1
30” Freestanding Electric Range
SERVICE MANUAL
MODEL: LRE3085ST
CAUTION
BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
Website http://biz.lgservice.com
P/NO : MFL37118326
May, 2013
Printed in Korea
삼흥
정판
Internal Use Only

This LG Service Manual, “ 30” Freestanding Self-Cleaning Electric Range,” provides the
technician with information on the operation and service of the Freestanding Self-Cleaning
Electric Range. It is to be used as a training Service Manual. For specific information on the
model being serviced, refer to the “Owner’s Manual” or “Tech Sheet” provided with the electric
range.
SAFETY PRECAUTIONS
• Repairs of the appliance should be carried out by a licensed technician only. Incorrect repairs
may result in dangerous situations. If you need repairs, contact an LG Service Center or your
dealer.
• If the power cord is defective, it must be replaced by a qualified service agent with a UL listed
range cord.
• Electrical leads and cables should not be allowed to touch the oven.
• Rating plate is located on the left side of warming drawer.
• The power supply of the appliance should be turned off when it is being repaired.
FORWARD
LG Electronics assumes no responsibility for any repairs made
on our products by anyone other than Authorized Service Technicians.
WARNING
• DISCONNECT power supply cord from the outlet before servicing.
• Replace all panels and parts before operating.
• RECONNECT all grounding devices.
- Failure to do so can result in severe personal injury, death or electrical shock.
• DO NOT Touch when the oven operates.
- The interior parts will be very hot.
!

(Page)
GENERAL -------------------------------------------------------------------------------------------- 1-1 ~ 1-5
• Important safety instructions -------------------------------------------------------------------------------------- 1-1 ~ 1-3
• Model & Serial number label and tech sheet locations ----------------------------------------------------------- 1-4
• Specifications ------------------------------------------------------------------------------------------------------------------ 1-5
USING YOUR RANGE ------------------------------------------------------------------------- 2-1 ~ 2-5
• General information --------------------------------------------------------------------------------------------------------- 2-1
• Control panel features ---------------------------------------------------------------------------------------------- 2-2 ~ 2-5
- To turn on a single surface unit (Right Rear, Left Rear)
- To turn on a dual surface unit (Right Front, Left Front)
- To set the warming zone control
- Setting the Clock
- Start, Clear/Off and On/Off pad
- To turn On/Off the oven light
- Timer On/Off
- Setting pad: 6 categories
1) Convection auto conversion
2) Thermostat adjustment
3) Language selection (English or Spanish or French)
4) Preheating alarm light On/Off
5) Beeper volume
6) Temperature unit (°F or °C)
- Bake, Timed Bake, Delayed timed Bake
- Favorites
- Warm / Proof
- Oven lockout
- Changing hour mode on clock (12HR, 24HR)
- Self-Clean
- Easy Clean
- Warming drawer
COMPONENT ACCESS --------------------------------------------------------------------- 3-1 ~ 3-21
• Component Locations ------------------------------------------------------------------------------------------------------ 3-1
• Removing The Lamp, Controller, Back Cover and Controller Assembly(Membrane, PCB, Support) ----- 3-2 ~ 3-4
• Removing PCBs (Main PCB and Relay PCB) ----------------------------------------------------------------------- 3-5
• Removing the Surface Element and the Ceramic Glass Cooktop ------------------------------------------- 3-6
• Removing the Door Latch and the Door Switch --------------------------------------------------------------------- 3-7
• Removing the Outer Broil Element(Sheathed Heater) ------------------------------------------------------------ 3-8
• Removing the Inner Broil Element(Charcoal Heater) ----------------------------------------------------- 3-9 ~ 3-10
• Removing the HIIDDEN BAKE element ----------------------------------------------------------------------------- 3-11
• Removing the CONVECTION, Fan blade and Fan motor ------------------------------------------------------ 3-12
• Removing the Oven light & Socket assembly ---------------------------------------------------------------------- 3-13
• Removing the latch drive assembly ----------------------------------------------------------------------------------- 3-14
- Door locking mechanism ---------------------------------------------------------------------------------------------- 3-14
• Removing the Oven temperature Sensor --------------------------------------------------------------------------- 3-15
• Removing the Warming drawer element & temperature sensor ---------------------------------------------- 3-16
• Removing & Replacing the Lift-off Oven Door --------------------------------------------------------------------- 3-17
• Removing the Oven Door Handle ------------------------------------------------------------------------------------- 3-18
• Removing the Oven Door’s Inner Glass ----------------------------------------------------------------------------- 3-19
• Removing the Oven Door Gasket ------------------------------------------------------------------------------------- 3-20
• Removing the Side Panel ------------------------------------------------------------------------------------------------ 3-21
TABLE OF CONTENTS

(Page)
COMPONENT TEST ----------------------------------------------------------------------------- 4-1 ~ 4-7
• Convection Motor ----------------------------------------------------------------------------------------------------------- 4-1
• Door locking Motor ---------------------------------------------------------------------------------------------------------
4-2
• Micro Switch ------------------------------------------------------------------------------------------------------------------
4-2
• Oven Sensor -----------------------------------------------------------------------------------------------------------------
4-2
• Door switch -------------------------------------------------------------------------------------------------------------------
4-3
• Oven lamp --------------------------------------------------------------------------------------------------------------------
4-3
• Inner Broil heater ------------------------------------------------------------------------------------------------------------
4-3
• Outer Broil heater ------------------------------------------------------------------------------------------------------------
4-4
• Bake heater -------------------------------------------------------------------------------------------------------------------
4-4
• Conv. heater ------------------------------------------------------------------------------------------------------------------ 4-4
• Single surface unit(LR, RR) -------------------------------------------------------------------------------------------- 4-5
• Dual surface unit(LF, RF) ------------------------------------------------------------------------------------------------ 4-6
• Center Rear(CR): Warming Zone ------------------------------------------------------------------------------------- 4-7
COMPOSITION OF CONTROL
------------------------------------------------------------- 5-1 ~ 5-6
• Wiring Diagram
--------------------------------------------------------------------------------------------------------- 5-1~5-2
• Key Matrix ---------------------------------------------------------------------------------------------------------------------- 5-3
• Main PCB ----------------------------------------------------------------------------------------------------------------------- 5-5
• Oven Relay PCB -------------------------------------------------------------------------------------------------------------- 5-5
• Cook top display PCB ------------------------------------------------------------------------------------------------------- 5-6
• Key Pad ------------------------------------------------------------------------------------------------------------------------- 5-6
SVC TEST MODE ---------------------------------------------------------------------------------------- 6-1
CHECK THE FAILURE CODE
---------------------------------------------------------------- 7-1~7-2
• Check the Failure Code-------------------------------------------------------------------------------------------------- 7-1
• Failure Code Summary ----------------------------------------------------------------------------------------------------- 7-2
BASIC CHECK SUMMARY
--------------------------------------------------------------------- 8-1~8-2
CHECKING FLOW CHART BY FAILURE
--------------------------------------------- 9-1 ~ 9-25
• Power Failed(Dead), No display? ----------------------------------------------------------------------------- 9-1 ~ 9-3
• No heating, F9? ---------------------------------------------------------------------------------------------------- 9-4 ~ 9-8
• Cook top No heating?------------------------------------------------------------------------------------------- 9-9 ~ 9-12
• Door Lock System Failure, F10? --------------------------------------------------------------------------- 9-13 ~ 9-16
• Sensing Fail, F1, F2? ----------------------------------------------------------------------------------------- 9-17 ~ 9-18
• Oven hot, F6? -------------------------------------------------------------------------------------------------- 9-19 ~ 9-23
• Keypad Failure, F3 error? ------------------------------------------------------------------------------------- 9-24 ~ 9-25
APPENDIX ------------------------------------------------------------------------------------------------- 10-1
TROUBLE SHOOTING
---------------------------------------------------------------------
11-1 ~ 11-3
SCHEMATIC DIAGRAM
--------------------------------------------------------------------- 12-1~12-2
• STRIP CIRCUITS ------------------------------------------------------------------------------------------------- 12-3 ~12-6
EXPLODED VIEW ---------------------------------------------------------------------------- 13-1 ~ 13-8
REPLACEMENT PARTS LIST
---------------------------------------------------------- 14-1 ~ 14-3

1-1
GENERAL
IMPOR
IMPORT TANT SAFETY INSTRUCTIONS ANT SAFETY INSTRUCTIONS
Read and follow all instructions before using your oven to prevent the risk of fire, electric shock, injury to person, or
damage when using the range. This guide don’t cover all possible conditions that may occur. For further assistance
contact your service agent or manufacturer.
This is the safety alert symbol. This symbol alerts you to potential hazards that can kill or hunt you
and others. All safety messages will follow the safety alert symbol and either the word “WARNING”
or “CAUTION”. These word means :
!
This symbol will alert you to hazards or unsafe practices which could cause
serious bodily harm or death.
!
WARNING
This symbol will alert you to hazards or unsafe practices which could cause
bodily injury or property damage.
!
CAUTION
WARNING
• DO NOT step or sit on the door and install the Anti-Tip Bracket packed with range.
- The range could be tipped and injury might result from spilled hot liquid, food, or the range itself.
- If the range is pulled away from the wall for cleaning, service, or any other reason, ensure that the Anti-Tip
Device is properly reengaged when the range is pushed back against the wall.
• DISCONNECT power supply cord from the outlet before servicing.
• Replace all panels and parts before operating.
• RECONNECT all grounding devices.
- Failure to do so can result in severe personal injury, death or electrical shock.
• DO NOT touch heating elements or interior surfaces of oven.
- Heating element may be hot even though they are dark in color.
- Interior surfaces of an oven become hot enough to cause burns.
• During and after use, do not touch, or let clothing or other flammable materials
contact heating elements or interior surfaces of oven until they have had sufficient
time to cool.
-Other surfaces of the appliance may become hot enough to cause burns among these surfaces are oven vent
openings and surfaces near these openings, oven doors, and windows of oven doors.
• DO NOT store items of interest to children in cabinets above a range or on the back guard of a range.
- Children climbing on the range to reach items could be seriously injured.
!
CAUTION
• Always use Pot Holders or oven mitts when removing food from the Warming Drawer.
- You can be burned as cookware and plates will be hot.
• Be careful when you work on the electric range handling the sheet metal part.
- Sharp edge may be present and you can cut yourself.
• Be careful not to bend the fan blade
- Failure to do so can result in vibration, noise, and poor performance of convection when operating.
• Be careful not to scratch or chip the oven liner paint when you remove the oven light socket
in the next step.
• Turn power OFF before removing the Warming Drawer.
• Be careful when removing and lifting the door.
• DO NOT lift the door by the handle.
- Failure to do so can result in personal injury as the door is very heavy.
!

1-2
GENERAL
IMPOR
IMPORT TANT SAFETY INSTRUCTIONS ANT SAFETY INSTRUCTIONS
• Be sure your appliance is properly installed and grounded by a
qualified technician.
• Do not repair or replace any part of the appliance unless
specifically recommended in the manual.
All other servicing should be referred to a qualified technician.
• Always disconnect power to appliance before servicing by
removing the fuse or switching off the circuit breaker
To reduce the risk of tipping of the range, the range must be
secured by properly installed anti-tip devices. To check if the
bracket is installed properly,
- Warming drawer : grasp the top rear edge of the Range and
carefully attempt to tilt it forward.
verify that the anti-tip devices are engaged.
- Storage drawer : Remove drawer and verify leveling leg is
inserted into and fully secured by the anti-tip devices.
Refer to the installation manual for proper anti-tip bracket
installation.
WARNING
• DO NOT touch heating elements or
interior surfaces of oven.
- Heating element may be hot even though they are
dark in color.
- Interior surfaces of an oven become hot enough to
cause burns.
• During and after use, do not touch, or
let clothing or other flammable
materials contact heating elements or
interior surfaces of oven until they
have had sufficient time to cool.
-Other surfaces of the appliance may become hot
enough to cause burns among these surfaces are
oven vent openings and surfaces near these
openings, oven doors, and windows of oven
doors.
!
WARNING
• DO NOT store items of interest to
children in cabinets above a range or
on the back guard of a range.
- Children climbing on the range to reach items
could be seriously injured.
!
WARNING
• DO NOT step or sit on the
door and install the Anti-Tip
Bracket packed with range.
- The range could be tipped and injury
might result from spilled hot liquid,
food, or the range itself.
- If the range is pulled away from the
wall for cleaning, service, or any other
reason, ensure that the Anti-Tip Device
is properly reengaged when the range
is pushed back against the wall.
!

1-3
GENERAL
SURFACE COOKING UNITS
• Use Proper Pan Size – This appliance is equipped with one or more
surface units of different sizes. Select utensils having flat bottoms large
enough to cover the surface unit heating element. The use of
undersized utensils will expose a portion of the heating element to direct
contact and may result in ignition of clothing. Proper relationship of
utensil to burner will also improve efficiency.
• Never Leave Surface Units Unattended at High Heat Settings – Boil
overs may cause smoking and greasy spillovers may ignite.
• Make Sure Reflector Pans or Drip Bowls Are in Place – Absence of
these pans or bowls during cooking may subject wiring or components
underneath to damage.
• Protective Liners – Do not use aluminum foil to line surface unit drip
bowls or oven bottoms, except as suggested in the manual. Improper
installation of these liners may result in a risk of electric shock, or fire.
• Glazed Cooking Utensils – Only certain types of glass, glass/ceramic,
ceramic, earthenware, or other glazed utensils are suitable for range-
top service without breaking due to the sudden change in temperature.
• Utensil Handles Should Be Turned Inward and Not Extend Over
Adjacent Surface Units – To reduce the risk of burns, ignition of
flammable materials, and spillage due to unintentional contact with the
utensil, the handle of a utensil should be positioned so that it is turned
inward, and does not extend over adjacent surface units.
• Do Not Soak Removable Heating Elements – Heating elements
should never be immersed in water.
• Be sure you know which control pads operate each surface unit.
Make sure you turned on the correct surface unit.
IMPOR
IMPORT TANT SAFETY INSTRUCTIONS ANT SAFETY INSTRUCTIONS
SELF-CLEAN OVENS
• Do Not Clean Door Gasket – The door gasket is essential for a
good seal. Care should be taken not to rub, damage, or move the
gasket.
• Do Not Use Oven Cleaners – No commercial oven cleaner or
oven liner protective coating of any kind should be used in or
around any part of the oven.
• Clean in the self-clean cycle only parts listed in this manual.
Before self-cleaning the oven, remove the broiler pan and any
utensils from the oven.
• Never keep pet birds in the kitchen – the health of birds is
extremely sensitive to the fumes released during an oven self-
clean cycle. Fumes may be harmful or fatal to birds. Move birds to
well-ventilated room.
• Important Instruction – In the event the self-clean mode “F”
code goes on, or three long beeps sound, oven is malfunctioning
in the self-clean mode. Turn off or disconnect appliance from
power supply and have serviced by a qualified technician.
VENTILATING HOODS:
• Clean Ventilating Hoods Frequently – Grease should not
be allowed to accumulate on hood or filter.
• When flaming foods under the hood, turn the fan on.
OVEN
• Use Care When Opening Door – Let hot air or steam escape
before you remove or replace food in the oven
• Do Not Heat Unopened Food Containers – Build-up of pressure
may cause container to burst and result in injury.
• Keep Oven Vent Ducts Unobstructed – the oven vent is located
above the left rear surface unit. this area could become hot during
oven use. Never block this vent and never place plastic or heat-
sensitive items on vent
• Placement of Oven Racks – Always place oven racks in desired
location while oven is cool. If rack must be moved while oven is
hot, do not let potholder contact hot heating element in oven.
• Do Not allow aluminum foil or meat probe to contact heating
elements.
GLASS/CERAMIC COOKING SURFACES
• Do Not Cook on Broken Cook-Top – If cook-top should break,
cleaning solutions and spillovers may penetrate the broken cook-
top and create a risk of electric shock. Contact a qualified
technician immediately.
• Clean Cook-Top With Caution – If a wet sponge or cloth is used
to wipe spills on a hot cooking area, be careful to avoid steam
burn. Some cleaners can produce noxious fumes if applied to a hot
surface.
DEEP FAT FRYERS:
• Use extreme caution when moving the grease kettle or disposing
of hot grease.
• Do Not Leave Children Alone - Children should not be left alone or
unattended in area where appliance is in use. They should never be
allowed to sit or stand on any part of the appliance.
• Never Use Your Appliance for Warming or Heating the Room.
• Storage in or on Appliance – Flammable materials should not be stored
in an oven or near surface units. Be sure all packing materials are removed
from the appliance before operating it. Keep plastics, clothes and paper
away from parts of the appliance that may become hot
• Wear Proper Apparel – Loose-fitting or hanging garments should never
be worn while using the appliance.
• Do Not Use Water on Grease Fires – Turn off oven to avoid spreading
the flame. Smother the fire or flame by closing the door or use dry
chemical, baking soda or foam- type extinguisher.
• Use Only Dry Potholders – Moist or damp potholders on hot surfaces
may result in burns from steam.
Do not let potholder touch hot heating elements. Do not use a towel or
other bulky cloth.
WARNING
• DISCONNECT power supply cord from
the outlet before servicing.
• Replace all panels and parts before
operating.
• RECONNECT all grounding devices.
- Failure to do so can result in severe personal
injury, death or electrical shock.
!

1-4
GENERAL
The Model/Serial Number label and Tech Sheet locations are shown below.
Model & Serial
Number Location
MODEL & SERIAL NUMBER LABEL
MODEL & SERIAL NUMBER LABEL
AND TECH SHEET LOCA
AND TECH SHEET LOCATIONS TIONS
Tech Sheet Location
(On Rear Cover)

1-5
GENERAL
SPECIFICA
SPECIFICATIONS TIONS
Model Number LRE3085ST
Category Convection
Overall
Control
Cooktop
Power
Oven
Drawer
Dimensions
(inch)
Power
Width
Installation type
Color availability
Oven
Cooktop
Display
Electronic clock & timer
Control lock capability
Audible preheat signal
Special function
Material
# of element
LR
RR
CR
LF
RF
Capacity(cu.ft)
Broil element
Bake element
Convection System
-Convection element
# of Racks
Interior oven light
Proof
Cook & warm
Favorites
Easy clean
Door lockout
Type
Element
Warming rack
Oven Interior(W x H x D)
Exterior - Width
Exterior - Height
Exterior - Depth
Net weight: Lbs (Kg)
Rating
30"
Freestanding
STS
Keypad(Membrane)
Keypad(Membrane)
Scroll VFD
Yes
Yes
Yes
Option(6 categories)
1. Convection auto conversion 0n/0ff
2. Thermostat Adjustment
3. Language -English, Spanish, French
4. Preheating alarm light On/Off
5. Beeper Volume
(loud, normal, low, mute)
6. Temperature unit (˚F / ˚C)
Ceramic glass
5
6"-1,200
6"-1,200
warming zone
Dual(6”/9”-1,400/3,200 watts)
Dual(6”/9”-1,400/3,200 watts)
6.3
Inner/Outer 1,600/2,400 watts
3400 watts
Yes
Yes(700 watts, 240V)
4(2 standard, 1 offset, 1 drawer)
120V, 40Watts
Yes
Yes
Yes
1. Bread 2. Meat 3. Chicken
Yes
Yes
Warming drawer
500 watts
Yes
24 1/2x 20 1/4x 19 3/8
29 7/8
36 (cooktop), 47 5/8 (backguard top)
25 11/16 (Door), 28 (with handle)
187.8 lbs (85.2kg)
15.3Kw(120/240V) / 11.5Kw(120/208V)

2-1
USING YOUR RANGE
Rating Label
Model numbers are recorded on the rating label.
Rating label is located on the lower front left corner
of the oven frame. It can be seen by opening the
storage drawer or warming drawer. Before ordering
parts, write down the correct model and serial
number from rating label. This avoids incorrect
shipments and delays. Please refer to parts
reference material when ordering replacement parts.
Functional Operation
Bake Mode
Top and hidden bottom elements operate during
bake. Bake can be used to cook foods which are
normally baked. Oven must be preheated.
Broil Mode
Top element operates during broil. Broil can be
used to cook foods which are normally broiled. All
foods should be turned at least once except fish,
which does not need to be turned.
Convection Bake / Roast Mode
Upper element, lower element, Rear element(some
model) and fan operate during convection bake.
Convection bake should be used for cooking
casseroles and roasting meats. Oven should be
preheated for best results when using convection
bake. Pans do not need to be staggered. Cooks
approximately 25% quicker than bake.
Cooking Guide
Refer to the owners manual for recommendations
of times and temperatures. Times, rack position,
and temperatures may vary depending on
conditions and food type. For best results, always
check food at minimum time. When roasting,
choose rack position based on size of food item.
GENERAL INFORMA
GENERAL INFORMATION TION
Broil element
Hidden bake
element
Broil element
Convection
element
Hidden bake
element
Broil element
Hidden bake
element

2-2
USING YOUR RANGE
CONTROL P
CONTROL PANEL FEA ANEL FEATURES TURES
1. BAKE PAD: Press to select the bake function.
2. BROIL PAD: Press to select the broil function.
3. CONVECTION BAKE PAD: Press to select baking
with the convection function.
4. CONVECTION ROAST PAD: Press to select
roasting with the convection function.
5. NUMBER PADS: Use to set any function requiring
numbers such as the time of day on the clock, the
timer, the oven temperature, the start time and
length of operation for timed baking.
6. START PAD: Must be pressed to start any cooking
or cleaning function.
7. CLEAR/OFF PAD: Press to cancel all oven
operations except the clock and timer.
8. WARM/PROOF PAD
• Press to keep cooked foods warm.
• Press to select a warm environment useful for
rising yeast-leavened produts.
9. SPEED BROIL: Press to select the SPEED BROIL
function.
10. FAVORITES PAD: Press to set favorite cooking.
11. KIDS MEAL: Press to select the Kids Meal function
12. CLOCK PAD: Press before setting the time of day.
13. COOK TIME PAD: Press and then use the number
pads to set the amount of time you want your food
to cook. The oven will shut off when the cooking
time has run out.
14. START TIME PAD: Use along with BAKE, CONV.
BAKE, CONV. ROAST, COOK TIME and SELF
CLEAN pads to set the oven to start and stop
automatically at a time you set.
15. TIMER ON/OFF PAD: Press to select the timer
feature.
16.
OVEN LIGHT PAD: Press to turn the oven light on or off.
17. SELF CLEAN PAD: Press to select self-cleaning
function. See page 2-4 for pad operation.
18. EASY CLEAN: Use to select the Easy Clean.
19. SETTING: Press to set 6 types of option category.
20. DISPLAY
Single surface unit
: Right Rear, Left Rear
Dual surface unit : Right Front, Left Front
Warming Zone : Center Rear
Warming Drawer
A
B
C
D

2-3
USING YOUR RANGE
To turn on a single surface unit
(Right Rear, Left Rear)
1. Press ON/OFF pad for the desired element.
2. Press ( + / – ) pad to choose the desired setting.
To turn on a dual surface unit
(Right Front, Left Front)
1. Press ON/OFF pad
2. Press the SELECT pad as needed to select
the desired burner size. When first selected, 9”
size is on. The light above the SELECT pad
indicates which size surface unit is on.
2. Press ( + / – ) pad to choose the desired setting.
Note:
• Each time a pad is pressed a beep will sound.
• The power level decreases or increases by 0.5
from 9.0 through 3.0. (by 0.2 from 3.0 through 1.0)
• Lo is the lowest power level available.
• “HS” will appear when the unit is hot to touch
To set the warming zone control
1. Press ON/OFF pad at the warming zone.
2. Press ( + / – ) pad to choose the desired setting.
Note:
• Each time a pad is pressed a beep will sound.
• The controls for the warming zone allow for 5
different heat settings : Lo~Hi
• “HS” will appear when the unit is hot to touch.
1. SETTING THE CLOCK
2. START, CLEAR/OFF AND ON/OFF PAD
1. Touch START pad to start oven.
2. Touch CLEAR/OFF pad to cancel a program
during cooking or Erase during programming.
3. Touch ON/OFF pad to start or cancel the
surface unit.
3. TO TURN ON/OFF THE OVEN LIGHT
The oven light automatically turns ON when the
door is opened. The oven light may also be
manually turned ON or OFF by pressing the
OVEN LIGHT pad
Note: The oven light cannot be turned on if self-clean feature
is active.
4. TIMER ON/OFF
To cancel timer at any time, touch TIMER ON/OFF pad.
Note:
1. If you press TIMER ON/OFF pad once, this allows you to
select "minutes"
(for example: if you press “5” and “6”, it means 56 minutes)
2. If you press TIMER ON/OFF pad twice, this allows you to
select "seconds"
(for example: if you press “5” and “6”, it means 56 seconds)
5. SETTING PAD: 6 types of category
1) CONVECTION AUTO CONVERSION
1. Press SETTING pad once
2. Press “1” pad for ENABLE
or “2” pad for DISABLE
3. Press START pad.
2) THERMOSTAT ADJUSTMENT
The oven temperature can be adjusted from
-35°F (-19°C) to 35°F (19°C).
Note: The thermostat adjustments made with this feature will
just change Bake, Convection Bake and Convection
Roast temperature.
To increase the oven temperature:
1. Press SETTING pad twice
2. Press the desired temperature
3. Press START pad.
To decrease the oven temperature:
1. Press SETTING pad twice
2. Press the desired temperature
3. Press the SETTING pad once
4. Press START pad
3) LANGUAGE SELECTION (English or
Spanish or French)
1. Press SETTING pad 3 times
2. Press “1” pad for ENGLISH
or “2” pad for SPANISH
or “3” pad for FRENCH
3. Press START pad
4) PREHEATING ALARM LIGHT ON/OFF
1. Press SETTING pad 4 times
2. Press “1” pad for ON
or “2” pad for OFF
3. Press START pad
CLEAR
/OFF CLOCK Desired Time START
TIMER
ON/OFF
Desired
time
TIMER
ON/OFF
A
B
C

5) BEEPER VOLUME
1. Press SETTING pad 5 times
2. Press “1” pad for loud level,
“2” pad for normal level,
“3” pad for low level,
“4” pad for mute level,
3. Press START pad
6) TEMPERATURE UNIT (°F or °C)
1. Press SETTING pad 6 times
2. Press “1” pad for °F
or “2” pad for °C
3. Press START pad
6. BAKE, TIMED BAKE, DELAYED TIMED BAKE
* This feature can also be used with the:
CONVECTION BAKE and CONVECTION ROAST
modes.
7. BROIL / SPEED BROIL
8. FAVORITES
9. WARM/PROOF
10. OVEN LOCKOUT
11. CHANGING HOUR MODE ON CLOCK
(12HR, 24HR)
12. SELF-CLEAN
13. Easy clean
2-4
USING YOUR RANGE
START
FAVORITES
: Once →Bread
: Twice →Meat
: 3 times →Chicken
START
SELF CLEAN
: Once →4-hour
: Twice →5-hour
: 3 times →3-hour
START
WARM
/PROOF
Press and hold the START pad for 3 seconds
(to activate or reactivate LOCKOUT)
Press and hold the CLOCK pad for 3 seconds
Press “1” pad for 12-hour,
“2” pad for 24-hour. START
START
TIME
Desired
start time START
BAKE Desired
temperature START
COOK
TIME Desired time START
START
TIME
Desired
start time START
START
BROIL or SPEED BROIL : once →Hi
: twice →Low
EASY
CLEAN START

2-5
USING YOUR RANGE
To Operate the Warming Drawer
The purpose of the Warming Drawer
is to keep hot cooked foods at serving
temperature. Always start with hot
food. It is not recommended to heat
cold food in the Warming Drawer.
All food placed in the Warming
Drawer should be covered with a lid
or aluminum foil to maintain quality.
Do not use plastic wrap to cover food.
Plastic may melt onto the drawer and be
very difficult to clean. Use only utensils
and cookware recommended for oven
use in the Warming Drawer.
To set the warming drawer control
1. Press the WARMING
DRAWER SET/OFF
button(near the number
buttons). The indicator light
will flash. (If no further
buttons are pressed within 25
seconds, the display will
clear.)
2. Use the number buttons to
set the power level. 1 for
LOW, 2 for MEDIUM, and 3
for HIGH
3. When the food is ready, or to
cancel, press the WARMING
DRAWER SET/OFF button.
Note: The Warming Drawer will shut off
automatically after 3 hours.
W
WARMING DRA ARMING DRAWER WER
Warming drawer rack in position
Warming
Drawer
Control
CAUTION
• Always use Pot Holders or oven
mitts when removing food from
the Warming Drawer.
- You can be burned as cookware and
plates will be hot.
!

3-1
COMPONENT ACCESS
This section instructs you on how to service each component inside the range. The components and their
locations are shown below.
COMPONENT LOCA
COMPONENT LOCATIONS TIONS
Broil Heater
Convection Heater
Oven Light
Door Switch
Surface Elements
Door Locking Motor
& Micro Switch
Main PCB
Hinge Hanger
Warming Drawer
Heater
Oven Sensor
Door Latch Assembly
Convection Motor
Oven Relay PCB
Bake Heater
Broil Heater
Cook Top
Display PCB

6. Remove the 5 screws and wirings from Main
PCB and Main PCB can be detached from the
support assembly.
7. Remove the 3 screws from controller's lower side
and pull the support assembly out of the
controller by using the same method such as
below pictures.
Pull 3 hooks out of
the controller and the
PCB support can be
detached easily.
8. Remove 4 screws from Cooktop Display PCB
and the PCB can be detached from the support.
3-2
COMPONENT ACCESS
1. Turn off the electrical supply going to the range.
2. Pull the range away from the wall so that you can
access the rear panel.
3. Remove 2 screws from the lamp cover and
remove the lamp cover.
4. Remove 12 screws from the controller cover and
remove the controller cover.
5. Remove the 4 screws from the back cover and
remove the back cover
REMOVING THE LAMP
REMOVING THE LAMP, CONTROLLER, BACK COVER AND , CONTROLLER, BACK COVER AND
CONTROLLER ASSEMBL
CONTROLLER ASSEMBLY(MEMBRANE, PCB, SUPPOR Y(MEMBRANE, PCB, SUPPORT) T)
WARNING
• DISCONNECT power supply cord
from the outlet before servicing.
• Replace all panels and parts before
operating.
• RECONNECT all grounding devices.
- Failure to do so can result in severe personal
injury, death or electrical shock.
!
CAUTION
• Be careful when you work on the
electric range handling the sheet
metal part.
- Sharp edge may be present and you can cut
yourself.
!
Control Cover
Lamp Cover
Back Cover
Main PCB
3 hooks
Cooktop Display PCB PCB support
For Model : LRE3085ST /00

3-3
9. Remove a cooktop plate assembly (See the page
3-6) and remove 4 screws from side panel.
10. Remove 4 screws from the controller assembly
(back guard R/L)
11. Remove 6 screws from the controller assembly.
12. For serving the KEY Membrane, the controller sub
assembly should be separated in whole. Both
Control-panel and KEY Membrane are 1 service
part.
COMPONENT ACCESS

3-4
6. Remove 3 screw and unplug wiring from Main
PCB to pull it out. Cooktop display PCB can be
removed after remove Main PCB.
7. Remove the 3 screws from controller's lower side
and pull the support assembly out of the
controller by using the same method such as
below pictures.
Remove 6 screw and
pull 3 bracket out of
the controller and the
PCB support can be
detached easily.
8. For servicing the Key Membrane, the key pad
sub assembly should be separated in whole.
Both PCB supporter and Key Membrane are 1
service part.
COMPONENT ACCESS
1. Turn off the electrical supply going to the range.
2. Pull the range away from the wall so that you can
access the rear panel.
3. Remove 2 screws from the lamp cover and
remove the lamp cover.
4. Remove 12 screws from the controller cover and
remove the controller cover.
5. Remove the 4 screws from the back cover and
remove the back cover
REMOVING THE LAMP
REMOVING THE LAMP, CONTROLLER, BACK COVER AND , CONTROLLER, BACK COVER AND
CONTROLLER ASSEMBL
CONTROLLER ASSEMBLY(MEMBRANE, PCB, SUPPOR Y(MEMBRANE, PCB, SUPPORT) T)
WARNING
• DISCONNECT power supply cord
from the outlet before servicing.
• Replace all panels and parts before
operating.
• RECONNECT all grounding devices.
- Failure to do so can result in severe personal
injury, death or electrical shock.
!
CAUTION
• Be careful when you work on the
electric range handling the sheet
metal part.
- Sharp edge may be present and you can cut
yourself.
!
Control Cover
Lamp Cover
Back Cover
Main PCB
Cooktop display PCBB
For Model : LRE3085ST /01

3-5
COMPONENT ACCESS
REMOVING PCBs (MAIN PCB AND RELA
REMOVING PCBs (MAIN PCB AND RELAY PCB) Y PCB)
1. Turn off the electrical supply going to the range.
2. Pull the range away from the wall so that you can
access the rear panel.
3.Remove the lamp, controller and back cover.
(See the page 3-2)
4. There are 2 PCBs. When you check PCB, check
the proper PCB in default mode and check Main
PCB.
NOTE: Refer to the page 5-1~5-6 for
composition of control board.
Main PCB
Relay PCB
WARNING
• DISCONNECT power supply cord
from the outlet before servicing.
• Replace all panels and parts before
operating.
• RECONNECT all grounding devices.
- Failure to do so can result in severe personal
injury, death or electrical shock.
!
CAUTION
• Be careful when you work on the
electric range handling the sheet
metal part.
- Sharp edge may be present and you can cut
yourself.
!

CERAMIC GLASS COOKTOP REMOVAL
Step. 1
Unplug the cord or disconnect power
Step. 2
Remove lamp, controller and back cover
(See the page 3-2)
Step. 3
Remove wiring from the
cooktop assembly.
Step. 4
Open oven door and
remove the 3screws located
at the front of the cook-top,
then close the door.
Step. 5
Lift up the cooktop
assembly and turn the
cooktop assembly over
(protect the cooktop
surface).
3-6
COMPONENT ACCESS
REMOVING THE SURF
REMOVING THE SURFACE ELEMENTS ACE ELEMENTS
AND THE CERAMIC GLASS COOKT
AND THE CERAMIC GLASS COOKTOP OP
WARNING
• DISCONNECT power supply cord
from the outlet before servicing.
• Replace all panels and parts before
operating.
• RECONNECT all grounding devices.
- Failure to do so can result in severe personal
injury, death or electrical shock.
!
3 Screws
Step. 6
To remove the surface
elements
a) Remove the wires from
the element and limiter
terminals.
b) Remove the element
brackets for the element you are servicing and
the element can be detached.
REASSEMBLY NOTE: When you reinstall the
element, make sure that the wires are inserted into
the correct tap and that the brackets are secured
firmly. When wiring, refer to the technical card in
order to prevent wires and connectors from
mismating.
