Important Safety Information
Congratulations on purchasing the DLP projector!
Important:
It is strongly recommended that you read this section carefully before using the projector. These
safety and usage instructions will ensure that you enjoy many years of safe use of the projector.
Keep this manual for future reference.
Symbols Used
Warning symbols are used on the unit and in this manual to alert you of hazardous situations.
The following styles are used in this manual to alert you to important information.
Note:
Provides additional information on the topic at hand.
Important:
Provides additional information that should not be overlooked.
Caution:
Alerts you to situations that may damage the unit.
Warning:
Alerts you to situations that may damage the unit, create a hazardous environment, or cause per-
sonal injury.
Throughout this manual, component parts and items in the OSD menus are denoted in bold font as in this
example:
“Push the Menu button on the remote control to open the Main menu.”
Remote Control
Some remote controls have a laser for pointing out items on a screen.
DANGER: Do not point the laser in the eyes. Doing so can damage the eyes permanently.
General Safety Information
 Do not open the unit case. Aside from the projection lamp, there are no user-serviceable parts in
the unit. For servicing, contact qualified service personnel.
 Follow all warnings and cautions in this manual and on the unit case.
 The projection lamp is extremely bright by design. To avoid damage to eyes, do not look into the
lens when the lamp is on.
 Do not place the unit on an unstable surface, cart, or stand.
 Avoid using the system near water, in direct sunlight, or near a heating device.
 Do not place heavy objects such as books or bags on the unit.
Downloaded from ProjectorsManual.com Manuals

P P
Pr
r
re
e
ef
f
fa
a
ac
c
ce
e
e
–iii –
Power Safety
 Only use the supplied power cord.
 Do not place anything on the power cord. Place the power cord where it will not be in the way of
foot traffic.
 Remove the batteries from the remote control when storing or not in use for a prolonged period.
Replacing the Lamp
Replacing the lamp can be hazardous if done incorrectly. Refer to “Replacing the Projection Lamp” on
page 36 for clear and safe instructions for this procedure. Before replacing the lamp:
 Unplug the power cord.
 Allow the lamp to cool for about one hour.
Spent Lamp Management
 This product contains a metal halide lamp, which contains mercury. Dispose of it as required by lo-
cal ordinances and regulations.
 The USA restricts or prohibits the disposal of some or all mercury containing lamps in the municipal
waste stream. Please visit www.lamprecycle.org for more information on specific state disposal re-
quirements and recycling facilities.
 The following states have laws that deal with information that wholesalers must provide to contrac-
tors for lamp disposal.
Connecticut
Maine
Minnesota
Rhode Island
 For users in Connecticut, please call our toll free number 1-888-657-5267 to place an order for the
delivery of a kit for returning a used lamp. The kit includes a box for the lamp, tape, and a return
shipping label. To return a lamp:
1. Place the lamp in the box, complete the enclosed form, and seal the box with the pro-
vided tape.
2. Affix the return shipping label to the box and call 1.800.463.3339 (FedEx Ground Service)
for box pickup.
Cleaning the Projector
 Unplug the power cord before cleaning. Refer to “Cleaning the Projector” on page 38.
 Allow the lamp to cool for about one hour.
Regulatory Warnings
Before installing and using the projector, read the regulatory notices in the “Regulatory Compliance” sec-
tion on page 53.
Downloaded from ProjectorsManual.com Manuals

D
D
DL
L
LP
P
P
P P
Pr
r
ro
o
oj
j
je
e
ec
c
ct
t
to
o
or
r
r—
—
—U
U
Us
s
se
e
er
r
r’
’
’s
s
s
M M
Ma
a
an
n
nu
u
ua
a
al
l
l
— iv —
Main Features
• Lightweight unit, easy to pack away and transport
• Compatible with all major video standards including NTSC, PAL, and SECAM
• A high brightness rating allows for presentations in daylight or in lit rooms
• Supports resolutions up to SXGA at 16.7 million colors to deliver crisp, clear images
• Flexible setup allows for front, rear, and ceiling projections
• Line-of-vision projections remain square, with advanced keystone correction for angled
projections
• Input source automatically detected
• “Off-to-go” cooling system allows this projector to shut down without a long cooling time
About this manual
This manual is intended for end users and describes how to install and operate the DLP projector. Wher-
ever possible, relevant information—such as an illustration and its description—has been kept on one
page. This printer-friendly format is both for your convenience and to help save paper, thereby protecting
the environment. It is suggested that you only print sections that are relevant to your needs.
