LG CF3DJS User manual

G
Order Number : GETEC-C1-10-100 FCC Part 15 subpart B
Test Report Number : GETEC-E3-10-041 Page 1 / 1
EUT Type: LCOS PROJECTOR
FCC ID.: BEJCF3DJS
APPENDIX G
: USER’S MANUAL

OWNER’S MANUAL
LCOS PROJECTOR
CF3D
Please read this manual carefully before operating
your set and retain it for future reference.
www.lg.com

LCOS PROJECTOR
LCOS PROJECTOR
Warning - Class B
(b) For a Class B Digital device or peripheral, the instructions furnished the user shall include the fol-
lowing or similar statement, placed in a prominent location in the text of the manual:
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protec-
tion against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.

Contents
3
Contents
Disposal of your old appliance
1. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by
the European Directive 2002/96/EC.
2. All electrical and electronic products should be disposed of separately from the municipal waste stream
through designated collection facilities appointed by your government or your local authorities.
3. The correct disposal of your old appliance will help prevent potential negative consequences for the
environment and human health.
4. For more detailed information about disposal of your old appliance, please contact your city office,
waste disposal service or the shop where you purchased the product.
5. The fluorescent lamp used in this product contains a small amount of mercury. Do not dispose of this
product with general household waste. Disposal of this product must be carried out in accordance to
the regulations of your local authority.
Safety Instructions .......................................................4
Names of parts
Main Body ..........................................................................................7
Control Panel.....................................................................................7
Connecting Part .............................................................................. 8
Remote Control .............................................................................. 9
Installing Batteries........................................................................... 9
Projector Status Indicators ..........................................................10
Accessories ....................................................................................... 11
Optional Extras ...............................................................................11
Installing and Composition
Installation Precautions.................................................................12
Positioning the Projector..............................................................13
Kensington Security System.......................................................14
Turning on the Projector ..............................................................14
Turning off the Projector ..............................................................14
Focus and Position of the Screen Image................................15
Selecting Input Mode ...................................................................15
Connection
Connecting to a Desktop PC......................................................16
Connecting to a Video Source ...................................................16
Connecting to a DVD Player ....................................................... 17
Connecting to a D-TV Set-Top Box .......................................... 17
Function
To Use The 3D Video
Caution When Viewing 3D Video ..............................................18
When Viewing 3D Video ..............................................................18
How to Watch 3D Video...............................................................19
PICTURE Menu Options
Picture Mode ..................................................................................20
Color Temperature Function.......................................................20
Adjusting Picture Mode................................................................21
Advanced Control Function.........................................................21
Picture Reset Function.................................................................23
TruMotion Demo Function ..........................................................23
SCREEN Menu Options
Using the Still Function ...............................................................24
To Change PJT Mode..................................................................24
Using Aspect Ratio Function.....................................................25
Test Pattern Function ...................................................................25
Using Keystone Function ............................................................25
Auto Configure Function.............................................................26
RGB Config. Function ..................................................................26
TIME Menu Options
Sleep Time Function .................................................................... 27
Auto Off Function ......................................................................... 27
OPTION Menu Options
Selecting Language .....................................................................28
Using Blank Function ...................................................................28
Selecting Blank image.................................................................28
To Calibrate the Camera .............................................................29
To Adjust the Brightness of the Lamp....................................29
High Altitude Mode ......................................................................30
To Use the Monitor.......................................................................30
Network Setup ................................................................................31
Setting Input Label.......................................................................32
Setting Power Sound ...................................................................32
INFORMATION Menu Options
To See The Projector Information.............................................32
Information
Supported Monitor Display.........................................................33
Maintenance ...................................................................................34
Replacing the Lamp.....................................................................35
Specifications .................................................................................38
Open Source Software Notice...................................................39

Safety Instructions
4
Safety Instructions
Please take note of the safety instructions to prevent any potential accident or misuse of the projector.
ᰶSafety Instructions are given in two forms as detailed below.
WARNING : The violation of this instruction may cause serious injuries and even death.
NOTES : The violation of this instruction may cause injuries or damage to the projector.
ᰶAfter reading this manual, keep it in the place that you can access easily.
Indoor Installation WARNING
Do not place the Projector in direct
sunlight or near heat sources such
as radiators, fires, stove etc.
This may cause a fire hazard!
Do not place flammable materi-
als in, on or near the projector.
This may cause a fire hazard!
Do not hang on the installed
projector.
It may cause the projector to fall,
causing injury or death.
Power WARNING
Indoor Installation NOTES
Earth wire should be connected.
Ensure that you connect the earth ground
wire to prevent possible electric shock (That
is a Projector with a three-prong grounded
AC plug must be connected to a three-
prong grounded AC outlet).
If grounding methods are not possible, have
a qualified electrician install a separate circuit
breaker.
Do not try to ground the unit by connecting
it to telephone wires, lightening rods, or gas
pipes.
The power cord should be inserted
fully into the power outlet to avoid
a fire hazard!
This may cause a fire hazard or damage
the unit.
Do not place heavy objects on
the power cord.
This may cause a fire or an electric
shock hazard!
Do not place the projector close
to sources of steam or oil such
as a humidifier.
This may create a fire hazard or an
electric shock hazard!
Do not place the projector where
it might be exposed to dust.
This may cause a fire hazard or
damage to the unit!
Do not block the vents of the pro-
jector or restrict air-flow in any way.
This would cause the internal tempera-
ture to increase and could cause a fire
hazard or damage to the unit!
Ensure good ventilation around the
projector. The distance between
the projector and the wall should
be more than 30 cm.
An excessive increase in its internal
temperature may cause a fire hazard or
damage to the unit!
Do not use the projector in a
damp place such as a bathroom
where it is likely to get wet.
This may cause a fire or an electric
shock hazard!
Do not place the projector direct-
ly on a carpet, rug or place where
ventilation is restricted.
This would cause its internal tempera-
ture to increase and might create a
fire hazard or damage the unit.
When installing the projector on
a table, be careful not to place it
near the edge.
The projector could fall causing injury
and damage to the projector.
Only use a suitable stand.
Only use the projector on a level
and stable surface.
It may fall and cause injury and/or
damage to the unit.
Disconnect from the power sup-
ply and remove all connections
before moving, or cleaning.

Safety Instructions
5
Using WARNING
If water is spilt into the projector unplug it from the power supply
immediately and consult your Service Agent.
This may cause an electric shock hazard or damage to the unit!
Dispose of used batteries
carefully and safely.
In the case of a battery being
swallowed by a child please consult
a doctor immediately.
CAUTION concerning the Power Cord
It is recommend that most appliances be placed on a dedicated circuit; that is, a single outlet circuit
which powers only that appliance and has no additional outlets or branch circuits.Check the specification
page of this owner's manual to be certain.
Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords,
frayed power cords, or damaged or cracked wire insulation are dangerous.Any of these conditions could
result in electric shock or fire. Periodically examine the cord of your appliance, and if its appearance
indicates damage or deterioration, unplug it, discontinue use of the appliance, and have the cord
replaced with an exact replacement part by authorized service personnel.
Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched,
closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the
cord exits the appliance.
Do not remove any covers. High
risk of Electric Shock!
Don’t look directly into the lens
when the projector is in use. Eye
damage may occur!
Do not touch metal parts during
or soon after operation since the
vents will remain very hot!
Power WARNING
Power NOTES
Do not plug-in too many items
into one power outlet.
It may result in overheating of the out-
let and create a fire hazard!
Never touch the power plug with
a wet hand.
This may cause an electric shock
hazard!
Prevent dust from collecting on
the power plug pins or outlet.
This may cause a fire hazard!
Hold the plug firmly when
unplugging. If you pull the cord,
it may be damaged.
This may cause a fire hazard!
Do not use if the power cord or
the plug is damaged or any part
of the power outlet is loose.
This may cause a fire or an electric
shock hazard or damage to the unit!
Ensure the power cord does not
come into contact with sharp or
hot objects.
This may cause a fire or an electric
shock hazard or damage to the unit!
Place the projector where people
will not trip or tread on the power
cord.
This may cause a fire or an electric
shock hazard or damage to the unit!
Do not turn the projector On/Off by plugging-in or unplugging the
power plug to the wall outlet.
(Allow the unit to cool before removing power.)
It may cause mechanical failure or could cause an electric shock.
Do not place anything containing
liquid on top of the projector
such as flowerpot, cup, cosmet-
ics or candle.
This may cause a fire hazard or
damage to the unit!
In case of impact shock or damage
to the projector switch it off and
unplug it from the power outlet and
contact an authorized service center.
This may cause a fire or an electric shock
hazard or damage to the unit!
Do not allow any objects to fall
into the projector.
This may cause an electric shock haz-
ard or damage to the unit!

Safety Instructions
6
Using NOTES
Do not place heavy objects on
top of projector.
This may cause mechanical failure or
personal injury!
Take care not to impact the lens
particularly when moving the
projector.
Do not touch the lens of the pro-
jector. It is delicate and easily
damaged.
Others NOTES
Cleaning NOTES
Contact the Service
Center once a year to
clean the internal
parts of the projector.
Accumulated dust can
cause mechanical failure.
When cleaning the plastic parts such as projector case, unplug the power and
wipe it with a soft cloth. Do not use cleanser, spray water or wipe with a wet
cloth. Especially, never use cleanser (glass cleaner), automobile or industrial
shiner, abrasive or wax, benzene, alcohol etc., which can damage the product.
Use an air spray or soft cloth that is moist with a neutral detergent and water
for removing dust or stains on the projection lens.
It can cause fire, electric shock or product damage (deformation, corrosion and damage).
Cleaning WARNING
Do not use water while cleaning
the projector.
This may cause damage to the pro-
jector or an electric shock hazard.
In the unlikely event of smoke or
a strange smell from the projec-
tor, switch it off, unplug it from
the wall outlet and contact your
dealer or service center.
This may cause a fire or an electric
shock hazard or damage to the unit!
Use an air spray or soft cloth that
is moist with a neutral detergent
and water for removing dust or
stains on the projection lens.
Others WARNING
Do not attempt to service the projector yourself. Contact your dealer or service center.
This may cause damage to the projector and could give an electric Shock as well as invalidating the warranty!
Using WARNING
If the projector is in a room that experiences a gas leak, do not touch
the projector.
It can cause a fire or a burn by a spark.
Always open the lens door or
remove the lens cap when the
projector lamp is on.
Do not use any sharp tools on
the projector as this will damage
the casing.
In the event that an image does
not appear on the screen please
switch it off and unplug it from the
power outlet and contact your
Service Agent.
This may cause a fire or an electric
shock hazard or damage to the unit!
Do not drop the projector or
allow impact shock.
This may cause mechanical failure or
personal injury!
Be sure to unplug if the projector is
not to be used for a long period.
Accumulated dust may cause a fire haz-
ard or damage to the unit!
Only use the specified type
of battery.
This could cause damage to the
remote control.
Do not mix new batteries with old
batteries.
This may cause the batteries to over-
heat and leak.

Names of parts
7
Names of parts
Main Body
* The projector is manufactured using high-precision technology. You may, however, see on the Projector screen tiny black
points and/or bright points (red, blue, or green). This can be a normal result of the manufacturing process and does not
always indicate a malfunction.
Control Panel
MENU Button
Displays or closes menus.
AUTO Button
It automatically corrects the position and
shaking of the image in RGB mode.
INPUT Button
Switches to input modes.
LENS SHIFT Dial
Move the screen image up or down.
ġ/Ģ/˘/˚Button
Adjusts functions of menus.
󲄇OK Button
Checks present mode and saves
the change of functions.
Filter Cover
* Do not block this filter when using the
projector.
Remote Control Sensor
Camera Sensor
* Camera Calibration ໚ፏ⟮#ᒃ⠻㘊#ᗶ#⅖❓㘓፲ᎎ1
Air Vent Door
* Do not close the air vent door when using
the projector. There is chance that projector
may be turned off.
Lens and Lens Cap
* Do not touch the lens and opening the lens cap when using
the projector.
Slide the Door.
Focus Ring
Zoom Ring

Names of parts
8
Connecting Part
SVC Only
IR (Remote control sensor)
* Do not block the IR port for normal operation
of remote control.
COMPONENT IN
AC IN
Kensington Security System Connector
VIDEO IN
HDMI IN 1/2/3
RGB IN
RGB OUT
LAN

10
Names of parts
Projector Status Indicators
* Lamp indicator, operation indicator and temperature indicator at the top of the projector show the user the operating status
of the projector.
Operation
Blue Standby.
Green (Blinking) Power on.
Green Using the Projector.
Cyan (Blinking) Power off (lamp is cooling for 90 seconds).
Temperature
Red (Blinking) An error has occurred in the internal cooling fan.
Yellow High temperature warning.
Yellow (Blinking) Turned off due to excessive heat.
Lamp
Magenta The lamp is reaching the end of its life and needs to be replaced with a new
lamp.
Magenta (Blinking) An error has occurred in the lamp.
Red The lamp cover is opened.
Air Vein Door Cyan An error has occurred in the air vein.
Filter Blue (Blinking) The filter cover is opened.
Operation Indicator
Temperature Indicator
Lamp Indicator
Top Filter Cover Lock
Power Button
Turns ON/OFF the projector.

11
Names of parts
Ceiling mount for projector
Accessories
Optional Extras
* Contact your dealer to purchase these items.
* Optional parts can be changed without notice to improve the quality of the product, and new optional parts can be added.
Remote Control AAA Battery Owner’s manual CD Owner’s manual
Power Cord Polishing Cloth 3D Glasses eZ-Net Manager CD
Top Filter Bottom Filter
Projection Screen Lamp Computer Cable HDMI Cable
Video Cable Audio Cable Component Cable LAN Cable

Installing and Composition
12
Installing and Composition
Provide proper ventilation for this projector.
Place this projector in adequate temperature and humidity conditions.
• Install this projector only in a location where adequate temperature and humidity is available. (Refer to page 38)
Don’t place the projector where it can be covered with dust.
• This may cause overheating of the projector.
This projector is manufactured using high-precision technology. You may, however, see tiny black points and/or bright
points (red, blue or green) that continuously appear on the projector Screen. This is a normal result of the manufacturing
process and does not indicate a malfunction.
To display DTV programs, it is necessary to purchase a DTV receiver (Set-top Box) and connect it to the projector.
Installation Precautions
The remote control may not work when a lamp equipped with electronic ballast or a three-wavelength lamp is installed.
Replace those lamps with international standard products to use the remote control normally.
Do not obstruct the slots and openings of the projector. This may cause overheating and create a fire hazard.
• The projector is equipped with ventilation holes(intake) on
the bottom and ventilation holes(exhaust) on the front. Do
not block or place anything near these holes. Internal heat
build-up may occur, causing picture degradation or dam-
age to the projector.
• Do not place the projector on a carpet, rug or other similar
surface. It may prevent a adequate ventilation of the pro-
jector bottom. This product should be mounted to a wall
or ceiling only.
• Never push projector or spill any kind of liquid into the
projector.
• Leave an adequate distance (30 cm or more) around the
projector.

Installing and Composition
13
1. Place the projector on a sturdy and horizontal surface with the PC or AV source.
2. Place the projector with the desired distance from the screen. The distance between the projector and
the screen determines the actual size of the image.
3. Position the projector so that the lens is set at a right angle to the screen. If the projector is not set at a
right angle, the screen image will be crooked. Although, slight angles can be counteracted using the
Keystone adjustement. (Refer to page 26.)
4. Connect the power cable to the projector and the wall outlet after placing the projector in its desired
location.
Projection distance (D)
Lens shift
Max
Max
0%
80.5 mm
Projection distance (D)
Positioning the Projector
Screen
< Projection Distance Based on the Picture Format >
Screen height (X)
X/2
X/2
Y/2
Y/2
Screen
Screen Width (Y)
16 : 9 Scale
Screen Projection Distance
Diagonal Size (mm) Screen Width (Y)
(mm)
Screen height (X)
(mm)
Minimum Projection
Distance (D1) (m)
Maximum Projection
Distance (D2) (m)

Installing and Composition
14
• This projector has a Kensington Security System Connector on the side panel. Connect the Kensington Security System
cable as below.
• For the detailed installation and use of the Kensington Security System, refer to the user’s guide included with the
Kensington Security System set. And for further information, contact http://www.kensington.com, the internet homepage
of the Kensington company that deals with expensive electronic equipment such as notebook PCs or projectors.
• The Kensington Security System is an optional item.
Kensington Security System
Turning on the Projector
1. Make sure the power cord is connected correctly.
2.
Press the POWER button. The operation indicator is blinking green.
• 6G#Surmhfwru⠂#㍣⇛Ⅻ#Srzhu#rq#wlph⠞#໫፲ᎎ1
• Press the INPUT button to select the input signal you want.
• There will be short sound when the projector is being turned on.
• Check if the lens cap is open before turning on the power.
Turning off the Projector
1. Press the POWER button.
2. Press the POWER button again to turn off the power. If the operation indicator is blinking cyan, in other
words the fan is working (90 seconds), do not disconnect the projector. When the indicator turns blue, you
may remove the power cord (Refer to page 10).
LPower off?
Please press Power key again.

Installing and Composition
15
Selecting Input Mode
1. Press the INPUT button.
2. Selecting an input signal with the INPUT button will only change the projector only to connected inputs. You
can change it to any inputs with the ˘, ˚button.
• Selecting an input signal with the VIDEO, COMP, RGB, HDMI1, HDMI2 and HDMI3 buttons.
Input
ComponentVideo RGB HDMI 1 HDMI 2 HDMI 3
When an image appears on the screen, check if it is in focus and fits the screen properly.
When you need to move the screen image up or down, use the zoom ring on the projector to adjust the height as shown
below.
• To adjust the focus of the image, rotate the focus ring.
• To adjust the size of the image, rotate the zoom ring.
• Turn the Lens shift dial left or right to adjust the projector image up or down.
• Turning the Lens shift dial with excessive power may cause damage to the projector.
Focus and Position of the Screen Image
Focus Ring
Zoom Ring
Lens shift Dial

Connection
16
Connection
Connecting to a Desktop PC
* You can connect the projector to a computer with VGA, SVGA, XGA, SXGA output.
* Refer to page 33 for resolutions the projector supports.
< How to connect >
Connect the RGB IN of the projector and the RGB out-
put port of the computer with a computer cable.
* You may have to change the resolution that your PC
exports to one supported by the projector. Refer to page
33. This projector may not support output from laptops
when the laptop screen is on.
Connecting to a Video Source
< How to connect >
Connect the VIDEO of the projector to the output jack of
the video source with a video cable.
* You can connect a VCR, a camcorder or any other compatible video image source to the projector.
< VCR >
Video Cable
Computer Cable
Computer Cable

Connection
17
Connecting to a DVD Player
< How to connect a Component source >
Connect the COMPONENT IN of the projector and the
compontnt output port of the DVD Player with a compo-
nent cable.
* When connecting the component cable, match the jack
colors with the component cable.(Y=green, PB=blue, PR
=red)
< How to connect a HDMI source >
1. Connect the HDMI IN 1 (or HDMI IN 2/3) of the pro-
jector and the HDMI output port of the DVD Player
with an HDMI cable.
2. Set the DVD Player's resolution to one of the following:
480p(576p)/720p/1080i/1080p mode.
< How to use a HDMI source >
Surmhfwruᨦ#󰪇⢪#⿊#㝮/#KGPL#໚໚ᨦ#⿆⇢✾1
* Depending on the equipment, the component output jacks (Y, PB, PR) of the DVD Player may be labeled as Y, Pb, Pr/Y, B-Y, R-Y/Y, Cb, Cr.
< DVD Player >
Component cable
Component cable
Connecting to a D-TV Set-Top Box
< How to connect a HDMI source >
1. Connect the HDMI IN 1 (or HDMI IN 2/3) of the pro-
jector and the HDMI output port of the DTV set-top
box with an HDMI cable.
2. Set the DTV receiver's resolution to one of the follow-
ing: 480p(576p)/720p/1080i/1080p mode.
< How to use a HDMI source >
Surmhfwruᨦ#󰪇⢪#⿊#㝮/#KGPL#໚໚ᨦ#⿆⇢✾1
* To receive Digital TV (D-TV) programs, it is necessary to purchase a D-TV receiver (Set-Top Box) and connect it to
the projector.
* Please refer to the owner's manual of the D-TV Set-Top Box for the connection between the projector and D-TV
Set-Top Box.
< How to connect a Component source >
Connect the COMPONENT IN of the projector and the
compontnt output port of the D-TV Set-Top Box with a
component cable.
* When connecting the component cable, match the jack
colors with the component cable.(Y=green, PB=blue, PR
=red)
< D-TV Set-Top Box >
< D-TV Set-Top Box >
< DVD Player >
HDMI Cable
HDMI Cable

10
10
Function
18
To Use The 3D Video
Function
* The On-Screen Display (OSD) in this manual may be slightly different from your projector.
* This operating guide explains operation of RGB(PC) mode mainly.
Caution When Viewing 3D Video
When Viewing 3D Video
ŹWhen viewing 3D video, watch the projector within effective viewing angle and distance.
- If you exceed the viewing angle or distance, you may not be able to view the 3D video.
ŹIf you watch the 3D video too closely for a long period of time, it may hurt you eyesight.
ŹWatching screen with the 3D video glasses for a long period of time can cause drowsiness or fatigue to your eyes.
- If you feel headache, fatigue or drowsiness, stop watching screen and take a rest.
ŹPregnant woman, senior, person with heart problem or frequent drowsiness should refrain from watching 3D video.
- Viewers can confuse 3D video as reality to be surprised or excited.
ŹWhen watching 3D video, do not leave any fragile or dangerous objects nearby.
- You can confuse the 3D video as reality and suddenly move to cause an injury.
ŹDo not use the 3D glasses to replace the general glasses, sunglasses or protective goggles. It can cause an injury.
ŹDo not store the 3D glasses in hot or cold location. It can be deformed. Do not use deformed glasses.
ŹBecause the lens (Polarized film) of 3D glasses is sensitive to scratches, always use a soft and clean cloth to wipe the
product.
- Because any alien particle on the cloth can result in scratches, be cautious.
ŹDo not scratch the surface of the lens (Polarized film) of 3D glasses with a sharp tool or wipe the lens with chemicals.
- The polarized film can be scratched and the video may not look normal when viewing the 3D image.
ŹThe lens of the 3D glasses is different from those of general glasses, and is very thin. Therefore be careful with the glass-
es as the lens can be popped out easily.
ŹWarning for photosensitization seizure: Specific image from the video game and light or specific pattern from the video
can cause a seizure to some individuals. If you or anybody from your family has a history of epilepsy or seizure, please
consult your doctor before watching 3D video. Also the following symptoms can occur in unspecified conditions without
any previous history.
- If you experience dizziness, visual transition, visual or facial instability, unconscious action, convulsion, loss of con-
science, confusion, loss of directional sense or nausea during or after watching the 3D video, immediately stop watching
the 3D video and consult the doctor. Especially special care is required for children watching the 3D video. Risk of pho-
tosensitization seizure can be reduced with the following actions.
- Do not watch the 3D video when sleepy, tired or sick, and avoid watching the 3D video for a long period of time.
* 3D video is the technology of using the different view between the two eyes to make the screen on the screen to look as a 3D
space.
* Effective viewing angle: Top/Bottom 10°
Effective viewing distance: 1.5 m to 5 m
1.5 m ~ 5 m
ƒSpecific menus may not work while watching the 3D video.
ƒ3D video does not work during external input transition and editing naming of external device.
ƒ3D effect can be seen when 3D Mode is selected appropriately for the 3D input signal supplied to the
Projector.
ƒHDMI/DVI-PC input does not support 3D Mode.

Function
19
How to Watch 3D Video
1. Play the title produced in 3D video. Refer to the following for 3D video input format supported.
Signal Resolution Horizontal Frequency(kHz) Vertical Frequency(Hz) Playable 3D video format
HDMI
720p 1280x720 45.00 60
Top & Bottom, Side by Side
37.50 50
1080i
1920x1080
33.75 60
28.125 50
1080p
27.00 24 Top & Bottom, Side by Side,
Checker Board, Frame Sequential
33.75 30
67.50 60 Top & Bottom, Side by Side,
Checker Board, Frame Sequential
56.25 50
2. Press the 3D button on the remote control.
3. Press the ˘, ˚button to selecting the shape as shown in the screen, wear the 3D glasses.
To turn on 3D Mode, select this icon.
ᰯMove ᰷OK ᱷExit
Top & Bottom Side by Side Checker Board Frame Sequential
4. Press the L/Rbutton, the left/right video switches. Select the screen with 3D video with better visibility.
• Press the 3D button to return to normal screen viewing.
O
O
O
O
X
X
X
X
X
X
X
X
X
X
O
O
O
O
O
O
O
O
O
O
O
O
X
X
X
X
X
X
X
X
X
X
O
O
O
O
O
O
O
O
O
O
O
O
X
X
X
X
X
X
X
X
X
X
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
X
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
X
O
O
O
O
O
O
O
O
O
O
O
< 3D Mode ⠦#ᗶ#ᒃ⠻ಪፏ㘆#ᩖ᭒⾒#໚ፏ >
3D Mode Top & Bottom Side by Side Checker Board Frame Sequential
Resolution 720p, 1080i, 1080p 1080p 720p 1080p
Vertical Frquency 24 Hz, 30 Hz, 50 Hz, 60 Hz 24 Hz, 30 Hz, 50 Hz, 60 Hz 50 Hz, 60 Hz 24 Hz (1080p only)
Power
Input
3D
L/R
PATTERN
KEY.S
BLANK
RATIO
SLEEP
MENU
AUTO
Q.MENU
STILL
BACK
OK
VIDEO
COMP
RGB
HDMI1
HDMI2
HDMI3

Function
22
Color Temperature - This function enables Vivid/Standard/Natural/Cinema/Sport/Game.
ᰶSet to warm to enhance hotter colors such as red, or set to cool to make picture bluish.
Noise Reduction ᰶReduces screen noise without compromising video quality.
Gamma
Low : Make dark and middle gray level area of the picture brighter.
Medium: Express original picture levels.
High: Make dark and middle gray level area of the picture darker.
ᰶYou can adjust brightness of dark area and middle gray level area of the picture.
Black Level
Low: The reflection of the screen gets darker.
High: The reflection of the screen gets brighter.
ᰶSet black level of the screen to proper level.
ᰶThis function disables RGB input.
Real Cinema ᰶMakes video clips recorded in film look more natural by eliminating judder effect.
ᰶDVD and Blu-ray movies are filmed at 24 frames per second.
TruMotion
ᰶAdvance video technology that provides clearer, smoother images, even during fast action
scenes creating a more stable structure for a crisper picture.
Off: Turn off TruMotion operation.
Low: Provides smooth picture movement. Use this setting for standard use.
High: Provides smoother picture movement.
ᰶTruMotion works with all inputs except PC mode.
ᰶIf you enable TruMotion, noise may appear on the screen. If this occurs, set to Off.
ᰶIf you select Picture mode - Game set TruMotion to Off.
White Balance
- This function enables Expert 1/2.
ᰶThis is the function to adjust the overall color of the screen to the feeling you want.
a. Method : 2 Points
- Pattern: Inner, Outer
- Red/Green/Blue Contrast, Red/Green/Blue Brightness: The adjustment range is -50 ~
+50.
b. Method : 20 Points IRE
- Pattern: Inner, Outer
- IRE (Institute of Radio Engineers) is the unit to display the size of the video signal and
can be set among 5, 10, 15 - 95, 100. You can adjust Red, Green or Blue according to
each setting.
- Red/Green/Blue: The adjustment range is -50 - +50.
Color Management
System
- This function enables Expert 1/2.
ᰶAs the tool used by the experts to make adjustments by using the test patterns, this does
not affect other colors but can be used to selectively adjust the 6 color areas (Red/Green/
Blue/Cyan/Mgt/Yellow).
Color difference may not be distinctive even when you make the adjustments for the gen-
eral video.
Adjusts Red/Green/Blue/Yellow/Cyan, Magenta.
- Red/Green/Blue/Yellow/Cyan, Magenta Color: The adjustment range is -30 ~ +30.
- Red/Green/Blue/Yellow/Cyan, Magenta Tint: The adjustment range is -30 ~ +30.
- This function disables RGB input.
* ⠯ᣏ⎊㛢/#⚫Ⅻ⇎⢿#ᖛ♺#ᗚᠦ#⇎⢿㘊#⋂#⠲ጾ#㘗᭓⠞#᎖ᠦ⩻፲ᎎ1
