DLP PROJECTOR

SERVICE MANUAL

CHASSIS : RE-058A

MODEL : AN110B AN110W

MODEL : AN110B-JD AN110W-JD

website:http://biz.LGservice.com

e-mail:http://www.LGEservice.com/techsup.html

CAUTION

BEFORE SERVICING THE CHASSIS,

READ THE SAFETY PRECAUTIONS IN THIS MANUAL.

- 2 -

CONTENTS

CONTENTS .......................................................................................................................2

SAFETY PRECAUTIONS .................................................................................................3

CONTROL DESCRIPTIONS .............................................................................................4

REPLACING OF LAMP ....................................................................................................9

SPECIFICATIONS ...........................................................................................................11

ADJUSTMENT INSTRUCTION.......................................................................................13

BLOCK DIAGRAM..........................................................................................................17

EXPLODED VIEW...........................................................................................................18

EXPLODED VIEW PARTS LIST .....................................................................................19

REPLACEMENT PARTS LIST........................................................................................20

SVC. SHEET .......................................................................................................................

PRINTED CIRCUIT BOARD ...............................................................................................

- 3 -

SAFETY PRECAUTIONS

Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by in

the Schematic Diagram and Replacement Parts List.

It is essential that these special safety parts should be replaced with the same components as recommended in this manual to

prevent X-RADIATION, Shock, Fire, or other Hazards.

Do not modify the original design without permission of manufacturer.

General Guidance

An isolation Transformer should always be used during

the servicing of a receiver whose chassis is not isolated from

the AC power line. Use a transformer of adequate power rating

as this protects the technician from accidents resulting in

personal injury from electrical shocks.

It will also protect the receiver and it's components from being

damaged by accidental shorts of the circuitry that may be

inadvertently introduced during the service operation.

If any fuse (or Fusible Resistor) in this TV receiver is blown,

replace it with the specified.

When replacing a high wattage resistor (Oxide Metal Film

Resistor, over 1W), keep the resistor 10mm away from PCB.

Keep wires away from high voltage or high temperature parts.

Due to high vacuum and large surface area of picture tube,

extreme care should be used in handling the Picture Tube.

Do not lift the Picture tube by it's Neck.

X-RAY Radiation

Warning:

To determine the presence of high voltage, use an accurate

high impedance HV meter.

Adjust brightness, color, contrast controls to minimum.

Measure the high voltage.

The meter reading should indicate

23.5 ±1.5KV: 14-19 inch, 26 ±1.5KV: 19-21 inch,

29.0 ±1.5KV: 25-29 inch, 30.0 ±1.5KV: 32 inch

If the meter indication is out of tolerance, immediate service

and correction is required to prevent the possibility of

premature component failure.

Before returning the receiver to the customer,

always perform an AC leakage current check on the exposed

metallic parts of the cabinet, such as antennas, terminals, etc.,

to be sure the set is safe to operate without damage of

electrical shock.

Leakage Current Cold Check(Antenna Cold Check)

With the instrument AC plug removed from AC source,

connect an electrical jumper across the two AC plug prongs.

Place the AC switch in the on position, connect one lead of

ohm-meter to the AC plug prongs tied together and touch other

ohm-meter lead in turn to each exposed metallic parts such as

antenna terminals, phone jacks, etc.

If the exposed metallic part has a return path to the chassis, the

measured resistance should be between 1MΩ and 5.2MΩ.

When the exposed metal has no return path to the chassis the

reading must be infinite.

An other abnormality exists that must be corrected before the

receiver is returned to the customer.

Leakage Current Hot Check (See below Figure)

Plug the AC cord directly into the AC outlet.

Do not use a line Isolation Transformer during this check.

Connect 1.5K/10watt resistor in parallel with a 0.15uF capacitor

between a known good earth ground (Water Pipe, Conduit, etc.)

and the exposed metallic parts.

Measure the AC voltage across the resistor using AC

voltmeter with 1000 ohms/volt or more sensitivity.

Reverse plug the AC cord into the AC outlet and repeat AC

voltage measurements for each exposed metallic part. Any

voltage measured must not exceed 0.75 volt RMS which is

corresponds to 0.5mA.

In case any measurement is out of the limits specified, there is

possibility of shock hazard and the set must be checked and

repaired before it is returned to the customer.

Leakage Current Hot Check circuit

The source of X-RAY RADIATION in this TV receiver is the

High Voltage Section and the Picture Tube.

For continued X-RAY RADIATION protection, the

replacement tube must be the same type tube as specified in

the Replacement Parts List.

1.5 Kohm/10W

To Instrument's

exposed

METALLIC PARTS

Good Earth Ground

such as WATER PIPE,

CONDUIT etc.

AC Volt-meter

IMPORTANT SAFETY NOTICE

0.15uF

Part Descriptions

Main Body

Indicators

Remote control sensor

* The projector is manufactured using high-precision technology. You may, however, see on the Projector screen tiny black

points and/or bright points (red, blue, or green). This can be a normal result of the manufacturing process and does not

always indicate a malfunction.

Lens shift

Kensington Security System Connector

(Refer to Desktop Stand Installation and Setup

Guide)

RS-232C[SERVICE]

Auto sliding door

*When the projector is turned on, auto sliding door

is opened automatically.

Shutter

*When the projector is turned on, shutter is

opened automatically.

S-Video

RGB Input

(PC/DTV)

HDMI Input

Video

AC IN

- 4 -

CONTROL DESCRIPTIONS

- 5 -

Control Panel

MENU Button

SOURCE Button

A OK Button

FOCUS +/- Button

ZOOM +/- Button

POWER Button

- 6 -

Remote Control

Installing Batteries

POWER

AUTO SOURCE

STILL

BLANK

KEYSTONE

FOCUS

LIGHT

ZOOM

ARC OK

POWER Button

SOURCE Button

D / E Button

MENU Button

ARC Button (Refer to p.29)

AOK Button

ZOOM +/- Button (Refer to p.21)

LIGHT Button

* If you press the LIGHT buttons, the LED will be

turned on. As 5 seconds go on, LED will be

turned off.

STILL Button (Refer to p.33)

BLANK Button (Refer to p.31)

KEYSTONE +/- Button (Refer to p.31)

FOCUS D / EButton (Refer to p.21)

F /G Button

• Open the battery compartment cover on the back of the remote control and insert the

batteries with correct polarity, match “+” with “+”, and match “-” with “-”.

• Install two 1.5V “AAA” batteries.

Don’t mix used batteries with new batteries.

CAUTION

RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

AUTO Button (Refer to p.34)

- 7 -

* Lamp Indicator, operation indicator and temperature indicator at the top of the projector show the user the operating status

of the projector.

* If operation indicator is red, it’s state of checking the closed door or shutter.

Lamp Indicator

Temperature Indicator

Operation Indicator

Projector Status Indicators

Operation Indicator

Lamp Indicator

Temperature Indicator

Orange

Green(flashing)

Green

Orange(flashing)

Off

Red

Red(flashing)

Green(flashing)

Orange(flashing)

Orange

Red

Red (flashing)

Standby.

Lamp cooling until the lamp turn on.

On operation. (Turn on the lamp)

Projector lamp is cooling as power out (2 minutes)

Power off.

Projector lamp is reaching the end of its life and needs

to be replaced with a new lamp. (over 4000 hours)

The OSD, “Replace the Lamp” is displayed 5 seconds

from the first power on.

The projector has trouble in the lamp or around it at

power-on. Retry Power On again later. If lamp indicator

is red (flashing) again, contact a service center.

The lamp cover is not closed.

It’s state of not opening well the door or shutter. Contact a

service center.

This projector is in high temperature. Turn the power of

projector off and check the ventilator.

The projector is turned off as its high temperature.

Power has turned off due to problem with the

internal cooling fan. Contact a service center.

- 8 -

Accessories

Optional Extras

POWER

AUTO SOURCE

STILL

BLANK

KEYSTONE

FOCUS

LIGHT

ZOOM

ARC OK

* Contact your dealer to purchase these items.

* Contact your service personnel for replacing a new lamp.

* Projector lamp is reaching the end of its life and needs to be replaced with a new lamp.

Remote Control Power Cord Video Cable

Operating guide Wall mounting bracket

* Bolt and anchor are included in

the wall bracket.

Computer Cable RCA to D-Sub Adaptor

SCART to RCA jack (option)

Lamp Desktop Stand

S-Video Cable

Projection Screen

HDMI Cable HDMI to DVI Cable

1.5V

2 Batteries (size AAA)

RS-232C Cable Cable Cover

Last of Lamp unit replacement

Be careful when replacing lamp

The projector lamp usually lasts for about 4000 hours. You can see the used lamp

time in the Selecting Function section. You must replace the lamp when:

OThe projected image gets darker or starts to be deteriorated.

OThe lamp indicator is red.

OThe message “Replace The lamp” appears on the screen when turning the

projector lamp on.

- Press the POWER button on the control panel or remote control to cut off the power.

- If the operation indicator LED is orange and blinking, do not disconnect the mains supply until the operation indicator LED

is lit up constantly (orange).

- Allow the lamp to cool for 1 hour before replacing it.

- Replace only with the same type lamp from a LG Electronics Service Center using and other lamp

may cause damage to the Projector and lamp.

- Pull out the lamp only when replacing the lamp.

- Keep the lamp unit out of reach of children or and heat sources such as radiators, stoves.

- To reduce the risk of fire, lamp shall not be exposed to liquids or foreign material.

- Do not place the lamp near any heat source.

- Make sure the new lamp is securely tightened with screws. If not, the image may be dark or there could be a risk of fire.

- Never touch the lamp unit glass or otherwise image quality may be worse or lamp life may be reduced.

To obtain a replacement Lamp unit

Lamp model number is on page 47. Check the lamp model and then purchase it at LG Electronics Service Center.

Using other lamp may cause damage to the projector.

Lamp unit disposal

Dispose of the used lamp by returning it to the LG electronic service center.

Lamp indicators

- 9 -

REPLACING OF LAMP

* Checking and Initiating the Lamp time

1) Turn the power on and in normal mode , press the Enter key of the set and Enter key of the remote control for more than 5secons

at the same time.

2) Press the OK key to reset the lamp time and the press Menu key to exit.

- 10 -

Turn off the projector and unplug the power cable.

Carefully place the lens side down on a

cushioned surface that will protect the lens

from damage.

(Allow the lamp to cool for 1 hour before

replacing it.)

Remove the two retaining screws on the lamp

cover with a screwdriver or similar objects and then

lift off the lamp cover.

Lamp case bolt

After lifting the lamp cover off, remove the two

retaining screws on the lamp case with a screw-

driver or similar objects. 4Lift up the fixed wire knob on the lamp.

5Pull out the handle slowly and remove the lamp

case. 6Insert the new lamp gently into the correct position.

Make sure it is inserted correctly.

7Tighten the screws you removed in step 3.

(Make sure it is fixed hardly.)

8Replace the lamp cover and tighten the cover

screws.

(If the lamp cover is open, the lamp indicator flashes green

and the projector is not turned on.)

Replacing the Lamp

Bolt

Knob

Using and other lamp may cause damage to the projector or lamp.

Make sure the lamp cover is securely fastened. If the lamp cover is open, and the projector is not turned on.

In this case, contact your service center after checking the lamp to fix well.

SPECIFICATIONS

NOTE : Specifications and others are subject to change without notice for improvement

AScope

This standard can be applied to the DLP Projector(chassis : RE-058A) related to AN110B/W-JD Model.

ATest Condition

1) Temperature : 25°C±5°C (Only CST is 40°C ±2°C )

2) Relative Humidity: 65±10%

3) Power Voltage: Standard input voltage (100-240V~, 50/60Hz)

4) Use only parts designated in B.O.M.,PARTS SPEC.,or drawings.

5) Follow each drawing or spec for spec and performance of parts,based upon P/N of B.O.M

6) Warm up projector for more than 30min. before the measurement.

ATest and Inspection Method

1) performance:Follow the Standard of LG TV test

2) RCA JACK performance: Follow the standard of LG

3) Standards of extra requirement

SAFETY:CB(EN55013), Electric wave:CE(EN55020)

AGeneral Specification

- 11 -

No. Item

Video input applicable system

Power

Input Voltage

Market

Screen size

Aspect ratio

Operating Temperature

Operating Humidity

Storage Temperature

Storage Humidity

NTSC M

NTSC 4.43

PAL

PAL M

PAL N

SECAM

NTSC-PB

SMPS

100V(-10%) - 240(+6%)V~, 50/60Hz

World wide

16:9/ 4:3

16:9

-20

deg

3.579545 / 60Hz

4.433618 / 60Hz

4.433618 / 50Hz

3.575611 / 60Hz

3.582056 / 50Hz

4.286 / 50Hz

4.433618 / 60Hz

Specification

Min Typ Max Unit

Remark

- 12 -

AFeature and function

No. Item

REMOCON

DVI Input

RGB Input

Component input

Composite input

S-video input

RS232C Port

Local Key

Picture, Gamma

Picture, User Control

ACC

Display mode

Sound

OSD Language

NEC Code

1 Digital RGB

1 Separate

1 Y, PB, PR

480i, 480p, 720p, 1080i, 576i,576p

1 480i, 576i

1 480i,576i

Menu, Source, Enter, Focus+/-, Zoom+/-, Power

\Normal/ Film/ Sports

Contrast/ Brightness/ Color/ Tint/ Sharpness

Normal/ Warm/ Cool

Full/ 16:9 / 4:3/ Zoom1/ Zoom2

Korean/ English/ Deutsche/ Italian/ Espanol

/ Chinese/ France/ Swedish

DVI-D

D-Sub 15 pin

RCA jack(Yellow)

S-VIDEO jack

RS232 jack(only for Download)

Specification

Min Typ Max Unit

Remark

- 13 -

1. Application Object

This instruction is for the application to the DLP Projector

(Chassis : RE-058A).

2. Notes

(1) The power source insulation of this DLP Projector is not

charging type and you may not use the transformer for

isolation. It is advised to use an isolation transformer

between the power supply cable and power input of the set

to protect the test equipment.

(2) The adjustment must be performed under the correct

sequence.

(3) The adjustment must be performed under conditions of

25±5°C of temperature and 65°æ10% of relative humidity.

(4) The input voltage of the projector must remain at 110V~,

60Hz during adjustment.

(5) The set must be on for 5 minutes prior to any adjustment.

After receiving possible 100% white pattern, it is ready for

adjustment.

3. Components of adjustment mode

1) Pressing the adjust key on the service remote control will

open or close the service menu.

2) Components of adjustment mode : In pressing early Adjust

showing screen set

3) As shown <Fig.1>, use the CH+ (D),CH- (E) key to select

item, press the ENTER or VOLUME key to enter the item

you wish to adjust.

4) Press the ADJ key to exit the service menu.

5) Preparation for Adjustment

a. Power is connected in set to be power on.

b. Execute heat run over 5minutes.

4. Folding Mirror Adjustment

4-1. Illuminator Adjustment Sequence

After placing the optical engine on the JIG, check the

mirrors have correct vertical alignment.

Check with full white screen and make adjustments in the

following sequence.

(1) Up and Down Adjustment

1) Turn screw (A) up / down adjustment to the right and
