LG Lifeband Touch User manual

LG Lifeband Touch
Model : FB84-BS / FB84-BM / FB84-BL / FB84-BX / FB84-SS / FB84-SM /
FB84-SL / FB84-SX / FB84-RS / FB84-RM / FB84-RL / FB84-RX
For more details, please refer to the Owner’s manual at
LG Fitness App or www.lg.com
Quick Setup Guide
The actual device may differ from the image.
This device is not intended to diagnose, treat or
prevent any disease or medical condition.
Always seek the advice of a qualied professional
before making any changes to your exercise,
sleep or nutrition.

2
USB cable
LG Lifeband Touch
Quick setup guide/
Warranty card
USB gender
vStretch the tip of the band and slide it on to
your wrist. Face the open end towards the
outside for a more comfortable t.
Package Contents
Wearing the LG Lifeband Touch

3
Product Overview
Power On
vWhen Powering on the LG Lifeband Touch for the rst
time, press and hold the Menu button for 2 seconds.
�Menu button :
Holding down or pressing the Menu button will allow
you to access dierent menu functions.
�Display :
Shows detailed information. Swipe left or right and
touch to select an item.
�LED :
Shows information such as Goal achievement rate.
Menu button
Display
LED
Charging Battery
vInsert the Micro USB connector to the charging dock,
then connect the USB connector to a USB AC adapter.
vFully charge the device before using for the rst time.
vIt takes 3 hours to fully charge battery.
vTo charge this product, you must always use a AC
5V, 100mA or more. Certied /Listed Adapter which
complies with LPS.
AC Adapter is not supplied.

4
v
You can view your workout data recorded by the this device using the app.
To use this function, sign up for the app and register your device.
You can view time and music control mode on LG Lifeband Touch after syncing with the app.
1. Search for“LG Fitness”in Play Store (Android phone) or App Store (iPhone) and then, install the app.
2. Turn on the LG Lifeband Touch. (Press and hold Menu button for 2 seconds.)
3. Run the “LG Fitness”app. And select [Sign Up] to register device.
4. Touch [Search] in the [Register Device] screen.
When using Bluetooth® technology, you have to make
a connection between the LG Lifeband Touch and the
smartphone as close as possible and keep the distance.
Note : Bluetooth function is available if your smartphone
supports Bluetooth 4.0 LE or later.
5. [Pairing?
/YES | NO] appears on the screen. Touch [YES].
To connect to the smartphone, touch [YES] within 10 seconds.
In case that the connection has failed, repeat step 4 and step 5.
Installing LG Fitness Smartphone App and Connecting
Bluetooth

5
1. Each time you press the Menu button, 3 types of modes are displayed in the following order.
2. To display more information in each mode, swipe left or right.
Display
Time Date Battery life
Total consumed calories / Goal consumed calories / Goal achievement rate
Total distance Number of steps Workout
v
To display your Goal consumed calories or Goal achievement rate, touch the screen in the Total
consumed calories repeatedly.
Play or Pause Forward or Backward Volume Up or Down
v
Music control function is available when you sync LG Lifeband Touch with the app and have music
stored on your smartphone.
Time mode
Activity mode
Music Control mode
Time mode Activity mode Music Control mode

6
1. Press Menu button to select Activity mode.
2. Swipe the screen in the Activity mode to select [START].
3. Touch [START] to start Workout.
4. To check various workout information, swipe left or right.
Time Calories Distance Number of steps Speed Pace Heart Rate
5. Touch the screen in Workout mode. [STOP] and [PAUSE] button will appear. To complete Workout mode,
touch [STOP]. To pause Workout mode, touch [PAUSE].
Using Workout

7
Button Functions Initial Bluetooth
Connection
Select Orientation
(Left or Right) Power o Restart automatically
Press and hold
for
About 2 seconds,
1st vibration
About 4 seconds,
2nd vibration
More than 6
seconds,
3rd vibration
More than 10
seconds
Display
Performance LED indicator
Ready to pair Violet / Blinks.
Paired Violet / Fade in and out.
Battery LED indicator
Low (less than 10%) Red / Blinks.
Charging Red / Turned on dimly.
Charged LED o / When pressing MENU button, Green LED indicator turned on.
Menu Button Functions
LED Indications

8
vThe LG Lifeband Touch is splash resistant not waterproof. It should not be used underwater or under
running water.
vActivity records are reset every night at 12:00 AM local time. Data that has not been updated can be
saved on the device for up to 1 month. The data will be updated when you sync the device to LG
Fitness App on your Smartphone.
Auto display On/O
vThis device features gesture recognition technology. The display will turn on when motioning your arm
up to check the time. The display will turn o when motioning your arm back down.
Note : You can set [Screen auto-o time] on the LG Fitness app. [More /LG Lifeband Touch Settings]
Reconnecting Bluetooth
vTo reconnect to the smartphone, turn Bluetooth setting [OFF] and [ON] again by pressing and holding
for 2 seconds the Menu button when the app is running.
/ /
vPairing is kept even if the Bluetooth connection on your smartphone is turned o and on again.
Notice

9
Appendix
WARNING: This product contains chemicals known
to the State of California to cause cancer and birth
defects or other reproductive harm. Wash hands
after handling.
FCC Compliance Statement
This device complies with part 15 of the FCC
rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference,
and
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses, and can radiate radio frequency energy
and, if not installed and used in accordance with
the instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment o and
on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
�
Reorient or relocate the receiving antenna.
�
Increase the separation between the
equipment and receiver.
�
Connect the equipment into an outlet on
a circuit dierent from that to which the
receiver is connected.
�
Consult the dealer or an experienced radio/TV
technician for help.
CAUTION: Any changes or modications not
expressly approved by the party responsible for
compliance could void the user’s authority to
operate this equipment.

10
FCC WARNING : This equipment may generate
or use radio frequency energy. changes or
modications to this equipment may cause harmful
interference unless the modications are expressly
approved in the instruction manual. The user could
lose the authority to operate this equipment if an
unauthorized change or modication is made.
FCC RF Radiation Exposure Statement : This
equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment.
CAUTION: Regulations of the FCC and FAA prohibit
airborne operation of radio-frequency wireless
devices because their signals could interfere with
critical aircraft instruments.
Responsible Party :
LG Electronics USA, Inc.1000 Sylvan Avenue
Englewood Clis, NJ 07632
TEL. : [phone]

Printed in China
LG Customer Information Center
1-800-243-0000 USA, Consumer
1-888-865-3026 USA, Commercial
Register your product Online!
www.lg.com
