LG PD820 User manual

1
PD820
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Important Information . . . . . . . . . . . . . . . . . . . . . . .5
Check Accessories . . . . . . . . . . . . . . . . . . . . . . . . .5
Bodily Contact During Operation . . . . . . . . . . . . . .7
Vehicle-Mounted External Antenna . . . . . . . . . . . .7
FCC Part 15 Class B Compliance . . . . . . . . . . . . .8
Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Phone Components . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Phone Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Using the Battery Pack . . . . . . . . . . . . . . . . . . . . . . . .12
Installing the Battery . . . . . . . . . . . . . . . . . . . . . . .12
Removing the Battery . . . . . . . . . . . . . . . . . . . . . .12
Battery Charge Level . . . . . . . . . . . . . . . . . . . . . .12
Using the Desktop Charger . . . . . . . . . . . . . . . . . . . . .13
Technical Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Screen Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Phone Menu Reference . . . . . . . . . . . . . . . . . . . . . . . .16
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Travel Charger . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Desktop Charger . . . . . . . . . . . . . . . . . . . . . . . . . .18
Cigarette Lighter Charger . . . . . . . . . . . . . . . . . . .19
Hands-Free Car Kit (Portable) . . . . . . . . . . . . . . . .19
AC Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Explosion, Shock, and Fire Hazards . . . . . . . . . .20
General Warnings and Cautions . . . . . . . . . . . . . .21
Battery Information and Care . . . . . . . . . . . . . . . . . . . .23
Basic Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Turning the Phone On and Off . . . . . . . . . . . . . . . . . . .25
Turning the Phone On . . . . . . . . . . . . . . . . . . . . . .25
Turning the Phone Off . . . . . . . . . . . . . . . . . . . . . .25
Signal Strength . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Power Save Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
PD820_eng.qxd 04/5/21 7:09 PM Page 1

PD820
2
Correcting Dialing Errors . . . . . . . . . . . . . . . . . . .26
Receiving Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
My Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . .28
Ring Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Quick Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Adjusting Manner Mode . . . . . . . . . . . . . . . . . . . .29
Adjusting Lock Function . . . . . . . . . . . . . . . . . . . .29
Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Mute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Redialing Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Speed Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Additional Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
How to enter Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Key Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Examples Using Text Input . . . . . . . . . . . . . . . . . .34
Phone Book Features . . . . . . . . . . . . . . . . . . . . . . . . .35
Personal Phone Book Memory . . . . . . . . . . . . . . .35
Saving Numbers inYour Personal Phone Book . . .35
Find Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Menu Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
General Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Phone Book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
New Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Speed Dial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Call Duration . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Clear History . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Delete All . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Volume/Ringer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Select Ringer . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Melody Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Ring/Vibrate . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Ring Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Key Tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Flip Tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Connect Alert . . . . . . . . . . . . . . . . . . . . . . . . . . .41
PD820_eng.qxd 04/5/21 7:09 PM Page 2

PD820
3
Service Alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
1 Min Alert . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Voice Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Display Theme . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Banner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Num Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Standby Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Menu Theme . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Backlight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
PIMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Scheduler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
New Schedule . . . . . . . . . . . . . . . . . . . . . . . . .47
Find Schedule . . . . . . . . . . . . . . . . . . . . . . . . .51
Delete Past . . . . . . . . . . . . . . . . . . . . . . . . . . .52
BookMark . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Alarm Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Wake-up Call . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Phone Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Call Barring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Call Answer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Modem/Fax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Phone Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Outbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Write New . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Received Msg . . . . . . . . . . . . . . . . . . . . . . . . .60
Sent Msg . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Draft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Clear Outbox . . . . . . . . . . . . . . . . . . . . . . . . . .61
SMS Info . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
PD820_eng.qxd 04/5/21 7:09 PM Page 3

PD820
4
Inbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Voice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Store . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Clear Inbox . . . . . . . . . . . . . . . . . . . . . . . . . .65
Clear Store . . . . . . . . . . . . . . . . . . . . . . . . . .65
Inbox Alert . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Alert Tone . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Font Color . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Inter Portal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Game&App . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Ring&Pics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Voice Portal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
What’s New . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
Safety Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
TIA Safety Information . . . . . . . . . . . . . . . . . . . . . . . . .70
Exposure to Radio Frequency Signal . . . . . . . . . .70
FDA Consumer Update . . . . . . . . . . . . . . . . . . . . . . . .74
PD820_eng.qxd 04/5/21 7:09 PM Page 4

PD820
5
Introduction
Congratulations on your purchase of the advanced and
compact PD820 cellular phone, designed to operate with
the latest digital mobile communication technology, Code
Division Multiple Access (CDMA). Along with the many
advanced features of the CDMA system such as greatly
enhanced voice clarity this phone offers:
Large, easy-to-read, 8-line backlight LCD with status
icons.
Paging, messaging, voice mail, and caller ID.
20-key keypad.
Long battery stand-by and talk time.
Menu-driven interface with prompts for easy operation
and configuration.
Any key answer, one-touch and speed dialing with 99
memory locations.
Bilingual (English and Hebrew).
Important Information
This user’s manual provides important information on the
use and operation of your phone.Please read all the
information carefully prior to using the phone for the best
performance and to prevent any damage to or misuse of
the phone.Any unapproved changes or modifications void
your warranty.
Check Accessories
Your mobile phone comes with a one-slot desktop
charger and a rechargeable battery. Please verify that
these accessories are included.
PD820_eng.qxd 04/5/21 7:09 PM Page 5

PD820
6
FCC RF Exposure Information
WARNING! Read this information before
operating the phone.
In August 1996, the Federal Communications (FCC) of
the United States, with its action in Report and Order
FCC 96-326, adopted an updated safety standard for
human exposure to radio frequency (RF) electromagnetic
energy emitted by FCC regulated transmitters.Those
guidelines are consistent with the safety standard
previously set by both U.S. and international standards
bodies.
The design of this phone complies with the FCC
guidelines and these international standards.
CAUTION
Use only the supplied and approved antenna.Use of
unauthorized antennas or modifications could impair call
quality, damage the phone, void your warranty and/or
result in violation of FCC regulations.
Do not use the phone with a damaged antenna. If a
damaged antenna comes into contact with the skin a
minor burn may result. Contact your local dealer for a
replacement of antenna.
PD820_eng.qxd 04/5/21 7:09 PM Page 6

PD820
7
Bodily Contact During Operation
This device was tested for typical use with the back of the
phone kept 1.5 cm from the body.To comply with
FCC RF exposure requirements, a minimum separation
distance of 1.5 cm must be maintained between
the user’s body and the back of the phone, including the
antenna whether extended or retracted.Third-party belt-
clips, holsters, and similar accessories containing metallic
components should not be used. Avoid the use of
accessories that cannot maintain 1.5 cm distance
between the user’s body and the back of the phone and
have not been tested for compliance with FCC RF
exposure limits.
Vehicle-Mounted External Antenna
(Optional, if available.)
A minimum distance of 8 in (20 cm) must be maintained
between the user / bystander and the vehicle-mounted
external antenna to satisfy FCC RF exposure
requirements.For more information about RF exposure,
visit the FCC website at www.fcc.gov.
PD820_eng.qxd 04/5/21 7:09 PM Page 7

FCC Part 15 Class B Compliance
This device and its accessories comply with part 15 of
FCC rules. Operation is subject to the following two
conditions: (1) This device and its accessories may not
cause harmful interference, and (2) this device and its
accessories must accept any interference received,
including interference that causes undesired operation.
PD820
8
PD820_eng.qxd 04/5/21 7:09 PM Page 8

PD820
9
GETTING STARTED
PPhhoonnee CCoommppoonneennttss
The following shows key components of your mobile
phone.
1 Getting Started
Headset Jack
LCD screen
Soft Key 1
Phone Book Key
Side Keys
CALL Key
Vibrate Mode
Key
Data/Charger
Port
Soft Key 2
Services Key
Navigation Key
END/PWR Key
Clear Key
Alphanumeric
Keypad
Lock Mode Key
Power Mode Key
Earpiece
Microphone
OK Key
PD820_eng.qxd 04/5/21 7:09 PM Page 9

PD820
10
PPhhoonnee OOvveerrvviieeww
Caller LCD When there are incoming calls and
messages, the LCD flashes.
LCD Screen Displays messages & indicator icons.
Soft Key 1
Perfoms variety of functions according to
the menu.
Soft Key 2
Perfoms variety of functions according to
the viewing function.
CALL Allows user to place or answer calls.
ND/PWR Used to turn power on/off and to end a
call. Using this key, you can return to the
main menu display screen.
These keys enable you to enter numbers
and characters and choose menu items.
Navigation key : Press to check the Text, Voice and
Push messages, Voice rec and
Today’s schedule.
: Press to select Volume/Ringer
menu.
: Press to check the message
Outbox, Inbox.
: Press to select My Menu.
Soft Keys
(the names of the
functions of these
keys appear at
the bottom of the
screen)
Alphanumeric
Keypad
PD820_eng.qxd 04/5/21 7:09 PM Page 10

PD820
11
GETTING STARTED
Clear Key When writing a message, press to delete
a single space or character or press and
hold to delete entire words.
Lock Mode Key
In standby mode, set the lock function
by pressing and holding the key
about 3 seconds.
Manner Mode Key
In standby mode, set the Manner mode
by pressing and holding the key
about 3 seconds.
Power Mode Key
In standby mode, set the Power mode by
pressing and holding the key about
3 seconds.
Side Keys Used to adjust the volume during a call.
Functions same as key when
selecting menus.
In Standby mode:
When the folder is closed, the current time
is displayed ; press once to display today’s
date.
When the folder is open; adjust the key
volume.
Phone Book Press to select Phone Book.
Services Press to select Services Menu.
OK
Press to select the menu or connect to
internet.
PD820_eng.qxd 04/5/21 7:09 PM Page 11

PD820
12
UUssiinngg tthhee BBaatttteerrPPaacckk
Note: It is important to charge the battery fully before
the initial use of the phone.
The phone comes with a rechargeable battery. Keep the
battery charged while not in use in order to maximize talk
and standby time when using the phone.
Installing the Battery
To install the battery, insert the bottom of the battery into
the opening on the back of the phone.Then push the
battery down until the latch clicks.
Removing the Battery
Turn the power off. Lift the release latch to detach the
battery.
Battery Charge Level
The battery charge level is shown at the top right of the
LCD screen.
When the battery charge level becomes low, the low
battery sensor alerts you in three ways: sounding an
audible tone, blinking the battery icon, and displaying
LOW BATTERY WARNING! If the battery charge level
becomes exceedingly low, the phone automatically
switches off and any function in progress is not saved.
Fully Charged Fully Discharged
PD820_eng.qxd 04/5/21 7:09 PM Page 12

PD820
13
UUssiinngg tthhee DDeesskkttoopp CChhaarrggeerr
The desktop charger has a slot for recharging batteries that
accommodates the phone and battery for charging.
Warning! Use only the desktop charger
provided with the phone. Using any charger
other than the one included with the PD820
may damage your phone or battery.
1. Plug the charger into a wall outlet.The phone must
be charged from a 120 VAC power source.
2. Insert the phone with an installed battery or the
battery by itself into the slot of the charger.The red
light indicates the battery is charging and the green
light indicates the battery is fully charged.
The charge time varies depending upon the battery
level and the maximum charge time for a fully
discharged battery is 3 hours.
GETTING STARTED
PD820_eng.qxd 04/5/21 7:09 PM Page 13

PD820
14
TTeecchhnniiccaall DDeettaaiillss
The PD820 is a single-band phone that operates on
Code Division Multiple Access (CDMA) frequencies:
cellular services at 800 MHz.
CDMA technology uses a feature called DSSS (Direct
Sequence Spread Spectrum) that enables the phone to
keep communication from being crossed and to use one
frequency channel by multiple users in the same specific
area.This results in a 10-fold capacity increase when
compared with analog mode.In addition, features such as
soft / softer handoff, hard Handoff, and dynamic RF
power control technologies combine to reduce call
interruptions.
The Cellular and PCS CDMA networks consist of MSO
(Mobile Switching Office), BSC (Base Station Controller),
BTS (Base station Transmission System), and MS (Mobile
Station).The following table lists some major CDMA
standards.
PD820_eng.qxd 04/5/21 7:09 PM Page 14

PD820
15
GETTING STARTED
SSccrreeeenn IIccoonnss
Icons Descriptions
Displays the strength of the signal received by the
phone and current signal strength is indicated by the
number of bars displayed on the screen.
No service
The phone is not receiving a system signal.
The Manner mode is selected.
When the ringer type is ‘Silent’or ‘Light’or when
the ringer volume is ‘Off’.
In Vibrate or Vib1+Ring or Vib2+Ring mode
Roaming
The phone is outside of its home service area.
In Alarm mode (alarm clock is set).
Indicates that a text message or voice mail has
been received
In use
A call is in progress.
*No icon indicates the phone is in standby mode.
Shows your current battery charge strength.
(Icon shown fully charged)
The Power mode is selected.
PD820_eng.qxd 04/5/21 7:09 PM Page 15

PD820
16
Phone Book
1. New Entry
2. Speed Dial
3. Call Duration
4. Clear History
5. Delete All
Volume/Ringer
1. Select Ringer
2. Melody Box
3. Ring/Vibrate
4. Ring Volume
5. Key Tone
6. Flip Tone
7. Connect Alert
8. Service Alert
9. 1 Min Alert
0.Voice Guide
Display
1. Display Theme
2. Banner
3. Num Setting
4. Standby Clock
5. Menu Theme
6. Backlight
7. Contrast
PIMS
1. Scheduler
2. BookMarks
3. Alarm Clock
4.Wake-up Call
5. Calculator
Security
1. Phone Lock
2. Security Code
Settings
1.
2. Call Answer
3. Connection
4. Modem/Fax
5. Phone Info
Press Soft Key 1 Menu. Press to Scroll.
PPhhoonnee MMeennuuRReeffeerreennccee
PD820_eng.qxd 04/5/21 7:09 PM Page 16

17
GETTING STARTED
Outbox
1.Write New
2. Received Msg
3. Sent Msg
4. Draft
5. Clear Outbox
6. SMS Info
Inbox
1.Text
2.Voice
3. Store
4. Clear Inbox
5. Clear Store
6. Inbox Alert
7. Alert Tone
8. Font Color
Services
1. Internet Portal
2. Game&App
3. Rings&Pics
4.Voice Portal
5.What’s New
Press .
Press to Scroll.
Press .
Press to Scroll.
PD820_eng.qxd 04/5/21 7:09 PM Page 17

PD820
18
AAcccceessssoorriieess
There are a variety of accessories available for your
mobile phone.You can select these options according to
your personal communication requirements.Consult your
local dealer for availability.
Travel Charger
This charger allows you to
charge the battery while away
from home or your office. It
supports standard U.S. AC120
Volt 60 Hz outlets. It takes 5
hours to charge a completely
discharged battery.
Battery
The battery is available for
standard battery charge.
Desktop Charger
The desktop charger allows you
to place the phone in the stand
for charging. It can charge a
completely discharged battery in
3 hours.
Standard
PD820_eng.qxd 04/5/21 7:09 PM Page 18

PD820
19
Cigarette Lighter Charger
You can operate the phone and trickle
charge the phone’s battery from your
vehicle by using the cigarette lighter
charger.
It takes 5 hours to charge a
completely discharged battery.
Hands-Free Car Kit (Portable)
The hands-free car kit enables you to
attach the phone to the power jack in
your car, providing you with hands-
free operation.It can charge a
completely discharged battery in 5
hours.
GETTING STARTED
PD820_eng.qxd 04/5/21 7:09 PM Page 19

PD820
20
SSaaffeett IInnffoorrmmaattiioonn
Please read and observe the following information for safe
and proper use of your phone and to prevent damage. Also,
keep the user’s guide in an accessible place at all the times
after reading it.
Explosion, Shock, and Fire Hazards
●
Make sure that no sharp-edged items such as animal’s
teeth, nails, come into contact with the battery.There is
a risk of this causing a fire.
●
Do not use harsh chemicals(such as alcohol, benzene,
thinners, etc.) or detergents to clean your phone.There
is a risk of this causing a fire.
●
When riding in a car, do not leave your phone or set up
the hands-free kit near to the air bag. If wireless
equipment is improperly installed and the air bag is
activated, you may be seriously injured.
●
Do not handle the phone with wet hands while it is
being charged. It may cause an electric shock or
seriously damage your phone.
●
Do not drop, strike, or shake your phone severely. Such
actions may harm the internal circuit boards of the phone.
●
Be careful that children do not swallow any parts such as
rubber plugs (earphone, connection parts of the phone,
etc.).This could cause asphyxiation or suffocation.
●
Do not use your phone in high explosive areas as the
phone may generate sparks.
●
Do not put your phone in a place subject to excessive
dust and keep the minimum required distance between
the power cord and heat sources.
●
Unplug the power cord prior to cleaning your phone,
and clean the power plug pin when it is dirty.
PD820_eng.qxd 04/5/21 7:09 PM Page 20
