LG 55LA9650 User manual

www.lg.com
Please read this manual carefully before operating your set
and retain it for future reference.
OWNER’S MANUAL
LED TV*
* LG LED TV applies LCD screen with LED backlights.
55LA9650
65LA9650
P/NO : MFL67652642 (1308-REV00)

ENGLISH
2IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
Always comply with the following precautions to avoid dangerous situations and ensure peak
performance of your product.
yDo not use this apparatus near water.
yClean only with a dry cloth.
yDo not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
yDo not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
yDo not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are
provided for your safety. If the provided plug does
not fit into your outlet, consult an electrician for
replacement of the obsolete outlet (Can differ by
country).
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF ELECTRIC SHOCK DO
NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of
uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING/CAUTION
- TO REDUCE THE RISK OF FIRE AND ELECTRIC
SHOCK, DO NOT EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE.
WARNING
If you ignore the warning message, you may be
seriously injured or there is a possibility of accident
or death.
CAUTION
If you ignore the caution message, you may be
slightly injured or the product may be damaged.
NOTE
The note helps you understand and use the
product safely. Please read the note carefully
before using the product.
WARNING: This product contains chemicals known to
the State of California to cause cancer and birth defects
or other reproductive harm.
:DVKKDQGVDIWHUKDQGOLQJ

ENGLISH
3
IMPORTANT SAFETY INSTRUCTIONS
yDo not press strongly upon the panel with a hand
or a sharp object such as a nail, pencil or pen, or
make a scratch on it.
yProtect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
yOnly use attachments/accessories specified by
the manufacturer.
yUse only with a cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
yUnplug this apparatus during lightning storms or
when unused for long periods of time.
yRefer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
yDo not stick metal objects or any other conductive
material into the power cord. Do not touch the
end of the power cord while it is plugged in.
yKeep the packing anti-moisture material or vinyl
packing out of the reach of children. Anti-moisture
material is harmful if swallowed. If swallowed
by mistake, force the patient to vomit and visit
the nearest hospital. Additionally, vinyl packing
can cause suffocation. Keep it out of the reach of
children.
yCAUTION concerning the Power Cord
(Can differ by country):
It is recommended that appliances be placed
upon a dedicated circuit; that is, a single outlet
circuit which powers only that appliance and
has no additional outlets or branch circuits.
Check the specification page of this owner’s
manual to be certain. Do not connect too many
appliances to the same AC power outlet as
this could result in fire or electric shock. Do not
overload wall outlets. Overloaded wall outlets,
loose or damaged wall outlets, extension cords,
frayed power cords, or damaged or cracked wire
insulation are dangerous. Any of these conditions
could result in electric shock or fire. Periodically
examine the cord of your appliance, and if its
appearance indicates damage or deterioration,
unplug it, discontinue use of the appliance, and
have the cord replaced with an exact replacement
part by an authorized service. Protect the power
cord from physical or mechanical abuse, such
as being twisted, kinked, pinched, closed in a
door, or walked upon. Pay particular attention to
plugs, wall outlets, and the point where the cord
exits the appliance. Do not move the TV with the
power cord plugged in. Do not use a damaged
or loose power cord. Be sure do grasp the plug
when unplugging the power cord. Do not pull on
the power cord to unplug the TV.
yWarning - To reduce the risk of fire or electrical
shock, do not expose this product to rain,
moisture or other liquids. Do not touch the TV
with wet hands. Do not install this product near
flammable objects such as gasoline or candles, or
expose the TV to direct air conditioning.

ENGLISH
4IMPORTANT SAFETY INSTRUCTIONS
yDo not expose to dripping or splashing and do
not place objects filled with liquids, such as
vases, cups, etc. on or over the apparatus (e.g. on
shelves above the unit).
yGrounding
(Except for devices which are not grounded.)
Ensure that you connect the earth ground wire to
prevent possible electric shock (i.e. a TV with a
three-prong grounded AC plug must be connected
to a three-prong grounded AC outlet). If grounding
methods are not possible, have a qualified
electrician install a separate circuit breaker. Do
not try to ground the unit by connecting it to
telephone wires, lightening rods, or gas pipes.
Short-circuit
Breaker
Power Supply
yAs long as this unit is connected to the AC wall
outlet, it is not disconnected from the AC power
source even if the unit is turned off.
yDo not attempt to modify this product in any way
without written authorization from LG Electronics.
Unauthorized modification could void the user’s
authority to operate this product.
yOutdoor Antenna Grounding
(Can differ by country):
If an outdoor antenna is installed, follow the
precautions below. An outdoor antenna system
should not be located in the vicinity of overhead
power lines or other electric light or power
circuits, or where it can come in contact with
such power lines or circuits as death or serious
injury can occur. Be sure the antenna system
is grounded to provide some protection against
voltage surges and built-up static charges. Section
810 of the National Electrical Code (NEC) in the
U.S.A. provides information with respect to proper
grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors,
location of antenna discharge unit, connection to
grounding electrodes and requirements for the
grounding electrode.
Antenna grounding according to the National
Electrical Code, ANSI/NFPA 70
Ground Clamp
Grounding Conductor
(NEC Section 810-21)
Antenna Lead in Wire
Electric Service
Equipment
Antenna Discharge Unit
(NEC Section 810-20)
Ground Clamp
Power Service Grounding
Electrode System
(NEC Art 250, Part H)
NEC: National Electrical Code
yCleaning
When cleaning, unplug the power cord and wipe
gently with a soft cloth to prevent scratching. Do
not spray water or other liquids directly on the TV
as electric shock may occur. Do not clean with
chemicals such as alcohol, thinners, or benzine.
yMoving
Make sure the product is turned off, unplugged,
and all cables have been removed. It may take 2
or more people to carry larger TVs. Do not press
or put stress on the front panel of the TV.
yVentilation
Install your TV where there is proper ventilation. Do
not install in a confined space such as a bookcase.
Do not cover the product with cloth or other
materials while plugged. Do not install in excessively
dusty places.
yIf you smell smoke or other odors coming from
the TV, unplug the power cord and contact an
authorized service center.
yKeep the product away from direct sunlight.
yNever touch this apparatus or antenna during a
thunder or lightning storm.
yWhen mounting a TV on the wall, make sure not
to install the TV by hanging the power and signal
cables on the back of the TV.
yDo not allow an impact shock or any objects to fall
into the product, and do not drop anything onto
the screen.
yDisconnecting the Main Power
The power outlet used with this device must
remain easily accessible.
yStore the accessories (battery, etc.) in a safe
location out of the reach of children.
yThis apparatus use batteries. In your community
there might be regulations that require you
to dispose of these batteries properly due to
environmental considerations. Please contact
your local authorities for disposal or recycling
information.
yDo not dispose of batteries in a fire.
yDo not short circuit, disassemble, or allow the
batteries to overheat.

ENGLISH
5
IMPORTANT SAFETY INSTRUCTIONS
yDot Defect
The Plasma or LCD panel is a high technology product
with resolution of two million to six million pixels.
In a very few cases, you could see fine dots on
the screen while you’re viewing the TV. Those
dots are deactivated pixels and do not affect the
performance and reliability of the TV.
yGenerated Sound
Cracking noise: A cracking noise that occurs
when watching or turning off the TV is generated
by plastic thermal contraction due to temperature
and humidity. This noise is common for products
where thermal deformation is required.
Electrical circuit humming/panel buzzing: A
low level noise is generated from a high-speed
switching circuit, which supplies a large amount of
current to operate a product. It varies depending
on the product.
This generated sound does not affect the
performance and reliability of the product.
yTake care not to touch the ventilation openings.
When watching the TV for a long period, the
ventilation openings may become hot. This does
not affect the performance of the product or
cause defects in the product.
yIf the TV feels cold to the touch, there may be a
small flicker when it is turned on. This is normal,
there is nothing wrong with TV. Some minute dot
defects may be visible on the screen, appearing
as tiny red, green, or blue spots. However, they
have no adverse effect on the TV’s performance.
Avoid touching the LCD screen or holding your
finger(s) against it for long periods of time. Doing
so may produce some temporary distortion
effects on the screen.
Preventing Image burn or Burn-in on
your TV screen
yIf a fixed image displays on the TV screen for
a long period of time, it will be imprinted and
become a permanent disfigurement on the
screen. This is image burn or burn-in and not
covered by the warranty.
yIf the aspect ratio of the TV is set to 4:3 for a
long period of time, image burn may occur on the
letterboxed area of the screen.
yAvoid displaying a fixed image on the TV screen
for a long period of time (2 or more hours for LCD,
1 or more hours for the Plasma TV) to prevent
image burn.
For USA and Canada
FCC NOTICE
yThis equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there
is no guarantee that interference will not
occur in a particular installation. If this
equipment does cause harmful interference
to radio or television reception, which can
be determined by turning the equipment
off and on, the user is encouraged to try to
correct the interference by one or more of
the following measures:
y- Reorient or relocate the receiving antenna.
y- Increase the separation between the
equipment and the receiver.
y- Connect the equipment to an outlet on
a circuit different from that to which the
receiver is connected.
y- Consult the dealer or an experienced radio/
TV technician for help.
yThis device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) this device may not cause
harmful interference and (2) this device must
accept any interference received, including
interference that may cause undesired
operation of the device.
Any changes or modifications in construction
of this device which are not expressly
approved by the party responsible for
compliance could void the user’s authority to
operate the equipment.
NOTE TO CABLE/TV INSTALLER
yThis reminder is provided to call the CATV
system installer’s attention to Article 820-
40 of the National Electric Code (U.S.A.).
The code provides guidelines for proper
grounding and, in particular, specifies that
the cable ground shall be connected to the
grounding system of the building, as close to
the point of the cable entry as practical.

ENGLISH
6IMPORTANT SAFETY INSTRUCTIONS
Viewing 3D Imaging
WARNING
Viewing Environment
yViewing Time
- When watching 3D content, take 5 - 15
minute breaks every hour. Viewing 3D
content for a long period of time may
cause headache, dizziness, fatigue or eye
strain.
Those that have a photosensitive seizure
or chronic illness
ySome users may experience a seizure or
other abnormal symptoms when they are
exposed to a flashing light or particular
pattern from 3D content.
yDo not watch 3D videos if you feel
nauseous, are pregnant and/ or have a
chronic illness such as epilepsy, cardiac
disorder, or blood pressure disease, etc.
y3D Content is not recommended for those
who suffer from stereo blindness or stereo
anomaly. Double images or discomfort in
viewing may be experienced.
yIf you have strabismus (cross-eyed),
amblyopia (weak eyesight) or astigmatism,
you may have trouble sensing depth and
easily feel fatigue due to double images.
It is advised to take more frequent breaks
than the average adult.
yIf your eyesight varies between your right
and left eye, revise your eyesight prior to
watching 3D content.
Symptoms which require discontinuation
or refraining from watching 3D content
yDo not watch 3D content when you feel
fatigue from lack of sleep, overwork, or
intoxication.
yWhen these symptoms are experienced,
stop using/watching 3D content and get
enough rest until the symptom subsides.
- Consult your doctor when the symptoms
persist. Symptoms may include headache,
eyeball pain, dizziness, nausea, palpitation,
blurriness, discomfort, double image, visual
inconvenience, or fatigue.
CAUTION
Viewing Environment
yViewing Distance
- Maintain a distance of at least twice the
screen diagonal length when watching 3D
content. If you feel discomfort in viewing
3D content, move further away from the
TV.
Viewing Age
yInfants / Children
- Usage/ Viewing 3D content for children
under the age of 5 are prohibited.
- Children under the age of 10 may
overreact and become overly excited
because their vision is in development
(for example: trying to touch the screen or
trying to jump into it. Special monitoring
and extra attention is required for children
watching 3D content.
- Children have greater binocular disparity of
3D presentations than adults because the
distance between the eyes is shorter than
one of adults. Therefore they will perceive
more stereoscopic depth compared to
adults for the same 3D image.
yTeenagers
- Teenagers under the age of 19 may be
stimulated to light coming from 3D videos.
Advise them not to watch 3D videos for a
long time when they are tired.
yElderly
- The elderly may perceive less of a 3D
effect than the youth. Do not sit closer to
the TV than the recommended distance.
Cautions when using the 3D glasses
yOnly use LG 3D glasses. Otherwise,
you may not be able to view 3D videos
properly.
yDo not use 3D glasses instead of your
normal glasses, sunglasses, or protective
goggles.
yUsing modified 3D glasses may cause eye
strain or image distortion.
yDo not keep your 3D glasses in extremely
high or low temperatures. It will cause
deformation.
yThe 3D glasses are fragile and are easy to
scratched. Use a soft, clean piece of cloth
when wiping the lenses. Do not scratch
the lenses of the 3D glasses with sharp
objects or clean/wipe them with chemicals.

ENGLISH
7
LICENSES / OPEN SOURCE SOFTWARE NOTICE
LICENSES
Supported licenses may differ by model. For more information about licenses, visit www.lg.com.
Manufactured under license from Dolby Laboratories. “Dolby” and the
double-D symbol are trademarks of Dolby Laboratories.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the
HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC
in the United States and other countries.
ABOUT DIVX VIDEO: DivX®is a digital video format created by DivX, LLC, a
subsidiary of Rovi Corporation. This is an official DivX Certified®device that
plays DivX video. Visit divx.com for more information and software tools to
convert your files into DivX video.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified®device must be
registered in order to play purchased DivX Video-on-Demand (VOD) movies.
To obtain your registration code, locate the DivX VOD section in your device
setup menu. Go to vod.divx.com for more information on how to complete
your registration.
“DivX Certified®to play DivX®video up to HD 1080p, including premium
content.”
“DivX®, DivX Certified®and associated logos are trademarks of Rovi
Corporation or its subsidiaries and are used under license.”
“Covered by one or more of the following U.S. patents:
7,295,673; 7,460,668; 7,515,710; 7,519,274”
Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380;
6,487,535 & other U.S. and worldwide patents issued & pending. DTS, the
Symbol & DTS and the Symbol together are registered trademarks & DTS
2.0+Digital Out is a trademark of DTS, Inc. Product includes software. ©
DTS, Inc. All Rights Reserved.
OPEN SOURCE SOFTWARE NOTICE
To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in
this product, please visit http://opensource.lge.com.
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices
are available for download.
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost
of performing such distribution (such as the cost of media, shipping and handling) upon email request
to [email protected]. This offer is valid for three (3) years from the date on which you purchased
the product.

ENGLISH
8TABLE OF CONTENTS
2 IMPORTANT SAFETY INSTRUCTIONS
6 Viewing 3D Imaging
7 LICENSES
7 OPEN SOURCE SOFTWARE NOTICE
8 TABLE OF CONTENTS
9 INSTALLATION PROCEDURE
9 ASSEMBLING AND PREPARING
9 Unpacking
11 Optional Extras
12 Parts and Buttons
13 Lifting and Moving the TV
14 Setting up the TV
14 - Attaching the Stand
15 - Mounting on a Table
16 - Tidying cables
16 - Mounting on a Wall
18 MAKING CONNECTIONS
18 Connecting to an Antenna or Cable
19 Connecting to a HD receiver, DVD Player or
VCR
19 - HDMI Connection
20 - DVI to HDMI Connection
21 - Connecting to a Mobile Phone
22 - Component Connection
23 - Composite Connection
24 Connecting a PC
24 - HDMI Connection or DVI to HDMI
Connection
26 Connecting to an Audio System
26 - Digital Optical Audio Connection
27 Connecting Headphones
28 Connecting a USB Device
29 MAGIC REMOTE CONTROL
FUNCTIONS
30 Registering Magic Remote Control
30 How to use Magic Remote Control
30 Precautions to Take when Using the Magic
Remote Control
31 WATCHING TV
31 Turning the TV on for the First Time
32 USING THE USER GUIDE
33 SPECIFICATIONS
36 EXTERNAL CONTROL DEVICE SETUP
37 MAINTENANCE
37 Cleaning Your TV
37 - Screen, Frame, Cabinet, and Stand
37 - Power Cord
37 TROUBLESHOOTING
TABLE OF CONTENTS
yImage shown may differ from your TV.
yYour TV’s OSD (On Screen Display) may
differ slightly from that shown in this
manual.
yThe available menus and options may
differ from the input source or product
model that you are using.
yNew features may be added to this TV in
the future.
NOTE

ENGLISH
9
INSTALLATION PROCEDURE / ASSEMBLING AND PREPARING
INSTALLATION PROCEDURE
1Open the package and make sure all the accessories are included.
2Attach the stand to the TV set.
3Connect an external device to the TV set.
4Make sure the network connection is available.
You can use the TV network functions only when the network connection is made.
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual
product and item.
yDo not use any unapproved items to ensure the safety and product life span.
yAny damages or injuries by using unapproved items are not covered by the warranty.
ySome models appear to have a thin film on the screen. It is actually part of the screen; do not
remove it.
CAUTION
yThe items supplied with your product may vary depending on the model.
yProduct specifications or contents of this manual may be changed without prior notice due to
upgrade of product functions.
yFor an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm
(0.39 inches) thick and 18 mm (0.7 inches) width.
yUse an extension cable that supports USB 2.0 if the USB cable or USB memory stick does not fit
into your TV’s USB port.
B
AA
B
*A 10 mm (0.39 inches)
*B 18 mm (0.7 inches)
NOTE

ENGLISH
10 ASSEMBLING AND PREPARING
Tag On
Magic Remote Control,
Batteries (AA)
(See page 29.)
Owner’s Manual Tag On
Stand Base
(See page 14.)
Stand Screws
4 EA, M4 x 14
(See page 14.)
Cable Holder
(See page 16.)
Component Video Cable
(See page 22.)
Composite Video Cable
(See page 22, 23.)
Cinema 3D Glasses
The number of 3D glasses
may differ depending on the
model or country.
(Depending on model)

ENGLISH
11
ASSEMBLING AND PREPARING
Optional Extras
Optional extras can be changed or modified for quality improvement without any notification.
Contact your dealer to buy these items.
These devices only work with certain models.
The model name or design may be changed manufacturer’s circumstances or policies.
AN-MR400
Magic Remote
AG-F***
Cinema 3D Glasses
AG-F***DP
Dual Play Glasses
Tag On
LG Audio Device Tag On AN-BL***
Wireless IR Blaster
(Depending on model)

ENGLISH
12 ASSEMBLING AND PREPARING
Parts and Buttons
Button Description
/ ( / ) Scrolls through the saved channels.
/ ( / ) Adjusts the volume level.
(OK ) Selects the highlighted menu option or confirms an input.
(SETTINGS)Accesses the main menus, or saves your input and exits the menus.
(INPUT )Changes the input source.
( ) Turns the power on or off.
SETTINGS
INPUT
OK
Screen
Buttons
Remote control sensor
Speakers
Power Indicator
yTo avoid possible SPEAKER damage or degradation in performance
please keep contact of TV /Speaker out of reach of Children.
CAUTION

ENGLISH
13
ASSEMBLING AND PREPARING
Lifting and Moving the TV
When moving or lifting the TV, read the following
to prevent the TV from being scratched or
damaged and for safe transportation regardless
of its type and size.
yAvoid touching the screen at all times, as
this may result in damage to the screen.
yDo not place the product on the floor with
its front facing down. Doing so may result
in damage to the screen.
CAUTION
yHold the top and bottom of the TV
frame firmly. Make sure not to hold the
transparent part, speaker, or speaker grill
area.
yIt is recommended to move the TV in
the box or packing material that the TV
originally came in.
yBefore moving or lifting the TV, disconnect
the power cord and all cables.
yWhen holding the TV, the screen should
face away from you to avoid damage.
yWhen transporting a large TV, there should
be at least 2 people.
yWhen transporting the TV by hand, hold the
TV as shown in the following illustration.
yWhen transporting the TV, do not expose
the TV to jolts or excessive vibration.
yWhen transporting the TV, keep the TV
upright, never turn the TV on its side or tilt
towards the left or right.

ENGLISH
14 ASSEMBLING AND PREPARING
Setting up the TV
You can mount your TV to a wall or attach the stand if you wish to place the TV on an entertainment
center or other furniture.
Attaching the Stand
If you are not mounting the TV to a wall, use the following instructions to attach the stand.
yWhen attaching the stand to the TV set, place the screen facing down on a cushioned table or
flat surface to protect the screen from scratches.
yMake sure that the screws are fastened tightly. (If they are not fastened securely enough, the
TV may tilt forward after being installed.)
yDo not tighten the screws with too much force; otherwise they may be damaged and come
loose later.
CAUTION
yRemove the stand before installing the TV on a wall mount by performing the stand attachment
in reverse.
NOTE
1
2
M4 x 14
2 EA
M4 x 14
2 EA
Stand Base
3
Stand Base
12
1Attach the stand to the TV using the upper
mounting hole on the back of the TV.
2Attach the stand to the TV using the lower
connection on the back of the TV.
yBe sure to attach the upper mounting hole first,
and then attach the lower connection second.
NOTE

ENGLISH
15
ASSEMBLING AND PREPARING
Mounting on a Table
1Lift and tilt the TV into its upright position on
a table.
- Leave a 10 cm (4 inches) (minimum) space
from the wall for proper ventilation.
10 cm
10 cm
10 cm
10 cm
2Connect the power cord to a wall outlet.
yDo not place the TV near or on sources
of heat, as this may result in fire or other
damage.
CAUTION
Securing the TV to a wall (optional)
(Depending on model)
1Insert and tighten the eye-bolts, or TV
brackets and bolts on the back of the TV.
- If there are bolts inserted at the eye-bolts
position, remove the bolts first.
2Mount the wall brackets with the bolts to
the wall.
Match the location of the wall bracket and
the eye-bolts on the rear of the TV.
3Connect the eye-bolts and wall brackets
tightly with a sturdy rope.
Make sure to keep the rope horizontal with
the flat surface.
yMake sure that children do not climb on or
hang on the TV.
CAUTION
yUse a platform or cabinet that is strong
and large enough to support the TV
securely.
yBrackets, bolts, and ropes are optional.
You can obtain additional accessories from
your local dealer.
NOTE
(4 inches)

ENGLISH
16 ASSEMBLING AND PREPARING
Mounting on a Wall
An optional wall mount can be used with your
LG Television. Consult with your local dealer for
a wall mount that supports the VESA standard
used by your TV model. Carefully attach the wall
mount bracket at the rear of the TV. Install the
wall mount bracket on a solid wall perpendicular
to the floor. If you are attaching the TV to other
building materials, please contact qualified
personnel to install the wall mount. Detailed
instructions will be included with the wall mount.
We recommend that you use an LG brand wall
mount.
10 cm
10 cm
10 cm
10 cm
Make sure to use screws and wall mounts that
meet the VESA standard. Standard dimensions
for the wall mount kits are described in the
following table.
Model 55LA9650
VESA (A x B)
A
B
400 x 400
Standard screw M6
Number of screws 4
Wall mount bracket
(optional)
LSW430B
MSW240
(4 inches)
Tidying cables
1Gather and bind the cables with the cable
management.
Cable
Management
2Gather and bind the cables with the cable
holder.
Cable Holder

ENGLISH
17
ASSEMBLING AND PREPARING
Model 65LA9650
VESA (A x B)
A
B
400 x 400
Standard screw M6
Number of screws 4
Wall mount bracket
(optional)
LSW430B
Wall mount bracket (optional)
LSW430B
MSW240
yDisconnect the power before moving or
installing the TV. Otherwise electric shock
may occur.
yIf you install the TV on a ceiling or slanted
wall, it may fall and result in severe injury.
Use an authorized LG wall mount and
contact the local dealer or qualified
personnel.
yDo not over tighten the screws as this
may cause damage to the TV and void
your warranty.
yUse the screws and wall mounts that
meet the VESA standard. Any damages
or injuries by misuse or using an improper
accessory are not covered by the warranty.
CAUTION
yUse the screws that are listed in the VESA
standard screw specifications.
yThe wall mount kit includes an installation
manual and necessary parts.
yThe wall mount bracket is optional. You
can obtain additional accessories from
your local dealer.
yThe length of screws may differ depending
on the wall mount. Make sure to use the
proper length.
yFor more information, refer to the manual
supplied with the wall mount.
NOTE

ENGLISH
18 MAKING CONNECTIONS
MAKING CONNECTIONS
You can connect various external devices to the TV. Supported external devices are: HD receivers,
DVD players, VCRs, audio systems, USB storage devices, PC, gaming devices, and other external
devices. For more information on external device’s connection, refer to the manual provided with
each device.
yIf you record a TV program on a DVD recorder or VCR, make sure to connect the TV signal input
cable to the TV through a DVD recorder or VCR. For more information of recording, refer to the
manual provided with the connected device.
yThe external device connections shown may differ slightly from illustrations in this manual.
yConnect external devices to the TV regardless of the order of the TV port.
yIf you connect a gaming device to the TV, use the cable supplied with the gaming device.
yRefer to the external equipment’s manual for operating instructions.
NOTE
Connecting to an Antenna or Cable
Connect an antenna, cable, or cable box to watch TV while referring to the following. The illustrations
may differ from the actual items and a RF cable is optional.
yMake sure not to bend the copper wire of
the RF cable.
Copper wire
yComplete all connections between
devices, and then connect the power cord
to the power outlet to prevent damage to
your TV.
CAUTION
(*Not Provided)
Antenna
Coaxial (75Ω)
Terminal
yUse a signal splitter to use more than 2
TVs.
yVisit http://lgknowledgebase.com for more
information about the antenna and cable
connection. Search for antenna.
yDTV Audio Supported Codec: MPEG,
Dolby Digital.
yDisplay of Ultra HD (3840 x 2160 pixels)
content compatible; additional device
capable of processing Ultra HD source
content (in 2D or 3D) may be required and
will be sold separately.
NOTE
VHF Antenna
UHF Antenna

ENGLISH
19
MAKING CONNECTIONS
Connecting to a HD receiver, DVD Player or VCR
Connect a HD receiver, DVD Player, or VCR to the TV and select an appropriate input mode.
HDMI Connection
HDMI is the best way to connect a device.
Transmits digital video and audio signals from an external device to the TV. Connect the external
device and the TV with the HDMI cable as shown in the following illustration.
yUse the latest High Speed HDMI™ Cable that supports CEC (Customer Electronics Control)
function.
yHigh Speed HDMI™ Cables are tested to carry an HD signal up to 1080p and higher.
yHDMI Audio Supported Format: PCM (Up to 192 kHz, 32 kHz / 44.1 kHz / 48 kHz / 88 kHz /
96 kHz / 176 kHz / 192 kHz)
NOTE
ARC (Audio Return Channel)
yWhen connected with a high-speed HDMI cable,
digital audio can be sent to a compactible device
without an additional optical audio cable.
yARC is only supported on the HDMI input 1 (ARC)
port. An external audio device that supports ARC
should be connected to HDMI 1 if you wish to
use ARC.
HDMI
DVD / Blu-Ray / HD Cable Box / HD STB
(*Not Provided)
Choose any HDMI input port to connect.
It does not matter which port you use.

ENGLISH
20 MAKING CONNECTIONS
AUDIO OUT
DVI OUT
DVI to HDMI Connection
Transmits the digital video signal from an external device to the TV. Connect the external device and
the TV with the DVI-HDMI cable as shown in the following illustration. To transmit an audio signal,
connect an audio cable.
Choose any HDMI input port to connect.
It does not matter which port you use.
yWhen using the HDMI/DVI cable, Single link only is supported.
NOTE
(*Not Provided)
(*Not Provided)
DVD / Blu-Ray / HD Cable Box
YELLOW
