LG 19LV2500 User manual

G
Order Number : GETEC-C1-10-206 FCC Part 15 subpart B
Test Report Number : GETEC-E3-10-106 Page 1 / 1
EUT Type: LED LCD TV/Monitor
FCC ID.: BEJ55LV3500UA
APPENDIX G
: USER’S MANUAL

www.lg.com
P/NO : SAC34134216 (1010-REV00)
OWNER’S MANUAL
LED LCD TV / LCD TV /
PLASMA TV
Please read this manual carefully before operating the
set and retain it for future reference.
LED LCD TV MODELS
19LV2500
22LV2500
26LV2500
32LV2500
LCD TV MODELS
22LK330
26LK330
32LK330
32LK430
42LK430
PLASMA TV MODELS
42PW340
50PW340
42PW350
50PW350
50PZ250
60PZ250
32LV3500
37LV3500
42LV3500
47LV3500
55LV3500
32LK450
37LK450
42LK450
47LK450
42LK520
47LK520
55LK520
42PW350U
50PW350U

2
ENG
ENGLISH
LICENSES
LICENSES
Supported licenses may differ by model. For more information of the licenses, visit www.lg.com.
Manufactured under license from Dolby Laboratories. “Dolby” and the double-D
symbol are trademarks of Dolby Laboratories.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC.
ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, Inc. This is
an official DivX Certified® device that plays DivX video. Visit www.divx.com for
more information and software tools to convert your files into DivX video.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered
in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your
registration code, locate the DivX VOD section in your device setup menu. Go to
vod.divx.com for more information on how to complete your registration.
“DivX Certified® to play DivX® video up to HD 1080p, including premium
content.”
“DivX®, DivX Certified® and associated logos are registered trademarks of DivX,
Inc. and are used under license.”
“Covered by one or more of the following U.S. patents:
7,295,673; 7,460,668; 7,515,710; 7,519,274”
NOTE
y
Plasma
: Plasma TV
LCD
: LED LCD TV, LCD TV

3
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
Always comply with the following precautions to avoid dangerous situations and ensure peak performance
of your product.
TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR
BACK). NO USER SERVICEABLE PARTS
INSIDE. REFER TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be
of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature accompanying
the appliance.
- TO REDUCE THE RISK OF FIRE AND
ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE.
- TO PREVENT FIRE OR SHOCK HAZARDS,
DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
WARNING/CAUTION
Read these instructions.
Keep these instructions.
Heed all warning.
Follow all instruction.
y Do not use this apparatus near water.
y Clean only with a soft cloth.
y Do not block any ventilation openings. Install
in accordance with the manufacturer’s
instructions.
y Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
y Do not disregard the safety purpose of the
polarized or grounding-type plug. A polarized
plug is a plug that has two blades with one
wider than the other. A grounding-type plug
is a plug that has two blades and a third
grounding prong. The wide blade or the third
prong are provided for your safety. If the
provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.

4
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
y Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
y Use only attachments/accessories specified
by the manufacturer.
y Use only with a cart, stand, tripod, bracket,
or table specified by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
y Unplug this apparatus during lightning
storms or when unused for long periods of
time.
y Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way. For
example, if the power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.
y Never touch this apparatus or antenna during
a thunder or lightning storm.
y When mounting a TV on the wall, make sure
not to install the TV by hanging the power
and signal cables on the back of the TV.
y Do not allow an impact shock or any objects
to fall into the product, and do not drop
anything onto the screen.
y CAUTION concerning the Power Cord
(Can differ by country):
It is recommended that appliances be
placed upon a dedicated circuit; that is, a
single outlet circuit which powers only that
appliance and has no additional outlets or
branch circuits. Check the specification page
of this owner’s manual to be certain. Do not
connect too many appliances to the same
AC power outlet as this could result in fire or
electric shock. Do not overload wall outlets.
Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power
cords, or damaged or cracked wire insulation
are dangerous. Any of these conditions could
result in electric shock or fire. Periodically
examine the cord of your appliance, and
if its appearance indicates damage or
deterioration, unplug it, discontinue use of
the appliance, and have the cord replaced
with an exact replacement part by an
authorized service. Protect the power cord
from physical or mechanical abuse, such as
being twisted, kinked, pinched, closed in a
door, or walked upon. Pay particular attention
to plugs, wall outlets, and the point where
the cord exits the appliance. Do not move
the TV with the power cord plugged in. Do
not use a damaged or loose power cord. Be
sure do grasp the plug when unplugging the
power cord. Do not pull on the power cord
to unplug the TV.
y Warning - To reduce the risk of fire or
electrical shock, do not expose this product
to rain, moisture or other liquids. Do not
touch the TV with wet hands. Do not install
this product near flammable objects such
as gasoline or candles, or expose the TV to
direct air conditioning.

5
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
y Do not expose to dripping or splashing and
do not place objects filled with liquids, such
as vases, cups, etc. on or over the apparatus
(e.g. on shelves above the unit).
y Grounding
Ensure that you connect the earth ground
wire to prevent possible electric shock
(i.e. a TV with a three-prong grounded AC
plug must be connected to a three-prong
grounded AC outlet). If grounding methods
are not possible, have a qualified electrician
install a separate circuit breaker. Do not try to
ground the unit by connecting it to telephone
wires, lightening rods, or gas pipes.
Power Supp
Short-circuit Breaker
y DISCONNECTING DEVICE FROM MAINS
Mains plug is the disconnecting device. The
plug must remain readily operable.
y As long as this unit is connected to the AC
wall outlet, it is not disconnected from the
AC power source even if the unit is turned
off.
y Do not attempt to modify this product in any
way without written authorization from LG
Electronics. Unauthorized modification could
void the user’s authority to operate this
product.
y ANTENNAS Outdoor antenna grounding
(Can differ by country):
If an outdoor antenna is installed, follow
the precautions below. An outdoor antenna
system should not be located in the vicinity
of overhead power lines or other electric light
or power circuits, or where it can come in
contact with such power lines or circuits as
death or serious injury can occur. Be sure the
antenna system is grounded so as to provide
some protection against voltage surges
and built-up static charges. Section 810 of
the National Electrical Code (NEC) in the
U.S.A. provides information with respect to
proper grounding of the mast and supporting
structure, grounding of the lead-in wire to
an antenna discharge unit, size of grounding
conductors, location of antenna discharge
unit, connection to grounding electrodes and
requirements for the grounding electrode.
Antenna grounding according to the National
Electrical Code, ANSI/NFPA 70
NEC: National Electrical Code
Ground Clamp
Antenna Lead in Wire
Antenna Discharge Unit
(NEC Section 810-20)
Grounding Conductor
(NEC Section 810-21)
Power Service Grounding
Electrode System
(NEC Art 250, Part H)
Electric Service
Equipment
Ground Clamp
y Cleaning
When cleaning, unplug the power cord and
wipe gently with a soft cloth to prevent
scratching. Do not spray water or other
liquids directly on the TV as electric shock
may occur. Do not clean with chemicals
such as alcohol, thinners or benzine.
y Moving
Make sure the product is turned off,
unplugged and all cables have been
removed. It may take 2 or more people to
carry larger TVs. Do not press or put stress
on the front panel of the TV.
y Ventilation
Install your TV where there is proper
ventilation. Do not install in a confined
space such as a bookcase. Do not cover the
product with cloth or other materials while
plugged. Do not install in excessively dusty
places.
y If you smell smoke or other odors coming
from the TV, unplug the power cord contact
an authorized service center.
y Do not press strongly upon the panel with
hand or sharp object such as nail, pencil or
pen, or make a scratch on it.
y Keep the product away from direct sunlight.

6
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
y Dot Defect
The Plasma or LCD panel is a high
technology product with resolution of two
million to six million pixels. In a very few
cases, you could see fine dots on the screen
while you’re viewing the TV. Those dots
are deactivated pixels and do not affect the
performance and reliability of the TV.
y Generated Sound
“Cracking” noise: A cracking noise that
occurs when watching or turning off the TV
is generated by plastic thermal contraction
due to temperature and humidity. This noise
is common for products where thermal
deformation is required.
Electrical circuit humming/panel buzzing: A
low level noise is generated from a high-
speed switching circuit, which supplies a
large amount of current to operate a product.
It varies depending on the product.
This generated sound does not affect the
performance and reliability of the product.
y Viewing 3D Imaging (For 3D TV)
- When viewing 3D imaging, watch the TV
from an effective viewing angle and within
the appropriate distance. If you exceed this
viewing angle or distance, you may not be
able to view the 3D imaging. Furthermore,
the 3D imaging may not display if it is viewed
while you are lying down.
- If you watch the 3D imaging too closely or
for a long period of time, it may harm your
eyesight.
- Watching the TV or playing video games
that incorporate 3D imaging with the 3D
glasses for a long period of time can cause
drowsiness, headaches or fatigue to you
and/or your eyes. If you have a headache,
or otherwise feel fatigued or drowsy, stop
watching the TV and take a rest.
- Pregnant woman, seniors, persons with
heart problems or persons who experience
frequent drowsiness should refrain from
watching 3D TV.
- Some 3D imaging may cause you to duck
or dodge the image displayed in the video.
Therefore, it is best if you do not watch 3D
TV near fragile objects or near any objects
that can be knocked over easily.
- Please prevent children under the age of
5 from watching 3D TV. It may affect their
vision development.
- Warning for photosensitization seizure: Some
viewers may experience a seizure or epilepsy
when exposed to certain factors, including
flashing lights or images in TV or video
games. If you or anybody from your family
has a history of epilepsy or seizure, please
consult with your doctor before watching 3D
TV.
Also certain symptoms can occur in
unspecified conditions without any previous
history. If you experience any of the following
symptoms, immediately stop watching the
3D imaging and consult a doctor: dizziness or
lightheadedness, visual transition or altered
vision, visual or facial instability, such as eye
or muscle twitching, unconscious action,
convulsion, loss of conscience, confusion
or disorientation, loss of directional sense,
cramps, or nausea. Parents should monitor
their children, including teenagers, for these
symptoms as they may be more sensitive to
the effects of watching 3D TV.
Risk of photosensitization seizure can be
reduced with the following actions.
- Take frequent breaks from watching 3D TV.
- For those who have vision that is different
in each eye, they should watch the TV after
taking vision correction measures.
- Watch the TV so that your eyes are on the
same level as the 3D screen and refrain from
sitting too closely to the TV.
- Do not watch the 3D imaging when tired or
sick, and avoid watching the 3D imaging for a
long period of time.
- Do not wear the 3D glasses for any other
purpose than viewing 3D imaging on a 3D TV.
- Some viewers may feel disoriented after
watching 3D TV. Therefore, after you watch
3D TV, take a moment to regain awareness
of your situation before moving.

7
ENG
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
y
LCD
If the TV feels cold to the touch, there may
be a small “flicker” when it is turned on. This
is normal, there is nothing wrong with TV.
Some minute dot defects may be visible on
the screen, appearing as tiny red, green, or
blue spots. However, they have no adverse
effect on the TV’s performance. Avoid
touching the LCD screen or holding your
finger(s) against it for long periods of time.
Doing so may produce some temporary
distortion effects on the screen.
DISPOSAL (Only Hg lamp used LCD TV)
The fluorescent lamp used in this product contains
a small amount of mercury. Do not dispose of
this product with general household waste.
Disposal of this product must be carried out
in accordance to the regulations of your local
authority.
For USA and Canada
FCC NOTICE
This equipment has been tested and found
to comply with the limits for a Class B
digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is
no guarantee that interference will not occur
in a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be determined
by turning the equipment off and on, the user
is encouraged to try to correct the interference
by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the
equipment and the receiver.
- Connect the equipment to an outlet on
a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/
TV technician for help.
This device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) this device may not cause
harmful interference and (2) this device must
accept any interference received, including
interference that may cause undesired
operation of the device.
Any changes or modifications in construction of
this device which are not expressly approved
by the party responsible for compliance
could void the user’s authority to operate the
equipment.
NOTE TO CABLE/TV INSTALLER
This reminder is provided to call the CATV
system installer’s attention to Article 820-40 of
the National Electric Code (U.S.A.). The code
provides guidelines for proper grounding and,
in particular, specifies that the cable ground
shall be connected to the grounding system of
the building, as close to the point of the cable
entry as practical.

8
ENG
ENGLISH
TABLE OF CONTENTS
TABLE OF CONTENTS
2 LICENSES
3 IMPORTANT SAFETY IN-
STRUCTIONS
8 TABLE OF CONTENTS
10 ASSEMBLING AND PREPARING
10 Unpacking
13 Optional Extras
14 Parts and buttons
18 Lifting and moving the TV
18 Setting up the TV
18 Attaching the stand
22 Mounting on a table
23 Mounting on a wall
24 Tidying cables
25 REMOTE CONTROL
28 WATCHING TV
28 Connecting an antenna or cable
28 Connecting an antenna or basic cable
28 Connecting with a cable box
29 Turning the TV on for the first time
30 Watching TV
30 Managing channels
30 Setting up channels
31 Using favorite channels
32 Checking current program info
34 Using additional options
34 Adjusting aspect ratio
35 Changing AV modes
35 Using the input list
36 Locking the buttons on the TV (Child
Lock)
36 Using the quick menu
37 Viewing the on-screen manual (
LCD
)
37 Using the customer supprot
37 Testing the Picture / Sound
37 Using the product or service informa-
tion
38 3D IMAGING
(FOR PLASMA TV)
38 3D TECHNOLOGY
39 When using 3D Glasses
39 3D Imaging viewing range
40 Viewing 3D Imaging
42 ENTERTAINMENT
42 Connecting USB storage devices
43 Browsing files
45 Viewing videos
48 DivX registration code
49 Viewing photos
51 Listening to music
54 CUSTOMIZING TV SETTINGS
54 Accessing main menus
55 Customizing settings
55 CHANNEL settings
56 PICTURE settings
60 AUDIO settings
61 TIME settings
62 LOCK settings
64 OPTION settings
66 MAKING CONNECTIONS
67 Connection overview
68 Connecting to a HD receiver, DVD, or
VCR player
68 HDMI connection

9
ENG
ENGLISH
TABLE OF CONTENTS
68 DVI to HDMI connection
69 Component connection
69 Composite connection
70 RGB Connection
70 Connecting to an audio system
70 Digital optical audio connection
71 Connecting to a USB
71 SIMPLINK connection
71 Activating and Using the SIMPLINK
menus
73 MAINTENANCE
73 Cleaning your TV
73 Screen and frame
73 Cabinet and stand
73 Power cord
73 Preventing “Image burn” or “Burn-in” on
your TV screen
74 TROUBLESHOOTING
76 SPECIFICATIONS
81 IR CODES
83 EXTERNAL CONTROL DEVICE
SETUP

10
ENG
ENGLISH
ASSEMBLING AND PREPARING
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual
product and item.
Remote control and batteries (AAA) Owner’s manual CD
D-sub 15 pin signal cable1
(optional)
Polishing cloth2(optional)
FREEZE
RATIO
L/RSELECT
ENTER
BACK EXIT
Q.MENU
INFO
MENU
CHVOL
P
A
G
E
FAV
3D
MUTE
123
456
78
0
9
MARK
LIST
FLASHBK
ENERGY
SAVING
TV
AVMODE INPUT
1 When using the VGA (D-sub 15 pin signal cable) PC connection, use the shielded signal interface cable
with a ferrite core to maintain standards compliance for the product.
2 Gently wipe the spots on the cabinet with the polishing cloth.

11
ENG
ENGLISH
ASSEMBLING AND PREPARING
42/50PW340, 42/50PW350, 42/50PW350U, 50/60PZ250
Screw for assembly Cable holder Protection cover Power Cord
M4 x 26
x 4
M5 x 14.5
x 3
32/37/42/47/55LV3500
Screw for assembly Cleansing Cloths (Mitt)3
Composite gender cable Cable holder
M4 x 12
x 8
3 Wipe spots on the exterior only with the cleasing cloths.
Do not wipe roughly when removing stains. Excessive
pressure may cause scratches or discoloration.
For cleaning front frame, please slowly wipe in one direction
after spraying water 1-2 times on cleansing cloths. Please
remove excessive moisture after cleaning. Excessive moisture
may cause water stains on the frame.

12
ENG
ENGLISH
ASSEMBLING AND PREPARING
32/37/42/47LK450
Screw for assembly Screw for fixing Protection cover Power Cord
CAUTION
y Do not use any pirated items to ensure the safety and product life span.
y Any damages or injuries by using pirated items are not covered by the warranty.
NOTE
y The items supplied with your product may vary depending on the model.
y Product specifications or contents of this manual may be changed without prior notice due to
upgrade of product functions.
y (
Plasma
)How to use the ferrite core
- (㦤ἼG⒈GὨG䂈㛨G㇠㟝PUse the ferrite core to reduce the electromagnetic waves in the PC audio
cable.
Wind the PC audio cable on the ferrite core thrice. Place the ferrite core far from the TV.
AUDIO IN
(RGB/DVI)
- Use the ferrite core to reduce the electromagnetic waves that interfere with the TV. Wind the PC
audio cable on the ferrite core once. Place the ferrite core on the power cable close to the wall plug.
y (
LCD
) For an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm
(0.39 inches) thick and 18 mm (0.7 inches) width.
B
AA
B
*A 10 mm (0.39 inches)
*B 18 mm (0.7 inches)
M4 x 20
x 8
Except 47LK450

13
ENG
ENGLISH
ASSEMBLING AND PREPARING
Optional Extras
Optional extras can be changed or modified for quality improvement without any notification.
Contact your dealer for buying these items.
This device only works with compatible LG LED LCD TV, LCD TV, or Plasma TV.
Wireless Media Box
(AN-WL100W)
3D Glasses
(AG-S230, AG-S250, AG-S270)

14
ENG
ENGLISH
ASSEMBLING AND PREPARING
Parts and buttons
Touch button2Description
/ITurns the power on or off.
INPUT Changes the input source.
HOME Accesses the main menus, or saves your input and exits the menus.
ENTER Selects the highlighted menu option or confirms an input.
- VOL + Adjusts the volume level.
^
CH v Scrolls through the saved channels.
1 Intelligent sensor - Adjusts the image quality corresponding to the surrounding environment.
2 All of the buttons are touch sensitive and can be operated through simple touch with your finger.
42/50PW340, 42/50PW350, 42/50PW350U, 50/60PZ250
AV IN 2
L/MONO
R
AUDIO
VIDEO
USB ININ 3
COMPONENT IN
VIDEO
AUDIO
YL
PBPRR
RGB IN (PC)
AUDIO IN
(RGB/DVI)
ANTENNA
/CABLE
IN
RS-232C IN
(CONTROL & SERVICE)
REMOTE
CONTROL IN
OPTICAL
DIGITAL
AUDIO OUT
AV IN 1
1
/DVI IN
VIDEO
AUDIO
L/MONO
R
2
1
2
ENTER CH
VOL
HOME
INPUT
Remote control and
intelligent1sensors
USB input
HDMI IN
AV (Audic
and Video)
IN
Screen
Speakers
Connection panel
(See p.66)
Touch buttons2

15
ENG
ENGLISH
ASSEMBLING AND PREPARING
32/37/42/47/55LV3500
NOTE
You can set the Power indicator to on or off by selecting OPTION in the main menus.
Touch button2Description
/ITurns the power on or off.
INPUT Changes the input source.
HOME Accesses the main menus, or saves your input and exits the menus.
ENTER Selects the highlighted menu option or confirms an input
- VOL + Adjusts the volume level.
v CH
^
Scrolls through the saved channels.
1 Intelligent sensor - Adjusts the image quality corresponding to the surrounding environment.
2 All of the buttons are touch sensitive and can be operated through simple touch with your finger.
IN 3
USB IN
LAN
OPTICAL DIGITAL
AUDIO OUT
ANTENNA/
CABLE IN
ENTER
CH VOL HOME INPUT
AV IN 2
VIDEO / AUDIO
H/P
ANTENNA /
CABLE IN
RS-232C IN (CONTROL & SERVICE)
RGB IN (PC)
(RGB/DVI)
AUDIO IN
OPTICAL
DIGITAL
AUDIO OUT
1
2
VIDEO AUDIO
COMPONENT IN
Y
P
B
P
R
R
L
VIDEO
AUDIO
L/MONO
R
AV IN 1
/ DVI IN
21
USB IN
IN 3
Screen
Touch buttons2
Power indicator
Remote control and
intelligent1sensors
Connection panel
(See p.66)
Speakers

16
ENG
ENGLISH
ASSEMBLING AND PREPARING
19/22/26/32LV2500
NOTE
You can set the Power indicator to on or off by selecting OPTION in the main menus.
Touch button2Description
/ITurns the power on or off.
INPUT Changes the input source.
HOME Accesses the main menus, or saves your input and exits the menus.
ENTER Selects the highlighted menu option or confirms an input
- VOL + Adjusts the volume level.
v CH
^
Scrolls through the saved channels.
1 Intelligent sensor - Adjusts the image quality corresponding to the surrounding environment.
2 All of the buttons are touch sensitive and can be operated through simple touch with your finger.
USB ININ 3
ANTENNA/
CABLE IN
VIDEO AUDIO
COMPONENT IN
Y
P
B
P
R
R
L
(RGB/DVI)
AUDIO IN
OPTICAL
DIGITAL
AUDIO OUT
RS-232C IN ( CONTROL & SERVICE)
RGB IN (PC)
/ DVI IN
21
VIDEO
AUDIO
R
AV IN 1
L/MONO
DC-IN
ENTER
CH VOL HOME INPUT
Screen
Touch buttons2
Power indicator
Remote control and
intelligent1sensors
Connection panel
(See p.66)
Speakers
USB input
HDMI IN
HEAD
PHONE

17
ENG
ENGLISH
ASSEMBLING AND PREPARING
32/37/42/47LK450
NOTE
You can set the Power indicator to on or off by selecting OPTION in the main menus.
Touch button2Description
/ITurns the power on or off.
INPUT Changes the input source.
HOME Accesses the main menus, or saves your input and exits the menus.
ENTER Selects the highlighted menu option or confirms an input
- VOL + Adjusts the volume level.
v CH
^
Scrolls through the saved channels.
1 Intelligent sensor - Adjusts the image quality corresponding to the surrounding environment.
2 All of the buttons are touch sensitive and can be operated through simple touch with your finger.
ENTER
CH VOL HOME INPUT
USB IN
VIDEO
AUDIO
R
L/MONO
IN 3
AV IN 2
1
2
COMPONENT IN
YPB
P
R
R
L
VIDEO
AUDIO
R
AV IN 1
L/MONO
ANTENNA /
CABLE IN
RS-232C IN (CONTROL & SERVICE)
RGB IN (PC)
OPTICAL DIGITAL
AUDIO OUT
(RGB/DVI)
AUDIO IN
/ DVI IN
21
VIDEO AUDIO
Screen
Touch buttons2
Power indicator
Remote control and
intelligent1sensors
Connection panel
(See p.66)
Speakers
USB input
HDMI IN
HEAD
PHONE
AV (Audic
and Video)
IN

18
ENG
ENGLISH
ASSEMBLING AND PREPARING
Lifting and moving the TV
When moving or lifting the TV, read the following
to prevent the TV from being scratched or
damaged and for save transportation regardless of
its type and size.
CAUTION
Avoid touching the screen at all times, as this
may result in damage on the screen or some
of the pixels used to create images.
y It is recommended to move the TV in the
box or packing material that the TV originally
came in.
y Before moving or lifting the TV, disconnect
the power cord and all cables.
y When holding the TV, the screen should face
away from you to prevent the screen from
scratches.
y Hold the top and bottom of the TV frame
firmly. Make sure not to hold the transparent
part, speaker, or speaker grill area.
y When transporting a large TV, there should
be 2 or 3 people.
y When transporting the TV by hand, hold the
TV as shown in the following illustration.
y When transporting the TV, do not expose the
TV to jolts or excessive vibration.
y When transporting the TV, keep the TV
upright, never turn the TV on its side or tilt
towards the left or right.
Setting up the TV
Put your TV on a pedestal stand and mount the TV
on a table or wall.
Attaching the stand
Plasma
Plasma
1Lay the TV with the screen side down on a flat
surface.
CAUTION
Lay a foam mat or soft protective cloth
on the surface to protect the screen from
damage.
2Assemble the parts of the STAND BODY with
the STAND BASE of the TV.
3Secure the TV and the stand with the 4
screws.
CAUTION
Tighten the screws firmly to prevent the TV
from tilting forward. Do not over tighten.

19
ENG
ENGLISH
ASSEMBLING AND PREPARING
To detach the stand,
1Lay the TV with the screen side down on a flat
surface.
2Remove the 4 screws and pull the stand away
from the TV.
3Push the supplied protection cover into the
opening at the bottom of the TV until it locks in
place.
This will protect the opening from accumulating
dust and dirt.
When installing the wall mounting bracket, use
the Protection cover.
Protection cover
32/37/42/47/55LV3500
1Lay the TV with the screen side down on a flat
surface.
CAUTION
Lay a foam mat or soft protective cloth
on the surface to protect the screen from
damage.
2Assemble the parts of the STAND BODY with
the STAND BASE of the TV.
3Secure the TV and the stand with the 4
screws.
CAUTION
Tighten the screws firmly to prevent the TV
from tilting forward. Do not over tighten.
To detach the stand,
1Lay the TV with the screen side down on a flat
surface.
2Remove the 4 screws and pull the stand away
from the TV.
