LG MS450H User manual

MS450H
Network Twin HD Recorder
English
MEDIA STATION
To ensure proper use of this product, please read this
owner’s manual carefully and retain for future reference.

2
This lightning ash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product’s enclosure that may be of sufcient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the product.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR
MOISTURE.
WARNING: Do not install this equipment in a confined space
such as a book case or similar unit.
CAUTION: The apparatus should not be exposed to water
(dripping or splashing) and no objects lled with liquids, such as
vases, should be placed on the apparatus.
CAUTION concerning the Power Cord
Most appliances recommend they be placed upon a
dedicated circuit;
That is, a single outlet circuit which powers only that appliance
and has no additional outlets or branch circuits. Check the
specication page of this owner's manual to be certain.
Do not overload wall outlets. Overloaded wall outlets, loose or
damaged wall outlets, extension cords, frayed power cords,
or damaged or cracked wire insulation are dangerous. Any of
these conditions could result in electric shock or re. Periodically
examine the cord of your appliance, and if its appearance
indicates damage or deterioration, unplug it, discontinue use
of the appliance, and have the cord replaced with an exact
replacement part by an authorized servicer.
Protect the power cord from physical or mechanical abuse, such
as being twisted, kinked, pinched, closed in a door, or walked
upon. Pay particular attention to plugs, wall outlets, and the point
where the cord exits the appliance.
To disconnect power from the unit, unplug the unit from the
outlet. When installing the product, ensure that the plug is easily
accessible.
Disposal of your old appliance
1. When this crossed-out wheeled bin symbol is
attached to a product it means the product is covered
by the European Directive 2002/96/EC.
2. All electrical and electronic products should be
disposed of separately from the municipal waste
stream via designated collection facilities appointed
by the government or the local authorities.
3. The correct disposal of your old appliance will help
prevent potential negative consequences for the
environment and human health.
4. For more detailed information about disposal of your
old appliance, please contact your city office, waste
disposal service or the shop where you purchased
the product.
For Wireless product European Union
Notice
Products bearing the CE marking comply
with the R&TTE Directive (1999/5/EC),
EMC Directive (2004/108/EC), and the
Low Voltage Directive (2006/95/EC) issued
by the Commission of the European
Community. Indoor use only.
Compliance with these directives implies conformity to the
following European Norms (in parentheses are the equivalent
international standards and regulations):
• EN 55022 (CISPR 22)-Electromagnetic Interference
• EN 55024 (IEC61000-4-2,3,4,5,6,8,11)-Electromagnetic
Immunity
• EN 60065 (IEC 60065) - Product Safety
• EN 300 328-Technical requirements for radio equipment
• 301 489-1 and EN 301 489-17-General EMC requirements for
radio equipment.
European representative :
LG Electronics Service Europe B.V.
Veluwezoom 15, 1327 AE Almere, The Netherlands
(Tel : [phone])
As an Energy Star® Partner, LG has
determined that this product or product
models meet the Energy Star®guidelines
for energy efciency.
Energy Star®is a U.S. registered mark.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK
OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.

3
Copyrights
l Recording equipment should be used only for lawful
copying and you are advised to check carefully what
is lawful copying in the area in which you are making
a copy. Copying of copyright material such as films or
music is unlawful unless permitted by a legal exception
or consented to by the rights owner.
lThis product incorporates copyright protection
technology that is protected by method claims of certain
U.S. patents and other intellectual property rights owned
by Macrovision Corporation and other rights owners.
Use of this copyright protection technology must be
authorized by Macrovision Corporation, and is intended
for home and other limited viewing uses only, unless
otherwise authorized by Macrovision corporation.
Reverse engineering or disassembly is prohibited.
lCONSUMERS SHOULD NOTE THAT NOT ALL
HIGH DEFINITION TELEVISION SETS ARE FULLY
COMPATIBLE WITH THIS PRODUCT AND MAY
CAUSE ARTIFACTS TO BE DISPLAYED IN THE
PICTURE. IN CASE OF 625 PROGRESSIVE SCAN
PICTURE PROBLEMS, IT IS RECOMMENDED
THAT THE USER SWITCH THE CONNECTION TO
THE ‘STANDARD DEFINITION’ OUTPUT. IF THERE
ARE QUESTIONS REGARDING OUR TV SET
COMPATIBILITY WITH THIS MODEL 625p UNIT
PLEASE CONTACT OUR CUSTOMER SERVICE
CENTRE.
Licenses
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
Manufactured under license under U.S. Patent #’s:
5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,487,535 &
other U.S. and worldwide patents issued & pending. DTS
and DTS 2.0+ Digital Out are registered trademarks and
the DTS logos and Symbol are trademarks of DTS, Inc. ©
1996-2008 DTS, Inc. All Rights Reserved.
HDMI, the HDMI logo and High-Definition Multimedia
Interface are trademarks or registered trademarks of
HDMI licensing LLC.
YouTube is a trademark of Google Inc.
Picasa Web Albums is a trademark of Google Inc.
DLNA and DLNA CERTIFIED are trademarks and/or
service marks of Digital Living Network Alliance.
WIFI CERTIFIED 802.11n based on Draft 2.0.
Draft 2.0 refers to the version of the not-yet-ratified IEEE
802.11n standard used in Wi-Fi Alliance as of June 2007.
The “HD TV” Logo is trademark of DIGITALEUROPE.
Trademark of DVB Digital video Broadcasting Project
(1991 to 1996)
WARNING:
l Media contents including but not limited to broadcast
materials, movie, music, and photo les are protected
by copyright and that recording copy and playback of
those contents would only be permissible by permission
of the copyright owner. LG has no right to grant such
permission. Permission should always be sought from
the copyright owner.
lAndio and Video recordings and copies you make
using this products are for your personal and non-
commercial use only. You may sell, lend or rent them to
other people. LG is not responsible for your panelties,
disadvantages by illegal use of this product.
About the Symbol Display
“ ” may appear on your TV display during operation
and indicates that the function is not permitted by this
recorder or specific media.
Symbol Used in this Manual
Indicates special notes and operating features.
Indicates tips and hints for making the task easier.
Caution
Indicates hazards likely to cause harm to the recorder
itself or other material damage.

4
Table of contents
File requirement.........................................................................5
File compatibility........................................................................... 5
Home Menu Overview ...............................................................6
Remote control ..........................................................................8
Main unit.....................................................................................9
Connection overview ..............................................................10
Connections to Your TV.............................................................. 10
(Option A) Best quality - HDMI connection (includes audio and
video)...........................................................................................11
(Option B) Excellent quality - Component video and stereo audio
connection .................................................................................. 12
(Option C) Connections to your TV (Composite or Scart) .......... 12
Connecting to an Amplier.......................................................... 13
Network connection ................................................................14
Wired network connection .......................................................... 14
Wireless network connection...................................................... 16
Setup Wizard (Initial install)....................................................20
DTV ........................................................ 21
DTV Installation .......................................................................21
Settings for Digital TV.............................................................22
Selecting a Region ..................................................................... 22
Scanning programmes automatically ......................................... 22
Scanning programmes manually................................................ 22
Editing Programme List .............................................................. 23
Setting the Lock System............................................................. 23
Setting a new password ............................................................. 23
Adjusting TV Rating level ........................................................... 24
Setting the antenna power ......................................................... 24
Setting the permanent Timeshift................................................. 24
Setting a recording storage location........................................... 24
Using the Digital TV functions ...............................................25
Viewing the Digital TV ................................................................ 25
Adjusting volume of audio out .................................................... 25
Changing Digital TV programmes .............................................. 25
Setting favorite programmes ...................................................... 25
Viewing the programme information........................................... 25
Selecting DTV audio language................................................... 25
Selecting DTV subtitle language ................................................ 26
Viewing the EPG (Electronic Programme Guide) Display.......... 26
Using the timeshift function manually......................................... 26
Using the permanent timeshift.................................................... 27
Using the teletext (Viewing Teletext) .......................................... 27
Recording TV programmes ....................................................28
Normal Recording....................................................................... 28
Dual Programme Recording....................................................... 28
Timer Recording (Manual).......................................................... 28
Timer Recording (EPG) .............................................................. 29
Canceling a timer recording........................................................ 29
Checking the history................................................................... 29
Editing a timer recording............................................................. 30
Instant Timer Recording ............................................................. 30
Media ..................................................... 31
Playback functions..................................................................32
General playback........................................................................ 32
Sorting the recorded titles .......................................................... 32
Frame-by-Frame playback ........................................................ 33
Fast forward and fast reverse .................................................... 33
Slow down the playing speed .................................................... 33
Skip to the next/previous le ...................................................... 33
Resume playback ...................................................................... 33
Enlarges the playback image .................................................... 33
Selecting a subtitle language .................................................... 33
Selecting a subtitle language code ............................................ 33
Selecting an audio language ..................................................... 34
Repeat playback ........................................................................ 34
Playback from selected time ...................................................... 34
Add les to the Playlist .............................................................. 34
Delete a le/folder from the list .................................................. 34
Naming a le .............................................................................. 35
Playing selected les ................................................................. 35
Selecting a slideshow speed ..................................................... 35
Selecting a slideshow effect ...................................................... 35
Listening to music while viewing a slideshow ............................ 35
Playing les on your PC .........................................................36
Accessing to your PC ................................................................. 36
Editing the [My_Shortcuts].......................................................... 36
Using [File Copy] features......................................................37
Copying or moving les/folders .................................................. 37
Deleting les/folders ................................................................... 37
DLNA...................................................... 38
About DLNA .............................................................................38
Notes on DLNA features............................................................. 38
Installing Nero MediaHome 4 Essentials.................................... 39
Sharing les and folders............................................................. 39
Operating DLNA feature..........................................................40
General operation....................................................................... 40
YouTube™ ............................................. 41
Operating YouTube™ feature .................................................41
General operation....................................................................... 41
Searching YouTube videos......................................................... 42
Selecting your local site.............................................................. 42
Picasa ................................................... 43
Operating Picasa Web Albums feature..................................43
General operation....................................................................... 43
Searching Picasa Web Albums .................................................. 44
Viewing your Picasa Web Albums .............................................. 44
Removing an ID from the ID List ................................................ 44
Setup...................................................... 45
General Setup Operation ........................................................45
DTV settings............................................................................... 45
Audio settings............................................................................. 46
Display settings .......................................................................... 46
Record settings........................................................................... 47
Network settings......................................................................... 47
System settings .......................................................................... 48
Others settings ........................................................................... 48
Reference .................................................................................49
Software update via the Internet ................................................ 49
Software update via built-in tuner............................................... 49
Formatting HDD.......................................................................... 49
External HDD Installation ........................................................... 50
About the internal/External HDD ................................................ 51
Connecting an USB Device........................................................ 51
Controlling a TV with the Supplied Universal Remote Control ... 52
Code numbers of controllable TVs ............................................. 53
Troubleshooting.......................................................................... 55
Specications ............................................................................. 57
IMPORTANT INFORMATION RELATING TO NETWORK
SERVICES ................................................................................58
Open source software notice .................................................59

5
File requirement
File compatibility
l Because the compatibility and available playback
functions on the [DLNA] menu are tested on the
bundle DLNA server (Nero MediaHome 4 Essentials)
environment, file requirements and playback functions
on the [DLNA] menu may differ depending on the media
servers.
lThe file requirements on this page are not always
compatible for DLNA features. There may have some
restrictions by file features and media server's ability.
l This unit can recognize file/folder name less than 512
characters include path name.
l This unit can recognize filles less than 4000 file/folders
is one folder.
l Depending on the size and number of the files, it may
takes several minutes to read the contents of the media.
Movie le
• Available resolution size: 1920 x1080 (W x H) pixels.
• The file names of movie and subtitle are limited to 50
characters.
• Supported extensions: “.avi”, “.divx”, “.mpg”, “.mpeg”, “.m2ts”,
“.mp4”, “.mkv”, “.wmv”, “.ts”, “.xvid”, “.asf”, “.mov”, “.trp”,
“.dat”, “.flv”, “.mts”, “.tp”
• Supported encodings: DIVX3.xx, DIVX4.xx, DIVX5.xx, XVID,
DIVX6.xx (Standard playback only), MPEG1/2,
H.264/MPEG-4 AVC, WMV9, VC-1
• This device might not playback the file which is not encoded
on the list, even though its extesion belongs to “Supported
extensions” above.
• Playable movie subtitle: SubRip (.srt / .txt), SAMI (.smi),
SubStation Alpha (.ssa/.txt), MicroDVD (.sub/.txt), SubViewer
2.0 (.sub/.txt), VobSub (“.idx” and “.sub” files should be
together in the media)
• Playable Audio format: “Dolby Digital”, “DTS”, “MP3”, “WMA”,
“AAC”
• Not all WMA Audio formats are compatible with this recorder.
• Sampling frequency: within 8 - 48 kHz (MP3),
within 32 - 48 kHz (WMA)
• Bit rate: within 8 - 320 kbps (MP3),
within 32 - 192 kbps (WMA)
• This recorder supports H.264/MPEG-4 AVC profile Main,
High at Level 4.1. and Baseline at Level 3.1
• For a file with higher level, the recorder will ask whether you
want to play or not.
• Displaying subtitle on DLNA is only available for bundle
DLNA server (Nero MediaHome 4 Essentials) environment.
• This recorder does not support the file that are recorded with
GMC. (GMC: Global Motion Compensation)
Music files
• File extensions: “.mp3”, “.wma”,“.aac”,“.ogg”, “.asf”, “.flac”,
“.mp4”
• Sampling frequency: within 8 - 48 kHz (MP3),
within 32 - 48kHz (WMA)
• Bit rate: within 8 - 320kbps (MP3),
within 32 - 192kbps (WMA)
• This recorder does not support the ID3 Tag embedded in the
MP3 file.
• The total playback time indicated on the screen may not
correct for VBR files.
• The total playback time will not be displayed for “.aac”, and
“.flac” files.
Photo file
• File extensions: “.jpg”, “.jpeg”, “.bmp”, “.png”, “.gif”, “.tif/tiff”
• Photo files with “.png”, “.gif” or “.tif” extensions are not be
completely supported on this recorder. Only limited basic
format of them are supported.
• Recommended size:
Less than 4,000 x 3,000 x 24 bit/pixel
Less than 3,000 x 3,000 x 32 bit/pixel
• Progressive and lossless compression photo image files are
not supported.

Setup Wizard
(page 20)
DTV Installation
(page 21)
Settings for Digital TV
(page 22-24)
Using the Digital TV functions
(page 25-27)
Recording TV programmes
(page 28-30)
File requirement
(page 5)
Playback functions
(page 32-35)
Playing les on your PC
(page 36)
Using [File Copy] features
(page 37)
Network connection
(page 14-19)
About DLNA
(page 38)
Installing Nero MediaHome 4
Essentials
(page 39)
Operating DLNA feature
(page 40)
6
Home Menu Overview
Starting from HOME
To access numerous functions of the server, press the “HOME” button on the remote.

7
Home Menu Overview
Basic button operations
- HOME : Accesses or removes the HOME menu.
- b/ B :Used to navigate on-screen displays.
- OK ( ): Acknowledges menu selection.
- BACK (O): Exits the menu.
Operating YouTube feature
(page 41)
General operation
(page 41)
Searching YouTube videos
(page 42)
Selecting your local site
(page 42)
Operating Picasa Web Albums
feature
(page 43)
General operation
(page 43)
Searching Picasa Web Albums
(page 44)
Viewing your Picasa Web
Albums
(page 44)
Removing an ID from the ID
List
(page 44)
General Setup Operation
(page 45)
DTV settings
(page 45)
Audio settings
(page 46)
Display settings
(page 46-47)
Record settings
(page 47)
Network settings
(page 47)
System settings
(page 48)
Others settings
(page 48)

POWER (1): Switches the recorder ON or OFF.
TV/PVR: To view channels selected by the recorder tuner or by the TV tuner.
VOL (- / +): Adjusts the sound level of the recorder.
TV Control Buttons: You can control the programme selection, sound level, input
source, and power switch of your TV (see page 52).
0-9 numerical buttons: Selects numbered options in a menu.
REC (z): Starts recording and copying.
TIMESHIFT: Pauses live TV/playback (timeshift) for a live TV programme.
m/ M(SCAN): Searches backward or forward.
./ >(SKIP): Goes to next or previous track/le.
X(PAUSE): Pauses playback.
B(PLAY): Starts playback.
x(STOP): Stops playback.
HOME: Accesses or removes the HOME menu.
GUIDE: Displays the EPG menu.
b/ B/ v/ V(left/right/up/down): Navigates on-screen displays.
OK ( ): Acknowledges menu selection or displays the programme list.
BACK (O): Exits the menu or back to previous step.
INFO ( ): Displays or exits On-Screen Display.
PR (U/ u): Scans up or down through memorized programmes.
PAGE (U/ u): Moves to next or previous page of contents/TV list.
REPEAT: Repeats a desired section or sequence.
ZOOM: Displays or exits the [ZOOM] menu.
MARKER ( ): Used for selecting multiple files or folders in certain operation.
EDIT: Displays an editing menu
Coloured buttons: Used for [MOVIE], [PHOTO] and [MUSIC] menu or when an
EPG screen is displayed. The function of each button will be described on-screen,
and changes depending on the screen being displayed.
PR LIST: Displays the programme list.
FAV: Displays the favorite programme list.
AUDIO ( ): Selects an audio language or audio channel.
SUBTITLE ( ): Selects a subtitle language.
TIMER REC: Display [Timer Recording] menu.
TEXT: Switches between teletext mode and normal TV viewing.
GOTO: Displays the time search option during movie playback.
RESOLUTION: Sets the output resolution for HDMI and COMPONENT VIDEO
OUT jacks. (This key only work in TV watching mode or Home Menu mode.)
8
Remote control

a1(POWER) Button
Switches the recorder ON or OFF.
bExternal HDD Slot
Mounting an additional HDD here.
cDisplay window
Shows the current status of the recorder.
dRemote Sensor
Point the remote control here.
eRESET
Press this button to reboot.
fz(REC.)
Starts recording.
gPROG. v/V
Scans up or down through memorized programmes.
hUSB Port
Connect a USB Device.
9
Main unit
aAC IN connector
Connect the supplied power cord.
bUSB Port
Connect the supplied Wireless LAN Adapter.
cLAN port
Connect a network with an always-on broadband
connection.
dHDMI OUT
Connect to TV with HDMI inputs. (Interface for digital
audio and video)
eCOMPONENT VIDEO OUT (Y PBPR)
Connect to a TV with Y PBPRinputs.
fDIGITAL AUDIO OUT (COAXIAL)
Connect to digital (coaxial) audio equipment.
gANTENNA IN
Connect the antenna to this terminal.
hVIDEO OUT
Connect to a TV with video inputs.
iAUDIO OUT (Left/Right)
Connect to a TV with audio inputs.
jDIGITAL AUDIO OUT (OPTICAL)
Connect to digital (optical) audio equipment.
kANTENNA OUT (TO TV)
Passes the signal from the ANTENNA IN jack to your
TV/monitor.
lSCART (TO TV)
Connect to a TV with SCART jack.
PUSH / OPEN
 a b c d e f g h
hijk l
 a b cd e fg

lDepending on your TV and other equipment you wish to connect, there are various ways you could connect the
recorder. Use only one of the connections described on pages 11-13.
l Please refer to the manuals of your TV, Stereo System or other devices as necessary to make the best connections.
Be sure to switch off the recorder before installation and connection.
Broadband
Service
Wireless LAN
Adapter
Broadband
Service
Connections to Your TV
Make one of the following connections, depending on the capabilities of your existing equipment.
Connect to your TV with option A, B or C.
Caution
lMake sure the recorder is connected directly to the TV. Tune the TV to the correct video input source.
l Do not connect the recorder’s AUDIO OUT jack to the phono in jack (record player) of your audio system.
l Do not connect your recorder via your VCR. The image could be distorted by the copy protection system.
10
Connection overview
