AVALON H
User Manual


AVALON H |Gt

G
G
G

Preface
i
Preface
We sincerely appreciate your choice to purchase Avalon products. Avalon Security
operates on the principle that our customers deserve strong, reliable security
products with an emphasis on value.
This is the user and installation guide for the Avalon-H series Legacy Series
embedded DVR.
Please read this manual carefully before you begin using the DVR.
We recommend retaining this manual in a location that can be easily located by the
operator of the system.
Copyright© 360 Vision Technology, Avalon.
No reproduction of any part may take place without the written permission of 360
Vision Technology in accordance with copyright policy.
AVALON H 5004/5008/5016 is 360 Vision Technology's trade mark.
The logo of the AVALON H series and that of Avalon is a trademark of 360 Vision
Technology Company limited.
Ethernet is a trade mark of Xerox Corporation.
Microsoft, MS -DOS, the Windows logo, Windows and Windows NT. used in the USA
and other countries is a trade mark of Microsoft Corporation.
xThe manufacturer, importer and agent shall not be responsible for accidental
damage - including injury - and other damage caused by inappropriate use or
operation of this product.
xThis manual has been made for use with the Avalon-H.
x360 Vision Technology (Avalon) does its best to provide accurate information but
cannot be held responsible for typos or mistakes. Information contained in this
document is subject to change without prior notice.

AVALON H User Manual
ii

Caution
iii
AVALON H User Manual
This is an operating manual for use with the Avalon H product.
All graphical and technical descriptions are given on the basis of
Avalon H
Caution
We strongly recommend that users read all safety cautions carefully before operating
the product, and operate the product appropriately.
Since the indicated cautions contain critical safety information, they must be fully
complied with.
Danger Risk of death or serious injury. This is the highest priority danger warning.
Warning Risk of serious or lesser degree of injury. May also cause damage to the
product or to property.
Caution Risk of minor injury or damage.
Important
Requirements or limitations regarding operation. Users are recommended
to read the relevant details carefully so as to operate the product properly
and without harm.
The above cautions indicate the degree of danger or injury that may occur due to
inappropriate use of the Avalon H

AVALON H User Manual
iv
Do not score, bend, twist, pull or heat the
power cord. Damage to the power cord
may lead to fire and electric shock.
#
Do not remove the top casing of the
product. Doing so may result in electric
shock. If internal examination and
maintenance are deemed necessary,
contact the authorized system vendors or
installers.
Do not place heavy objects on top of the
power cord. Damage to the power cord
may result in fire and electric shock.
Do not place containers with liquid or small
metal objects on top of the product. Liquid
or small metal objects getting into the unit
may lead to fire and electric shock.
#
Please connect the power cord only to the
type of AC outlet indicated in the manual
or product specification. If connected to
other types of power outlet, fire and
electric shock may result.
Do not expose the product to moisture
and dampness. Doing so may result in fire
and electric shock.

 
͵ΒΟΘΖΣ


Non-compliance may result in death or serious injury.
These messages contain the highest degree of importance.


























y
ers
.

Caution
v
Do not modify the product in any way.
Doing so may lead to fire and electric
shock.
In case of lightning, immediately turn off
the power switch and remove the power
cord from the power outlet. Failure to do so
may result in fire and electric shock.
Do not touch the product with wet hands.
Doing so may result in electric shock.

#
Please use only the correct voltage with
the product. Use of incorrect power voltage
may result in fire and electric shock.
#
If the product is dropped or damaged, turn
off the power switch and remove the power
cord from the power outlet. Continued
operation of the product may result in fire
and electric shock.
#
In case of smoke or burning odor,
immediately turn off the power switch and
remove the power cord from the power
outlet. Continued operation of the product
may result in fire and electric shock.
#


 

AVALON H User Manual
vi
Do not leave the power cord or other
cables in passageways or walkways.
Passers-by may trip and fall.
Avoid contact with water or beverages.
Contact with water or beverages may
result in damage that cannot be repaired.
#
Excessive current from the product and the
camera may result in an electric shock.
Connect the power cord to an external
device only when the products themselves
are disconnected from their power supply.

ΈΒΣΟΚΟΘ
Non-compliance may result in a serious or lesser degree of
injury. It may also cause damage to the product or to property.



































Caution
vii
If a foreign substance is stuck to the
product, remove it using a soft cloth or
tissue. Do not use chemical agents
(thinner, solvent, etc.) to remove the
substance.
#
Do not place credit cards/telephone
cards/bank account books/tickets and
other objects with magnetic properties near
the product.
#
Static electricity may cause damage to the
internal parts of the product. Please
remove static electricity from your body
before touching the rear panel and internal
electronic parts of the product.
.
If this product is damaged beyond repair or
reaches its maximum service life, dispose
of it in compliance with local laws and
regulations regarding the disposal of lead
and plastic waste.
Do not operate or store the product in the
following places:
-An area that is either too cold or too hot.
- An area of high humidity, or in front of an
air-conditioner, or in places subject to
sudden temperature changes.
-An area where there is excessive dust.
- Areas where heat from the product
cannot be emitted through both of the
product's side ventilation openings.
#

ʹΒΦΥΚΠΟ
Non-compliance may result in minor injury or damage.
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G
G

.

AVALON H User Manual
viii
Since the product is designed to record
video data on the hard disk, an error in the
hard disk or other miscellaneous errors
might prevent the product from recording
properly. Periodic maintenance is required
for proper operation of the product
#
The product is designed for users to
configure their own interface. However a
user configuration error could lead to
operation malfunction. This product should
be set up by certified installers
only.
#
Since the product is connected - and tightly
coupled - to exterior accessories (camera,
sensor, LAN,Hard Disk, etc.), there is a risk
of malfunction from external causes.
Ensure periodic maintenance by the
certified installers
#
The product may not work properly if the
power source is unstable or/and if electric
shock occurs.Make sure the correct rated
power is available.
The product is designed to be proof
against electric power failures; however,
damage may occur as a result of power
failure. Current data may be damaged or
data might not be recorded. Make sure to
use an Uninterruptible Power Supply
(UPS).
In this product, 1 Kbyte equals 1,024 bytes,
1 Mbyte equals 1,024,000 bytes and 1
Gbyte equals 1,024,000,000 bytes.
#

Important Denotes requirements and limitations in operation. Users are
recommended to read the relevant details carefully so as to
operate the product properly and without harm.

x



᭓Ⳓ
ix

Wdeoh#ri#frqwhqwv#
Preface ...............................................................................................................................i
Copyright / Certifications / Registered Trademark / Terms of Use ....................................i
AVALON H User Manual...................................................................................................ii
Caution ..............................................................................................................................ii
Table of contents..............................................................................................................vi
Chapter 1 Introduction and Installation of AVALON H.................................................. 1-1
1. About AVALON H .................................................................................. 1-3
2. AVALON H Specification ....................................................................... 1-4
3. System Diagram .................................................................................... 1-5
4. Components........................................................................................... 1-6
Chapter 2 Start AVALON H........................................................................................... 2-1
1. AVALON H Outlook ............................................................................... 2-3
(1) Front Design.................................................................................... 2-3
(2) Rear panel and connection locations............................................ 2-10
(3) Remote controller.......................................................................... 2-12
2. How to Install........................................................................................ 2-14
(1) Installation..................................................................................... 2-14
(2) Replace CMOS battery................................................................. 2-20
Chapter 3 Operating AVALON H................................................................................... 3-1
1. Log In ..................................................................................................... 3-3
2. Live Mode............................................................................................... 3-4
(1) Select a Channel............................................................................. 3-4
(2) Icon ................................................................................................. 3-5
(3) Pop Up Menu.................................................................................. 3-7
3. PTZ ...................................................................................................... 3-10

AVALON H User Manual
x
4. Search.................................................................................................. 3-12
(1) Simple Searc................................................................................. 3-12
(2) Quick backup in playback ............................................................. 3-13
(3) Calendar Search........................................................................... 3-14
(4) Event Log...................................................................................... 3-15
(5) Jump to First saved data............................................................... 3-16
(6) Jump to Last saved data............................................................... 3-16
(7) DST (Daylight Saving Time) ......................................................... 3-17
(8) System log .................................................................................... 3-18
Chapter 4 AVALON H SETUP ...................................................................................... 4-1
1. Setup Menu............................................................................................ 4-3
(1) About Setup .................................................................................... 4-3
2. System Setup......................................................................................... 4-4
(1) System configuration ...................................................................... 4-5
(2) Disk Configuration......................................................................... 4-10
(3) User configuration......................................................................... 4-11
(4) Configuration................................................................................. 4-13
(5) Shutdown...................................................................................... 4-13
3. Camera ............................................................................................... 4-14
(1) Camera Configuration................................................................... 4-14
(2) PTZ Configuration......................................................................... 4-15
(3) Spot/Sequence configuration........................................................ 4-16
(4) Monitor Configuration.................................................................... 4-17
4. Record ................................................................................................ 4-18
(1) Record Configuration.................................................................... 4-18
(2) Motion/Event configuration ........................................................... 4-25
5. Network................................................................................................ 4-29
(1) Network configuration ................................................................... 4-29
(2) Serial Configuration ...................................................................... 4-31
(3) E-mail server................................................................................. 4-32

᭓Ⳓ
xi
6. Information ......................................................................................... 4-33
(1) System Log................................................................................... 4-33
(2) System status .............................................................................. 4-34
(3) Version ........................................................................................ 4-36
7. Quick Setup ........................................................................................ 4-37
8. Backup ............................................................................................... 4-39
(1) Backup.......................................................................................... 4-39
(2) Auto USB backup ........................................................................ 4-41
(3) Backupviewer .............................................................................. 4-42
(3) Backupviewer options ................................................................. 4-44
Chapter 5 Troubleshooting Guide and Glossary...........................................................A-1
Troubleshooting Guide...............................................................................A-3
Glossary.....................................................................................................A-8
Product Warranty Card

1-1
###############





















Lqwurgxfwlrq#ri#wkh#surgxfw#ihdwxuhv#
dqg#frpsrqhqwv#+uhdg#ehiruh#xvh,1

DYDORQ
#
K
K##
L
Lqwurgxfwlrq #
This guide based on the model AVALON H5016

AVALON H User Manual
1-2
#







































Chapter 1. Introduction
1-3
1
1. About AVALON H
AVALON H is Digital Video recorder which uses the leading codec compression (H.264)
for its image storage and networking. There are 3 different models (
available within the Avalon H5000 series.
Main Features
- H.264 codec compression.
- PIP(picture in picture) mode
- Multi-User level access and control system.
- Professionalized menu functions and configuration.
- Powerful remote & network applications.
- Large Storage (3-4 HDD-optional- and Optical device for backup)
- Advanced User friendly interface
- Easy upgrade by USB memory.
- Supports all main PTZ protocols
- Loop-out composite Video and Spot monitor support







AVALON H User Manual
1-4
#

2. AVALON H Specification
Description AVALON H 5004 AVALON H 5008 AVALON H 5016
Inputs y4 CH Composite y8 CH Composite y16 CH Composite
Outputs yVGA Monitor (NTSC/PAL) yCCTV (VGA) Monitor y1 Spot CCTV Monitor (NTSC/PAL)
y4CH/8CH /16CH Loop Composite Videos
Screen split y1/4 Split & PIP y1/4/9 Split & PIP y1/4/9/16 Split & PIP
Display
Performance yNTSC : 240fps yPAL : 200fps yNTSC : 240fps yPAL : 200fps yNTSC : 240fps yPAL : 200fps
Record
Performance
yNTSC: CIF 120fps,
2CIF120fps, D1 60fps
yPAL: CIF 100fps, 2CIF
100fps,D1 50fps
yNTSC: CIF 240fps,
2CIF 120fps,D1 60fps
yPAL: CIF 240fps,
2CIF 100fps,D1 50fps
yNTSC: CIF 240fps, 2CIF
120fps,D1 60fps
yPAL: CIF 200fps,
2CIF 100fps,D1 50fps
Record
Resolution NTSC: CIF (352x240) 2CIF (704x240), D1 (704x480) PAL : CIF (352x288), 2CIF (704x288), D1 (704x576)
Compression H.264
Mode Motion detection, Sensor, Schedule
Storage Internal 4 x HDD (W/DVD 3 x HDD) yCD-R/W,DVD-R/W (Optional)
Audio 4 Channel, G.723.1 Compression
Mode Multi-channel playback (Max 16ch), Calendar/Event/Oldest & Latest
Searching By Channel, Time, Date, Motion detection, Sensor events
Remote S/W Remote Software / Web based viewer
Alarm/Sensor 4/4 4/8 4/16
Camera Control Pan/Tilt, Zoom, Focus, Iris
Back-up Through External USB2.0 Ports (Memory Stick, Portable HDD, CD RW)
CD-RW/DVD-RW yNDMS(S/W)
Size 420(W) x 392(D) x 88(H) : 2U Rack Mount Kit
Power 2 HDDs or less External Adapter(12V,5A),
3 HDDs: External Adapter(12V,7A)

Chapter 1. Introduction
1-5
1
3. System Diagram
AVALON H can be connected with the following devices. For more detail on the
connection, see each chapter’s explanation in the manual.













AVALON H User Manual
1-6
#
G ͿΠΥΚΔΖ

zSome components are subject to change by manufacturer
G
4. Components
Following components are included in the box with AVALON H


ل
1 AVALON H Main unit טטטטטטטטטט ΖΒ
ل
2 DC Adapter טטטטטטטטטט ΖΒ
ل
3 AVALON H (CD) טטטטטטטטטט ΖΒ
ل
4 Remote controller טטטטטטטטטט ΖΒ
ل
5. User’s Guide טטטטטטטטטט ΖΒ
ل
6 Loopback Cable (optional) טטטטטטטטטט ΖΒ
ل
7 Rack Mount Kit (optional) טטטטטטטטטט ΖΒ

