LG 50PB560B User manual

Please read this manual carefully before operating
your TV and retain it for future reference.
OWNER’S MANUAL
PLASMA TV
www.lg.comP/NO : MFL68040802 (1312-REV00)
50PB560B 50PB5600
60PB5600
*MFL68040802*
Downloaded from www.vandenborre.be

ENGLISH
2IMPORTANT SAFETY INSTRUCTIONS
yDo not allow the television to become wet.
yClean only with a dry cloth.
yDo not block any ventilation openings. Install
in accordance with the manufacturer’s
instructions.
yDo not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
yDo not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than
the other. A grounding type plug has two
blades and a third grounding prong. The
wide blade or the third prong are provided
for your safety. If the provided plug does not
fit into your outlet, consult an electrician for
replacement of the obsolete outlet (Can differ
by country).
yDo not press strongly upon the panel with a
hand or a sharp object such as a nail, pencil
or pen, or make a scratch on it.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
IMPORTANT SAFETY INSTRUCTIONS
Always comply with the following precautions to avoid dangerous situations and ensure peak
performance of your product.
Short-circuit
Breaker
Power Supply
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR
BACK). NO USER SERVICEABLE PARTS
INSIDE. REFER TO QUALIFIED SERVICE
PERSONNEL.
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead
symbol, within an equilateral triangle,
is intended to alert the user to the presence
of uninsulated dangerous voltage within the
product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature accompanying
the appliance.
WARNING/CAUTION
- TO REDUCE THE RISK OF FIRE AND
ELECTRIC SHOCK, DO NOT EXPOSE THIS
PRODUCT TO RAIN OR MOISTURE.
WARNING
If you ignore the warning message, you
may be seriously injured or there is a
possibility of accident or death.
CAUTION
If you ignore the caution message, you may
be slightly injured or the product may be
damaged.
NOTE
The note helps you understand and use
the product safely. Please read the note
carefully before using the product.
WARNING: This product contains chemicals
known to the State of California to cause cancer
and birth defects or other reproductive harm.
Wash hands after handling.
Downloaded from www.vandenborre.be

ENGLISH
3
IMPORTANT SAFETY INSTRUCTIONS
yProtect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
yOnly use attachments/accessories specified
by the manufacturer.
yUse only with a cart, stand, tripod, bracket,
or table specified by the manufacturer, or
sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
yUnplug this apparatus during lightning storms
or when unused for long periods of time.
yRefer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.
yDo not stick metal objects or any other
conductive material into the power cord. Do
not touch the end of the power cord while it
is plugged in.
yKeep the packing anti-moisture material or
vinyl packing out of the reach of children. Anti-
moisture material is harmful if swallowed. If
swallowed by mistake, induce vomiting and
go the nearest hospital. Additionally, vinyl
packing can cause suffocation. Keep it out of
the reach of children.
yCAUTION concerning the Power Cord
(Can differ by country):
It is recommended that appliances be
placed upon a dedicated circuit; that is, a
single outlet circuit which powers only that
appliance and has no additional outlets or
branch circuits. Check the specification page
of this owner’s manual to be certain. Do not
connect too many appliances to the same
AC power outlet as this could result in fire or
electric shock. Do not overload wall outlets.
Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power
cords, or damaged or cracked wire insulation
are dangerous. Any of these conditions could
result in electric shock or fire. Periodically
examine the cord of your appliance, and
if its appearance indicates damage or
deterioration, unplug it, discontinue use of
the appliance, and have the cord replaced
with an exact replacement part by an
authorized service. Protect the power cord
from physical or mechanical abuse, such as
being twisted, kinked, pinched, closed in a
door, or walked upon. Pay particular attention
to plugs, wall outlets, and the point where
the cord exits the appliance. Do not move
the TV with the power cord plugged in. Do
not use a damaged or loose power cord. Be
sure do grasp the plug when unplugging the
power cord. Do not pull on the power cord to
unplug the TV.
yWarning - To reduce the risk of fire or
electrical shock, do not expose this product
to rain, moisture or other liquids. Do not
touch the TV with wet hands. Do not install
this product near flammable objects such
as gasoline or candles, or expose the TV to
direct air conditioning.
yDo not expose to dripping or splashing and
do not place objects filled with liquids, such
as vases, cups, etc. on or over the apparatus
(e.g. on shelves above the unit).
Downloaded from www.vandenborre.be

ENGLISH
4IMPORTANT SAFETY INSTRUCTIONS
yGrounding
(Except for devices which are not grounded.)
Ensure that you connect the earth ground
wire to prevent possible electric shock
(i.e. a TV with a three-prong grounded AC
plug must be connected to a three-prong
grounded AC outlet). If grounding methods
are not possible, have a qualified electrician
install a separate circuit breaker. Do not try to
ground the unit by connecting it to telephone
wires, lightening rods, or gas pipes.
Short-circuit
Breaker
Power
Supply
yAs long as this unit is connected to the AC
wall outlet, it is not disconnected from the
AC power source even if the unit is turned
off.
yDo not attempt to modify this product in
any way without written authorization from
LG Electronics. Unauthorized modification
could void the user’s authority to operate this
product.
yOutdoor Antenna Grounding (Can differ by
country):
If an outdoor antenna is installed, follow
the precautions below. An outdoor antenna
system should not be located in the vicinity
of overhead power lines or other electric light
or power circuits, or where it can come in
contact with such power lines or circuits as
death or serious injury can occur. Be sure the
antenna system is grounded so as to provide
some protection against voltage surges
and built-up static charges. Section 810 of
the National Electrical Code (NEC) in the
U.S.A. provides information with respect to
proper grounding of the mast and supporting
structure, grounding of the lead-in wire to
an antenna discharge unit, size of grounding
conductors, location of antenna discharge
unit, connection to grounding electrodes and
requirements for the grounding electrode.
Antenna grounding according to the National
Electrical Code, ANSI/NFPA 70
Short-circuit
Breaker
Power Supply
Ground Clamp
Grounding Conductor
(NEC Section 810-21)
Antenna Lead in Wire
Electric Service
Equipment
Antenna Discharge Unit
(NEC Section 810-20)
Ground Clamp Power Service Grounding
Electrode System
(NEC Art 250, Part H)
NEC: National Electrical Code
yCleaning
When cleaning, unplug the power cord and
wipe gently with a soft cloth to prevent
scratching. Do not spray water or other
liquids directly on the TV as electric shock
may occur. Do not clean with chemicals such
as alcohol, thinners, or benzine.
yMoving
Make sure the product is turned off,
unplugged, and all cables have been
removed. It may take 2 or more people to
carry larger TVs. Do not press or put stress
on the front panel of the TV.
yVentilation
Install your TV where there is proper
ventilation. Do not install in a confined space
such as a bookcase. Do not cover the product
with cloth or other materials while plugged.
Do not install in excessively dusty places.
yIf you smell smoke or other odors coming
from the TV, unplug the power cord and
contact an authorized service center.
yKeep the product away from direct sunlight.
yNever touch this apparatus or antenna during
a lightning storm.
yWhen mounting a TV on the wall, make sure
not to install the TV by hanging the power
and signal cables on the back of the TV.
yDo not allow an impact shock, any objects to
fall into the product, and do not drop anything
onto the screen.
yDisconnecting the Main Power
The power outlet used with this device must
remain easily accessible.
yStore the accessories (battery, etc.) in a safe
location out of the reach of children.
yThis apparatus uses batteries. In your
community there might be regulations that
require you to dispose of these batteries
properly due to environmental considerations.
Please contact your local authorities for
disposal or recycling information.
yDo not dispose of batteries in a fire.
yDo not short circuit, disassemble, or allow
the batteries to overheat.
Downloaded from www.vandenborre.be

ENGLISH
5
IMPORTANT SAFETY INSTRUCTIONS
yDot Defect
The panel is a high technology product with
resolution of two million to six million pixels.
In a very few cases, you could see fine dots
on the screen while you’re viewing the TV.
Those dots are deactivated pixels and do not
affect the performance and reliability of the
TV.
yGenerated Sound
Cracking noise: A cracking noise that occurs
when watching or turning off the TV is
generated by plastic thermal contraction
due to temperature and humidity. This noise
is common for products where thermal
deformation is required.
Electrical circuit humming/panel buzzing: A
low level noise is generated from a high-
speed switching circuit, which supplies a
large amount of current to operate a product.
It varies depending upon the product.
This generated sound does not affect the
performance and reliability of the product.
yTake care not to touch the ventilation
openings. When watching the TV for a long
period, the ventilation openings may become
hot. This does not affect the performance of
the product or cause defects in the product.
Preventing image burn or burn-in on your
TV screen
yIf a fixed image displays on the TV screen for
a long period of time, it will be imprinted and
become a permanent disfigurement on the
screen. This is image burn or burn-in and not
covered by the warranty.
yIf the aspect ratio of the TV is set to 4:3 for a
long period of time, image burn may occur on
the letterboxed area of the screen.
yAvoid displaying a fixed image on the TV
screen for a long period of time (2 or more
hours for LCD, 1 or more hours for the
Plasma TV) to prevent image burn.
For USA and Canada
FCC NOTICE
This equipment has been tested and found
to comply with the limits for a Class B
digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is
no guarantee that interference will not occur
in a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be determined
by turning the equipment off and on, the user
is encouraged to try to correct the interference
by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the
equipment and the receiver.
- Connect the equipment to an outlet on
a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced
radio/TV technician for help.
This device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) this device may not cause
harmful interference and (2) this device must
accept any interference received, including
interference that may cause undesired
operation of the device.
Any changes or modifications in construction
of this device which are not expressly
approved by the party responsible for
compliance could void the user’s authority to
operate the equipment.
NOTE TO CABLE/TV INSTALLER
This reminder is provided to call the CATV
system installer’s attention to Article 820-
40 of the National Electric Code (U.S.A.).
The code provides guidelines for proper
grounding and, in particular, specifies that
the cable ground shall be connected to the
grounding system of the building, as close to
the point of the cable entry as practical.
Downloaded from www.vandenborre.be

ENGLISH
6LICENSES / OPEN SOURCE SOFTWARE NOTICE
LICENSES
Supported licenses may differ by model. For more information about licenses, visit www.lg.com .
Manufactured under license from Dolby Laboratories. “Dolby” and the
double-D symbol are trademarks of Dolby Laboratories.
The terms HDMI and HDMI High-Definition Multimedia Interface,
and the HDMI logo are trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other countries.
OPEN SOURCE SOFTWARE NOTICE
To obtain the source code we have obligation to release under GPL, LGPL, MPL and other open source
licenses, that is contained in this product, please visit http://opensource.lge.com .
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are
available for download.
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of
performing such distribution (such as the cost of media, shipping and handling) upon email request to
[email protected]. This offer is valid for three (3) years from the date on which you purchased the
product.
yImage shown may differ from your TV.
yYour TV’s OSD (On Screen Display) may differ slightly from that shown in this manual.
yThe available menus and options may differ from the input source or product model that you are
using.
yNew features may be added to this TV in the future.
NOTE
Downloaded from www.vandenborre.be

ENGLISH
7
ASSEMBLING AND PREPARING
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual
product and item.
yDo not use any unapproved items to ensure the safety and product life span.
yAny damages or injuries by using unapproved items are not covered by the warranty.
ySome models appear to have a thin film on the screen. It is actually part of the screen; do not
remove it.
CAUTION
Remote Control,
Batteries (AAA)
Owner’s Manual Power Cord Stand Body,
Stand Base
Stand Sticker
(Depending
upon model)
Stand Screws
3 EA, M5 x L25
Stand Screws
4 EA, M4 x L14
Ferrite core
(Depending
upon model)
yThe items supplied with your product may vary depending upon the
model.
yProduct specifications or contents of this manual may be changed
without prior notice due to upgrade of product functions.
yFor an optimal connection, HDMI cables and USB devices should
have bezels less than 10 mm (0.39 inches) thick and 18 mm
(0.7 inches) width.
yUse an extension cable that supports USB 2.0 if the USB cable or
USB flash drive does not fit into your TV’s USB port.
NOTE
B
AA
B
*A 10 mm (0.39 inches)
*B 18 mm (0.7 inches)
Downloaded from www.vandenborre.be

ENGLISH
8ASSEMBLING AND PREPARING
yHow to use the ferrite core (Depending upon model)
- If there are two ferrite cores, follow as shown in Figure 1.
- If there are three ferrite cores, follow as shown in Figures 1 & 2-1 (or 2-2).
1. Use the ferrite core to reduce the electromagnetic interference in the power cable.
Place the ferrite core close to the TV and a wall plug.
[Figure 1]
[to the TV]
[to a wall plug]
Wind the power cable on the ferrite core once.
2. Use the ferrite core to reduce the electromagnetic interference in the cable.
Place the ferrite core close to the TV.
[to an External device]
[to an External device]
[Figure 2-1] 10 mm(+ / - 5 mm)
10 mm(+ / - 5 mm)
Wind the component cable on the ferrite core once.
Wind the PC audio cable on the ferrite core once.
[Figure 2-2]
[to the TV]
[to the TV]
NOTE
(Black)
[Cross Section of
Ferrite Core]
(Black)
[Cross Section of
Ferrite Core]
Downloaded from www.vandenborre.be

ENGLISH
9
ASSEMBLING AND PREPARING
Lifting and moving the TV
When moving or lifting the TV, read the
following to prevent the TV from being
scratched or damaged and for safe
transportation regardless of its type and size.
yAvoid touching the screen at all times, as
this may result in damage to the screen.
yDo not place the product on the floor with
its front facing down. Failure to do so may
result in damage to the screen.
CAUTION
yIt is recommended to move the TV in the
box or packing material that the TV originally
came in.
yBefore moving or lifting the TV, disconnect
the power cord and all cables.
yWhen holding the TV, the screen should face
away from you to avoid damage.
yHold the top and bottom of the TV frame
firmly. Make sure not to hold the transparent
part, speaker, or speaker grill area.
yUse at least two people to move a large TV.
yWhen transporting the TV by hand, hold the
TV as shown in the following illustration.
yWhen transporting the TV, do not expose the
TV to jolts or excessive vibration.
yWhen transporting the TV, keep the TV
upright; never turn the TV on its side or tilt
towards the left or right.
Parts and Buttons
Screen
Joystick Button
Power Indicator
Remote Control Sensor
Intelligent Sensor1
Speakers
yJoystick button is located below the
screen of TV.
NOTE
1 Intelligent Sensor - Adjusts the image quality
and brightness based on the surrounding
environment.
Downloaded from www.vandenborre.be

ENGLISH
10 ASSEMBLING AND PREPARING
Using the joystick button
You can operate the TV by pressing the button or moving the joystick left, right, up, or down.
Basic Functions
Power On When the TV is turned off, place your finger on the joystick button,
press it once and release it.
Power Off When the TV is turned on, place your finger on the joystick button,
press it once for a few seconds and release it.
Volume Control If you place your finger over the joystick button and move it left or
right, you can adjust the volume level you want.
Channels Control If you place your finger over the joystick button and move it up or
down, you can scroll through the saved channels you want.
yWhen your finger over the joystick button and push it to the up, down, left, or right, be careful not to
press the joystick button. If you press the joystick button first, you can not adjust the volume level
and saved channels.
NOTE
Adjusting the Menu
When the TV is turned on, press the joystick button one time.
You can adjust the Menu items ( , , , ) moving the joystick button up, down, left, or right.
TV Off Turns the power off.
Settings Accesses the main menu.
Close Clears on-screen displays and returns to TV viewing.
Input List Changes the input source.
Downloaded from www.vandenborre.be

ENGLISH
11
ASSEMBLING AND PREPARING
Setting up the TV
You can mount your TV to a wall or attach the stand if you wish to place the TV on an entertainment
center or other furniture.
Attaching the stand
If you are not mounting the TV to a wall, use the following instructions to attach the stand.
2
Stand Body
Stand Base
Front
1 3
4 EA
M4 x L14
3 EA
M5 x L25
Before assembling, attach the Stand
Sticker under the Stand Body to reduce
the electromagnetic interference as
shown below. (Depending upon model)
yWhen attaching the stand to the TV
set, place the screen facing down on a
cushioned table or flat surface to protect the
screen from scratches.
CAUTION
Stand Sticker
Downloaded from www.vandenborre.be

ENGLISH
12 ASSEMBLING AND PREPARING
Mounting on a table
1Lift and tilt the TV into its upright position on
a table.
- Leave a 10 cm (4 inches) (minimum) space
from the wall for proper ventilation.
10 cm
10 cm
10 cm
10 cm
(4 inches)
2Connect the power cord to a wall outlet.
yDo not place the TV near or on sources
of heat, as this may result in fire or other
damage.
CAUTION
Securing the TV to a wall (optional)
(Depending upon model)
1Insert and tighten the eye-bolts, or TV
brackets and bolts on the back of the TV.
- If there are bolts inserted at the eye-bolts
position, remove the bolts first.
2Mount the wall brackets with the bolts to
the wall.
Match the location of the wall bracket and
the eye-bolts on the rear of the TV.
3Connect the eye-bolts and wall brackets
tightly with a sturdy rope or cable.
Make sure to keep the rope parallel to the
flat surface.
yMake sure that children do not climb on or
hang on the TV.
CAUTION
yUse a platform or cabinet that is strong and
large enough to support the TV securely.
yBrackets, bolts and ropes, are optional. You
can obtain additional accessories from your
local dealer.
NOTE
Downloaded from www.vandenborre.be

ENGLISH
13
ASSEMBLING AND PREPARING
Mounting on a wall
An optional wall mount can be used with your
LG Television. Consult with your local dealer for
a wall mount that supports the VESA standard
used by your TV model. Carefully attach the
wall mount bracket at the rear of the TV.
Install the wall mount bracket on a solid wall
perpendicular to the floor. If you are attaching
the TV to other building materials, please
contact qualified personnel to install the wall
mount. Detailed instructions will be included
with the wall mount. We recommend that you
use an LG brand wall mount.
10 cm
10 cm
10 cm
10 cm
(4 inches)
Make sure to use screws and wall mounts that
meet the VESA standard. Standard dimensions
for the wall mount kits are described in the
following table.
Model 50PB560B
50PB5600
60PB5600
VESA (A x B)
A
B
400 x 400
Standard screw M6
Number of screws 4
Wall mount bracket
(optional)
PSW420BX
yDisconnect the power before moving or
installing the TV. Otherwise electric shock
may occur.
yIf you install the TV on a ceiling or slanted
wall, it may fall and result in severe
injury. Use an authorized LG wall mount
and contact the local dealer or qualified
personnel. When using a third-party wall
mount, it is not covered by the warranty.
yDo not over tighten the screws as this may
cause damage to the TV and void your
warranty.
yUse the screws and wall mounts that meet
the VESA standard. Any damages or injuries
by misuse or using an improper accessory
are not covered by the warranty.
CAUTION
yUse the screws that are listed in the VESA
standard screw specifications.
yThe wall mount kit includes an installation
manual and necessary parts.
yThe wall mount bracket is optional. You can
obtain additional accessories from your local
dealer.
yThe length of screws may differ depending
upon the wall mount. Make sure to use the
proper length.
yFor more information, refer to the manual
supplied with the wall mount.
NOTE
Downloaded from www.vandenborre.be

ENGLISH
14 MAKING CONNECTIONS
MAKING CONNECTIONS
You can connect various external devices to the TV. Supported external devices are: HD receivers, DVD
players, VCRs, audio systems, USB storage devices, PC, gaming devices, and other external devices.
For more information on external device’s connection, refer to the manual provided with each device.
yIf you record a TV program on a DVD recorder or VCR, make sure to connect the TV signal input
cable to the TV through a DVD recorder or VCR. For more information about recording, refer to the
manual provided with the connected device.
yThe external device connections shown may differ slightly from illustrations in this manual.
yConnect external devices to the TV regardless about the order of the TV port.
yIf you connect a gaming device to the TV, use the cable supplied with the gaming device.
yRefer to the external equipment’s manual for operating instructions.
NOTE
Connecting to an antenna or cable
Connect an antenna, cable, or cable box to watch TV while referring to the following. The illustrations
may differ from the actual items and an RF cable is optional.
yMake sure not to bend the copper wire of
the RF cable.
Copper wire
yComplete all connections between devices,
and then connect the power cord to the
power outlet to prevent damage to your TV.
CAUTION
yUse a signal splitter to use more than
2 TVs.
yDTV Audio Supported Codec: MPEG,
Dolby Digital
NOTE
ANTENNA/
CABLE IN
VHF Antenna
UHF Antenna
Antenna
Terminal
Coaxial (75Ω)
(*Not Provided)
Downloaded from www.vandenborre.be

ENGLISH
15
MAKING CONNECTIONS
Other connections
Connect your TV to external devices. For the best picture and audio quality, connect the external device
and the TV with the HDMI cable as shown. Depending upon the model, a cable may be provided.
PBPRY RL
VIDEO AUDIO
COMPONENT IN
/ AV IN
PC-AUDIO INY P B
P R
VIDEO L/MONO-AUDIO-R
ANTENNA/
CABLE IN
OPTICAL
DIGITAL
AUDIO OUT
OPTICAL AUDIO IN
VIDEO
MONO
( )
AUDIOL R
USB ININ (PC)
RS232C IN
(CONTROL & SERVICE)
HDMI
AUDIO OUT DVI OUT
Digital Audio
System
VCR / DVD / Blu-Ray / HD Cable Box
DVD / Blu-Ray /
HD Cable Box / HD STB / PC
USB
GREEN
BLUE
RED
WHITE
RED
YELLOW
WHITE
RED
GREEN
BLUE
RED
WHITE
RED
YELLOW
WHITE
RED
Downloaded from www.vandenborre.be

ENGLISH
16 REMOTE CONTROL
REMOTE CONTROL
The descriptions in this manual are based on the buttons on the remote control.
Please read this manual carefully and use the TV correctly. To install batteries,
open the battery cover, replace batteries (1.5 V AAA) matching the and
ends to the label inside the compartment, and close the battery cover. Failure to match the correct
polarities of the battery may cause the battery to burst or leak, resulting in fire, personal injury, or
ambient pollution. To remove the batteries, perform the installation actions in reverse.
yDo not mix old and new batteries, as this may damage the remote control.
CAUTION
This remote uses infrared light. When in use, it should be pointed in the direction of the TV’s remote
sensor.
(POWER) Turns the TV on or off.
TV Returns to the last TV channel.
CAPTION Activates or deactivates the subtitles.
AV MODE Selects an AV mode.
RATIO Resizes an image.
INPUT Changes the input source. Turns the TV on if it is off.
Number button Enters numbers.
- (Dash) Inserts a dash between numbers such as 2-1 and 2-2.
LIST Accesses the saved channel list.
FLASHBK Alternates between the two last channels selected (pressing repeatedly).
VOL Adjusts the volume level.
FAV Accesses your favorite channel list; Selects a menu or option.
AUDIO
Digital signal: Changes the audio language.
Analog signal: Changes the MTS sound.
MUTE Mutes all sounds.
CH Scrolls through the saved channels.
PAGE Moves to the previous or next screen.
PICTURE Changes the image mode.
INFO Shows information on the current program.
SOUND Changes the sound mode.
SETTINGS Accesses the main menu.
Q.MENU Accesses the quick menu.
Navigation buttons Scrolls through menus or options. (up/down/left/right)
OK Selects menus or options and confirms your input.
BACK Returns to the previous screen.
EXIT Clears all on-screen displays and returns to TV viewing.
Not functional.
SLEEP Sets the length of time until the TV to turns off.
Control buttons ( , , , , ) Controls the compatible devices (USB).
(Freeze) Freezes the current frame. (Not supported when using USB mode)
Color buttons These access special functions in some menus.
(: Red, : Green, : Yellow, : Blue)
Downloaded from www.vandenborre.be

ENGLISH
17
SETTINGS
SETTINGS
To set up the channels automatically
SETTINGS ➾CHANNEL ➙Auto Tuning
Memorizes automatically the channels being
broadcast.
yThe channels will not be memorized properly
if the antenna/cable is not installed correctly.
yAuto Tuning memorizes the channels that are
currently being broadcast.
yIf Lock System is turned on, a pop-up
window will appear asking for password.
To select Picture Mode
SETTINGS ➾ PICTURE ➙Picture Mode
Select the picture mode optimized for the
viewing environment or the program.
yVivid : Adjusts the video image for the retail
environment by enhancing the contrast,
brightness, color, and sharpness.
yStandard : Adjusts the image for the normal
environment.
yEco : The Energy Saver feature changes
settings on the TV to reduce power
consumption.
yCinema : Optimizes the video image for a
cinematic look to enjoy movies as if you are
in a movie theater.
yGame : Optimizes the video image for a fast
gaming screen such as PCs or games.
yExpert 1, 2 : Adjusts the detailed video image
settings for video experts as well as general
viewers.
yDepending upon input signal, available range
of picture modes may differ.
To set advanced control
SETTINGS ➾PICTURE ➙Picture Mode ➙
Advanced Control / Expert Control
For each picture mode, screen can be
calibrated; or for a special screen, picture
settings can be adjusted.
Select the desired Picture Mode.
yDynamic Contrast :Adjusts the contrast to
the optimal level according to the image’s
brightness.
yDynamic Color :Adjusts colors to make the
image appear in more natural colors.
ySkin Color : Skin color spectrum can be
separately set to implement the skin color as
defined by the user.
ySky Color : Sky color is set separately.
yGrass Color : Natural color spectrum
(meadows, hills, etc.) can be separately set.
yGamma : Sets the gradation curve according
to the output of picture signal in relation to
the input signal.
yColor Gamut : Selects the range of colors
that can be expressed.
yEdge Enhancer : Shows clearer and
distinctive yet natural edges of the video.
yColor Filter : Filters a specific color spectrum
in RGB colors to fine-tune color saturation
and hue accurately.
yColor Temperature : Adjusts the overall tone
of the screen as desired. In Expert mode,
detailed fine-tuning can be set via Gamma
method, etc.
yColor Management System : This system is
used by experts to adjust color with a test
pattern. They can select from six color areas
(Red/ Green/Blue/ Cyan/Magenta/Yellow)
without affecting other colors. For normal
images, adjustments may not result in
noticeable color changes.
yDepending upon input signal or other picture
settings, the range of detailed items for
adjustment may differ.
Downloaded from www.vandenborre.be

ENGLISH
18 SETTINGS
To set additional picture options
SETTINGS ➾PICTURE ➙Picture Mode ➙
Picture Option
Adjusts detailed setting for images.
yNoise Reduction : Eliminates noise in the
picture.
yMPEG Noise Reduction : Eliminates noise
generated while creating digital picture
signals.
yBlack Level : Adjusts the brightness and
contrast of the screen to suit the black level.
yReal Cinema : Optimizes the screen for
movie viewing.
yMotion Eye Care : [Depending upon model]
Saves power consumption by adjusting the
brightness corresponding to the movement
of the image on the screen.
yDepending upon input signal or other picture
settings, the range of detailed items for
adjustment may differ.
To use Energy Saving feature
SETTINGS ➾PICTURE ➙Energy Saving
Saves electric power by adjusting screen
brightness.
yIntelligent sensor : TV sensor detects the
ambient lighting and automatically adjusts
the screen brightness.
yOff : Turns off the Energy Saving.
yMinimum/Medium/Maximum : Applies the
pre-set Energy Saving.
yScreen Off : Screen is turned off and only
sound is played. Press any button on the
remote control to turn the screen back on.
To use TV speaker
SETTINGS ➾AUDIO ➙ TV Speaker
Sound is output through the TV speaker.
To set the password
SETTINGS ➾LOCK ➙ Set Password
Set or change the TV password.
yThe initial password is set to “0000”.
To set the caption
SETTINGS ➾OPTION ➙ Caption
View captions when the TV station provides
captioned programming. Program captions work
only on digital/analog broadcasts or external
input.
Change Caption to On and select caption
settings.
yMode
CC 1-4 (Closed Captioning) / Text 1-4 :
Displays the audio portion of a TV program
as text on the TV screen. CC1 is the most
common mode in use. Field 1 data channels:
two Captions (CC1, CC2), two Text (T1, T2).
Field 2 data channels: two Captions (CC3,
CC4), two Text (T3, T4).
Service 1-6 : This is only available for the
digital broadcasting system.
yDigital Option : Set up the size and color of
the captions on Digital Option. Please select
Set by Program or Custom. Select Custom to
adjust minute options such as the captions’
size and color.
To return to initial settings
SETTINGS ➾OPTION ➙ Initial Setting
Returns to initial default mode by deleting all
optional setup. Once initialization is completed,
the TV will turn off and on by itself.
yWhen Lock System is in place, a pop-up
window appears and asks for password.
yDo not turn off the power during initialization.
Downloaded from www.vandenborre.be

ENGLISH
19
SETTINGS / TO SEE WEB MANUAL
To remove the USB device
Q.MENU ➾Eject USB
Select a USB storage device and remove it.
Once the message that the USB device was
removed is displayed, remove the device from
the TV.
yAfter selecting to remove USB device, the
USB storage Device cannot be read. Remove
the USB storage device and then reconnect
it.
Warning when using USB storage devices
yThe TV recognizes only a USB storage
device.
yIf you connect a USB storage device to the
TV through a USB hub, your TV may not
recognize the USB storage device.
yThe TV may not recognize a USB storage
device that requires a special driver.
yThe recognition speed of a USB storage
device may differ Depending upon the
device.
yOnly use a USB storage device which has
normal music or image files.
yUse only USB storage devices that are
formatted as a FAT 32 or NTFS file system.
yYou may need to connect a USB storage
device to an external power supply with a
power adapter.
yIf the TV does not recognize a connected
USB storage device, replace the cable and try
again. Do not use an excessively long cable.
yThe TV does not support some USB storage
devices properly.
yYou can use a multi-partition (up to 4) USB
storage device.
yThe file alignment method of a USB storage
device is similar to the one of Window XP.
yYou cannot create or delete a folder saved in
a USB storage device directly on the TV.
yThe number of characters for a file name is
up to 100 English characters.
yIf there are too many folders and files in one
folder, it may not operate properly.
yThe recommended capacity for a USB
external hard disk is 2 TB or less and for a
USB storage device is 32 GB or less.
yIf a USB external hard disk with the Energy
Saving feature does not work, turn the USB
external hard disk off and on again to make
it work properly. For more information, refer
to the user manual of the USB external hard
disk.
yThe electrostatic can cause USB device’s
malfunction. In this case, USB Device has to
be plugged again.
Supported Photo Formats
yCategory : 2D (jpeg, jpg)
[Available file type]
SOF0: baseline,
SOF1: Sequential,
SOF2: Progressive
[Photo size]
Minimum: 64 x 64
Maximum: Normal Type:
15360 (W) x 8640 (H)
Progressive Type: 1024 (W) x 768 (H)
Supported Audio Formats
yFile type : mp3
[Bit rate] 32 Kbps - 320 Kbps
[Sample freq.] 16 kHz - 48 kHz
[Support] MPEG1, MPEG2, Layer2, Layer3
TO SEE WEB MANUAL
Web manual allows you to easily access
detailed TV information.
Go to
http://www.lg.com .
Downloaded from www.vandenborre.be

ENGLISH
20 SPECIFICATIONS
SPECIFICATIONS
Product specifications may be changed without prior notice due to upgrade of product functions.
Power requirement AC 110 - 240 V ~ 50 / 60 Hz
Television System NTSC-M, ATSC, 64 & 256 QAM
Program Coverage VHF 2-13, UHF 14-69, CATV 1-135, DTV 2-69, CADTV 1-135
External Antenna Impedance 75 Ω
Environment
condition
Operating Temperature 0°C ~ 40 °C (32 °F ~ 104 °F)
Operating Humidity Less than 80 %
Storage Temperature -20°C ~ 60 °C (-4 °F ~ 140 °F)
Storage Humidity Less than 85 %
MODELS 50PB5600
(50PB5600-UA)
60PB5600
(60PB5600-UA)
Dimensions
(W x H x D)
With stand 1,172 x 756.7 x 315 (mm) 1,390.8 x 880.9 x 340 (mm)
46.1 x 29.7 x 12.4 (inch) 54.7 x 34.6 x 13.3 (inch)
Without stand 1,172 x 700.9 x 56 (mm) 1,390.8 x 823.7 x 56 (mm)
46.1 x 27.5 x 2.2 (inch) 54.7 x 32.4 x 2.2 (inch)
Weight With stand 24.9 kg (54.8 lbs) 35.7 kg (78.7 lbs)
Without stand 23.3 kg (51.3 lbs) 33 kg (72.7 lbs)
Current Value / Power consumption 2.3 A / 250 W 3.1 A / 340 W
MODELS 50PB560B
(50PB560B-UA)
Dimensions
(W x H x D)
With stand 1,172 x 756.7 x 315 (mm)
46.1 x 29.7 x 12.4 (inch)
Without stand 1,172 x 700.9 x 56 (mm)
46.1 x 27.5 x 2.2 (inch)
Weight With stand 24.9 kg (54.8 lbs)
Without stand 23.3 kg (51.3 lbs)
Current Value / Power consumption 1.7 A / 190 W
Downloaded from www.vandenborre.be
