MODEL : LST-3410A

SERVICE MANUAL

P/NO : 3829RVN006Z

DECEMBER, 2003

Printed in Korea

HD/SD PRESONAL VIDEO RECORDER

& RECEIVER WITH GEMSTAR

SERVICE MANUAL

CAUTION

BEFORE SERVICING THE UNIT, READ THE “SAFETY PRECAUTIONS”

IN THIS MANUAL.

1-1

SECTION 1

SUMMARY

CONTENTS

INTRODUCTION ......................................................................................................1-2

PRODUCT SAFETY SERVICING GUIDELINES FOR VIDEO PRODUCTS............1-3

SERVICING PRECAUTIONS....................................................................................1-4

SPECIFICATIONS .....................................................................................................1-5

LOCATION OF CUSTOMER CONTROLS ...............................................................1-7

1-2

INTRODUCTION

- Digital/Analog broadcasting recorder/receiver [HD/SD PRESONAL VIDEO RECORDER & RECEIVER] or

PVR(Personal Video Recorder)-STB(Set-Top Box) receives the ground wave HD Digital broadcasting pro-

gram /Analog NTSC or Cable broadcasting program and saves a video or audio signal at a HDD with a spe-

cific form or offers related additional services.

- Configuration

The CUP is the IBM PPC405GP of the PowerPC series supporting PCI Bus I/F for PVR, and the tuner

receives a digital ground wave and transfers it as a TP signal, transmitting the NTSC signal of the ground

wave/the cable signal and transferring the audio signal to the SIF.

The MPEG Decoder uses the HD-II supporting MP@HL built with the AC-3 Decoder.

The PVR section transforms the TP data of a digital TV signal and an analog audio/video signal into the TP

by using the MPEG-II Encoder and saves only the necessary one at the HDD via the IDE I/F Chip.

Overall configuration

- System section

CPU, Main Memory, MPEG-II Decoder, Flash Memory, and System CPLD.

- MPEG Video/Audio Decoder section

HD-2, Memory, PLL IC, Audio Processor, Audio ADC, and so on.

- PVR section

TPN-II performing PCI I/F and TP De-Mux, Memory, MPEG-II Encoder, IDE I/F Chip, and 120GB HDD.

- Video/Audio input section

CVBS Decoder, and Audio processor

-1394 section

1394 1-Chip supporting D-VHS and MV Camcoder.

- Tuner

It can receive a signal from ATSC/NTSC/Cable, and send a signal from the ATSC as TP, an analog video sig-

nal as NTSC, and an audio signal as SIF.

- Front section

It is located at the front receiving various key inputs from users and displaying the status of a set-top box at

the VFD.

- Power section

It supplies a DC power to Main Digital Board, Front Board, and HDD with the input of AC 110V.

1-3

IMPORTANT SAFETY NOTICE

This manual was prepared for use only by properly trained audio-video service

technicians.

When servicing this product, under no circumstances should the original

design be modified or altered without permission from Zenith Electronics

Corporation. All components should be replaced only with types identical to

those in the original circuit and their physical location, wiring and lead dress

must conform to original layout upon completion of repairs.

Special components are also used to prevent x-radiation, shock and fire haz-

ard. These components are indicated by the letter “x” included in their compo-

nent designators and are required to maintain safe performance. No deviations

are allowed without prior approval by Zenith Electronics Corporation.

Circuit diagrams may occasionally differ from the actual circuit used. This way,

implementation of the latest safety and performance improvement changes

into the set is not delayed until the new service literature is printed.

CAUTION: Do not attempt to modify this product in any way. Never perform

customized installations without manufacturer’s approval. Unauthorized modi-

fications will not only void the warranty, but may lead to property damage or

user injury.

Service work should be performed only after you are thoroughly familiar with

these safety checks and servicing guidelines.

GRAPHIC SYMBOLS

The exclamation point within an equilateral triangle is intended to

alert the service personnel to important safety information in the

service literature.

The lightning flash with arrowhead symbol within an equilateral tri-

angle is intended to alert the service personnel to the presence of

noninsulated “dangerous voltage”that may be of sufficient magni-

tude to constitute a risk of electric shock.

The pictorial representation of a fuse and its rating within an equi-

lateral triangle is intended to convey to the service personnel the

following fuse replacement caution notice:

CAUTION: FOR CONTINUED PROTECTION AGAINST RISK

OF FIRE, REPLACE ALL FUSES WITH THE SAME TYPE AND

RATING AS MARKED NEAR EACH FUSE.

SERVICE INFORMATION

While servicing, use an isolation transformer for protection from AC line shock.

After the original service problem has been corrected, make a check of the fol-

lowing:

FIRE AND SHOCK HAZARD

1. Be sure that all components are positioned to avoid a possibility of adjacent

component shorts. This is especially important on items trans-ported to and

from the repair shop.

2. Verify that all protective devices such as insulators, barriers, covers, shields,

strain reliefs, power supply cords, and other hardware have been reinstalled

per the original design. Be sure that the safety purpose of the polarized line

plug has not been defeated.

3. Soldering must be inspected to discover possible cold solder joints, solder

splashes, or sharp solder points. Be certain to remove all loose foreign par-

ticles.

4. Check for physical evidence of damage or deterioration to parts and compo-

nents, for frayed leads or damaged insulation (including the AC cord), and

replace if necessary.

5. No lead or component should touch a high current device or a resistor rated

at 1 watt or more. Lead tension around protruding metal surfaces must be

avoided.

6. After reassembly of the set, always perform an AC leakage test on all

exposed metallic parts of the cabinet (the channel selector knobs, antenna

terminals, handle and screws) to be sure that set is safe to operate without

danger of electrical shock. DO NOT USE A LINE ISOLATION TRANS-

FORMER DURING THIS TEST. Use an AC voltmeter having 5000 ohms per

volt or more sensitivity in the following manner: Connect a 1500 ohm, 10

watt resistor, paralleled by a .15 mfd 150V AC type capacitor between a

known good earth ground water pipe, conduit, etc.) and the exposed metal-

lic parts, one at a time. Measure the AC voltage across the combination of

1500 ohm resistor and .15 mfd capacitor. Reverse the AC plug by using a

non-polarized adaptor and repeat AC voltage measurements for each

exposed metallic part. Voltage measured must not exceed 0.75 volts RMS.

This corresponds to 0.5 milliamp AC. Any value exceeding this limit consti-

tutes a potential shock hazard and must be corrected immediately.

TIPS ON PROPER INSTALLATION

1. Never install any receiver in a closed-in recess, cubbyhole, or closely fitting

shelf space over, or close to, a heat duct, or in the path of heated air flow.

2. Avoid conditions of high humidity such as: outdoor patio installations where

dew is a factor, near steam radiators where steam leakage is a factor, etc.

3. Avoid placement where draperies may obstruct venting. The customer

should also avoid the use of decorative scarves or other coverings that

might obstruct ventilation.

4. Wall- and shelf-mounted installations using a commercial mounting kit must

follow the factory-approved mounting instructions. A product mounted to a

shelf or platform must retain its original feet (or the equivalent thickness in

spacers) to provide adequate air flow across the bottom. Bolts or screws

used for fasteners must not touch any parts or wiring. Perform leakage tests

on customized installations.

5. Caution customers against mounting a product on a sloping shelf or in a tilt-

ed position, unless the receiver is properly secured.

6. A product on a roll-about cart should be stable in its mounting to the cart.

Caution the customer on the hazards of trying to roll a cart with small cast-

ers across thresholds or deep pile carpets.

7. Caution customers against using extension cords. Explain that a forest of

extensions, sprouting from a single outlet, can lead to disastrous conse-

quences to home and family.

A.C. Voltmeter

1500 OHM

10 WATT

Place this probe

on each exposed

metal part.

Good Earth Ground

such as the Water

Pipe, Conduit, etc.

0.15uF

PRODUCT SAFETY SERVICING GUIDELINES FOR VIDEO PRODUCTS

1-4

SERVICING PRECAUTIONS

CAUTION: Before servicing the HD/SD PRESONAL VIDEO

RECORDER & RECEIVER WITH GEMSTAR covered by

this service data and its supplements and addends, read and

follow the SAFETY PRECAUTIONS. NOTE: if unforeseen

circumstances create conflict between the following servic-

ing precautions and any of the safety precautions in this pub-

lications, always follow the safety precautions.

Remember Safety First:

General Servicing Precautions

1. Always unplug the HD/SD PRESONAL VIDEO RECORDER

& RECEIVER WITH GEMSTAR AC power cord from the

AC power source before:

(1) Removing or reinstalling any component, circuit board,

module, or any other assembly.

(2) Disconnecting or reconnecting any internal electrical

plug or other electrical connection.

(3) Connecting a test substitute in parallel with an elec-

trolytic capacitor.

Caution: A wrong part substitution or incorrect

polarity installation of electrolytic capacitors may result

in an explosion hazard.

2. Do not spray chemicals on or near this HD/SD PRESON-

AL VIDEO RECORDER & RECEIVER WITH GEMSTAR

or any of its assemblies.

3. Unless specified otherwise in this service data, clean

electrical contacts by applying an appropriate contact

cleaning solution to the contacts with a pipe cleaner,

cotton-tipped swab, or comparable soft applicator.

Unless specified otherwise in this service data, lubrication

of contacts is not required.

4. Do not defeat any plug/socket B+ voltage interlocks with

which instruments covered by this service manual might

be equipped.

5. Do not apply AC power to this HD/SD PRESONAL VIDEO

RECORDER & RECEIVER WITH GEMSTAR and / or any

of its electrical assemblies unless all solid-state device

heat sinks are correctly installed.

6. Always connect the test instrument ground lead to an

appropriate ground before connecting the test instrument

positive lead. Always remove the test instrument ground

lead last.

Insulation Checking Procedure

Disconnect the attachment plug from the AC outlet and turn

the power on. Connect an insulation resistance meter (500V)

to the blades of the attachment plug. The insulation resis-

tance between each blade of the attachment plug and acces-

sible conductive parts (Note 1) should be more than 1M-

ohm.

Note 1: Accessible Conductive Parts include Metal panels,

Input terminals, Earphone jacks,etc.

Electrostatically Sensitive (ES) Devices

Some semiconductor (solid state) devices can be damaged

easily by static electricity. Such components commonly are

called Electrostatically Sensitive (ES) Devices. Examples of

typical ES devices are integrated circuits and some field

effect transistors and semiconductor chip components.

The following techniques should be used to help reduce the

incidence of component damage caused by static electricity.

1. Immediately before handling any semiconductor compo-

nent or semiconductor-equipped assembly, drain off any

electrostatic charge on your body by touching a known

earth ground. Alternatively, obtain and wear a commer-

cially available discharging wrist strap device, which

should be removed for potential shock reasons prior to

applying power to the unit under test.

2. After removing an electrical assembly equipped with ES

devices, place the assembly on a conductive surface such

as aluminum foil, to prevent electrostatic charge buildup or

exposure of the assembly.

3. Use only a grounded-tip soldering iron to solder or unsolder

ES devices.

4. Use only an anti-static solder removal device. Some

solder removal devices not classified as “anti-static”can

generate electrical charges sufficient to damage ES

devices.

5. Do not use freon-propelled chemicals. These can

generate an electrical charge sufficient to damage ES

devices.

6. Do not remove a replacement ES device from its protec-

tive package until immediately before you are ready to

install it. (Most replacement ES devices are packaged with

leads electrically shorted together by conductive foam,

aluminum foil,or comparable conductive material).

7. Immediately before removing the protective material from

the leads of a replacement ES device, touch the protective

material to the chassis or circuit assembly into which the

device will be installed.

Caution: Be sure no power is applied to the chassis or

circuit, and observe all other safety precautions.

8. Minimize bodily motions when handling unpackaged

replacement ES devices. (Normally harmless motion such

as the brushing together of your clothes fabric or the lifting

of your foot from a carpeted floor can generate static elec-

tricity sufficient to damage an ES device.)

1-5

SPECIFICATIONS

♦CPU [PPC405GP Rev E]

•PowerPC405GP, 32-bit, 200MHz RISC Processor

•I Cache 16K, D Cache 8K

•SDRAM Controller(100MHz speed)

•External Peripheral Bus(up to 8 device)

•PCI 2.2 I/F(32-bit, 33MHz)]

•DMA, Interrupt Controller, Serial Port, GPIO, I2C

♦System Memory

•Main Memory : 32MB(K4S281632 x2)

•Flash Memory : 8MB(MEM29DL323x2)

•NVRAM : EEPROM(32KB, 105 Read/Write)

•Probe ROM : 512KB (Am29LV040)

♦MPEG 2 A/V Decoder [LGDT1102A]

•1 HD(MP@HL) or 4 SD(MP@ML)

•ATSC all format Decoding

•Memory : SDRAM 32MB(K4S641632 x4)

•Graphics

•2D Graphics

•HD Resolution(max. 1080x1920 x16-bit)

•BitBLT/Rendering Cursor Support(by H/W)

•Alpha Blending(6-bit level) Support

•Audio Decoder

•AC-3 Decoding

•MPEG Audio Layer 1, 2 Decoding

•SPDIF Output

♦PLL IC [LGDT1901A]

•HD-2 Video Clock Generation

•27MHz VCXO input & Control Signals

♦System CPLD [EPM7256AETC]

•HD-2 I/F Signal

•Address Decode

•GPIO

♦Audio Processor [MSP4450]

•SIF Processing

•Audio Input Selection

•ADC/DAC

•Volume control

♦Video Decoder [VPX3226F]

•CVBS Decoding

•Video Processing

•656 Data Output

•VBI/CC support

♦DVI Transmitter [Sil170]

•DVI output

•HDCP Support

♦I2C Controller [PCF8584]

•Tuner(ATSC/NTSC/Cable) I/F

•Gemstar I/F

•Front MiCOM I/F

♦TPN-II

•TP Processing for PVR

•PCI I/F

•SDRAM I/F 16MB(K4S641632)

•PVR Function

♦MPEG-2 Encoder [BCM7040]

•MPEG-2 Encoding (MP@ML)

•656/I2S Input, TP output

•SDRAM I/F 16MB(K4S643232)

•PCI I/F

♦E-IDE Controller [ARS0303D]

•PCI I/F

•E-IDE Controller

♦ATSC/NTSC/CableTuner[TDVL-H100P]

•AT/NT/Cable NIM Tuner

•I2C I/F, TP/CVBS/SIF Out

♦Miscellaneous

•RS-232C

•RF Switch

•MiCOM( Timer, Gemstar Tuning)

•Gemstar I/F : Video Input, I2C

♦IEEE-1394[TSB43CA42]

•1394 TP In/Out

•Link&PHY(1-Chip)

♦MUX CPLD [EPM7256AETC]

•1394 TP In/Out

•Encoder TP, VSB TP, TPN-II TP In/Out

♦Gemstar Board

•GS501 : Gemstar Processor

•GS502 : AD Converter

•G-Link

♦Power Board

•Input: AC120V/60Hz

•Output

- Main Board : 9V,5V,3.3V,L_5V,L_33V

- Front Board : -28V,-24V,-21.5V

- HDD : 12V, 5V

♦HDD [?]

•120GB

•Ultra DMA-100

♦Front Panel

•I2C I/F, Power On/Off

•VFD Display

♦Remote Controller

•Basic TV

•PVR Function

System Specifications

1-6

♦Input

•Antenna In : Terrestrial [F Connector]

•Antenna In : Cable [F Connector]

•CVBS Video/Audio-1 [RCA Jack, 3EA]

♦Output

•Video Out

- Component Out : YPbPr [RCA Jack, 3EA]

- Composite Out : CVB S-1 [RCA Jack, 1EA]

- S-Video Out [Mini DIN Jack, 1EA]

•Composite Out : CVBS-2 [RCA Jack, 1EA]

•RGB Out : VGA [D-SUB 15-P, 1EA]

•DVI Out

•Audio Out

- Stereo Out -1 [RCA Jack, 2EA]

- Stereo Out-2 [RCA Jack, 2EA]

- SPDIF Out : Photo Link

•Serial Port

•IEEE-1394 Port [1394 2EA]

♦G-Link

•S/W Up-grade

•IR Blaster

♦Input

•AC120V/60Hz

♦Output

•Main Board : 9V,5V,3.3V,L_5V,L_33V

•Front Board : -28V,-24V,-21.5V

•HDD : 12V, 5V

♦Power Consumption : 35W

♦Main Board Size

•213(D) x317(W) with Dummy[Unit : mm]

•170(D) x317(W) [Unit : mm]

♦Gemstar Board Size

•130(D) x48(W) [Unit: mm]

♦Power Board Size

•247(D) x 93(W) [Unit: mm]

♦Front Panel Board Size

•50(D) x 280(W) [Unit: mm]

♦430(W) x 69(H) x 297(D) [Unit: mm]

♦55(W) x 240(H) x 35(D) [Unit: mm]

In/out Connector Set-Top Box Size

Remote Controller Size

Power

Board Size

1-7

REAR

LOCATION OF CUSTOMER CONTROLS

FRONT

Power Display Window

DISPLAY FORMAT

RECORD

MENU GUIDE

SELECT

EXIT

Remote Control Sensor

Arrow Buttons

@@@@@@@@e?

@@h?

@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e

@@@@@@@@

?@@

?@@@@@@@@

?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@

@@g

@@@@@@@@

ANT IN

S-VIDEO OUT

Fixed “volume”AUDIO OUT (Left/Right) IEEE-1394

AC Power Cord

G-LINK®

AUDIO/VIDEO INPUT 1, 2

VIDEO OUT 1, 2 COMPONENT OUTPUT

DIGITAL AUDIO OUT (OPTICAL)

AUTHORIZED SERVICE ONLY

DVI OUT

@@@@@@@@e?

@@h?

@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e

@@@@@@@@

?@@

?@@@@@@@@

?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@

@@g

@@@@@@@@

Variable “volume”AUDIO OUT (Left/Right) RGB OUT

@@@@@@@@e?

@@h?

@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e

@@@@@@@@

?@@

?@@@@@@@@

?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@

@@g

@@@@@@@@

1-8

REMOTE CONTROL

STB

TV/INPUT/SIGNAL /1394

Numbers

Dash (-)

MUTE

TV GUIDE/BLUE, GREEN/INFO

SYNOPSIS/REPEAT/MENU/EXIT

TIMESHIFT

Arrow Buttons, DRAG + / –,

SKIP + / -/SELECT

VCR Plus+

VOL (Volume) (+/-)

RATIO/AUDIO/CC

PLAY/SLOW/PAUSE/STOP/

RECORD/EDIT

START/ENDREW/FF

PROG. LIST

SURF

CH (Channel) (+/–), PG UP/DN

FLASHBK

SELECT

POWER

MODE INDICATOR

MODE

2-1

SECTION 2

CABINET & MAIN CHASSIS

CONTENTS

EXPLODED VIEWS .....................................................................................................................2-2

1. Cabinet and Main Frame Section ...........................................................................................2-2

2. Packing Accessory Section....................................................................................................2-3

2-2

EXPLODED VIEWS

1. Cabinet and Main Frame Section

300

A44

260

320

265

457

463

250

463

A48

463

A47

A51

A43

280

A50 452

452 271

270

466

465

469

470

271A

271B

BCD

NOTE) Refer to “SECTION 4 REPLACEMENT

PARTS LIST”in order to look for the

part number of each part.

2-3

2. Packing Accessory Section

808 BATTERY

REMOCON

INSTRUCTION ASSEMBLY

PACKING (RF)

BAG

CABLE

PACKING (LF)

BOX CARTON

806

804

803

811

812

820

801

900

802

803

825 DVI CABLE

3-1

SECTION 3

ELECTRICAL

CONTENTS

SYSTEM S/W UP-GRADE......................................3-2

1. UP-GRADE CABLE CONFIGURATION .......3-2

2. CPLD PROGRAM..........................................3-4

3. S/W UP-GRADE ............................................3-9

TEST S/W..............................................................3-11

1. TEST S/W ....................................................3-11

2. DIAGNOSTIC S/W.......................................3-14

GEMSTAR UP-GRADE.........................................3-27

ELECTRICAL TROUBLESHOOTING GUIDE......3-30

1. POWER ON .................................................3-30

2. SYSTEM PART ............................................3-31

3. VIDEO PART-1.............................................3-32

4. YPbPr VIDEO OUTPUT

TROUBLESHOOTING.................................3-33

5. RGB VIDEO OUTPUT

TROUBLESHOOTING.................................3-34

6. CVBS VIDEO OUTPUT

TROUBLESHOOTING.................................3-35

7. AUDIO TROUBLESHOOTING ....................3-36

8. TUNER TROUBLESHOOTING ...................3-37

9. PVR PART TROUBLESHOOTING..............3-38

10. GEMSTER TROUBLESHOOTING............3-39

WAVEFORMS .........................................................-41

1. SYSTEM PART-1 .........................................3-41

2. DIGITAL SYSTEM [SYSTEM MEMORY]

SECTION .....................................................3-43

3. VIDEO PART-1.............................................3-45

4. VIDEO PART-2.............................................3-47

5. AUDIO PART-1 ............................................3-49

6. AUDIO PART-2 ............................................3-51

7. VIDEO IN & DVI OUT ..................................3-53

8. PVR PART-1 ................................................3-55

9. PVR PART-2 ................................................3-57

10. YPbPr, RGB OUT......................................3-59

11. CVBS OUT.................................................3-61

12. 1394 PART.................................................3-63

13. GEMSTAR PART .......................................3-65

BLOCK DIAGRAM ...............................................3-67

1. WIRING DIAGRAM......................................3-67

2. TOTAL BLOCK DIAGRAM..........................3-68

3. SIGNAL PATH DIAGRAM ...........................3-69

CIRCUIT DIAGRAMS ...........................................3-70

1. POWER CIRCUIT DIAGRAM......................3-70

2. CPU CIRCUIT DIAGRAM 1.........................3-72

3. BOOT STRAPPING, CLOCK, CPLD

CIRCUIT DIAGRAM ...................................3-74

4. SYSTEM MEMORY, FLASH, I2C COT

CIRCUIT DIAGRAM.....................................3-76

5. HD-II CIRCUIT DIAGRAM ...........................3-78

6. HD2 MEMORY PLL CIRCUIT DIAGRAM 2 3-80

7. AUDIO PROCESSOR, SPDIF OUT

CIRCUIT DIAGRAM.....................................3-82

8. NTSC DECODER, DVI OUTPUT

CIRCUIT DIAGRAM.....................................3-84

9. TPN-II, MEMORY CIRCUIT DIAGRAM.......3-86

10. MPEG ENCODER & MEMORY

CIRCUIT DIAGRAM ..................................3-88

11. PCI2IDE CONTROLLER CIRCUIT

DIAGRAM ..................................................3-90

12. ATSC/QAM/NTSC NIM TUNER

CIRCUIT DIAGRAM ..................................3-92

13. AUDIO/VIDEO OUT CIRCUIT

DIAGRAM ..................................................3-94

14. 1394 CIRCUIT DIAGRAM .........................3-96

15. MICOM, POWER I/F, FRONT I/F

CIRCUIT DIAGRAM ..................................3-98

16. FRONT CIRCUIT DIAGRAM ...................3-100

17. GEMSTAR CONTROLLER

CIRCUIT DIAGRAM ................................3-102

18. GEMSTAR MEMORY

CIRCUIT DIAGRAM ................................3-104

19. GEMSTAR MICOM, I/F CIRCUIT

DIAGRAM ................................................3-106

PRINTED CIRCUIT DIAGRAMS ........................3-108

1. DIGITAL MAIN PRINTED CIRCUIT

DIAGRAMS(TOP) ......................................3-108

2. DIGITAL MAIN PRINTED CIRCUIT

DIAGRAMS(BOTTOM) ..............................3-110

3. SMPS(POWER) PRINTED CIRCUIT

DIAGRAM ..................................................3-112

4. GEMSTAR PRINTED CIRCUIT

DIAGRAM(TOP).........................................3-114

5. GEMSTAR PRINTED CIRCUIT

DIAGRAM(BOTTOM) ................................3-115

6. KEY PRINTED CIRCUIT DIAGRAM .........3-116

7. TIMER PRINTED CIRCUIT DIAGRAM .....3-116

VOLTAGE MEASURED VALUE .........................3-118

1. ALUMINUM CAPACITOR-1.......................3-118

2. ALUMINUM CAPACITOR-2.......................3-118

3. ALUMINUM CAPACITOR-3.......................3-119

4. ALUMINUM CAPACITOR-4.......................3-121

5. DIODE ........................................................3-121

3-2

- LST-3410A Side

- PC Side

1. UP-GRADE CABLE CONFIGURATION

SERVICE

2: TX

3: RX

1: High

4: +3.3V

5: GND

7: TMS

8: TDO

6: TDI

9: TCK

LST-3410A Service Port

Female Type

2: TX

3: RX

5: GND

4: +3.3V

7: TMS

8: TDO

6: TDI

9: TCK

LST-3410A Service Cable

Male Type

1: TCK 2: GND

3: TDO

4: +3.3V

5: TMS

6: NC

7: NC 8: NC

9: TDI 10: GND

CPLD Program Conn.

Male Type

SYSTEM S/W UP-GRADE

3-3

- Up-grade Cable Connection

- Up-grade Cable Configuration

Male Type

2: TX

3: RX

5: GND

4: +3.3V

7: TMS

8: TDO

6: TDI

9: TCK

Female Type

2: RX

3: TX

5: GND

1: TCK

3: TDO

5: TMS

9: TDI

Male Type

(Top View)

4: +3.3V

SERVICE

RGB/HV

PCPrint Port

Serial Port

3-4

1> Check that the ALTERA Programming hardware is installed.

* Connect the Byte blaster to the parallel port (printer port) of the PC.

2> Run the ALTERA MAX2PLUS.

PC printer port

Programming tool

2. CPLD PROGRAM

3-5

3> Press ‘MAX+plusII’at the main menu and select ‘programmer.’

--> If ‘programmer’is selected, ‘programmer’window is popped up.

3-6

4> Select ‘programming options’of ‘Options’menu.

--> Blank-check before Programming

--> Verify after Programming

5> Select ‘Hardware setup’of ‘Options’menu.

--> programming hardware (ByteBlater)

3-7

6> Select ‘setup’of ‘JTAG’menu.

--> Multi-Device JTAC chain setup (select the file to be programmed)

--> Check that the file to be programmed is properly selected.

3-8

7> The connector of the Byte blaster can be connected to the connector that may be connected to the service

port.

8> Turn on the Digital Board.

9> Run the program by pressing ‘Enter’key.

10>. Check that it is properly programmed.

=> When the program is completed, the green LED of the IC105 is turned ON.

11> Turn off the Digital Board.

PC Printer P ort

Byte Bl aste

Servi ce Port

SERVICE

RGB/HV

9-Pi n D- Sub

Male

Other manuals for LST-3410A

Table of contents

Popular DVR manuals by other brands

Topband

Topband 5000 series user manual

JVC

JVC DR-M10S instructions

360 Vision

360 Vision H Series user manual

Vicon

Vicon Kollector Elite Installation & operation manual

Johnson Controls

Johnson Controls Tyco exacqVision A Series quick start guide

Velleman

Velleman DVR16T2 Quick installation guide

Archos

Archos Gmini 500 Series user manual

dallmeier

dallmeier DMS 240 operating instructions

Electronics123

Electronics123 DVR608 instruction manual

cogeco

cogeco TiVo user guide

Omnivision

Omnivision 16CH H264 DVR user guide

DirecTV

DirecTV Plus HD user guide

TALOS

TALOS DVR Quick reference guide

MISUMI

MISUMI MP-550 manual

Lorex

Lorex LHA2000M Series Quick setup guide

Interlogix

Interlogix TruVision TVR-1116D-2T quick start guide

Dahua

Dahua XVR7416L user manual

Lilin

Lilin DVR304 instruction manual

LG LST-3410A User manual

Popular DVR manuals by other brands
