OWNER’S MANUAL
LCD TV MODELS
3322LLHH33******
LCD TV
Please read this manual carefully before operating
your TV.
Retain it for future reference.
Record the model number and serial number of the
TV.
Refer to the label on the back co er and quote this
information.
To your dealer when requiring any ser ice.
ENGLISH

HDMI, the HDMI logo and High-Definition
Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC.

1
ACCESSORIES
ACCESSORIES
Ensure that the following accessories are included with your TV
If an accessory is missing, please contact the dealer where you purchased the TV
■
Image shown may differ from your TV.
Owner’s Manual Batteries
Remote Control
Power Cord
Polishing Cloth
Polishing cloth for use on the screen.
his item is not included for all models.
* Lightly wipe any stains or fingerprints on
the surface of the V with the polishing
cloth.
Do not use excessive force. his may cause
scratching or discolouration.
Bolts for stand assembly
(Refer to p.6)
x 4
Protection cover
(Refer to p.6)
1-screw for stand fixing
(Refer to p.6)
Wall Mounting Bracket(Separate purchase)
RW230
(32LF3***)
AVMODE ENERGYSAVING
MUTE
POWER
LIST
Q.VIEW
RATIO
AVMODEVMODE ENERGYENERGYSASAVINGVING
RETURN
MENU
Q.MENU
MARK
MUTEMUTE
LISTLIST
Q.VIEWQ.VIEW
FAV

CONTENTS
2
CONTENTS
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
PREPARA ION
Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . 4
Back Panel Information . . . . . . . . . . . . . . . . . . . . . . 5
Stand Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Swi el Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Not Using the desk-type stand . . . . . . . . . . . . . . . .6
Attaching the TV to a desk . . . . . . . . . . . . . . . . . . . .6
Back Co er for Wire Arrangement . . . . . . . . . . . . . 7
Careful Installation Ad ice . . . . . . . . . . . . . . . . . . . . 7
Desktop Pedestal Installation . . . . . . . . . . . . . . . . . 8
Wall Mount: Horizontal Installation . . . . . . . . . . . . 8
KENSINGTON SECURITY SYSTEM . . . . . . . . . . . . . . . . . . 9
Antenna Connection . . . . . . . . . . . . . . . . . . . . . . . 10
EX ERNAL EQUIPMEN SE UP
HD Recei er Setup . . . . . . . . . . . . . . . . . . . . . . . . . 11
DVD Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
VCR Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Other A/V Source Setup . . . . . . . . . . . . . . . . . . . . 17
External Stereo Setup . . . . . . . . . . . . . . . . . . . . . . 18
AV Output Setup . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Usb in Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
PC Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
- Screen Setup for PC Mode . . . . . . . . . . . . . . 22
WA CHING V / PROGRAMME CON ROL
Remote Control Key Functions . . . . . . . . . . . . . . . 26
Turning on the TV . . . . . . . . . . . . . . . . . . . . . . . . . 28
Programme Selection . . . . . . . . . . . . . . . . . . . . . . 28
Volume Adjustment . . . . . . . . . . . . . . . . . . . . . . . 28
Quick Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
On-Screen Menus Selection and Adjustment . . . 30
Auto Programme Tuning . . . . . . . . . . . . . . . . . . . . 31
Manual Programme Tuning . . . . . . . . . . . . . . . . . . 32
Programme Edit . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Selecting the Programme List . . . . . . . . . . . . . . . . 36
Fa ourite Programme Setup . . . . . . . . . . . . . . . . . 37
Input List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Input Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Key Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Initializing(Reset to original factory settings) . . . 44
AV Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
O USE A USB DEVICE
When connecting the USB de ice . . . . . . . . . . . . 46
Photo List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Music List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
Mo ie List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Di x Registration Code . . . . . . . . . . . . . . . . . . . . . .57
Deacti ation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58

CONTENTS
3
PIC URE CON ROL
Picture Size (Aspect Ratio) Control....................... 59
Energy Sa ing ............................................................... 61
Preset Picture Settings
- Picture Mode-Preset............................................ 62
Manual Picture Adjustment
- Picture Mode-User option................................. 63
Picture Impro ement Technology........................... 64
Expert Picture Control............................................... 65
Picture Reset................................................................. 68
Power Indicator .............................................................69
Demo Mode.................................................................. 70
Mode Setting................................................................ 71
SOUND & LANGUAGE CON ROL
Auto Volume Le eler................................................... 72
Preset Sound Settings - Sound Mode................... 73
Sound Setting Adjustment - User Mode .............. 74
SRS TruSurround XT .................................................. 74
Clear Voice ll................................................................. 75
Balance........................................................................... 76
TV Speakers On/ Off Setup..................................... 77
Selecting Audio Out................................................... 78
Audio Reset....................................................................79
I/II
- Stereo/Dual Reception....................................... 80
- NICAM Reception .............................................................. 81
- Speaker Sound Output Selection .....................81
On-Screen Menu Language Selection......................... 82
IME SE ING
Clock Setup .................................................................. 83
Auto On/ Off Timer Setting..................................... 84
Sleep Timer Setting .................................................... 84
ELE EX
Switch on/off ............................................................... 85
SIMPLE Text.................................................................. 85
TOP Text........................................................................ 85
FASTEXT .........................................................................86
Special Teletext Functions ........................................ 86
APPENDIX
Troubleshooting........................................................... 87
Maintenance ................................................................ 89
Product Specifications............................................... 90
IR Codes ........................................................................ 91
External Control De ice Setup................................ 93

PREPARATION
4
PREPARATION
FRONT PANEL CONTROLS
■
Image shown may differ from your TV.
GGWhen the TV cannot be turned on with the remote control, press the main power button on the TV.
(When the power is turned off with the main power button on the TV, it will not be turned on with the
remote control.)
CAU ION
INPUT
MENU
OK
P
PROGRAMME
VOLUME
OK
MENU
INPUT
POWER
Remote Control Sensor
Power/Standby Indicator
• Illuminates red in standby mode.
• Illuminates blue when the TV is switched on.
ON OFF
Main Power Switch

5
PREPARATION
P
AUDIO
VIDEO
L(L(MONO)MONO)
R
AUDIOAUDIO
AV
VIDEOVIDEO
IN1
OUT
VARIABLE AUDIO OUTVARIABLE AUDIO OUT
ANTENNA
IN
RGB IN (PC)
RS-232C IN
(CONTROL)
AUDIO IN
(RGB/DVI)
1
2
/DVI IN
COMPONENT IN
5
3
24
689
7
L( MONO)
R
AUDIO
VIDEO
VARIABLE AUDIO OUT
ANTENNA
IN
AV IN2
IN 3
2
7
10
1
■
Image shown may differ from your TV.
Power Cord Socket
This TV operates on an AC power. The oltage is
indicated on the Specifications page. Ne er
attempt to operate the TV on DC power.
HDMI Input
Connect a HDMI signal to HDMI IN.
Or DVI(VIDEO)signal to HDMI/DVI port with DVI
to HDMI cable.
RS-232C IN PORT
Connect to the RS-232C port on a PC.
This port is used for Ser ice or Hotel mode.
RGB IN Input
Connect the output from a PC.
RGB/DVI Audio Input
Connect the audio from a PC.
Component Input
Connect a component ideo/audio de ice to
these jacks.
Audio/Video Input
Connect audio/ ideo output from an external
de ice to these jacks.
AV Output
Connect second TV or monitor to the AV OUT
socket on the TV.
Variable Audio Output
Connect an external amplifier or add a subwoofer
to your surround sound system.
Antenna Input
Connect RF antenna to this jack.
USB IN Input
Connect USB storage de ice to this jack.
S-Video Input
Connect S-Video out from an S-VIDEO de ice.
1
2
3
4
5
6
8
9
10
11
7
11
BACK PANEL INFORMATION

6
PREPARATION
PREPARATION
STAND INSTALLATION
■
Image shown may differ from your TV.
When assembling the desk type stand, check whether the
bolt is fully tightened. (If not tightened fully, the product
can tilt forward after the product installation.) If you
tighten the bolt with excessi e force, the bolt can de iate
from abrasion of the tightening part of the bolt.
1
2
3
Carefully place the TV screen side down on a cushioned
surface to protect the screen from damage.
Assemble the TV as shown.
Fix the 4 bolts securely using the holes in the
back of the TV.
ATTACHING THE TV TO A
DESK
■
Image shown may differ from your TV.
The TV must be attached to desk so it cannot be pulled
in a forward/backward direction, potentially causing
injury or damaging the product. Use only an attached
screw.
1-Screw (pro ided as parts of the product)
Desk
Stand
WARNING
!
G To prevent TV from falling over, the TV should
be securely attached to the floor/wall per installa-
tion instructions Tipping, shaking, or rocking the
machine may cause injury
■
Image shown may differ from your TV.
When installing the wall-mounted unit, use the pro-
tection cover
NOT USING THE DESK-TYPE
STAND
Insert the PPRROOTTEECCTTIIOONN CCOOVVEERRinto the TV
until clicking sound.
SWIVEL STAND
■
This feature is not a ailable for all models.
■
After installing the TV, you can adjust the TV manually
to the left or right direction by 20 degrees to suit your
iewing position.

7
PREPARATION
BACK COVER FOR WIRE
ARRANGEMENT
■
Image shown may differ from your TV.
Connect the cables as necessary.
To connect additional equipment, see the
External Equipment Setup section of the manual.
1
Open the CCAABBLLEE MMAANNAAGGEEMMEENNTT CCLLIIPPas
shown and manage the cables.
2
CABLE MANAGEMENT CLIP
Fit the CCAABBLLEE MMAANNAAGGEEMMEENNTT CCLLIIPPas
shown.
3
GGDo not hold the CABLE MANAGEMEN CLIP
when mo ing the TV.
- If the TV is dropped, you may be injured or
the TV may be damaged.
NO E
!
CAREFUL INSTALLATION ADVICE
AYou should purchase necessary components to fix the TV
safety and secure to the wall on the market.
APosition the TV close to the wall to avoid the possibility
of it falling when pushed
AThe instructions shown below are a safer way to set up
the TV, by fixing it to the wall, avoiding the possibility of
it falling forwards if pulled This will prevent the TV from
falling forward and causing injury This will also prevent
the TV from damage Ensure that children do not climb
or hang from the TV
NO E
!
G When moving the TV undo the cords first
G Use a platform or cabinet strong and large enough
to support the size and weight of the TV
G To use the TV safely make sure that the height of the
bracket on the wall and on the TV is the same
3
1
2
Use the eye-bolts or TV brackets/bolts to fix the
product to the wall as shown in the picture.
(If your TV has bolts in the eyebolts, loosen then
bolts.)
* Insert the eye-bolts or TV brackets/bolts and tight-
en them securely in the upper holes.
Secure the wall brackets with the bolts on the wall.
Match the height of the bracket that is mounted on
the wall.
3
Use a sturdy rope to tie the product for alignment. It
is safer to tie the rope so it becomes horizontal
between the wall and the product.
2
1
2
1

8
PREPARATION
PREPARATION
AThe TV can be installed in various ways such as on
a wall, or on a desktop etc
A The TV is designed to be mounted horizontally
Power Supply
Circuit breaker
EAR HING
Ensure that you connect the earth wire to pre ent
possible electric shock. If grounding methods are not
possible, ha e a qualified electrician install a separate
circuit breaker.
Do not try to earth the TV by connecting it to tele-
phone wires, lightening rods or gas pipes.
4 inches
4 inches 4 inches 4 inches
DESKTOP PEDESTAL INSTALLATION
For adequate ventilation allow a clearance of 4”
(10cm) all around the TV
WALL MOUNT: HORIZONTAL
INSTALLATION
AWe recommend the use of a LG Brand wall mounting
bracket when mounting the TV to a wall
AWe recommend that you purchase a wall mounting
bracket which supports VESA standard
ALG recommends that wall mounting be performed
by a qualified professional installer
4 inches
4 inches
4 inches
4 inches
4 inches
NO E
!
G Should Install wall mount on a solid wall perpendicular to
the floor
G Should use a special wall mount, if you want to install it to
ceiling or slanted wall
G The surface that wall mount is to be mounted on should
be of sufficient strength to support the weight of TV set;
e g concrete, natural rock, brick and hollow block
G Installing screw type and length depends on the wall
mount used Further information, refer to the instructions
included with the mount
G LG is not liable for any accidents or damage to property or
TV due to incorrect installation:
- Where a non-compliant VESA wall mount is used
- Incorrect fastening of screws to surface which may cause
TV to fall and cause personal injury
- Not following the recommended Installation method
Model VESA
(A *B) Standard
Screw Quantity
32LH3*** 200 * 10 0 M 4 4
AA
BB

9
PREPARATION
KENSINGTON SECURITY SYSTEM
■
This feature is not a ailable for all models.
■
Image shown may differ from your TV.
The TV is equipped with a Kensington Security System connector on the back panel. Connect the Kensington
Security System cable as shown below.
For the detailed installation and use of the Kensington Security System, refer to the user’s guide pro ided with
the Kensington Security System.
For further information, contact http://www kensington com, the internet homepage of the Kensington
company. Kensington sells security systems for expensi e electronic equipment such as notebook PCs and LCD
projectors.
NOTE
- The Kensington Security System is an optional accessory.
NOTES
a. If the TV feels cold to the touch, there may be a small “flicker” when when it is turned on.
This is normal, there is nothing wrong with TV.
b. Some minute dot defects may be isible on the screen, appearing as tiny red, green, or blue spots. Howe er,
they ha e no ad erse effect on the monitor's performance.
c. A oid touching the LCD screen or holding your finger(s)
against it for long periods of time.
Doing so may produce some temporary distortion effects on the screen.

10
PREPARATION
PREPARATION
L(MONO)
R
AUDIO
VIDEO
VARIABLE AUDIO OUT
ANTENNA
IN
L(MONO)
R
AUDIO
VIDEO
VARIABLE AUDIO OUT
ANTENNA
IN
P
ANTENNA CONNECTION
■For optimum picture quality, adjust antenna direction.
■An antenna cable and con erter are not supplied.
■To pre ent damage do not connect to the mains outlet until all connections are made between the de ices.
Multi-family Dwellings/Apartments
(Connect to wall antenna socket)
Single-family Dwellings /Houses
(Connect to wall jack for outdoor antenna)
Outdoor
Antenna
(VHF, UHF)
Wall
Antenna
Socket
RF Coaxial Wire (75 ohm)
Antenna
UHF
Signal
Amplifier
VHF
■In poor signal areas, to achie e better picture quality it may be necessary to install a signal amplifier to the
antenna as shown abo e.
■If signal needs to be split for two TVs, use an antenna signal splitter for connection.

11
EXTERNAL EQUIPMENT SETUP
EXTERNAL EQUIPMENT SETUP
COMPONENT IN
AUDIO
VIDEO
HD RECEIVER SETUP
■To avoid damaging any equipment, never plug in any power cords until you have finished connecting all equipment
■
Image shown may differ from your TV.
Connecting with a component cable
12
Signal
480i/576i
480p/576p
720p/1080i
1080p
Component
O
O
O
O
(50/60Hz only)
HDMI
X
O
O
O
(24Hz/30Hz/50Hz/60Hz)
Connect the ideo outputs (Y, PB, PR)of the digital set
top box to the CCOOMMPPOONNEENNTT IINN VVIIDDEEOOjacks on the
TV.
Connect the audio output of the digital set-top box to
the CCOOMMPPOONNEENNTT IINN AAUUDDIIOOjacks on the TV.
Turn on the digital set-top box.
(Refer to the owner’s manual for the digital set-top box.)
Select CCoommppoonneennttinput source using the IINNPPUUTT
button on the remote control.
2
3
4
1

12
EXTERNAL EQUIPMENT SETUP
EXTERNAL EQUIPMENT SETUP
Connecting a set-top box with an HDMI cable
Connect the digital set-top box to HHDDMMII//DDVVII IINN 11,
HHDDMMII IINN22 or HHDDMMII IINN33jack on the TV.
Turn on the digital set-top box.
(Refer to the owner’s manual for the digital set-top box.)
Select HHDDMMII11. HHDDMMII22 or HHDDMMII IINN33input source
using the IINNPPUUTTbutton on the remote control.
2
3
1
GGCheck that your HDMI cable is ersion 1.3 or higher.
If the HDMI cables don’t support HDMI ersion 1.3, flicker-
ing or no screen display can result. Please use the latest
cables that support at least HDMI ersion 1.3.
NO E
!
1
2
/DVI IN
1
Connecting with an HDMI to DVI cable
Connect the digital set-top box to HHDDMMII//DDVVII IINN 11
jack on the TV.
Connect the audio output of the digital set-top box to
the AAUUDDIIOO IINN ((RRGGBB//DDVVII)) jack on the TV.
Turn on the digital set-top box. (Refer to the owner’s
manual for the digital set-top box.)
Select HHDDMMII11 input source using the IINNPPUUTTbutton
on the remote control.
2
3
4
1
COMPONENT IN
VIDEO
LYP
B P R R
AUDIO
VIDEO
AUD
/MONO
RGB IN (PC)
RS-232C IN
(CONTROL)
AUDIO IN
(RGB/DVI)
AV
VARIABLE AUDIO
1
/DVI IN
2
12

13
EXTERNAL EQUIPMENT SETUP
DVD SETUP
Connecting with a component cable
COMPONENT IN
AUDIO
VIDEO
Component Input ports
To achieve better picture quality, connect a DVD player to the component input ports as shown below
Component ports on the TV
YPBPR
Video output ports
on DVD player
Y
Y
Y
Y
PB
B-Y
Cb
Pb
PR
R-Y
Cr
Pr
12
Connect the ideo outputs (Y, PB, PR)of the DVD to the
CCOOMMPPOONNEENNTT IINN VVIIDDEEOOjacks on the TV.
Connect the audio outputs of the DVD to the
CCOOMMPPOONNEENNTT IINN AAUUDDIIOOjacks on the TV.
Turn on the DVD player, insert a DVD.
Select CCoommppoonneenntt input source using the IINNPPUUTT
button on the remote control.
Refer to the DVD player's manual for operating instruc-
tions.
2
3
4
5
1

14
EXTERNAL EQUIPMENT SETUP
EXTERNAL EQUIPMENT SETUP
GGThe TV can recei e ideo and audio signals simultaneously when using a
HDMI cable.
GGIf the DVD does not support Auto HDMI, you must set the output reso-
lution appropriately.
GGCheck that your HDMI cable is ersion 1.3 or higher.
If the HDMI cables don’t support HDMI ersion 1.3, flickering or no
screen display can result. Please use the latest cables that support at
least HDMI ersion 1.3.
GGWe recommed using under 10m of the HDMI cable. When using o er the
length, connect a amplifier or repeater.
NO E
!
Connecting the HDMI cable
Connect the HDMI output of the DVD to the
HHDDMMII//DDVVII IINN 11,HHDDMMII IINN22 or HHDDMMII IINN33jack on
the TV.
Select HHDDMMII11, HHDDMMII IINN22 or HHDDMMII IINN33input
source using the IINNPPUUTTbutton on the remote control.
Refer to the DVD player's manual for operating instructions.
2
3
1
1
2
/DVI IN
1
Connecting with a S-Video cable
Connect the S-VIDEO output of the DVD to the
SS--VVIIDDEEOOinput on the TV.
Connect the audio outputs of the DVD to the AAUUDDIIOO
input jacks on the TV.
Turn on the DVD player, insert a DVD.
Select AAVV 11input source using the IINNPPUUTTbutton
on the remote control.
Refer to the DVD player's manual for operating
instructions.
2
3
4
5
1
L R
AUDIO
VIDEO
AUDIO
/MONO
ANTENNA
IN
B IN (PC)
O)
AUDIO IN
(RGB/DVI)
AV
VARIABLE AUDIO OUT
IN1
OUT
VIDEO
OUTPUT
SWITCH
ANT IN
ANT OUT
L R S-VIDEO
1
2

15
EXTERNAL EQUIPMENT SETUP
VCR SETUP
■To avoid picture noise (interference), allow adequate distance between the VCR and TV
Connecting with a RF Cable
Connect the AANNTT OOUUTTsocket of the VCR to the AANNTTEENNNNAA IINNsocket on the TV.
Connect the antenna cable to the AANNTT IINNsocket of the VCR.
Press the PPLLAAYYbutton on the VCR and match the appropriate channel between the TV and VCR for
iewing.
2
3
1
ANTENNA
IN
OUTPUT
SWITCH
ANT IN
R
S-VIDEO VIDEO
ANT OUT L
VIDEO
AUDIO
/MONO
AV
VARIABLE AUDIO OUT
IN1
OUT
Wall Jack
Antenna
1
2

16
EXTERNAL EQUIPMENT SETUP
EXTERNAL EQUIPMENT SETUP
Connecting with a RCA cable
Connect the AAUUDDIIOO/VVIIDDEEOOjacks between TV and
VCR. Match the jack colours (Video = yellow, Audio Left
= white, and Audio Right = red)
Insert a ideo tape into the VCR and press PLAY on
the VCR. (Refer to the VCR owner’s manual.)
Select AAVV22input source using the IINNPPUUTTbutton on
the remote control.
If connected to AAVV IINN 11, select AAVV11 input source.
1
2
3
GGIf you ha e a mono VCR, connect the audio cable from the
VCR to the AAUUDDIIOO LL//MMOONNOOjack of the TV.
NO E
!
AV IN2
LR
S-VIDEO VIDEO
OUTPUT
SWITCH
ANT IN
ANT OUT
GGIf both S-VIDEO and VIDEO sockets ha e been connected to
the S-VHS VCR simultaneously, only the S-VIDEO can be
recei ed.
NO E
!
NT IN
L R
AUDIO
VIDEO
AUDIO
/MONO
RGB IN (PC)
AUDIO IN
(RGB/DVI)
AV
VARIABLE AUDIO OUT
OUT
IN1
LR
S-VIDEO VIDEO
OUTPUT
SWITCH
ANT IN
ANT OUT
Connecting with a S-Video cable
Connect the S-VIDEO output of the VCR to the SS --
VVIIDDEEOOinput on the TV set. The picture quality is
impro ed; compared to normal composite (RCA cable)
input.
Connect the audio outputs of the VCR to the AAUUDDIIOO
input jacks on the TV.
Insert a ideo tape into the VCR and press PLAY on the
VCR. (Refer to the VCR owner’s manual.)
Select AAVV 11input source with using the IINNPPUUTTbutton
on the remote control.
2
3
4
1
1
2
1
EXTERNAL EQUIPMENT SETUP

17
EXTERNAL EQUIPMENT SETUP
OTHER A/V SOURCE SETUP
Connect the AAUUDDIIOO/VVIIDDEEOOjacks between TV and external equipment. Match the jack colours
.
(Video = yellow, Audio Left = white, and Audio Right = red)
Select AAVV11 input source with using the IINNPPUUTTbutton on the remote control.
If connected to AAVV IINN 22, select AAVV22 input source.
Operate the corresponding external equipment.
Refer to external equipment operating guide.
1
2
3
L/MONO
R
AUDIO
VIDEO
AV IN2
IN 3
L R
VIDEO
Camcorder
Video Game Set
1
R
O
C)
RVICE)
AUDIO IN
(RGB/DVI)
AV OUT
VARIABLE AUDIO OUT
L/L/MONOMONO
R
AUDIOAUDIO
VIDEOVIDEO
AV IN1
L R
VIDEO
ANTENNA
IN
Camcorder
Video Game Set
1
or

18
EXTERNAL EQUIPMENT SETUP
EXTERNAL EQUIPMENT SETUP
EXTERNAL STEREO SETUP
T IN
L R
AUDIO
VIDEO
AUDIO
/MONO
AV
VARIABLE AUDIO OUT
OUT
IN1
GGWhen connecting with external audio equipments, such as
amplifiers or speakers, please turn the TV speakers off.
(GG pp..7777)
GGSelect VVaarriiaabbllee OOuuttin AAUUDDIIOOmenu to connect the
VVAARRIIAABBLLEE AAUUDDIIOO OOUUTTjacks.(GG pp..7788)
NO E
!
Use to connected either an external amplifier, or add a sub-woofer
to your surround sound system
Connect the input jack of the stereo amplifier to the
VVAARRIIAABBLLEE AAUUDDIIOO OOUUTTjacks on the TV.
Set up your speakers through your analog stereo
amplifier, according to the instructions pro ided with
the amplifier.
2
1
11
AV OUTPUT SETUP
The TV has a special signal output capability which allows you
to hook up the second TV or monitor
VIDEO
AUDIO
/MONO
AUDIO IN
(RGB/DVI)
AV
VARIABLE AUDIO OUT
OUT
IN1
L R
S-VIDEO
VIDEO
Connect the second TV or monitor to the TV’s AAVV OOUUTT
jacks.
See the Operating Manual of the second TV or monitor
for further details regarding that de ice’s input settings.
GGComponent, RGB, HDMI input sources cannot be used for
AV out.
GGWe recommend to use the AV OUT jacks for VCR recording.
NO E
!
2
1
1
EXTERNAL EQUIPMENT SETUP
