LG 20MN48A User manual

P/No: MBM64536723 (1601-REV00)
LED MONITOR
20MN48A
22MN48A
24MN48A
Read Safety and Reference.
AAA
www.lg.com
Unpacking
Check your product box for the following items. If there
are any missing accessories, contact the local dealer
where you purchased your product. The illustrations in
this manual may differ from the actual product and item.
*Image may vary depending on model.
MBM64536723

1 2
For the power supply and power consumption, refer to the label attached to the product
Image shown may differ from your
monitor.
When attaching the stand to the monitor
set, place the screen facing down on a
cushioned table or flat surface to protect
the screen from scratches.
CAUTION

USB IN
5 V 0.5 A
HDMI IN RGB IN (PC)
AV IN
VIDEO
L L
RR
AUDIO
(MONO) AUDIO OUT
AV IN
LR
(MONO) AUDIO
USB IN
DC-IN
(19 V )(19 V )(19 V )(19 V )(19 V )
AUDIO OUT AUDIO IN
VIDEO LR
LR
AUDIO OUT
HDMI OUT
VIDEO
RGB OUT (PC)
USB Connection
Connect a USB storage device such as a USB
flash memory, external hard drive, or a USB
memory card reader to the monitor and access
the entertainment menu to use Various
multimedia files
Note: All connection cables shown in the picture are not included along with the monitor set

12
43
DC-IN
(19 V )
DC-IN
(19V )
IN002043
Do not use sub standard batteries in monitor
remote which may lead to leakage & damage
the remote control unit permanently. For long
unused applications of remote controller it is
advisable to remove batteries from remote
control unit.
NOTE
