LG 32LD650H User manual

lcd tv
w w w. LG s o l u t i o n s . c o m
LG’s EXCLU IVE Pro:Centric APPLICATION PLATFORM
Supports Java™ and Adobe®lash®applications
b-LAN™ INTEGRATION
Includes full support of:
LodgeNet®'s HD Video On Demand (VOD)
LodgeNet's HD ree-To-Guest ( TG)
Supports many other TG system providers (see sales rep)
Compatible with MA-LG101
ENERGY TAR 4.1 QUALIFIED & RoH COMPLIANT
Eco mart™
Intelligent Sensor
Dynamic Power Savings
Static Power Savings
MPEG-4 DECODING
HD VOD PPV ENCRYPTION
Integrated Pro:Idiom
U B CLONING
U B 2.0 MEDIA HO T
for photos and music
NATIVE DI PLAY RE OLUTION
1920 x 1080 (37”/42”/47”/55”)
1366 x 768 (32”)
NEW! IMPROVED TAND
(32”/37”/42”)
BUILT-IN TUNER
ATSC/NTSC/QAM Clear Tuner
DYNAMIC CONTRA T RATIO
50:000:1
LG’s EXCLU IVE XD ENGINE®
REAL CINEMA™ AND CLEAR VOICE
AUTO- EN ING REMOTE JACK PACK
(RJP) COMPATIBLE
PIP/Split Screen feature with optional RJP
2 HDMI™ V1.3 INPUT WITH HDCP
2-YEAR LIMITED WARRANTY
parts/labor
NOTE: Contact your LG Sales represensative on the RJPs that are
compatible with these models
HDTV with Applications Platform Pro:Centric™LCD Widescreen
hi loss black
hi loss black
hi loss black
matte black
hi loss black
matte black
hi loss black
matte black
55LD650H
47LD650H
42LD650H
42LD655H
37LD650H
37LD655H
32LD650H
32LD655H
55" class (55.0" dia onal)
47" class (47.0" dia onal)
42" class (42.0" dia onal)
37" class (37.0" dia onal)
32" class (31.5" dia onal)

*
Pro:Centric
Pro:Centric PLATFORM*
May require optional software, hardware, third
party subscription service/contract, and
customization at an additional cost.
Electronic Program Guide
Interactive Guestroom Experience
An industry leading Pay-Per-View (PPV)
compatible television to include an embedded
applications platform, LG’s new LD650H
series allows hoteliers to customize the in-room
experience. Pro:Centric provides an easy way
for the LD650H series to interface with
interactive program guides, games and
internet data feeds, as well as applications
designed to connect guests to hotel services
such as room service menus,
spa services and golf course scheduling.
R E E - T O - G U E S T MANAGEMENT APPLIANCE
FMA-LG101
HEAD-END Y TEM
Manages channel line-up changes, channel label changes, designates a
startup channel, cloning of commercial installer menu settings, and can set
the time/date, and broadcast that information to all the terminals on a
regular basis. Also, enables Pro:Idiom tuning for Pro:Idiom encrypted
content.
Pro:Centric SYSTEM OVERVIEW
Dramatization
(example for illustrative purpose only)
R E E - T O - G U E S T INTEGRATED b-LAN
FREE-TO-GUEST TECH OLOGY
Allows viewing of HD secured Pro:Idiom encrypted content from Pro:Idiom
licensed Cable of Satellite providers. Compatible with MA-LG101 systems.
Pay-Per-View ready.
L I E ’ S G O O D . . .
WHEN IT’sGREEN.
LG is committed to improving product development,
manufacturing and usage to meet the demand for
environmentally friendlier products. Our LD650H
televisions have technologies to reduce power
consumption and in return increase cost savings
per room. We’ve also placed limits in the amounts
of harmful materials used in these televisions.
EcoSmart
•Intelligent Sensor - Continually monitors room light conditions to automatically
optimize the picture quality for a more enjoyable viewing experience, which can help
save energy.
•Dynamic Power Savings - Using built-in algorithms, TV will automatically reduce the
power consumption based on incoming video, while maximizing picture performance.
•Static Power Savings - Picture brightness level can be set at the preferred power
consumption level to reduce power and increase energy savings.
•RoHS Compliant - Meets directive on restriction of hazardous substances.
•Energy Star 4.1 Qualified - Meets current reduction requirements of energy
consumption.
LG'S FREE-TO-GUEST COST EFFECTIVE SOLUTIO
or ree-To-Guest hotel installations, when using LG televisions with b-LAN integration plus LG’s
ree-to-Guest Management Appliance ( MA), virtual channel mapping, cloning of commercial
installer menu settings, and other adjustments can be made from the centralized head-end MA
system. This is an added value of time savings and therefore cost savings in labor charges by not
having to go room to room for a change of settings.
Estimated
Labor Costs
*FMA MAP
price Total Savings over other brand
Other brand
$20 (est.) x 2 times per year
(to update channels)
x 100 rooms x 5 years
$20,000
LG Pro:Idiom TV
with b-LAN integration
plus MA
$1,999 $1,999 $18,001
* MA MAP price subject to change.
HOTEL COSTS FOR FREE-TO-GUEST CHA EL MA AGEME T

SHARPER
BRIGHTER
CLEARER
DIGITAL RIGHTS
MA AGEME T SYSTEM
The Pro:Idiom system’s high-quality
security unlocks access to premium
content availability to help
assure rapid, broad deployment
of HDTV and other high value
digital content. Pro:Idiom has
been designed specifically for
industries that use premium HDTV
content from cable, satellite or
video on demand (VOD) services
and as such, could result in lower
costs, and reduced maintenance.
This system is one of the leading
DRM systems embraced by
content providers for both of these
key programming sources. By
using this embedded approach,
security is provided and helps
eliminate the possibility of
customers tampering with or
removing needed components.
(Moving Picture Experts Group)
MPEG-4 decodes and delivers
high-definition programming it
receives via satellite. The advanced
coding system is compatible with
national and local HD channels,
along with digital HD channels
currently launched by DIRECTV.
LG built this technology into its
LD650H series TVs to deliver
pure HD without the need for an
external box*.
Certain functions, such as Pay-Per-View,
may require a set-top box.
ANTENNA INANTENNA IN M.P.I.M.P.I.
REMOTE
CONTROL
OUT
OPTICAL
DIGITAL
UPDATE
RESET
LAN
HDMI/DVI IN
2
1
RJP
INTERFACE
SPEAKER
OUT
8
RGB IN (PC) AUDIO IN
(RGB/DVI)
TV-LINKCFG
GAME
CONTROL/M.P.I.
RS-232C IN
(SERVICE ONLY)
AUDIO OUT
V
AN
I1
AUDIO
VIDEO
MONO
/
T
N
E
N
O
P
N
O
C
IN
LR
AV IN 2
L/MONO
RR
AUDIO
VIDEO
USB IN
55LD650H
52.3”
31.3”
34.3”
21.6” 13.0”
3.8”
2.7” 18.3”
9.7”
5.9”
400mm
400mm
47LD650H
32LD650H/655H
REAR JACK PA EL
SIDE JACK
PA EL
*
Dramatization
MPEG-4 TECH OLOGY
Six distinct processes contribute to picture improvement. LG’s XD Engine takes
the low resolution of analog signals to near HD levels by improving brightness,
contrast, detail and enhancing color as well as reducing signal noise.
Dramatization
U S B
C L O N I N G
AVIN2
L/MONO
R
AUDIO
VIDEO
USBIN
44.8”
26.9”
29.8”
19.7”
2.3” 3.0”
10.6”
18.5”
8.8”
10.3”
200mm
200mm
31.4”
19.5”
21.8”
15.7”
2.1” 2.9”
8.1”
11.8”
6.1”
9.8”
42LD650H/655H
37LD650H/655H
40.3”
36.0”
24.4”
22.0”
27.0”
24.6”
19.2”
19.2”
2.3”
2.2” 3.0”
3.0”
10.3”
10.3”
16.2”
14.1”
6.4”
8.1”
7.6”
6.0”
200mm
200mm
200mm
200mm
32/37/42LD650H/655H
R
REMOTE
CONTROL
OUT
OPTICAL
DIGITAL
UPDATE
RESET
LAN
HDMI/DVI IN
2
1
RJP
INTERFACE
SPEAKER
OUT
8
RGB IN (PC) AUDIO IN
(RGB/DVI)
TV-LINK CFG
GAME CONTROL
/ M.P. I .
RS-232C IN
(SERVICE ONLY)
AUDIO OUT
AN
I
V1
AUDIO
VIDEO
MONO
/
T
N
E
N
O
P
M
O
C
IN
LR
ANTENNA
IN
AV IN 2
L/MONO
RR
AUDIO
VIDEO
USB IN
REAR JACK PA EL
SIDE JACK
PA EL
47/55LD650H/655H

LG Electronics U.S.A., Inc.
Business Solutions Division
2000 Millbrook Drive
Lincolnshire, IL 60069
Customer Service: 888.865.3026
www.LGsolutions.com/support
Contact your LG Regional Sales Representative:
Hospitality: 800.228.1236
Vertical Markets: 800.897.8788
Channel: 800.897.8871
E-mail: [e-mail]
SPEC_LD650H_55H_051005_PR
All screen images are simulated. Dimensions and weights are approximate. Design,
features and specifications subject to change without notice.
© Copyright 2010 LG Electronics USA, Inc. All Rights Reserved. “LG Life’s Good” is a
registered trademark of LG Corp. XD Engine, Pro:Centric and EcoSmart are registered
trademarks or trademarks of LG Electronics, Inc. Pro:Idiom and MPI are trademarks of Zenith
Electronics Corp.
DIRECTV is a registered trademark of DIRECTV, Inc. VESA is a trademark of Video Electronics
Standards Association. HDMI, the HDMI Logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC. Dolby and the double-D symbol
are registered trademarks of Dolby Laboratories. Java is a trademark of Sun Microsystems,
Inc. Adobe and lash are either registered trademarks or trademarks of Adobe Systems
Incorporated in the United States and/or other countries. b-LAN is a trademark of LodgeNet
Interactive Corporation. All other product and brand names are trademarks or registered
trademarks of their respective companies.
Printed in the USA. August 2010
specifications
www.LGsolutions.com
lcd tv
PA EL
LCD Panel Type 55”, 47", 42", 37" , 32"
Display Area 55.0” diagonal, 47.0” diagonal, 42.0" diagonal,
37.0" diagonal , 31.5" diagonal
Dynamic Contrast Ratio 50,000:1
Contrast Ratio 1200:1
Native Display Resolution 1920 x 1080
(37”/42”/47”/55”)
1366 x 768 (32”)
Maximum Computer Resolution (RGB) 1360 x 768
Life Span 60,000 hours (approx.)
Viewing Angle (HxV) 178°x 178°
Response Time 8ms (max)
VIDEO
Built-In Tuner ATSC/NTSC/QAM Tuner
Comb ilter 3D Digital
Color Temperature Cool, Normal, Warm, User
Aspect Ratio Adjustment 5 Modes
Picture Status Mode 7 Modes (Intelligent Sensor, Vivid, Standard,
Cinema, Sports, Game, Natural)
EZ Picture Selection Mode 3 Modes (Cool, Medium, Warm)
XD Engine Yes
Black Stretcher Yes
XD Color (Active Color Management) Yes
All ormat Converter 1080i/720p/480p/480i
~
768p
Decoder ormats MPEG-2/MPEG-4 H.264 (full HD real time
decoding, AC-3 decoding)
24p Real Cinema Yes
DTV Signal Strength (digital) Yes
Video Reset/Intializing Yes
Just Scan 0% over scan
HDMI/Component 1080i/1080p/720p (32” 1080i only)
R DTV 720p
AUDIO
Audio Power 20W (10W x 2)
Speaker System Details 2 Way 4 Speaker
SRS TruSurround XT™ Yes
Clear Voice Yes
Invisible Speaker System Yes
Dolby Digital Decoder Yes
Bass/Treble/Balance Yes
EZ SoundRite (Auto Volume Limiter) Yes
EZ Sound/Sound Selection Mode 5 Modes (Standard, Music, Cinema, Sports, Game)
Mute Yes
Mono/Stereo/Dual (MTS/SAP) Yes
I PUTS/OUTPUTS
R In 1 (ATSC/NTSC)
HDMI V1.3 2 Inputs
RGB In (PC/DTV Input) 1(Rear for PC RGB)
Composite Video & Audio L/R In 1 Rear/1 Side
Digital Audio Out (Optical) 1
PC Audio In (RGB/DVI with adaptor) 1
Component HD/DVD & Audio L/R In 1
Remote Control Out (IR) 1
RJP Interface 1
LAN (RJ-45) 1(service only)
USB 2.0 1 Side (Media Host, Cloning, and Service)
MPI Slot 1 (32”, 37”, 42” only)
MPI™ Port (RJ12) 1 (47”, 55” only)
Bathroom Speaker Out (3.5mm phone jack) 1
RS-232C Input 1
IR Pass Thru 1
IR In/Out 1
SPECIAL FEATURES
Integrated Pro:Idiom Yes
Pro:Centric Platform Yes (supports Java/Adobe lash applications)
b-Lan Embeded (Version 6.3 or up) Yes
MPEG4 Yes
Commercial Mode Setup Menu Yes
(Installer Menu)
TV Link Protocol Yes
USB Cloning Yes
USB Media Host (JPEG & MP3) Yes
Multi Remote IR Code (Bed1/2/3/4) Yes
PIP with RJP Yes
Channel Add/Delete Yes
avorite Channel Yes
Channel Labeling Yes
RJP Plug&Play Support Yes
Discrete IR Codes Yes
Splash Image-Logo (on startup) Yes
Trilingual Menus English/Spanish/ rench
Manual Clock Yes
Sleep Timer, On/Off Timer Yes
lashback (Quick View) Yes
Parental Control w/V-Chip Yes
Auto Programming Yes
Closed Captions Yes
Anti-theft Warning Label Yes
Key Lock/Child Lock Yes
CABI ET
Dimensions with Stand
(W×H×D) 52.3" x 34.3" x 13.0" (55”)
44.8" x 29.8" x 10.6" (47”)
40.3" x 27.0" x 10.3" (42”)
36.1" x 24.6" x 10.3" (37”)
31.4" x 21.8" x 8.1" (32”)
without Stand (W×H×D) 52.3" x 31.3" x 3.8" (55”)
44.8" x 26.9" x 3.0" (47”)
40.3" x 24.4" x 3.0" (42”)
36.1" x 22.0" x 3.0" (37”)
31.4" x 19.5" x 2.9" (32”)
Unit Weight with Stand without Stand
72.8 lbs
(55”) 65.7 lbs (55”)
44.8 lbs (47”) 40.3 lbs (47”)
34.2 lbs (42”) 30.6 Ibs (42”)
28.2 lbs (37”) 24.7 lbs (37”)
19.2 lbs (32”) 16.8 Ibs (32”)
Packaging (W×H×D) 58.9" x 34.7" x 11.3" (55”)
48.4" x 32.0" x 10.0" (47”)
43.6" x 30.3" x 9.0" (42”)
39.2" x 26.0" x 9.0" (37”)
34.6" x 23.6" x 7.5" (32”)
Weight with Packaging 85.5 Ibs (55”)
54.0 Ibs (47”)
42.0 Ibs (42”)
35.7 Ibs (37”)
26.7 Ibs (32”)
TORX Security Screws (2 each) Yes
Standard Stand ixing Hole (360 x 90) Yes
Top Side Mounting Screw Yes
Table Stand Included ±90° Swivel (32”, 37”, 42” - New improved stand)
±20° Swivel (47”, 55”)
Power Cord Length 9 ft.
Color High-Gloss Black
Matte Black (LD655H series only)
VESA Standard Mount Interface 400mm x 400mm (55”)
200mm x 200mm (37”, 42”, 47”)
200mmx 100mm (32”)
REQUIRED LISTI GS
UL, c-UL, NOM Yes
ENERGY STAR 4.1 Qualified Yes
RoHS Compliant Yes
Lead ree Yes
UPC
32LD650H/LD655H 7 19192 90164 3 / 7 19192 90169 8
37LD650H/LD655H 7 19192 90165 0 / 7 19192 90170 4
42LD650H/LD655H 7 19192 90166 7 / 7 19192 90171 1
47LD650H 7 19192 90167 4
55LD650H 7 19192 90168 1
POWER
Power Source 100~240V 50/60Hz
Stand-by Under 1W
Power Consumption (typ.) with
Power Saving Modes Disabled 160W (42”) , 140W (37”) , 105W (32”)
EcoSmart
Intelligent Sensor Yes
Dynamic Power Savings Yes
Static Power Savings Yes
SERVICE/LIMITED WARRA TY
Limited Warranty (Parts/Labor) 2 Years
XT
55LD650H
47LD650H
42LD650H
42LD655H
37LD650H
37LD655H
32LD650H
32LD655H
55" class (55.0" dia onal)
47" class (47.0" dia onal)
42" class (42.0" dia onal)
37" class (37.0" dia onal)
32" class (31.5" dia onal)
hi loss black
hi loss black
hi loss black
matte black
hi loss black
matte black
hi loss black
matte black
