LG 40UH61 Series User manual

Please read this manual carefully before operating your set and
retain it for future reference.
*MFL69361119* www.lg.com
P/NO : MFL69361119(1607-REV02)
Printed in Korea
Safety and Reference
OWNER’S MANUAL
LED TV*
* LG LED TV applies LCD screen with LED
backlights.

2
ENGLISH
Safety instructions
Please read these safety precautions
carefully before using the product.
WARNING
Do not place theTV and/or remote control in
the following environments:
• A location exposed to direct sunlight
• An area with high humidity such as a
bathroom
• Near any heat source such as stoves and
other devices that produce heat
• Near kitchen counters or humidiers where
they can easily be exposed to steam or oil
• An area exposed to rain or wind
• Near containers of water such as vases
Otherwise, this may result in re, electric
shock, malfunction or product deformation.
Do not place the product where it might be
exposed to dust.This may cause a re hazard.
Mains Plug is theTV connecting/disconnecting
device to AC mains electric supply. This plug
must remain readily attached and operable
whenTV is in use.
Do not touch the power plug with wet hands.
Additionally, if the cord pin is wet or covered
with dust, dry the power plug completely or
wipe dust o. You may be electrocuted due to
excess moisture.
Make sure to connect Mains cable to compliant
AC mains socket with Grounded earth pin.
(Except for devices which are not grounded
on earth.) Otherwise possibility you may be
electrocuted or injured.
Insert power cable plug completely into wall
socket otherwise if not secured completely into
socket, re ignition may break out.
Ensure the power cord does not come into
contact with hot objects such as a heater.This
may cause a re or an electric shock hazard.
Do not place a heavy object, or the product
itself, on power cables.
Otherwise, this may result in re or electric
shock.

ENGLISH
3
Bend antenna cable between inside and
outside building to prevent rain from owing
in.This may cause water damaged inside the
Product and could give an electric shock.
When mountingTV onto wall make sure to
neatly install and isolate cabling from rear of
TV as to not create possibility of electric shock /
re hazard.
Do not plug too many electrical devices into a
single multiple electrical outlet. Otherwise, this
may result in re due to over-heating.
Do not drop the product or let it fall over when
connecting external devices. Otherwise, this
may result in injury or damage to the product.
Keep the anti-moisture packing material or
vinyl packing out of the reach of children.
Anti-moisture material is harmful if
swallowed. If swallowed by mistake, force
the patient to vomit and visit the nearest
hospital. Additionally, vinyl packing can cause
suocation. Keep it out of the reach of children.
Do not let your children climb or cling onto the
TV.
Otherwise, theTV may fall over, which may
cause serious injury.
Dispose of used batteries carefully to ensure
that a small child does not consume them.
Please seek Doctor- Medical Attention
immediately if child consumes batteries.
Do not insert any metal objects/conductors
(like a metal chopstick/cutlery/screwdriver)
between power cable plug and input Wall
Socket while it is connected to the input
terminal on the wall. Additionally, do not touch
the power cable right after plugging into the
wall input terminal. You may be electrocuted.
(Depending on model)
Do not put or store inammable substances
near the product.There is a danger of
combustion/explosion or re due to careless
handling of the inammable substances.

4
ENGLISH
Do not drop metallic objects such as coins,
hair pins, chopsticks or wire into the product,
or inammable objects such as paper and
matches. Children must pay particular
attention. Electrical shock, re or injury can
occur. If a foreign object is dropped into the
product, unplug the power cord and contact the
service centre.
Do not spray water on the product or scrub
with an inammable substance (thinner or
benzene). Fire or electric shock accident can
occur.
Do not allow any impact, shock or any objects
to fall into the unit, and do not drop anything
onto the screen.You may be injured or the
product can be damaged.
Never touch this product or antenna during a
thunder or lighting storm.
You may be electrocuted.
Never touch the wall outlet when there
is leakage of gas, open the windows and
ventilate. It may cause a re or a burn by a
spark.
Do not disassemble, repair or modify the
product at your own discretion. Fire or electric
shock accident can occur.
Contact the service centre for check, calibration
or repair.
If any of the following occur, unplug the
product immediately and contact your local
service centre.
• The product has been impacted by shock
• The product has been damaged
• Foreign objects have entered the product
• The product produced smoke or a strange
smell
This may result in re or electric shock.
Unplug theTV from AC mains wall socket if you
do not intend to use theTV for a long period of
time. Accumulated dust can cause re hazard
and insulation deterioration can cause electric
leakage/shock/re.

ENGLISH
5
Apparatus shall not be exposed to dripping or
splashing and no objects lled with liquids,
such as vases, shall be placed on the apparatus.
Do not install this product on a wall if it could
be exposed to oil or oil mist.This may damage
the product and cause it to fall.
If water enters or comes into contact withTV,
AC adapter or power cord please disconnect
the power cord and contact service centre
immediately. Otherwise, this may result in
electric shock or re.
Only use an authorized AC adapter and power
cord approved by LG Electronics. Otherwise, this
may result in re, electric shock, malfunction or
product deformation.
Never Disassemble the AC adapter or power
cord. This may result in re or electric shock.
Be careful in handling the adapter to prevent
any external shocks to it. An external shock may
cause damage to the adapter.
Make sure the power cord is connected securely
to the power plug on theTV. (Depending on
model)
CAUTION
Install the product where no radio wave occurs.
There should be enough distance between an
outside antenna and power lines to keep the
former from touching the latter even when the
antenna falls.This may cause an electric shock.
Do not install the product on places such as
unstable shelves or inclined surfaces. Also avoid
places where there is vibration or where the
product cannot be fully supported. Otherwise,
the product may fall or ip over, which may
cause injury or damage to the product.

6
ENGLISH
If you install theTV on a stand, you need to
take actions to prevent the product from
overturning. Otherwise, the product may fall
over, which may cause injury.
If you intend to mount the product to a wall,
attachVESA standard mounting interface
(optional parts) to the back of the product.
When you install the set to use the wall
mounting bracket (optional parts), x it
carefully so as not to drop.
Only use the attachments / accessories specied
by the manufacturer.
When installing the antenna, consult with a
qualied service technician. If not installed by
a qualied technician, this may create a re
hazard or an electric shock hazard.
We recommend that you maintain a distance
of at least 2 to 7 times the diagonal screen size
when watchingTV. If you watchTV for a long
period of time, this may cause blurred vision.
Only use the specied type of battery. This could
cause damage to the remote control.
Do not mix new batteries with old batteries.
This may cause the batteries to overheat and
leak.
Batteries should not be exposed to excessive
heat. For example, keep away from direct
Sunlight, open replace and electric heaters.
Do not place non-rechargeable batteries in
charging device.
Make sure there are no objects between the
remote control and its sensor.
Signal from Remote Control can be interrupted
due to external/internal lighting eg Sunlight,
uorescent lighting. If this occurs turn o
lighting or darken viewing area.

ENGLISH
7
When connecting external devices such as
video game consoles, make sure the connecting
cables are long enough. Otherwise, the product
may fall over, which may cause injury or
damage the product.
Do not turn the product On/O by plugging-
in or unplugging the power plug to the wall
outlet. (Do not use the power plug for switch.)
It may cause mechanical failure or could give an
electric shock.
Please follow the installation instructions
below to prevent the product from overheating.
• The distance between the product and the
wall should be more than 10cm.
• Do not install the product in a place with
no ventilation (e.g., on a bookshelf or in a
cupboard).
• Do not install the product on a carpet or
cushion.
• Make sure the air vent is not blocked by a
tablecloth or curtain.
Otherwise, this may result in re.
Take care not to touch the ventilation openings
when watching theTV for long periods as the
ventilation openings may become hot.This
does not aect the operation or performance of
the product.
Periodically examine the cord of your appliance,
and if its appearance indicates damage or
deterioration, unplug it, discontinue use of the
appliance, and have the cord replaced with
an exact replacement part by an authorized
servicer.
Prevent dust collecting on the power plug pins
or outlet.This may cause a re hazard.
Protect the power cord from physical or
mechanical abuse, such as being twisted,
kinked, pinched, closed in a door, or walked
upon. Pay particular attention to plugs, wall
outlets, and the point where the cord exits the
appliance.
Do not press strongly upon the panel with a
hand or sharp object such as nail, pencil or pen,
or make a scratch on it, as it may causedamage
to screen.

8
ENGLISH
Avoid touching the screen or holding your
nger(s) against it for long periods of time.
Doing so may produce some temporary or
permanent distortion/damage to screen.
When cleaning the product and its components,
unplug the power rst and wipe it with a soft
cloth. Applying excessive force may cause
scratches or discolouration. Do not spray with
water or wipe with a wet cloth. Never use glass
cleaner, car or industrial shiner, abrasives or
wax, benzene, alcohol etc., which can damage
the product and its panel. Otherwise, this may
result in re, electric shock or product damage
(deformation, corrosion or breakage).
As long as this unit is connected to the AC wall
outlet, it is not disconnected from the AC power
source even if you turn o this unit by SWITCH.
When unplugging the cable, grab the plug and
unplug it, by pulling at the plug.
Don’t pull at the cord to unplug the power
cord from the power board, as this could be
hazardous.
When moving the product, make sure you turn
the power o rst. Then, unplug the power
cables, antenna cables and all connecting
cables.
TheTV set or power cord may be damaged,
which may create a re hazard or cause electric
shock.
When moving or unpacking the product,
work in pairs because the product is heavy.
Otherwise, this may result in injury.
Refer all servicing to qualied service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or
has been dropped.
If the product feels cold to the touch, there may
be a small“icker”when it is turned on.This is
normal, there is nothing wrong with product.

ENGLISH
9
This panel is an advanced product that contains
millions of pixels.You may see tiny black dots
and/or brightly coloured dots (red, blue or
green) at a size of 1ppm on the panel.This does
not indicate a malfunction and does not aect
the performance and reliability of the product.
This phenomenon also occurs in third-party
products and is not subject to exchange or
refund.
You may nd dierent brightness and color
of the panel depending on your viewing
position(left/right/top/down).
This phenomenon occurs due to the
characteristic of the panel. It is not related
with the product performance, and it is not
malfunction.
Displaying a still image for a prolonged period
of time may cause image sticking. Avoid
displaying a xed image on theTV screen for a
long period of time.
Generated Sound
“Cracking”noise: A cracking noise that
occurs when watching or turning o theTV
is generated by plastic thermal contraction
due to tempera-ture and humidity. This
noise is common for products where thermal
deformation is required. Electrical circuit
humming/panel buzzing: A low level noise is
generated from a high-speed switching circuit,
which supplies a large amount of current to
operate a product. It varies depending on the
product.
This generated sound does not aect the
performance and reliability of the product.
Do not use high voltage electrical goods near
theTV (e.g. electric mosquito-swatter).This
may result in product malfunction.

10
ENGLISH
Viewing 3D imaging (Only
3D models)
CAUTION
• Children should be supervised by an
adult when viewing 3D video. If a child
experiences eye fatigue, headaches or
blurred vision while watching 3D, they
should take a break, before they resume
watching 3D content.
• When viewing a 3D video, some may
experience discomfort such as a headache,
dizziness, fatigue, or blurred vision. In this
case, stop watching the 3D video and take
a rest.
• If you watch a 3D video for a long time, you
may experience eye fatigue. In this case,
stop watching the 3D video and take a rest.
• Only use LG 3D glasses. Otherwise, you may
not be able to view 3D videos properly.
• Do not use 3D glasses instead of your
normal glasses, sunglasses, or protective
goggles.
• Do not keep your 3D glasses in extremely
high or low temperatures. It will cause
deformation.
• Do not use 3D glasses while walking or
moving around. It may cause an accident or
injury.
• Be careful not to poke your eye with the
frames of the 3D glasses.
• Do not watch 3D content if you have
photosensitive seizures, epilepsy, or heart
disease.
Preparing
NOTE
• If theTV is turned on for the rst time
after it was shipped from the factory,
initialization of theTV may take a few
minutes.
• Image shown may dier from yourTV.
• Your TV’s OSD (On Screen Display) may dier
slightly from that shown in this manual.
• The available menus and options may dier
from the input source or product model that
you are using.
• New features may be added to thisTV in the
future.
• The items supplied with your product may
vary depending on the model.
• Product specications or contents of this
manual may be changed without prior
notice due to upgrade of product functions.
• For an optimal connection, HDMI cables
and USB devices should have bezels less
than 10 mm thick and 18 mm width. Use an
extension cable that supports USB 2.0 if the
USB cable or USB memory stick does not t
into yourTV’s USB port.
A
B
A
B
*A
<
=
10 mm
*B
<
=
18 mm
• Use a certied cable with the HDMI logo
attached.
• If you do not use a certied HDMI cable, the
screen may not display or a connection error
may occur. (Recommended HDMI Cable
Types)

ENGLISH
11
-High-Speed HDMI®/TM cable (3 m or less)
-High-Speed HDMI®/TM cable with Ethernet
(3 m or less)
• How to use the ferrite core (Depending on
model)
-Use the ferrite core to reduce the
electromagnetic interference in the power
cord. Wind the power cord on the ferrite
core once.
[Wall side] [TV side]
10 cm (+ / -2 cm)
• Antenna Isolator Installation Guide
(Depending on model)
-Use this to installTV in a place where there
is a voltage dierence betweenTV Set and
GND of antenna signal.
»If there is a voltage difference between
TV Set and GND of antenna signal, the
antenna contact might be heated and
excessive heat might cause an accident.
-You can improve the safety when watching
TV by eciently removing power voltage
fromTV antenna. It is recommended to
mount the isolator to the wall. If it cannot
be mounted to the wall, mount it on the
TV. Avoid disconnecting the antenna
Isolator after installation.
-Before starting, be sure that theTV
antenna is connected.
ANTENNA/
CABLE IN
Wall
Cable /
Antenna
or
Isolator
1. Connect toTV.
2. Connect to Set-Top box.
-Connect one end of the isolator to cable/
antenna jack and the other toTV set or
set-top box.
-“Equipment connected to the protective
earthing of the building installation
through the mains connection or through
other equipment with a connection
to protective earthing - and to a cable
distribution system using coaxial cable,
may in some circumstances create a re
hazard. Connection to a cable distribution
system has therefore to be provided
through a device providing electrical
isolation below a certain frequency range
(galvanic isolator, see EN 60728-11)”
-When applying the RF Isolator, a slight loss
of signal sensitivity can occur.

12
ENGLISH
CAUTION
• Do not use any unapproved items to ensure
the safety and product life span.
• Any damage or injuries caused by using
unapproved items are not covered by the
warranty.
• Some models have a thin lm attached on
to the screen and this must not be removed.
• When attaching the stand to theTV
set, place the screen facing down on a
cushioned table or at surface to protect
the screen from scratches.
• Make sure that the screws are inserted
correctly and fastened securely. (If they are
not fastened securely enough, theTV may
tilt forward after being installed.) Do not
use too much force and over tighten the
screws; otherwise screw may be damaged
and not tighten correctly.
• Make sure to wring any excess water or
cleaner from the cloth.
• Do not spray water or cleaner directly onto
theTV screen.
• Make sure to spray just enough of water or
cleaner onto a dry cloth to wipe the screen.
• When cleaning the product, be careful not
to allow any liquid or foreign objects to
enter the gap between the upper, left or
right side of the panel and the guide panel.
(Depending on model)
Separate purchase
Separate purchase items can be changed or
modied for quality improvement without any
notication. Contact your dealer to buy these
items. These devices only work with certain
models.
The model name or design may be changed
depending on the upgrade of product functions,
manufacturer’s circumstances or policies.
(Depending on model)
AG-F***
Cinema 3D Glasses
AN-MR650
Magic Remote
AN-VC550
Smart camera
AG-F***DP
Dual Play Glasses
Lifting and moving
the TV
Please note the following advice to prevent the
TV from being scratched or damaged and for
safe transportation regardless of its type and
size.
• It is recommended to move theTV in
the box or packing material that theTV
originally came in.
• Before moving or lifting theTV, disconnect
the power cord and all cables.
• When holding theTV, the screen should
face away from you to avoid damage.

ENGLISH
13
• Hold the top and bottom of theTV
frame rmly. Make sure not to hold the
transparent part, speaker, or speaker grill
area.
• When transporting a largeTV, there should
be at least 2 people.
• When transporting the TV by hand, hold the
TV as shown in the following illustration.
• When transporting the TV, do not expose
theTV to jolts or excessive vibration.
• When transporting the TV, keep theTV
upright, never turn the TV on its side or tilt
towards the left or right.
• Do not apply excessive pressure to cause
exing /bending of frame chassis as it may
damage screen.
• When handling theTV, be careful not to
damage the protruding buttons.
CAUTION
• Avoid touching the screen at all times, as
this may result in damage to the screen.
• Do not move theTV by holding the cable
holders, as the cable holders may break,
and injuries and damage to theTV may
occur.
Using the button
(Depending on model)
You can simply operate theTV functions,
pressing or moving the button.
NOTE
• 43/49UH60, 43/49UH61, 43/49UH62 series
does not have a Joystick functions but has
only a power On/O button.
<A type>
Joystick Button
Dome Button
or
<B type>
Joystick Button

14
ENGLISH
Basic functions
Power On (Press)
Power O (Press
and hold)1
Volume Control
Programmes
Control
1 All running apps will close, and any
recording in progress will stop.
Adjusting the menu
When theTV is turned on, press the button
one time.You can adjust the Menu items
pressing or moving the buttons.
Turns the power o.
Clears on-screen displays and returns
toTV viewing.
Changes the input source.
Accesses the settings menu.
Mounting on a
table
1 Lift and tilt theTV into its upright position
on a table.
• Leave a 10 cm (minimum) space from the
wall for proper ventilation.
10 cm
10 cm
10 cm
10 cm
10 cm
2 Connect the power cord to a wall outlet.
CAUTION
• Do not place theTV near or on sources
of heat, as this may result in re or other
damage.
Securing the TV to a wall
(This feature is not available for all models.)
1 Insert and tighten the eye-bolts, orTV
brackets and bolts on the back of theTV.
• If there are bolts inserted at the eye-bolts
position, remove the bolts rst.
2 Mount the wall brackets with the bolts to
the wall.
Match the location of the wall bracket and
the eye-bolts on the rear of theTV.
3 Connect the eye-bolts and wall brackets
tightly with a sturdy rope. Make sure to keep
the rope horizontal with the at surface.
CAUTION
• Make sure that children do not climb on or
hang on theTV.
NOTE
• Use a platform or cabinet that is strong and
large enough to support the TV securely.
• Brackets, bolts and ropes are not provided.
You can obtain additional accessories from
your local dealer.

ENGLISH
15
Mounting on a wall
Attach an optional wall mount bracket at the
rear of theTV carefully and install the wall
mount bracket on a solid wall perpendicular
to the oor. When you attach theTV to other
building materials, please contact qualied
personnel. LG recommends that wall mounting
be performed by a qualied professional
installer.We recommend the use of LG’s wall
mount bracket. LG’s wall mount bracket is
easy to move with cables connected.When
you do not use LG’s wall mount bracket, please
use a wall mount bracket where the device is
adequately secured to the wall with enough
space to allow connectivity to external devices.
It is advised to connect all the cables before
installing xed wall mounts.
10 cm
10 cm
10 cm
10 cm
Make sure to use screws and wall mount
bracket that meet theVESA standard. Standard
dimensions for the wall mount kits are
described in the following table.
Separate purchase(Wall
mounting bracket)
Model
43UH60**
43UH61**
40/43UH62**
40UH63**
43UH65**
43UH66**
40/43UH67**
43UH74**
43UH75**
49/55UH60**
49/55UH61**
49/55UH62**
50UH63**
49/55UH65**
49/55UH66**
49/50/55UH67**
49/55UH74**
49/55UH75**
49/55UH77**
49/55UH79**
49/55UH80**
49/55UH84**
49/55UH85**
VESA (A x
B) (mm) 200 x 200 300 x 300
Standard
screw M6 M6
Number
of screws 4 4
Wall
mount
bracket
LSW240B
MSW240
LSW350B
MSW240

16
ENGLISH
Model
60/65UH60**
60/65UH61**
60/65UH62**
58UH63**
60/65UH65**
60/65UH66**
58/60/65UH67**
60UH74**
60/65UH75**
60/65UH77**
60/65UH80**
60UH84**
60/65UH85**
70UH63**
75UH65**
70UH67**
70UH70**
75UH77**
75UH78**
75UH80**
75UH85**
79/86UH95**
VESA (A x
B) (mm) 300 x 300 600 x 400
Standard
screw M6 M8
Number
of screws 4 4
Wall
mount
bracket
LSW350B LSW640B
Model 55/65UH95**
VESA (A x
B) (mm) 300 x 200
Standard
screw M6
Number
of screws 4
Wall
mount
bracket
OTW420B
A
B
CAUTION
• Remove the stand before installing theTV
on a wall mount by performing the stand
attachment in reverse.
NOTE
• When installing the wall mounting bracket,
use the adhesive label or protective cover
provided.The adhesive label or protective
cover will protect the opening from
accumulating dust and dirt. (Only when the
label or cover is provided)
Provided item
Adhesive label
Provided item
Adhesive label
Provided item
Protective cover

ENGLISH
17
• When installing the wall mounting bracket,
it is recommended to cover the stand hole
using tape, in order to prevent the inux of
dust and insects. (Depending on model)
Stand hole
• When attaching a wall mounting bracket
to theTV, insert the wall mount spacers
into theTV wall mount holes to adjust the
vertical angle of the TV. (Only when the
item of the following form is provided)
Provided
Item
Wall Mount
Spacer
• Depending on the shape of the stand, use
a at tool to remove the stand cover as
illustrated below. (e.g., a at screwdriver)
(Only when the item of the following form
is provided)
Flat tool
Connections
(notications)
Connect various external devices to theTV
and switch input modes to select an external
device. For more information of external device’s
connection, refer to the manual provided with
each device.
Available external devices are: HD receivers, DVD
players,VCRs, audio systems, USB storage devices,
PC, gaming devices, and other external devices.
NOTE
• The external device connection may dier
from the model.
• Connect external devices to theTV regardless
of the order of theTV port.
• If you record aTV program on a DVD recorder
orVCR, make sure to connect the TV signal
input cable to theTV through a DVD recorder
orVCR. For more information of recording,
refer to the manual provided with the
connected device.
• Refer to the external equipment’s manual
for operating instructions.
• If you connect a gaming device to theTV, use
the cable supplied with the gaming device.
• In PC mode, there may be noise associated
with the resolution, vertical pattern, contrast
or brightness. If noise is present, change
the PC output to another resolution, change
the refresh rate to another rate or adjust
the brightness and contrast on the PICTURE
menu until the picture is clear.
• In PC mode, some resolution settings
may not work properly depending on the
graphics card.

18
ENGLISH
• If ULTRA HD content is played on your PC,
video or audio may become disrupted
intermittently depending on your PC’s
performance. (Depending on model)
Antenna connection
Connect theTV to a wall antenna socket with
an RF cable (75 Ω).
• Use a signal splitter to use more than 2TVs.
• If the image quality is poor, install a signal
amplier properly to improve the image
quality.
• If the image quality is poor with an
antenna connected, try to realign the
antenna in the correct direction.
• An antenna cable and converter are not
supplied.
• Supported DTV Audio: MPEG, Dolby Digital,
Dolby Digital Plus, HE-AAC
• For a location that is not supported with
ULTRA HD broadcasting, thisTV cannot
receive ULTRA HD broadcasts directly.
(Depending on model)
Satellite dish connection
(Only satellite models)
Connect theTV to a satellite dish to a satellite
socket with a satellite RF cable (75 Ω).
CI module connection
(Depending on model)
View the encrypted (pay) services in digital TV mode.
• Check if the CI module is inserted into the
PCMCIA card slot in the right direction. If
the module is not inserted properly, this can
cause damage to theTV and the PCMCIA
card slot.
• If theTV does not display any video and
audio when CI+ CAM is connected, please
contact to theTerrestrial/Cable/Satellite
Service Operator.
USB connection
Some USB Hubs may not work. If a USB device
connected using a USB Hub is not detected,
connect it to the USB port on theTV directly.
Other connections
Connect yourTV to external devices. For the
best picture and audio quality, connect the
external device and theTV with the HDMI cable.
Some separate cable is not provided.
• General HDMI
ULTRA HD Deep Colour
-On : Support 4K @ 50/60 Hz (4:4:4, 4:2:2,
4:2:0)
-Off : Support 4K @ 50/60 Hz 8 bit (4:2:0)
If the device connected to Input Port also
supports ULTRA HD Deep Colour, your picture
may be clearer. However, if the device doesn’t
support it, it may not work properly. In that
case, connect the device to a dierent HDMI
port or change theTV’s HDMI ULTRA HD
Deep Colour setting to Off.
(This feature is available on certain models
which are supported ULTRA HD Deep Colour
only.)

ENGLISH
19
NOTE
• Supported HDMI Audio format :
Dolby Digital (32 kHz, 44.1 kHz, 48 kHz),
DTS (44.1 kHz, 48 kHz),
PCM (32 kHz, 44.1 kHz, 48 kHz, 96 kHz, 192 kHz)
(Depending on model)
Remote control
The descriptions in this manual are based on
the buttons on the remote control. Please read
this manual carefully and use theTV correctly.
To replace batteries, open the battery cover,
replace batteries (1.5V AAA) matching the and
ends to the label inside the compartment, and
close the battery cover. To remove the batteries,
perform the installation actions in reverse.
Make sure to point the remote control toward
the remote control sensor on theTV.
(Depending on model)
A
B
RECENT LIVE
MENU
2
1
3
4
5
A
(POWER)Turns theTV on or o.
Selects Radio,TV and DTV
programme.
(INPUT) Changes the input source.
(Q. Settings) Accesses the Quick Settings.
1, 2By zooming in on the
selected area, you can view it in full screen.
(Depending on model)
1, 2
Views the information of the
current programme and screen. (Depending
on model)
1(SEARCH) Search for content such as
TV programmes, movies and other videos, or
perform a web search by entering text in the
search bar. (Depending on model)
2Recalls your preferred subtitle in
digital mode. (Depending on model)
Number buttons Enters numbers.
Accesses the saved programmes list.
(Space) Opens an empty space on the
screen keyboard.
3Shows programme guide.
(Depending on model)
3Returns to the previously viewed
programme. (Depending on model)

20
ENGLISH
B
4
Views the information of the
current programme and screen. (Depending
on model)
4
,
5
(SEARCH) Search for content such
asTV programmes, movies and other videos,
or perform a web search by entering text in
the search bar. (Depending on model)
4
,
5Shows programme guide.
(Depending on model)
5Used for viewing 3D video. (Depending
on model)
(MUTE) Mutes all sounds.
Adjusts the volume level.
Scrolls through the saved programmes.
Moves to the previous or next
screen.
C
D
RECENT LIVE
MENU
67
89
10
C
Shows the previous history.
(HOME) Accesses the Home menu.
Shows the list of Programmes and
Recommended. (Depending on model)
6, 8Returns to the previous level.
(Depending on model)
6, 7, 8, 9Teletext buttons (
) These buttons are used for
teletext. (Depending on model)
7, 9Clears on-screen displays and
returns toTV viewing. (Depending on model)
Navigation buttons (up/down/left/right)
Scrolls through menus or options.
Selects menus or options and conrms
your input.
D
By pressing the AD button, audio
descriptions function will be enabled.
10 Starts to record and displays
record menu.
(OnlyTime MachineReady supported model)
(Depending on model)
10 By zooming in on the
selected area, you can view it in full screen.
(Depending on model)
10 Selects the MHPTV menu source.
(Depending on model)
Returns to LIVETV.
Control buttons ( )
Controls media contents.
Coloured buttonsThese access special
functions in some menus.
( : Red, : Green, :Yellow,
: Blue)
