LG RVF1000 User manual

OWNER’S MANUAL
Video Conference System
Please read this manual carefully before operating
your set and retain it for future reference.
MODEL
RVF1000
P/NO : MFL66683301 1011 (V1.0)

2Safety Information
1
Safety Information
1
Safety Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This lightning ash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product’s enclosure that may be of sucient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the product.
FCC WARNING: This equipment may generate or use radio
frequency energy. Changes or modications to this equipment may
cause harmful interference unless the modications are expressly
approved in the instruction manual. The user could lose the
authority to operate this equipment if an unauthorized change or
modication is made.
REGULATORY INFORMATION: FCC Part 15
This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment.
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications.
Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to
correct the interference at his own expense.
• A suitable conduit entries, knock-outs or glands shall be
provided in the cable entries of this product in the end user.
• Caution: Danger of explosion if battery is incorrectly replaced.
Replaced only with the same or equivalent type recommended
by the manufacturer. Dispose of used batteries according to the
manufacturer’s instructions.
• Holes in metal, through which insulated wires pass, shall
have smooth well rounded surfaces or shall be provided with
brushings.
This Class A digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe A est conforme à la norme
NMB-003 du Canada.
Warning: Do not install this equipment in a conned space such as
a bookcase or similar unit.
Warning: Wiring methods shall be in accordance with the National
Electric Code, ANSI/NFPA 70.
Warning: This is a class A product. In a domestic environment this
product may cause radio interference in which case the user may
be required to take adequate measures.
Warning: To reduce a risk of re or electric shock, do not expose
this product to rain or moisture.
Caution: This installation should be made by a qualied service
person and should conform to all local codes.
Caution: To avoid electrical shock, do not open the cabinet. Refer
servicing to qualied personnel only.
Caution: The apparatus should not be exposed to water (dripping
or splashing) and no objects lled with liquids, such as vases, should
be placed on the apparatus.
Caution:
This product employs a Laser System. To ensure proper use of this
product, please read this owner’s manual carefully and retain it
for future reference. Should the unit require maintenance, contact
an authorized service center. Performing controls, adjustments,
or carrying out procedures other than those specied herein may
result in hazardous radiation exposure. To prevent direct exposure to
laser beam, do not try to open the enclosure. Visible laser radiation
when open. DO NOT STARE INTO BEAM.
To disconnect power from mains, pull out the mains cord plug.
When installing the product, ensure that the plug is easily
accessible.

Safety Information 3
1
Safety Information
LG Electronics hereby declares that this/these
product(s) is/are in compliance with the essential
requirements and other relevant provisions of
Directive 2004/108/EC, 2006/95/EC, and 2009/125/
EC.
European representative :
LG Electronics Service Europe B.V. Veluwezoom 15,
1327
AE Almere. The Netherlands
(Tel : [phone])
Disposal of your old appliance
1. When this crossed-out wheeled bin symbol is
attached to a product it means the product is
covered by the European Directive 2002/96/EC.
2. All electrical and electronic products should
be disposed of separately from the municipal
waste stream via designated collection facilities
appointed by the government or the local
authorities.
3. The correct disposal of your old appliance will help
prevent potential negative consequences for the
environment and human health.
4. For more detailed information about disposal of
your old appliance, please contact your city oce,
waste disposal service or the shop where you
purchased the product.
EEE Compliance with Directive. (for Turkey only)
Safety way to remove the battery or the battery from the
equipment:
Remove the old battery or battery pack, follow the steps in
reverse order than the assembly. To prevent contamination of the
environment and bring on possible threat to human and animal
health, the old battery or the battery put it in the appropriate
container at designated collection points. Do not dispose of
batteries or battery together with other waste. It is recommended
that you use local, free reimbursement systems batteries and
accumulators. The battery shall not be exposed to excessive heat
such as sunshine, re or the lile.
• Lamp(s) Contain Mercury, Dispose Properly.
• The lamps in this product contain mercury. Please dispose
according to state, local or federal law.
• This product contains a lamp(s) which contains mercury;
dispose according to local state, or federal laws.
IMPORTANT SAFETY
INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including ampliers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong
are provided for your safety. If the provided plug does not t
into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specied by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specied
by the manufacturer, or sold with the apparatus. When a
cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused
for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.

4Safety Information
1
Safety Information
Safety warnings and Cautions
The following are warnings and cautions for the safety of the users and for the prevention of any property damage. Please read the following
carefully.
WARNING
• Turn o the system before installation. Do not plug in several electric devices to the same outlet.
-This may cause heating, re, or electric shock.
• Do not place any liquid container on the system, such as water, coee, or other beverage.
-If liquid is poured onto the system, it can cause a system breakdown or re.
• Prevent the power cable from being severely bent or having pressure exerted on it by a heavy object.
-This may cause re.
• Clean the dust around the system on a regular basis. When cleaning the system, always use a dry cloth. Do not use a wet cloth or other
organic
solvents.
-This may damage the surface of the system and can cause a system breakdown or electric shock.
• Avoid any place with moisture, dust, or soot.
-This can cause re or electric shock.
• When pulling the power cable from the plug, do so gently. Do not touch the plug with wet hands and avoid using the plug if the holes in
the outlet are too loose.
-This may cause re or electric shock.
• Do not attempt to disassemble, repair, or modify the system on your own. It is extremely dangerous due to the high voltage running
through the system.
-This may cause re, electric shock, or serious injury.
• Check for any danger signs such as a moist oor, a loosened or damaged power cable, or an unstable surface. If you encounter any
problems, ask your dealer for assistance.
-This may cause re or electric shock.
• Keep a distance of at least 15cm between the back of the system and the wall for the cables connected to the system otherwise, they may
be bent, damaged, or cut.
-This may cause re, electric shock, or injury.
• Install the system in a cool place without direct sunlight and always maintain room temperature. Avoid candlelight and heat generating
devices such as heaters. Keep the system away from places where many people pass.
-This may cause re.
• Install the system on a plain surface with sucient air ventilation. Do not place the system on an elevated surface.
-This may cause system breakdown or serious injury.
• The power outlet must be placed on the ground, and the voltage range must be within 10% of the voltage rate. Do not use the same
outlet with a hair dryer, iron, refrigerator, or any heating appliances.
-This may cause re, over heating or electric shock.

Safety Information 5
1
Safety Information
CAUTION
Please beware of the following precautions before installing the VCS.
• Avoid positioning the product in any place where the unit may come into contact with moisture, dust, or soot.
• Avoid placing in direct sunlight or near heating appliances.
• Keep the product away from electric sparks or magnetic substances.
• Avoid temperature extremes (recommended operating temperature is between 0°C - 40°C).
• Do not place any conductive material through the ventilation grills.
• Keep the system turned o before installation.
• Ensure enough space is left for cable connections.
• Place the system on a solid surface with sucient air ventilation. Avoid any surface that vibrates.
• Placing the system near electronic devices such as a radio may cause the product to breakdown.
• Do not disassemble the product without seeking assistance from LG Electronics.
• Do not place any heavy object on the system.
• Prevent any substances from being inserted into the system.
-This may cause system breakdown.
• Install the system in a place with sucient air ventilation.
-Keep at least 15cm distance between the back of the system and the wall.
• Do not install the system in a place with high magnetic, electric wave, or wireless devices such as a radio.
-Do not install the system in a place with magnetic objects, electric frequencies, or vibration.
• Do not place any heavy object on the system.
-This may cause system breakdown.
• Install the system on a stable, level surface.
-The system may not operate properly.
• Install the system in a place with appropriate moisture and temperature levels.
-Avoid installing the system in a place with high (over 40°C) or low (under 0°C) temperature.
• The system can be damaged from a strong impact or vibration. Avoid throwing objects within the vicinity of the system.
• Avoid direct sunlight or any heating appliances.
-Recommended operating temperature is over 0°C (32°F).
• Ventilate the air inside the system operation room, and tighten the system cover rmly.
-System breakdown may be caused by an inappropriate environment. It is recommended to use AVR (Automatic Voltage Regulator)
for a stable power supply. It is recommended to coil the core-ferrite around the connector of the system to avoid electromagnetic
interference.
• The outlet must be placed on the ground.
• If there is strange sound or smell, unplug the power cable immediately and contact the service center.
-This may cause re or electric shock.
• In order to maintain stable system performance, have your system checked regularly by the service center.
-LG Electronics is not held responsible for system breakdown caused by user mishandling.
-There is a risk of explosion if a battery is replaced by an incorrect type. Dispose of used batteries according to the instructions.
• Do not overturn the product during use.

6Contents
Contents
1
Safety Information
3 IMPORTANT SAFETY INSTRUCTIONS
2
Preparation
8 Introduction
8 What is the VCS system?
8 Features
9 Unpacking
10 Codec unit overview
11 HD camera overview
12 Remote Control
3
Installation
13 Connections
13 Precautions
13 Connection overview
14 HD camera connection
15 HDMI connection
16 PC connection
17 Connecting Network
18 Connecting a Headphone
18 Connecting a Microphone
19 Connecting Power
19 System connection check
20 Initial settings
24 Main screen overview
25 System configuration menu
25 User settings
25 General
26 Audio
27 Video
28 DateTime
29 Admin settings
29 Call settings
33 Network settings
37 System settings
38 System Information
38 System Status

Contents 7
2
3
4
5
1
38 Audio/Video
39 Network Utility
39 Server Status
4
Operation
40 Before using the system
40 Placing a Call
40 Placing a call manually
41 Placing a Call from the Call History
41 Placing a Call from the Directory
42 Placing a Call using the Speed Dial
42 Answering or Rejecting a Call
42 Managing a Call
42 Ending a Call
42 Hiding or Showing User Interface Elements
42 Managing Audio
43 Managing Video Layout
43 Sharing content
43 Viewing Call information
44 Get the Snapshot
44 Managing the Directory
44 Adding an Entry to the Directory
45 Editing or deleting an Entry from the Directory
46 Copying an Entry from the Call histroy
46 Copying an Entry from the Coporate Contact
46 Deleting an Entry from the History
47 Sorting and Searching
47 Placing a call when device is registered in Gatekeeper server
47 Making a call when device is registered in Sip server
48 Using Far End Camera Control
48 Using Far End Camera Preset
48 Using SnapShot
48 Using the Web Service
49 Upgrading your System Software
49 Uploading the Certification file
49 Importing or exporting the address book
5
Appendix
50 Trouble Shooting
52 Open source software notice
53 Specifications

8Preparation
2
Preparation
Introduction
What is the VCS system?
LG video conference system is designed to be used for video conferencing that enables people in a dierent space such as conference room
or oce to have a meeting (by seeing, listening and speaking each other on a screen.)
Through this device, not only can executives or managers make a meeting and communicate with customers, subcontractors and coworkers
in real time but also you can make a decision and interchange information immediately that saves your time and cost.
VCS
VCS
Network
Features
• Provide convenient and easy graphical user interface
• Provide H.323 / SIP Network codec of International Standard
• Provide HD video quality – 1 280 X 720 (30 fps)
• Available changing the screen layout of video image
• Provide graphic presentation using Content Sharing Technology (Share Document/Audio/Video)
• Provide administrator password and H235 codec (Advanced Encryption Standard) for security
• One-touch call connecting using Speed Dial
• Create graphical directory using snapshot and Groups can be specied
• Provide variety of easy phonebook search function
• Provide 720P high-denition camera
• Provide natural conversation sound using full duplex mode
• Support Build-in Speaker.
2
Preparation

Preparation 9
2
Preparation
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your
product. The illustrations in this manual may dier from the actual product and item.
Codec unit HD camera Remote Control and Batteries
Power Adapter HDMI cable Camera connection cable
Owner’s Manual CD MicPod (Optional) Carrying case

10 Preparation
2
Preparation
Codec unit overview
a b
POWER
DC IN
LAN
RGB(PC) IN
CAMERA
HDMI OUT
c d e f g h i j k
a Power indicator: Lights when the unit turns on.
b Speaker: Speaker is built-in.
c HDMI port: Connects the VCS and the display device with a HDMI cable.
d Cooling fan.
e Camera connection port: Connects the HD camera.
f RGB(PC) IN port: Connects the PC with a D-SUB cable for presentation.
g LAN port: Connects to a network via a hub with RJ-45 connector.
h Power input jack: Connects to a DC 12 V power supply using proper cables.
i Power button: Turns the unit on or o.
j MIC jack: Connects a microphone.
k AUDIO jack: Connects a headphone.

Preparation 11
2
Preparation
HD camera overview
a
POWER
DC IN
LAN
RGB(PC) IN
CAMERA
HDMI OUT
b c d
a Internal microphone
b Remote Sensor: Points the remote control here.
c Camera activation indicator: Lights when the camera is connected to the codec uite and activates correctly.
d CAMERA IN port: Connects the Codec unit and the HD Camera with the supplied camera conntion cable.

12 Preparation
2
Preparation
Remote Control
This remote control provides wireless control of all Video conference system functions and enables you to navigate the user interface, place
and receive calls and control far end cameras connected to the system.
Button Description Button Description
Use this button to zoom in or
zoom out of the far end camera.
Use this button to adjust the
volume of the system in a call.
Use this button to mute
microphones of the near end
system.
/
Use this button to select the near
or far end camera.
Displays the system or call
information.
Displays the system setup menu.
Use this button to select the
video input source (camera or
PC) of the near camera.
• Arrow buttons: Navigate
the menu options. Use this
button to Pan/Tilt control for
far end camera.
• OK: Conrms menu
selections.
Use this button to return to the
previous condition.
Use this button to change the
screen layout.
Use this button to return to the
main screen.
Use this button when the system
receives a call or manully make a
call.
Displays the directory menu. Use this button when you want
to hang up the call.
Use these buttons to input text
or numbers.
• 1/a/A: Change the input type
among the number, lower
case and upper case.
• DEL.: Delete a character
before the cursor position.
• SPACE: Insert a space at the
cursor position.
Use this button to set the far end
camera preset.
/
Function buttons.
Each button function is changed
as the condition of the menu
and system operation refers to
the each screen for more details.
Battery Installation
Open the battery cover, replace batteries (1.5 V AAA) matching 3 and 3 ends to the label inside the compartment and then close the
battery cover.
CAUTION
Do not mix old and new batteries as this may damage the remote control.

Installation 13
3
Installation
Connections
Precautions
Before setting up the this system, ensure that the monitor, the computer system and other attached devices are turned o.
Connection overview
The illustration below shows connections of the system. For specic information of each connection, refer to the next pages.
Connection overview
POWER
DC IN
LAN
RGB(PC) IN
CAMERA
HDMI OUT
21
Optional
Optional Optional
3 4
HDMI
CABLE
CAMERA
CABLE
D-SUB
CABLE
LAN
CABLE
3
Installation

14 Installation
3
Installation
HD camera connection
Connect the HD camera to the camera jack of the codec unit with the supplied camera connection cable as shown in the following
illustrations.
HD camera connection
POWER
DC IN
LAN
RGB(PC) IN
CAMERA
HDMI OUT
NOTE
• After connection is completed, adjust the angle of the camera to suit your view.
• If you use the built-in speaker of the Codec unit, the distance between the camera and the Codec unit should be more than 1 meter.
• The recommended distance between the camera and the user is about 1 m to 2 m.

Installation 15
3
Installation
HDMI connection
Transmits the digital video and audio signals from the system to your monitor set with the HDMI cable as shown in the following illustrations.
HDMI cable connection
POWER
DC IN
LAN
RGB(PC) IN
CAMERA
HDMI OUT
NOTE
• It is recommended to use the monitor set with the 1280X720 @60Hz mode for the best image quality.
• If you connect the Codec unit to the HDMI TV and use the speaker of the TV, the distance between the camera and the TV should be
more than 1 meter.
• The recommended distance between the camera and the user is about 1 m to 2 m.
• If you connect the Codec unit to the DVI port of monitor (TV) using HDMI to DVI converter, you should hear the audio through built-in
speaker or headphone because DVI does not support audio interface. Please go to Setup > User > Audio > Audio Out and change Audio
Out to “Built-In Speaker” or “Headset Out”.

16 Installation
3
Installation
PC connection
Transmits the analog video signal from your PC to codec unit. Connect the PC and the codec unit with the optional D-sub 15 pin signal cable
as shown in the following illustrations.
You can give a presentation to the far-end user with this connection.
PC connection
POWER
DC IN
LAN
RGB(PC) IN
CAMERA
HDMI OUT

Installation 17
3
Installation
Connecting Network
Connect the codec unit’s LAN port to the corresponding port on your router or network using the optional LAN or Ethernet cable with RJ-45
connector.
Network connection
POWER
DC IN
LAN
RGB(PC) IN
CAMERA
HDMI OUT
NOTE
When plugging or unplugging the LAN cable, hold the plug portion of the cable. When unplugging, you should hold the lock of the plug
portion.

18 Installation
3
Installation
Connecting a Headphone
Connect a headphone cable to the headphone port of the codec unit as shown in the following illustrations.
Headphone connection
POWER
DC IN
LAN
RGB(PC) IN
CAMERA
HDMI OUT
Connecting a Microphone
Connect a microphone to the MIC port of the codec unit as shown in the following illustrations.
Microphone connection
POWER
DC IN
LAN
RGB(PC) IN
CAMERA
HDMI OUT

Installation 19
3
Installation
Connecting Power
Connect the power cable as shown in the following illustrations.
Power connection
POWER
DC IN
LAN
RGB(PC) IN
CAMERA
HDMI OUT
CAUTION
You must use supported Adaptor. If you connect other adaptor which is not oered by RVF1000 device, you may make malfunction, failure
and re.
System connection check
After all of the connections are completed, follow below steps to check the system operation.
1. Turn on the monitor.
2. Press the power button on the rear of the codec unit.
System booting will commence. When the booting is completed the initial conguration menu will be displayed.
If it is not displayed, check the device connections and make sure the connections are correctly set.
Now, you can use the system. Do the next conguration.
NOTE
Video out of RVF1000 default setting is 720p. If the monitor (TV) does not support the 720p, press the blue llll button 5 time. And then
RVF1000 is rebooted automatically as 480p.

20 Installation
3
Installation
Initial settings
When you access the VCS for the rst time, the Initial setting screen appears. Select a language and customize the basic settings.
1. Insert two AAA batteries matching + and - correctly into the remote controller.
2. Turn on the unit. System booting will commence. The logo image will be displayed during the system booting.
3. When the booting is complete the initial conguration menu will be displayed.
4. Select the wizard option.
4-1. Select one of the below options.
• Start Wizard: Select this option when you want to set the conguration with wizard. If you select this option, follow next steps.
NOTE
Recommend to use the Start Wizard option than Manual setting option.
• Manual Setting: Skip the wizard conguration and display the main setup window. You can set the system conguration manually.
NOTE
If you setup incorrect in the Maual Setting, you may not connect call.
4-2. Select the [Next] button and press [OK] button to go to the next step or press ll button.
