LG 32LE7500 User manual

www.lg.com
OWNER’S MANUAL
LCD TV / LED LCD TV /
PLASMA TV
Please read this manual carefully before operating
your set and retain it for future reference.
ENGLISH

HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks or regis-
tered trademarks of HDMI Licensing LLC.
Wireless Media Box
Separate purchase
Wireless LAN for
Broadband/
DLNA Adaptor
(Except for
50/60PK950,
50/60PK950N,
50/60PK980,
50/60PK990)
Optional extras can be changed or modified for quality improvement without any notification.
Contact your dealer for buying these items.
This device only works with compatible LG LED LCD TV, LCD TV, or Plasma TV.
OUT
WIRELESS
CONTROL
AV1 AV2 COM HDMI1 HDMI2 HDMI3 HDMI4
RGB WIRELESS
(50PK5**, 50PK7***, 50PK9***)
AW-50PG60MS
(60PK5**, 60PK7***, 60PK9***)
AW-60PG60MS
AW-50PG60M
or
AW-60PG60M
or
Wall Mounting Bracket
(32LE5***,
32LE7***,
32LD6***,
32LD7***,
32LD8***)
LSW100B or
LSW100BG
(37/42/47LE5***,
37/42/47LE7***,
42/47LE8***,
37/42/47LD6***,
42/47LD7***,
37/42LD8***,
42/47LX6***)
LSW200B or
LSW200BG
(55LE5***,
55LE7***,
55LE8***,
55LD6***)
LSW400B or
LSW400BG

I
CONTENTS
CONTENTS
PREPARATION
LED LCD TV Models : 32/37/42/47/55LE5***,
32/37/42/47/55LE7***, 42/47/55LE8***, 42/47LX6***...A-1
LCD TV Models : 32/37/42/47/55LD6***,
32/42/47LD7***, 32/37/42LD8*** ..................A-15
PLASMA TV Models : 50/60PK5**, 50/60PK7***,
50/60PK9*** .................................................A-27
EXTERNAL EQUIPMENT SETUP
Antenna Connection............................................1
Connecting with a Component cable..................2
Connecting with an HDMI cable .........................3
Connecting with an HDMI to DVI cable ..............4
Connecting with a Euro Scart cable ...................5
Usb setup ............................................................6
Connecting with AN RF Cable ............................6
Connecting with AN RCA cable ..........................7
Connecting with a D-sub 15 pin cable................8
Insertion of A CI Module......................................9
Headphone Setup ...............................................9
Digital audio out Setup......................................10
External Equipment WIreless Connection ........11
Supported Display Resolution...........................12
Screen Setup for PC mode...............................15
Network setup ...................................................19
WATCHING TV / PROGRAMME CON-
TROL
Turning on the TV .............................................29
Initializing Setup ...............................................29
Programme Selection........................................29
Volume Adjustment ...........................................29
Quick Menu .......................................................30
On Screen Menus Selection and adjustment...31
Auto programme tuning ...................................33
Cable DTV setting.............................................38
Manual programme Tuning...............................39
Programme Edit ...............................................43
Booster ..............................................................47
CI [Common Interface] Information...................48
Software Update ...............................................49
Picture/Sound test.............................................51
Signal Test.........................................................52
Product/service information...............................53
Network Test......................................................53
Simple Manual ..................................................54
Selecting the Programme List...........................55
Input List............................................................57
Input Label ........................................................58
Data Service......................................................59
MHP Service .....................................................60
SIMPLINK..........................................................62
AV Mode............................................................66
Initializing(Reset to original factory settings) ....67
NETCAST
Legal Notice ......................................................68
Netcast Menu ....................................................70
YOUTUBE.........................................................71
AccuWeather.....................................................73
picasa ................................................................74
TO USE THE BLUETOOTH
Bluetooth? ........................................................76
Setting the Bluetooth.........................................77
Bluetooth headset ............................................78
Remove the bluetooth device ...........................82
My Bluetooth Information..................................83
Receiving photos from external Bluetooth device. 84
Listening to the Musics from external Bluetooth
device ................................................................85
TO USE 3D VIDEO
3D Video............................................................86
Caution when using 3D Glasses.......................87
3D Video viewing range....................................87
Watching 3D Video ...........................................88
TO USE A USB OR PC DEVICE
When connecting a USB device .......................90
DLNA.................................................................92
Movie list ...........................................................96
Photo list..........................................................107
Music list..........................................................117
DivX Registration Code...................................126
Deactivation.....................................................127

II
CONTENTS
CONTENTS
GAME
Game...............................................................128
EPG(ELECTRONIC PROGRAMME
GUIDE)(IN DIGITAL MODE)
Switch on/off EPG...........................................130
Select a programme........................................130
Button Function in NOW/NEXT Guide Mode .130
Button Function in 8 Day Guide Mode ...........131
Button Function in Date Change Mode ..........132
Button Function in Extended Description Box 132
Button Function in Record/Remind Setting Mode.133
Button Function in Schedule List Mode..........134
PICTURE CONTROL
Picture Size (Aspect Ratio) Control ................135
Picture Wizard.................................................137
Energy Saving.................................................138
Preset Picture Settings ...................................139
Manual Picture Adjustment .............................141
Picture Improvement Technology....................143
Expert Picture Control.....................................144
Picture Reset...................................................147
Trumotion ........................................................148
LED LOCAL DIMMING ...................................149
Power Indicator ...............................................150
Image Sticking Minimization (ISM) Method ....151
Mode Setting ...................................................152
Demo Mode.....................................................153
SOUND & LANGUAGE CONTROL
Auto Volume Leveler.......................................154
Clear Voice II...................................................155
Preset Sound Settings-Sound Mode ..............156
Sound Setting Adjustment -User Mode ..........157
Infinite Sound ..................................................157
Balance ...........................................................158
TV Speakers On/ Off Setup............................159
DTV Audio Setting (in digital mode only)........160
Selecting Digital Audio out ..............................161
Audio Reset.....................................................162
Audio Description (In digital mode only).........163
I/II
- Stereo/Dual Reception (In Analogue Mode Only)164
- NICAM Reception (In Analogue Mode Only)165
- Speaker Sound Output Selection .................165
On-Screen Menu Language / Country Selection 166
Language Selection ........................................167
TIME SETTING
Clock Setup.....................................................169
Auto on/off time setting ...................................170
Sleep Timer setting .........................................171
PARENTAL CONTROL / RATINGS
Set Password & Lock System.........................172
Block Programme............................................173
Parental Control (In Digital Mode only)...........174
External Input Blocking ...................................175
Key Lock..........................................................176
TELETEXT
Switch on/off ...................................................177
SIMPLE Text....................................................177
TOP Text..........................................................178
FASTEXT ........................................................178
Special Teletext Functions ..............................179
DIGITAL TELETEXT
Teletext within Digital Service .........................180
Teletext in Digital Service................................180
APPENDIX
Troubleshooting...............................................181
Maintenance....................................................183
Product Specifications ...................................184
IR Codes .........................................................201
External Control Device Setup........................202
Open source software notice ..........................209

A-1
PREPARATION
PREPARATION
LED LCD TV MODELS : 32/37/42/47/55LE5***,
32/37/42/47/55LE7***, 42/47/55LE8***, 42/47LX6***
ACCESSORIES
Ensure that the following accessories are included with your TV. If an accessory is missing, please
contact the dealer where you purchased the TV.
■Image shown may differ from your TV.
Owner’s Manual
Nero MediaHome
4 Essentials CD
Batteries
(AAA)
Polishing Cloth
Polishing cloth for
use on the screen.
This item is not included for all models.
* Lightly wipe any stains or
fingerprints on the surface
of the TV with the polish-
ing cloth.
Do not use excessive
force. This may cause
scratching or discoloura-
tion.
Remote Control
AV MODE
LIGHT
INPUT
TV/
RAD
ENERGY
SAVING
1
.,;@
2
abc
3
def
4
ghi
5
jkl
6
mno
7
pqrs
8
tuv
0
[
9
wxyz
BACK EXIT
OK
LIST
Q.VIEW
MENU
Q.MENU
GUIDE
AD APP/*
INFO
FAV
RATIO
MUTE
MARK
DELETE
CHAR/NUM
P
P
A
G
E
Install the power plug closely.
Ferrite Core
( This item is not included
for all models. )
Use of ferrite core (This feature is not available for all models.)
Ferrite core can be used to reduce the
electromagnetic wave when connecting
the power cord.
The closer the location of the ferrite core
to the power plug, the better it is.
Cable Holder
Component gender cable,
AV gender cable
x 2
Bolts for stand assembly
x 8
(M4 x 16)
(Only 32/37/42/47LE5***,
32/37/42/47LE7***,
42/47LX6***)
x 8
(M4 x 20)
(Only 42/47/55LE8***)
x 4x 4
(M4 x 16)(M4 x 24)
(Only 55LE5***,
55LE7***)
1-screw for stand fixing
(Only 32LE5***)
Slightly wipe stained spot on the exterior only with
the cleansing cloths(mitt) for the product exterior if
there is stain or fingerprint on surface of the exterior.
For cleaning front frame, please slowly wipe in one
direction after spraying water 1~2 times on cleansing
cloths. Please remove excessive moisture after cleaning.
Excessive moisture may cause water stains on the frame.
(Only 32/37/42/47/55LE7***)
cleansing cloths(mitt)
3D Glasses
(Only 42/47LX6***)

A-2
PREPARATION
PREPARATION
FRONT PANEL CONTROLS
■Image shown may differ from your TV.
NOTE
►TV can be placed in standby mode in order to reduce the power consumption. And TV should be
switched off using the power switch on the TV if it will not be watched for some time, as this will
reduce energy consumption.
The energy consumed during use can be significantly reduced if the level of
brightness of the picture is reduced, and this will reduce the overall running cost.
CAUTION
►Do not step on the glass stand or subject it to any impact. It may break, causing possible injury from frag-
ments of glass, or the TV may fall.
►Do not drag the TV. The floor or the product may be damaged.
SPEAKER
Emitter (Only 42/47LX6***)
It is the part equipped with the emitter
exchanging signal with 3D glasses.
Please be careful not to block
the screen with objects or people
while watching a 3D Video.
Remote Control Sensor
Intelligent Sensor
Adjusts picture according to
the surrounding conditions.
Only 32/37/42/47/55LE5***, 32/37/42/47/55LE7***, 42/47LX6***
PROGRAMME VOLUME MENU POWER
INPUTOK
Touch Button
You can use the desired button function by touching.
Power/Standby Indicator
(Can be adjusted using the Power
Indicator in the OPTION menu.)

A-3
PREPARATION
SPEAKER
Remote Control Sensor
Intelligent Sensor
Adjusts picture according to
the surrounding conditions.
INPUTOK
MENU POWER
Touch Button
You can use the desired button function by touching.
Only 42/47/55LE8***
Power/Standby Indicator
(Can be adjusted using the Power Indicator in
the OPTION menu.)
PROGRAMME
VOLUME

A-4
PREPARATION
PREPARATION
BACK PANEL INFORMATION
■Image shown may differ from your TV.
Power Cord Socket
This TV operates on an AC power. The volt-
age is indicated on the Specifications page.
(► p.184 to 200) Never attempt to operate
the TV on DC power.
LAN
Network connection for AccuWeather,
Picasa, YouTube, etc.
Also used for video, photo and music files on
a local network.
OPTICAL DIGITAL AUDIO OUT
Connect digital audio to various types of
equipment.
Connect to a Digital Audio Component.
Use an Optical audio cable.
RGB/DVI Audio Input
Connect the audio from a PC or DTV.
Euro Scart Socket (AV1)
Connect scart socket input or output from an
external device to these jacks.
Component Input
Connect a component video/audio device to
these jacks.
HDMI/DVI IN Input
Connect an HDMI signal to HDMI IN. Or DVI
(VIDEO) signal to HDMI/DVI port with DVI to
HDMI cable.
RGB IN Input
Connect the output from a PC.
RS-232C IN (CONTROL & SERVICE) PORT
Connect to the RS-232C port on a PC.
This port is used for Service or Hotel mode.
WIRELESS Control
Connect the Wireless Ready Dongle to the
TV to control the external input devices con-
nected to Wireless Media Box wirelessly.
Audio/Video Input
Connect audio/video output from an external
device to these jacks.
Antenna Input
Connect antenna or cable to this jack.
USB Input
Connect USB storage device to this jack.
PCMCIA (Personal Computer Memory
Card International Association) Card Slot
Insert the CI Module to PCMCIA CARD
SLOT.
(This feature is not available in all countries.)
Headphone Socket
Plug the headphone into the headphone
socket.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
CAUTION
►Use a product with the
following thickness for
optimal connection to
HDMI cable (Only HDMI
IN 4) / USB device.
*A 10 mm
9 10 11 12
7 8
432 56
1
13
14
7
11
6
15
13
14
11
6
7
Only 32/37/42/47/55LE5***,
32/37/42/47/55LE7***,
42/47/55LE8*** Only 42/47LX6***

A-5
PREPARATION
STAND INSTALLATION
■Image shown may differ from your TV.
When assembling the desk type stand, check whether the bolt is fully tightened. (If not tightened fully,
the product can tilt forward after the product installation.) If you tighten the bolt with excessive force,
the bolt can deviate from abrasion of the tightening part of the bolt.
Carefully place the TV screen side down
on a cushioned surface to protect the
screen from damage.
1
Assemble the TV as shown.
3
Assemble the parts of the Stand Rear
Cover with the TV.
4
Stand Rear
Cover
Fix the 4 bolts securely using the holes in
the back of the TV.
5
Assemble the parts of the Stand Body with
the Stand Base of the TV.
At this time, tighten the screws that hold the
Stand Body on.
2
Stand Body
Stand Base
M4 X 16
(Only 32/37/42/47LE5***,
32/37/42/47LE7***, 42/47LX6***)
M4 X 24
(Only 55LE5***,
55LE7***)
M4 X 16
(Only
32/37/42/47/55LE5***,
32/37/42/47/55LE7***,
42/47LX6***)
M4 X 20
(Only 42/47/55LE8***)
M4 X 20
(Only 42/47/55LE8***)

A-6
PREPARATION
PREPARATION
ATTACHING THE TV TO A
DESK
(Only 32LE5***)
Desk
Stand
■Image shown may differ from your TV.
The TV must be attached to desk so it cannot be
pulled in a forward/backward direction, potentially
causing injury or damaging the product. Use only
an attached screw.
WARNING
►To prevent TV from falling over, the TV
should be securely attached to the floor/wall
per installation instructions. Tipping, shaking,
or rocking the machine may cause injury.
1-Screw (provided as parts of the product)
BACK COVER FOR
WIRE ARRANGEMENT
■Image shown may differ from your TV.
1Secure the power cord with the Cable
Holder on the TV back cover.
It will help prevent the power cable from
being removed by accident.
After connecting the cables as necessary,
install Cable Holder as shown and bundle
the cables.
2
Cable Holder
Cable Holder
SWIVEL STAND
■Image shown may differ from your TV.
After installing the TV, you can adjust the TV set
manually to the left or right direction by 20
degrees to suit your viewing position.
