LG PA75U User manual

OWNER'S MANUAL
DLP PROJECTOR
PA75U
Please read the SAFETY INSTRUCTIONS section carefully before
using the product.
www.lg.com
P/NO : SAC30666053(1302-REV01)

2LICENSE
LICENSE
Manufactured under license from Dolby Laboratories. "Dolby"
and the double-D symbol are trademarks of Dolby Laboratories.
ABOUT DIVX VIDEO: DivX® is a digital video format created
by DivX, LLC, a subsidiary of Rovi Corporation. This is an
ofcial DivX Certied® device that plays DivX video. Visit divx.
com for more information and software tools to convert your
les into DivX videos.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX
Certied® device must be registered in order to play pur-
chased DivX Video-on-Demand (VOD) movies. To obtain your
registration code, locate the DivX VOD section in your device
setup menu. Go to vod.divx.com for more information on how
to complete your registration.
DivX Certied® to play DivX® video up to HD 1080p, including
premium content.
DivX®, DivX Certied® and associated logos are trademarks
of Rovi Corporation or its subsidiaries and are used under
license.
Covered by one or more of the following U.S. patents:
7,295,673; 7,460,668; 7,515,710; 7,519,274
The terms HDMI and HDMI High-Denition Multimedia
Interface, and the HDMI logo are trademarks or registered
trademarks of HDMI Licensing LLC in the United States and
other countries.
Manufactured under license under U.S. Patent Nos:
5,956,674; 5,974,380; 6,487,535 & other U.S. and worldwide
patents issued & pending. DTS, the Symbol, & DTS and the
Symbol together are registered trademarks & DTS 2.0 Chan-
nel is a trademark of DTS, Inc. Product includes software. ©
DTS, Inc. All Rights Reserved.
NOTE
 The product images and On-Screen Display (OSD) in this manual are examples
to help you understand how to operate the product, so they may be different from
the actual projector.
This device meets the EMC requirements for home appliances (Class B) and is
intended for home usage. This device can be used in all regions.

3
SAFETYINSTRUCTIONS
SAFETYINSTRUCTIONS
Please take note of the safety instructions to prevent any potential accident or misuse
of the projector.
 Safety precautions are given in two forms, i.e. Warning and Caution as detailed
below.
WARNING: Failure to follow the instructions may cause serious injury and even
death.
CAUTION: Failure to follow the instructions may cause injury to persons or dam- Failure to follow the instructions may cause injury to persons or dam-Failure to follow the instructions may cause injury to persons or dam-
age to the product.
 Read the owner's manual carefully and keep it to hand.
WARNING/CAUTION
- TO REDUCE THE RISK OF FIRE
AND ELECTRIC SHOCK, DO
NOT EXPOSE THIS PRODUCT
TO RAIN OR MOISTURE.
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF
ELECTRIC SHOCK DO NOT
REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS
INSIDE. REFER TO QUALIFIED
SERVICE PERSONNEL.
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with
arrowhead symbol, within an
equilateral triangle, is
intended to alert the user to the
presence of uninsulated “dangerous
voltage” within the product’s
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
WARNING/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within
an equilateral triangle is
intended to alert the user to
the presence of important operating
and maintenance (servicing)
instructions in the literature
accompanying the appliance.

4SAFETYINSTRUCTIONS
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
IndoorInstallation
WARNING
 Do not place the projector in direct
sunlight or near heat sources such as
radiators, fires, stoves, etc.
- This may cause fire.
 Do not place inflammables such as
flammable spray near the projector.
- This may cause fire.
 Do not allow children to cling to or
climb up to the projector.
- This may cause the projector to fall,
causing injury or death.
 Do not place the projector directly on
a carpet, rug or place where ventila-
tion is restricted such as a book shelf
or closet.
- This may cause the projector's in- This may cause the projector's in-This may cause the projector's in-
ternal temperature to rise and cause
fire.
 Do not place the projector close to
sources of steam or oil such as a
humidifier or kitchen counter.
- This may cause fire or electric
shock.
 Do not place the projector where it
might be exposed to dust.
- This may cause fire.
 Do not use the projector in a damp
place, such as a bathroom or a place
exposed to the wind and rain, where
it is likely to get wet.
- This may cause fire or electric
shock.
 Do not allow a tablecloth or curtain to
block the vents.
- This may cause the internal tem- This may cause the internal tem-This may cause the internal tem-
perature of the projector to rise and
cause fire.
 The distance between the projector
and the wall should be more than 30
cm for ventilation purposes.
- Otherwise, this may cause the inter- Otherwise, this may cause the inter-Otherwise, this may cause the inter-
nal temperature of the projector to
rise and cause fire.

5
SAFETYINSTRUCTIONS
CAUTION
 When installing the projector on a
table, be careful not to place it near
the edge.
- The projector may fall causing injury
to persons or product malfunction.
Make sure that you use the cabinet
or stand that fits the projector.
 Disconnect the projector from the
power supply and all connected ap-
paratus before moving the projector.
- Otherwise, the power cord may be
damaged causing fire or electric
shock.
 Do not place the projector on an
unstable or vibrating surface such as
a wobbly shelf or a slope.
- It may fall or flip and cause injury.
 Be careful not to tip or drop the pro-
jector over when connecting external
devices to the projector.
- This may cause injury to persons or
damage to the projector.
Power
WARNING
 The grounding wire should be con-
nected.
- Be sure to connect the grounding
wire to avoid damage to the projec-
tor or electric shock when there is a
short circuit.
If it is not possible to ground the unit,
purchase a circuit breaker and con-
nect the projector to its wall outlet.
Do not try to ground the projector to
the gas pipe, water pipe, lightning
rod, or telephone line, etc.
 The power plug should be inserted
fully into the power outlet.
- An unstable connection may cause
fire.
 Do not place heavy objects on the
power cord.
- This may cause fire or electric
shock.
 Never touch the power plug with a
wet hand.
- This may cause electric shock.
 Do not plug too many devices into
one multi-power outlet.
- This may cause fire due to the
power outlet overheating.
 Remove dust or contaminants around
power plug pins or wall outlets.
- Failure to do so may cause fire.
 To turn off the main power, remove
the power plug, which should be
positioned so it is easy to access for
operation.

6SAFETYINSTRUCTIONS
CAUTION
 Hold the plug firmly when unplugging.
- A broken wire in the cord may cause
fire.
 Ensure the power cord and plug are
not damaged, modified, severely
bent, twisted, pulled, sandwiched
or hot. Do not use the product if the
power outlet is loose.
- This may cause fire or electric
shock.
 Keep the power cord away from any
heating devices.
- The cord coating may melt and
cause fire or electric shock.
 Place the projector where people will
not trip over or tread on the power
cord to protect the power cord and
plug from any damage.
- This may cause fire or electric
shock.
 Do not turn the projector on or off by
plugging in the power plug or unplug-
ging it from the wall outlet.
(Do not use the power plug as a
switch.)
- This may cause electric shock or
product malfunction.
 Do not insert a conductor into the
other side of the wall outlet while the
power plug is inserted into the wall
outlet.
In addition, do not touch the power
plug immediately after it is discon-
nected from the wall outlet.
- This may cause electric shock.
 Only use the official power cord pro-
vided by LG Electronics. Do not use
other power cords.
- This may cause fire or electric
shock.
WheninUse
WARNING
 Do not place anything containing
liquid on top of the projector, such as
a vase, flower pot, cup, cosmetics, or
medicine; or ornaments, candles, etc.
- This may cause fire or electric
shock, or injury due to falling.
 In the event that there is a heavy
impact on the projector or the cabinet
is damaged, switch it off, unplug it
from the power outlet and contact an
authorized service center.
- Failure to do so may cause fire or
electric shock.
 Do not insert pieces of metal, such
as coins, hairpins or metal debris, or
flammable materials, such as paper
or matches, into the projector.
- This may cause fire or electric
shock.
 In the event that liquid or a foreign
object falls into the projector, switch it
off and unplug it from the power outlet
and contact our service center.
- Failure to do so may cause fire or
electric shock.
 Make sure that a child does not swal-
low the batteries when you replace
the old remote control batteries with
new ones. Keep batteries out of reach
of children.
- If a child swallows a battery, consult
a doctor immediately.
 Do not remove any covers except for
the lens cap. There is a high risk of
electric shock.
 Do not look directly into the lens when
the projector is in use. The strong
light may damage your eyes.

7
SAFETYINSTRUCTIONS
 When the lamp is on or has just been
turned off, avoid touching the air vent
or lamp, because these will be very
hot.
 If there is a gas leak, do not touch
the wall outlet. Open the window for
ventilation.
- A spark may cause a fire or burn.
 Be sure to open the lens cap before
using the projector.
 Never touch the projector or power
cord during thunder or lightning.
- This may cause electric shock.
 Do not use the projector near elec-
tronic devices that generate a strong
magnetic field.
 Do not wear the plastic package used
to pack the projector around your
head.
- This may cause suffocation.
 Do not use 3D glasses if you are not
watching 3D.
 Do not keep your hand on the projec-
tor for a long time when it is running.
 When you play a game by connect-
ing a game console to a projector, it
is recommended that you maintain a
distance of more than four times the
diagonal length of the screen.
 Make sure that the length of connect-
ing cable is long enough.
- Otherwise, the product may fall caus- Otherwise, the product may fall caus-Otherwise, the product may fall caus-
ing personal injury or damage to the
product.
CAUTION
 Do not place a heavy object on the
projector.
- It may fall down and cause physical
injury.
 Be careful to protect the lens from
heavy impact during transportation.
 Do not touch the lens of the projector.
The lens may be damaged.
 Do not use any sharp tools on the
projector such as a knife or hammer,
because this may damage the casing.
 In the event that no image appears
on the screen or no sound is heard,
stop using the projector. Switch off
the projector,
unplug it from the power outlet and
contact our service center.
- Failure to do so may cause fire or
electric shock.
 Do not drop an object onto the projec-
tor or apply heavy pressure to it.
- This may cause injury to persons or
product malfunction.
 It is recommended that you maintain
a distance of more than 5- 7 times
the diagonal length of the screen
between your eyes and the screen.
- If you watch the screen at a close
distance for a long time, your eye-
sight may become worse.

8SAFETYINSTRUCTIONS
Cleaning
WARNING
 Do not spray the projector with water
when cleaning. Do not allow water to
get into the projector or do not allow it
to get wet.
- This may cause fire or electric
shock.
 In the event that smoke or a strange
smell comes out from the projector or
a foreign object falls into the projector,
stop using it. Switch off the projector,
unplug it from the power outlet and
contact our service center.
- Otherwise, this may cause fire or
electric shock.
 Use an air spray or soft cloth or cotton
swab moistened with a lens cleaning
chemical or alcohol to remove dust or
stains on the front projection lens.
CAUTION
 Contact your seller or the Service
Center once a year to clean the inter-
nal parts of the projector.
- If you do not clean the contaminated
interior of the projector for a long
time, there may be a fire or product
malfunction.
 When cleaning plastic parts, such as
the projector case, unplug the power
first and wipe with a soft cloth. Do not
spray with water or wipe with a wet
cloth. When cleaning the plastic parts,
such as the projector case, do not
use cleanser, automobile or industrial
shiner, abrasive or wax, benzene,
alcohol, etc., which can damage the
product.
- This can cause fire, electric shock or
product damage (deformation, corro-
sion and damage).

9
SAFETYINSTRUCTIONS
Others
WARNING
 Only a qualified technician can disas-
semble or modify the projector. For
inspection, adjustment, or repair, con-
tact your seller or our service center.
- Otherwise, this may cause fire or
electric shock.
CAUTION
 Do not mix new batteries with old
batteries.
- This may cause fire or electric shock
caused by overheating and leakage.
 Unplug the power cord if the projector
is not used for a long period.
- Accumulated dust may cause electric
shock due to overheating, ignition, or poor
insulation, or fire due to a short circuit.
 Only use the specified type of battery.
- Burst or leaking batteries may cause
fire or electric shock.
 Do not charge the battery using any
devices other than the one provided
with the product.
- This may cause damage to the bat- This may cause damage to the bat-This may cause damage to the bat-
tery or fire.
 Dispose of the used battery properly.
- Failure to do so may cause explo- Failure to do so may cause explo-Failure to do so may cause explo-
sion or fire. The correct method of
disposal may vary depending on
your country or region. Dispose of
the battery pack according to the ap-
propriate instructions.
 Do not throw or disassemble the battery.
- This may cause fire or explosion due
to damage to the battery.
 Always use batteries approved and
certified by LG Electronics.- Failure to
do so may cause fire or explosion.
 Do not store the battery near
metallic objects, such as keys and
paper clips.
-Excess current may cause a rapid
increase in temperature, resulting in
fire or burns.
 Do not store the battery near any
heat source, such as a heater.
- This may cause fire or product mal-
function.
 Do not store it at temperatures higher
than 60°C or in high humidity.
- This may cause explosion or fire.
 Keep the battery out of reach of chil-
dren.
- Failure to do so may cause personal
injury or product malfunction.
 Make sure that the battery is
installed correctly.
- Failure to do so may cause explo-
sion or fire.
 The battery contains lithium-ion, so it
must be handled with care.
- Failure to do so may cause explo-
sion or fire.
 Make sure you use the same type of
battery for replacement.
 Incorrect battery replacement may
cause fire.

10 SAFETYINSTRUCTIONS
Antenna
 If you are using an outdoor antenna,
please install it away from electrical
wires to make sure it does not touch
any nearby wires even when it falls
down due to heavy wind.
- Failure to do so may cause electric
shock or physical injury.
 To prevent any raindrops flow into the
projector, bend the outdoor antenna
wire where it comes indoors.
- Raindrops flowing into the projector
may cause fire or electric shock.
 Do not use a portable antenna outside.
- If you use a portable antenna outside,
lightning or raindrops may cause fire
or electric shock. Therefore, be sure
to use it inside only.
 It is dangerous to wind a portable an-
tenna wire around a person, animal, or
object or to use the antenna wire as a
strap. Pay particularly special attention
to ensure an infant, child, elderly per-
son or a person with a mental disorder
or mental retardation does not use the
antenna wire.
 It is dangerous to throw a portable an-
tenna or use it as a toy. Be sure to use
it as a TV signal receiver only.
 Install a portable antenna away from
a person, metal, or an animal so that
it does not touch them. In particular, it
is extremely dangerous to insert your
head, hand, or foot into the antenna or
bend the antenna.
 Because the receiver sensitivity of
the portable antenna may be very
high depending on the location of or
distance from a TV transmitter, area,
house structure, surrounding environ-
ments (mountain, structure, building,
wall, or window material, etc.), or
nearby transportations (train, air-
plane, or vehicle, etc.), it is advisable
to subscribe to cable television at the
home or office.
 Antennagroundingaccordingto
theNationalElectricalCode,ANSI/
NFPA70
Antenna Lead in Wire
Grounding Conductor
(NEC Section 810-21)
Antenna Discharge Unit
(NEC Section 810-20)
Power Service
GroundingElectrode
System (NEC Art 250,
Part H)
NEC: National Electrical Code
Ground Clamp
Electric Service
Equipment
Ground Clamp

11
SAFETYINSTRUCTIONS
FCCNOTICE
FederalCommunications
Commission(FCC)Statement
You are cautioned that changes or
modifications not expressly approved
by the part responsible for compliance
could void the user’s authority to operate
the equipment.
This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to
part 15 of the FCC rules. These limits
are designed to provide reasonable
protection against harmful interference
in a residential installation. This
equipment generates, uses and can
radiate radio frequency energy and, if
not installed and used in accordance
with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does
cause harmful interference to radio
or television reception, which can be
determined by turning the equipment off
and on, the user is encouraged to try to
correct the interference by one or more
of the following measures:
- Reorient or relocate the receiving
antenna.
- Increase the separation between the
equipment and receiver.
- Connect the equipment into an outlet
on a circuit different from that to which
the receiver is connected.
- Consult the dealer or an experienced
radio/TV technician for help.
1) this device may not cause harmful
interference, and 2) this device must
accept any interference received,
including interference that may cause
undesired operation of the device of the
device.
FCCCaution
Any changes or modifications not
expressly approved by the party
responsible for compliance could void
the user’s authority to operate this
equipment and For indoor use only, use
outdoors or in other modes not covered
by this manual may violate the FCC
regulation and violate the user authority
to use the product. Specially, within the
5.15-5.25 GHz band, U-NII device is
restricted to indoor operations to reduce
any potential for harmful interference to
co-channel MSS operations.
FCCRFRadiationExposure
Statement:
This equipment complies with FCC
radiation exposure limits set forth for
an uncontrolled environment. End
users must follow the specific operating
instructions for satisfying RF exposure
compliance.

12 SAFETYINSTRUCTIONS
IC(CANADA)
IndustryCanadaStatement:
This device complies with RSS-210 of
the Industry Canada Rules. Operation
is subject to the
following two conditions:
1) this device may not cause
interference and
2) this device must accept any
interference, including interference
that may cause undesired operation
of the device.
Avisd’IndustrieCanada:
Cet appareil est conforme à la norme
CNR-210 des règlements d’Industrie
Canada. Son fonctionnement
est sujet aux deux conditions
suivantes :
1) Cet appareil ne doit pas provoquer
d’interférences et
2) Cet appareil doit accepter toutes
les interférences, y compris
celles pouvant entraîner son
dysfonctionnement.
ICRadiationExposureStatement:
This equipment complies with IC
radiation exposure limits set forth for
an uncontrolled environment.
NOTE: THE MANUFACTURER
IS NOT RESPONSIBLE
FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY
UNAUTHORIZED MODIFICATIONS
TO THIS EQUIPMENT. SUCH
MODIFICATIONS COULD VOID THE
USER’S AUTHORITY TO OPERATE
THE EQUIPMENT.
Avisd’IndustrieCanadasur
l’expositionauxrayonnements
Cet appareil est conforme aux limites
d’exposition aux rayonnements
d’Industrie Canada pour un
environnement non contrôlé.
REMARQUE : LE FABRICANT
N’EST PAS RESPONSABLE DES
INTERFÉRENCES
RADIOÉLECTRIQUES CAUSÉES
PAR DES MODIFICATIONS NON
AUTORISÉES APPORTÉES À
CET APPAREIL. DE TELLES
MODIFICATIONS POURRAIT
ANNULER L’AUTORISATION
ACCORDÉE À L’UTILISATEUR DE
FAIRE FONCTIONNER
L’APPAREIL.

13
SAFETYINSTRUCTIONS
Disposalofyouroldappliance
1. When this crossed-out wheeled bin
symbol is attached to a product it
means the product is covered by the
European Directive 2002/96/EC.
2. All electrical and electronic products
should be disposed of separately from
the municipal waste stream through
designated collection facilities ap-
pointed by your government or your
local authorities.
3. The correct disposal of your old
appliance will help prevent potential
negative consequences for the envi-
ronment and human health.
4. For more detailed information about
disposal of your old appliance, please
contact your city ofce, waste dis-
posal service or the shop where you
purchased the product.
Disposalofwaste
batteries/accumulators
1. When this crossed-out wheeled bin
symbol is attached to batteries/ac-
cumulators of Your product it means
they are covered by European Direc-
tive 2006/66/EC.
2. This symbol may be combined with
chemical symbols for mercury(Hg),
cadmium(Cd) or lead(Pb) if the bat-
tery Contains more that 0.0005 %
of mercury, 0.002 % of cadmium or
0.004 % of lead.
3. All batteries/accumulators should be
disposed separately from the mu-
nicipal waste stream via designated
collection facilities appointed by the
government or the local authorities.
4. The correct disposal of Your old
batteries/accumulators will help to
prevent potential negative conse-
quences for the environment, animal
and human health.
5. For more detailed information about
disposal of Your old batteries/accumu-
lators, please contact Your city ofce,
waste disposal service or the shop
where You purchased the product.

14 SAFETYINSTRUCTIONS
ForUSA
NOTETOCABLE/TVINSTALLER
This reminder is provided to call the
CATV system installer’s attention to
Article 820 - 40 of the National Electric
Code (U.S.A.). The code provides guide-
lines for proper grounding and, in partic-
ular, species that the cable ground shall
be connected to the grounding system of
the building, as close to the point of the
cable entry as practical.

15
Tableofcontents
UsingtheProjectorFunctions 31
-Home Menu 31
AdditionalOptions 32
-Adjusting the Aspect Ratio 32
-Using the Keystone
Function 33
-Using the Input List 33
UsingtheQuickMenu 34
ENTERTAINMENT 35
NetworkSetup 35
-One-Click Network
Connection 35
-Expert Settings for
Network Connection 35
-Wireless Network Connection 36
-Wireless Screen Sharing 36
UsingtheWi-FiScreenShare
Function 37
-Connecting the Wi-Fi Direct 37
UsingWiDi 37
-WiDi Setup (Wireless Display) 37
-Tips for Network Setup 38
UsingMediaLink 39
-Connecting Media Link 39
-Using Media Link 39
-System Requirements for PLEX
installation 40
-Cautions when Using Media Link 40
UsingthePremiumService 41
-Using the Premium Service 41
SMARTSHARE™ 42
BeforeUsing 42
-Connecting a USB Storage Device
42
-Removing a USB Storage Device 42
-Connecting DLNA 44
LICENSE 2
SAFETYINSTRUCTIONS 3
PREPARATION 17
Accessories 17
OptionalAccessories 18
PartsandComponents 19
Installation 20
-Installation Precautions 20
-Projection Distance per Screen Size
21
-How to Install the Projector Using a
Tripod 22
-Kensington Security System 22
REMOTECONTROL 23
MAGICREMOTECONTROL 25
PairingtheMagicRemoteControl 26
Re-pairingtheMagicRemoteControl 
 26
UsingtheMagicRemoteControl 26
WATCHINGWITHTHE
PROJECTOR 27
Connectingthe
AntennaorCable 27
ConnectingthePortableAntenna 28
-Antenna connection 28
-HDTV reception 29
-Antenna Installation 29
UsingtheProjector 30
-Turning on the Projector 30
-Focus and Position of the Screen
Image 30
-Using the Projector 30
Tableofcontents

16 Tableofcontents
UsingSmartShare™ 46
-Watching Videos 47
-Viewing the Photos 50
-Listening to Music 52
-Viewing the Files 53
UsingtheMagicalMirroringFunction 
 54
-Running Magical Mirroring 54
-MirrorOp Sender 57
3DFUNCTION 61
BeforeWatching3D 61
-While Watching 3D 61
RequirementsforWatching3D
Images 63
-Using the DLP-LINK (DLP-Ready)
Type Glasses 64
-Supported 3D Input Formats 64
Watching3DImages 65
CUSTOMIZINGSETTINGS 66
SettingsMenu 66
PICTURESettings 67
SOUNDSettings 71
CHANNELSettings 72
TIMESettings 73
LOCKSettings 74
OPTIONSettings 76
NETWORKSettings 78
CONNECTINGEXTERNAL
DEVICES 79
ConnectingHD
Receiver,DVDPlayer,orVCR 80
-HDMI Connection 80
ConnectingPC 80
-RGB Connection 80
ConnectingAV 81
-Component Connection 82
ConnectingHeadphones 82
ConnectingaLaptop 83
MAINTENANCE 84
Cleaning 84
-Cleaning the Lens 84
-Cleaning the Projector Case 84
HowtoFixtheLensCap 84
UpdatingtheSoftware 85
SmartProjectorFAQ 86
WIRELESSSPECIFICATIONS 
 87
WirelessLANModule
(TWFM-B003D)Specications 87
BluetoothModule
(BM-LDS302)Specications 88
SPECIFICATIONS 89

17
PREPARATION
PREPARATION
Accessories
Check the accessories provided with the product.
The picture may be different from the actual product.
 When connecting a cable to the HDMI or USB port,
be sure to use the jack that fits into the
USB/HDMI port. Use a standard sized jack
.
VOL
ENERGY SAVING INPUT
CH
FAV
MUTE
SETTINGS
OK
AV MODE EXIT
INFO
Key’s Key’s RATIO
1 2 3
4 5 6
7 8 9
0
FLASHBK
LIST
L/R AUTO SLEEP
STILL
HOME
MY APPS
Q.MENU
3D
莱单
確定
快捷莱单 退出
节目信息ⓘ
梯形 TV/RAD
1 2 3
4 5 6
7 8 9
0
左/右 自动调整 节目指南
图像静止
主页
我的应用
3D
节能模式 输入
节目列表 回看
音量 节目
喜愛节目
静音
翻
页
梯形
P
A
G
E
ⓘ
HOME
YRO FK
BACK
P\#DSSV
/ T1PHQX
6G
SURMHFWRU
Remote Control
Two AAA Batteries
Magic Remote Control
Two AA Batteries Owner's Manual Manual CD
Computer Cable Composite Gender AC-DC Adaptor
Power Cord Lens Cap, Strap Bag Portable
Antenna

18 PREPARATION
OptionalAccessories
To purchase optional accessories, visit an electronics store or online shopping site or
contact the retail store where you purchased the product.
Without prior notice, optional extras are subject to change in order to improve the per-
formance of the product, and new optional accessories may be added.
Projection Screen Tripod HDMI Cable
Video Cable Audio Cable
3D Glasses
(DLP-LINK or
DLP-Ready Type)
RGB to Component
Cable Coaxial Cable

19
PREPARATION
PartsandComponents
* The projector is manufactured using high-precision technology. You may, however,
see tiny black dots and/or bright colored dots (red, blue or green) that continuously
appear on the projector screen. This is a normal result of the manufacturing process
and does not indicate a malfunction.
$9,1
'&,1
$17(11$,1
5*%,1
Speaker
Focus Ring
Lens
2
Button Description
$9,1
'&,1
$17(11$,1
5*%,1
H
VOL -
VOL +
CH
CH
(Power) Turns the projector on or off.
$9,1
'&,1
$17(11$,1
5*%,1
H
VOL -
VOL +
CH
CH
(HOME) Enters the Home menu.
CH(Channel) Changes the TV channel.
Volume)-,+ Adjusts the volume level.
 Switches between menu functions.
ꔉ(OK) Shows the current mode and saves changes to the settings.
1 Due to the high temperature of the vent area, do not get close to the vent area.
2 Do not remove the lens cap while storing the projector or touch the lens when using
the projector. The lens may be damaged.
Control Panel
Back
H
VOL -
VOL +
CH
CH
Speaker
Vent
1

20 PREPARATION
Installation
InstallationPrecautions
 Place the projector in a well-ventilated
environment.
- To prevent internal heat from build-
ing up, install the projector in a well-
ventilated place.
Do not place anything near the
projector as this may block its air
vents. If the air vents are blocked,
the internal temperature
will increase.
- Do not place the projector on
a carpet or rug. If a projector model
has its inlet vent on its bottom, do
not block the vent and use the pro-
jector on a solid level surface.
- Be sure to prevent foreign objects
such as paper debris from entering
the projector.
- Leave an adequate distance (30 cm
or more) around the projector.
 Do not place the projector in a hot
or humid environment.
- Do not place the projector in a hot,
cold, or humid environment.
 Do not place the projector in a place
where it will easily attract dust.
- This may cause fire.
 Do not remove any covers
except for the lens cap. There is a
high risk of electric shock.
 The projector is manufactured using
high-precision technology. You may,
however, see tiny black dots and/
or bright colored dots (red, blue or
green) that continuously appear on
the projector screen. This is a
normal result of the manufacturing
process and does not indicate a mal-
function.
 The remote control may not work
in an environment where a lamp
equipped with electronic ballasts or a
three-wavelength fluorescent lamp is
installed. Replace the lamp with an
international standard lamp for
the remote control to work normally.
