LG LJ62 Series User manual

www.lg.com
LJ62**
OWNER’S MANUAL
LED TV*
* LG LED TV applies LCD screen with LED backlights.
Please read this manual carefully before operating your set and retain it
for future reference.

2TABLE OF CONTENTS
ENG
ENGLISH
21 SPECIFICATIONS
23 IRCODES
24 EXTERNALCONTROLDEVICE
SETUP
24 RS-232C setup
24 Type of connector:
D-Sub 9-Pin Male
24 RS-232C configurations
25 Communication parameters
25 Command reference list
26 Transmission / Receiving Protocol
TABLEOFCONTENTS
3 LICENSES
3 OPENSOURCESOFTWARE
NOTICE
4 INSTALLATIONPROCEDURE
4 ASSEMBLINGAND
PREPARING
4 Unpacking
7 Parts and buttons
8 Lifting and moving the TV
9 Setting up the TV
9 - Attaching the stand
10 Mounting on a table
11 Mounting on a wall
12 Tidying cables
13 MAKINGCONNECTIONS
13 Antenna connection
14 HDMI connection
14 DVI to HDMI connection
15 RGB-PC connection
15 Component connection
16 Speaker output SETUP
16 USB connection
17 Headphone connection
17 CI module connection
18 Euro Scart connection
19 REMOTECONTROL
20 MAINTENANCE
20 Cleaning your TV
20 - Screen, frame, cabinet and stand
20 - Power cord
20 TROUBLESHOOTING
WARNING
 If you ignore the warning message, you may
be seriously injured or there is a possibility
of accident or death.
CAUTION
 If you ignore the caution message, you may
be slightly injured or the product may be
damaged.
NOTE
 The note helps you understand and use
the product safely. Please read the note
carefully before using the product.

3
LICENSES / OPEN SOURCE SOFTWARE NOTICE
ENGENGLISH
LICENSES
Supported licenses may differ by model. For more information about licenses, visit www.lg.com.
Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol
are trademarks of Dolby Laboratories.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI Licensing LLC in the United States and
other countries.
ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a subsidiary
of Rovi Corporation. This is an official DivX Certified® device that plays DivX video. Visit
divx.com for more information and software tools to convert your files into DivX video.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered
in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your
registration code, locate the DivX VOD section in your device setup menu. Go to vod.
divx.com for more information on how to complete your registration.
“DivX Certified® to play DivX® video up to HD 1080p, including premium content.”
“DivX®, DivX Certified® and associated logos are trademarks of Rovi Corporation or its
subsidiaries and are used under license.”
Covered by one or more of the following U.S. patents :
7,295,673; 7,460,668; 7,515,710; 7,519,274
OPENSOURCESOFTWARENOTICE
To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this
product, please visit http://opensource.lge.com.
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are
available for download.
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of
performing such distribution (such as the cost of media, shipping and handling) upon email request to
[email protected]. This offer is valid for three (3) years from the date on which you purchased the product.

4INSTALLATION PROCEDURE / ASSEMBLING AND PREPARING
ENG
ENGLISH
 NOTE
 Image shown may differ from your TV.
 Your TV’s OSD (On Screen Display) may differ slightly from that shown in this manual.
 The available menus and options may differ from the input source or product model that you are
using.
 New features may be added to this TV in the future.
 The TV can be placed in standby mode in order to reduce the power consumption. And the TV should
be turned off if it will not be watched for some time, as this will reduce energy consumption.
 The energy consumed during use can be significantly reduced if the level of brightness of the picture
is reduced, and this will reduce the overall running cost.
INSTALLATIONPROCEDURE
1  Open the package and make sure all the accessories are included.
2  Attach the stand to the TV set.
3  Connect an external device to the TV set.
ASSEMBLINGANDPREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual product
and item.
CAUTION
 Do not use any unapproved items to ensure the safety and product life span.
 Any damages or injuries by using unapproved items are not covered by the manufacturer’s warranty.
 Some models have a thin film attached on to the screen and this must not be removed.
NOTE
 The items supplied with your product may vary depending on the model.
 Product specifications or contents of this manual may be changed without prior notice due to upgrade
of product functions.
 For an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm thick
and 18 mm width. Use an extension cable that supports USB 2.0 if the USB cable or USB memory
stick does not fit into your TV’s USB port.
B
AA
B
*A10mm
*B18mm

5
ASSEMBLING AND PREPARING
ENGENGLISH
FREEZE
RATIO
L/R SELECT
ENTER
BACK EXIT
Q.MENU
INFO
MENU
CHVOL
P
A
G
E
FAV
3D
MUTE
1 2 3
4 5 6
7 8
0
9
MARK
LIST
FLASHBK
ENERGY
SAVING
TV
AV MODE
INPUT
Remotecontrol,
Batteries(AAA)
(See p.19) Owner’smanual
CableHolder
(Depending on model)
(See p.12)
Powercord
(Depending on model)
StandScrews
4 EA, M4 x 12
2 EA, M4 x 16
(Only 22LJ62**)
(See p.9) 
StandScrews
8 EA, M4 x 12
(Only 26LJ62**)
(See p.9)
Standbody/Standbase
(See p.9)
or Isolator
(Depending on model)
(See p.6)

6ASSEMBLING AND PREPARING
ENG
ENGLISH
 NOTE
 Antenna Isolator Installation Guide
- Use this to install TV in a place where there is a voltage difference between TV Set and GND of
antenna signal.
»If there is a voltage difference between TV Set and GND of antenna signal, the antenna contact
might be heated and excessive heat might cause an accident.
- You can improve the safety when watching TV by efficiently removing power voltage from TV
antenna. It is recommended to mount the isolator to the wall. If it cannot be mounted to the wall,
mount it on the TV. Avoid disconnecting the antenna Isolator after installation.
- Before starting, be sure that the TV antenna is connected.
ANTENNA/
CABLE IN
Cable / Antenna
Wall
Isolator
1. Connect to TV.
2. Connect to Set-Top box.
or
Connect one end of the isolator to cable/antenna jack and the other to TV set or set-top box.
“Equipment connected to the protective earthing of the building installation through the mains
connection or through other equipment with a connection to protective earthing - and to a cable
distribution system using coaxial cable, may in some circumstances create a re hazard. Connection
to a cable distribution system has therefore to be provided through a device providing electrical
isolation below a certain frequency range (galvanic isolator, see EN 60728-11)”
When applying the RF Isolator, a slight loss of signal sensitivity can occur.

7
ASSEMBLING AND PREPARING
ENGENGLISH
Partsandbuttons
Speakers
Screen
Button Description
∧∨
Scrolls through the saved programmes.
Adjusts the volume level.
Turns the power on or off.
Buttons
Power Indicator
(Can be adjusted using
the Power Indicator in the
OPTION -menu.)
Remote control sensor

8ASSEMBLING AND PREPARING
ENG
ENGLISH
 It is recommended to move the TV in the
box or packing material that the TV originally
came in.
 Before moving or lifting the TV, disconnect
the power cord and all cables.
 When holding the TV, the screen should face
away from you to avoid damage.
 Hold the top and bottom of the TV frame
firmly. Make sure not to hold the transparent
part, speaker, or speaker grill area.
 When transporting a large TV, there should
be at least 2 people.
 When transporting the TV by hand, hold the
TV as shown in the following illustration.
 When transporting the TV, do not expose the
TV to jolts or excessive vibration.
 When transporting the TV, keep the TV
upright, never turn the TV on its side or tilt
towards the left or right.
 Do not apply excessive pressure to cause
flexing / bending of frame chassis as it may
damage screen.
CAUTION
 Avoid touching the screen at all times, as this
may result in damage to the screen.
LiftingandmovingtheTV
When moving or lifting the TV, read the following to
prevent the TV from being scratched or damaged
and for safe transportation regardless of its type
and size.

9
ASSEMBLING AND PREPARING
ENGENGLISH
SettinguptheTV
Put your TV on a pedestal stand and mount the TV on a table or wall.
Attachingthestand
Front
Stand Body
Stand Base
1
2
3
M4 x 12
4 EA
(Only 22LJ62**)
(Only 26LJ62**)
M4 x 12
4 EA
M4 x 16
2 EA

10 ASSEMBLING AND PREPARING
ENG
ENGLISH
AdjustingtheangleoftheTVtosuitview
Swivel 90 degrees to the left or right and adjust the
angle of the TV to suit your view.
Mountingonatable
1  Lift and tilt the TV into its upright position on a
table.
- Leave a 10 cm (minimum) space from the
wall for proper ventilation.
2  Connect the power cord to a wall outlet.
10 cm
10 cm
10 cm
10 cm
CAUTION
 Do not place the TV near or on sources
of heat, as this may result in fire or other
damage.
CAUTION
 When adjusting the angle of the product,
watch out for your fingers.
»Personal injury may occur if hands or
fingers are pinched. If the product is tilted
too much, it may fall, causing damage or
injury.
CAUTION
 When attaching the stand to the TV
set, place the screen facing down on a
cushioned table or flat surface to protect the
screen from scratches.
 Make sure that the screws are fastened
completely. (If they are not fastened securely
enough, the TV may tilt forward after being
installed.)
Do not fasten the screws with too much
force; otherwise they may be worn out and
get loosened.
NOTE
 Remove the stand before installing the TV
on a wall mount by performing the stand
attachment in reverse.
90
90
UsingtheKensingtonsecuritysystem
(This feature is not available for all models.)
The Kensington security system connector is
located at the rear of the TV. For more information
of installation and using, refer to the manual
provided with the Kensington security system or
visit http://www.kensington.com.
Connect the Kensington security system cable
between the TV and a table.
