (P39).
• Remove the AC adapter and options beforehand.
Inserting
1. Insert the UIM with its IC-side facing downwards in
the direction of the arrow underneath the guide
Removing
1. Slide the UIM in the direction of the arrow to
remove it
Operation of
phone
How to operate
phone
operation
When playing moving
images/melodies
]
FE
Adjusting the volume
when moving images/
melodies are replayed
Open/
Close
When moving images/
melodies are stopped, ]
G(play)
When the moving
images/ melodies are
played, ]G(pause)
Playing and pausing
moving images/
melodies
Open/
Close

37
Confirming before use
Confirming before use
Information
• When inserting / removing the UIM, close the flip, and then put
it on your hand. Take care not to accidentally torch or scratch
the IC.
About Password of UIM
You can set 2 passwords, PIN1 and PIN2, for a UIM.
>P107
UIM Restriction Functions
The UIM has a restriction function to protect your data and
files.
If you obtain the following types of data and files with a
UIM inserted, restrictions are automatically imposed to
disable them when the UIM is not inserted or when
another UIM is inserted.
• Images/melodies/i-motion/i-appli obtained from sites
and Internet web pages
• Files attached to i-mode mail messages and
MessagesR/F
Differences of UIM
The card (blue) differs from the card
(Green/White) as follows:
aAbout WORLD WING
WORLD WING is international roaming
service that allows you to use the same mobile pone
number for making and receiving calls after inserting
your UIM (Green/White) in a phone applicable to
the service or mobile phone available for overseas use
(WCDMA or GSM).
• Application is not required for the user who signed a
service contract after September 1, 2005.
However, those who notified that the service is not
required during signing the service contract or
canceled in the middle of the contract need to apply
for the service again.
UIM
(Green/White)
Function UIM (Blue)
Number of digits of the phone
number that can be stored in
the UIM phonebook
Up to 26 digitsUp to 20 digits
WORLD WING AvailableNot available
Service dialing AvailableNot available

38
Confirming before use
Ç≤égópëOÇÃämîF
Confirming before use
• Those who did not apply for WORLD WING before
August 31, 2005 need to apply for the service.
• Some billing plans may not be applied to WORLD
WING.
• For loss or theft of the phone, account settlement of
total charges, or phone failure while overseas, see
"Failure while overseas" the back side of the
operation manual. Note that the customer shall also
pay the fees for call and communication after the
phone is lost or stolen.
Attaching/Removing the Battery Pack
Make sure that you attach the dedicated battery pack L02
for L704i to use it.
Attaching
1. Press the rear cover in the direction of the arrow 1
to slide it in the direction of the arrow 2, then lift it
up in the direction of the arrow 3to remove
2. Insert the battery in the direction of the arrow 1
with the label facing downwards, then push it in
the direction of the arrow 2

39
Confirming before use
Confirming before use
Next Page
3. Adjust the rear cover to the ditch of the
phone holding the cover approx. 3mm off, then
press it in the direction of the arrow 1to slide it in
the direction of the arrow 2, then push it until it
clicks
Removing
1. Press the rear cover in the direction of the arrow 1
to slide it in the direction of the arrow 2, then lift it
up in the direction of the arrow 3to remove
2. Take the projection of the battery pack to lift it up
in the direction of the arrow

40
Confirming before use
Ç≤égópëOÇÃämîF
Confirming before use
Information
• Attach/remove the battery pack with the phone closed
and held in your hand after you turn off the power. In addition,
If you attach/remove the battery pack forcibly, it may damage
the charging connector of battery.
• Take care not to attach/remove the rear cover. Note that if the
rear cover is forcibly depressed, the slot of the rear cover may
be damaged.
• For details about the battery, see the manual for Battery Pack L02.
Charging the Phone
Charging
Connect specified AC Adapter (option) to charge the
battery after attaching the battery pack to the
phone (P38). You need AC Adapter 01 for both
overseas and domestic usage (option) separately when
using the phone overseas.
1. Open the cover※of the external connector terminal
of the phone
※: You can rotate it forward or backward when it is open.
2. Place the arrow side of the AC adaptor connector
up and keep the connector level with head
set to connect in the arrow direction
3. Insert the AC adapter’s plug into a power socket
