DLP PROJECTOR

SERVICE MANUAL

CAUTION

BEFORE SERVICING THE CHASSIS,

READ THE SAFETY PRECAUTIONS IN THIS MANUAL.

CHASSIS : FM12A

MODEL : HW300Y HW300Y-JE

North/Latin America http://aic.lgservice.com

Europe/Africa http://eic.lgservice.com

Asia/Oceania http://biz.lgservice.com

Internal Use Only

Printed in KoreaP/NO : MFL67213602(1105-REV00)

Only for training and service purposes

- 2 - LGE Internal Use Only

CONTENTS

CONTENTS .......................................................................................................2

SAFETY PRECAUTIONS .................................................................................3

SPECIFICATION ...............................................................................................4

ADJUSTMENT INSTRUCTION.........................................................................5

BLOCK DIAGRAM..........................................................................................13

EXPLODED VIEW...........................................................................................14

SCHEMATIC CIRCUIT DIAGRAM......................................................................

Only for training and service purposes

- 3 - LGE Internal Use Only

SAFETY PRECAUTIONS

Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by in the

Schematic Diagram and Replacement Parts List.

It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent

X-RADIATION, Shock, Fire, or other Hazards.

Do not modify the original design without permission of manufacturer.

General Guidance

An lsolation Transformer should always be used during the

servicing of a receiver whose chassis is not isolated from the AC

power line. Use a transformer of adequate power rating as this

protects the technician from accidents resulting in personal injury

from electrical shocks.

It will also protect the receiver and it's components from being

damaged by accidental shorts of the circuitary that may be

inadvertently introduced during the service operation.

If any fuse (or Fusible Resistor) in this monitor is blown, replace it

with the specified.

When replacing a high wattage resistor (Oxide Metal Film Resistor,

over 1W), keep the resistor 10mm away from PCB.

Keep wires away from high voltage or high temperature parts.

Due to high vacuum and large surface area of picture tube,

extreme care should be used in handling the Picture Tube. Do not

lift the Picture tube by it's Neck.

Leakage Current Cold Check(Antenna Cold Check)

With the instrument AC plug removed from AC source, connect an

electrical jumper across the two AC plug prongs. Place the AC

switch in the on positioin, connect one lead of ohm-meter to the AC

plug prongs tied together and touch other ohm-meter lead in turn to

each exposed metallic parts such as antenna terminals, phone

jacks, etc.

If the exposed metallic part has a return path to the chassis, the

measured resistance should be between 1MΩand 5.2MΩ.

When the exposed metal has no return path to the chassis the

reading must be infinite.

An other abnormality exists that must be corrected before the

receiver is returned to the customer.

Leakage Current Hot Check (See below Figure)

Plug the AC cord directly into the AC outlet.

Do not use a line Isolation Transformer during this check.

Connect 1.5K/10watt resistor in parallel with a 0.15uF capacitor

between a known good earth ground (Water Pipe, Conduit, etc.)

and the exposed metallic parts.

Measure the AC voltage across the resistor using AC voltmeter

with 1000 ohms/volt or more sensitivity.

Reverse plug the AC cord into the AC outlet and repeat AC voltage

measurements for each esposed metallic part. Any voltage

measured must not exceed 0.75 volt RMS which is corresponds to

3.5mA.

In case any measurement is out of the limits sepcified, there is

possibility of shock hazard and the set must be checked and

repaired before it is returned to the customer.

Leakage Current Hot Check circuit

1.5 Kohm/10W

To Instrument’s

exposed

METALLIC PARTS

Good Earth Ground

such as WATER PIPE,

CONDUIT etc.

AC Volt-meter

IMPORTANT SAFETY NOTICE

0.15uF

1. Application range

This specification is applied all of the DLP Projector FM12A chassis.

2. Requirement for Test

* Each part is tested as below without special appointment.

(1) Temperature : 25 ºC ± 5 ºC, CST : 40 ºC ± 2 ºC

(2) Relative Humidity : 65 % ± 10 %

(3) Power Voltage : Standard input voltage (100 V - 240 V @ 50 Hz / 60 Hz)

* Standard Voltage of each products is marked by models.

(4) Specification and performance of each parts are followed each drawing and specification by part number in accordance with

BOM.

(5) The receiver must be operated for about 30 minutes prior to the adjustment.

3. Test method

(1) Performance: LGE TV test method followed

(2) Required other specification

- Safety : UL, CSA, IEC, CE specification(EN55022 Class B)

- EMC : FCC, ICES, IEC, CE specification(EN60950-1)

4. General Specification

- 4 -

Only for training and service purposes

LGE Internal Use Only

SPECIFICATION

NOTE : Specifications and others are subject to change without notice for improvement

No. Item Specification Remark

Min Max Unit 3.579545 / 60 Hz

1. Video input applicable system 1) NTSC M

2. Power Adapter - DC 19.5 V @ 5.64 A (110 W)

3. Input Voltage AC 100 V ~ 240 ( ± 10 %) V, 50 Hz / 60 Hz

4. Market North America

5. Picture size WXGA (1280 x 800)

6. Aspect ratio 16:10

7. Operating Temperature 0 40 deg

8. Operating Humidity 80 %

9. Storage Temperature -20 60 deg

10. Storage Humidity 85 %

Only for training and service purposes

- 5 - LGE Internal Use Only

1. Application Object

This instruction is for the application to the DLP Projector

(Chassis: FM12A).

2. Notes

(1) The power source insulation of this DLP Projector is not

charging type and you may not use the transformer for

insulation. It is advised to use an insulation transform

between the power supply cable and power input of the set

to protect the test equipment.

(2) The adjustment must be performed under the correct

sequence. But, it can be changed within the error

boundary of performance, considering the mass

productivity.

(3) The adjustment must be performed in the circumstance of

25 °C ± 5 °C of temperature and 65 % ± 10 % of relative

humidity.

(4) For the adjustment, the receptor’s input voltage shall be

maintained at 220 V, 60 Hz.

(5) The set must be on for 5 minutes prior to any adjustment.

After receiving possible 100 % White Pattern, it is ready for

adjustment. If it is inevitable, it can be regardless of the

signal.

3. Composition of Adjustment Mode

(1) Select Default Mode for input source.

(2) The adjustment mode can be entered by pressing ADJ key

of the adjustment remote controller, and it also exits by

pressing EXIT key.

(3) Preparation for Adjustment

(4) Power is connected in set to be power on.

(5) Do heat run 5minutes.

4. Folding Mirror Adjustment

4-1. Illuminator Adjustment Sequence

- After putting the optical engine on the jig, check whether the

mirror part is fixated vertically. At this time the screen size

should be based on 40”. With the screen in full white

condition, look at the change in screen and brightness of the

illuminator to make appropriate adjustments.

- During the adjustment of the lights, adjust for the screws at

the three locations to be fully tight. After they were adjusted,

if they became loose and changed, tighten the screws at the

three locations and complete the adjustment of the lights

when they are tightened to the maximum.

(1) Up and Down Adjustment

- Before the adjustment, first adjust the screws to be

adequately tightened.

1) Turn screw (A) up / down adjustment to the right and

mark where the image is aligned.

2) Turn screw (A) up / down adjustment to the left and

mark where the image is aligned.

3) Turn screw (A) up / down adjustment to the right / left

and mark where the image is aligned. Fix the

adjustment screw in position.

(2) Left and Right Adjustment 1

- Before the adjustment, first adjust the screws to be

adequately tightened.

1) Turn screw (B)Left / Right adjustment to the right and

mark where the image is aligned.

2) Turn screw (B) Left / Right adjustment to the left and

mark where the image is aligned.

3) Turn screw (B)Left / Right adjustment to the right / left

and mark where the image is aligned. Fix the

adjustment screw in position.

(3) Left and Right Adjustment 2

- Before the adjustment, first adjust the screws to be

adequately tightened.

1) Turn screw (C)up / down adjustment to the right and

mark where the image is aligned.

2) Turn screw (C) up / down adjustment to the left and

mark where the image is aligned.

3) Turn screw (C)up / down adjustment to the right / left

and mark where the image is aligned. Fix the

adjustment screw in position.

ADJUSTMENT INSTRUCTION

(Fig. 4-1) Check location of the bottom side of the folding mirror

Step 1 Step 2 Step 3

(Fig. 4-1-1) Illuminator Up / Down Adjustment Sequence

Step 1 Step 2 Step 3

(Fig. 4-1-2) Illuminator Left/Right Adjustment Sequence 1

Step 1 Step 2 Step 3

(Fig. 4-1-3) Illuminator Left/Right Adjustment Sequence 2

Only for training and service purposes

- 6 - LGE Internal Use Only

(4) Final Adjustment

Repeat the adjustments of 1), 2), and 3) 2 times, and verify

with a driver if the lights are adjusted in the direction of the

screws being tightened to the maximum. Also, find the

optimal position of the lights and visually verify if there is any

part missing the light system, find the light position with the

highest brightness of the light system, measure the

brightness of the light system(CL-200), and fix the

adjustment screws of the light system after foreign object

inspection, focus line width(measurement category: refer to

the picture) inspection, and Focus Stopper position

inspection.

Up/down

screw A

Right

(tighten

direction)

Adjustment

part

Screen state

Initial state State after adjusting

Screw

direction Description

At first, upside illuminator goes down

and right illuminator also goes down in

detail.

Left

(loosen

direction)

At first, downside illuminator goes

down and left illuminator also goes

down.

left/right

screw B

Right

(tighten

direction)

At first, left illuminator goes down and

downside illuminator also goes down.

Left

(loosen

direction)

At first, right illuminator goes down and

upside illuminator also goes down.

left/right

screw C

Right

(tighten

direction)

At first, left illuminator goes down and

downside illuminator also goes down.

Left

(loosen

direction)

At first, right illuminator goes down and

upside illuminator also goes down.

4-2. Illuminator Phenomenon Adjustment

Illuminator goes down direction Illuminator goes down area

- 7 -

4-3. Focus test method and subject

- Test pattern : Resolution Pattern , White Cross-Hatch

Pattern

- Tools : Focus width measurement ruler

(1) Focus adjustment method

1) Set the projection distance of Engine as 1200 mm (40

Inch screen).

2) Pop up the Resolution Pattern among the Test Patterns

of Set, and fix the Focus on the part where the

Resolution Pattern is classified on each part of screen.

(all parts Balancing)

3) Popup the White Cross-Hatch Pattern and measure the

width of each Point.

4) Focus judging standard : 3.5 mm or less

4-4. Focus Stopper Location Verification

(Verification corresponding to screen

inch)

(1) Test pattern : White cross-hatch

(2) Visually verify focus after locating a white board 586 mm

from the projection lens so that screen is set to 20 inches.

(3) Inspect the location of the stopper after locating a white

board 1200 mm from the projection lens so that screen is

set to 40 inches

(4) Evaluation criteria for stopper location

Non-defective : Bushing shall be located within A

marking.(Fig. 4-4)

5. Caution for DMD

(Digital Micro-mirror Device)

5-1. Caution for DMD ESD

(1) Connector the grounding to prevent a damage of ESD

(Electrostatic Discharge) when handing the DMD.

(2) Wear a wrist strap to connect the ESD grounding in flesh

necessarily.

(3) Connect the ESD ground to workstation and an electric

conductor.

(4) Save the DMD after getting rid of a static electricity. Keep

it at an exclusive case when moving it When grounding,

open the case.

(5) Put on gloves for preventing static electricity.

(6) All work is done at static free location. Attach the tape or

remove a dust on the DMD front or DMD back pin

5-2. Caution for DMD Clean

(1) Follow the procedure and caution to prevent the screen

from being scratched.

(2) When DMD glass stains with dust, polish the front and

back DMD glass with soft cloth. Then, do it again after

rotating 180 degree the DMD. If necessary, keep under

observation.

(3) Don’t clean the DMD with the high pressure. The static

electricity and pressure will damage the DMD.

* Attachment )TI Reference :

DMD Handling Specification, DMD Cleaning

6. EDID Data Download

6-1. Used Device

Adjustment remote control

6-2. Adjustment Method

(1) Enter to adjustment mode with selecting “ADJ” on remote

control.

(2) Enter to “0. PCM EDID D/L”. with pressing right direction

key to get in EDID Download adjustment menu (Fig. 6-2-1)

(3) Select “START”

(4) When adjustment is completed, check RGB “OK(PCM)”,

HDMI1 “0K(PCM)”. (Fig. 6-2-2)

When it fails, Reset and check by trying the (3) process

again.

(5) To exit, press “ADJ” or “EXIT” of the adjustment remote

controller again to exit.

(6) To verify the adjustment result, enter PCM EDID D/L or IN-

START and verify.

Only for training and service purposes

LGE Internal Use Only

(Fig. 4-3) Resolution Pattern

(Fig. 4-4) Bushing verification location

(Fig.6-2-1

) Adjustment Menu when ADJ is selected (Left)

(Fig.6-2-2

)

Selection Category on ADJ Adjustment Menu (Right)

Only for training and service purposes

- 8 - LGE Internal Use Only

7. ADC Adjustment

7-1. Used Device

- Adjustment remote control

- Master equipment - MSPG-925FA

- RS232C Interface Board 1EA, RS232C Cable 1EA,

USB Cable 1EA, component cable 1EA,

component to jack cable 1EA, RGB PC cable 1EA

7-2. Adjustment Method

- The installation for the adjustment is as follows. Before the

adjustment, compose the remaining connections except

USB cable.

- Adjust Spec.

(1) Enter to adjustment mode with selecting “ADJ” on remote

control.

(2) Enter to “2. ADC CALIBRATION” with pressing right

direction key to get in ADC adjustment menu

(3) Connect USB cable to the Projector. (Fig. 7-2-1)

(4) Select “START” . (Fig. 7-2-4)

(5) When the adjustment is completed, Success message is

displayed, and if it fails, Fail message is displayed.

(6) While Success message is displayed, release the

connection of USB cable, and press “OK” or “EXIT” to

make the message disappear.

(7) When exiting from Fig. 7-2-4 state, press “ADJ” or “EXIT”

of the adjustment remote controller again to exit.

(8) To verify the adjustment result, enter ADC Calibration or

IN-START and verify.(Fig. 7-2-3, Fig. 7-2-4)

8. MAC Address Download

8-1. Used Device

- Adjustment remote control

- Play file: keydownload.exe

- Interface Board 1EA, RS232C cable USB Cable 1EA,

8-2. Adjustment Setting

(1) Connect PC and Interface Board with RS232C Cable, and

connect to the Set using USB Cable. (Fig. 8-3-1)

(2) Activate Play file:keydownload.exe, and select

“MAC_Only” for “INI File NAME” (Fig. 8-3-2, Fig. 8-3-3)

8-3. Adjustment Method

(1) Select “ADJ”of the adjustment remote controller to enter

adjustment mode.

(2) Press right direction key of “9. Mac ADDRESS D/L” to

enter Mac Address D/L state.

(3) In Fig.6.5 state, click ENTER key of PC.

(4) When the adjustment is completed, OK message is

displayed, and if it fails, NG message is displayed. (Fig. 8-

3-6)

(5) To exit, press “ADJ” or “EXIT” of the adjustment remote

controller again to exit.

(6) To verify the adjustment result, enter IN-START, and

verify. (Fig. 9-2)

(Fig. 8-3-1) Device Setting Diagram

Pattern No. Mode No. Resolution

ADC Comp 480i 65 209 720*480/60i

ADC Comp 1080p 225 1920*1080/60p

ADC RGB 126 1920*1080/60p

(Fig.

7-2-1)

Device Setting Diagram

(Fig.

7-2-2)

Pattern No. 65 Image

(Fig.

7-2-3) Adjustment Menu when ADJ is selected (Left)

(Fig.

7-2-4)

Selection Category on ADJ Adjustment Menu (Right)

(Fig. 8-3-2) Play file: keydownload.exe icon(Left)

(Fig. 8-3-3) Play file: keydownload.exe(Right)

- 9 -

- Enter Power Only Mode

(1) After assembling the SET, during the start of post process,

DC on the SET. (use keypad or remote controller)

(2) Press‘P-ONLY’key of the adjustment remote controller

to enter‘Power Only’mode.

(Full White Screen is displayed)

(3) To enter the next adjustment, press‘EXIT’key of the

remote controller to exit Full white screen, and proceed

with the adjustment.

9. EDID/ADC/MAC ADDRESS

Verification Adjustments

9-1. Used Device

- Adjustment Remote Controller

9-2. EDID, ADC, MAC Address verification

Methode

(1) Select“IN-START”of the adjustment remote controller.

(Input‘0413’for password)

(2) Verify RGB“OK”and HDMI1“0K”in“1.Adjust Check”

→.“3.EDID(PCM)”category. (Fig.7.1)

(3) Verify ADC Comp 480i“OK”, ADC Comp 1080p“0K”, and

ADC RGB“0K”in“1.Adjust Check”→.“2.Adjust ADC”

category

(4) “1.Adjust Check”→ Verify MAC Address downloaded at

the bottom left

(5) To exit, press“IN-START”or“EXIT”of the adjustment

remote controller again to exit.

10. White Balance Adjustment

10-1. Used Device

(1) Illuminometer (Model : CL-200) 1EA : Chromaticity

measurement from projection screen center

(2) Remote control 1EA

(3) CL200 and SET connection Interface Board 1EA

(4) CL200 Uart Communication Cable 1EA

10-2. Equipment Composition

10-3. Adjustment

* Carry out a heat run on the set for 5 minutes before

adjustment

(1) Connect as in the equipment composition diagram then

enter into adjustment mode by selecting “ADJ” on the

remote control.

(2) Execute adjustment by pressing the right direction key on

“3. DDP AUTO CCA” (Fig. 10-3-1)

Only for training and service purposes

LGE Internal Use Only

(Fig. 8-3-6)

Mac Address Download Completed Screen

(Fig. 8-3-4)

Adjustment Menu when ADJ is selected (Left)

(Fig. 8-3-5)

Setting

Screen on Mac Address D/L (Right)

(Fig. 9-2)

Adjustment Menu when IN-START is selected

(Fig. 10-3-1) Selection Category on ADJ Adjustment Menu

- 10 -

(3) Message as shown below can be verified after completion

of adjustment, and readjust following the (2)(3) step if

“Fail” occurs.

“OK” : White Balance Process Successful and Warm, Cool

chromaticity diagram is within the target.

“Fail” : White Balance Process Failure -> Execute

readjustment.

“Warm Fail” : White Balance Process Successful and

Warm chromaticity diagram deviated more

than 0.005 from the target.

“Cool Fail” : White Balance Process Successful and Cool

chromaticity diagram deviated more than

0.005 from the target.

“Warm and Cool Fail” : White Balance Process Successful,

and both Warm can Cool

chromaticity diagrams deviated

more than 0.005 from the target.

(4) For verification of White Balance adjustment results, press

ADJ Key and enter “4. DDP Manual CCA”. (Fig. 10-3-2)

(5) Read the coordinate of CL200 changing the Color Temp

Mode to Medium, COOL, Warm for checking the Spec of

each mode.

- Warm Mode : x = 0.313 ± 0.004, y = 0.326 ± 0.004

- Cool Mode : x = 0.283 ± 0.004, y = 0.297 ± 0.004

- If it goes over the deviation boundary with the value of

0.005, it has no problem. During Auto CCA, it becomes

OK only when it comes within the above deviation

boundary. Afterwards, if it goes out of the boundary a

little bit when it is checked with a manual CCA, it can be

judged as a deviation due to meter/environment. (Only for

Warm Mode and Cool Mode)

11. Brightness Inspection

- Measure the subjects below and it should satisfy the spec of

product specification.

(1) Brightness(Annsi-Lumen)

(2) Whiteness color coordinate(KAGA measures R,G,B color

coordinate)

(3) Color Uniformity

(4) Brightness Uniformity

11-1. Preparation for Adjustment and

Device Composition

(1) Adjustment Preparation

1) Input source: Default (No need to designate Source)

2) The order of operating the adjustment remote controller

buttons

- IN-STAR -> 4. DDP OPTIC CHECK -> Select Full

White.

(2) Brightness Measurement Screen Setting

(3) Projector Brightness Measurement JIG Software

Organization

1) Model Selection: HW300

2) Selecting screen size : W: 861 , H : 539

Only for training and service purposes

LGE Internal Use Only

(Fig. 10-3-2) Selection Category on INSTART Menu (Left)

(Fig. 10-3-3) Menu after entering Manual CCA (Right)

(Fig. 11-1-1)

Brightness Measurement Screen Setting Composition

(Fig. 11-1-2)

- 11 -

3) Explanation of R, G, B Inspection and Method

1. Press Black Adjustment Verification Button. (Fig. 11-1-3)

- The left side of the screen changes from Red/ Green

/Blue to Color Coordinate Table Measurement Screen

(x.y.Y).

2. Press Color Purity Inspection Button. (Fig. 11-1-4)

3. The screen (status indication line: Chromaticity

Measurement- Red Color Purity Inspection) changes to

Red Color Purity Inspection.

- The color of the inspection boundary at top right of the

screen changes to Red.

4. Press the direction key of the adjustment remote

controller to change the video of the projector to Red

Pattern.

- After 2~3 seconds, Red Color Coordinate Table Data

is transmitted from CL200.

- In the Result Display Window at right center of the

screen, the coordinate of the Red color and the

brightness are displayed.

5. Press "Next" button on the screen.

6. Screen (status indication line: Chromaticity

Measurement- Green Color Purity Inspection) changes

to Green Color Purity Inspection.

- The color of the inspection boundary at top right of the

screen changes to Green.

7. Press the direction key of the adjustment remote

controller to change the video of the projector to Green

Pattern.

- After 2~3 seconds, Green Color Coordinate Table

Data is transmitted from CL200.

- In the Result Display Window at right center of the

screen, the coordinate of the Green color and the

brightness are displayed.

8. Press "Next" button on the screen.

9. Screen (status indication line: Chromaticity

Measurement- Blue Color Purity Inspection) changes to

Blue Color Purity Inspection.

- The color of the inspection boundary at top right of the

screen changes to Blue.

10. Press the direction key of the adjustment remote

controller to change the video of the projector to Blue

Pattern.

- After 2~3 seconds, Blue Color Coordinate Table Data

is transmitted from CL200.

- In the Result Display Window at right center of the

screen, the coordinate of the Blue color and the

brightness are displayed.

11. Press “Finish” button on the screen.

4) White Brightness Inspection:

- Verify if it is at least HW300 Brightness Min Spec 210

ANSI lm.(Type : 255 ANSI-lm)

Only for training and service purposes

LGE Internal Use Only

(Fig. 11-1-3)

(Fig. 11-1-4)

(Fig. 11-1-5)

(Fig. 11-1-6)

(Fig. 11-1-7)

- 12 -

Only for training and service purposes

LGE Internal Use Only

12. TV Performance Inspection

(1) Channel Scan

1) Connect the signal to RF Jack.

2) Select “TV” by pressing “Input” on the remote control

3) Inspect the channels by carrying out auto scan by

selecting Menu-Channel-Auto Channel.

- Make sure to carry out AUTO SCAN on the first

production set (Lot)

(2) Analog TV inspection

1) Connect the signal to RF Jack.

2) Select “TV” by pressing “Input” on the remote control.

3) Select CH2, CH4 by changing the channel using

“CH+/CH-” on the remote control, then check the display

status.

(3) Digital TV Inspection

1) Connect the signal to RF Jack.

2) Check the DTV reception status by selecting DTVCH

31-3

[Reference]

1. EDID Data

1) RGB : BLOCK 0

2) HDMI : BLOCK 0

3) HDMI : BLOCK 1

0 123456789ABCDEF

0 00FFFFFFFFFFFF001E6DC73601 01 0101

10 01 15 01 03 68 73 41 78 0A CF 30 A3 57 4C B0 23

20 09 50 4E 21 08 00 81 C0 81 00 81 80 90 40 B3 00

30 71 40 01 01 01 01 9E 20 00 90 51 20 1F 30 48 80

40 36 00 90 3F 63 00 00 1E 01 1D 00 72 51 D0 1E 20

50 6E 28 55 00 7E 8A 42 00 00 1E 21 39 90 30 62 1A

60 27 40 68 B0 36 00 C0 41 84 00 00 20 00 00 00 FC

70 00 4C 47 20 50 4A 54 52 0A 20 20 20 20 20 00 B8

0 123456789ABCDEF

0 00FFFFFFFFFFFF001E6DC83601 01 0101

10 01 15 01 03 80 73 41 78 0A CF 74 A3 57 4C B0 23

20 09 48 4C 21 08 00 81 C0 81 00 81 80 90 40 B3 00

30 71 40 01 01 01 01 9E 20 00 90 51 20 1F 30 48 80

40 36 00 90 3F 63 00 00 1E 01 1D 00 72 51 D0 1E 20

50 6E 28 55 00 7E 8A 42 00 00 1E 21 39 90 30 62 1A

60 27 40 68 B0 36 00 C0 41 84 00 00 00 00 00 00 FC

70 00 4C 47 20 50 4A 54 52 0A 20 20 20 20 20 01 84

0 123456789ABCDEF

0 020318F1471022200584030223090707

10 67 03 0C 00 10 00 B8 2D 9E 20 00 90 51 20 1F 30

20 48 80 36 00 90 3F 63 00 00 1E 01 1D 80 18 71 1C

30 16 20 58 2C 25 00 7E 8A 42 00 00 9E 01 1D 00 72

40 51 D0 1E 20 6E 28 55 00 7E 8A 42 00 00 1E 8C 0A

50 D0 8A 20 E0 2D 10 10 3E 96 00 7E 8A 42 00 00 18

60 26 36 80 A0 70 38 1F 40 30 20 25 00 7E 8A 42 00

70 00 1A 00 00 00 00 00 00 00 00 00 00 00 00 00 AF

Only for training and service purposes

- 13 - LGE Internal Use Only

BLOCK DIAGRAM

- 14 -

Only for training and service purposes

LGE Internal Use Only

EXPLODED VIEW

300

810

720

400

500

800

730

700

520

510

200

120

100

110

630

650

620

670

680

690

660

691

640

610

600

Many electrical and mechanical parts in this chassis have special safety-related characteristics. These

parts are identified by in the Schematic Diagram and EXPLODED VIEW.

It is essential that these special safety parts should be replaced with the same components as

recommended in this manual to prevent X-RADIATION, Shock, Fire, or other Hazards.

Do not modify the original design without permission of manufacturer.

IMPORTANT SAFETY NOTICE

Pease refer to the work order standard for detail product disassembly / assembly.

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES

SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.

FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS

ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR

THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

2010.09.01

GP2_BCM_ATSC

USB_DM1

USB_DP1

HDMI_SDA

VOLUME

HDMI_CLK-

MAIN_TU_IF_OUT-

DSUB_B

DSUB_G

DSUB_R

MAIN_TU_IF_OUT+

HDMI_DET

HDMI_SCL

DSUB_HSYNC

USB_P

USB_N

UART0_RXD

UART0_TXD

USB_DM1

IC1400

PI3USB14LE

3IA3

2S1

4IA2

1EN

6IA0

5IA1

7YA

8GND

IB0

IB1

IB2

IB3

VCC

USB_DAT_P

C1401

0.1uF

16V

USB_S0

USB_DP1

USB_DAT_N

R1401

USB_N

USB_S1

COMP_DET

USB_P

Q1402

KRC104S

D1401

5.5V OPT

Q1403

KRC104S

HDMI_HPD_1

D1400

5.5V OPT

R1408

R1411

4.7K

+5V_NORMAL

+3.3V_NORMAL

R1415

100K

USB_PWRON1

+3.3V_NORMAL

R1416

180

C1403

0.1uF

C1402

0.1uF

IC1401

MIC2009YM6-TR

3ENABLE

2GND

FAULT/

1VIN

VOUT

ILIMIT

R1419

4.7K

USB_PWRFLT1

C1405

10uF

10V

R1421 0

R1420 0

EDID_WP

R1431 10K

R1433 100

R1427 22

C1407

0.1uFR1429 22

AUDIO_LIN

AUDIO_RIN

REAR_AV_DET

4814V00112J

OPT

C931 0.1uF

L901

BLM18PG121SN1D

R972 1K

OPT

+5V_NORMAL

C916 1000pF

A1.2V

R93622

C911 4.7uF

C940

4.7uF

R93522

C956

0.1uF

R916

C926 0.1uF

A1.2V

R93422

C920 0.01uF

A1.2V

C933 0.1uF

C946

0.01uF

C921 0.1uF

L903

BLM18PG121SN1D

A1.2V

C938 0.01uF

A1.2V

C917 1000pF

C952

0.1uF

C957 0.1uF

C918 4.7uF

A2.5V

D3.3V

L902

BLM18PG121SN1D

C945 0.01uF

R930 499

C944 0.1uF

C961 0.1uF

A2.5V

C907 0.1uF

C939 0.1uF

L906

BLM18PG121SN1D

+5V_NORMAL

C905 0.1uF

C942 0.1uF

C919 0.01uF

L904

BLM18PG121SN1D

R926

C953 0.1uF

C924 0.1uF

D3.3V

A1.2V

R931 10K

OPT

L907

BLM18PG121SN1D

C935 0.1uF

R990 10K

C936 0.01uF

C903 0.1uF

C951

1000pF

C908 0.1uF

R956 10K

R922

C915 0.1uF

R948 10K

C943 0.1uF

IC900

LGE3549XS (LGE3549XS P22 , B2 version)

DEV

EAN60345904

DS_AGCI_CTL

W26

DS_AGCT_CTL

W25

EDSAFE_AVSS_1

V20

EDSAFE_AVSS_2

W21

EDSAFE_AVSS_3

W22

EDSAFE_AVSS_4

Y23

EDSAFE_AVSS_5

AA24

EDSAFE_AVSS_6

Y26

EDSAFE_AVDD2P5

Y24

EDSAFE_DVDD1P2

AB26

EDSAFE_IF_N

AA26

EDSAFE_IF_P

AA25

PLL_DS_AVDD1P2

Y21

PLL_DS_TESTOUT

R21

SD_V1_AVDD1P2

AA16

SD_V1_AVDD2P5

AB13

SD_V1_AVSS_1

W14

SD_V1_AVSS_2

AA15

SD_V2_AVDD1P2

AB15

SD_V2_AVDD2P5

AB14

SD_V3_AVDD1P2

AA14

SD_V3_AVDD2P5

AC15

SD_V2_AVSS

Y14

SD_V3_AVSS_1

W13

SD_V3_AVSS_2

Y13

SD_V4_AVDD1P2

AA13

SD_V4_AVDD2P5

Y11

SD_V4_AVSS

Y12

SD_R

AB12

SD_G

AC11

SD_B

AF11

SD_INCM_B

AE11

SD_Y1

AE17

SD_PR1

AC17

SD_PB1

AD17

SD_INCM_COMP1

AF17

SD_Y2

AE18

SD_PR2

AF19

SD_PB2

AD18

SD_INCM_COMP2

AF18

SD_Y3

AE16

SD_PR3

AD16

SD_PB3

AC16

SD_INCM_COMP3

AF16

SD_L1

AF12

SD_C1

AE12

SD_INCM_LC1

AC12

SD_L2

AC13

SD_C2

AD13

SD_INCM_LC2

AF13

SD_L3

AF15

SD_C3

AC14

SD_INCM_LC3

AD14

SD_CVBS1

AB11

SD_CVBS2

AE13

SD_CVBS3

AE14

SD_CVBS4

AD15

SD_INCM_CVBS1

AA11

SD_INCM_CVBS2

AD12

SD_INCM_CVBS3

AF14

SD_INCM_CVBS4

AE15

SD_SIF1

AD19

SD_INCM_SIF1

AE19

PLL_VAFE_AVDD1P2

AB16

PLL_VAFE_AVSS

Y16

PLL_VAFE_TESTOUT

Y15

RGB_HSYNC

AB6

RGB_VSYNC

AC6

I2S_CLK_IN AC20

I2S_CLK_OUT AD20

I2S_DATA_IN AA19

I2S_DATA_OUT AF21

I2S_LR_IN AB20

I2S_LR_OUT AE20

AUD_LEFT0_N AC26

AUD_LEFT0_P AC25

AUD_AVDD2P5_0 AB25

AUD_AVSS_0_1 W19

AUD_AVSS_0_2 W20

AUD_AVSS_0_3 Y22

AUD_AVSS_0_4 AA23

AUD_RIGHT0_N AD25

AUD_RIGHT0_P AD26

AUD_LEFT1_N AF25

AUD_LEFT1_P AE25

AUD_RIGHT1_N AE26

AUD_RIGHT1_P AF26

AUD_AVDD2P5_1 AB24

AUD_AVSS_1_1 AA22

AUD_AVSS_1_2 AB23

AUD_LEFT2_N AD23

AUD_LEFT2_P AC23

AUD_RIGHT2_N AD24

AUD_RIGHT2_P AE24

AUD_AVDD2P5_2 AC24

AUD_AVSS_2_1 Y20

AUD_AVSS_2_2 AA21

AUD_AVSS_2_3 AB22

AUD_AVSS_2_4 AC22

AUD_SPDIF AF5

SPDIF_AVDD2P5 AD5

SPDIF_IN_N AF4

SPDIF_IN_P AE5

SPDIF_AVSS_1 AD6

SPDIF_AVSS_2 AB8

SPDIF_AVSS_3 AA9

HDMI_RX_0_CEC_DAT AE3

HDMI_RX_0_AVSS_4 AF3

HDMI_RX_0_HTPLG_IN AA6

HDMI_RX_0_HTPLG_OUT AA5

HDMI_RX_0_DDC_SCL AB3

HDMI_RX_0_DDC_SDA Y6

HDMI_RX_0_RESREF AC4

HDMI_RX_0_CLK_N AC1

HDMI_RX_0_CLK_P AC2

HDMI_RX_0_DATA0_N AD1

HDMI_RX_0_DATA0_P AD2

HDMI_RX_0_DATA1_N AE1

HDMI_RX_0_DATA1_P AE2

HDMI_RX_0_DATA2_N AF1

HDMI_RX_0_DATA2_P AF2

HDMI_RX_0_VDD3P3 AD3

HDMI_RX_0_VDD1P2 AD4

HDMI_RX_0_VDD2P5 AC3

HDMI_RX_0_AVSS_5 AC5

HDMI_RX_0_AVSS_1 AB5

HDMI_RX_0_AVSS_2 V8

HDMI_RX_0_AVSS_3 W8

HDMI_RX_0_PLL_AVSS W6

HDMI_RX_0_PLL_DVDD1P2 AE4

HDMI_RX_0_PLL_DVSS W7

HDMI_RX_1_CEC_DAT AA3

HDMI_RX_1_AVSS_7 AB4

HDMI_RX_1_HTPLG_IN V4

HDMI_RX_1_HTPLG_OUT U6

HDMI_RX_1_DDC_SCL V5

HDMI_RX_1_DDC_SDA V3

HDMI_RX_1_RESREF W4

HDMI_RX_1_CLK_N W2

HDMI_RX_1_CLK_P W3

HDMI_RX_1_DATA0_N Y1

HDMI_RX_1_DATA0_P Y2

HDMI_RX_1_DATA1_N AA2

HDMI_RX_1_DATA1_P AA1

HDMI_RX_1_DATA2_N AB2

HDMI_RX_1_DATA2_P AB1

HDMI_RX_1_VDD3P3 Y3

HDMI_RX_1_VDD1P2 Y4

HDMI_RX_1_VDD2P5 W5

HDMI_RX_1_AVSS_6 Y5

HDMI_RX_1_AVSS_1 W1

HDMI_RX_1_AVSS_2 U5

HDMI_RX_1_AVSS_3 V6

HDMI_RX_1_AVSS_4 U7

HDMI_RX_1_AVSS_5 U8

HDMI_RX_1_PLL_AVSS V7

HDMI_RX_1_PLL_DVDD1P2 AA4

HDMI_RX_1_PLL_DVSS Y7

SD_V5_AVDD1P2

AB19

SD_V5_AVDD2P5

AC19

SD_V5_AVSS

AA18

SD_INCM_G

AD11

SD_INCM_R

AA12

C922 0.1uF

C934 4.7uF

C923 0.1uF

C962 0.1uF

C925 0.1uF

A2.5V

C910 0.1uF

L905

BLM18PG121SN1D

R957 10K

R932 499

C937 0.01uF

R929

510

C941 4.7uF

C950 1000pF

A2.5V

R1500

C1502 0.47uF

C1510 1uF

+3.5V_ST

C1507 1uF

P1500

12507WR-04L

R1504

20K

R1506

47K

OPT

R1513

10K

HP_DET

C1503 0.47uF

C1504 10uF

R1501

47K

R1502

22K

VOLUME

R1503

R1510 0

C1512

10uF

C1513

0.47uF

Q1500

2SC3052

C R1511

100

R1505

10K

IC1501

TPA6011A4PWPRG4

PVDD_1

ROUT-

RHPIN

PGND_1

RIN

RLINEIN

VDD

LIN

LLINEIN

LHPIN

PVDD_2

LOUT- 13 PGND_2

14 LOUT+

15 SHUTDOWN

16 FADE

17 BYPASS

18 AGND

19 SEMAX

20 SEDIFF

21 VOLUME

22 HP/LINE

23 SE/BTL

24 ROUT+

C1506 1uF

R1507 0

+5V_NORMAL

L1500

BLM18AG151SN1D

AUDIO_SLEEP

C1509 1uF

R928

OPT

C891 0.1uF

R921 12

C527 0.1uF

C5300.1uF

D502

50V

BAP70-02

C5260.1uF

R523 100

C5280.1uF

C506

0.1uF

16V

C519

0.1uF

C5240.1uF

C501

0.1uF

16V

C514 0.1uF

+3.3V_TU

C541 0.1uF

C543

0.1uF

16V

C504

120pF

50V

L504

0603CS-R39XGLW

390nH

C551

18pF

50V

+3.3V_TU

C540 0.1uF

C505

39pF

50V

C517 0.1uF C545

18pF

50V

C550

18pF

50V

C542

0.1uF

16V

OPT

L501

0603CS-R27XGLW

270nH

C523 1000pF 50V

TU_ATTEN

002:H2

C525 0.1uF

XC5000_RESET

R518

2.7K

R526

4.7K

L508

1008CS-821XGLC

C503

2200pF

50V

C539

0.1uF

16V

C502

56pF

50V

R517

C529 0.1uF

+1.8V_TU

+3.3V_TU

C5330.1uF

C531 0.1uF

R512

1/16W

R524 100

C516 0.1uF

C547

18pF

50V

C515 1000pF

50V

R527

4.7K

L513

MLB-201209-0120P-N2

+5V

+1.8V_TU

C562

0.1uF

16V

L515

BLM18PG121SN1D

C569

0.1uF

16V

C568

0.1uF

16V

C561

0.1uF

16V

IC502

AZ1117D-3.3TRE1

ADJ/GND

2OUTPUT

INPUT

+3.3V_TU

X501

31.875MHz

4GND_2

X-TAL_1

GND_1 3X-TAL_2

C1134 0.01uF

C1133 0.01uF

C804

0.1uF

C803

0.1uF

TU_CVBS_IN

C805

10uF

6.3V

C831

0.1uF

Q803

ISA1530AC1

Q804

ISA1530AC1

C832

0.1uF

L802

BG1608B501F

C973

0.1uF

16V

L911

MLB-201209-0120P-N2

JK1501

KJA-PH-0-0177

3DETECT

5GND

R975

10K

JK901

KJA-PH-1-0177

3 M3_DETECT

4 M4

5 M5_GND

1 M1

6 M6

D905

5.5V

+3.3V_NORMAL

D903

5.5V

D901

5.6V

R909

D908

5.5V

C932

27pF

C977

27pF

C913

27pF

C928

27pF

C975

27pF

C976

27pF

L908 CM2012FR27KT

L910 CM2012FR27KT

L909 CM2012FR27KT

C906

100pF

JK902

KJA-PH-1-0177

3 M3_DETECT

4 M4

5 M5_GND

1 M1

6 M6

R911

+3.3V_NORMAL

R903

10K

R914

R913

R1424

2.7K

R908

R1442

2.7K

EDID_WP

R1432

100

C902

100pF

DSUB_DET

D911

30V

R1430

10K

C927

22pFOPT

R1402

R1400

D907

ENKMC2838-T112

C1408

18pF

50V

RGB_DDC_SDA

+5V_NORMAL

D913

30V

C1410

18pF

50V

D915

30V

RGB_DDC_SCL

C930

22pFOPT

C1406

0.1uF

16V

R1428

R1426

R902

10K

D912

5.6V

OPT

D914

5.6V

OPT

R910

470K

R912

470K

C901

100pF

C929

100pF

C914

100pF

D910

5.6V

D904

5.6V

D909

5.6V

D906

5.6V

R1102

R907

R906

R1100

R954

36 C966

47pF

C967

47pF

C968

47pF

C960

47pF

L900

BLM18PG121SN1D

R893 22

R941 22

C520

33pF

50V

R506 0

R505 0

C972

0.1uF

R943

R892

200

TU_CVBS_IN

C965 0.1uF

TU_SIF

001:Z26

R950

10K

R953

12K

R933

240

R891

12K

A2.5V

R952

10K

C964 0.1uF

R927

120

TU_SIF

001:W9

C904 0.1uF

PC_LR_INCM

R168

5.1

R905

R904 12

R992

+3.3V_NORMAL

D916

30V

D917

30V

DSUB_HSYNC

DSUB_VSYNC

R1437 22

R1438 22

R915

R920

R925

SCL0_3.3V

SDA0_3.3V

+5V

+5V_NORMAL

R919 10

R918 0

R917 0

C1505 47uF 6.3V

C1511 47uF 6.3V

C970 0.1uF

JK1502

KCN-BT-0-0089

BCM_RX

BCM_TX

HDMI_SCL

HDMI_SDA

C571

22uF

10V

C574

22uF

10V

C974

22uF

16V

C955

10uF

C954 10uF

C949 10uF

C948 10uF

C560

10uF

6.3V

C947 10uF

C564

10uF

6.3V

C563

10uF

6.3V

C557

10uF

6.3V

C909 1uF

10V

C912 1uF

10V

IC501

XC5000C

VDDA_1

IN1

GND_1

IN2

GND_2

EXTCHOKE

GND_3

VDDA_2

VDDA_3

VDDC_1

GND_4

VDDC_2

VDDC_3

VDDA_4

VAGC

VIF

VDDA_5

SIF

GND_5

VDDC_4

VDDA_6

GND_6

VDDD_1

TESTMODE

25 DDI1

26 VDDC_5

27 DDI2

28 ADDRSEL

29 X2

30 GND_7

31 X1

32 EXTREF

33 VDDD_2

34 SCL

35 SDA

36 GND_8

37 RESET

38 VI2C

39 VDDC_6

40 VREF_N

41 VREF_P

42 VDDC_7

43 VDDC_8

44 REXT

45 VDDA_7

46 GND_9

47 VDDC_9

48 VDDA_8

D500

RCLAMP0502B

L503

0603CS-12NXGLW

12nH

C581

6.8pF

50V

C582

6.8pF

50V

R501

820

1/16W

R502

1/16W

C971

0.01uF

R510 4.99K 1%

R528

680

R529

680

IC1502

CS4344-CZZR

LRCK

DEM/SCLK

MCLK

SDIN

VQ 6FILT+

7AOUTL

8GND

9VA

10 AOUTR

I2S_AUD_FS1_CLK

C1514

10uF

6.3V

C1517

10uF

6.3V

C1501

0.1uF

16V

C1518

4.7uF

C1519

4.7uF

R1509

10K R1508

10K

R1516

470

R1517

470

C1521

1500pF

50V

C1520

1500pF

50V

+5V_NORMAL

L1501

BLM18AG151SN1D

C1516

1uF

6.3V

C1515

0.1uF

16V

R8216 0

R8217 0

R8218

R82190

JK1401

SPG08-HU-002

14 NC

13 CEC

5DATA1_SHIELD

12 CLK-

CLK_SHIELD

2DATA2_SHIELD

19 HPD

18 +5V_POWER

CLK+

4DATA1+

1DATA2+

17 DDC/CEC_GND

9DATA0-

8DATA0_SHIELD

3DATA2-

16 SDA

7DATA0+

6DATA1-

15 SCL

JACK_GND

U1 U1

U2 U2

U3 U3

U4 U4

R1403 1K

R964 1K

R1414

51K

+5V_NORMAL

IC1500

74LVC1G126

GND

OE 5VCC

DSUB_VSYNC

IC1405

NL17SZ08DFT2G

1 5

DSUB_HSYNC

+3.3V_NORMAL

IC1404

NL17SZ08DFT2G

1 5

P901

KCN-DS-3-0062

10 10

11 11

12 12

13 13

14 14

15 15

1616

IC503

AZ1117BH-1.8TRE1

ADJ/GND

2OUT

SE/BTL

IC1503

NLASB3157DFT2G

GND

B1 6SELECT

5VCC

Audio_5V

C1522 1uF

SE/BTL

R1514

R1515

+5V_NORMAL

R1518

13K

R1519

20K

C507

10uF

6.3V

C508

10uF

6.3V

C1508 0.47uF

C1523 10uF

C1524

10uF

C567

22uF

10V

C570

22uF

10V

C566

22uF

10V

C565

22uF

10V

MDS62110211

MDS62110212

OPT

4814V00112J

OPT

R1434

R1435

R1436

D902

5.6V

R1412

2.7K

R1413

2.7K

R988 22

R999 22

R993 1K

+5V_NORMAL HDMI_DET

D1403

5.5V

D1404

5.5V

IC1403

R1EX24002ASAS0A

EAN60997601

VSS

5SDA

6SCL

7WP

8VCC

IC1402

R1EX24002ASAS0A

EAN60997601

VSS

5SDA

6SCL

7WP

8VCC

R815

390

R816

390

R101 5.6

R102 5.6

R108 5.6

R107 5.6

R106 5.6

R105 5.6

R104 5.6

R103 5.6

R14040

R14050

R1512

4814V00112J

MGJ63021801

C1525

0.1uF

OPT_EMS

C1526

0.1uF OPT_EMS

S1 S0 PATH

----------------------

0 0 S6

0 1 DPP DEBUG

1 0 DPP UART(CCA)

DDP2230 USB FOR DBG

DDP2230 UART FOR CCA

BCM USB

HDMI INPUT

ATSC Tuner

USB SWITCH

USB BLOCK

When High,

USB 5V out

When Low,

current limit

1 1 BCM UART

BCM3549 VIDEO

Headphone OUT

Speaker

AUDIO AMP

Place close to BCM

NEED TO VERY CLOSE TO RF LINE

0xC8

BECAUSE THIS POINT MAKE ATTENUATOR

845 OHM 1%

TUNER2 I2C Address : 0xC8

DO NOT CHANGE ORDER

Isolation & Impedance 75ohm

Capacitors on VBUSA should be

placed as close to Connector as possible.

RGB IN

BCM Reference

Close to BCM(for EMI)

Comp IN

A/V IN

Tuner Power

Only for training and service purposes

LGE Internal Use Only

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES

SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.

FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS

ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR

THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

09/10/xx

BCM-BOOT/FLASH/GPIO

9 100

GP2_BCM_ATSC

NAND_IO[7]

NAND_IO[6]

NAND_IO[5]

NAND_IO[4]

NAND_IO[3]

NAND_IO[2]

NAND_IO[1]

NAND_IO[0]

NAND_IO[0-7]

NAND_IO[0]

NAND_IO[1]

NAND_IO[3]

NAND_IO[2]

NAND_IO[5]

NAND_IO[4]

NAND_IO[7]

NAND_IO[6]

NAND_RBb

NAND_CEb

NAND_REb

NAND_WEb

NAND_IO[4]

NAND_IO[6]

NAND_IO[5]

NAND_IO[7]

NAND_IO[0]

NEC_EEPROM_SCL

OCD1B

NEC_EEPROM_SDA

LED_CNT01

54MHz_XTAL_P

JTAG_RESETb

54MHz_XTAL_N

RESET_OUTB

KEY_IN0

KEY_IN1

LED_CNT02

NAND_ALE

NAND_CLE

NAND_IO[3]

NAND_IO[2]

NAND_IO[1]

SOC_RESET

BCM_RX

BCM_TX

BCM3549_JTAG_TDI

BCM3549_JTAG_TMS

BCM3549_JTAG_TCK

BCM3549_JTAG_TRSTb

BCM3549_JTAG_TDO

OCD1A

SIGN21474836471

R924 1K

R995

10K

HDMI_HPD_1

D3.3V

C963

4700pF

R973 22

R974 22

R994

2.7K

SCL3_3.3V

SCL1_3.3V

R997 1K

SDA1_3.3V

FLASH_WP

002:L7

R996 1K

R634 2.7K

D3.3V R628 2.7K

SDA3_3.3V

RGB_DDC_SDA

R603 2.7K

R970 22

DSUB_DET

RGB_DDC_SCL

R630 2.7K

R635 2.7K

D3.3V

Q901

KRC103S

R1041 0

D3.3V

R602 2.7K

C959

0.1uF

R636 2.7K

D3.3V

R1042 2.7K

R998 1K

D3.3V

R633 2.7K

R608 2.7K

C958

0.1uF

R606 2.7K

REAR_AV_DET

R951 0

OPT

R939

3.3K

R940

3.3K

R958 0

R959 0

R966 0

R967 0

R9420

R955 22

R986 22

R985 22

IC900

LGE3549XS (LGE3549XS P22 , B2 version)

DEV

EAN60345904

GPIO_00

G24

GPIO_01

E24

GPIO_02

G22

GPIO_03

E23

GPIO_04

D26

GPIO_05

D25

GPIO_06

D23

GPIO_07

D24

GPIO_08

C26

GPIO_09

R25

GPIO_10

R26

GPIO_11

R24

GPIO_12

GPIO_13

GPIO_14

GPIO_15

P23

GPIO_16

P24

GPIO_17

F25

GPIO_18

R23

GPIO_19

H23

GPIO_20

G26

GPIO_21

G25

GPIO_22

AF20

GPIO_23

J21

GPIO_24

E22

GPIO_25

AB21

GPIO_26

AC21

GPIO_27

GPIO_28

GPIO_29

E21

GPIO_30

P26

GPIO_31

P25

GPIO_32

GPIO_33

GPIO_34

GPIO_35

GPIO_36

GPIO_37

F21

GPIO_38

H21

GPIO_39

GPIO_40

GPIO_41

GPIO_42

E25

GPIO_43

F24

GPIO_44

G21

GPIO_45

H25

GPIO_46

H24

GPIO_47

K22

GPIO_48

K21

GPIO_49

J23

GPIO_50

GPIO_51

GPIO_52

J22

GPIO_53

GPIO_54

GPIO_55

GPIO_56

GPIO_57

SGPIO_00

N25

SGPIO_01

N26

SGPIO_02

N24

SGPIO_03

N23

SGPIO_04

SGPIO_05

SGPIO_06

SGPIO_07

NAND_DATA0 H26

NAND_DATA1 J24

NAND_DATA2 J25

NAND_DATA3 J26

NAND_DATA4 K24

NAND_DATA5 K25

NAND_DATA6 L24

NAND_DATA7 L25

NAND_CS0B L23

NAND_ALE L21

NAND_REB M21

NAND_CLE L22

NAND_WEB K23

NAND_RBB M22

SF_MISO N22

SF_MOSI M24

SF_SCK M25

SF_CSB M26

+3.3V_NORMAL

R654

SCL3_3.3V

R655

OPT SDA3_3.3V

IC601

M24M01-HRMN6TP

EAN60771501

DEV

VSS

5SDA

6SCL

7WP

8VCC

C601

0.1uF

R653

OPT

R656

4.7K

IC901-*1

NAND08GW3B2CN6E

MAIN_FLASH_8G_NUMONYX

DEV

EAN60694001

26 NC_17

27 NC_18

28 NC_19

29 I/O0

30 I/O1

31 I/O2

32 I/O3

33 NC_20

34 NC_21

35 NC_22

36 VSS_2

37 VDD_2

38 NC_23

39 NC_24

40 NC_25

41 I/O4

42 I/O5

43 I/O6

44 I/O7

45 NC_26

46 NC_27

47 NC_28

48 NC_29

NC_3

NC_6

NC_10

NC_9

VSS_1

VDD_1

NC_8

NC_7

NC_4

NC_5

25 NC_16

NC_15

NC_14

NC_2

NC_13

NC_12

NC_1

NC_11

IC901-*2

TC58NVG2S3ETA00

MAIN_FLASH_4G_TOSHIBA

DEV

EAN60997701

26 NC_17

27 NC_18

28 NC_19

29 I/O1

30 I/O2

31 I/O3

32 I/O4

33 NC_20

34 NC_21

35 NC_22

36 VSS_2

37 VCC_2

38 NC_23

39 NC_24

40 NC_25

41 I/O5

42 I/O6

43 I/O7

44 I/O8

45 NC_26

46 NC_27

47 NC_28

48 NC_29

ALE

NC_3

NC_6

CLE

NC_10

NC_9

VSS_1

VCC_1

NC_8

NC_7

RY/BY

NC_4

NC_5

25 NC_16

NC_15

NC_14

NC_2

NC_13

NC_12

NC_1

NC_11

HP_DET R1058 0

R900 2.7K

R946 56

IC901-*3

K9F8G08U0M-PCB0

DEV

MAIN_FLASH_8G_SAMSUNG

26 NC_17

27 NC_18

28 NC_19

29 I/O0

30 I/O1

31 I/O2

32 I/O3

33 NC_20

34 NC_21

35 NC_22

36 VSS_2

37 VCC_2

38 NC_23

39 NC_24

40 NC_25

41 I/O4

42 I/O5

43 I/O6

44 I/O7

45 NC_26

46 NC_27

47 NC_28

48 NC_29

ALE

NC_3

NC_6

CLE

NC_10

NC_9

VSS_1

VCC_1

NC_8

NC_7

R/B

NC_4

NC_5

25 NC_16

NC_15

NC_14

NC_2

NC_13

NC_12

NC_1

NC_11

R984 22

DPP_TX

DPP_RX

VOLUME

R1043 0 OPT

USB_S0

USB_S1

R1059 22

BCM_INT

DDP_ASIC_READY R1060 0

R1061 0

R657

R658

R901 0

OPT

DOWN_ENZ

3.3V

C969

0.1uF

16V

R978

PWRGOOD

R977

EPHY_LINK

EPHY_ACTIVITY

COMP_DET

C8104 0.1uF

GND

R8197 22

R8189 10K

POWER_ON/OFF1

R8126

10K

OPT

R8129 22

R8178 22

C8107

1uF

R8193 22

SDA1_3.3V

R8194 22

POWER_DET

POWER_ON/OFF2_1

R8136

R8177

R8175

4.7M

MICOM_RESET

R8130 22

R8143 10K

R8190 22

SOC_RESET

R8135

R8127 22

EDID_WP

R8179

C8106

15pF

R8195 22

+3.5V_ST

B_NTC

R8186 20K

1/16W

R8187 22

+3.5V_ST

R8140 47K

OPT

+3.5V_ST

R8142 22

AUDIO_SLEEP

RL_ON

SCL1_3.3V

IC8101

UPD78F0513AGA-GAM-AX

S/W ASSY

P60/SCL0

P61/SDA0

P62/EXSCL0

P63

P33/TI51/TO51/INTP4

P75

P74

P73/KR3

P72/KR2

P71/KR1

P70/KR0

P32/INTP3/OCD1B

P31/INTP2/OCD1A

P30/INTP1

P17/TI50/TO50

P16/TOH1/INTP5

P15/TOH0

P14/RXD6

P13/TXD6

P12/SO10

P11/SL10/RXD0

P10/SCK10/TXD0

AVREF

AVSS

25 ANI7/P27

26 ANI6/P26

27 ANI5/P25

28 ANI4/P24

29 ANI3/P23

30 ANI2/P22

31 ANI1/P21

32 P20/ANI0

33 P130

34 P01/TI010/TO00

35 P00/TI000

36 P140/PCL/INTP6

37 P120/INTP0/EXLVI

38 P41

39 P40

40 RESET

41 P124/XT2/EXCLKS

42 P123/XT1

43 FLMD0

44 P122/X2/EXCLK/OCD0B

45 P121/X1/OCD0A

46 REGC

47 VSS

48 VDD

R8199

10K

R8196 22

R8145

R8131 22

Q8100

2SC3052

R8200

10K

FLASH_WP

R8185

20K

1/16W

X8101

32.768KHz

R8184

47K

C8105

15pF

C8103

0.1uF

R8191 22

R8128 22

C8108

0.1uF

R8198 22

R8144

R8133 22

+3.5V_ST

R8125 4.7K

BBS_SCL

R8103 10K

USB_DAT_P

MICOM_RESET

UART0_RXD

USB_DAT_N

FLMD0

R8117

UART0_TXD

IC18100

M24C16-WMN6T

NC/E2

NC/E1

VSS

NC/E0

5SDA

6SCL

7WC

8VCC

C8109

4.7uF

+3.5V_ST

R8122 4.7K

BBS_SDA

R8205

1.5K

R8105

1.5K

R8100

47K

R8114

C8100

0.1uF

C1415

0.1uF

C1414

0.1uF

R143947

L1400

BLM18PG121SN1D

R144047

C1412

0.1uF

16V

C1413

0.1uF

16V

P1403

0500HR-10N2(G)

ST_5V

R961 0

XC5000_RESET

001:Z35

R962 100

TU_ATTEN

001:J37

SCL0_3.3V

SDA0_3.3V

D3.3V

EPHY_RDP

D3.3V

L1009

2.7uH

A2.5V

USB_DP1

001:AU34

USB_PWRFLT1

001:AW6

C1031 0.1uF

R1047

604

L1000

BLM18PG121SN1D

C1041

0.1uF

A2.5V

R1011

240

C1034 4.7uF

A2.5V

C1040

0.1uF

EPHY_TDN

A2.5V

BBS_SCL

LVDS_TX_0_DATA1_P

R1051

10K

D3.3V

A1.2V

A2.5V

LVDS_TX_0_DATA2_P

LVDS_TX_0_DATA3_P

C1030 4.7uF

LVDS_TX_0_DATA0_P

D3.3V

C1006

100pF

50V

LVDS_TX_0_DATA0_N

R1014

A1.2V

R1026

2.7K

C1011 0.1uF

USB_DM1

001:AU35

D3.3V

X1001

54MHz

6212AA2600E

EPHY_TDP

LVDS_TX_0_CLK_P

LVDS_TX_0_DATA2_N

LVDS_TX_0_DATA1_N

AUDIO_RIN

LVDS_TX_0_DATA3_N

C1033 0.1uF

R10212.7K

C1027 4.7uF

C1025 0.1uF

R1010

120

C1005 0.1uF

C1003 100pF

R160 49.9

LVDS_TX_0_DATA4_P

EPHY_RDN

IC900

LGE3549XS (LGE3549XS P22 , B2 version)

DEV

EAN60345904

PKT0_CLK

C25

PKT0_DATA

C24

PKT0_SYNC

B26

RMX0_CLK

A25

RMX0_DATA

A26

RMX0_SYNC

B25

VDAC_AVDD2P5

AA20

VDAC_AVDD1P2

AD22

VDAC_AVDD3P3_1

AE22

VDAC_AVDD3P3_2

AE23

VDAC_AVSS_1

W16

VDAC_AVSS_2

Y17

VDAC_AVSS_3

Y18

VDAC_AVSS_4

Y19

VDAC_RBIAS

AF24

VDAC_1

AF22

VDAC_2

AE21

VDAC_AVSS_5

AD21

VDAC_VREG

AF23

BSC_S_SCL

F23

BSC_S_SDA

F22

USB_AVSS_1

USB_AVSS_2

USB_AVDD1P2

USB_AVDD1P2PLL

USB_AVDD2P5

USB_AVDD2P5REF

USB_AVDD3P3

USB_RREF

USB_DM1

USB_DP1

USB_DM2

USB_DP2

USB_MONCDR

USB_MONPLL

USB_PWRFLT_1

USB_PWRFLT_2

USB_PWRON_1

USB_PWRON_2

EPHY_VREF

EPHY_RDAC

EPHY_RDN

EPHY_RDP

EPHY_TDN

EPHY_TDP

EPHY_AVDD1P2

EPHY_AVDD2P5

EPHY_PLL_VDD1P2

EPHY_AGND_1

EPHY_AGND_2

EPHY_AGND_3

AUDMX_LEFT1

AC8

AUDMX_RIGHT1

AB9

AUDMX_INCM1

AD8

AUDMX_LEFT2

AF6

AUDMX_RIGHT2

AE7

AUDMX_INCM2

AE6

AUDMX_LEFT3

AE8

AUDMX_RIGHT3

AD9

AUDMX_INCM3

AC9

AUDMX_LEFT4

AF7

AUDMX_RIGHT4

AE9

AUDMX_INCM4

AF8

AUDMX_LEFT5

AB10

AUDMX_RIGHT5

AD10

AUDMX_INCM5

AC10

AUDMX_LEFT6

AF9

AUDMX_RIGHT6

AF10

AUDMX_INCM6

AE10

AUDMX_AVSS_1

AD7

AUDMX_AVSS_2

Y10

AUDMX_LDO_CAP

AA10

AUDMX_AVDD2P5

AC7

LVDS_TX_0_DATA0_P B4

LVDS_TX_0_DATA0_N A4

LVDS_TX_0_DATA1_P C6

LVDS_TX_0_DATA1_N B6

LVDS_TX_0_DATA2_P B3

LVDS_TX_0_DATA2_N A3

LVDS_TX_0_DATA3_P A1

LVDS_TX_0_DATA3_N A2

LVDS_TX_0_DATA4_P D5

LVDS_TX_0_DATA4_N D6

LVDS_TX_0_CLK_P C5

LVDS_TX_0_CLK_N B5

LVDS_TX_1_DATA0_P B1

LVDS_TX_1_DATA0_N B2

LVDS_TX_1_DATA1_P C2

LVDS_TX_1_DATA1_N C3

LVDS_TX_1_DATA2_P D1

LVDS_TX_1_DATA2_N D2

LVDS_TX_1_DATA3_P E1

LVDS_TX_1_DATA3_N E2

LVDS_TX_1_DATA4_P E3

LVDS_TX_1_DATA4_N E4

LVDS_TX_1_CLK_P D3

LVDS_TX_1_CLK_N D4

LVDS_PLL_VREG F5

LVDS_TX_AVDDC1P2 F1

LVDS_TX_AVDD2P5_1 F4

LVDS_TX_AVDD2P5_2 F2

LVDS_TX_AVSS_1 C1

LVDS_TX_AVSS_2 F3

LVDS_TX_AVSS_3 C4

LVDS_TX_AVSS_4 A5

LVDS_TX_AVSS_5 E5

LVDS_TX_AVSS_6 E6

LVDS_TX_AVSS_7 D7

LVDS_TX_AVSS_8 E7

LVDS_TX_AVSS_9 F7

LVDS_TX_AVSS_10 G7

LVDS_TX_AVSS_11 H7

LVDS_TX_AVSS_12 G8

LVDS_TX_AVSS_13 G10

CLK54_AVDD1P2 U22

CLK54_AVDD2P5 U23

CLK54_AVSS_1 T20

CLK54_AVSS_2 T23

CLK54_AVSS_3 U24

CLK54_XTAL_N U25

CLK54_XTAL_P U26

CLK54_MONITOR T21

PM_OVERRIDE P21

VCXO_AVDD1P2 Y25

VCXO_PLL_AUDIO_TESTOUT W23

VCXO_AGND U21

RESET_OUTB H22

RESETB F6

NMIB G23

TMODE_0 J5

TMODE_1 J4

TMODE_2 J6

TMODE_3 J3

SPI_S_MISO M23

POR_OTP_VDD2P5 AB7

EJTAG_TCK H4

EJTAG_TDI H3

EJTAG_TDO H2

EJTAG_TMS H1

EJTAG_TRSTB G1

EJTAG_CE0 H6

EJTAG_CE1 H5

PLL_MAIN_AVDD1P2 T22

PLL_MAIN_AGND T25

PLL_MAIN_MIPS_EREF_TESTOUT T24

PLL_RAP_AVD_TESTOUT M6

PLL_RAP_AVD_AVDD1P2 N6

PLL_RAP_AVD_AGND N7

PLL_DS_AGND_1 V22

PLL_DS_AGND_2 V23

BYP_CPU_CLK R22

BYP_DS_CLK P22

BYP_SYS216_CLK V25

BYP_SYS175_CLK V26

POR_VDD1P2 Y8

L1003

BLM18PG121SN1D

R1025

OPT

C1007

100pF

50V

A1.2V

LVDS_TX_0_CLK_N

D3.3V

C1012 0.1uF

A1.2V

C1029 0.1uF

R10222.7K

R1007 22

R1020 1K

R1046 22

A1.2V

C1036

0.1uF

C1049

0.1uF

C1004 0.1uF

C1047

0.1uF

R1052 0

L1002

BLM18PG121SN1D

BBS_SDA

C1014 0.1uF

A1.2V

R1050

910

C1032

0.1uF

PC_LR_INCM

R1024 2.7K

OPT

C1050

0.1uF

C1043

0.1uF

R163 49.9

R1027 0

OPT

L1006

BLM18PG121SN1D

AUDIO_LIN

R1023 4.7K

C1020

0.01uF

C1024

0.1uF C1008

33pF

A2.5V

R1009

3.9K

R1049

330

C1042 0.1uF

L1005

BLM18PG121SN1D

USB_PWRON1

001:AQ6

LVDS_TX_0_DATA4_N

A1.2V

C1028

0.1uF

R1008 22

D3.3V

R1045 22

L1004

BLM18PG121SN1D

C1023

0.1uF

C1039

0.1uF

L1001

BLM18PG121SN1D

A2.5V

+3.5V_ST

R1030 1K

EPHY_TDN

D3.3V

EPHY_TDP

R1032 1K

EPHY_LINK

R1028 1K

OPT

R1029

EPHY_RDP

EPHY_RDN

EPHY_ACTIVITY

R1031 1K

SOC_RESET

HDMI_DET

C163 0.015uF

C158 0.015uF

C173 0.047uF

C174 0.047uF

R1019 560

C1009

22uF

10V

OPT

R1048

R1054

OPT

HDMI_SDA

HDMI_SCL R8204 22

R8203 22

BCM_RX

BCM_TX

C1026

10uF

C1010

10uF

6.3V

C1035

10uF OPT

C1038 10uF

IC901

NAND04GW3B2DN6E

MAIN_FLASH_4G_NUMONYX

EAN61009301

DEV

26 NC_17

27 NC_18

28 NC_19

29 I/O0

30 I/O1

31 I/O2

32 I/O3

33 NC_20

34 NC_21

35 NC_22

36 VSS_2

37 VDD_2

38 NC_23

39 NC_24

40 NC_25

41 I/O4

42 I/O5

43 I/O6

44 I/O7

45 NC_26

46 NC_27

47 NC_28

48 NC_29

NC_3

NC_6

NC_10

NC_9

VSS_1

VDD_1

NC_8

NC_7

NC_4

NC_5

25 NC_16

NC_15

NC_14

NC_2

NC_13

NC_12

NC_1

NC_11

R8101

10K

R8102

10K

P8102

05004HR-20B01S

R1033 0

BCM_RX

BCM_TX

+3.3V_NORMAL P8100

0500HR-10N2(G)

FLMD0

C8110

0.01uF

R8206

3.9K

R8210 75

R8211 75

I2S_AUD_FS1_CLK

IC903

74LVC1G126

3GND

1OE

VCC

C1013 4.7uF

C1037

4.7uF

C1044

4.7uF

C1045

4.7uF C1046

4.7uF

C1048

4.7uF

IC1000

AZ7029RTRE1

EAN38061701

GND

OUT 1VCC

C1017

4.7uF

P8101

0500HR-06N2(G)

ST_5V

C8111

10uF

10V

SE/BTL

R937

2.7K

R938

2.7K

R944

2.7K

R945

2.7K

R947

2.7K

R949

2.7K

C1001 22pF

C1000 22pF

C179 0.33uF

C164 0.22uF

Open Drain

* I2C_0: Tuner

* I2C_1: MICOM(52)

* I2C_2: FMT

* I2C_3: NVRAM(A8)/DPP6401 /

I2C MAP

Default Res. of all NAND pin is Pull-down

NAND_IO[0] : Flash Select (1)

0 : Boot From Serial Flash

1 : Boot From NAND Flash

NAND_IO[1] : NAND Block 0 Write (DNS)

0 : Enable Block 0 Write

1 : Disable Block 0 Write

NAND_IO[3:2] : NAND ECC (1, DNS)

00 : No ECC

01 : 1 ECC Bit

10 : 4 ECC Bit

11 : 8 ECC Bit

NAND_IO[4] : CPU Endian (0)

0 : Little Endian

1 : Big Endian

NAND_IO[6:5] : Xtal Bias Control (1, DNS)

00 : 1.2mA (Fundmental Recommand)

01 : 1.8mA

10 : 2.4mA (3rd over tune Recommand)

11 : 3.0mA

NAND_IO[7] : MIPS Frequency (DNS)

0 : 405MHz

1 : 378MHz

NAND_ALE : I2C Level (DNS)

0 : 3.3V Switching

1 : 5V Switching

NAND_CLE

0 : Enable D2CDIFF AC (DNS)

1 : Disabe D2CDIFF AC

BCM3549 Boot Strap

NAND FLASH MEMORY

BCM3549 GPIO

A8’h

NVRAM

8G 4G

DEBUG BCM

DPP6400 Reset

10Mhz Crystal



EEPROM for Micom

Key Control

AUDIO INCM

Route INCM between associated

left and right signals of same channel

The INCM trace ends at the

same point where the connector

ground connects to the board ground

(thru-hole connector pin).

PLACE BOTTOM

RESET_OUTB

USB1 is inserted

3rd Ovretone Crystal

ALL RESET READY

Place close to BCM

BCM3549 LVDS/AUDIO

BCM AUDIO

BCM LVDS

RESET

#CAUTION

Location numer is mixed

100 & 1000

#CAUTION

Location numer is mixed

600 & 900 & 1000

EJTAG

To IR B/D

Only for training and service purposes

LGE Internal Use Only

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES

SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.

FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS

ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR

THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

2010.09.01

BCM-DDR 3 5

HW300-JE

DDR0_DQ[0]

DDR0_DQ[1]

DDR0_DQ[2]

DDR0_DQ[3]

DDR0_DQ[4]

DDR0_DQ[6]

DDR0_DQ[5]

DDR0_DQ[7]

DDR0_DQ[8]

DDR0_DQ[10]

DDR0_DQ[9]

DDR0_DQ[11]

DDR0_DQ[12]

DDR0_DQ[14]

DDR0_DQ[13]

DDR0_DQ[15]

DDR1_DQ[0]

DDR1_DQ[1]

DDR1_DQ[3]

DDR1_DQ[2]

DDR1_DQ[6]

DDR1_DQ[7]

DDR1_DQ[5]

DDR1_DQ[4]

DDR1_DQ[10]

DDR1_DQ[11]

DDR1_DQ[9]

DDR1_DQ[8]

DDR1_DQ[14]

DDR1_DQ[15]

DDR1_DQ[13]

DDR1_DQ[12]

DDR0_DQ[0]

DDR0_DQ[1]

DDR0_DQ[3]

DDR0_DQ[2]

DDR0_DQ[5]

DDR0_DQ[4]

DDR0_DQ[7]

DDR0_DQ[6]

DDR1_DQ[1]

DDR1_DQ[0]

DDR1_DQ[3]

DDR1_DQ[5]

DDR1_DQ[2]

DDR1_DQ[4]

DDR1_DQ[7]

DDR1_DQ[6]

DDR0_DQ[8]

DDR0_DQ[9]

DDR0_DQ[13]

DDR0_DQ[12]

DDR0_DQ[11]

DDR0_DQ[15]

DDR0_DQ[14]

DDR0_DQ[10]

DDR1_DQ[8]

DDR1_DQ[9]

DDR1_DQ[13]

DDR1_DQ[12]

DDR1_DQ[14]

DDR1_DQ[15]

DDR1_DQ[11]

DDR1_DQ[10]

DDR01_A[13]

DDR01_A[12]

DDR01_A[11]

DDR01_A[10]

DDR01_A[9]

DDR01_A[8]

DDR01_A[7]

DDR01_A[3]

DDR01_A[2]

DDR01_A[1]

DDR01_A[0]

DDR0_A[6]

DDR0_A[5]

DDR0_A[4]

DDR1_A[6]

DDR1_A[5]

DDR1_A[4]

DDR01_A[3]

DDR01_A[2]

DDR01_A[1]

DDR01_A[0]

DDR01_A[13]

DDR01_A[12]

DDR01_A[11]

DDR01_A[9]

DDR01_A[10]

DDR01_A[7]

DDR01_A[8]

DDR01_A[7]

DDR01_A[1]

DDR1_A[4]

DDR01_A[9]

DDR01_A[0]

DDR01_A[11]

DDR01_A[3]

DDR01_A[8]

DDR01_A[12]

DDR01_A[10]

DDR1_A[6]

DDR1_A[5]

DDR01_A[2]

DDR01_A[13]

DDR01_A[7]

DDR01_A[1]

DDR0_A[4]

DDR01_A[9]

DDR01_A[0]

DDR01_A[11]

DDR01_A[3]

DDR01_A[8]

DDR01_A[12]

DDR01_A[10]

DDR0_A[6]

DDR0_A[5]

DDR01_A[2]

DDR01_A[13]

DDR01_A[7]

DDR01_A[1]

DDR1_A[4]

DDR01_A[9]

DDR01_A[0]

DDR01_A[11]

DDR01_A[3]

DDR01_A[8]

DDR01_A[12]

DDR01_A[10]

DDR1_A[6]

DDR1_A[5]

DDR01_A[2]

DDR01_A[13]

DDR0_A[6]

DDR0_A[5]

DDR0_A[4]

DDR01_A[0]

DDR01_A[2]

DDR1_A[6]

DDR1_A[5]

DDR1_A[4]

DDR01_A[12]

DDR01_A[9]

DDR01_A[7]

DDR01_A[11]

DDR01_A[8]

DDR01_A[13]

DDR01_A[10]

DDR01_A[1]

DDR01_A[3]

DDR01_A[10]

DDR0_A[6]

DDR01_A[11]

DDR01_A[12]

DDR01_A[2]

DDR01_A[0]

DDR0_A[5]

DDR0_A[4]

DDR01_A[3]

DDR01_A[1]

DDR01_A[9]

DDR01_A[7]

DDR01_A[8]

DDR01_A[13]

DDR01_A[0-3]

DDR01_RASb

C647

0.1uF

C642

0.047uF

DDR1_CLKb

DDR01_CKE

DDR1_DQS0

R617

100

C666

0.1uF

DDR01_BA1

DDR01_A[7-13]

C660

0.047uF

C682

0.047uF

C662

0.1uF

R621 75

DDR0_CLK

DDR01_BA0

DDR0_CLKb

DDR01_ODT

C679

470pF

DDR01_CASb

DDR01_BA0

DDR01_A[7-13]

DDR1_CLKb

C653 1uF

C641

0.1uF

DDR01_A[0-3]

R625 75

D1.8V

DDR01_WEb

AR614

DDR01_RASb

R616 0

OPT

DDR0_DQS1b

DDR1_DM0

DDR1_VREF0

R620 75

AR607

DDR01_ODT

DDR0_DQS1b

DDR1_DQS1b

C6570.1uF

DDR1_CLK

C670

0.1uF

C622

0.1uF

DDR01_WEb

C690

0.1uF

DDR01_RASb

DDR01_BA0

DDR1_CLK

DDR1_DM1

C669

0.047uF

C633

0.047uF

DDR01_CASb

C673

470pF

DDR0_CLK

DDR1_A[4-6]

C652 470pF

DDR01_BA1

C659

0.1uF

DDR01_WEb

DDR0_A[4-6]

DDR0_DQS1

D1.8V

DDR01_BA2

DDR01_BA0

R614

240

DDR0_DQ[0-15]

C677

0.1uF

L603

120

CIS21J121

DDR1_DM1

DDR0_A[4-6]

D1.8V

C634

0.1uF

DDR0_DQS0b

DDR01_BA2

DDR1_DQ[0-15]

DDR01_A[0-3]

DDR0_VREF0

DDR01_A[0-3]

DDR0_A[4-6]

D1.8V

AR610

DDR0_CLK

DDR1_VREF0

DDR01_A[7-13]

DDR01_ODT

C639

0.1uF

C654 470pF

C696

0.1uF

C643

470pF

R619

100

DDR0_CLKb

AR606

C629

0.047uF

DDR1_A[4-6]

DDR01_RASb

C691

0.1uF

DDR01_CKE

C630

0.1uF

C624

0.1uF

R611 75

DDR01_ODT

DDR1_DQS0b

DDR0_CLKb

D1.8V

DDR0_VREF0

AR613

DDR0_VREF0

C692

0.1uF

DDR0_DQS0

C620

470pF

DDR01_BA0

DDR01_WEb

DDR0_DQS0

DDR01_BA2

C627

0.1uF

A1.2V

IC602

BD35331F-E2

EAN52430901

VTTS

VREF

GND

5VDDQ

6VCC

7VTT_IN

8VTT DDR01_BA1

C621

0.1uF

DDR01_A[0-3]

DDR1_CLKb

C658 0.1uF

DDR01_BA0

AR611

DDR0_DM0

C693

0.1uF

D1.8V

DDR0_DM1

DDR1_DQS1

R615

DDR01_BA2

DDR01_A[7-13]

C6560.1uF

DDR01_CASb

C649 1uF

AR608

C661

470pF

C697

470pF

DDR1_DQS1b

DDR01_CKE

DDR1_A[4-6]

AR612

C694

0.1uF

C681

0.1uF

DDR01_RASb

DDR01_WEb

C650 470pF

C678

0.047uF

DDR01_WEb

C665

0.047uF

R613

220

DDR01_RASb

DDR01_A[0-3]

C689

0.1uF

DDR1_DQ[0-15]

DDR01_BA2

C655 1uF

DDR01_CASb

C628

0.1uF

C626

0.1uF

DDR01_CKE

DDR0_DQS0b

DDR01_BA1

DDR01_ODT

DDR01_BA1

DDR1_VREF0

C663

470pF

DDR01_A[7-13]

C648 470pF

DDR01_RASb

DDR01_A[7-13]

DDR1_CLK

D1.8V

DDR_VTT

DDR01_BA1

D1.8V

DDR01_CKE

DDR01_ODT

DDR01_A[7-13]

C619

0.1uF

DDR0_DQS1

DDR0_DM0

AR615

DDR01_A[0-3]

C632

470pF

DDR01_ODT

DDR01_CASb

DDR1_DQS1

C640

470pF

DDR0_DM1

DDR1_DQS0

C664

470pF

DDR0_DQ[0-15]

DDR1_A[4-6]

C668

470pF

DDR1_DQS0b

DDR01_BA0 AR609

C695

470pF

DDR01_BA2

DDR1_DM0

DDR01_WEb

003:D2;003:D4;003:D6;003:F2;003:F4;003:F6

DDR01_BA2

DDR0_A[4-6]

C674

0.1uF

DDR01_CASb

DDR1_VREF0

DDR0_VREF0

DDR_VTT

POWER_ON/OFF1

R612 10K

IC900

LGE3549XS (LGE3549XS P22 , B2 version)

EAN60345904

DEV

DDR_BVDD0 A6

DDR_BVDD1 A24

DDR_BVSS0 B7

DDR_BVSS1 B24

DDR_PLL_TEST F20

DDR_PLL_LDO B23

DDR01_CKE B17

DDR_COMP C22

DDR01_ODT E16

DDR_EXT_CLK C23

DDR0_CLK B12

DDR0_CLKB C12

DDR1_CLK A13

DDR1_CLKB A12

DDR01_A00 B15

DDR01_A01 E14

DDR01_A02 A15

DDR01_A03 D15

DDR0_A04 E13

DDR0_A05 E12

DDR0_A06 F13

DDR01_A07 C14

DDR01_A08 F14

DDR01_A09 B14

DDR01_A10 D14

DDR01_A11 C13

DDR01_A12 D13

DDR01_A13 B13

DDR1_A04 F15

DDR1_A05 C15

DDR1_A06 D16

DDR01_BA0 F16

DDR01_BA1 B16

DDR01_BA2 E15

DDR01_CASB A17

DDR0_DQ00 A8

DDR0_DQ01 B11

DDR0_DQ02 B8

DDR0_DQ03 D11

DDR0_DQ04 E11

DDR0_DQ05 C8

DDR0_DQ06 C11

DDR0_DQ07 C9

DDR0_DQ08 D8

DDR0_DQ09 E10

DDR0_DQ10 E9

DDR0_DQ11 F11

DDR0_DQ12 F12

DDR0_DQ13 E8

DDR0_DQ14 D10

DDR0_DQ15 F8

DDR1_DQ00 C18

DDR1_DQ01 C20

DDR1_DQ02 A18

DDR1_DQ03 B21

DDR1_DQ04 C21

DDR1_DQ05 B18

DDR1_DQ06 B20

DDR1_DQ07 D18

DDR1_DQ08 E18

DDR1_DQ09 D21

DDR1_DQ10 F18

DDR1_DQ11 E20

DDR1_DQ12 A22

DDR1_DQ13 F17

DDR1_DQ14 B22

DDR1_DQ15 E17

DDR0_DM0 A10

DDR0_DM1 C10

DDR1_DM0 A20

DDR1_DM1 F19

DDR0_DQS0 B10

DDR0_DQS0B B9

DDR0_DQS1 F10

DDR0_DQS1B F9

DDR1_DQS0 B19

DDR1_DQS0B C19

DDR1_DQS1 E19

DDR1_DQS1B D19

DDR01_RASB C16

DDR_VREF0 A7

DDR_VREF1 A23

DDR01_WEB C17

DDR_VDDP1P8_1 C7

DDR_VDDP1P8_2 D22

C687

0.1uF

C685

0.1uF

C683

0.1uF

C688

0.1uF

C686

0.1uF

C684

0.1uF

C602

0.1uF

C603

0.1uF

C604

0.1uF

DDR01_CKE

003:B1;003:D2;003:D4;003:F2;003:F4;003:F6

DDR01_CKE

003:B1;003:D2;003:D4;003:D7;003:F2;003:F4

C651 1uF

C672

22uF

C637

22uF

C675

10uF

C671

10uF

C638

10uF

C676

10uF

C636

10uF

C667

10uF

C635

10uF

C631

10uF

C680

10uF

C644

10uF

IC603

NT5TU128M8DE_BD

NANYA_DDR

DEV

EAN60992101

CKE

RAS

CAS

BA0

BA1

A10/AP

A11

A12

NC_1/BA2

NC_2/A14

NC_3/A15

A13

ODT

DQ0 C8

DQ1 C2

DQ2 D7

DQ3 D3

DQ4 D1

DQ5 D9

DQ6 B1

DQ7 B9

DQS B7

DQS A8

DM/RDQS B3

NU/RDQS A2

VDDQ_1 A9

VDDQ_2 C1

VDDQ_3 C3

VDDQ_4 C7

VDDQ_5 C9

VDD_1 A1

VDD_2 L1

VDD_3 E9

VDD_4 H9

VSSQ_1 A7

VSSQ_2 B2

VSSQ_3 B8

VSSQ_4 D2

VSSQ_5 D8

VSS_1 A3

VSS_2 E3

VSS_3 J1

VSS_4 K9

VREF E2

VDDL E1

VSSDL E7

IC605

NT5TU128M8DE_BD

NANYA_DDR

DEV

EAN60992101

CKE

RAS

CAS

BA0

BA1

A10/AP

A11

A12

NC_1/BA2

NC_2/A14

NC_3/A15

A13

ODT

DQ0 C8

DQ1 C2

DQ2 D7

DQ3 D3

DQ4 D1

DQ5 D9

DQ6 B1

DQ7 B9

DQS B7

DQS A8

DM/RDQS B3

NU/RDQS A2

VDDQ_1 A9

VDDQ_2 C1

VDDQ_3 C3

VDDQ_4 C7

VDDQ_5 C9

VDD_1 A1

VDD_2 L1

VDD_3 E9

VDD_4 H9

VSSQ_1 A7

VSSQ_2 B2

VSSQ_3 B8

VSSQ_4 D2

VSSQ_5 D8

VSS_1 A3

VSS_2 E3

VSS_3 J1

VSS_4 K9

VREF E2

VDDL E1

VSSDL E7

IC604

NT5TU128M8DE_BD

NANYA_DDR

DEV

EAN60992101

CKE

RAS

CAS

BA0

BA1

A10/AP

A11

A12

NC_1/BA2

NC_2/A14

NC_3/A15

A13

ODT

DQ0 C8

DQ1 C2

DQ2 D7

DQ3 D3

DQ4 D1

DQ5 D9

DQ6 B1

DQ7 B9

DQS B7

DQS A8

DM/RDQS B3

NU/RDQS A2

VDDQ_1 A9

VDDQ_2 C1

VDDQ_3 C3

VDDQ_4 C7

VDDQ_5 C9

VDD_1 A1

VDD_2 L1

VDD_3 E9

VDD_4 H9

VSSQ_1 A7

VSSQ_2 B2

VSSQ_3 B8

VSSQ_4 D2

VSSQ_5 D8

VSS_1 A3

VSS_2 E3

VSS_3 J1

VSS_4 K9

VREF E2

VDDL E1

VSSDL E7

IC606

NT5TU128M8DE_BD

NANYA_DDR

DEV

EAN60992101

CKE

RAS

CAS

BA0

BA1

A10/AP

A11

A12

NC_1/BA2

NC_2/A14

NC_3/A15

A13

ODT

DQ0 C8

DQ1 C2

DQ2 D7

DQ3 D3

DQ4 D1

DQ5 D9

DQ6 B1

DQ7 B9

DQS B7

DQS A8

DM/RDQS B3

NU/RDQS A2

VDDQ_1 A9

VDDQ_2 C1

VDDQ_3 C3

VDDQ_4 C7

VDDQ_5 C9

VDD_1 A1

VDD_2 L1

VDD_3 E9

VDD_4 H9

VSSQ_1 A7

VSSQ_2 B2

VSSQ_3 B8

VSSQ_4 D2

VSSQ_5 D8

VSS_1 A3

VSS_2 E3

VSS_3 J1

VSS_4 K9

VREF E2

VDDL E1

VSSDL E7

C645

10uF

6.3V

C625

10uF

6.3V

C646

2.2uF

C623

22uF

10V

+3.3V_NORMAL

R8220

R8221

R8222

K4T1G084QF-BCF8

IC606-*1

SS DDR

CKE

RAS

CAS

BA0

BA1

BA2

A10/AP

A11

A12

A13

NC_1

NC_2

ODT0

DQ0 C8

DQ1 C2

DQ2 D7

DQ3 D3

DQ4 D1

DQ5 D9

DQ6 B1

DQ7 B9

DQS B7

DQS A8

DM/RDQS B3

NU/RDQS A2

VDDQ_1 A9

VDDQ_2 C1

VDDQ_3 C3

VDDQ_4 C7

VDDQ_5 C9

VDD_1 A1

VDD_2 L1

VDD_3 E9

VDD_4 H9

VSSQ_1 A7

VSSQ_2 B2

VSSQ_3 B8

VSSQ_4 D2

VSSQ_5 D8

VSS_1 A3

VSS_2 E3

VSS_3 J1

VSS_4 K9

VREF E2

VDDL E1

VSSDL E7

K4T1G084QF-BCF8

IC603-*1

SS DDR

CKE

RAS

CAS

BA0

BA1

BA2

A10/AP

A11

A12

A13

NC_1

NC_2

ODT0

DQ0 C8

DQ1 C2

DQ2 D7

DQ3 D3

DQ4 D1

DQ5 D9

DQ6 B1

DQ7 B9

DQS B7

DQS A8

DM/RDQS B3

NU/RDQS A2

VDDQ_1 A9

VDDQ_2 C1

VDDQ_3 C3

VDDQ_4 C7

VDDQ_5 C9

VDD_1 A1

VDD_2 L1

VDD_3 E9

VDD_4 H9

VSSQ_1 A7

VSSQ_2 B2

VSSQ_3 B8

VSSQ_4 D2

VSSQ_5 D8

VSS_1 A3

VSS_2 E3

VSS_3 J1

VSS_4 K9

VREF E2

VDDL E1

VSSDL E7

K4T1G084QF-BCF8

IC605-*1

SS DDR

CKE

RAS

CAS

BA0

BA1

BA2

A10/AP

A11

A12

A13

NC_1

NC_2

ODT0

DQ0 C8

DQ1 C2

DQ2 D7

DQ3 D3

DQ4 D1

DQ5 D9

DQ6 B1

DQ7 B9

DQS B7

DQS A8

DM/RDQS B3

NU/RDQS A2

VDDQ_1 A9

VDDQ_2 C1

VDDQ_3 C3

VDDQ_4 C7

VDDQ_5 C9

VDD_1 A1

VDD_2 L1

VDD_3 E9

VDD_4 H9

VSSQ_1 A7

VSSQ_2 B2

VSSQ_3 B8

VSSQ_4 D2

VSSQ_5 D8

VSS_1 A3

VSS_2 E3

VSS_3 J1

VSS_4 K9

VREF E2

VDDL E1

VSSDL E7

K4T1G084QF-BCF8

IC604-*1

SS DDR

CKE

RAS

CAS

BA0

BA1

BA2

A10/AP

A11

A12

A13

NC_1

NC_2

ODT0

DQ0 C8

DQ1 C2

DQ2 D7

DQ3 D3

DQ4 D1

DQ5 D9

DQ6 B1

DQ7 B9

DQS B7

DQS A8

DM/RDQS B3

NU/RDQS A2

VDDQ_1 A9

VDDQ_2 C1

VDDQ_3 C3

VDDQ_4 C7

VDDQ_5 C9

VDD_1 A1

VDD_2 L1

VDD_3 E9

VDD_4 H9

VSSQ_1 A7

VSSQ_2 B2

VSSQ_3 B8

VSSQ_4 D2

VSSQ_5 D8

VSS_1 A3

VSS_2 E3

VSS_3 J1

VSS_4 K9

VREF E2

VDDL E1

VSSDL E7

R618 0

* DDR2 1.8V By CAP - Place these Caps near Memory

DDR VTT

Place Caps close to DRAM pin Place Caps close to DRAM pin

Place Caps close to DRAM pin

$ 0.180

BCM-DDR

Only for training and service purposes

LGE Internal Use Only

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES

SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.

FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS

ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR

THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

4 100

PMDATA[12]

PMADR[1]

PMADR[8]

PMDATA[0-15]

PMADR[7]

PMADR[0]

PMDATA[15]

PMDATA[13]

PMDATA[1]

PMDATA[4]

PMADR[9]

PMADR[6]

PMADR[8]

PMDATA[5]

PMADR[0]

PMADR[0-20]

PMADR[11]

PMADR[3]

PMDATA[15]

PMDATA[10]

PMDATA[6]

PMADR[15]

PMADR[4]

PMDATA[14]

PMADR[12]

PMDATA[2]

PMADR[5]

PMDATA[4]

PMADR[18] PMDATA[6]

PMDATA[2]

PMDATA[9]

PMADR[16]

PMADR[2]

PMADR[10]

PMADR[14]

PMDATA[0]

PMDATA[7]

PMADR[4]

PMDATA[11]

PMDATA[13]

PMDATA[1]

PMADR[3]

PMDATA[0]

PMDATA[8]

PMDATA[11]

PMDATA[3]

PMADR[0-20]

PMADR[1]

PMADR[17]

PMADR[7]

PMADR[9]

PMADR[6]

PMDATA[12]

PMADR[15]

PMADR[17]

PMADR[10]

PMDATA[14]

PMDATA[3]

PMADR[18]

PMADR[13]

PMADR[20]

PMADR[14]

PMDATA[8]

PMADR[5]

PMDATA[9]

PMADR[11]

PMADR[12]

PMDATA[5]

PMDATA[7]

PMADR[19]

PMADR[2]

PMADR[13]

PMADR[16]

PMDATA[10]

DMD_D[23]

DMD_D[22]

DMD_D[21]

DMD_D[20]

DMD_D[18]

DMD_D[17]

DMD_D[16]

DMD_D[15]

DMD_D[14]

DMD_D[13]

DMD_D[12]

DMD_D[11]

DMD_D[10]

DMD_D[9]

DMD_D[8]

DMD_D[7]

DMD_D[6]

DMD_D[5]

DMD_D[4]

DMD_D[3]

DMD_D[2]

DMD_D[1]

DMD_D[0]

DMD_D[19]

DMD_D[0-23]

DMD_D[21]

DMD_D[19]

DMD_D[18]

DMD_D[16]

DMD_D[17]

DMD_D[15]

DMD_D[14]

DMD_D[4]

DMD_D[13]

DMD_D[11]

DMD_D[22]

DMD_D[1]

DMD_D[10]

DMD_D[0]

DMD_D[9]

DMD_D[2]

DMD_D[8]

DMD_D[5]

DMD_D[6]

DMD_D[3]

DMD_D[7]

DMD_D[23]

DMD_D[0-23]

DMD_D[12]

DMD_D[20]

DOWN_ENZ

PMADR[20]

PMADR[19]

R305 33

PM_OESZ

FLASH_CSSZ

R308

10K

3.3V

C301 0.1uF

PM_OESZ

R311

10K

FLASH_CSSZ

R304 33

R307

R306 33

PM_WESZ

R303

10K

3.3V

R310 OPT

R302

10K

PM_WESZ

IC301

S29JL032H70TFI020

S/W ASSY

26 CE

27 VSS0

28 OE

29 DQ0

30 DQ8

31 DQ1

32 DQ9

33 DQ2

34 DQ10

35 DQ3

36 DQ11

37 VCC

38 DQ4

39 DQ12

40 DQ5

41 DQ13

42 DQ6

43 DQ14

44 DQ7

45 DQ15/A_1

46 VSS1

47 BYTE

48 A16

A17

A13

A10

A18

RY/BY

WP/ACC

RESET

A20

A19

A12

A11

25 A0

A14

A15

PWRGOOD

R309

10K

IC402

KA2903

IN1+

IN1-

GND

OUT1

5IN2+

6IN2-

7OUT2

8VCC

C413 1uF

C408

100pF

R_TEMP_COMP_OUT

V_ADJ_CH3

AMBIENT_NTC_PWM

GRN_EN

R407

22K

R410

22K

GRN_NTC_PWM

AMBIENT_TEMP_COMP_OUT

RED_NTC_PWM

R430

C401

0.1uF

16V

R426 33

FAN1

3.3V

R401

22K

R419 33

AMBIENT_NTC_PWM

C406

0.1uF

16V

FAN2_TACH

G_NTC

IC11

KA2903

IN1+

IN1-

GND

OUT1

5IN2+

6IN2-

7OUT2

8VCC

G_TEMP_COMP_OUT

R422 1.5K

C404

0.1uF

16V

FAN2

R408

20K

R424 1.5K

R_TEMP_COMP_OUT

RED_NTC_PWM

R429 33

R400

3.9K

R427 33

C412 1uF

R418

10K

DPP_TX

R425 1.5K

R420 33

R417

10K

3.3V

C402

0.1uF

16V

R406

R403 33

C410 1uF

GRN_NTC_PWM

R404 33

AMBIENT_TEMP_COMP_OUT

C405

0.01uF

25V

3.3V

C411 1uF

R405 33

C403

0.01uF

25V

R402 33

C409

100pF

G_TEMP_COMP_OUT

C10001

0.047uF

25V

V_ADJ_CH1

BLU_EN

USB_ENZ

RED_EN

R423 33

DOWN_ENZ

R409 33

R421 1.5K

R411

3.9K

FAN1_TACH

3.3V

R_NTC

C414 1uF

R413

3.3K

R415

22 R41422

V_ADJ_CH2

R412

3.3K

3.3V

R428 1.5K

DPP_RX

C400

0.01uF

25V

3.3V

L202

BLM18PG121SN1D

C220

0.1uF

16V

R13 0

R21

3.3K

R11

1.5K

R26

3.3V

R22 10K

R15 27

R16 10K

R17

100K

C80

0.1uF

16V

3.3V

R24

3.3K

X10

32.0MHz

GND_2 1HOT_1

2GND_1

HOT_2

UART0_TXD

3.3V

R23

330

1/16W

R38

10K

R12 1K

OPT

3.3V

R20 10K

R27

4.7K

DDP_ASIC_READY

R19 10K

R36

3.3K

R30 33

R35

3.3K

POSENSE

C78

18pF

R18 10K

R34

3.3K

PWRGOOD

R14 27

3.3V

USB_DAT_N

R32

R37 33

USB_ENZ R33 33

R28

USB_DAT_P

3.3V

UART0_RXD

IC12

74VIT125CTR

3GND

21A

11G

VCC

R29

3.3K

BCM_INT

LVDS_TX_0_DATA0_N

LVDS_TX_0_DATA4_P R126 100

LVDS_TX_0_DATA2_N

R121 100

LVDS_TX_0_CLK_N

LVDS_TX_0_DATA1_P

LVDS_TX_0_DATA0_P

R124 120

LVDS_TX_0_DATA1_N

LVDS_TX_0_CLK_P

LVDS_TX_0_DATA3_P

R123 100

LVDS_TX_0_DATA2_P

LVDS_TX_0_DATA4_N

R122 100

LVDS_TX_0_DATA3_N

R125 100

2.5V

DMD_SCTRL

DMD_DAD_BUS

DMD_DAD_OEZ

DMD_DCLK

DMD_DAD_STRB

DMD_SAC_BUS

DMD_SAC_CLK

DMD_LOADB

R431 5.1

R432 5.1

R433 5.1

R434 5.1

R459 20

R460 20

R461 20

R462 20

R463 20

R435 0

DMD_TRC

DMD_PWR_EN

R31 1K

R42

10K

R465

22 R467

R416

OPT

R41 27

DMD_REF_2.5V

C300 10uF 6.3V

C221

10uF

6.3V

DMD_PWR_EN

P401

104060-6017

DMD_REF_2.5V

DMD_REF_1.9V

DMD_TRC

DMD_SCTRL

DMD_LOADB

DMD_DAD_OEZ

DMD_SAC_CLK

DMD_SAC_BUS

DMD_DAD_STRB

DMD_DAD_BUS

DMD_DCLK

TH1

47k-ohm

NCP18WB473F10RB

TH2

47k-ohm

NCP18WB473F10RB

+5V_NORMAL

C407

0.1uF

16V

+5V_NORMAL+5V_NORMAL

R464 150

BLU_EN

R_NTC

G_NTC

RED_EN

GRN_EN

V_ADJ_CH1

V_ADJ_CH3

V_ADJ_CH2

B_NTC

GND

P402

05004HR-20B01S

+5V_NORMAL

+3.3V_NORMAL

+5V_NORMAL

C415

10uF

10V

SW1

JTP-1127WEM

1 2

IC400

AT24C32D-SSHM-T

GND

5SDA

6SCL

7WP

8VCC

R312

R313

R314

2.2KOPT

R315

OPT

C302 10uF 6.3V

OPT

R466 33

R470 33

R469 33

C79

1uF

6.3V

IC10

DPP6401

P1_A_0

AA17

P1_A_1

W16

P1_A_2

AB18

P1_A_3

Y17

P1_A_4

AA18

P1_A_5

AB19

P1_A_6

W17

P1_A_7

Y18

P1_A_8

AA19

P1_A_9

AB20

P1_B_0

W18

P1_B_1

Y19

P1_B_2

AA20

P1_B_3

W21

P1_B_4

W22

P1_B_5

V21

P1_B_6

U19

P1_B_7

V22

P1_B_8

U20

P1_B_9

U21

P1_C_0

U22

P1_C_1

T19

P1_C_2

T20

P1_C_3

T21

P1_C_4

R22

P1_C_5

R21

P1_C_6

R20

P1_C_7

R19

P1_C_8

P22

P1_C_9

P21

P1A_CLK

W15

P1B_CLK

AB17

P1C_CLK

Y16

P1_FIELD

W14

P1_DATEN

AA16

P1_VSYNC

Y15

P1_HSYNC

AB16

ALF_VSYNC

P19

ALF_HSYNC

P20

ALF_CSYNC

N22

RCK_IN_P

RCK_IN_N

RA_IN_P

AB10

RA_IN_N

AA10

RB_IN_P

Y11

RB_IN_N

W11

RC_IN_P

AB12

RC_IN_N

AA12

RD_IN_P

Y13

RD_IN_N

W13

RE_IN_P

AB14

RE_IN_N

AA14

AFE_IRQ

M22 AFE_CLK M21

AFE_ARSTZ M20

IC10

DPP6401

MOSC

A14

MOSCN

A15

PWRGOOD

H19

POSENSE

G21 EXT_ARSTZ H20

IC10

DPP6401

PM_DATA_15 M1

PM_DATA_14 N1

PM_DATA_13 N2

PM_DATA_12 N3

PM_DATA_11 N4

PM_DATA_10 P1

PM_DATA_9 P2

PM_DATA_8 P3

PM_DATA_7 P4

PM_DATA_6 R2

PM_DATA_5 R3

PM_DATA_4 R4

PM_DATA_3 T1

PM_DATA_2 T2

PM_DATA_1 T3

PM_DATA_0 T4

GPIO_17 V3

GPIO_16 W1

PM_ADDR_20 W2

PM_ADDR_19 Y1

PM_ADDR_18 AB2

PM_ADDR_17 AA3

PM_ADDR_16 Y4

PM_ADDR_15 W5

PM_ADDR_14 AB3

PM_ADDR_13 AA4

PM_ADDR_12 Y5

PM_ADDR_11 W6

PM_ADDR_10 AB4

PM_ADDR_9 AA5

PM_ADDR_8 Y6

PM_ADDR_7 W7

PM_ADDR_6 AB5

PM_ADDR_5 AA6

PM_ADDR_4 Y7

PM_ADDR_3 AB6

PM_ADDR_2 W8

PM_ADDR_1 AA7

PM_ADDR_0 AB7

PM_BLSZ_1 AA8

PM_BLSZ_0 AB8

PM_WEZ V2

PM_OEZ U4

PM_CSZ_0 U3

PM_CSZ_1 U2

PM_CSZ_2 U1

IC10

DPP6401

UART0_TXD

L19

UART0_CTSZ

L20

UART0_RXD

L21

UART0_RTSZ

M19

USB_DAT_N

USB_DAT_P

SSP0_CLK F4

SSP0_TXD F3

SSP0_RXD D1

SSP0_CSZ_1 C1

SSP0_CSZ_0 D2

IC10

DPP6401

DMD_PWR_EN G20

DMD_TRC D9

DMD_SCTRL C9

DMD_LOADB B9

DMD_DCLK A9

DMD_D23 C6

DMD_D22 C10

DMD_D21 E9

DMD_D20 B6

DMD_D19 D7

DMD_D18 A10

DMD_D17 B7

DMD_D16 D12

DMD_D15 C12

DMD_D14 B12

DMD_D13 A12

DMD_D12 A6

DMD_D11 D10

DMD_D10 E7

DMD_D9 B10

DMD_D8 C7

DMD_D7 E11

DMD_D6 D11

DMD_D5 C11

DMD_D4 B11

DMD_D3 D8

DMD_D2 C8

DMD_D1 B8

DMD_D0 A8

DMD_SAC_CLK A5

DMD_SAC_BUS D6

DMD_DAD_OEZ B5

DMD_DAD_STRB C5

DMD_DAD_BUS D5

EXRES A3

IC10

DPP6401

GPIO_15

B19

IIC0_SDA0

IIC0_SCL0

GPIO_08

GPIO_09

GPIO_28

E22

GPIO_29

F20

GPIO_25

D22

GPIO_26

F19

GPIO_27

E21

GPIO_24

E20

GPIO_37

K21

GPIO_30

F21

GPIO_11

A19

GPIO_10

C17

GPIO_20

N19

GPIO_21

N20

CMP_OUT

GPIO_19 D18

GPIO_18 C18

GPIO_01 D15

GPIO_02 A17

GPIO_07 B17

GPIO_06 A18

GPIO_05 D16

GPIO_32 F22

GPIO_31 G19

GPIO_04 C16

GPIO_03 B16

GPIO_00 C15

GPIO_23 D21

GPIO_22 N21

GPIO_13 L2

GPIO_12 M4

LEDR_EN L3

LEDG_EN L4

LEDB_EN K1

LEDR_PWM K2

LEDG_PWM K3

LEDB_PWM K4

CMP_PWM J1

GPIO_33 H2

GPIO_34 H3

GPIO_35 H4

GPIO_36 G1

GPIO_14 B18

IC10

DPP6401

TDO2

M18

TDO1

L18

TMS2

V16

TMS1

V15

TDI

P18

TCK

R18

TRSTZ

V17

ICTSEN

HW_TEST_EN

TSTPT_7 K20

TSTPT_6 K19

TSTPT_5 J22

TSTPT_4 J21

TSTPT_3 J20

TSTPT_2 J19

TSTPT_1 H22

TSTPT_0 H21

ETM_PIPESTAT_2 F1

ETM_PIPESTAT_1 G4

ETM_PIPESTAT_0 G3

ETM_TRACESYNC F2

ETM_TRACECLK G2

RTCK G18

SPARE E16

VPGM D17

SDA3_3.3V

SCL3_3.3V R472 33

R471 33

C77

18pF

TP401

TP402

R452 33

R446 33

R440 33

R453 33

R443 33

R447 33

R449 33

R442 33

R456 33

R437 33

R455 33

R451 33

R454 33

R458 33

R441 33

R445 33

R436 33

R438 33

R444 33

R450 33

R468 33

R457 33

R439 33

R448 33

32Mb / Bottom type / 4 Banks

DPP6400 FLASH ROM

VPP : High - Normal Operation

Low - Write/Erase Protection

Slave Address : 0xA2

EEPROM

FOR DPP6400

PLACE BOTTOM

DOWNLOAD ENABLEZ S/W

TO SENSOR BOARD

ADC for TEMP Sensor

S6 communication

DPP6400 GPIO

TO DMD BOARD

for CCA

POSENSE

PWRGOOD

POSENSE

>500us

DPP6400 ETC

PWRGOOD

DPP6400

Front End

DPP6401 DEBUG

(To DAD)

(To DMD)

PWM OUT0

PWM OUT2

PWM OUT1

PWM OUT3

PWM OUT4

2010.09.01

4 5

HW300-JE

TOP Bottom

FOR MACRONIX 16Mb : delete R313

FOR ATMEL 32Mb : delete R312, add R314,R315,C302

change R311 0 ohm

Only for training and service purposes

LGE Internal Use Only

THERMAL

THERMALTHERMAL

THERMAL

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES

SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.

FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS

ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR

THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

D3.3V

ST_5V

C1085

0.01uF

R8066

3.9K

OPT

L203

BLM18PG121SN1D

C62 0.1uF

C1079

0.01uF

IC8005

AOZ1024DI

EAN60660601

PGND

VIN

AGND

COMP

+5V

C8021

22uF

25V

1.2V_Core

L8020

BLM18PG121SN1D

0.1uF

C8062

C1066

0.1uF

C8050

C18

1000pF

IC900

LGE3549XS (LGE3549XS P22 , B2 version)

EAN60345904

DEV

DVSS_1

DVSS_2

DVSS_3

DVSS_4

DVSS_5

DVSS_6

DVSS_7

AA7

DVSS_8

DVSS_10

AA8

DVSS_11

DVSS_12

DVSS_13

DVSS_14

K10

DVSS_15

L10

DVSS_16

M10

DVSS_17

N10

DVSS_18

P10

DVSS_19

R10

DVSS_20

T10

DVSS_21

U10

DVSS_22

W10

DVSS_23

A11

DVSS_24

K11

DVSS_25

L11

DVSS_26

M11

DVSS_27

N11

DVSS_28

P11

DVSS_29

R11

DVSS_30

T11

DVSS_31

U11

DVSS_32

D12

DVSS_33

G12

DVSS_34

K12

DVSS_35

L12

DVSS_36

M12

DVSS_37

N12

DVSS_38

P12

DVSS_39

R12

DVSS_40

T12

DVSS_41

U12

DVSS_42

K13

DVSS_43

L13

DVSS_44

M13

DVSS_45

N13

DVSS_46

P13

DVSS_47

R13

DVSS_48

T13

DVSS_49

U13

DVSS_50

G14

DVSS_51

K14

DVSS_52

L14

DVSS_53

M14

DVSS_54

N14

DVSS_55

P14

DVSS_56

R14

DVSS_57

T14

DVSS_58

U14

DVSS_59

K15

DVSS_60

L15

DVSS_61

M15

DVSS_62

N15

DVSS_63 P15

DVSS_64 R15

DVSS_65 T15

DVSS_66 U15

DVSS_67 W15

DVSS_68 A16

DVSS_69 G16

DVSS_70 K16

DVSS_71 L16

DVSS_72 M16

DVSS_73 N16

DVSS_74 P16

DVSS_75 R16

DVSS_76 T16

DVSS_77 U16

DVSS_78 D17

DVSS_79 K17

DVSS_80 L17

DVSS_81 M17

DVSS_82 N17

DVSS_83 P17

DVSS_84 R17

DVSS_85 T17

DVSS_86 U17

DVSS_87 AA17

DVSS_88 AB17

DVSS_89 G18

DVSS_91 AB18

DVSS_92 AC18

DVSS_95 D20

DVSS_96 G20

DVSS_97 H20

DVSS_98 J20

DVSS_99 K20

DVSS_100 L20

DVSS_101 M20

DVSS_102 N20

DVSS_103 P20

DVSS_104 R20

DVSS_105 U20

DVSS_106 A21

DVSS_107 N21

DVSS_90 V21

DVSS_93 W24

DVSS_94 F26

DVSS_9

K26

D8001

40V

RB160M-40

C8001

0.1uF

16V

C54 0.1uF

+5V_NORMAL

C1056

1000pF

C8072

0.1uF

16V

C1052

4.7uF

C60 0.1uF

0.1uF

C8055

C1302

0.1uF

D1.8V

GND

C1061

1000pF

D3.3V

C59 0.1uF

C50 0.1uF

D1.2V

C40 0.1uF

C8051

0.1uF

50V

C76

0.1uF R8051

10K

FAN1

L8006

MLB-201209-0120P-N2

C43 0.1uF

R8012

20K

C1051

1000pF

R204

C67 0.1uF

C72 0.1uF

C1064

4.7uF

C1095

0.01uF

C57 0.1uF

C41 0.1uF

R8057

10K

+3.5V_ST

C1099

0.1uF

P201

12507WR-03L

C1093

0.01uF

C8017

10uF

10V

D3.3V

C8030

10uF

10V

C49 0.1uF

R8009 10K

C63 0.1uF

R8080

10K

1/16W

C1082

0.1uF

C8054

3300pF

50V

L205

BLM18PG121SN1D

R8014

L13 BLM18PG121SN1D

+3.3V_NORMAL

L8018

BLM18PG121SN1D

IC202

TCA0372DM2ELG

OUT_A

NC1

VCC

VEE/GND1

NC2

OUT_B

NC3

VEE/GND2 9VEE/GND3

10 NC4

11 IN_B-

12 IN_B+

13 IN_A+

14 IN_A-

15 NC5

16 VEE/GND4

L8016

CIC21J501NE

C1059

0.1uF

L8002

BLM18PG121SN1D

+5V_NORMAL

C61 0.1uF

P8001

12507WR-06L

C28 0.1uF

C1065

1000pF C1071

0.01uF

C223

100pF

50V

IC8003

BD9306AFVM

3ENB

2CT

4GD

1RT

VCC

GND

COMP

C1301

0.01uF

D1.2V

C27 0.1uF

C1089

1000pF

C1062

1000pF

C1077

0.1uF

C1080

1000pF

1.2V_Core

L12 BLM18PG121SN1D

POSENSE

C8076

0.1uF

16V

R8069

27K

C8019

100pF

50V

C26 0.1uF

R8011

FAN2

C1075

0.1uF

C64 0.1uF

C24 0.1uF

D1.8V

C1060

0.1uF

FAN1_TACH

L8001

MLB-201209-0120P-N2

R8058

20K

1/16W

D3.3V

C47 0.1uF

L8019

BLM18PG121SN1D

C58 0.1uF

C1091

4.7uF

L1007

BLM18PG121SN1D

C25 0.1uF

C46 0.1uF

C1097

0.01uF

C1068

0.01uF

0.1uF

C8056

OPT

C1057

1000pF

R8056

20K

0.1uF

C8042

OPT

C8020

100pF

50V

C8032

0.1uF

16V

C20

0.1uF

C68 0.1uF

3.3V

C48 0.1uF

C8022

22uF

25V

+3.3V_NORMAL

L8015

3.6uH

R8071

10K

C23 0.1uF

FAN2_TACH

C224

10uF

25V

C1054

0.01uF

L10 BLM18PG121SN1D

D1.2V

C1078

4.7uF

C1083

4.7uF

R203

2.5V

C1086

4.7uF

C1063

0.01uF

C55 0.1uF

C13

0.1uF

C44 0.1uF

C1053

0.1uF

C1074

0.01uF

C1070

0.1uF

C8069

3300pF

50V

L8013

CIC21J501NE

R8059

IC900

LGE3549XS (LGE3549XS P22 , B2 version)

EAN60345904

DEV

VDDC_1

VDDC_2

VDDC_3

VDDC_4

VDDC_5

VDDC_6

VDDC_7

VDDC_8

VDDC_9

VDDC_10

H10

VDDC_11

H11

VDDC_12

H12

VDDC_13

H13

VDDC_14

H14

VDDC_15

H15

VDDC_16

H16

VDDC_17

H17

VDDC_18

H18

VDDC_19

H19

VDDC_20

J19

VDDC_21

K19

VDDC_22

L19

VDDC_23

M19

VDDC_24

N19

VDDC_25

P19

VDDC_26

R19

VDDC_27

T19

VDDC_28

U19

VDDC_29

V19

AGC_VDDO

V24

VDDO_1

W11

VDDO_2

W12

VDDO_3

W17

VDDO_4

W18

VDDO_5

E26

VDDO_6

L26

VDDO_7

T26

DDRV_1

DDRV_2

DDRV_3

G11

DDRV_4

G13

DDRV_5

A14

DDRV_6

G15

DDRV_7

G17

DDRV_8

A19

DDRV_9

G19

IC8002

AP2132MP-2.5TRG1

EAN61387601

VIN

VCTRL

VOUT

ADJ

GND

[EP]

C1073

1000pF

C225

0.1uF

50V

C1094

0.1uF

L11 BLM18PG121SN1D

C69 0.1uF

C8007

0.1uF

16V

C1076

4.7uF

C51 0.1uF

C1072

0.1uF

C1069

1000pF

R8070

4.7K

1/16W

C65 0.1uF

D1.8V

C1067

1000pF

C39 0.1uF

C1084

4.7uF

D202

100V

1N4148W_DIODES

C8029

10uF

10V

R8060

10K

R8010

C42 0.1uF

C17

1000pF

POWER_ON/OFF2_1

C73 0.1uF

C8070

0.1uF

16V

D203

100V

1N4148W_DIODES

C8018

0.1uF

D1.8V

+5V_NORMAL

+3.3V_NORMAL

C56 0.1uF

+3.3V_NORMAL

R8013

100K

1/16W

C1092

1000pF

L204

BLM18PG121SN1D

0.1uF

C8039

D3.3V

C45 0.1uF

C52 0.1uF

C1058

4.7uF

D3.3V

C222

100pF

50V

C1055

0.1uF

C74 0.1uF

IC8004

AP2132MP-2.5TRG1

EAN61387601

VIN

VCTRL

VOUT

ADJ

GND

[EP]

C70 0.1uF

D3.3V

D1.2V

A2.5V

C71 0.1uF

C1088

0.01uF

C8063

0.1uF

16V

C53 0.1uF

R8052

C8053

10uF

6.3V

C8061

10uF

6.3V

C8058

10uF

6.3V

C8048

10uF

6.3V

C8038

10uF

6.3V

C134

10uF

6.3V

+3.3V_NORMAL

0.1uF

C136

OPT

+5V_NORMAL

C131

10uF

6.3V

R8081

10K

C132

10uF

6.3V

IC8006

AP2132MP-2.5TRG1

EAN61387601

VIN

VCTRL

VOUT

ADJ

GND

[EP]

0.1uF

C133

0.1uF

C135

R8082

C10

0.1uF

C90 0.1uF

C95 0.1uF

C88 0.1uF

C93 0.1uF

C89 0.1uF

C84 0.1uF

C85 0.1uF

C81 0.1uF

C97 0.1uF

C87 0.1uF

C82 0.1uF

C91 0.1uF

C96 0.1uF

C94 0.1uF

C86 0.1uF

C92 0.1uF

C83 0.1uF

C101 0.1uF

C102 0.1uF

C100 0.1uF

C98 0.1uF

C99 0.1uF

C121 0.1uF

C123 0.1uF

C120 0.1uF

C126 0.1uF

C124 0.1uF

C122 0.1uF

C125 0.1uF

C130 0.1uF

C128 0.1uF

C127 0.1uF

C129 0.1uF

1.2V_Core

C104

0.1uF

C107

0.1uF

C106

22uF

3.3V

R8083

10K

R8084

22K

DMD_REF_1.9V

C1300

22uF

10V

C1096

22uF

10V

C8057

22uF

10V

C1090

22uF

10V

C10000

22uF

10V

C8052

22uF

10V

C16 22uF 10V

C75 22uF 10V

C8006

22uF

10V

C8059

22uF

10V

C103

22uF

C37 10uF 6.3V

C36 10uF 6.3V

C1098

10uF

C8031

10uF

6.3V

C14

10uF

C8071

10uF

6.3V

C8073

10uF

6.3V

C8077

10uF

6.3V

C1087

10uF

C1081

10uF

C12

10uF

C38 10uF 6.3V

C15

10uF

C19 10uF 6.3V

C21 10uF 6.3V

C22 10uF 6.3V

C66 10uF 6.3V

C105

0.01uF

25V

C108

0.01uF

25V

L8023

500 L8022

500

L8014

500 L8017

500

L8008

500 L8012

500

IC8008

TPS54331D

VIN

SS/TR

BOOT

5VSENSE

6COMP

7GND

8PH C8064

0.1uF

16V

L8010

6.8uH

L8007

MLB-201209-0120P-N2

C8046

22uF

10V C8049

22uF

10V

C8024

0.1uF

50V

C8033

0.1uF

16V

C8028

0.015uF

50V

RL_ON

C8027

0.1uF

16V

C8047

22uF

10V

IC8007

TPS54331D

VIN

SS/TR

BOOT

5VSENSE

6COMP

7GND

8PH

C8025

0.1uF

50V

C8044

22uF

10V

L8005

MLB-201209-0120P-N2

R8008

100

R8016

330K

OPT

C8060

0.1uF

16V

C8026

0.015uF

50V

L8009

6.8uH

R8023

R8022

10.5K

R8019

51K

C8035

27pF

50V

C8040

390pF

50V

R8017

91K

R8007

330K

C8015

22uF

25V

C8023

22uF

25V

C8014

22uF

25V

C8016

22uF

25V

R8020

10.5K

R8021

C8036

390pF

50V

C8034

27pF

50V

R8018

51K

R8073

C8013

22uF

25V

C8000

22uF

10V

R8207

1/10W

R8208

1/10W

R8209

1/10W

R210

13K

R211

13K

R209

47K R208

47K

L8003 22.0uH

R8025

10K

1/10W

POWER_DET

C8065

1uF

10V

R8024 47K

D8004

40V

SMAB34

D8003

40V

SMAB34

Q8002

AO3438

ST_5V

+3.3V_NORMAL

IC8009

AZ1117BH-ADJTRE1

OUTPUT

3INPUT

ADJ/GND

R8001

1.5K

R8223

910

P200

53261-0390

C8010

3300pF

50V

OPT

C8004

0.1uF

50V

D1.2V

R8003

100 RL_ON

R8004

330K

OPT

C8043

22uF

10V

C8008

0.1uF

16V

C8037

22uF

10V

C8002

22uF

10V

C8012

0.1uF

16V

A1.2V

C8041

22uF

10V C8045

0.1uF

16V

C8003

22uF

10V

R8002

L8011

BLM18PG121SN1D

IC8010

AOZ1038PI

AGND

VIN

PGND

5COMP

6EN

7NC_1

8NC_2

[EP]LX

L8004

2uH

C8005

22uF

10V

R8006

4.99K

R8005

16K

C8011

1000pF

50V

IC10

DPP6401

VSS_1 A2

VSS_2 A7

VSS_3 A13

VSS_4 A21

VSS_5 A22

VSS_6 B1

VSS_7 B2

VSS_8 B3

VSS_9 B4

VSS_10 B13

VSS_11 B20

VSS_12 B21

VSS_13 B22

VSS_14 C2

VSS_15 C3

VSS_16 C4

VSS_17 C19

VSS_18 C20

VSS_19 C21

VSS_20 C22

VSS_21 D3

VSS_22 D4

VSS_23 D19

VSS_24 D20

VSS_25 E4

VSS_26 E5

VSS_27 E18

VSS_28 E19

VSS_29 F9

VSS_30 F11

VSS_31 F14

VSS_32 H1

VSS_33 J9

VSS_34 J10

VSS_35 J11

VSS_36 J12

VSS_37 J13

VSS_38 J14

VSS_39 K9

VSS_40 K10

VSS_41 K11

VSS_42 K12

VSS_43 K13

VSS_44 K14

VSS_45 K22

VSS_46 L9

VSS_47 L10

VSS_48 L11

VSS_49 L12

VSS_50 L13

VSS_51 L14

VSS_52 L22

VSS_53 M9

VSS_54 M10

VSS_55 M11

VSS_56 M12

VSS_57 M13

VSS_58 M14

VSS_59 M17

VSS_60 N6

VSS_61 N9

VSS_62 N10

VSS_63 N11

VSS_64 N12

VSS_65 N13

VSS_66 N14

VSS_67 P9

VSS_68 P10

VSS_69 P11

VSS_70 P12

VSS_71 P13

VSS_72 P14

VSS_73 R1

VSS_74 U8

VSS_75 U15

VSS_76 V4

VSS_77 V5

VSS_78 V8

VSS_79 V14

VSS_80 V18

VSS_81 V19

VSS_82 V20

VSS_83 W3

VSS_84 W4

VSS_85 W10

VSS_86 W12

VSS_87 W19

VSS_88 W20

VSS_89 Y2

VSS_90 Y3

VSS_91 Y8

VSS_92 Y10

VSS_93 Y12

VSS_94 Y14

VSS_95 Y20

VSS_96 Y21

VSS_97 AA1

VSS_98 AA2

VSS_99 AA9

VSS_100 AA11

VSS_101 AA13

VSS_102 AA21

VSS_103 AB11

VSS_104 AB13

VSS_105 AB22

PLLM_VSS B15

PLLD_VSS B14

PLLM_VAS C14

PLLD_VAS C13

VDDC_1

VDDC_2

E12

VDDC_3

E17

VDDC_4

VDDC_5

VDDC_6

VDDC_7

F12

VDDC_8

F16

VDDC_9

F17

VDDC_10

F18

VDDC_11

VDDC_12

VDDC_13

G17

VDDC_14

VDDC_15

K17

VDDC_16

VDDC_17

L17

VDDC_18

VDDC_19

VDDC_20

N17

VDDC_21

VDDC_22

P17

VDDC_23

VDDC_24

R17

VDDC_25

VDDC_26

VDDC_27

VDDC_28

U16

VDDC_29

U17

VDDC_30

U18

PLLD_VDD

E13

PLLM_VDD

E14

PLLD_VAD

D13

PLLM_VAD

D14

VDD33_1

A16

VDD33_2

A20

VDD33_3

VDD33_4

E15

VDD33_5

F13

VDD33_6

F15

VDD33_7

G22

VDD33_8

VDD33_9

VDD33_10

H17

VDD33_11

H18

VDD33_12

VDD33_13

VDD33_14

J17

VDD33_15

J18

VDD33_16

VDD33_17

K18

VDD33_18

VDD33_19

VDD33_20

VDD33_21

N18

VDD33_22

VDD33_23

VDD33_24

VDD33_25

VDD33_26

T17

VDD33_27

T18

VDD33_28

T22

VDD33_29

VDD33_30

U14

VDD33_31

VDD33_32

VDD33_33

Y22

VDD33_34

AA15

VDD33_35

AA22

VDD33_36

AB1

VDD33_37

AB9

VDD33_38

AB15

VDD33_39

AB21

DMD18_1

DMD18_2

A11

DMD18_3

DMD18_4

E10

DMD18_5

DMD18_6

F10

FPD12_1

U11

FPD12_2

U12

FPD12_3

V11

FPD12_4

V12

FPD33_1

U10

FPD33_2

U13

FPD33_3

V10

FPD33_4

V13

R8015

8.2K

+3.3V_NORMAL

ST_BY Power

BCM3549 POWER

D1.8V

Max 1100 mA

Typ:500mA

Typ:9mA

Fan Control

Typ:7mA

A2.5V

Vout=0.6*(1+R1/R2)

BCM3549 DDR 1.8V By CAP : Place near to BCM3549

DPP6401 Power

Typ:160mA

BCM core 1.2V volt

VOUT : 2.533V

MAX 2.3A

1.9V_DMD

Vout=0.6*(1+R1/R2)

14.5V_FAN

2010.09.01

HW300-JE

Power

MAX 3.1A

Normal Power

Switching freq: 555K

*NOTE 17

MAX 3.1A

Only for training and service purposes

LGE Internal Use Only

THERMAL

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES

SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.

FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS

ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR

THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

DMD_D[6]

DMD_D[8]

DMD_D[9]

DMD_D[10]

DMD_D[11]

DMD_D[12]

DMD_D[14]

DMD_D[17]

DMD_DAD_STRB

DMD_D[7]

DMD_D[3]

DMD_D[5]

DMD_D[2]

DMD_D[0]

DMD_D[1]

DMD_D[4]

DMD_D[15]

DMD_D[16]

DMD_D[18]

DMD_D[19]

DMD_D[21]

DMD_DCLK

DMD_LOADB

DMD_SCTRL

DMD_D[23]

DMD_TRC

DMD_SAC_CLK

DMD_D[20]

DMD_SAC_BUS

DMD_DAD_BUS

DMD_DAD_OEZ

DMD_D[22]

DMD_D[13]

DMD_REF_1.9V

VBIAS_16V

VOFFSET_8.5V

DMD_REF_1.9V DMD_REF_2.5V

VRST_-10V

0.1uF

16V

6.8pF

50V

BAT54S

C15

10uF

16V

DMD_PWR_EN

C14

10uF

16V

C12

0.1uF

16V

VBIAS_16V

15K

22uF

16V

R510K

BAT54S

C13

0.1uF

16V

VOFFSET_8.5V

1000pF

50V

40V

RB160M-40

10uF

16V

VRST_-10V

0.1uF

16V

0.1uF

16V

+5V

DMD_PWR_EN

+5V

22uH

43K

1/16W

270K

1/16W

C16

0.22uF

10V

470K

1/16W

56K

1/16W

DMD_REF_2.5V

P103

104060-6017

1uF

C11

1uF

C10

1uF

56K

1/16W

680K

1/10W

IC1

TPS65145PWPR

BASE

FB4

VIN

FB1

SW_2

SW_1

PGND_1

PGND_2

SUP

GND_1

FB3 13 OUT3

14 C2+

15 C2-/MODE

16 C1+

17 C1-

18 DRV

19 GND_2

20 REF

21 FB2

22 COMP

23 ENR

24 EN

[EP]

FBX0040CMFF6UA00

P102

A1 A2 A3 A4

B1 B2 B3 B4

C1 C2 C3 C4

D1 D2 D3 D4

E1 E2 E3 E4

F1 F2 F3 F4

G1 G2 G3 G4

H1 H2 H3 H4

J1 J2 J3 J4

K1 K2 K3 K4

FBX0040CMFF6UA00

P101

A1 A2 A3 A4

B1 B2 B3 B4

C1 C2 C3 C4

D1 D2 D3 D4

E1 E2 E3 E4

F1 F2 F3 F4

G1 G2 G3 G4

H1 H2 H3 H4

J1 J2 J3 J4

K1 K2 K3 K4

HS151 PP 2008.12.15

DMD

22 20 19

Only for training and service purposes

LGE Internal Use Only

This manual suits for next models

Table of contents

Popular Projector manuals by other brands

Barco

Barco FS40 - 4K Safety manual

NEC

NEC NP-PA500U installation guide

Samsung

Samsung L220 Owner's instructions

NEC

NEC NP04CM Installation and adjustment manual

Ask Proxima

Ask Proxima E1655-A Specifications

Liesegang

Liesegang ddv 1500 user manual

Dukane

Dukane ImagePro 8918 user manual

3M X45 quick start guide

Optoma

Optoma TX565UT specification

adapt

adapt Pico Play ADPP-99 user manual

InFocus

InFocus SP4805 quick start guide

Barco

Barco Galaxy NH-12 user guide

Sanyo

Sanyo PLC-WL2501 owner's manual

Optoma

Optoma EP757 Specifications

Sanyo

Sanyo DSU21B owner's manual

Epson

Epson EH-TW6000 Brochure & specs

Barco

Barco OVERVIEW D 50" installation manual

ROMAS

ROMAS SMART-BEAMER V6 manual

LG HW300Y User manual

Popular Projector manuals by other brands
