Dahua XVR7416L User manual

Dahua HDCVI Standalone DVR User’s Manual
Dahua HDCVI Standalone DVR User’s Manual
V1.9.1

i
Table of Contents
1FEATURES AND SPECIFICATIONS .......................................................1
1.1 Overview...................................................................................................................................1
1.2 Features....................................................................................................................................1
1.3 Specifications ...........................................................................................................................2
1.3.1 HCVR5104C Series ...........................................................................................................2
1.3.2 HCVR51XXC-V2 Series ....................................................................................................6
1.3.3 HCVR7104C-V2 Series .....................................................................................................8
1.3.4 HCVR410XC-S2 Series.....................................................................................................9
1.3.5 HCVR510XC-S2 Series...................................................................................................11
1.3.6 HCVR7104C-S2 Series ...................................................................................................12
1.3.7 HCVR2108C-S2 Series ...................................................................................................13
1.3.8 HCVR410XC-S3 Series...................................................................................................15
1.3.9 HCVR510XC-S3 Series...................................................................................................16
1.3.10 HCVR7104C-S3 Series...............................................................................................18
1.3.11HCVR51XXH Series....................................................................................................19
1.3.12 HCVR51XXH-V2 Series..............................................................................................23
1.3.13 HCVR51XXHC Series.................................................................................................25
1.3.14 HCVR51XXHC-V2 Series...........................................................................................29
1.3.15 HCVR51XXHE Series.................................................................................................30
1.3.16 HCVR51HE-V2 Series ................................................................................................34
1.3.17 HCVR71XXH-V2 Series..............................................................................................36
1.3.18 HCVR71XXHC-V2 Series...........................................................................................37
1.3.19 HCVR71XHE-V2 Series..............................................................................................38
1.3.20 HCVR41XXHE-S2 Series...........................................................................................40
1.3.21 HCVR51XXH-S2 Series..............................................................................................41
1.3.22 HCVR51XXHE-S2 Series...........................................................................................43
1.3.23 HCVR710XH-S2 Series..............................................................................................44
1.3.24 HCVR710XHE-S2 Series ...........................................................................................45
1.3.25 HCVR41XXHE-S3 Series...........................................................................................47
1.3.26 HCVR51XXHE-S3 Series...........................................................................................48
1.3.27 HCVR71XXHE-S3 Series...........................................................................................50
1.3.28 HCVR71XXH-S3 Series..............................................................................................52
1.3.29 HCVR41XXHS-S2 Series...........................................................................................54
1.3.30 HCVR21XXHS-S2 Series...........................................................................................56
1.3.31 HCVR21XXHS-S3 Series...........................................................................................57

ii
1.3.32 HCVR41XXHS-S3 Series...........................................................................................58
1.3.33 HCVR51XXHS-S3 Series...........................................................................................60
1.3.34 HCVR71XXHS-S3 Series...........................................................................................62
1.3.35 HCVR52XXA-V2 Series..............................................................................................64
1.3.36 HCVR72XXA-V2 Series..............................................................................................65
1.3.37 HCVR42XXA-S2/4216AN-S2 Series........................................................................66
1.3.38 HCVR4224/4232AN-S2 Series..................................................................................67
1.3.39 HCVR52XXA-S2/HCVR5216AN-S2 Series.............................................................69
1.3.40 HCVR720XA-S2 Series ..............................................................................................70
1.3.41 HCVR42XXA-S3 Series..............................................................................................72
1.3.42 HCVR42XXAN-S3 Series...........................................................................................74
1.3.43 HCVR52XXA-S3 Series..............................................................................................76
1.3.44 HCVR52XXAN-S3 Series...........................................................................................78
1.3.45 HCVR72XXA-S3/HCVR7216AN-S3 Series.............................................................79
1.3.46 HCVR52XXL-V2 Series ..............................................................................................82
1.3.47 HCVR54XXL-V2 Series ..............................................................................................83
1.3.48 HCVR4224/32L-S2 Series..........................................................................................85
1.3.49 HCVR44XXL-S2 Series ..............................................................................................86
1.3.50 HCVR48XXS-S2 Series..............................................................................................89
1.3.51 HCVR58XXS-V2 Series..............................................................................................92
1.3.52 HCVR71XXH-4M Series.............................................................................................93
1.3.53 HCVR72XXAN-4M Series ..........................................................................................95
1.3.54 XVR410XC Series .......................................................................................................97
1.3.55 XVR510XC Series .......................................................................................................98
1.3.56 XVR7104C Series......................................................................................................100
1.3.57 XVR41XXHE Series ..................................................................................................101
1.3.58 XVR51XXH Series.....................................................................................................103
1.3.59 XVR51XXHE Series ..................................................................................................105
1.3.60 XVR71XXHE Series ..................................................................................................107
1.3.61 XVR71XXH Series.....................................................................................................109
1.3.62 XVR21XXHS Series ..................................................................................................111
1.3.63 XVR41XXHS Series ..................................................................................................113
1.3.64 XVR51XXHS Series ..................................................................................................114
1.3.65 XVR7104HS Series...................................................................................................116
1.3.66 XVR42XXA Series.....................................................................................................118
1.3.67 XVR42XXAN Series ..................................................................................................120
1.3.68 XVR52XXA Series.....................................................................................................122
1.3.69 XVR52XXAN Series ..................................................................................................124
1.3.70 XVR72XXA Series.....................................................................................................126
1.3.71 XVR72XXAN Series ..................................................................................................128
1.3.72 XVR54XXL Series......................................................................................................130
1.3.73 XVR74XXL Series......................................................................................................132
1.3.74 XVR58XXS Series.....................................................................................................134
1.3.75 XVR78XXS Series.....................................................................................................136

iii
2OVERVIEW AND CONTROLS.............................................................139
2.1 Front Panel ...........................................................................................................................139
2.1.1 HCVR5104C/HCVR51XXC-V2/HCVR71XXC-V2/ HCVR4104/4108C-S2/
HCVR5104 5108C-S2/ HCVR7104C-S2/ HCVR2108C-S2/
HCVR410XC-S3/HCVR510XC-S3/7104C-S3/ XVR410XC/XVR510XC/7104C Series.....139
2.1.2 HCVR51XXH/HCVR51XXHE/ HCVR51XXH-V2 /
HCVR51XXHE-V2/HCVR71XXH-V2 / HCVR71XXHE-V2 Series.........................................139
2.1.3 HCVR51XXHC/ HCVR51XXHC-V2/ HCVR71XXHC-V2 Series..............................140
2.1.4 HCVR41XXHE-S2/ HCVR51XXH-S2/ HCVR51XXHE-S2/ HCVR710XH-S2/
HCVR710XHE-S2/
HCVR41XXHE-S3/HCVR51XXHE-S3/HCVR71XXH-S3/HCVR71XXHE-S3
/HCVR41XXHS-S2/ HCVR21XXHS-S2/
HCVR21XXHS-S3/HCVR41XXHS-S3/51XXHS-S3/7104HS-S3/
XVR41XXHE/XVR51H/XVR51XXHE/XVR71XXH/XVR71XXHE /HCVR41XXHS-S2/
HCVR21XXHS-S2/ XVR21XXHS/XVR41XXHS/51XXHS/7104HS/HCVR71XX-4M Series
141
2.1.5 HCVR52XXA-V2/ HCVR72XXA-V2 Series.................................................................142
2.1.6 HCVR42XXA-S2/ HCVR42XXAN-S2/ HCVR52XXA-S2/
HCVR5216AN-S2/HCVR720XA-S2/
HCVR42XXA-S3/HCVR42XXAN-S3/HCVR52XXA-S3/HCVR52XXAN-S3/HCVR72XXA-S3
/HCVR7216AN-S3/XVR42XXA/XVR42XXAN/XVR52XXA/XVR52XXAN/XVR72XXA/XVR7
216AN/HCVR 72XXAN-4M Series.............................................................................................143
2.1.7 HCVR42XXL-S2/HCVR44XXL-S2/ XVR54XXL/ XVR74XXL Series......................144
2.1.8 HCVR52XXL-V2/ HCVR54XXL-V2 Series..................................................................145
2.1.9 HCVR58XXS-V2 Series.................................................................................................146
2.1.10 HCVR48XXS-S2/ XVR58XXS/ XVR78XXS Series ..............................................149
2.2 Rear Panel............................................................................................................................149
2.2.1 HCVR5104C Series .......................................................................................................149
2.2.2 HCVR5104C-V2/HCVR5108C-V2 Series...................................................................150
2.2.3 HCVR7104C-V2 Series .................................................................................................152
2.2.4 HCVR4104/HCVR4108C-S2/HCVR2108C-S2 Series..............................................153
2.2.5 HCVR5104/5108C-S2 Series .......................................................................................154
2.2.6 HCVR7104C-S2 Series .................................................................................................155
2.2.7 HCVR410XC-S3/HCVR510XC-S3/7104C-S3/XVR410XC/XVR510XC/7104C
Series 156
2.2.8 HCVR5104H/HCVR5108H Series ...............................................................................158
2.2.9 HCVR5104H-V2/HCVR5108H-V2/HCVR5116H-V2 Series.....................................159
2.2.10 HCVR5104HC/HCVR5108HC Series.....................................................................161
2.2.11 HCVR5104HC-V2/HCVR5108HC-V2/HCVR5116HC-V2 Series........................162
2.2.12 HCVR5104HE/HCVR5108HE Series .....................................................................164

iv
2.2.13 HCVR5104HE-V2/HCVR5108HE-V2/HCVR5116HE-V2 Series........................165
2.2.14 HCVR7104H-V2/HCVR7108H-V2 Series ..............................................................167
2.2.15 HCVR7104HC-V2/HCVR7108HC-V2 Series.........................................................169
2.2.16 HCVR7104HE-V2/HCVR7108HE-V2 Series.........................................................170
2.2.17 HCVR4104/4108/4116HE-S2 Series......................................................................172
2.2.18 HCVR5104/5108/5116H-S2 Series.........................................................................174
2.2.19 HCVR5104/5108/5116HE-S2 Series......................................................................176
2.2.20 HCVR7104/7108H-S2 Series...................................................................................178
2.2.21 HCVR7104/7108HE-S2 Series................................................................................180
2.2.22 HCVR41XXHE-S3/HCVR51XXHE-S3/HCVR71XXH-S3/HCVR71XXHE-S3
/XVR41XXHE/XVR51XXH/XVR51XXHE/XVR71XXH/XVR71XXHE Series........................181
2.2.23 HCVR41XXHS-S2/ HCVR2108HS-S2/ HCVR2116HS-S2 Series.....................183
2.2.24 HCVR21XXHS-S3/HCVR41XXHS-S3/51XXHS-S3/7104HS-S3
/XVR21XXHS/XVR41XXHS/51XXHS/7104HS Series............................................................185
2.2.25 HCVR52XXA-V2/ HCVR72XXA-V2 Series............................................................187
2.2.26 HCVR42XXA-S2/ HCVR4216AN-S2 Series..........................................................188
2.2.27 HCVR4224/HCVR4232AN-S2 Series.....................................................................191
2.2.28 HCVR52XXA-S2/ HCVR5216AN-S2 Series..........................................................192
2.2.29 HCVR720XA-S2 Series ............................................................................................194
2.2.30
HCVR42XXA-S3/HCVR42XXAN-S3/HCVR52XXA-S3/HCVR52XXAN-S3/HCVR
72XXA-S3/HCVR7216AN-S3/XVR42XXA/XVR42XXAN/XVR52XXA/XVR52XXAN/XVR72X
XA/XVR7216AN Series................................................................................................................195
2.2.31 HCVR52XXL-V2/ HCVR54XXL-V2/HCVR44L-S2 Series....................................197
2.2.32 HCVR42XXL-S2 Series ............................................................................................200
2.2.33 HCVR58XXS-V2/HCVR48XXS-S2 Series.............................................................202
2.2.34 HCVR71XXH-4M Series...........................................................................................205
2.2.35 HCVR72XXAN-4M Series ........................................................................................207
2.2.36 XVR54XXL/ XVR74XXL Series ...............................................................................208
2.2.37 XVR58XXS/ XVR78XXS Series ..............................................................................216
2.3 Connection Sample.............................................................................................................221
2.3.1 Smart Box Series............................................................................................................222
2.3.2 Smart 1U Series..............................................................................................................222
2.3.3 Compact 1U Series ........................................................................................................223
2.3.4 Mini 1U Series.................................................................................................................224
2.3.5 1U Series .........................................................................................................................224
2.3.6 1.5U Series......................................................................................................................225
2.3.7 2U Series .........................................................................................................................226
2.4 Remote Control....................................................................................................................227

v
2.5 Mouse Control......................................................................................................................229
2.6 Virtual Keyboard & Front Panel.........................................................................................231
2.6.1 Virtual Keyboard .............................................................................................................231
2.6.2 Front Panel......................................................................................................................231
3INSTALLATION AND CONNECTIONS ................................................232
3.1 Check Unpacked DVR........................................................................................................232
3.2 About Front Panel and Rear Panel...................................................................................232
3.3 HDD Installation...................................................................................................................232
3.3.1 Smart Box Series............................................................................................................232
3.3.2 Smart 1U Series..............................................................................................................233
3.3.3 Compact 1U and Mini 1U Series..................................................................................234
3.3.4 The 1U Series .................................................................................................................235
3.3.5 The 1.5U Series..............................................................................................................236
3.3.6 The 2U Series .................................................................................................................237
3.3.7 Rack Installation..............................................................................................................237
3.4 Connecting Power Supply..................................................................................................238
3.5 Connecting Video Input and Output Devices ..................................................................238
3.5.1 Connecting Video Input..................................................................................................238
3.5.2 Connecting Video Output ..............................................................................................238
3.6 Connecting Audio Input & Output, Bidirectional Audio ..................................................239
3.6.1 Audio Input.......................................................................................................................239
3.6.2 Audio Output....................................................................................................................239
3.7 Alarm Input and Output Connection .................................................................................239
3.7.1 Alarm Input and Output Details ....................................................................................240
3.7.2 Alarm Input Port..............................................................................................................241
3.7.3 Alarm Output Port...........................................................................................................241

vi
3.8 RS485 ...................................................................................................................................242
3.9 Other Interfaces ...................................................................................................................242
4OVERVIEW OF NAVIGATION AND CONTROLS ................................243
4.1 Boot up and Shutdown .......................................................................................................243
4.1.1 Boot up.............................................................................................................................243
4.1.2 Shutdown.........................................................................................................................243
4.1.3 Auto Resume after Power Failure................................................................................243
4.1.4 Replace Button Battery..................................................................................................243
4.2 Set/Reset Password............................................................................................................243
4.2.1 Set Password ..................................................................................................................244
4.2.2 Reset Password..............................................................................................................245
4.3 Startup Wizard .....................................................................................................................245
4.4 Live Viewing .........................................................................................................................251
4.5 Right-Click Menu .................................................................................................................253
4.5.1 Window Switch................................................................................................................254
4.5.2 Previous Screen/Next Screen.......................................................................................255
4.5.3 PTZ Control .....................................................................................................................255
4.5.4 Auto Focus.......................................................................................................................260
4.5.5 Color.................................................................................................................................260
4.5.6 Display..............................................................................................................................262
4.5.7 Face Search ....................................................................................................................263
4.5.8 Search..............................................................................................................................263
4.5.9 Record Control................................................................................................................263
4.5.10 Alarm Output...............................................................................................................263
4.5.11 Remote Device...........................................................................................................263
4.5.12 Video Matrix................................................................................................................263
4.5.13 Main menu ..................................................................................................................263
4.6 Navigation Bar .....................................................................................................................263
4.6.1 Main Menu.......................................................................................................................264

vii
4.6.2 Output Screen.................................................................................................................264
4.6.3 Previous/Next Screen ....................................................................................................264
4.6.4 Tour...................................................................................................................................264
4.6.5 Favorites ..........................................................................................................................264
4.6.6 Channel............................................................................................................................264
4.6.7 PTZ...................................................................................................................................264
4.6.8 Color.................................................................................................................................264
4.6.9 Search..............................................................................................................................264
4.6.10 Alarm Status ...............................................................................................................264
4.6.11 Channel Info ...............................................................................................................265
4.6.12 Remote Device...........................................................................................................265
4.6.13 Network .......................................................................................................................265
4.6.14 HDD Manager.............................................................................................................265
4.6.15 USB Manager.............................................................................................................265
4.7 USB Device Auto Pop-up...................................................................................................266
4.8 Main Menu............................................................................................................................266
4.9 Operation ..............................................................................................................................267
4.9.1 Search..............................................................................................................................267
4.9.2 Human Face Search ......................................................................................................276
4.9.3 Backup..............................................................................................................................277
4.9.4 Shut Down .......................................................................................................................279
4.10 Information............................................................................................................................280
4.10.1 System Info.................................................................................................................280
4.10.2 Event............................................................................................................................286
4.10.3 Network .......................................................................................................................287
4.10.4 Log ...............................................................................................................................289
4.11 Setting ...................................................................................................................................291
4.11.1 Camera........................................................................................................................291
4.11.2 Network .......................................................................................................................309
4.11.3 Event............................................................................................................................329
4.11.4 Storage........................................................................................................................360
4.11.5 System.........................................................................................................................373
5WEB OPERATION ...............................................................................399

viii
5.1 Network Connection............................................................................................................399
5.2 Login......................................................................................................................................399
5.3 LAN Mode.............................................................................................................................401
5.4 Real-time Monitor ................................................................................................................403
5.5 PTZ ........................................................................................................................................404
5.6 Image/Relay-out ..................................................................................................................405
5.6.1 Image................................................................................................................................405
5.6.2 Relay output ....................................................................................................................406
5.7 WAN Login ...........................................................................................................................406
5.8 Setup .....................................................................................................................................407
5.8.1 Camera.............................................................................................................................407
5.8.2 Network............................................................................................................................417
5.8.3 Event.................................................................................................................................433
5.8.4 Storage.............................................................................................................................454
5.8.5 Setting ..............................................................................................................................458
5.9 Information............................................................................................................................476
5.9.1 Version .............................................................................................................................476
5.9.2 Log....................................................................................................................................477
5.9.3 Online User......................................................................................................................478
5.9.4 HDD..................................................................................................................................478
5.10 Playback ...............................................................................................................................478
5.10.1 Search Record............................................................................................................479
5.10.2 File List ........................................................................................................................480
5.10.3 Playback......................................................................................................................481
5.10.4 Download ....................................................................................................................481
5.10.5 Load more...................................................................................................................482

ix
5.11 Face Search .........................................................................................................................484
5.12 Alarm .....................................................................................................................................485
5.13 Log out ..................................................................................................................................486
5.14 Un-install Web Control........................................................................................................487
6PROFESSIONAL SURVEILLANCE SYSTEM......................................488
7FAQ ......................................................................................................489
APPENDIX A HDD CAPACITY CALCULATION .......................................497
APPENDIX B COMPATIBLE BACKUP DEVICES.......................................499
Appendix B-1 Compatible USB list...............................................................................................499
Appendix B-2 Compatible SD Card list.......................................................................................500
Appendix B-3 Compatible Portable HDD list..............................................................................500
Appendix B-4 Compatible USB DVD List ...................................................................................500
Appendix B-5 Compatible SATA DVD List..................................................................................500
Appendix B-6 Compatible SATA HDD List.................................................................................501
APPENDIX C COMPATIBLE CD/DVD BURNER LIST.............................505

x
APPENDIX D COMPATIBLE DISPLAYER LIST .......................................506
APPENDIX E COMPATIBLE SWITCHER ...................................................507
APPENDIX F COMPATIBLE WIRELESS MOUSE LIST...........................508
APPENDIX G EARTHING ........................................................................509

xi
Welcome
Thank you for purchasing our HDCVI DVR!
This user’s manual is designed to be a reference tool for the installation and operation of
your system.
Here you can find information about this series standalone DVR features and functions, as
well as a detailed menu tree.
Before installation and operation please read the following safeguards and warnings
carefully!

xii
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
The product must be grounded to reduce the risk of electric shock.
We assume no liability or responsibility for all the fires or electrical shock caused by
improper handling or installation.
2．Transportation security
Heavy stress, violent vibration or water splash are not allowed during transportation,
storage and installation.
3．Installation
Keep upwards. Handle with care.
Do not apply power to the DVR before completing installation.
Do not place objects on the DVR.
4．Qualified engineers needed
All the examination and repair work should be done by the qualified service engineers.
We are not liable for any problems caused by unauthorized modifications or attempted
repair.
5．Environment
The DVR should be installed in a cool, dry place away from direct sunlight, inflammable,
explosive substances and etc.
6. Accessories
Be sure to use all the accessories recommended by manufacturer.
Before installation, please open the package and check all the components are included.
Contact your local retailer ASAP if something is broken in your package.
7. Lithium battery
Improper battery use may result in fire, explosion, or personal injury!
When replace the battery, please make sure you are using the same model!
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
CAUTION
FOR YOUR OWN SAFETY, PLEASE CHANGE SYSTEM DEFAULT PASSWORD
AFTER YOU FIRST LOGIN!

1
1FEATURES AND SPECIFICATIONS
1.1 Overview
The standalone series DVR is an excellent digital monitor product designed for security
field.
It adopts embedded Linux OS to maintain reliable operation. Popular H.264 compression
algorithm and G.711 audio compression technology realize high quality, low bit stream.
Unique frame by frame play function is suitable for detailed analysis. It has various
functions such as record, playback, monitor at the same time and can guarantee audio
video synchronization. This series product has advanced technology and strong network
data transmission function.
This series device adopts embedded design to achieve high security and reliability. It can
work in the local end, and at the same time, when connecting it to the professional
surveillance software (PSS), it can connect to the security network to realize strong
network and remote monitor function.
This series product can be widely used in various areas such as banking,
telecommunication, electric power, interrogation, transportation, intelligent resident zone,
factory, warehouse, resources, and water conservancy.
1.2 Features
This series product has the following features:
Real-time surveillance
Support VGA port and HDMI port. Realize the surveillance through displayer. Support
HDMI, VGA, and TV output at the same time.
Storage function
Special data format to guarantee data security and can remove the risk of the vicious data
modification. Support digital watermark.
Compression format
Support multiple-channel audio and video. An independent hardware decodes the audio
and video signal from each channel to maintain video and audio synchronization.
Backup function
Support backup operation via USB port (such as U disk, portable HDD, burner)
Client-end user can download the file to local HDD to backup via network.
Record & playback function

2
Support each channel real-time record independently, and at the same time it can support
search, forward play, network monitor, record search, download and etc.
Support various playback modes: slow play, fast play, backward play and frame by frame
play.
Support time title overlay so that you can view event accurate occurred time
Support customized zoom function during the preview.
Network operation
Support network remote real-time monitor, remote record search and remote PTZ control.
Alarm activation function
Several relay alarm outputs to realize alarm activation and on-site light control.
The alarm input port and output has the protection circuit to guarantee device safety.
Communication port
RS485 port can realize alarm input and PTZ control.
RS232 port can connect to keyboard to realize central control, and can also connect to PC
COM to upgrade system and realize maintenance, and matrix control.
Standard Ethernet port can realize network access function.
The dual-network port has the multiple-access, fault-tolerance, load-balance setup mode.
PTZ control
Support PTZ decoder via RS485.
Intelligent operation
Mouse operation function
In the menu, support copy and paste setup function
UPNP (Universal Plug and Play)
Establish mapping connection between LAN and WAN via UPNP protocol.
Slight function differences may be found due to different series.
1.3 Specifications
1.3.1 HCVR5104C Series
Parameter
HCVR5104C
System
Main
Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
System
Resources
Multiplex operations: Multiple-channel record, multiple-channel playback
and network operation simultaneously
Interface
User-friendly graphical user interface

3
Input
Devices
USB mouse
Input
Method
Arabic number, English character, donation and extension Chinese
(optional)
Shortcut
Function
Copy/paste operation, USB mouse right-key shortcut menu, double click
USB mouse to switch screen.
Compression
Standard
Video
Compressio
n
H.264
Audio
Compressio
n
G711A, G711U, PCM
Video monitor
Video Input
4-CH composite video input: (NTSC/PAL) BNC (1.0VBP- P, B75Ω)
Video
Output
1-ch VGA output.
1-ch HDMI output.
Support VGA/HDMI video output at the same time.
Video
Standard
Support PAL/NTSC.
Record
Speed
Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s per
channel
Video
Partition
1/4 windows(Optional)
Monitor
Touring
Support monitor tour functions such as motion detection, and schedule
auto control.
Resolution
(PAL/NTSC)
PAL/NTSC
Real-time monitor：
720P 1280*720
Playback：
All-ch: 720P 1280*720, 960H 960 ×576/960×480, D1
704×576/704×480, HD1 352×576/352×480, 2CIF 704×288/704×240,
CIF 352×288/ 352×240 , QCIF 176×144/176×120
Support dual streams: extra stream resolution CIF 352×288/ 352×240,
QCIF 176×144/176×120.
Quality
6-level image quality (Adjustable)
Privacy
mask
Support one privacy mask of user-defined size in full screen.
Support max 4 zones.
Information
Channel information, time information and privacy mask zone.
TV Adjust
Adjust TV output zone suitable to anamorphic video.

4
Channel
Lock
Cover secret channel with black screen though system is encoding
normally.
Screen-lock function to prevent unauthorized user seeing secret video.
Channel
Information
Channel name, recording status, screen lock status, video loss status and
motion detection status are shown on the bottom left of display screen.
Color
Configuratio
n
Hue, brightness, contrast, saturation and gain setup for each channel.
Audio
Audio Input
N/A
Audio
Output
N/A
Bidirectional
Audio
N/A
Hard disk
Hard Disk
1 built-in SATA port. Support 1 HDD.
One HDD
Space
4T
Hard Disk
Occupation
Audio：PCM 28.8MByte/h
Video：56-900MByte/h
Record and
playback
Recording
Mode
Manual recording, motion detection recording, schedule recording and
alarm recording
Priority: Manual recording> alarm recording>motion detection
recording>schedule recording.
Storage
Mode
Support channel record quota setup
Recording
Length
1 to 120 minutes single record duration (Default setup is 60 minutes)
Playback
Repeat Way
When hard disk is full, system can overwrite previous video file.
Record
Search
Various search engines such as time, type and channel.
Playback
Mode
Various fast play, slow play speeds, manual frame by frame playback and
reverse play mode.
Various File
Switch
Ways
Can switch to previous or next file or any file in current play list.
Can switch to file on other channel of the same time. (If there is a file)
Support file continuous play, when a file is end system auto plays the next
file in the current channel
Playback
Way
Support mark playback
Multi-chann
el Playback
There is 1/4-channel playback mode.
Window
Zoom
Switch between self-adaptive screen/full screen when playback

5
Partial
Enlargemen
t
When in one-window full-screen playback mode, you can select any zone
to activate partial enlargement function.
Backup
function
Backup
Mode
HDD backup
Support peripheral USB backup device. (Flash disk, portable disk and
etc.)
Support peripheral USB burner.
Support network download and save
Network
Function
Network
control
View monitor channel remotely.
DVR configuration through client-end and web browser
Upgrade via client or browser to realize remote maintenance.
View alarm information such as motion detection and video loss via client.
Support network PTZ lens control
File download backup and playback
Multiple devices share information via corresponding software such as
professional surveillance software (PSS)
Duplex transparent COM
Network alarm input and output
Zero-channel encoding
Bidirectional audio.
Motion
Detection and
Alarm
Motion
Detection
Zone setup: support 396((PAL 22×18, NTSC 22×15)) detection zones.
Various sensitivity levels.
Alarm can activate record or external alarm or screen message prompt.
Video Loss
Alarm can activate screen message prompt.
External
Alarm
N/A
Manual
Alarm
Control
N/A
Alarm Input
N/A
Alarm
Output
N/A
Alarm Relay
N/A
Interface
USB
Interface
2 USB 2.0 port.
Network
connection
1 RJ45 10M/100M self-adaptable Ethernet port
RS485
N/A
RS232
N/A
System
Information
Hard Disk
Information
Display HDD current status

6
Data
Stream
Statistics
Data stream statistics for each channel (in wave mode)
Log
statistics
Backup to 1024 log files.
Support various search engines such as time and type.
Version
Display version information: channel amount, system version and release
date.
On-line user
Display current on-line user
User
Management
User
Manageme
nt
Multi-lever user management; various management modes
Integrated management for local user, serial port user and network user.
Configurable user power.
Support user /group and its corresponding rights modification.
No limit to the user or group amount.
Password
Authenticati
on
Password modification
Administrator can modify other user’s password.
Account lock strategy
Five times login failure in thirty minutes may result in account lock.
Upgrade
Web browser, client-end and update tool.
Login, Logout and Shutdown
Password login protection to guarantee safety
User-friendly interface when login. Provide the following options: Logout
/shutdown/ restart.
Right authentication when shut down to make sure only those proper
people can turn off DVR
General
Parameter
Power
DC 12V
Power
Consumptio
n
≤15W (With adapter, no HDD)
Working
Temperatur
e
-10℃－＋55℃
Working
Humidity
10%－90%
Air Pressure
86kpa－106kpa
Dimension
SMART 1U case 270(W) x205 (D) x41mm(H)
Weight
1.25KG(no HDD)
Installation
Mode
Desktop installation
1.3.2 HCVR51XXC-V2 Series
Parameters
HCVR5104C-V2
HCVR5108C-V2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX

7
Parameters
HCVR5104C-V2
HCVR5108C-V2
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
720P/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
PAL:1~25f/s；NTSC：1~30f/s
Video Bit Rate
1536Kbps-4096Kbps，
For 720P: default setup is 2Mbps，max supports 4Mbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel，BNC port
8-channel，BNC port
Network Video
Input
N/A
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGAvideo output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
N/A
Audio Output
N/A
Bidirectional
Talk Input
N/A
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel playback
Max 8-channel playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD Space
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
N/A
USB
2 USB ports
Others
Power
DC12V
Power
≤15W（With power adapter, no HDD）
